Microsoft RM-675, RM-675X User Manual
Nokia C7–00 User Guide
Cyan
Magenta
Yellow
Black
Cyan
9222032
Magenta
Issue 1
Yellow
Black
Contents
Cyan
Magenta
Yellow
Black
Safety 3
About this user guide 4
Use the in-device user guide 4
Get started 4
Keys and parts 4
Insert the SIM card and battery 5
Insert a memory card 6
Charging 7
Switch the device on or off 8
Nokia account and Nokia's Ovi
services 8
Device set-up 8
Copy contacts or pictures from your old
device 8
Lock or unlock the keys and screen 9
Change the volume of a call, song, or
video 9
Install Nokia Ovi Suite on your PC 9
Personalise your tones 13
Change your theme 13
Switch between home screens 13
Personalise the home screen 13
Add items to the home screen 14
About Mail 14
Social networks 14
About Social 14
Take a picture 15
Find more help 15
Support 15
Keep your device software and
applications up to date 16
Back up files 16
Access codes 17
Green tips 17
Save energy 17
Recycle 18
Touch screen actions 10
Call a phone number 11
Answer a call 12
Mute a call 12
Save phone numbers and mail
addresses 12
Add your important contacts to the
home screen 12
Send a message 12
Personalisation 13
2 www.nokia.com/support
Product and safety information 18
Cyan
Magenta
Yellow
Black
Safety
Cyan
Magenta
Yellow
Black
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
GLASS PARTS
The front cover of the device is
made of glass. This glass can
break if the device is dropped
on a hard surface or receives a
substantial impact. If the glass
breaks, do not touch the glass
parts of the device or attempt
to remove the broken glass
from the device. Stop using the
device until the glass is
replaced by qualified service
personnel.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not hold
the device near your ear when
the loudspeaker is in use.
KEEP YOUR DEVICE DRY
Your device is not waterresistant. Keep it dry.
www.nokia.com/support 3
Cyan
Magenta
Yellow
Black
About this user guide
Cyan
Magenta
Yellow
Black
Get started
This short user guide helps you get started
with your device. With a short printed user
guide, Nokia helps save energy and paper.
Your device contains a complete in-device
user guide, which you can refer to for
additional information about your device.
To read the in-device user guide, select
Menu > Applications > User guide.
For even more support information, go to
www.nokia.com/support, or using a
mobile device, nokia.mobi/support.
Use the in-device user guide
Select Menu > Applications > User
guide.
Open the user guide from an
application
Select Options > User guide. This is not
available for every application.
Search the user guide
When the user guide is open, select
Options > Search, and enter a letter or a
word in the search field.
Switch between the user guide and an
application
Press and hold the menu key, swipe left or
right, and select the desired application.
Keys and parts
Top
1 Micro USB connector
2 Nokia AV connector (3.5 mm)
3 Power key
Front
1 Earpiece
2 Call key
3 Microphone
4 Menu key
5 End key
6 Secondary camera lens
Links to related topics may be at the end
of instructions.
related topic, and
web page.
4 www.nokia.com/support
indicates a link to a
indicates a link to a
Cyan
Magenta
Yellow
Black
Sides
Cyan
Magenta
Yellow
Black
1 Charger connector
2 Volume up/Zoom in key
3 Voice key
4 Volume down/Zoom out key
5 Lock switch
6 Camera key
Back
Touch screen
To control your device, lightly touch the
screen with your fingertips. The screen
does not respond when you use your
fingernails.
If your fingertips are cold, the screen may
not respond to your touch.
To avoid scratching the touch screen,
never use a pen, pencil, or other sharp
object to write on the touch screen.
Noise cancellation
If you are calling from a noisy
environment, your device filters out
background noise to make your voice
sound clearer to the person at the other
end of the line.
Noise cancellation is not available when
using the loudspeaker or a headset.
For the best noise cancellation, hold the
device with the earpiece to your ear and
the main microphone towards your
mouth. Do not cover the secondary
microphone at the back of the device.
1 Loudspeaker
2 Camera lens
3 Camera flash
4 Secondary microphone
5 Wrist strap hole
www.nokia.com/support 5
Cyan
Magenta
Insert the SIM card and battery
Important: Do not use a micro-SIM or a
micro-SIM with an adapter in this device.
This device does not support use of microSIM cards, and use of incompatible SIM
cards may damage the card or the device,
and may corrupt data stored on the card.
Yellow
Black
Follow the instructions carefully, to avoid
Cyan
Magenta
Yellow
Black
damaging the back cover.
Safe removal. Always switch the device off
and disconnect the charger before
removing the battery.
1 Unlock the back cover release latch,
and lift the back cover.
2 If the battery is inserted, lift the
battery out.
3 Insert a SIM card. Use the diagram
printed on the device to correctly
align the card.
4 Line up the contacts of the battery and
the battery compartment, and insert
the battery.
Insert a memory card
Switch off the device before inserting a
memory card.
1 Remove the back cover of the device.
2 If the battery is inserted, lift the
battery out.
3 Insert a compatible memory card into
the slot. Make sure the contact area of
the card is facing down.
5 To replace the back cover, direct the
top locking catches toward their slots,
and press down until the cover locks
into place.
6 www.nokia.com/support
Cyan
Magenta
4 Push the card in, until it clicks.
Yellow
Black
5 Replace the battery and the back
Cyan
Magenta
Yellow
Black
cover. Make sure the cover is properly
closed.
Charging
Charge the battery
Your battery has been partially charged at
the factory, but you may need to recharge
it before you can switch on your device for
the first time.
If the device indicates a low charge, do the
following:
1
2
You do not need to charge the battery for
a specific length of time, and you can use
the device while it is charging.
If the battery is completely discharged, it
may take several minutes before the
charging indicator appears on the display
or before any calls can be made.
Tip: You can also use a compatible USB
charger to charge your battery.
Charge the battery over USB
Battery low, but you don't have a charger
with you? You can use a compatible USB
cable to connect to a compatible device,
such as a computer.
To avoid breaking the charger connector,
be careful when connecting or
disconnecting the charger cable.
If connected to a computer, you can
synchronise your device while charging.
Charging over USB can take longer to start,
and may not work if you connect through
a non-powered USB hub. Your device
charges more quickly when connected to
a wall outlet.
When the battery is charging, the
charging indicator light next to the USB
connector is lit. When the battery charge
is low, the charging indicator light flashes.
It may take a while for charging to start.
www.nokia.com/support 7
Cyan
Magenta
Yellow
Black
