Nokia 6280 User Guide

924XXXX

Issue 1

DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product RM-78 is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from http://www.nokia.com/phones/declaration_of_conformity/.

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of-life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal waste.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Visual Radio, Nokia Connecting People, and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Nokia tune is a sound mark of Nokia Corporation.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommer cial use in co nnection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connec tion with MPEG- 4 video provided by a licensed vid eo provider. No license is granted or shall be implied for any other use. Additional information including that relating to promotional, internal and commercial uses may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of th is document are pr ovided "as is". Ex cept as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability a nd fitness for a particu lar purpose, are made i n relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

This device may contain commodities, technology or software subject to export laws and regulations from the US and oth er countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telep hone if such interference cannot be elimin ated. If you require assistance , contact your local service fac ility. This device complie s with part 15 of the FCC rules. Operation is subject to the follo wing two conditions: (1) This device may not cause harmful in terference, and (2) th is device must accept an y interference receiv ed, including interfe rence that may cause undesired operation.

924XXXX/Issue 1

Contents

For your safety.......................... 6

General information................. 9

Access codes............................................ 9

Configuration settings service ........ 10

Download content and applications 10 Nokia support and contact

information........................................... 11

1. Get started ......................... 12

Install the SIM card and

the battery ............................................ 12

Install a memory card........................ 13

Charge the battery.............................. 14

Switch the phone on and off........... 15

Open the keypad ................................. 16

Normal operating position ............... 16

2. Your phone......................... 17

Keys and parts...................................... 17

Standby mode ...................................... 18

Keypad lock (keyguard) ..................... 21

3. Call functions..................... 22

Make a voice call ................................ 22

Answer or reject a voice call ........... 23

Options during a voice call .............. 24

Make a video call ................................ 24

Answer or reject a video call ........... 25

Options during a video call .............. 25

4. Write text........................... 26

Settings.................................................. 26

Predictive text input .......................... 26

Traditional text input......................... 27

5. Navigate the menus .......... 28

6. Messaging .......................... 29

Text messages (SMS).......................... 29

SIM messages....................................... 30

Multimedia messages ........................ 31

Memory full .......................................... 34

Folders.................................................... 34

Flash messages .................................... 34

Audio messages ................................... 35

Instant messaging............................... 36

E-mail application .............................. 41

Voice messages.................................... 44

Info messages ...................................... 44

Service commands .............................. 44

Delete messages .................................. 44

Message settings................................. 45

7. Contacts.............................. 49

Search for a contact .......................... 49

Save names and phone numbers.... 49

Save numbers and text items .......... 49

Copy contacts ...................................... 50

Edit contact details ............................ 50

Delete contacts.................................... 50

My presence ......................................... 51

Subscribed names ............................... 52

Business cards...................................... 53

Settings.................................................. 53

Groups.................................................... 54

Speed dials............................................ 54

Service and my numbers................... 54

8. Call register ........................ 55

9. Settings............................... 56

Profiles ................................................... 56

Themes ................................................... 56

Tones....................................................... 56

Display.................................................... 57

Time and date ...................................... 58

My shortcuts ........................................ 58

Connectivity ......................................... 60

Contents

Call........................................................... 66

Phone ...................................................... 66

Enhancements ...................................... 67

Configuration........................................ 68

Security .................................................. 69

Restore factory settings..................... 70

10.Operator menu.................. 70

11.Gallery ............................... 71

Format memory card .......................... 71

12.Media ................................ 72

Camera ................................................... 72

Media player ......................................... 73

Music player.......................................... 74

Radio ....................................................... 75

Voice recorder....................................... 77

Equalizer................................................. 78

Stereo widening ................................... 78

13.Push to talk....................... 79

Connect to the PTT service ............... 79

Make and receive a PTT call ............. 80

Callback requests................................. 81

Add a one-to-one contact ................ 82

PTT channels ......................................... 83

PTT settings ........................................... 84

14.Organizer........................... 86

Alarm clock............................................ 86

Calendar ................................................. 87

To-do list................................................ 88

Notes....................................................... 88

Calculator .............................................. 88

Countdown timer ................................ 89

Stopwatch ............................................. 89

15.Applications ...................... 91

Games ..................................................... 91

Collection............................................... 91

16.Web.................................... 93

Basic steps to access and

use services ........................................... 93

Set up browsing ................................... 93

Connect to a service........................... 93

Browse pages........................................ 94

Bookmarks ............................................. 95

Appearance settings ........................... 96

Security settings .................................. 97

Download settings .............................. 97

Service inbox ........................................ 97

Cache memory...................................... 98

Browser security .................................. 98

17.SIM services.................... 100

18.PC connectivity .............. 101

Nokia PC Suite................................... 101

EGPRS, HSCSD, and CSD................. 101

Data communication applications 101

19.Battery information....... 102

Charging and discharging .............. 102

Nokia battery authentication

guidelines............................................ 103

20.Technical Information ... 105

Care and maintenance ........ 106

Additional safety

information.......................... 107

Appendix.............................. 111

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Do not use the phone at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the phone where blasting is in progress.

USE SENS IBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

For your safety

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the end key as many times as needed to clear the display and return to the start screen. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

■ About your device

The wireless device described in this guide is approved for use on the EGSM 900; GSM 1800 and,1900; and WCDMA2100 networks. Contact your service provider for more information about networks.

When you use the features in this device, obey all laws and respect privacy and legitimate rights of others.

When you take and use images or video clips, obey all laws and respect local customs as well as privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

■ Network services

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services. Network services are designated in this guide by .

For your safety

Your service provider may have requ ested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Your device may also have been specially configured. This configuration may include changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as multimedia messaging (MMS), browsing, e-mail application, instant messaging, presence-enhanced contacts, remote synchronization, and content downloading using the browser or MMS, require network support for these technologies.

■ Shared memory

The following features in this device may share memory: gallery, contacts, text messages, multimedia messages, instant messages, e-mail, calendar, to-do notes,

Java

games and applications, and note application. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. For example, saving many Java applications may use all of the available memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features, such as text messages, may have a certain amount of memory specially allotted to them in addition to the memory shared with other features.

■ Enhancements

A few practical rules about accessories and enhancements.

• Keep all accessories and enhancements out of the reach of small children.

• When you disconnect the power cord of any accessory or enhancement, grasp

and pull the plug, not the cord.

• Check regularly that enhancements installed in a vehicle are mounted and

are operating properly.

• Installation of any complex car enhancements must be made by qualified

personnel only.

General information

■ Access codes

Security code

The security code (5 to 10 digits) helps to protect your phone against unauthorized use. The preset code is 12345. To change the code, and to set the phone to request the code, see “Security,” p. 69.

If you enter an incorrect security code five times in succession, the phone ignores further entries of the code. Wait for 5 minutes, and enter the code again.

PIN codes

The personal identification number (PIN) code and the universal personal identification number (UPIN) code (4 to 8 digits) help to protect your SIM card against unauthorized use. See “Security,” p. 69. The PIN code is usually supplied with the SIM card. Set the phone to request the PIN code each time the phone is switched on.

The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required for some functions.

The module PIN is required to access the information in the security module. See “Security module,” p. 99. The module PIN is supplied with the SIM card if the SIM card has a security module in it.

The signing PIN is required for the digital signature. See “Digital signature,” p. 100. The signing PIN is supplied with the SIM card if the SIM card has a security module in it.

PUK codes

The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) is required to change a blocked PIN code and UPIN code, respectively. The PUK2 code is required to change a blocked PIN2 code.

General information

If the codes are not supplied with the SIM card, contact your service provider for the codes.

Barring password

The barring password (4 digits) is required when you use the Call barring

service. See “Security,” p. 69. You can obtain the password from your

service provider.

If you enter an incorrect barring password three times in succession, the password is blocked. Contact your service provider or network operator.

■ Configuration settings service

Before you use multimedia messaging, instant messaging and presence, push to talk, e-mail, synchronization, streaming, and the browser, you must have the proper configuration settings on your phone. You may receive the settings directly as a configuration message, which you save to your phone. For more information on availability, contact your network operator, service provider, or nearest authorized Nokia dealer.

When you have received the settings as a configuration message, and the settings are not automatically saved and activated, Configuration

settings received is displayed.

To save the received settings, select Show > Save. If the phone requests

Enter set tings’ PIN:, enter the PIN code for the settings, and select OK. To

receive the PIN code, contact the service provider that supplies the settings.

If no settings are saved yet, these settings are saved and set as default configuration settings. Otherwise, the phone asks Activate saved

configuration settings?.

To discard the received settings, select Show > Discard.

■ Download content and applications

You may be able to download content, such as themes, tones, and video clips, to the phone (network service). Select the download function (for example, in the Gallery menu). To access the download function, see the

General information

respective menu descriptions. For availability of different services, pricing, and tariffs, contact your service provider.

Important: Use only services that you trust and that offer adequate security and protection against harmful software.

■ Nokia support and contact information

Check www.nokia.com/support or your local Nokia Web site for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

On the Web site, you can get information on the use of Nokia products and services. If you need to contact customer service, check the list of local Nokia Care contact centers at www.nokia.com/customerservice.

For maintenance services, check your nearest Nokia Care services location at www.nokia.com/repair.

Get started

1. Get started

■ Install the SIM card and the battery

Always switch the device off and disconnect the charger before removing the battery.

Keep all SIM cards out of the reach of small children.

For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.

This device is intended for use with the BP-6M battery.

The SIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

1. With the back of the phone facing

you, slide the back cover to remove it from the phone (1).

2. To remove the battery, lift it as

shown (2).

3. To release the SIM card holder,

gently pull the locking clip of the card holder, and open it (3).

Get started

4. Insert the SIM card into the SIM card holder (4). Make sure that the SIM card is properly inserted and that the golden contact area on the card is facing downwards.

Close the SIM card holder, and press it until it snaps into position.

5. Replace the battery (5).

6. Slide the back cover into place (6).

■ Install a memory card

Your phone’s miniSD card contains pre-loaded ringtones, themes, tones, and graphics. If you delete, reload, or replace this card, these functions/features may cease to function properly.

Use only compatible miniSD cards with this device. Other memory cards, such as reduced size MMCs, do not fit in the memory card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted.

You can use a memory card to extend the memory of Gallery. See “Gallery,” p. 71.

You can insert or change the memory card without switching the phone off.

Get started

Important: Do not remove the memory card in the middle of an

operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

To insert the memory card, open the memory card holder as shown (1). Place the memory card in the card holder (2). Make sure that the memory card is properly inserted and that the golden contact area on the card is facing upwards. Close the memory card holder.

You can use the memory card to save your multimedia files, such as video clips, sound files, and images, in Gallery.

To format the memory card, see “Format memory card,” p. 71.

■ Charge the battery

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from the AC-4, AC-3, or DC-4 charger.

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

Get started

1. Connect the charger to a wall socket.

2. Connect the lead from the charger to the CA-44 charging adapter (1), and the adapter to the socket on the bottom of your phone (2).

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The charging time depends on the charger and the battery used.

■ Switch the phone on and off

Warning: Do not switch the phone on when wireless phone use is

prohibited or when it may cause interference or danger.

Press and hold the power key as shown.

If the phone asks for a PIN or UPIN code, enter the code, and select OK.

You can switch on the phone in demo mode without a SIM card inserted. In this mode all bearer-independent features are available and you can, for example, make emergency calls.

Plug and play service

When you switch on your phone for the first time, and the phone is in the standby mode, you may be asked to get the configuration settings from your service provider (network service). Confirm or decline the query. See Connect to serv. support in “Configuration,” p. 68 and “Configuration settings service,” p. 10.

Get started

■ Open the keypad

To open the keypad, slide the phone as shown.

■ Normal operating position

Use the phone only in its normal operating position.

Your device has an internal antenna.

Note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the device optimizes the antenna performance and the battery life.

2. Your phone

■ Keys and parts

•Power key (1)

• Volume keys (2)

• Mirror (3)

• Camera lens (4)

• Camera light (5)

• Camera key (6)

• Front camera (7)

• Earpiece(8)

• Left, middle, and right selection keys (9)

• 4-way navigation key (10)

• Call key (11)

• End key (12)

• Number keys (13).

Your phone

• Push to talk key (14)

• Infrared (IR) port (15)

• Memory card slot (16)

• Charger connector (17)

• Enhancements connector (18)

Your phone

■ Standby mode

When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.

• Signal strength of the cellular network (1)

• Battery charge level (2)

• Indicators (3)

• The name of the network or the operator logo (4)

• Clock (5)

• Active standby (6). See “Active standby,” p. 18.

• The left selection key (7) is Go to or a shortcut to another function. See “Left selection key,” p. 58.

• The middle selection key (8) mode is Menu.

• The right selection key (9) may be Names to access the list of contacts in the Contacts menu, an operator-specific name to access an operator-specific Web site, or a shortcut to a function that you selected. See “Right selection key,” p. 59.

Active standby

In active standby the phone can display separate content item windows, such as shortcuts (1), audio functions (2), the calendar (3), and a user note (4). To select whether the active standby is shown, see Active

standby in “Standby settings,” p. 57.

When the active standby is idle, to access the menu structure, press the middle selection key Menu (5). To access the features in active standby, press the navigation key up or down.

Your phone

To change the key to access the navigation mode, see Enabling active

standby in “Standby settings,” p. 57. When the arrow indicators (6) are

shown, you can scroll the item left and right.

Content items in navigation mode

Shortcut bar — To select a shortcut, scroll to the desired function, using

left/right navigation key, and select it.

To change or organize the shortcuts when in the navigation mode, select Options > Active standby > My active standby > Options >

Personalise > Options > Select links or Organise links.

Audio applications — To switch on the radio or the music player, scroll to

and select it. To change a track in the music player or a channel in the radio, scroll left or right. To start the radio channel search, scroll and hold left or right.

Calendar — To view today’s notes, select the desired one. To view the

notes for the previous or next days, scroll left or right.

My note — To enter a note, select the content window, write your note,

and save it.

My presence — To change your presence status information, select the

content item.

Countdown timer — To start the countdown timer, select the content

item. The remaining time with a note is shown.

General indicators — To show standby indicators, such as date, cell info

display, info messages, PTT default group name, and closed user group index. The date is shown if the calendar is not selected as active standby content.

Standby mode shortcuts

• To access the list of dialed numbers, press the call key once. See “Make a voice call,” p. 22.

• To call your voice mailbox (network service) when you have saved your voice mailbox number in the phone, press and hold 1.

• To connect to a browser service, press and hold 0.

Your phone

• To set shortcut functions for the navigation key, see Navigation key in “My shortcuts,” p. 58.

• To change the profile, briefly press the power key to open the list of profiles. Scroll to the desired profile, and select it.

Power saver

To set the power saving function On, see Pow er sa ver in “Display,” p. 57.

Indicators

You have unread messages in the Inbox folder.

You have unsent, canceled, or failed messages in the Outbox folder.

The phone registered a missed call.

/ Your phone is connected to the instant messaging service, and

the availability status is online or offline.

You received one or several instant messages, and you are connected to the instant messaging service.

The keypad is locked.

The phone does not ring for an incoming call or text message. See also “Tones,” p. 56.

The alarm clock is set to On.

The countdown timer is running.

The stopwatch is running in the background.

/ The phone is registered to a GPRS, EGPRS, or WCDMA network.

/ A packet data connection is established.

/ The packet data connection is suspended (on hold), for example,

if there is an incoming or outgoing call during a packet data dial-up connection.

Your phone

When the infrared connection is activated, the indicator is shown continuously.

A Bluetooth connection is active.

If you have two phone lines, the second phone line is selected.

All incoming calls are diverted to another number.

The loudspeaker is activated, or the music stand is connected to the phone.

Calls are limited to a closed user group.

The timed profile is selected.

, , , or

A headset, hands-free, loopset, or music stand enhancement is connected to the phone.

/ A push to talk connection is active/suspended.

■ Keypad lock (keyguard)

To prevent the keys from being accidentally pressed, select Menu, and press

within 3.5 seconds to lock the keypad; or close the slide, and

select Lock.

To unlock the keypad, open the slide, or select Unlock > OK. If the slide is open, select Unlock, and press

keyguard is set On, select Unlock, press

To answer a call when the keyguard is on, press the call key. When you end or reject the call, the keypad automatically locks.

For Automatic keyguard and Security keyguard, see “Phone,” p. 66.

When the keyguard is on, calls still may be possible to the official emergency number programmed into your device.

within 1.5 seconds. If the Security

, and enter the security code.

Call functions

3. Call functions

■ Make a voice call

1. Enter the phone number, including the area code.

For international calls, press + character replaces the international access code), enter the country code, the area code without the leading 0, if necessary, and the phone number.

2. To call the number, press the call key.

3. To end the call, or to cancel the call attempt, press the end key.

To end the call by closing the slide, see Slide call handling in “Call,” p. 66.

To search for a name or phone number that you have saved in Contacts, see “Search for a contact,” p. 49. Press the call key to call the number.

To access the list of phone numbers you have most recently called or attempted to call, in the standby mode, press the call key once. To call the number, scroll to the number or name you want, and press the call key.

Speed dialing

Assign a phone number to one of the speed-dialing keys, 2 to 9. See “Speed dials,” p. 54. Call the number in either of the following ways:

• Press the speed-dialing key, then the call key.

•If Speed dialling is set to On, press and hold a speed-dialing key until the call begins. See “Call,” p. 66.

twice for the international prefix (the

Enhanced voice dialing

To make a phone call, select and hold Names and say the name of the contact you wish to call. The phone will automatically associate a virtual voice tag with each contact.

Call functions

Make a voice dialing call

If an application is sending or receiving data using a packet data connection, end the application before you use voice dialing.

Voice commands are language-dependent. To set the language, see

Voice playback language in “Phone,” p. 66.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialing in all circumstances.

1. In the standby mode, press and hold the right selection key. A short tone is played, and Speak now is displayed.

If you are using a compatible headset with the headset key, press and hold the headset key to start the voice dialing.

2. Say the voice command clearly. If the voice recognition is successful, a list with matches is shown. The phone plays the voice command of the match on the top of the list. After about 1.5 seconds, the phone dials the number; or if the result is not the correct one, scroll to another entry, and select to dial the entry.

Using voice commands to carry out a selected phone function is similar to voice dialing. See Voice commands in “My shortcuts,” p. 58.

■ Answer or reject a voice call

To answer a call, press the call key. To answer the call by opening the slide, see also Slide call handling in “Call,” p. 66.

To mute the ringing tone before you answer the call, select Silence.

To end the call or reject a call, press the end key.

Call waiting

During a call, to answer the waiting call, press the call key. The first call is put on hold. To end the active call, press the end key.

To activate the Call waiting function, see “Call,” p. 66.

Call functions

■ Options during a voice call

Many of the options that you can use during a call are network services. For availability, contact your network operator or service provider.

Call options are Mute or Unmute, Contacts, Menu, Lock keypad, Record,

Loudspeaker, or Handset.

Network services options are Answer, Reject, Hold or Unhold, New call,

Add to conference, End call, End all calls, and the following:

Send DTMF — to send tone strings

Swap — to switch between the active call and the call on hold

Transfer — to connect a call on hold to an active call and disconnect

yourself

Conference — to make a conference call that allows up to five persons to

take part in a conference call

Private call — to discuss privately in a conference call

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

■ Make a video call

When you make a video call, you can see a real-time, two-way video between you and the recipient of the call. The video image captured by the front camera in your phone will be shown to the video call recipient.

To be able to make a video call, you need to have a USIM card and be connected in a WCDMA network. For availability of and subscription to video call services, contact your network operator or service provider. A video call can only be made between two parties. The video call can be made to a compatible phone or an ISDN client. Video calls cannot be made while another voice, video, or data call is active.

1. To start a video call, enter the phone number in the standby mode, or select Contacts and a contact. Then press and hold the send key, or select Options > Video call.

2. Starting a video call may take a while. Video call and an outgoing animation is shown. If the call is not successful (for example, video

Call functions

calls are not supported by the network, or the receiving device is not compatible) you are asked if you want to try a normal call or send a message instead.

Tip: To increase or decrease the volume during a call, press the volume keys.

The video call is active when you can see two video images and hear the sound through the loudspeaker. The call recipient may deny the video sending, in which case you may see a still image or a grey background graphic. You will hear the sound.

3. To end the call, press the end key.

■ Answer or reject a video call

When a video call arrives, Video Call is shown on the display.

1. Press the send key to answer the video call. Allow own video image

sending? is shown.

If you select Yes, the image being captured by the camera in your phone is shown to the caller. If you select No, or do nothing, video sending is not activated, and you hear a sound. A grey screen is shown in place of the video. To replace this grey screen with a still image, see “Call,” p66.

2. To end the video call, press the end key.

Note: Even if you deny video sending during a video call, the call is still charged as a video call. Check the pricing with your network operator or service provider.

■ Options during a video call

Select Options during a video call for the following options: Set

contrast, Video motion, Switch to voice, End call, Send DTMF and Loudspeaker

Write text

4. Write text

You can enter text (for example, when writing messages) using traditional or predictive text input. To use traditional text input, press a number key, 1 to 9, repeatedly until the desired character appears. In predictive text input you can enter a letter with a single keypress.

When you write text, or appears at the top left of the display, indicating predictive text input, and appears, indicating traditional text input. , , or appears next to the text input indicator, indicating the character case. To change the character case, press #.

indicates number mode. To change from the letter to number

mode, press and hold #, and select Number mode.

■ Settings

To set the writing language while writing text, select Options > Writing

language.

When writing text, select Options > Prediction settings.

To set predictive text input on or revert to traditional text input, select

Prediction > On or Off.

To select the prediction type, select Prediction type > Normal or Word

suggestions. If you select Normal, indicated with , the phone

predicts the word on the basis of the characters you entered. If you select Word suggestions, indicated with , the phone predicts and completes the word before you enter all the characters.

Tip: To quickly set predictive text input on or off when writing text, press # twice, or select and hold Options.

■ Predictive text input

Predictive text input allows you to write text quickly using the phone keypad and a built-in dictionary.

Write text

1. Start writing a word using the 2 to 9 keys. Press each key only once for one letter. The phone displays * or the letter if it separately has a meaning as a word. The entered letters are displayed underlined.

If you selected Word suggestions as prediction type, the phone starts to predict the word you are writing. After you enter a few letters, and if these entered letters are not a word, the phone tries to predict longer words. Only the entered letters are displayed underlined.

To insert a special character, press and hold *, or select Options >

Insert symbol. Scroll to a character, and select Use.

2. When you finish writing the word and it is correct, to confirm it, press 0 to add space.

If the word is not correct, press * repeatedly, or select Options >

Matches. When the word that you want appears, select Use.

If the ? character is displayed after the word, the word you intended to write is not in the dictionary. To add the word to the dictionary, select Spell. Complete the word (traditional text input is used), and select Save.

■ Traditional text input

Press a number key, 1 to 9, repeatedly until the desired character appears. Not all characters available under a number key are printed on the key. The characters available depend on the selected writing language. See “Settings,” p. 26.

If the next letter you want is located on the same key as the present one, wait until the cursor appears, or briefly press any of the navigation keys and enter the letter.

The most common punctuation marks and special characters are available under the 1 key. For more characters, press

Navigate the menus

5. Navigate the menus

The phone offers you an extensive range of functions, which are grouped into menus.

1. To access the menu, select Menu.

To change the menu view, select Options > Main menu view > List,

Grid, or Grid with labels.

To rearrange the menu, scroll to the menu you want to move, and select Options > Organise > Move. Scroll to where you want to move the menu, and select OK. To save the change, select Done >

Yes.

2. Scroll through the menu, and select an option (for example,

Settings).

3. If the selected menu contains further submenus, select the one that you want (for example, Call).

4. If the selected menu contains further submenus, repeat step 3.

5. Select the setting of your choice.

6. To return to the previous menu level, select Back. To exit the menu, select Exit.

The menus, submenus, and setting options are numbered. To access some of them, use their shortcut number.

To access the menu, select Menu. Enter quickly, within 2 seconds, the shortcut number of the menu function you want to access. To access the menu functions in menu level 1, enter 0 and 1.

Messaging

6. Messaging

You can read, write, send, and save text, multimedia, e-mail, audio, and flash messages. All messages are organized into folders.

■ Text messages (SMS)

With the short message service (SMS) you can send and receive text messages, and receive messages that can contain pictures (network service).

Before you can send any text or SMS e-mail message, you must save your message center number. See “Message settings,” p. 45.

To check SMS e-mail service availability and to subscribe to the service, contact your service provider. To save an e-mail address in Contacts, see “Save numbers and text items,” p. 49.

Your device supports the sending of text messages beyond the character limit for a single message. Longer messages is sent as a series of two or more messages. Your service provider may charge accordingly. Characters that use accents or other marks, and characters from some language options like Chinese, take up more space limiting the number of characters that can be sent in a single message.

At the top of the display, you can see the message length indicator counting backwards from the maximum number of characters supported by the phone.

Write and send SMS messages

1. Select Menu > Messaging > Create message > Text message.

2. Enter the recipient’s phone number in the To: field. To retrieve a phone number from Contacts, select Add > Contact. To send the message to multiple recipients, add the desired contacts one by one. To send the message to persons in a group, select Contact group and the desired group. To retrieve the contacts to which you recently sent messages, select Add > Recently used.

Messaging

3. Scroll down, and write your message in the Message: field. See “Write text,” p. 26.

To insert a template into the message, select Options > Use

template.

4. To send the message, select Send; or press the call key. See “Send a message,” p. 32.

Read and reply to an SMS message

1 message received, or the number of new messages with messages received are shown when you have received a message.

1. To view a new message, select Show. To view it later, select Exit.

To read the message later, select Menu > Messaging > Inbox. If more than one message is received, select the message you want to read.

is shown if you have unread messages in Inbox.

2. To view the list of available options while reading a message, select

Options. You can, for example, select to copy text from the

beginning of a message to your phone calendar as a reminder note.

3. To reply to a message, select Reply > Text message, Multimedia,

Flash message, or Audio message.

To send a text message to an e-mail address, enter the e-mail address in the To: field.

Scroll down, and write your message in the Message: field. See “Write text,” p. 26.

If you want to change the message type for your reply message, select Options > Change message type.

4. To send the message, select Send; or press the call key.

■ SIM messages

SIM messages are text messages that are saved to your SIM card. You can copy or move those messages to the phone memory, but not vice versa. Received messages are saved to the phone memory.

+ 89 hidden pages
