Nokia C5–03 User Guide

Issue 1

2Contents

Safety 6

Battery removing 7

Find help 8

In-device help 8 Accessibility solutions 8 Support 9 Software updates over the air 9 Update device software using your PC 10 Settings 11 Access codes 11 Prolong battery life 12 Increase available memory 13

Get started 14

Insert the SIM card and battery 14 Insert the memory card 18 Remove the memory card 20 Charge the battery 20 Keys and parts 22 Switch the device on 24 Lock the keys and touch screen 24 Home screen 25 Access the menu 27 Touch screen actions 27 Change the ringing tone 30

Ovi by Nokia 30 About Ovi Store 30

Your device 31

Device setup 31 Settings wizard 31 Transfer content for the first time 32 Display indicators 32 Contacts bar 35 Antenna locations 36 Offline profile 36 Shortcuts 37 Volume and loudspeaker control 38 Sensor settings and display rotation 38 Remote lock 39 Headset 39 Attach a wrist strap 40

Make calls 40

Calls 40 During a call 41 Voice mailbox 42 Answer or reject a call 43 Make a conference call 44 Speed dial a phone number 44 Call waiting 45 Voice dialling 46 Log 47

Write text 49

Contents 3

Virtual keyboard 49 Handwriting 50 Enter text with the virtual keypad 52 Touch input settings 54

Contacts 55

Save phone numbers and mail addresses 55 Manage names and numbers 55 Assign default numbers and addresses 56 Ringing tones, images, and call text for contacts 56 Copy contacts 57 SIM services 58

Messaging 59

Messaging main view 59 Write and send messages 60 Messaging inbox 62 Set up e-mail 64 E-mail service 64 Mailbox 65 Mail for Exchange 68 View messages on a SIM card 69 Service commands 70 Messaging settings 70

Personalise your device 73

Change the look of your device 73

Profiles 74

Music folder 74

Music player 74 Ovi Music 77 Nokia Podcasting 78 Radio 80

Camera 81

Activate the camera 81 Image capture 82 Video recording 85

Gallery 86

View and organise files 86 View images and videos 87 Organise images and video clips 88

Share online 88

About Share online 88 Subscribe to services 89 Manage your accounts 89 Create a post 90 Post files from Gallery 90

Nokia Video Centre 91

View and download video clips 91 Video feeds 93 My videos 93 Transfer video clips from your PC 94

4Contents

Video centre settings 94

Web browser 95

Browse the web 95 Add a bookmark 96 Subscribe to a web feed 96 Discover nearby events 97

Positioning (GPS) 98

About GPS 98 About assisted GPS (A-GPS) 98 Hold your device correctly 99 Tips on creating a GPS connection 99 Position requests 101 Landmarks 101 GPS data 102 Positioning settings 102

Maps 104

Maps overview 104 View your location and the map 104 Map view 106 Change the look of the map 106 Download and update maps 107 About positioning methods 108 Find a location 109 View location details 110 Save or view a place or route 110 Send a place to a friend 111 Check in 112

Synchronise your Favourites 113 Get voice guidance 114 Use the compass 115 Drive to your destination 116 Navigation view 117 Get traffic and safety information 118 Walk to your destination 118 Plan a route 119

Connectivity 121

Data connections and access points 121 Network settings 122 Wi-Fi/WLAN connection 123 Access points 127 Close a network connection 131 Synchronisation 131 Synchronise data with Ovi Sync 132 Bluetooth connectivity 133 Transfer data using a USB cable 138 PC connections 139 Administrative settings 139

Search 141

About Search 141 Start a search 141

Other applications 142

Clock 142 Calendar 144 File manager 144

Application manager 146 RealPlayer 150 Recorder 151 Write a note 152 Make a calculation 152 Converter 153 Dictionary 153

Settings 154

Phone settings 154 Call settings 161

Protect the environment 164

Save energy 164 Recycle 164

Product and safety information 165

Contents 5

6Safety

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

Safety 7

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Battery removing

Switch the device off and disconnect the charger before removing the battery.

8Find help

Find help

In-device help

Your device contains instructions to help to use the applications in your device.

To open help texts from the main menu, select Menu > Applications > Help and the application for which you want to read instructions.

When an application is open, to access the help text for the current view, select

Options > Help.

When you are reading the instructions, to change the size of the help text, select

Options > Decrease font size or Increase font size.

You may find links to related topics at the end of the help text. If you select an underlined word, a short explanation is displayed.

Help texts use the following indicators:

Link to a related help topic. Link to the application being discussed.

When you are reading the instructions, to switch between help texts and the application that is open in the background, select Options > Show open apps. and the desired application.

Accessibility solutions

Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. For more information, visit the Nokia website at www.nokiaaccessibility.com.

Find help 9

Support

When you want to learn more about how to use your product or you are unsure how your phone should function, read the user guide in your phone. Select Menu >

Applications > Help.

If this does not resolve your issue, do one of the following:

• Reboot your phone. Switch off the phone, and remove the battery. After about a minute, replace the battery, and switch on the phone.

• Update your phone software

• Restore the original factory settings

If your issue remains unsolved, contact Nokia for repair options. Go to www.nokia.com/repair, or in Latin America, www.nokia-latinoamerica.com/ centrosdeservicio. Before sending your phone for repair, always back up your data.

For additional product support information, see the warranty and reference leaflet included with your Nokia device.

Software updates over the air

Select Menu > Applications > Tools > SW update.

With Software update (network service), you can check if there are updates available for your device software or applications, and download them to your device.

Warning:

If you install a software update, you cannot use the device, even to make emergency calls, until the installation is completed and the device is restarted.

10 Find help

After updating your device software or applications using Software update, the instructions related to the updated applications in the user guide or the helps may no longer be up to date.

To download the available updates, select

. To unmark specific updates that you

do not want to download, select the updates from the list.

To view information on an update, select the update and

To view the status of previous updates, select

Select Options and from the following:

Update via PC — Update your device using a PC. This option replaces the Start update option when updates are only available using the Nokia Software Updater PC application.

View update history — View the status of previous updates. Settings — Modify the settings, such as the default access point used for

downloading updates.

Disclaimer — View the Nokia licence agreement.

Update device software using your PC

You can use the Nokia Ovi Suite PC application to update your device software. You need a compatible PC, a high-speed internet connection, and a compatible USB data cable to connect your device to the PC.

To get more information and to download the Nokia Ovi Suite application, go to www.ovi.com/suite.

Find help 11

Settings

Your device normally has MMS, GPRS, streaming, and mobile internet settings automatically configured in the device, based on your network service provider information. You may have settings from your service providers already installed in your device, or you may receive or request the settings from the network service providers as a special message.

Access codes

PIN code — This code protects your SIM card against unauthorised use. The PIN code (4 - 8 digits) is usually supplied with the SIM card.

PIN2 code — This code (4 - 8 digits) is supplied with some SIM cards, and is required to access some functions in your device.

If you forget an access code, contact the network service provider whose SIM card is in your device. After three consecutive incorrect PIN or PIN2 code entries, the code is blocked, and you need the PUK or PUK2 code to unblock it.

PUK code and PUK2 code — These codes (8 digits) are required to change a blocked PIN code or PIN2 code, respectively. If the codes are not supplied with the SIM card, contact the network service provider whose SIM card is in your device.

IMEI number — This number (15 digits) is used to identify valid devices in the GSM network. Devices that are, for example, stolen, can be blocked from accessing the network. The IMEI number for your device can be found under the battery.

Lock code (also known as security code) — The lock code helps you to protect your device against unauthorised use. You can create and change the code, and set the device to request the code. Keep the new code secret and in a safe place separate from your device. If you forget the code and your device is locked, your device will require service. Additional charges may apply, and all the personal data in your device may be deleted. For more information, contact a Nokia Care Point or your device dealer.

12 Find help

Prolong battery life

Many features in your device increase the demand on battery power and reduce the battery lifetime. To save battery power, note the following:

• Features that use Bluetooth connectivity, or allowing such features to run in the background while using other features, increase the demand on battery power. Deactivate Bluetooth connectivity when you do not need it.

• Features that use a wireless LAN (WLAN), or allowing such featu res t o run in the background while using other features, increase the demand on battery power. WLAN connectivity is deactivated when you are not trying to connect, not connected to an access point, or not scanning for available networks. To further reduce battery consumption, you can specify that your device does not scan, or scans less often, for available networks in the background.

• If you have selected Packet data connection > When available in the connection settings, and there is no packet data coverage (GPRS), the device periodically tries to establish a packet data connection. To prolong the operating time of your device, select Packet data connection > When

needed.

• The Maps application downloads new map information when you move to new areas on the map, which increases the demand on battery power. You can prevent the automatic download of new maps.

• If the signal strength of the cellular network varies much in your area, your device must scan for the available network repeatedly. This increases the demand on battery power.

If the network mode is set to dual mode in the network settings, the device searches for the 3G network. To set the device to use only the GSM network, select Menu > Settings and Connectivity > Network > Network mode >

GSM.

• The backlight of the display increases the demand on battery power. In the display settings, you can adjust the display brightness and change the time-out

Find help 13

period after which the backlight is switched off. Select Menu > Settings and

Phone > Display > Brightness or Light time-out.

• Leaving applications running in the background increases the demand on battery power. To access the applications you are not using, press and hold the menu key, and select an application.

Increase available memory

Do you need more available device memory for new applications and content?

View how much space is available for different data types

Select Menu > Applications > Office > File mgr..

Many features of the device use memory to store data. The device notifies you if the memory in different memory locations is low.

Increase available memory

Transfer data to a compatible memory card (if available) or to a compatible computer.

To remove data you no longer need, use File manager or open the respective application. You can remove the following:

• Messages in the folders in Messaging and retrieved e-mail messages in the mailbox

• Saved web pages

• Contact information

• Calendar notes

• Applications shown in Application manager that you do not need

14 Get started

• Installation files (.sis or .sisx) of applications you have installed. Transfer the installation files to a compatible computer.

• Images and video clips in Gallery. Back up the files to a compatible computer.

Get started

Insert the SIM card and battery

Safe removal. Always switch the device off and disconnect the charger before removing the battery.

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card,

a micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure) in this device. A micro SIM card is smaller than the standard SIM card. This device does not support the use of micro-SIM cards and use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card.

A SIM card may be already inserted in the device. If not, do the following:

1 Remove the back cover.

2 Remove the battery, if inserted.

3 Slide the SIM card holder, to unlock it.

Get started 15

16 Get started

4 Lift the SIM card holder up.

5 Make sure the contact area of the SIM card is facing toward the device, and slide

the SIM card into the SIM card holder.

Get started 17

6 Lower the SIM card holder into place. Slide the SIM card holder, to lock it. 7 Line up the battery contacts, and insert the battery.

8 To replace the cover, direct the top locking catches toward their slots, and press

down until the cover locks into place.

18 Get started

If the SIM card is not properly in place, the device can only be used in the offline profile.

Insert the memory card

Use only compatible memory cards approved by Nokia for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

1 Remove the back cover.

Get started 19

2 Make sure the contact area of a compatible memory card is facing down, and

insert it into the memory card slot.

3 Push the card in, until you hear a click.

4 Replace the back cover.

20 Get started

Remove the memory card

Important: Do not remove the memory card when an application is using

it. Doing so may damage the memory card and the device, and corrupt data stored on the card.

1 If the device is switched on, before you remove the card, press the power key,

and select Remove memory card.

2When Remove memory card? Some applications will be closed. is

displayed, select Yes.

3When Remove memory card and press 'OK' is displayed, remove the back

cover of the device, and push the card in, until you hear a click.

4 Pull out the memory card, and replace the back cover. If the device is switched

on, select OK.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can switch on your device for the first time. If the device indicates a low charge, do the following:

1 Connect the charger to a wall outlet.

Get started 21

2 Connect the charger to the device.

3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.

Tip: Disconnect the charger from the wall outlet when the charger is not in use. A charger that is connected to the outlet consumes power even when it is not connected to the device.

USB charging

You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

1 Use a compatible USB data cable to connect your device to a compatible USB

device.

22 Get started

Depending on the type of the device that is used for charging, it may take a while for charging to start.

2 If the device is switched on, select the appropriate USB mode.

Only connect your device to products that have USB-IF logo.

Keys and parts

1 Wrist strap hole 2 Nokia AV connector (3.5 mm) 3 Micro USB connector 4 Volume/Zoom key 5 Lock key 6 Earpiece

7 Touch screen 8 Call key 9 Menu key 10 End/power key 11 Camera lens 12 Loudspeaker 13 Charger connector 14 Microphone

Get started 23

24 Get started

Switch the device on

1 Press and hold the power key. 2 If the device asks for a PIN code or lock code, enter it, and select OK. To delete

a number, select

. The factory setting for the lock code is 12345.

3 Select your location. If you accidentally select the wrong location, select Back. 4 Enter the date and time. When using the 12-hour time format, to switch

between a.m. and p.m., select any number.

Lock the keys and touch screen

To lock the touch screen and the keys, press the lock key on the side of the device.

To unlock, press the lock key on the side of the device, and select the unlock icon on the screen.

Get started 25

When the touch screen and keys are locked, the touch screen is switched off and the keys are inactive.

The screen and keys may be locked automatically after a period of inactivity. To change the settings for automatic screen and key locking, select Menu >

Settings and Phone > Phone mgmt. > Auto. keyguard > Keypad autolock period.

Home screen

The home screen is your starting point where you can collect all your important contacts or application shortcuts.

26 Get started

Interactive display elements

To open the clock application, tap the clock (1).

To open calendar or change profiles in the home screen, tap the date or the profile name (2).

To view or modify connectivity settings (

), to see the available wireless LANs if

WLAN scanning is enabled, or to view missed events, tap the top right corner (3).

To make a phone call, select

(4), or, if the contacts bar is active, select

Telephone.

To open Contacts, select

(5), or, if the contacts bar is active, select Contacts.

Get started 27

To open the main menu, press the menu key (6).

Start using the contacts bar

To add a contact to the contacts bar, in the home screen, select and a contact, and follow the displayed instructions.

Contacts need to be saved in the phone memory.

To add a new contact to your contacts list, select

> Options > New contact,

and follow the displayed instructions. Contacts added from the contacts bar are always saved to the phone memory.

Change the home screen theme

To change the home screen theme or the shortcuts, select Menu > Settings and

Personal > Home screen.

Access the menu

To access the menu, press the menu key.

To open an application or folder in the menu, select the item.

Touch screen actions

Open an application or other screen element

Tap the application or element once.

28 Get started

To view the options available for the opened item, select Options or, if available, select an icon from a toolbar.

Access functions quickly

Tap and hold the item. A pop-up menu with available options opens. For example, to send an image, tap and hold the image, and from the pop-up menu, select the appropriate option.

Tip: To see the options available for an opened item, such as an image or a video clip, tap the screen.

Select

In this user documentation, opening applications or items by tapping them is called "selecting". If you need to select several items in a sequence, the menu items to select are separated by arrows.

For example, to select Options > Help, tap Options, and then tap Help.

Drag an item

Tap and hold the item, and slide your finger across the screen. The item follows your finger.

To scroll up or down on a web page, drag the page with your finger.

Swipe

Place a finger on the screen, and steadily slide your finger in the desired direction.

Get started 29

When viewing an image, to view the next or previous image, swipe the image left or right, respectively.

Scroll

To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.

Place your finger on the screen, slide it quickly up or down the screen, then lift your finger. The content of the screen scrolls with the speed and direction it had at the moment of release. To select an item from a scrolling list and to stop the movement, tap the item.

Tip: To view a brief description of an icon, place your finger on the icon. Descriptions are not available for all icons.

Touch screen backlight

The touch screen backlight is turned off after a period of inactivity. To turn the screen backlight on, tap the screen.

If the touch screen and keys are locked, tapping the screen does not turn the screen backlight on.

30 Get started

Change the ringing tone

Select Menu > Settings and Personal > Profiles.

You can use profiles to set and customise the ringing tones, message alert tones, and other tones for different events, environments, or caller groups.

To personalise a profile, go to the profile, and select Personalise.

Ovi by Nokia

With Ovi by Nokia, you can find new places and services, and stay in touch

with your friends. You can do, for example, the following:

• Download games, applications, videos, and ringing tones to your device

• Find your way with free walk and drive navigation, plan trips, and view locations

on a map

• Get a free Ovi Mail account

• Buy music

Some items are free of charge, others you may need to pay for.

The available services may also vary by country or region, and not all languages are supported.

To access Nokia's Ovi services, go to www.ovi.com, and register your own Nokia account.

For more help and information, go to www.ovi.com.

About Ovi Store

With Ovi Store, you can download mobile games, applications, videos, pictures,

themes, and ringing tones to your device. Some items are free of charge; others you

+ 144 hidden pages
