Microsoft RM-775 User Manual
Nokia X3-02 User Guide
5555555
Issue 1
2Contents
Contents
Safety 5
Get started 6
Keys and parts 6
Insert the SIM card and battery 6
Insert or remove a memory card 7
Charge the battery 8
Charge the battery over USB 9
GSM antenna 9
Attach a strap 10
Switch it on 10
Network services and costs 10
Access codes 10
Switch the device on or off 11
Lock the keys and screen 11
Touch screen actions 12
Touch screen settings 13
Interactive home screen elements 13
Change the volume of a call, song, or
video 13
Indicators 14
Media key 14
Messaging key 14
Copy contacts or pictures from your
old device 14
Functions without a SIM card 15
Use your device offline 15
Device management 16
Support 16
My Nokia 16
Update device software using your
device 16
Update device software using your
PC 18
Restore original settings 18
Organise files 18
Synchronise your calendar and
contacts with Ovi by Nokia 19
Back up your pictures and other
content to a memory card 19
Telephone 19
Make a call 19
View your missed calls 19
Call the last dialled number 20
Divert calls to your voice mailbox or
another phone number 20
Save a number from a received call
or message 20
About internet calls 21
Make an internet call 21
Make a conference call 22
Allow calls only to certain numbers 22
Prevent making or receiving calls 23
www.nokia.com/support
Contents 3
Contacts 23
Save a name and phone number 23
Use speed dial 23
Send your contact information 24
Create a contact group 24
Move or copy contacts to your SIM
card 24
Write text 25
Switch between text input modes 25
Write using traditional text input 25
Write using predictive text input 26
Messaging 26
Send a message 26
Send a message to a group of
people 27
Save an attachment 27
View a conversation 27
Listen to voice messages 27
Send an audio message 28
Nokia Messaging mail and IM 28
About Mail 28
Sign in to a mail account 28
Send a mail 29
Read and reply to mail 29
About Chat 29
Sign in to a chat service 29
Chat with your friends 30
Hide the Chat application 30
Personalisation 30
About the home screen 30
Add a shortcut to the home screen 31
Add your important contacts to the
home screen 31
Personalise the Go to menu 32
Personalise the home screen 32
Change the look of your device 32
Create your own profile 32
Personalise your tones 33
Use your T-coil hearing aid with your
device 33
Connectivity 33
Bluetooth 33
USB data cable 36
Connect to a WLAN 37
Nokia's Ovi services 39
Ovi by Nokia 39
Access Nokia's Ovi services 40
About Nokia Ovi Suite 40
Nokia Ovi Player 40
Time management 40
Change the time and date 40
Set an alarm 41
Snooze an alarm 41
www.nokia.com/support
4Contents
Time your workout 41
Set the countdown timer 42
Calendar 42
Make a shopping list 43
Pictures and videos 43
Take a picture 43
Record a video 43
Send a picture or video 43
Photos 44
Print a picture 44
Music and audio 45
Media player 45
FM radio 47
Use voice recorder 48
Web 49
About the web browser 49
Browse the web 49
Clear browsing history 49
Games and applications 50
About games and applications 50
Improve your gaming experience 50
Download a game or application 50
About Communities 50
Use the calculator 51
Convert currency and
measurements 51
Protect your device 52
Lock your device 52
Password protect your memory
card 53
Format a memory card 53
Prepare your device for recycling 54
Protect the environment 54
Save energy 54
Recycle 54
Product and safety information 55
Index 62
www.nokia.com/support
Safety 5
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
keep your hands free to
operate the vehicle while
driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
BATTERIES, CHARGERS AND OTHER
ACCESSORIES
Use only batteries, chargers,
and other accessories
approved by Nokia for use
with this device. Do not
connect incompatible
products.
KEEP YOUR DEVICE DRY
Your device is not waterresistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not
hold the device near your ear
when the loudspeaker is in
use.
www.nokia.com/support
6Get started
Get started
Keys and parts
1 Earpiece
2 Display
3 Messaging key
4 Call key
5 Keypad
6 Microphone
7 End/Power key
8 Media key
9 Light sensor
10 Loudspeaker
11 Micro USB connector
12 Charger connector
13 Wrist strap hole
14 Volume keys
15 Keylock button
16 Camera lens
17 Nokia AV connector (3.5 mm)
Insert the SIM card and battery
Important: Do not use a mini-
UICC SIM card, also known as a micro-SIM
card, a micro-SIM card with an adapter,
or a SIM card that has a mini-UICC cutout
(see figure) in this device. A micro SIM
card is smaller than the standard SIM
card. This device does not support the
www.nokia.com/support
use of micro-SIM cards and use of
incompatible SIM cards may damage the
card or the device, and may corrupt data
stored on the card.
This device is intended for use with a
BL-4S battery. Always use original Nokia
batteries.
The SIM card and its contacts can be
easily damaged by scratches or
bending, so be careful when handling,
inserting, or removing the card.
1 Press the release buttons, and
remove the cover. If the battery is
inserted, lift the battery out.
2 Insert a SIM card. Make sure the
contact area of the card is facing
down.
Get started 7
3 Line up the contacts of the battery
and the battery compartment, and
insert the battery. To replace the
back cover, direct the top locking
catches toward their slots, and
press down until the cover locks
into place.
Insert or remove a memory card
Use only compatible memory cards
approved by Nokia for use with this
device. Incompatible cards may damage
the card and the device and corrupt data
stored on the card.
Your device supports memory cards
with a capacity of up to 32 GB.
www.nokia.com/support
8Get started
Insert a memory card
1 Remove the back cover.
2 Make sure the contact area of the
card is facing down. Push the card
in, until you hear a click.
3 Replace the back cover.
Remove the memory card
Important: Do not remove the
memory card when an application is
using it. Doing so may damage the
memory card and the device, and
corrupt data stored on the card.
You can remove or replace the memory
card without switching the device off.
1 Remove the back cover.
2 Push the card in, until you hear a
click, and pull the card out.
3 Replace the back cover.
Charge the battery
Your battery has been partially charged
at the factory, but you may need to
recharge it before you can switch on
your device for the first time.
If the device indicates a low charge, do
the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full
charge, disconnect the charger from
the device, then from the wall
outlet.
You do not need to charge the battery
for a specific length of time, and you can
use the device while it is charging.
During charging, the device may feel
warm.
www.nokia.com/support
Get started 9
If the battery is completely discharged,
it may take several minutes before the
charging indicator appears on the
display or before any calls can be made.
If the battery has not been used for a
long time, to begin charging, you may
need to connect the charger, then
disconnect and reconnect it.
Charging the device while listening to
the radio may affect the quality of
reception.
Charge the battery over USB
Battery low, but you don't have a
charger with you? You can use a
compatible USB cable to connect to a
compatible device, such as a computer.
To avoid breaking the charger
connector, be careful when connecting
or disconnecting the charger cable.
Charging over USB can take longer to
start, and may not work if you connect
through a non-powered USB hub. Your
device charges more quickly when
connected to a wall outlet.
If connected to a computer, you can
synchronise your device while charging.
GSM antenna
The figure shows the GSM antenna area
marked in grey.
Avoid touching the antenna area
unnecessarily while the antenna is
transmitting or receiving. Contact with
antennas affects the communication
quality and may cause a higher power
www.nokia.com/support
10 Switch it on
level during operation and may reduce
the battery life.
Attach a strap
Switch it on
Network services and costs
Your device is approved for use on the
GSM 850, 900, 1800, 1900 MHz networks
and WCDMA 900, 1700-2100, 2100 MHz
networks. To use the device, you need a
subscription with a service provider.
Using network services and
downloading content to your device
requires a network connection and may
result in data traffic costs. Some product
features require support from the
network, and you may need to subscribe
to them.
Access codes
PIN or
PIN2
code
(4-8
digits)
PUK or
PUK2
code
(8
digits)
IMEI
number
These protect your SIM card
against unauthorised use or
are required to access some
features.
You can set your device to
ask for the PIN code when
you switch it on.
If not supplied with your SIM
card or you forget the codes,
contact your service
provider.
If you enter the code
incorrectly three times in a
row, you need to unblock
the code with the PUK or
PUK2 code.
These are required to
unblock a PIN or PIN2 code.
If not supplied with your SIM
card, contact your service
provider.
This is used to identify valid
devices in the network. The
number can also be used to
www.nokia.com/support
Switch it on 11
(15
digits)
block, for example, stolen
devices.
To view your IMEI number,
dial *#06#.
Lock
code
(security
code)
(min. 4
digits or
characte
rs)
This helps you protect your
device against unauthorised
use.
You can set your device to
ask for the lock code that
you define. The default lock
code is 12345.
Keep the code secret and in
a safe place, separate from
your device.
If you forget the code and
your device is locked, your
device will require service.
Additional charges may
apply, and all the personal
data in your device may be
deleted.
For more information,
contact a Nokia Care Point or
your device dealer.
The personal unblocking key (PUK) code
and the universal personal unblocking
key (UPUK) code (8 digits) are required
to change a blocked PIN code and UPIN
code, respectively. The PUK2 code (8
digits) is required to change a blocked
PIN2 code. These codes are not supplied
with the SIM card. Contact your local
service provider for the codes.
Switch the device on or off
Press and hold the power key
.
You may be prompted to get the
configuration settings from your service
provider (network service). For more
information, contact your service
provider.
Lock the keys and screen
To avoid accidentally making a call
when your device is in your pocket or
bag, lock the keys and screen of your
device.
Press the keylock button
.
www.nokia.com/support
12 Switch it on
Unlock the keys and screen
Press the keylock button
, and select
Unlock.
Tip: If the keylock button is out of reach,
to unlock the device, press the end key,
and select Unlock.
Touch screen actions
To interact with the touch screen user
interface, tap or tap and hold the touch
screen.
Open an application or other screen
element
Tap the application or element.
Access item-specific options
Tap and hold the item. A pop-up menu
with available options opens.
Scroll in a list or menu
Place your finger on the screen, slide it
quickly up or down the screen, and then
lift your finger. The content of the
screen scrolls with the speed and
direction it had at the moment of
release. To select an item from a
scrolling list and to stop the movement,
tap the item.
Swipe
Place a finger on the screen, and steadily
slide your finger in the desired
direction.
www.nokia.com/support
For example, when you are viewing a
picture, to view the next picture, swipe
left. To quickly browse through your
pictures, swipe the screen quickly, and
then scroll left or right through the
thumbnails.
Switch it on 13
Touch screen settings
Calibrate the touch screen and activate
vibration feedback.
Select Menu > Settings > Phone >
Touch settings.
Calibrate the touch screen
Select Scr. calibration, and follow the
instructions.
Activate vibration feedback
Select Vibration feedb. > On.
When you tap an icon, the device gives
a short vibration feedback.
Interactive home screen elements
The home screen elements are
interactive. For example, you can
change the date and time, set alarms, or
write calendar entries directly in the
home screen.
www.nokia.com/support
Set an alarm
Select the clock (1).
View or edit your schedule
Select the date (2).
Change the volume of a call, song, or
video
Use the volume keys.
The built-in loudspeaker allows you to
speak and listen from a short distance
without having to hold the device to
your ear.
Activate the loudspeaker during a
call
Select Loudsp..
14 Switch it on
Indicators
You have unread messages.
You have unsent, cancelled,
or failed messages.
The keypad is locked.
The device does not ring for
incoming calls or text
messages.
An alarm is set.
or The device is registered to
the GPRS or EGPRS network.
or A GPRS or EGPRS connection
is open.
or The GPRS or EGPRS
connection is suspended
(on hold).
The device is registered to
a 3G (UMTS) network.
or
The device is registered to
a 3.5G (HSDPA) network.
Bluetooth is activated.
WLAN is activated.
If you have two phone
lines, the second line is in
use.
All incoming calls are
diverted to another
number.
Calls are limited to a closed
user group.
The currently active profile
is timed.
A headset is connected to
the device.
The device is connected to
another device, using a USB
data cable.
Media key
To open either the media player or the
radio, depending on which was last
used, press the media key
.
Messaging key
To write a message or check your
message inbox, press the messaging
.
key
Copy contacts or pictures from your
old device
Want to copy important information
from your previous compatible Nokia
device and start using your new device
quickly? Use the Phone switch
application to copy, for example,
contacts, calendar entries, and pictures
to your new device, free of charge.
Select Menu > Settings > Sync &
backup.
www.nokia.com/support
Switch it on 15
yourself, must be entered in both
devices. The passcode in some
devices is fixed. For details, see the
user guide of the device.
The passcode is valid only for the
current connection.
5 If prompted, allow connection and
copying requests.
Functions without a SIM card
Some functions of your device may be
used without inserting a SIM card, such
as Organiser functions and games.
Some functions appear dimmed in the
menus and cannot be used.
Both devices must have Bluetooth
activated.
1 Select Phone switch > Copy to
this.
2 Select the content to copy and
Done.
3 Select your previous device from the
list. If the device is not listed, make
sure Bluetooth is activated in the
device.
4 If the other device requires a
passcode, enter the passcode. The
passcode, which you can define
www.nokia.com/support
Use your device offline
In places where you are not allowed to
make or receive calls, you can activate
the flight profile and play games or
listen to music.
Select Menu > Settings > Profiles.
Select Flight > Activate.
indicates that the flight profile is
active.
Tip: You can add a profiles shortcut to
the shortcut widget in the home screen.
16 Device management
Warning:
When the flight profile is activated, you
cannot make or receive any calls,
including emergency calls, or use other
features that require network coverage.
To make a call, activate another profile.
Device management
Support
If this does not resolve your issue, do
one of the following:
• Reboot your device. Switch off the
device, and remove the battery.
After about a minute, replace the
battery, and switch on the device.
• Update your device software
• Restore the original factory settings
If your issue remains unsolved, contact
Nokia for repair options. Go to
www.nokia.com/repair, or in Latin
America, www.nokialatinoamerica.com/centrosdeservicio.
Before sending your device for repair,
always back up your device data.
For additional product support
information, see the warranty and
reference leaflet included with your
Nokia device.
My Nokia
Select Menu > Applications >
Extras > Collection > My Nokia.
My Nokia is a free service that regularly
sends you text messages containing
tips, tricks, and support for your Nokia
device. It also allows you to browse the
My Nokia site where you can find details
about Nokia devices and download
tones, graphics, games, and
applications.
To use the My Nokia service, it must be
available in your country and supported
by your service provider. You must sign
up to use the service. Text message
charges apply when you send messages
to sign up or unsubscribe. For terms and
conditions, see the documentation
supplied with your device, or go to
www.nokia.com/mynokia.
Update device software using your
device
Want to improve the performance of
your device and get application updates
and great new features? Update the
software regularly to get the most out
www.nokia.com/support
of your device. You can also set your
device to automatically check for
updates.
Warning:
If you install a software update, you
cannot use the device, even to make
emergency calls, until the installation is
completed and the device is restarted.
Using the service or downloading
content may cause transfer of large
amounts of data, which may result in
data traffic costs.
Make sure that the device battery has
enough power, or connect the charger
before starting the update.
Select Menu > Settings.
Device management 17
1 Select Phone > Phone updates.
2 To display the current software
version and check whether an
update is available, select Curr. sw
details.
3 To download and install a software
update, select Downl. ph. sw.
Follow the displayed instructions.
4 If the installation was cancelled
after the download, select Install
sw update.
www.nokia.com/support
18 Device management
The software update may take several
minutes. If there are problems with the
installation, contact your service
provider.
Check for software updates
automatically
Select Auto sw update, and define how
often to check for new software
updates.
Your service provider may send device
software updates over the air directly to
your device. For more information on
this network service, contact your
service provider.
Update device software using your
PC
You can use the Nokia Ovi Suite PC
application to update your device
software. You need a compatible PC, a
high-speed internet connection, and a
compatible USB data cable to connect
your device to the PC.
To get more information and to
download the Nokia Ovi Suite
application, go to www.ovi.com/suite.
Restore original settings
If your device is not working properly,
you can reset some settings to their
original values.
1 End all calls and connections.
2 Select Menu > Settings and Rest.
fact. sett. > Settings only.
3 Enter the security code.
This does not affect documents or files
stored on your device.
After restoring the original settings,
your device switches off and then on
again. This may take longer than usual.
Organise files
You can move, copy, delete, or create
new files and folders in your device
memory or on the memory card. If you
organise your files into their own
folders, it might help you find the files
in future.
Select Menu > Applications > Gallery.
Create a new folder
In the folder where you want to create
a sub-folder, select Options > Add
folder.
www.nokia.com/support
Telephone 19
Copy or move a file to a folder
Select and hold the file, and from the
pop-up menu, select the appropriate
option.
Tip: You can also play music or videos,
or view pictures in Gallery.
Synchronise your calendar and
contacts with Ovi by Nokia
Select Menu > Settings > Sync &
backup.
1 Select Sync with Ovi > Sync now.
2 Sign in with your Nokia account
details. If you do not have an
account, sign up for one.
3 Follow the instructions.
Back up your pictures and other
content to a memory card
Want to make sure you will not lose any
important files? You can back up your
device memory to a compatible
memory card.
Select Menu > Settings > Sync &
backup.
Select Create backup.
Restore a backup
Select Restore backup.
Telephone
Make a call
1 Enter the phone number, including
the country and area code if
necessary.
2 Press the call key.
Answer an incoming call
Press the call key.
End a call
Press the end key.
Reject a call
Press the end key.
View your missed calls
Want to see who made the call you
missed?
On the home screen, select View. The
caller's name is displayed, if stored in
the contacts list.
Missed and received calls are logged
only if supported by the network, and
www.nokia.com/support
20 Telephone
the device is switched on and within the
network service area.
Call back the contact or number
Go to the contact or number, and press
the call key.
View the missed calls later
Select Menu > Contacts > Log and
Missed calls.
Call the last dialled number
Trying to call someone, but they are not
answering? It is easy to call them again.
In the home screen, press the call key,
select the number from the list, and
press the call key again.
Divert calls to your voice mailbox or
another phone number
When you cannot answer, you can
divert your calls to your voice mailbox
or to another number (network service).
1 Select Menu > Settings and Call >
Call divert.
2 Select an option, such as If busy or
If not answered.
3 Select Activate and To voice
mailbox or To other number.
Save a number from a received call or
message
Have you received a call or message
from a person whose phone number is
not yet saved in the contacts list? You
can easily save the number to your
contacts.
Save a number from a received call
1 Select Menu > Contacts > Log and
Received calls.
2 Select the number and Options >
Save.
3 Enter a name for the contact, and
select Save.
Save a number from a received
message
1 Select Menu > Messaging.
2 Select Conversations or Inbox and
a message.
3 Press the call key.
4 Select the number and Save.
5 Enter a name for the contact, and
select Save.
www.nokia.com/support
Loading...
