Nokia 303 User Guide

Issue 1

Safety 4

Get started 5

Keys and parts 5 Write with the keyboard 5 Insert a SIM card and battery 6 Insert a memory card 8 Charge the battery 9 Attach a strap 10 Switch the phone on or off 10 Antenna locations 11

Basic use 11

Access codes 11 Lock the keys and screen 12 Touch screen actions 12 Indicators 14 Copy contacts or pictures from your old phone 14 Change the volume of a call, song, or video 15

Calls 15

Make a call 15 Call the last dialled number 15 View your missed calls 15 About internet calls 16 Make an internet call 16

Contacts 17

Save a name and phone number 17 Use speed dial 17

Write text 18

Write using the keyboard 18 Predictive text input 19

Messaging 19

Send a message 19

View a conversation 20 Messaging key 20 Listen to voice messages 20 Send an audio message 21

Personalise your phone 21

About the home screen 21 Personalise the home screen 21 Personalise your phone tones 22

Time management 23

Change the time and date 23 Set an alarm 23 Add an appointment 23

Connectivity 24

Bluetooth 24 USB data cable 25 Connect to a WLAN 26

Music and audio 27

FM radio 27 Media player 29 Media key 30

Pictures and videos 30

Take a picture 30 Record a video 30 Send a picture or video 30

Web 31

About the web browser 31 Browse the web 31 Fit a web page to your phone display 32 Add a bookmark 33 Clear your browsing history 33

Keep in touch with your online friends 33

About Communities 33

Mail and chat 34

About Mail 34 Send a mail 34 Read and reply to mail 34 About Chat 34 Chat with your friends 35

Nokia Maps 35

About Maps 35 Download maps 35 View your current location on the map 36 Find a place 36 Share your location or a place 37 Create a walking route 37

Nokia Services 37

Availability and costs of Nokia Services 37 Access Nokia Services 38

Find help 38

Support 38 Subscribe to the Tips and Offers service 38 Keep your phone up to date 38

Protect the environment 41

Save energy 41 Recycle 41

Product and safety information 41

Index 48

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For further information, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Get started

Learn how to start using your phone.

Keys and parts

1 Earpiece 2 Touch screen 3 Messaging key 4 Call key 5 Keyboard 6 Volume up/Zoom in key 7 Volume down/Zoom out key 8 Key lock button 9 Media key 10 End/Power key 11 Nokia AV connector (3.5 mm) 12 Micro-USB connector 13 Charger connector 14 Camera lens. Before using the camera, remove the protective tape from the lens. 15 Wrist strap hole 16 Back cover release latch 17 Loudspeaker

Write with the keyboard

Your phone has a full keyboard.

1 Function key. To insert special characters printed at the top of keys, press the

function key, and then press the corresponding key. To enter several special characters in a row, press the function key twice. To return to normal mode, press the function key.

Shift key. To switch between the upper and lower case modes, press the shift key

twice. To enter a single upper case letter in lower case mode, or a single lower case letter in upper case mode, press the shift key, and then press the desired alphabet key.

Sym key. To insert special characters not shown on the keyboard, press the sym

key, and select the desired character.

Insert a variation of a letter

You can insert, for example, letters with accents. To insert á, press and hold the sym key, and then press A repeatedly, until the desired letter is displayed. The order and availability of letters depends on the selected writing language.

Insert a SIM card and battery

removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure) in this device. A micro SIM card is smaller than the standard SIM card. This device does not support the use of micro-SIM cards and use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card.

Backspace key. To delete a character, press the backs pace key. To delete several

characters, press and hold the backspace key.

Enter key. To move the cursor to the next row or text input field, press the enter key. Additional functions are based on the current context. For example, in the web address field of the web browser, the enter key acts as the Go icon.

Ctrl key

Note: Switch the device off and disconnect the charger and any other device before

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a micro-

This phone is intended for use with a BP-3L battery. Always use original Nokia batteries.

The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

1 Switch the phone off.

2 Pull the back cover release latch towards the bottom of the phone, and remove the

cover.

3 Remove the battery, if inserted.

4 Lift the SIM card holder cover, make sure the contact area of the SIM card is facing

down, and place the card in the holder.

5 Lower the SIM card holder cover. 6 Line up the battery contacts, and insert the battery.

7 Direct the top locking catches toward their slots, and press down until the cover

locks into place.

Remove the SIM card

1 Switch the phone off. 2 Remove the back cover. 3 Remove the battery, if inserted. 4 Lift the SIM card holder cover, and remove the SIM card.

Insert a memory card

Use only compatible memory cards approved by Nokia for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Your phone supports memory cards with a capacity of up to 32 GB.

1 Switch the phone off, and remove the back cover and battery. 2 To release the memory card holder, slide the holder in the direction indicated by

the arrow on the holder. Lift the memory card holder (1).

3 Make sure the contact area of the memory card would face down, and insert the

card (2). 4 Lower the memory card holder (3). 5 To lock the memory card holder, slide the holder to its original position (4).

Remove the memory card

1 Switch the phone off. 2 Remove the back cover and battery. 3 To release the memory card holder, slide the holder in the direction indicated by

the arrow on the holder. Open the memory card holder, and remove the memory

card.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can switch on your phone for the first time. If the phone indicates a low charge, do the following:

1 Connect the charger to a wall outlet. 2 Connect the charger to the phone. 3 When the phone indicates a full charge, disconnect the charger from the phone,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the phone while it is charging.

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.

If the battery has not been used for a long time, to begin charging, you may need to connect the charger, then disconnect and reconnect it.

Attach a strap

Remove the back cover, thread the strap through the hole, and loop the strap around the wrist strap peg.

The strap may be available separately.

Switch the phone on or off

Press and hold the power key

until the phone vibrates.

You may be prompted to get the configuration settings from your network service provider. For more information on this network service, contact your network service provider.

Antenna locations

The antenna area is highlighted.

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

Basic use

Learn how to use the basic features of your phone.

Access codes

PIN or PIN2 code

(4-8 digits)

PUK or PUK2 code

(8 digits)

These protect your SIM card against unauthorised use or are required to access some features.

You can set your phone to ask for the PIN code when you switch it on.

If not supplied with your SIM card or you forget the codes, contact your service provider.

If you enter the code incorrectly three times in a row, you need to unblock the code with the PUK or PUK2 code.

These are required to unblock a PIN or PIN2 code.

If not supplied with your SIM card, contact your service provider.

IMEI number

(15 digits)

Lock code (security code)

(min. 5 digits)

The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code, respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. These codes are not supplied with the SIM card. Contact your local service provider for the codes.

Lock the keys and screen

To avoid accidentally making a call when your phone is in your pocket or bag, lock the keys and screen of your phone.

Press the key lock button.

Unlock the keys and screen

Press the key lock button, and select Unlock.

This is used to identify valid phones in the network. The number can also be used to block, for example, stolen phones.

To view your IMEI number, dial *#06#.

This helps you protect your phone against unauthorised use.

You can set your phone to ask for the lock code that you define. The default lock code is 12345.

Keep the code secret and in a safe place, separate from your phone.

If you forget the code and your phone is locked, your phone will require service. Additional charges may apply, and all the personal data in your phone may be deleted.

For more information, contact a Nokia Care Point or your phone dealer.

Touch screen actions

To interact with the touch screen user interface, tap or tap and hold the touch screen.

Open an application or other screen element

Tap the application or element.

Access item-specific options

Tap and hold the item. A pop-up menu with available options opens.

Scroll in a list or menu

Place your finger on the screen, slide it quickly up or down the screen, and then lift your finger. The content of the screen scrolls with the speed and direction it had at the moment of release. To select an item from a scrolling list and to stop the movement, tap the item.

Swipe

Place a finger on the screen, and steadily slide your finger in the desired direction.

For example, when you are viewing a picture, to view the next picture, swipe left. To quickly browse through your pictures, swipe the screen quickly, and then scroll left or right through the thumbnails.

Indicators

You have unread messages. You have unsent, cancelled, or failed messages. The keypad is locked. The phone does not ring for incoming calls or text messages. An alarm is set.

Copy contacts or pictures from your old phone

Want to copy your content from your previous compatible Nokia phone and start using your new phone quickly? You can copy, for example, contacts, calendar entries, and pictures to your new phone, free of charge.

The phone is registered to the GPRS or EGPRS network. A GPRS or EGPRS connection is open. The GPRS or EGPRS connection is suspended (on hold). The phone is registered to a 3G (UMTS) network. The phone is registered to a 3.5G (HSDPA) network. Bluetooth is activated. WLAN is activated. If you have two phone lines, the second line is in use. All incoming calls are diverted to another number. Calls are limited to a closed user group. The currently active profile is timed. A headset is connected to the phone. The phone is connected to another device, using a USB data cable.

1 Activate Bluetooth in both phones.

Select Menu > Settings > Connectivity > Bluetooth and On. 2 Select Menu > Settings > Sync & backup. 3 Select Phone switch > Copy to this.

4 Select the content to copy and Done. 5 Select your previous phone from the list. 6 If the other phone requires a passcode, enter the passcode. The passcode, which

you can define yourself, must be entered in both phones. The passcode in some phones is fixed. For details, see the user guide of the other phone.

The passcode is valid only for the current connection.

7 If prompted, allow connection and copying requests.

Change the volume of a call, song, or video

Use the volume keys.

The built-in loudspeaker allows you to speak and listen from a short distance without having to hold the phone to your ear.

Activate the loudspeaker during a call

Select Loudsp..

Calls

Learn how to make and receive calls.

Make a call

1 On the home screen, enter the phone number.

To delete a number, select Clear. To enter the + character, used for international calls, press +. The + character may

not work in all regions. In this case, enter the international access code directly. 2 To make the call, press the call key. 3 To end the call, press the end key.

Tip: To use the virtual keypad to enter the phone number, press the call key, and select

Dialler.

Call the last dialled number

Trying to call someone, but they are not answering? It is easy to call them again.

1 On the home screen, press the call key. 2 Go to the number, and press the call key.

View your missed calls

Want to see who made the call you missed?
