Microsoft RM-688 User Manual

Nokia C5–00 User Guide
Cyan
Magenta
Yellow
Black
Cyan
3333333
Magenta
Issue 1
Black
2Contents
Cyan
Magenta
Yellow
Black
Contents
Safety 4
About your device 4 Office applications 5 Network services 5
Get started 6
Keys and parts 6 Insert SIM card and battery 6 Insert a memory card 7 Wrist strap 7 Charge the battery 8 Switch the device on and off 9 Keypad lock (keyguard) 9 Volume control 9 Connect a compatible headset 9 Antenna locations 10 Transfer content from another device 10 Install Ovi Suite 11 Visit Ovi 11 About Ovi Store 11 Remove a memory card 11 Remove battery and SIM card 12
Basic use 12
Write text 12 Menu 13 Display indicators 14 Shortcuts 15 Offline profile 16 Access codes 16 Configuration settings 16 Settings wizard 17 Remote lock 17
Personalise your device 17
Home screen 17
Contacts bar 18 Themes 18 Profiles 19
Telephone 20
Make a call 20 Answer a call 20 Make a video call 20 Answer or decline a video call 21 Call and data registers 21 Call divert 21
Contacts 22
Stay connected with your online friends 22 Copy contacts 22 Manage names and numbers 23 Save and edit names and numbers 23 Ringing tones, images, and call text for contacts 23
Messaging 24
About messaging 24 Write and send messages 24 E-mail 25 About Chat 27 About Ovi Contacts 27 Connect to the service 28
Connectivity 28
Connect your computer to web 28 About Ovi Files 28 About Bluetooth 29 Send and receive data with Bluetooth 29 Synchronisation 30
Web 31
About Web browser 31 Browse the web 31
2 www.nokia.com/support
Cyan
Magenta
Black
Contents 3
Cyan
Magenta
Yellow
Black
About Search 31 Web feeds and blogs 32
Positioning 32
About GPS 32 Assisted GPS (A-GPS) 32 Maps 33 Landmarks 38 GPS data 38
Music and audio 39
Ovi Music 39 Play a song 40 FM Radio 40
Camera 41
Capture an image 41 Record a video clip 41
Images and videos 42
About Gallery 42 About Share online 42
Time management 42
Calendar 42 Alarm clock 43 Clock settings 43
Settings 44
Device and SIM card security 44 Restore original settings 44
Green tips 47
Save energy 47 Recycle 47
Product and safety information 47
Index 55
Data management 44
Protected content 44
Find help 45
Support 45 Keep your device software and applications up to date 45 In-device help 46
www.nokia.com/support 3
Cyan
Magenta
Black
4Safety
Cyan
Magenta
Yellow
Black
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible products.
WATER-RESISTANCE
Your device is not water­resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for use on the (E)GSM 850, 900, 1800 and 1900 MHz networks, and UMTS 850 and 2100 MHz HSDPA and HSUPA networks. Contact your service provider for more information about networks.
Your device supports several connectivity methods and like computers may be exposed to viruses and other harmful content. Exercise caution with messages, connectivity requests, browsing, and downloads. Only install and use services and software from trustworthy sources that offer adequate security and protection, such as applications that are Symbian Signed or have passed the Java Verified™ testing. Consider installing antivirus and other security software on your device and any connected computer.
Your device may have preinstalled bookmarks and links for third-party internet sites and may allow you to access third-party sites. These are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you access such sites, take precautions for security or content.
4 www.nokia.com/support
Cyan
Magenta
Black
Safety 5
Cyan
Magenta
Yellow
Black
Warning:
To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.
Office applications
The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and
2003). Not all file formats are supported.
provider to use them. Network services involve transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply. Some networks may have limitations that affect how you can use some features of this device requiring network support such as support for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/ IP protocols and language-dependent characters.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have customized items such as menu names, menu order, and icons.
Safe removal. Always switch the device off and disconnect the charger before removing the battery.
Network services
To use the device you must have service from a wireless service provider. Some features are not available on all networks; other features may require that you make specific arrangements with your service
www.nokia.com/support 5
Cyan
Magenta
Black
6Get started
Cyan
Magenta
Yellow
Black
Get started
Keys and parts
1 Earpiece 2 Display 3 Left selection key 4 Home key 5 Call key 6 Number keys 7 Secondary camera lens 8 Navi™ key (scroll key). Can also be
used to capture images.
9 Right selection key 10 Clear key C 11 End/Power key 12 Microphone
6 www.nokia.com/support
13 Charger connector 14 Micro USB connector 15 Nokia AV connector (3.5 mm) 16 Camera flash 17 Volume keys. Can also be used to
zoom when using the camera.
18 Memory card slot 19 Main camera lens 20 Back cover release button 21 Wrist strap eyelet 22 Loudspeaker
Note: The surface of this device does not
contain nickel in the platings. The surface of this device contains stainless steel.
Insert SIM card and battery
1 To remove the back cover of the
device, pull the release button (1) toward the bottom of the device, and lift the cover off (2).
Cyan
Magenta
Black
2 Slide the SIM card into the SIM card
Cyan
Magenta
Yellow
Black
holder. The battery must be removed before you can insert the SIM card.
Ensure that the contact area on the card is facing down on the device, and the bevelled corner is facing towards the card holder slot.
3 Insert the battery.
Get started 7
Insert a memory card
The memory card may be supplied with the device, and may already be inserted.
1 Open the memory card slot cover.
2 Place the card in the slot with the
contact area facing up.
3 Push the card gently to lock it into
place. Close the slot cover.
4 To replace the back cover, carefully
align the top lugs (1), and line up the back cover, then gently press down until the cover locks into place (2).
www.nokia.com/support 7
Cyan
Magenta
Wrist strap
Thread the wrist strap, and tighten it.
Black
8Get started
Cyan
Magenta
Yellow
Black
A wrist strap may not be included.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet. 2 Connect the charger to the device.
3 When the battery is fully charged,
disconnect the charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.
Tip: If you have old compatible Nokia chargers, you can use them with your
device by attaching the CA-44 charger adapter to the old charger. The adapter is available as a separate accessory.
USB charging
You can use USB charging when a wall outlet is not available. When charging your device with the USB data cable, the charging time is longer. USB charging efficiency varies significantly. In some cases, it may take a very long time for charging to start and the device to start functioning.
With USB charging, you can also transfer data with the USB data cable while charging the device.
1 Connect a compatible USB device to
your device using a compatible USB data cable.
Depending on the type of the device that is used for charging, it may take a while for charging to start.
2 If the device is switched on, select
from the available USB mode options on the display of the device.
8 www.nokia.com/support
Cyan
Magenta
Black
Get started 9
Cyan
Magenta
Yellow
Black
Switch the device on and off
Press and hold the power key to switch the device on and off. Press the power key briefly to end a call or close an application.
If the device asks for a PIN code, enter the PIN code, and select OK.
If the device asks for the lock code, enter the lock code, and select OK. The factory setting for the lock code is 12345.
To set the correct time zone, time, and date, select the country you are presently in, then enter the local time and date.
Keypad lock (keyguard)
To lock the keypad in the home screen, press the left selection key and * within
1.5 seconds.
To set the device to automatically lock the keypad after a certain time, select
Settings > Settings and General > Security > Phone and SIM card > Keypad autolock period > User defined, and select the desired time.
>
To unlock the keypad, select Unlock, and press *. When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.
Volume control
To adjust the earpiece or loudspeaker volume during a call or when listening to an audio file, use the volume keys.
To activate or deactivate the loudspeaker during a call, select Loudsp. or Handset.
Warning:
Continuous exposure to high volume may damage your he aring. Listen to music at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.
Connect a compatible headset
Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.
When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.
www.nokia.com/support 9
Cyan
Magenta
Black
10 Get started
Cyan
Magenta
Yellow
Black
Antenna locations
Your device may have internal and external antennas. Avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with antennas affects the communication quality and may cause a higher power level during operation and may reduce the battery life.
Transfer content from another device
Select
With the Switch application, you can transfer content, such as contacts, between two compatible Nokia devices.
The type of content that can be transferred depends on the model of the device from which you want to transfer
> Settings > Switch.
content. If the other device supports synchronisation, you can also synchronise data between the other device and your device. Your device notifies you if the other device is not compatible.
If the other device cannot be switched on without a SIM card, you can insert your SIM card in it. When your device is switched on without a SIM card, the offline profile is automatically activated.
The other device must support Bluetooth connectivity.
Transfer content
To retrieve data from your other device for the first time:
1 Activate Bluetooth connectivity in
both devices.
2 Select the device from which you want
to transfer content. You are asked to enter a code on your device. Enter a code (1-16 digits), and select OK. Enter the same code on the other device, and select OK. The devices are now paired.
For some device models, the Switch application is sent to the other device as a message. To install the Switch application on the other device, open the message, and follow the instructions.
3 From your device, select the content
you want to transfer from the other device.
Content is transferred from the memory of the other device to the corresponding location in your device.
10 www.nokia.com/support
Cyan
Magenta
Black
Get started 11
Cyan
Magenta
Yellow
Black
Transfer time depends on the amount of data to be transferred. You can cancel the transfer and continue later.
The synchronisation is two-way, and the data in both devices is the same. If an item is deleted from either device, it is deleted from the other device when synchronising; you cannot restore deleted items by synchronising.
To view the log of the last transfer, select a shortcut in the main view and
Options > View log.
Install Ovi Suite
With the Nokia Ovi Suite application for PC, you can easily access the files on your Nokia C5-00, your other Nokia devices, and Ovi, all from a single view. You can transfer and synchronise messages, contacts, images, music, and more between your computer and device. You can also register for a Nokia account, share your images on Ovi, update your device software, download maps, and keep your content secure and accessible.
For more information, go to the support area at www.ovi.com.
For information on how to install Ovi Suite, see the included Ovi Suite leaflet.
If you do not want to install Ovi Suite, you can delete the installation files from the memory card to increase the available memory on the card.
Visit Ovi
Ovi contains services provided by
Nokia. With Ovi, you can create a mail
account, share your images and video clips with friends and family, plan trips and view locations on a map, download games, applications, video clips, and tones to your device, and purchase music. The available services may vary by region, and not all languages are supported.
To access Ovi services, go to www.ovi.com, and register your own Nokia account.
For more information on how to use the services, see the support pages of each service.
About Ovi Store
In Ovi Store, you can download mobile games, applications, videos, images, themes, and ringing tones to your device. Some items are free of charge; others you need to pay for with your credit card or in your phone bill. The availability of payment methods depends on your country of residence and your network service provider. Ovi Store offers content that is compatible with your mobile device and relevant to your tastes and location.
Remove a memory card Important: Do not remove the memory
card during an operation when the card is being accessed. Doing so may damage the memory card and the device, and corrupt data stored on the card.
1 Press the power key briefly, and select
Remove memory card > Yes.
2 Open the memory card slot cover. 3 Press the memory card gently to
release it.
www.nokia.com/support 11
Cyan
Magenta
Black
12 Basic use
Cyan
Magenta
Yellow
Black
4 Pull the card out, and select OK. 5 Close the slot cover.
Remove battery and SIM card
1 To remove the back cover of the
device, pull the release button (1) toward the bottom of the device, and lift the cover off (2).
2 Remove the battery.
3 Carefully pull the SIM card out of the
SIM card holder.
and indicate the uppercase
and lowercase. sentence case, that is, the first letter of the sentence is written in uppercase and all the other letters are automatically written in lowercase. mode.
To write text with the keypad, press a number key, 2-9, repeatedly until the desired character is displayed. There are more characters available for a number key than are printed on the key. If the next letter is located on the same key as the present one, wait until the cursor is displayed, and enter the letter.
To insert a number, press and hold the number key.
To switch between the different character cases and modes, press #.
To erase a character, press the clear key. Press and hold the clear key to erase more than one character.
To enter the most common punctuation marks, press 1 repeatedly until the desired punctuation mark is displayed.
To add special characters, press and hold *.
indicates the
indicates number
To insert a space, press 0. To insert a line
Basic use
Write text Traditional text input
indicates traditional text input.
12 www.nokia.com/support
Cyan
Magenta
break, press 0 three times.
Predictive text input
1 To activate or deactivate predictive
text input, press # twice quickly. This
Black
Basic use 13
Cyan
Magenta
Yellow
Black
activates or deactivates predictive text input for all editors in the device.
indicates that predictive text
input is activated.
2 To write the desired word, press the
keys 2-9. Press each key once for each letter.
3 When you have finished writing the
word, and it is correct, scroll right to confirm it, or press 0 to add a space.
If the word is not correct, press * repeatedly to view the matching words in the dictionary.
If the ? character is displayed after the word, the word you intended to write is not in the dictionary. To add a word to the dictionary, select Spell, enter the word (up to 32 letters) using traditional text input, and select OK. The word is added to the dictionary. When the dictionary is full, the new word replaces the oldest added word.
Write the first part of a compound word; to confirm it, scroll right. Write the second part of the compound word. To complete the compound word, press 0 to add a space.
Change the writing language
When you are writing text, you can change the writing language. For example, if you press the 6 key repeatedly to reach a specific character, changing the writing language gives you access to characters in a different order.
If you are writing text using a non-Latin alphabet and want to write Latin characters, for example e-mail or web addresses, you may need to change the
writing language. To change the writing language, select Options > Input
options > Writing language, and a
writing language that uses Latin characters.
Copy and delete text
1 To select letters and words, press and
hold #, and at the same time scroll left or right. To select lines of text, press and hold #, and at the same time scroll up or down.
2 To copy the text, press and hold #, and
at the same time select Copy. To delete the selected text, press the
clear key C.
3 To paste the text, scroll to the desired
location, press and hold #, and at the same time select Paste.
Menu
Press
In the menu, you can access the functions in your device.
To open an application or a folder, select the item.
If you change the order of the functions in the menu, the order may differ from the default order described in this user guide.
To mark or unmark an item in applications, press #.
To change the menu view, select
Options > Change Menu view.
To close an application or a folder, select
Options > Exit.
.
www.nokia.com/support 13
Cyan
Magenta
Black
14 Basic use
Cyan
Magenta
Yellow
Black
To display and switch between open applications, press and hold the home key, and select an application.
Leaving applications running in the background increases the demand on battery power and reduces the battery life.
Display indicators
The device is being used in a 3G network or a GSM network (network service). The bar next to the icon indicates the signal strength of the network at your current location. The higher the bar, the stronger the signal.
High-speed downlink packet access (HSDPA) / high-speed uplink packet access (HSUPA) (network service) in the 3G network is activated.
You have activated the offline profile, and the device is not connected to a cellular network.
The battery charge level. The higher the bar, the more charge remains in the battery.
You have unread messages in the Inbox folder in Messaging. If the indicator is blinking, your Inbox is full and you need to remove old messages from the Inbox before you can receive new messages.
You have received new e-mail in the remote mailbox.
There are messages waiting to be sent in the Outbox folder in Messaging.
You have missed calls.
The keys of the device are locked.
An alarm is active.
You have activated the silent profile, and the device does not ring for an incoming call or message.
Bluetooth connectivity is activated.
A Bluetooth connection is established. When the indicator is blinking, your device is trying to connect with another device.
A GPRS packet data connection is available (network service). indicates that the connection is active. connection is on hold.
An EGPRS packet data connection is available (network service). indicates that the connection is active. connection is on hold.
indicates that the
indicates that the
14 www.nokia.com/support
Cyan
Magenta
Black
Basic use 15
Cyan
Magenta
Yellow
Black
A 3G packet data connection is available (network service). indicates that the connection is active. connection is on hold.
HSDPA/HSUPA is supported and available (network service). The
icon may vary between regions. indicates that the connection is active. connection is on hold.
Your device is connected to a computer with a USB data cable.
The second phone line is being used (network service).
All calls are forwarded to another number. If you have two phone lines, a number indicates the active line.
A headset or a loopset is connected to the device.
A hands-free car kit is connected to the device.
Your device is synchronising.
Other indicators may also be displayed.
Shortcuts
Here are some of the available keyboard shortcuts in your device. Shortcuts can
indicates that the
indicates that the
make the use of the applications more efficient.
General shortcuts
Power key
* Press and hold to activate
# Press and hold to activate
Call key Press once to view a list of
Home
key
Home screen
Left selection key + *
Call key Open the call log.
Home
key
0 Press and hold to open
Press and hold to switch your device on and off.
Press once to switch between profiles.
or deactivate Bluetooth connectivity.
or deactivate the silent profile.
recently dialled numbers.
Press to go to the home screen from an open application.
Press and hold to switch between open applications.
Lock and unlock the keypad and keyboard.
Open the main menu.
your homepage in Web browser.
www.nokia.com/support 15
Cyan
Magenta
Black
16 Basic use
Cyan
Magenta
Yellow
Black
1 Press and hold to call your
Number key (2–9)
Offline profile
To quickly activate the Offline profile, press the power key briefly, and select
Offline.
To switch to another profile, press the power key briefly, and select a profile.
When the Offline profile is active, all connections that use radio frequencies are closed. However, you can use your device without the SIM card and listen to the radio or music. Remember to switch off your device when wireless phone use is prohibited.
Important: In the Offline profile you cannot make or receive any calls, or use other features that require cellular network coverage. Calls may still be possible to the official emergency number programmed into your device. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code.
Access codes
Select
To define how your device uses the access codes and security settings, select
voice mailbox.
Call a phone number using speed dialling. To activate speed dialling, select
> Settings >
Settings and Phone > Call > Speed dialling.
> Settings > Settings.
General > Security > Phone and SIM card and from the following:
The PIN (UPIN) code, supplied with the SIM (USIM) card, helps to protect the card against unauthorised use.
The PIN2 (UPIN2) code, supplied with some SIM (USIM) cards, is required to access certain services.
PUK (UPUK) and PUK2 (UPUK2) codes may be supplied with the SIM (USIM) card. If you enter the PIN code incorrectly three times in succession, you are asked for the PUK code. If the codes are not supplied, contact your service provider.
The security code helps to protect your phone against unauthorised use. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is locked, your phone will require service. Additional charges may apply, and all the personal data in your device may be deleted. For more information, contact a Nokia Care point or your device dealer.
The barring password is required when using the call barring service to restrict calls to and from your phone (network service).
Configuration settings
Before you can use multimedia messaging, e-mail, synchronisation, streaming, and the browser, you must have the proper configuration settings in your device. Your device may automatically configure browser,
16 www.nokia.com/support
Cyan
Magenta
Black
Personalise your device 17
Cyan
Magenta
Yellow
Black
multimedia messaging, access point, and streaming settings based on the SIM card used. If not, you can use the Settings wizard application to configure the settings. You may receive the settings as a configuration message that you can save to your device. For more information on availability, contact your service provider or nearest authorised Nokia dealer.
When you receive a configuration message, and the settings are not automatically saved and activated, 1 new
message is displayed. To save the
settings, select Show > Options > Save. You may need to enter a PIN code provided by the service provider.
Settings wizard
With Settings wizard, you can define e­mail and connection settings. The availability of the items in Settings wizard depends on the features of the device, SIM card, service provider, and the data in the Settings wizard database.
Select
To get the best results when using Settings wizard, keep your SIM card inserted in the device. If the SIM card is not inserted, follow the instructions on the display.
Select from the following: Operator — Define the operator-specific
settings, such as MMS, internet, WAP, and streaming settings.
E-mail setup — Configure a POP, IMAP, or Mail for Exchange account.
Video sharing — Configure video sharing settings.
> Settings > Sett. wizard.
The settings available for editing may vary.
Remote lock
You can lock your device from another device using a text message. To enable your device to be locked remotely, and to define the lock message to b e used, select
> Settings > General > Security
and Phone and SIM card > Remote
phone locking. When you have entered
the message, select OK. The message can be up to 20 characters long.
To lock your device, send the lock message as a text message to your mobile phone number. To unlock your device later, select Unlock, and enter the lock code.
Personalise your device
Home screen
When you have switched on the device, and it is registered to a network, the device is in the home scr een and ready for use.
To open a list of most recently dialled numbers, press the call key.
To call your voice mailbox, press and hold
1.
To use voice commands or voice dialling, press and hold the right selection key.
To change the profile, press the power key briefly, and select a profile.
To open a connection to the web, press and hold 0.
www.nokia.com/support 17
Cyan
Magenta
Black
18 Personalise your device
Cyan
Magenta
Yellow
Black
To modify the home screen, select >
Settings > Settings and General > Personalisation > Standby mode and
from the following: Standby theme — Select a home screen
theme. Shortcuts — Add shortcuts to
applications or events, or assign shortcuts to the scroll key, depending on the selected home screen theme.
Contacts bar
To add a contact to your home screen, select the Add contact icon and a contact from the list.
To create a new contact, select
Options > New contact, enter the
details, and select Done. You can also add an image to the contact information.
To add a web feed for a contact, select the Add feed icon, the desired feed from the list, and Done.
To create a new feed, select Options >
New feed.
To update a feed, select Refresh.
To remove a contact from the home screen, in the contact information view, select the Settings icon and Remove.
Menu view — Change the theme used in the main menu.
Standby — Change the theme used in the home screen.
Wallpaper — Change the background image of the home screen.
Power saver — Select an animation for the screen saver.
Call image — Change the image displayed during calls.
To activate or deactivate the theme effects, select General > Options >
Theme effects.
Download a theme
Select
To download a theme, select General >
Download themes > Options > Go to > New web page. Enter the web
address from which you want to download your theme. Once the theme is downloaded, you can preview or activate the theme.
To preview a theme, select Options >
Preview.
To activate a theme, select Options >
Set.
> Settings > Themes.
Themes Change the display theme
Select
Select from the following: General — Change the theme used in all
applications.
18 www.nokia.com/support
> Settings > Themes.
Cyan
Magenta
Talking theme
Select
Standby > Talking theme.
When the talking theme is activated, a list of functions supported by the talking theme is displayed in the active standby mode. As you scroll through the functions,
> Settings > Themes and
Black
Loading...
+ 40 hidden pages
