Microsoft RM-662 User Manual

Nokia C3–01m User Guide

FCC-Draft

Issue 1

2Contents

Contents

Safety 5

Get started 6

Keys and parts 6
Insert the SIM card and battery 6
Insert or remove a memory card 7
Charge the battery 7
Charge the battery over USB 8
GSM antenna 8
Attach a strap 8

Switch it on 9

Network services and costs 9
Access codes 9
Switch the device on or off 9
Lock the keys and screen 9
Touch screen actions 10
Touch screen settings 10
Interactive home screen elements 11
Change the volume of a call, song, or
video 11
Indicators 11
Copy contacts or pictures from your old
device 11
Functions without a SIM card 12
Use your device offline 12
Flashlight 12

Device management 13

Support 13
My Nokia 13
Update device software using your
PC 13
Restore original settings 13
Organise files 13
Synchronise your calendar and contacts
with Ovi by Nokia 14

Back up your pictures and other content
to a memory card 14

China Mobile services 15

Telephone 15

Make a call 15
View your missed calls 15
Call the last dialled number 15
Divert calls to your voice mailbox or
another phone number 16
Save a number from a received call or
message 16
About internet calls 16
Make an internet call 16
Make a conference call 17
Allow calls only to certain numbers 17
Prevent making or receiving calls 17

Contacts 18

Save a name and phone number 18
Use speed dial 18
Send your contact information 19
Create a contact group 19
Move or copy contacts to your SIM
card 19

Phonebook manager 20

Chinese text input 20

Writing language 20
Switch between input methods 20
Pinyin input method 20
Stroke input method 21
Phrase input 21
Activate predictive English text
input 22
Traditional text input 22
Predictive text input 22
Writing text tips 23

www.nokia.com/support

Contents 3

Dictionary 23

Handwrite text 24

Messaging 25

Send a message 25
Send a message to a group of
people 25
Save an attachment 25
View a conversation 26
Listen to voice messages 26
Send an audio message 26

Nokia Messaging mail and IM 27

About Nokia Messaging mail 27
Sign in to a mail account 27
Send a mail 27
Read and reply to mail 27
About Chat 27
Sign in to a chat service 28
Chat with your friends 28
Hide the Chat application 28

Personalisation 29

About the home screen 29
Add a shortcut to the home screen 29
Add your important contacts to the
home screen 29
Personalise the Go to menu 29
Personalise the home screen 30
Change the look of your device 30
Create your own profile 30
Personalise your tones 30

Connectivity 31

Bluetooth 31
USB data cable 33
Connect to a WLAN 34

Nokia's Ovi services 35

Ovi by Nokia 35
Access Nokia's Ovi services 36
About Nokia Ovi Suite 36
Install Nokia Ovi Suite on your PC 36
Ovi Player 37

Time management 38

Change the time and date 38
Set an alarm 38
Snooze an alarm 38
Time your workout 38
Set the countdown timer 38
Calendar 39
Make a shopping list 39
Lunar calendar 39

Pictures and videos 40

Take a picture 40
Record a video 40
Send a picture or video 41
Photos 41
Print a picture 41

Music and audio 42

Media player 42
FM radio 43
Use voice recorder 44

Monternet 45

Web 45

About the web browser 45
Browse the web 45
Clear browsing history 45

My favorites 46

Games and applications 47

About games and applications 47
Improve your gaming experience 47

www.nokia.com/support

4Contents

Download a game or application 47
About Communities 47
Use the calculator 48
Convert currency and
measurements 48

Protect your device 49

Lock your device 49
Password protect your memory
card 49
Format a memory card 49
Prepare your device for recycling 49

Green tips 50

Save energy 50
Recycle 50

e100 51

Product and safety information 51

Index 58

www.nokia.com/support

Safety 5

Safety

Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.

INTERFERENCE

All wireless devices may be
susceptible to interference,
which could affect
performance.

QUALIFIED SERVICE

Only qualified personnel may
install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water­resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a
moderate level, and do not hold
the device near your ear when
the loudspeaker is in use.

BATTERIES AND OTHER ACCESSORIES

Use only batteries, chargers
and other accessories approved
by Nokia for use with this
device. Do not connect
incompatible products.

www.nokia.com/support

6Get started

Get started

Keys and parts

1 Earpiece
2 Display
3 Call key
4 Microphone
5 Flashlight key. Press and hold to

switch the flashlight on or off.

6 End key
7 Keypad
8 Shortcut to Monternet. Press and hold

the key to access Monternet.

9 Nokia AV connector (3.5 mm)
10 Micro USB connector
11 Volume up key
12 Volume down key
13 Keylock button
14 Camera key
15 Loudspeaker
16 Camera flash
17 Camera lens
18 Charger connector

Insert the SIM card and battery
Note: Switch the device off and

disconnect the charger and any other
device before removing any covers. Avoid
touching electronic components while
changing any covers. Always store and use
the device with any covers attached.

This device is intended for use with a
BL-5CT battery. Always use original Nokia
batteries.

The SIM card and its contacts can be easily
damaged by scratches or bending, so be
careful when handling, inserting, or
removing the card.

1 Slide the cover, and remove it. If the

battery is inserted, lift the battery out.

2 Insert a SIM card. Make sure the

contact area of the card is facing
down.

www.nokia.com/support

3 Line up the contacts of the battery and

the battery compartment, and insert
the battery. To replace the back cover,
direct the top locking catches toward
their slots, and slide the cover, until it
locks into place.

Insert or remove a memory card

Use only compatible memory cards
approved by Nokia for use with this
device. Incompatible cards may damage
the card and the device and corrupt data
stored on the card.

Your device supports memory cards with
a capacity of up to 16 GB.

Insert a memory card

Get started 7

2 Make sure the contact area of the card

is facing down. Push the card in, until
you hear a click.

3 Replace the back cover.

Remove the memory card
Important: Do not remove the memory

card when an application is using it. Doing
so may damage the memory card and the
device, and corrupt data stored on the
card.

You can remove or replace the memory
card without switching the device off.

1 Remove the back cover.
2 Push the card in, until you hear a click,

and pull the card out.

3 Replace the back cover.

Charge the battery

Your battery has been partially charged at
the factory, but you may need to recharge
it before you can switch on your device for
the first time.

If the device indicates a low charge, do the
following:

1 Remove the back cover.

www.nokia.com/support

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full

charge, disconnect the charger from
the device, then from the wall outlet.

8Get started

You do not need to charge the battery for
a specific length of time, and you can use
the device while it is charging.

If the battery is completely discharged, it
may take several minutes before the
charging indicator appears on the display
or before any calls can be made.

If the battery has not been used for a long
time, to begin charging, you may need to
connect the charger, then disconnect and
reconnect it.

Charging the device while listening to the
radio may affect the quality of reception.

Charge the battery over USB

Battery low, but you don't have a charger
with you? You can use a compatible USB
cable to connect to a compatible device,
such as a computer.

To avoid breaking the charger connector,
be careful when connecting or
disconnecting the charger cable.

GSM antenna

The figure shows the GSM antenna area
marked in grey.

Avoid touching the antenna area
unnecessarily while the antenna is
transmitting or receiving. Contact with
antennas affects the communication
quality and may cause a higher power
level during operation and may reduce the
battery life.

Attach a strap

Charging over USB can take longer to start,
and may not work if you connect through
a non-powered USB hub. Your device
charges more quickly when connected to
a wall outlet.

If connected to a computer, you can
synchronise your device while charging.

www.nokia.com/support

Switch it on 9

Switch it on

Network services and costs

Your device is approved for use on the GSM
850, 900, 1800, 1900 MHz networks. To
use the device, you need a subscription
with a service provider.

Using network services and downloading
content to your device may result in data
traffic costs. Some product features
require support from the network, and
you may need to subscribe to them.

Access codes

PIN code — This code protects your SIM
card against unauthorised use. The PIN
code (4 - 8 digits) is usually supplied with
the SIM card.

PIN2 code — This code (4 - 8 digits) is
supplied with some SIM cards, and is
required to access some functions in your
device.

If you forget an access code, contact the
network service provider whose SIM card
is in your device. After three consecutive
incorrect PIN or PIN2 code entries, the
code is blocked, and you need the PUK
code to unblock it.

PUK code and PUK2 code — These codes (8
digits) are required to change a blocked
PIN code or PIN2 code, respectively. If the
codes are not supplied with the SIM card,
contact the network service provider
whose SIM card is in your device.

IMEI number — This number (15 or 17
digits) is used to identify valid devices in
the GSM network. Devices that are, for
example, stolen, can be blocked from
accessing the network. The IMEI number

for your device can be found under the
battery.

Lock code (also known as security
code) — The lock code helps you to protect
your device against unauthorised use. You
can create and change the code, and set
the device to request the code. Keep the
new code secret and in a safe place
separate from your device. If you forget
the code and your device is locked, your
device will require service. Additional
charges may apply, and all the personal
data in your device may be deleted. For
more information, contact a Nokia Care
Point or your device dealer.

Switch the device on or off

Press and hold the power key

.

You may be prompted to get the
configuration settings from your service
provider (network service). For more
information, contact your service
provider.

Lock the keys and screen

To avoid accidentally making a call when
your device is in your pocket or bag, lock
the keys and screen of your device.

Press the keylock button

.

www.nokia.com/support

10 Switch it on

Unlock the keys and screen

Press the keylock button

, and select

Unlock.

Touch screen actions

To interact with the touch screen user
interface, tap or tap and hold the touch
screen.

Open an application or other screen
element

Tap the application or element.

Access item-specific options

Tap and hold the item. A pop-up menu
with available options opens.

Scroll in a list or menu

Place your finger on the screen, slide it
quickly up or down the screen, and then
lift your finger. The content of the screen
scrolls with the speed and direction it had
at the moment of release. To select an
item from a scrolling list and to stop the
movement, tap the item.

Swipe

Place a finger on the screen, and steadily
slide your finger in the desired direction.

For example, when you are viewing a
picture, to view the next picture, swipe
left. To quickly browse through your
pictures, swipe the screen quickly, and
then scroll left or right through the
thumbnails.

Touch screen settings

Calibrate the touch screen and activate
vibration feedback.

Select Menu > Settings > Phone >

Touch settings.

Calibrate the touch screen

Select Scr. calibration, and follow the
instructions.

www.nokia.com/support

Switch it on 11

Activate vibration feedback

Select Vibration feedb. > On.
When you tap an icon, the device gives a

short vibration feedback.

Interactive home screen elements

The home screen elements are interactive.
For example, you can change the date and
time, set alarms, or write calendar entries
directly in the home screen.

Set an alarm

Select the clock (1).

View or edit your schedule

Select the date (2).

Change the volume of a call, song, or
video

Use the volume keys.

The built-in loudspeaker allows you to
speak and listen from a short distance
without having to hold the device to your
ear.

Activate the loudspeaker during a call

Select Loudsp..

Indicators

You have unread messages.
You have unsent, cancelled,
or failed messages.
The keypad is locked.

The device does not ring for
incoming calls or text
messages.
An alarm is set.

/ The device is registered to the

GPRS or EGPRS network.

/

A GPRS or EGPRS connection is
open.

/ The GPRS or EGPRS connection

is suspended (on hold).
Bluetooth is activated.
WLAN is activated.
All incoming calls are diverted
to another number.
Calls are limited to a closed
user group.
The currently active profile is
timed.
A headset is connected to the
device.
The device is connected to
another device, using a USB
data cable.

Copy contacts or pictures from your old
device

Want to copy important information from
your previous compatible Nokia device
and start using your new device quickly?
Use the Phone switch application to copy,
for example, contacts, calendar entries,
and pictures to your new device, free of
charge.

Select Menu > Settings > Sync &

backup.

www.nokia.com/support

12 Switch it on

Both devices must have Bluetooth
activated.

1 Select Phone switch > Copy to this.
2 Select the content to copy and Done.
3 Select your previous device from the

list. If the device is not listed, make
sure Bluetooth is activated in the
device.

4 If the other device requires a

passcode, enter the passcode. The
passcode, which you can define
yourself, must be entered in both
devices. The passcode in some devices
is fixed. For details, see the user guide
of the device.

The passcode is valid only for the
current connection.

5 If prompted, allow connection and

copying requests.

Organiser functions and games. Some
functions appear dimmed in the menus
and cannot be used.

Use your device offline

In places where you are not allowed to
make or receive calls, you can activate the
flight profile and play games or listen to
music.

Select Menu > Settings > Profiles.

Select Flight > Activate.

indicates that the flight profile is

active.

Tip: You can add a profiles shortcut to the
shortcut widget in the home screen.

Warning:

When the flight profile is activated, you
cannot make or receive any calls,
including emergency calls, or use other
features that require network coverage.
To make a call, activate another profile.

Flashlight

The camera flash can be used as a
flashlight. To switch the flashlight on or
off, in the home screen, press and hold

.

Do not shine the flashlight in anyone's
eyes.

Functions without a SIM card

Some functions of your device may be
used without inserting a SIM card, such as

www.nokia.com/support

Device management 13

Device management

Support

When you want to learn more about how
to use your product or y ou are unsure how
your device should function, go to
www.nokia.com/support, or using a
mobile device, nokia.mobi/support.

If this does not resolve your issue, do one
of the following:

• Reboot your device. Switch off the
device, and remove the battery. After
about a minute, replace the battery,
and switch on the device.

• Restore the original factory settings.

• Update your device software.

If your issue remains unsolved, contact
Nokia for repair options. Go to
www.nokia.com/repair, or in Latin
America, www.nokia-latinoamerica.com/
centrosdeservicio. Before sending your
device for repair, always back up the data
in your device.

My Nokia

Select Menu > Applications > Extras >

Collection > My Nokia.

My Nokia is a free service that regularly
sends you text messages containing tips,
tricks, and support for your Nokia device.
It also allows you to browse the My Nokia
site where you can find details about
Nokia devices and download tones,
graphics, games, and applications.

To use the My Nokia service, it must be
available in your country and supported
by your service provider. You must sign up

to use the service. Text message charges
apply when you send messages to sign up
or unsubscribe. For terms and conditions,
see the documentation supplied with
your device, or go to www.nokia.com/
mynokia.

Update device software using your PC

You can use the Nokia Software Updater
PC application to update your device
software. To update your device software,
you need a compatible PC, a high-speed
internet connection, and a compatible
USB data cable to connect your device to
the PC.

To get more information and to download
the Nokia Software Updater application,
go to www.nokia.com/softwareupdate,
or in Latin America, www.nokia­latinoamerica.com/nsu.

Restore original settings

If your device is not working properly, you
can reset some settings to their original
values.

1 End all calls and connections.
2 Select Menu > Settings and Rest.

fact. sett. > Settings only.

3 Enter the security code.

This does not affect documents or files
stored on your device.

After restoring the original settings, your
device switches off and then on again.
This may take longer than usual.

Organise files

You can move, copy, delete, or create new
files and folders in your device memory or

www.nokia.com/support

14 Device management

on the memory card. If you organise your
files into their own folders, it might help
you find the files in future.

Select Menu > Applications > Gallery.

Create a new folder

In the folder where you want to create a
sub-folder, select Options > Add folder.

Copy or move a file to a folder

Select and hold the file, and from the pop­up menu, select the appropriate option.

Tip: You can also play music or videos, or
view pictures in Gallery.

Synchronise your calendar and
contacts with Ovi by Nokia

Select Menu > Settings > Sync &

backup.

1 Select Sync with Ovi > Sync now.
2 Sign in with your Nokia account

details. If you do not have an account,
sign up for one.

3 Follow the instructions.

Back up your pictures and other
content to a memory card

Want to make sure you will not lose any
important files? You can back up your
device memory to a compatible memory
card.

Select Menu > Settings > Sync &

backup.

Select Create backup.

Restore a backup

Select Restore backup.

www.nokia.com/support

China Mobile services 15

China Mobile services

China Mobile services provide you high­quality customer support and enriched
online contents, such as music, games,
weather forecast, and other services.

The services may use general packet radio
service (GPRS). For information on the
pricing of GPRS and China Mobile services,
contact your network service provider.

Access China Mobile services

Select Menu > China Mobile.

Contact customer support

Select Menu > China Mobile > Customer

Services.

The online contents and services may vary
depending on your device and your
network service provider.

Telephone

Make a call

1 Enter the phone number, including

the country and area code if
necessary.

2 Press the call key.

Answer an incoming call

Press the call key.

End a call

Press the end key.

Reject a call

Press the end key.

View your missed calls

In the home screen, you can see when you
have missed calls. To view the phone
number, select View. The caller's name is
displayed if stored in the contacts list.

Missed and received calls are logged only
if supported by the network, and the
device is switched on and within the
network service area.

Call back the contact or number

Select the contact or number, and press
the call key.

View the missed calls later

Select Menu > Phone Book > Log and

Missed calls.

www.nokia.com/support

Call the last dialled number

Trying to call someone, but they are not
answering? It is easy to call them again.

16 Telephone

In the home screen, press the call key,
select the number from the list, and press
the call key again.

Divert calls to your voice mailbox or
another phone number

When you cannot answer, you can divert
your calls to your voice mailbox or to
another number (network service).

1 Select Menu > Settings and Call >

Call divert.

2 Select If busy or If not answered.
3 Select Activate and To voice

mailbox or To other number.

Save a number from a received call or
message

Have you received a call or message from
a person whose phone number is not yet
saved in the contacts list? You can easily
save the number to your contacts.

Save a number from a received call

1 Select Menu > Phone Book > Log

and Received calls.

2 Select the number and Options >

Save.

3 Enter a name for the contact, and

select Save.

Save a number from a received
message

1 Select Menu > Messaging.
2 Select Conversations or Inbox and a

message.

3 Press the call key.
4 Select the number and Save.
5 Enter a name for the contact, and

select Save.

Tip: To add a new number to an existing
contact, select the number and Add to

contact.

About internet calls

You can make and receive calls over the
internet (network service). Internet call
services may support calls between
computers, between mobile devices, and
between a VoIP device and a traditional
telephone.

Some internet call service providers allow
free internet calls. For availability and
connectivity costs, contact your internet
call service provider.

To make or receive an internet call, you
must be in the service area of a WLAN or
have a packet data (GPRS) connection in a
3G network, and be signed in to an
internet call service.

Make an internet call

When you are signed into an internet call
service, you can make internet calls.

For availability and costs of internet calls,
contact your internet call service provider.

The Net phone wizard helps you set up
your account. Have your account
information from your internet call
service provider available before you start
the wizard.

Set up your internet telephone account

1 Make sure a valid SIM card is inserted,

and that your device is connected to a
WLAN.

www.nokia.com/support

Telephone 17

2 Select Menu > Settings and

Connectivity > Internet phone >
Accounts.

3 Select Add new.
4 Select an account and Connect, and

follow the instructions.

When the wizard has finished, your
account is displayed in the accounts list.

If the internet telephone settings do not
work, contact your service provider.

Call a contact

1 Select Menu > Phone Book and a

contact.

2 Select Internet call.

Call a phone number

Enter the phone number, and select

Options > Internet call.

For emergency calls, only the cellular
network is used.

Make a conference call

For availability, contact your service
provider.

1 While in a call, select Options >

More > New call.

2 Enter a phone number, or search for a

contact.
3 Press the call key.
4 When both calls are active, select

Options > Conference.

5 To end the conference call, select

Options > End all calls.

Allow calls only to certain numbers

With the fixed dialling service (network
service), you can restrict calls, and only
allow calls to certain phone numbers. For
example, you can allow your children to
call only family members.

Select Menu > Settings and Security.

1 Select Fixed dialling > On.
2 Enter your PIN2 code.
3 Add the desired numbers to the list of

allowed numbers.

Tip: If you want to send a text message
while the fixed dialling service is active,
you need to add the message centre
number to the list of allowed numbers.

www.nokia.com/support

Prevent making or receiving calls

Keep your phone bill under control by
preventing certain types of calls (network
service). You can prevent, for example,
incoming calls while you're abroad.

Select Menu > Settings and Security. To
prevent calls, you need a barring
password from your service provider.

18 Contacts

Prevent certain call types

1 Select Call barr. service and the

desired option.

2 Select Activate, and enter your

barring password.

Contacts

Save a name and phone number

Select Menu > Phone Book.

Select Add new.

Add and edit the details of a contact

1 Select Names and a contact.
2 Select Details > Options > Add

detail.

Tip: To add a ringing tone, picture, or

video for a contact, select the contact and

Options > Add detail > Multimedia.

Use speed dial

You can quickly call your friends and
family when you assign your most-used
phone numbers to the number keys of
your device.

Select Menu > Phone Book > Speed

dials.

Assign a phone number to a number
key

1 Select a number key. 1 is reserved for

the voice mailbox.

2 Enter a number or search for a

contact.

Make a call

In the home screen, press and hold a
number key.

Remove or change a phone number
assigned to a number key

Select and hold the number key, and from
the pop-up menu, select Delete or

Change.

www.nokia.com/support

Contacts 19

Deactivate speed dialling

Select Menu > Settings and Call > Speed

dialling.

Send your contact information

Want to send your phone number or mail
address to a person you just met? Add
your own contact information to your
contacts list, and send a business card to
the person.

Select Menu > Phone Book and Names.

1 Select the contacts list entry that

contains your information.

2 Select Business card and the sending

type.

Save a received business card

Select Show > Save.

Create a contact group

If you add your family members or friends
to a contact group, you can easily send a
message to all of them at the same time.

Select Menu > Phone Book.

1 Select Groups > Add.
2 Enter a name for the group, optionally

select an image and a ringing tone,
and select Save.

3 To add contacts to the group, select

the group and Add.

in the device memory, but you can copy
your contacts to a SIM card.

Select Menu > Phone Book.

More contacts can be stored in the device
memory, and contacts saved on the SIM
card can only have one phone number.

indicates a contact stored on the SIM

card.

Copy all contacts

Select Copy contacts > From ph. to SIM.

Move all contacts

Select Move contacts > From ph. to

SIM.

Tip: If contacts are stored in both the

device memory and on the SIM card,
duplicate contacts may be displayed in the
contacts list. To display only contacts
stored in the device, select Settings >

Memory in use > Phone.

Move or copy contacts to your SIM card

Want to use your SIM card in another
device, but still have access to your
contacts? By default, contacts are stored

www.nokia.com/support

20 Phonebook manager

Phonebook manager

Phonebook manager is a service provided
by China Mobile. You can back up or
restore your phonebook entries online.
For the availability of this service, pricing,
and detailed instructions, contact your
service provider.

Phonebook manager uses general packet
radio service (GPRS). For information on
the pricing of GPRS, contact your service
provider.

Subscribe to or unsubscribe from the
Phonebook manager service

Select Menu > China Mobile >

Phonebook mgr. > Enter > .

Back up or restore phonebook entries
online

Select Menu > China Mobile >

Phonebook mgr. > Enter > .

Search for phonebook entries online

Select Menu > China Mobile >

Phonebook mgr. > Enter > Online
enquiry.

Chinese text input

Writing language

The available input methods depend on
where the device is sold.

This device supports simplified Chinese
input methods.

To change the writing language when
writing text, press and hold #, and select

Writing lang. and the desired language.

Switch between input methods

Input method indicators are shown at the
top of the display:

Pinyin

Stroke

Uppercase

Lowercase

Number input

Not all the methods may be available in all
circumstances. Always check the indicator
to see which input method is in use.

To switch between the available input
methods, press # repeatedly, until the
indicator of the desired input method is
displayed.

Pinyin input method
Pinyin input

The pinyin symbols are printed on the
number keys. You only need to press a key
once, regardless of the position of the
symbol on the number key. The phone

www.nokia.com/support

makes logical combinations of the pinyin
symbols.

To input a character using the pinyin input
method:

1 Press the number key once for each

pinyin symbol you want to enter (use
"v" for "u").

2Press 1 repeatedly until the desired

tone mark is displayed.

3 If necessary, press * repeatedly to

highlight the desired pinyin
combination.

4 Select the desired Chinese character.

Ambiguous Pinyin

With this feature, your phone will tolerate
ambiguity of certain pinyin pairs: c/ch, z/
zh, s/sh, n/l, r/l, f/h, an/ang, in/ing, and
en/eng. To select which ambiguous pinyin
pairs to use, when no input symbol or
prediction list is displayed, select

Options > More > Ambig. pinyin.

Stroke input method

The strokes constituting Chinese
characters have been divided into five
categories: horizontal, vertical, left­falling, dot, and turning. Each category
corresponds to a number key from 1 to 5,
respectively.

The strokes are classified according to the
following table:

Chinese text input 21

1 In the standard stroke order, press the

number keys to input the strokes.

If you are not sure which stroke to use

or which category it belongs to, press

6 to substitute that stroke, then

continue with the subsequent

strokes. A question mark appears in

the input area to represent that

stroke.
2 Select the desired Chinese character.

Phrase input

You may input a phrase of no more than
seven Chinese characters at a time.

1 Press the relevant number keys to

enter the syllable or pinyin initial, or

first strokes for the first character of

the phrase.
2 Press 0 to enter a separator; or, if in

the pinyin mode, press 1 repeatedly

www.nokia.com/support

22 Chinese text input

to enter the tone mark of the
character.

3 Enter the syllable or pinyin initial, or

first strokes of the next Chinese
character.

4 Repeat step 2 and 3, if necessary, to

enter the syllables or pinyin initials, or
first strokes of all the characters in the
phrase.

5 If in the pinyin mode, press *

repeatedly, if necessary, to highlight
the pinyin combination you want.

6 Scroll through the candidate list, and

select the desired phrase.

Not all phrases are stored in your phone.
To create a phrase of no more than seven
characters, when no input symbol or
prediction list is displayed, select

Options > More > User phrases > Add.

When the database becomes full, the new
phrase replaces the phrase that has not
been accessed for the longest time.

Use a separator to separate pinyin strings
for syllables of different characters or the
strokes of different characters. When you
enter a separator, the phone predicts
characters or character strings that can
form a phrase with the possible
candidates of the combination of pinyin or
stroke strings and separators, if any, that
you have entered.

Activate predictive English text input

When writing text in English, press and
hold #, and select Prediction on or

Prediction off.

Traditional text input

Write a word

Press a number key (2-9) repeatedly, until
the desired character is displayed. The
available characters depend on the
selected writing language. If the next
letter is located on the same key, wait
until the cursor is displayed or move the
cursor forward, and press the key again.

Insert a common punctuation mark
Press 1 repeatedly.

Insert a special character

Press *, and select a character from the
list.

Insert a space
Press 0.

Predictive text input

The built-in dictionary suggests words as
you press the number keys. You can also
add your own words to the dictionary.

Write a word

Press the number keys (2-9). Press each
key once for each letter.

Confirm a word
Scroll right, or to insert a space, press 0.

Select the correct word

If the proposed word is not correct, press
* repeatedly, and select the desired word
from the list.

www.nokia.com/support

Chinese text input 23

Add a word to the dictionary

If ? is displayed after the word, the word
you intended to write is not in the
dictionary. To add the word to the
dictionary, select Spell. Enter the word
using traditional text input, and select

Save.

Write a compound word

Write the first part of the word, and scroll
right to confirm it. Write the next part of
the word, and confirm again.

Writing text tips

Insert a number when no input symbol
is displayed

Press and hold the desired number key.

Insert a space when there is no
candidate or prediction list displayed

Press 0.

Enter a special character after you have
finished entering a word or character

Press *.

End Chinese character prediction

Select Back, or press the relevant keys to
start entering new text.

3 Enter the Chinese or English word.
4 Scroll to the desired word in the

displayed list of words, and select it to

view the translation.

To look up synonyms or antonyms of

an English word, select Options >

Synonyms or Options > Antonyms.

To view the translation of the

previous or next word in the displayed

list of words, scroll left or right.

Dictionary

In Dictionary, you can look up a Chinese
word for English translation, and look up
an English word for Chinese translation.

1 Select Menu > Applications >

Dictionary.

2 Switch to the desired input mode if

necessary.

www.nokia.com/support

24 Handwrite text

Handwrite text

Write your message directly on the screen.

1 Select Menu > Messaging > Create

message.

2 Select
3 Select the # icon and the desired text

input mode (

4 Draw the desired character in the

writing field. The device proposes a
character. If it is not the correct
character, select the correct one from
the proposed matches.

.

, , or

).

Close the handwriting window

Select Done.

1 Writing mode indicator
2 Writing field
3 Change writing mode

4. Special characters

5. Move cursor

Gestures in Chinese text input mode

Draw gesture 1 for space, 2 for backspace,
3 for enter, or 4 to repeat the last character
before the cursor.

www.nokia.com/support

Messaging 25

Messaging

Send a message

Keep in touch with your family and friends
with text and multimedia messages. You
can attach your pictures, video clips and
business cards to your message.

Select Menu > Messaging.

1 Select Create message.
2 To add an attachment , select

Options > Insert object.

3 Write your message, and select

Continue.

4 To enter a phone number or mail

address manually, select Number or

mail. Enter a phone number, or select
Mail, and enter a mail address.

5 Select Send.

Tip: To insert a special character or a
smiley, select Options > Insert symbol.

Sending a message with an attachment
may be more expensive than sending a
normal text message. For more
information, contact your service
provider.

You can send text messages that are
longer than the character limit for a single
message. Longer messages are sent as
two or more messages. Your service
provider may charge accordingly.

Characters with accents, other marks, or
some language options, take more space,
and limit the number of characters that
can be sent in a single message.

If the item you inserted in a multimedia
message is too large for the network, the
device may automatically reduce the size.

Only compatible devices can receive and
display multimedia messages. Messages
may look different in different devices.

Send a message to a group of people

Would you like to send a message to all
your family members? If you have
assigned them to a group, you can send a
message to all of them at the same time.

Select Menu > Messaging.

1 Select Create message.
2 Write your message, and select

Continue.

3 To select a group, select Contact

groups.

4 Select Send.

Save an attachment

You can save attachments from
multimedia and mail messages to your
device.

Select Menu > Messaging.

Save an attachment

1 Open the message.
2 Select Options > Save contents.
3 Select the desired file and Options >

Save.

Save a mail attachment

1Open the mail.
2 Select the attachment.
3 Select Save.

www.nokia.com/support

26 Messaging

Pictures and videos are saved in Gallery.

View a conversation

You can see the messages you have sent
to and received from a particular contact
from a single view, and continue the
conversation from that view.

Select Menu > Messaging.

Read a message in a conversation

Select Conversations, a conversation,
and a message.

Switch to the traditional Inbox view

Select Options > Inbox view.

Listen to voice messages

When you cannot answer, you can divert
calls to your voice mailbox and listen to
your messages later.

The voice mailbox is a network service to
which you may need to subscribe. For
more information, contact your service
provider.

Call your voice mailbox
In the home screen, press and hold 1.

Save your voice mailbox number

1 Select Menu > Messaging > Voice

messages and Voice call msgs. >
Voice mbox. no..

2 Enter your voice mailbox number, and

select OK.

Send an audio message

Don't have time to write a text message?
Record and send an audio message
instead!

Select Menu > Messaging.

1 Select Other messages > Audio

message.

2 To record your message, select

3 To stop recording, select

.

.

4 Select Continue and a contact.

www.nokia.com/support

Nokia Messaging mail and IM 27

Nokia Messaging mail and IM

About Nokia Messaging mail

Select Menu > Messaging > Set up

mail.

Access your mail accounts from different
providers with your mobile device to read,
write, and send mail.

If you do not already have a mail account,
you can create a Nokia account, which
includes Nokia's Ovi Mail service. For more
information, go to www.ovi.com. With
your Nokia account, you can access all of
Nokia's Ovi services.

Sign in to a mail account

You can sign in to several mail accounts.

Select Menu > Messaging > Set up

mail.

1 Select your mail service provider.
2 Enter your account user name and

password.

3 If you select Save password:, you do

not need to enter your password
every time you want to access your
mail account.

4 Select Sign in.

To sign in to an additional mail account,
select Add account.

If you do not have a mail account, you can
set up an account for Nokia's Ovi Mail.

Set up Ovi Mail

Select Ovi Mail > Create new address,
and follow the instructions.

Send a mail

Select Menu > Messaging > Set up

mail and a mail account.

1 Select Options > Compose new.
2 Enter the recipient’s mail address and

the subject, and write your message.
3 To attach a file, for example, a picture,

select Options > Attach > From

Gallery.

4 To take a picture to attach to the mail,

select Options > Attach > From

Camera.

5 Select Send.

Read and reply to mail

Select Menu > Messaging > Set up

mail and a mail account.

1 Select a mail.
2 To reply to or forward a mail, select

Options.

About Chat

Select Menu > Messaging > Chat.

With Chat (network service), you can
exchange instant messages with your
friends. If you do not have a chat account,
you can create a Nokia account, and use
Nokia's Ovi Chat.

You can leave the Chat application running
in the background while you use other
features of your device, and still be
notified of new instant messages.

Using the service or downloading content
may cause transfer of large amounts of
data, which may result in data traffic
costs.

www.nokia.com/support

28 Nokia Messaging mail and IM

Sign in to a chat service

Select Menu > Messaging > Chat.

Sign in to an existing IM account

1 Select a chat service.
2 Enter your account user name and

password.

3 Follow the instructions.

Use several chat services at the same
time

1 Select a chat service, and sign in.
2 To switch between chat services,

open the corresponding tab.

Chat with your friends

Select Menu > Messaging > Chat.

You can sign in to and chat in several
services at the same time. You must
separately sign in to each service.

You can have ongoing conversations with
several contacts at the same time.

1 Select a chat service.
2 In your contacts list, select the contact

you want to chat with.

3 Write your message in the text box at

the bottom of the display.

4 Select Send.

other applications, and later return to
Chat without signing in again.

Receive notifications of new messages
when the application is hidden

1 In the Chat main view, select

Options > More > Settings.

2 Select the desired notification types

and Save.

Sign out from IM

Open the Chat application, and select

Options > Exit > Close.

All conversations are closed.

Hide the Chat application

Select Menu > Messaging > Chat.

Select Hide.

Your sessions remain active for a period of
time, according to your service
subscription. When the Chat application is
running in the background, you can open

www.nokia.com/support

Personalisation 29

Personalisation

About the home screen

In the home screen, you can:

• See notifications of missed calls and
received messages

• Open your favourite applications

• Control applications, such as the radio

• Add shortcuts for different features,

such as writing a message

• View your favourite contacts, and
quickly call, chat, or send messages to
them

Add a shortcut to the home screen

Want to open your favourite applications
directly from the home screen? You can
add shortcuts to your most used features.

1 Select and hold the shortcut widget,

and from the pop-up menu, select

Select shortcuts.

2 Select the shortcut you want to

define, and select the desired item.

Tip: To remove a shortcut, replace it with
another.

Tip: You can also add shortcuts to the Go
to menu. Select Go to > Personalise

view.

Add your important contacts to the
home screen

Want to quickly call or send messages to
your favourite contacts? You can add
shortcuts to selected contacts in the home
screen.

1 Select and hold the Favourite contacts

bar.

2 Select Edit favourites.

3 Select a contact icon

and a contact

from the list.
The contact needs to be stored in the

device memory.

Tip: If a picture is added to the contact, it
is displayed in the Favourite contacts bar.

Call or send a message to a contact

Select the contact in the Favourite
contacts bar, and from the pop-up menu,
select the appropriate option.

Remove a contact from the home
screen

1 Select and hold the Favourite contacts

bar.

2 Select Edit favourites and the contact

you want to remove.

The contact is removed from the Fav ourite
contacts bar, but remains in your contacts
list.

Personalise the Go to menu

You can add shortcuts to your most used
features.

1 Select Go to > Personalise view.
2 Select a menu item and the desired

feature from the list.

To access a feature, select Go to and the
desired feature.

www.nokia.com/support

30 Personalisation

Personalise the home screen

Want to see your favourite landscape or
pictures of your family in the home screen
background? You can change this
wallpaper, and rearrange items in the
home screen, to personalise it to your
liking.

Select Menu > Settings and Display.

Change the wallpaper

Select Wallpaper and a picture.

Tip: Download more wallpapers from
Nokia's Ovi Store. To learn more about Ovi
Store, go to www.ovi.com.

Add content to the home screen

Select Home screen > Personalise

view.

Tip: To increase the font size in the

Messaging and Contacts applications,
when browsing the web, or in the main
menu, select Font size.

Change the look of your device

With themes, you can change the colours
and look of your home screen.

Select Menu > Settings and Themes.

Select Select theme > Themes and a
theme from the list.

Tip: Download more themes from Nokia's
Ovi Store. To learn more about Ovi Store,
go to www.ovi.com.

Create your own profile

How can you make your device meet your
needs at work or college or home? You can
create new profiles for different
situations, and give them appropriate
names.

Select Menu > Settings > Profiles.

1 Select My style 1 or My style 2.
2 Select Personalise, and define your

profile settings.

3 Enter a name for the profile, and select

OK > Save.

Personalise your tones

You can personalise the ringing, key, and
warning tones for each profile.

Select Menu > Settings and Tones.

Change the ringing tone

Select Ringing tone: and a ringing tone.

Tip: Download more ringing tones from
Nokia's Ovi Store. To learn more about Ovi
Store, go to www.ovi.com.

Change the keypad tone volume

Select Keypad tones:, and drag the
volume bar.

www.nokia.com/support

Connectivity 31

Connectivity

Bluetooth
About Bluetooth connectivity

Select Menu > Settings >

Connectivity > Bluetooth.

Use Bluetooth to connect wirelessly to
compatible devices, such as other mobile
devices, computers, headsets, and car kits.

You can also use the connection to send
items from your device, transfer files from
your compatible PC, and print files with a
compatible printer.

Devices with Bluetooth wireless
technology do not need to be physically
next to one another, as this technology
uses radio waves. However, the devices
must be within 10 metres (33 feet) of each
other, otherwise the connection can break
up. Obstructions, such as walls or other
electronic devices, can cause interference.

This device is compliant with Bluetooth
Specification 2.1 + EDR supporting the
following profiles: SIM access, object
push, file transfer, headset, handsfree,
generic access, serial port, generic object
exchange, dial-up networking, device ID,
phonebook access, service discovery
application, advanced audio distribution,
audio video remote control, and generic
audio/video distribution. To ensure
interoperability between other devices
supporting Bluetooth technology, use
Nokia approved accessories for this
model. Check with the manufacturers of
other devices to determine their
compatibility with this device.

Note: There may be restrictions on the
use of Bluetooth technology in some
countries. For example, in France, you are
only allowed to use the Bluetooth
technology of this product indoors. For
more information, contact your local
authorities.

Tip: To access Bluetooth settings from the
home screen, add a shortcut to the
shortcut widget.

Connect to a wireless headset

Want to keep working at your computer
during a call? Use a wireless headset. You
can also answer a call, even if your device
is not directly at hand.

1 Select Menu > Settings >

Connectivity > Bluetooth and
Bluetooth > On.

2 Switch the headset on.
3 To pair your device and the headset,

select Conn. to audio acc..

4 Select the headset.

www.nokia.com/support

32 Connectivity

5 You may need to enter a passcode. For

details, see the user guide of the
headset.

Tip: You can set your device to connect
automatically to your Bluetooth headset,
once you have paired it for the first time.

Send a picture or other content to
another device

Use Bluetooth to send business cards,
calendar entries, pictures, videos, and
other content created by you to your
computer, as well as to your friend's
compatible devices.

1 Select the item to send.
2 Select Options > Send > Via

Bluetooth.

3 Select the device to connect to. If the

desired device is not displayed, select

New search, to search for it.

Bluetooth devices within range are
displayed.

4 If the other device requires a

passcode, enter the passcode. The
passcode, which you can define
yourself, must be entered in both
devices. The passcode in some devices
is fixed. For details, see the user guide
of the device.

The passcode is valid only for the
current connection.

Connect to a car kit using remote SIM
mode

With remote SIM mode, a compatible car
kit can use the SIM card of your device.

Select Menu > Settings >

Connectivity > Bluetooth.

Before you can activate remote SIM mode,
you must first pair your device and the car
kit.

1 To activate Bluetooth on your device,

select Bluetooth > On.

2 Activate Bluetooth in the car kit.
3 Follow the instructions on the display

of your device.

In remote SIM mode, only the car kit is
connected to the cellular network.

To make or receive calls when in remote
SIM mode, you need to have a compatible
accessory, such as a car kit, connected to
your device.

Your device will only allow emergency
calls in this mode.

Remote SIM mode is automatically
deactivated when the car kit is switched
off, for example, when you switch off the
car engine.

Manually deactivate remote SIM mode

1 Select Paired devices.
2 Select the car kit, and from the pop-up

menu, select Delete pairing.

Connect automatically to a paired
device

Do you regularly want to connect your
device to another Bluetooth device, such
as a car kit, headset, or your PC? You can
set your device to connect automatically.

Select Menu > Settings >

Connectivity > Bluetooth and Paired
devices.

www.nokia.com/support

Connectivity 33

1 Select the device to connect to

automatically.

2 From the pop-up menu, select

Settings > Auto-connect > Yes.

Use Bluetooth securely

Do you want to secure who can see your
device when using Bluetooth? You can
control who can find and connect to your
device.

Select Menu > Settings >

Connectivity > Bluetooth.

Prevent others from detecting your
device

Select Phone visibility > Hidden.
When your device is hidden, others cannot

detect it. However, paired devices can still
connect to your device.

Deactivate Bluetooth

Select Bluetooth > Off.

Do not pair with or accept connection
requests from an unknown device. This
helps to protect your device from harmful
content.

USB data cable
Copy a picture or other content
between your device and a computer

You can use a USB data cable to copy
pictures, videos, music, and other content
between your device and a compatible
computer.

1 Use a compatible USB cable to connect

your device to a computer.

2 Select from the following:

Nokia Ovi Suite — Use this mode if
your computer has Nokia Ovi Suite
installed.

Media transfer — Use this mode if
your computer does not have Nokia
Ovi Suite installed. If you want to copy
DRM-protected music, or use home
entertainment systems or printers,
use this mode.

Mass storage — Use this mode if
your computer does not have Nokia
Ovi Suite installed. The device is
displayed as a portable device on your
computer. If you want to connect your
device to other devices, such as a
home or car stereo, use this mode.

3 Use the file manager of the computer

to copy the content.

Copy a picture or other content
between your device and a USB
memory stick

You can copy pictures from your device to
a compatible USB memory stick. Use this
to create backups of pictures that you take
when travelling.

1 Connect a compatible USB OTG

adapter cable to the USB port of your
device.

2 Connect a memory stick to the USB

OTG adapter cable.

www.nokia.com/support

34 Connectivity

3 Select Menu > Applications >

Gallery, and select and hold a file or

folder.

4 Select if you want to copy or move the

file or folder.

5 Select the target folder.

Connect to a WLAN
About WLAN connections

Select Menu > Settings >

Connectivity > WLAN.

Connect to a wireless local area network
(WLAN) and manage your WLAN
connections.

Important: Use encryption to increase
the security of your WLAN connection.
Using encryption reduces the risk of
others accessing your data.

Note: Using WLAN may be restricted in
some countries. For example, in France,
you are only allowed to use WLAN indoors.
For more information, contact your local
authorities.

Connect to a WLAN at home

To help save data costs, connect to your
home WLAN when you are at home and
want to browse the web on your device.

Select Menu > Settings >

Connectivity > WLAN.

Connect for the first time

1 To search for your home WLAN, select

Available WLANs.

2 To connect, select your home WLAN.
3If the WLAN is secured

, enter the

password.

4 If you save your home WLAN, you do

not always have to search for it in
future. Select and hold the WLAN, and
from the pop-up menu, select Save.

indicates a saved WLAN.

Connect to your saved home WLAN

1 Select Saved WLANs.
2 Select your home WLAN.

Disconnect from a WLAN

Select the connected WLAN

.

Connect to a WLAN on the move

Connecting to a WLAN is a handy way of
accessing the internet when not at home.
Connect to public WLANs in public places,
such as a library or internet café.

Select Menu > Settings >

Connectivity > WLAN.

You need a password to connect to
secured WLANs

.

1 To search for available WLANs, select

Available WLANs.

2 Select a WLAN.
3 If the WLAN is secured, enter the

password.

Disconnect from a WLAN

Select the connected WLAN

.

Connect to a hidden WLAN

Select Menu > Settings >

Connectivity > WLAN.

www.nokia.com/support

Nokia's Ovi services 35

You can connect to a hidden WLAN, if you
know the name (SSID) and password.

1 To search for available WLANs, select

Available WLANs.

2 Select (Hidden network).
3 Enter the name (SSID) and the

password.

Disconnect from a WLAN

Select the connected WLAN

.

Nokia's Ovi services

Ovi by Nokia
Availability and costs of Nokia's Ovi
services

The availability of Nokia's Ovi services may
vary by region. Using the services or
downloading content may cause transfer
of large amounts of data, which may
result in data traffic costs. For information
about data transmission charges, contact
your network service provider.

About Ovi Store

With Ovi Store, you can download
mobile games, applications, videos,
pictures, themes, and ringing tones to
your device. Some items are free of
charge; others you need to pay for with
your credit card or in your phone bill. The
availability of payment methods depends
on your country of residence and your
network service provider. Ovi Store offers
content that is compatible with your
mobile device and relevant to your tastes
and location.

About Ovi Contacts

With Ovi Contacts, you can stay
connected to your friends and family,
follow what they are up to, and discover
new friends in the Ovi community. You can
also back up contacts from your device to
Ovi.

To use Ovi Contacts, go to www.ovi.com.

www.nokia.com/support

About Ovi Mail

With Ovi Mail, you can easily access
your mail from popular webmail
providers. If you register for a Nokia

36 Nokia's Ovi services

account, you can also get a free mail
account from Ovi, and use it on your
mobile device or computer. The anti-spam
protection helps keep your mailbox in
order, and the virus protection increases
security.

About Ovi Organiser

With Ovi Organiser, you can create
notes on your noteboard and in your
calendar and to-do list to keep track of
your everyday life, and save the notes in
notebooks in your Nokia account.

You can share your notebooks with your
friends and family.

To use Ovi Organiser, go to
www.ovi.com.

About Ovi Music

With Ovi Music, you can purchase and
download songs to your device and your
computer. To manage your music
collection and downloads, you can install
Ovi Player on your compatible PC, or use
your internet browser to download music.

To start discovering music, go to
www.ovi.com.

About Ovi Files

You can save files on your computer,
and access them later with your device
using Ovi Files even when your computer
is switched off. When you select which
folders and files you want to be available,
Ovi Files automatically keeps an up-to­date copy stored in a protected online
storage. You can also transfer files from
your computer to your device, and send
files and folders from your computer

without transferring them to your device
first.

To learn more about Ovi Files, go to
www.ovi.com.

Access Nokia's Ovi services

Select Menu > Applications > Extras >

Collection and the desired Ovi service.

Using some of the services or
downloading content may cause transfer
of large amounts of data, which may
result in data traffic costs.

About Nokia Ovi Suite

With the Nokia Ovi Suite PC application,
you can manage content on your device
and keep it in sync with your computer.

For more information, and to download
Nokia Ovi Suite, go to www.ovi.com.

Install Nokia Ovi Suite on your PC

You can manage content on your device,
and keep it in sync with your computer.

1 Use a compatible USB data cable to

connect your device to your
computer.

Your memory card appears as a
removable disk on your PC.

www.nokia.com/support

Nokia's Ovi services 37

2 On your device, select Mass storage.
3 On your computer, select Install

Nokia Ovi Suite.

If the installation window does not
open automatically, open the
installation file manually. Select Open

folder to view files, and double-click
Install_Nokia_Ovi_Suite.exe.

4 Follow the instructions.

To learn more about Nokia Ovi Suite, go to
www.ovi.com.

Ovi Player

With Nokia Ovi Player, you can play and
organise your music, download music
from Nokia's Ovi Music, copy songs and
playlists between your compatible PC and
compatible Nokia mobile devices, and rip
and burn your audio CDs.

To manage your music collection, open
the My Music tab. You can connect several
compatible devices to Ovi Player, and view
and play music stored on the devices.

To sample and download millions of songs
from Ovi, open the Ovi Music tab. To
download music, you need to create a
Nokia account.

www.nokia.com/support

38 Time management

Time management

Change the time and date

Select Menu > Settings and Date and

time.

Change the time zone when travelling

1 Select Date & time settings > Time

zone:.

2 Select the time zone of your location

and Save.

The time and date are set according to the
time zone. This makes sure that your
device displays the correct sending time
of received text or multimedia messages.

For example, GMT -5 denotes the time
zone for New York (USA), 5 hours west of
Greenwich, London (UK).

Set an alarm

You can use your device as an alarm clock.

Select Menu > Applications > Alarm

clock.

1 Set the alarm time.
2 Select
3 To set the alarm to sound, for

example, at the same time every day,
select Settings > Alarm repeat >

On and the days.

Snooze an alarm

When an alarm sounds, you can snooze
the alarm. This pauses the alarm for a
defined length of time.

When the alarm sounds, select Snooze.

to set the alarm.

Set the length of the snooze time

Select Menu > Applications > Alarm

clock and Settings > Snooze time-out,

and select the length of time.

Time your workout

Challenge yourself when running your
daily route! Use the stopwatch to time
yourself.

Select Menu > Applications >

Stopwatch.

Time your laps

1 Select Lap timing > Start.
2 Select Lap when moving on to the

next lap. The lap time is added to the
list, and the timer is reset.

3 Select Stop.

Take intermediate times

1 Select Split timing > Start.
2 Select Split. The intermediate time is

added to the list, and the timer
continues running.

3 Select Stop.

Tip: Want to save your times to compare
your results later? Select Save, and enter
a name.

Hide the stopwatch

Press the end key. To return to the timer,
select Menu > Applications >

Stopwatch and Continue.

Set the countdown timer

Need to quickly set an alarm for a certain
amount of time, for example, when

www.nokia.com/support

Time management 39

boiling eggs? Use the countdown timer to
set the alarm.

Select Menu > Applications > Countd.

timer.

1 Select Normal timer.
2 Enter a time, and write a note that is

displayed when the time expires.

3 Select Start.

In the home screen, you can see the timer,
and how much time is left.

Calendar
Add an appointment

Save your important appointments to
your calendar as meeting entries.

Select Menu > Applications >

Calendar.

1 Go to the desired date, and select

Options > Make a note.

2 Select the entry type field Meeting,

and fill in the fields.

Remember a birthday

Add a reminder for birthdays and other
special dates. The reminders are repeated
annually.

Select Menu > Applications >

Calendar.

1 Go to the desired date, and select

Options > Make a note.

2 Select the entry type field Birthday,

and fill in the fields.

Add a task to your to-do list

You can save a to-do note for a task you
must do, and add a reminder to your
calendar.

Select Menu > Applications > To-do

list.

1 Select Add, and fill in the fields.
2 To add a reminder, go to the desired

to-do note, select Options > Save to

Calendar > Reminder, and fill in the

fields.

Make a shopping list

Shopping lists on paper are easy to lose. If
you write them on your device, you always
have the list with you! You can also send
the list to, for example, a family member.

Select Menu > Applications > Notes.

1 Select Add.
2 Enter text in the note field.

Send the list

Open the note, and select Options > Send

note and the sending method.

Lunar calendar

To use the lunar calendar, the device
language must be Chinese.

Select Menu > Applications > Calendar
and Options > Month view.

View lunar details for a day

Select Options > Lunar calendar.

www.nokia.com/support

40 Pictures and videos

Search for a lunar festival

In the lunar day view, select Lun. fest.,
enter the Gregorian year of the Spring
festival, and select the desired lunar
festival.

In the lunar day view, select Options and
from the following:

Solar item — Search for a solar item.
Gregorian to lunar — Convert a

Gregorian date to a lunar date.
Lunar to gregorian — Convert a lunar

date to a Gregorian date.

Pictures and videos

Take a picture

1 In the home screen, press the camera

key.
2 To zoom in or out, select
3 Press the camera key.

The pictures are saved in Gallery.

Activate the camera flash

To set the device to use the flash
automatically if there is not enough light,
select

> Flash > Automatic. To set

the device to always use the flash, select

Flash on.

Close the camera

Press the end key.

Keep a safe distance when using the flash.
Do not use the flash on people or animals
at close range. Do not cover the flash while
taking a picture.

Your device supports an image capture
resolution of up to 1944x2592 pixels.

Record a video

Besides taking pictures with your device,
you can also capture your special
moments as videos.

In the home screen, press the camera key.

or .

1 To switch from image mode to video

mode, if necessary, select

> Video

camera.

2 To start recording, press the camera

key.

www.nokia.com/support

Pictures and videos 41

To zoom in or out, select or , or
use the volume keys.

3 Select

to pause and to stop the

recording.

Videos are saved in Gallery.

Close the camera

Press the end key.

Send a picture or video

Share your pictures and videos with
friends and family as a multimedia
message or through Bluetooth
connectivity.

Select Menu > Photos.

Send a picture

1 Select the folder containing the

picture.

2 Select the picture to send, and select

Options > Send and the desired

sending method.
You can send several pictures at once.

Select Options > Mark, and mark the
pictures.

Send a video

1 Select the folder containing the video.
2 Mark the video to send. Select

Options > Mark, and mark the video.

You can mark several videos to send.

3 Select Options > Send marked and

the desired sending method.

Photos
About Photos

Select Menu > Photos.

The Photos application is the place from
where you can view all pictures and videos
on your device. You can play videos, or
browse through pictures, and print out
the best shots.

Organise your pictures

You can organise your pictures into
folders.

Select Menu > Photos.

1 Select My albums.
2 Select

> Create album, and enter

a name for the album.

3 Select the pictures to add to the

album.

Edit a picture

Is the picture you took too dark or not
ideally framed? In Photos, you can rotate,
flip, crop, and adjust the brightness,
contrast, and colours of pictures you have
taken.

1 Select a picture in My photos,

Timeline, or My albums.

2 Select

and the desired effect.

Print a picture

You can print your pictures directly using
a compatible printer.

1 Use a USB data cable or, if supported

by the printer, Bluetooth connectivity,
to connect your device to a PictBridge
compatible printer.

2 Select Media transfer as the USB

connection mode.

3 Select the picture to print.
4 Select Options > Print.

www.nokia.com/support

42 Music and audio

Music and audio

Media player
Play a song

Play music stored in the device memory or
on the memory card.

Select Menu > Music > My music.

Play a song

Select a song from a folder.

To pause playing, select

.

select

Fast-forward or rewind

Select and hold

Close the media player

Press and hold the end key.

Tip: To return to the home screen, and
leave the player playing in the
background, press the end key.

Play a video

Play videos stored in the device memory
or on the memory card.

Select Menu > Music > My music.

1 Select a video from the folder.
2 To pause playback, select

resume, select

Fast-forward or rewind

Select and hold

Close the media player

Press and hold the end key.

; to resume,

or .

; to

.

or .

Copy music from your PC

Do you have music on your PC that you
want to listen on your device? Use Nokia
Ovi Player and a USB data cable to manage
and synchronise your music collection.

1 Use a compatible USB data cable to

connect your device to your

computer. Make sure a compatible

memory card is inserted in your

device.
2 Select Media transfer as the

connection mode.
3 On your computer, open Nokia Ovi

Player. For more information, see the

Ovi Player help.

Tip: You can buy music from Nokia's Ovi
Music. To learn more, go to
www.ovi.com.

Some music files can be protected by
digital rights management (DRM) and
cannot be played on more than one
device.

Change the sound or tone of your
music

Did you know you can change the sound
or tone of music, to better suit the genre?
You can customise profiles for different
music styles in the equaliser.

www.nokia.com/support

Music and audio 43

Select Menu > Music > My music > Go

to Media pl. > Options > More >
Equaliser.

Activate an existing sound profile

Select a set and Activate.

Create a new sound profile

1 Select one of the last two sets in the

list.

2 Select the sliders, and adjust them.
3 Select Save.

Connect loudspeakers to your device

Listen to music on your device through
compatible loudspeakers (sold
separately).

Connect wired loudspeakers

Connect the loudspeakers to the 3.5 mm
AV connector in your device.

Connect Bluetooth loudspeakers

1 Select Menu > Settings >

Connectivity > Bluetooth and On.

2 Switch the loudspeakers on.
3 To pair your device and the

loudspeakers, select Conn. to audio

acc..

4 Select the loudspeakers.
5 You may need to enter a passcode. For

details, see the user guide of the
loudspeakers.

FM radio
About the FM radio

Select Menu > Music > Radio.

You can listen to FM radio stations using
your device - just plug in a headset , and
select a station!

To listen to the radio, you need to attach
a compatible headset to the device. The
headset acts as an antenna.

It is not possible to listen to the radio
through a Bluetooth headset.

Listen to the radio

Select Menu > Music > Radio.

Pause or resume playback

Select

or ).

Set the radio to play in the background

Briefly press the end key.

Close the radio

Press and hold the end key.

Tip: To listen to the radio using the
headset or the loudspeaker, select

Options > Settings > Play via and the

desired option.

www.nokia.com/support

44 Music and audio

Find and save radio stations

Search for your favourite radio stations,
and save them, so you can easily listen to
them later.

Select Menu > Music > Radio.

Search for the next available station

Select and hold

or

Save a station

Select Options > Save station.

Switch to a saved station

Select

or .

Rename a station

Select and hold the station, and from the
pop-up menu, select Rename.

Tip: To access a station directly from the
saved station list, press the number key
that corresponds to the number of the
station.

Improve radio reception

If you activate RDS, the radio
automatically switches to a frequency
that has better reception.

Select Menu > Music > Radio.

1 Select Options > Settings > RDS >

On.

2 Select Auto-frequency > On.

Select Menu > Applications > Voice

recorder.

Record a sound clip

Select

.

Stop recording

Select

. The recording is saved in the

Recordings folder in Gallery.

Record a phone conversation

During a call, select Options > More >

Record.

Both parties hear a tone at regular
intervals during the recording.

Use voice recorder

You can record sounds from nature, such
as birds singing, as well as voice memos
or phone conversations.

www.nokia.com/support

Monternet 45

Monternet

Monternet allows you to establish a
connection to operator's WAP gateway
and access Monternet online contents
with your device browser, using general
packet radio service (GPRS).

For information on the pricing of GPRS and
Monternet, contact your service provider.

Access Monternet

Select Menu > Monternet.

Web

About the web browser

Select Menu > Internet.

You can view web pages on the internet
with your device web browser.

To browse the web, you must have an
internet access point configured in your
device and be connected to a network.

For the availability of these services,
pricing, and instructions, contact your
service provider.

You may receive the configuration
settings required for browsing as a
configuration message from your service
provider.

Browse the web

Select Menu > Internet.

Tip: If you do not have a flat-rate data plan
from your service provider, to save data
costs in your phone bill, you can use a
WLAN to connect to the internet.

Go to a web page

Select Go to address, and enter the
address.

www.nokia.com/support

Clear browsing history

Select Menu > Internet.

A cache is a memory location that is used
to store data temporarily. If you have, or
have tried to, access confidential
information or a secure service, requiring
passwords, clear the cache after each use.

46 My favorites

Empty the cache

While browsing a website, select

Options > Tools > Clear the cache.

Clear cookies

While browsing a website, select

Options > Tools > Clear cookies.

Prevent cookies from being stored

Select Web settings > Security >

Cookies.

My favorites

You can manage images, video clips, and
music files, or enter Applications.

Select Menu > Gallery.

www.nokia.com/support

Games and applications 47

Games and applications

About games and applications

Select Menu > Applications and Extras.

Your device may contain games or
applications. They can be stored in the
device memory or on a memory card, and
can be arranged in folders.

To view a list of games, select Games. To
view a list of applications, select

Collection.

Improve your gaming experience

Activate or deactivate sounds, lights, or
vibrations, and improve your gaming
experience.

Select Menu > Applications and

Extras > Options > Application sett..

Download a game or application

You can download games and
applications directly to your device.

Select Menu > Applications and

Extras > Options > Downloads.

Your device supports Java™ ME
applications, that have the .jad or .jar file
extension. Make sure an application is
compatible with your device before
downloading.

1 Select App. downloads or Game

downloads. A list of available

services is displayed.

2 Select a service, and follow the

instructions.

Tip: Download games and applications
from Nokia’s Ovi Store. To learn more
about Ovi Store, go to www.ovi.com.

About Communities

Select Menu > Applications > Extras >

Collection > Communities, and sign in

to your relevant social networking
services.

With the Communities application, you
can enhance your social networking
experience. When signed in to social
networking services, such as Facebook or
Twitter, you can do the following:

• See your friends' status updates

• Post your own status update

• Instantly share pictures you take with

the camera

Only those features that are supported by
the social networking service are
available.

Using social networking services requires
network support. This may involve the
transmission of large amounts of data and
related data traffic costs. For information
about data transmission charges, contact
your service provider.

The social networking services are third
party services and not provided by Nokia.
Check the privacy settings of the social
networking service you are using as you
may share information with a large group
of people. The terms of use of the social
networking service apply to sharing
information on that service. Familiarise
yourself with the terms of use and the
privacy practices of that service.

www.nokia.com/support

48 Games and applications

Use the calculator

Select Menu > Applications >

Calculator.

1 Select Options and either the

scientific or standard calculator.

2 Enter the calculation, and select =.

Tip: Use the loan calculator to calculate
interest rates, loan periods, or
instalments of a loan. To switch to the
loan calculator, select Options.

Convert currency and measurements
About the converter

Select Menu > Applications > Extras >

Collection > Converter.

With the converter, you can convert
measures and currencies from one unit to
another.

Convert measures

You can convert measures, such as length,
from one unit to another, for example,
kilometres to miles.

Select Menu > Applications > Extras >

Collection > Converter and Select.

1 Select a conversion category.
2 Select conversion units.
3 Enter a value in one of the unit fields.

The converted value is automatically
displayed in the other unit field.

1 Select Select > Currency and a

currency pair.
2 Enter the amount for one currency.

The converted value is displayed

automatically.

Set an exchange rate

Select Menu > Applications > Extras >

Collection > Converter.

Before you can convert currency, you must
set the exchange rate.

1 Select Options > Set exchange

rates.

2 Select a currency pair.
3 Enter the exchange rate for one of the

currencies.

Add a currency pair

You can add additional currency pairs to
be converted.

Select Menu > Applications > Extras >

Collection > Converter.

1 Select Options > New currency

conv..

2 Enter the names of the two currencies,

and select OK.
3 Enter the exchange rate for one of the

currencies.

Convert currency

With the converter, you can quickly
convert currencies.

Select Menu > Applications > Extras >

Collection > Converter.

www.nokia.com/support

Protect your device 49

Protect your device

Lock your device

Want to protect your device against
unauthorised use? Define a security code,
and set your device to lock itself
automatically when you're not using it.

Set a personalised security code

1 Select Menu > Settings and

Security > Access codes > Change
sec. code.

2 Enter the preset security code, 12345.
3 Enter a new code. A minimum of 5

characters is required, and numbers,
symbols, and upper and lower case
letters can be used.

Keep the security code secret and in a
safe place separate from your device.
If you forget the security code and
your device is locked, your device will
require service. Additional charges
may apply, and all the personal data
in your device may be deleted. For
more information, contact a Nokia
Care point or your device dealer.

Activate the security keyguard

Select Menu > Settings and Phone >

Secur. keyguard > On.

The device is locked when the keys and
screen are locked. You need the security
code to unlock the device.

Password protect your memory card

Want to protect the memory card against
unauthorised use? You can set a password
to protect the data.

1 Select Menu > Applications >

Gallery.

2 Select and hold the memory card, and

from the pop-up menu, select Mem.

card opt..

3 Select Set password, and enter a

password.
Keep the password secret and in a safe

place, separate from the memory
card.

Format a memory card

Want to delete all content from your
memory card? When you format a
memory card, all the data on it is deleted.

1 Select Menu > Applications >

Gallery.

2 Select and hold the memory card, and

from the pop-up menu, select Mem.

card opt..

3 Select Format m. card > Yes.

Prepare your device for recycling

If you buy a new device, or otherwise want
to dispose of your device, Nokia
recommends that you recycle your device.
Beforehand, you may want to remove all
personal information and content from
your device.

Remove all content and restore
settings to the original values

1 Back up the content you want to keep

to a compatible memory card (if
available) or to a compatible
computer.

2 End all calls and connections.
3 Select Menu > Settings and Rest.

fact. sett. > All.

www.nokia.com/support

50 Green tips

4 Your device switches off and then on

again. Check carefully that all your
personal content, such as contacts,
pictures, music, videos, notes,
messages, mails, presentations,
games, and other installed
applications have been removed.

Content and information stored on
the memory card or SIM card is not
removed.

Green tips

Save energy

You do not need to charge your battery so
often if you do the following (if available
for your device):

• Close applications and data

connections, for example, your

Bluetooth connection, when not in

use.

• Decrease the brightness of the screen.

• Set your device to enter power saver

mode after the minimum period of

inactivity, if available in your device.

• Deactivate unnecessary sounds, such

as key tones.

Recycle

All materials of this device can be
recovered as materials and energy. For
information on how to recycle your old
Nokia products, go to www.nokia.com/
werecycle, or using a mobile device,
nokia.mobi/werecycle.

Recycle packaging and user guides at your
local recycling scheme.

For more information on the
environmental attributes of your device,
go to www.nokia.com/ecodeclaration.

www.nokia.com/support

e100 51

e100

e100 is a one-stop self-service provided by
China Mobile, including the following
service channels:

• Online service centre: You can

subscribe to China Mobile services,
check your account balance or user
credit, make online payments, and
access online services. For more
information, go to
www.chinamobile.com.

• 10086 hotline: You can call 10086 to

get information on services,
promotions, your account balance,
service subscriptions, and Monternet.

• Message service centre: You can

send a text message containing
10086 to the service number 10086
to get information on promotions,
account balance, and service
subscriptions.

• WAP service centre: To subscribe or

get information on services, go to the
Monternet homepage, and select
WAP service centre.

• Self-service machine: You can pay

your phone bill, print call logs,
subscribe to services, or get
information on the services.

Product and safety information

Battery
Battery and charger information

This device is intended for use with a BL-5CT re chargeable
battery. Nokia may make additional battery models available
for this device. Always use original Nokia batteries.

This device is intended for use when supplied with power
from the following chargers: AC-8. The exact charger model
number may vary depending on the type of plug. The plug

variant is identified by one of the following: E, X, AR, U, A, C,
K, or B.

The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, you need
to replace the battery.

Battery safety

Always switch the device off a nd disconnect the charger
before removing the battery. When you unplug a charger or
an accessory, hold and pull the plug, not the cord.

When your charger is not in use, unplug it from the electrical
plug and the device. Do not leave a fully ch arged battery
connected to a charger, as overcharging may shorten the
battery’s lifetime. If left unused, a fully charged battery will
lose its charge over time.

Always keep the battery between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce the capacity and lifetime
of the battery. A device with a hot or cold battery may not
work temporarily.

Accidental short-circuiting can happen when a metallic object
touches the metal strips on the battery, for example, if you
carry a spare battery in your pocket. Short-circuiting may
damage the battery or the connecting object.

Do not dispose of batteries in a fire as they may explode.
Dispose of batteries according to local regulations. Recycle
when possible. Do not dispose as household waste.

Do not dismantle, cut, open, crush, bend, puncture, or shred
cells or batteries. If a battery leaks, do not let battery liquid
touch skin or eyes. If this happens, immediately flush the
affected areas with water, or seek medical help.

Do not modify, remanufacture, attempt to insert foreign
objects into the battery, or immerse or expose it to water or
other liquids. Batteries may explode if damaged.

Use the battery and charger for their intended purposes only.
Improper use, or use of unapproved batteries or chargers may
present a risk of fire, explosion, or other hazard, and may
invalidate any approval or warranty. If you believe the battery
or charger is damaged, take it to a service centre for
inspection before continuing to use it. Never use a damaged
battery or charger. Only use the charger indoors.

Nokia battery authentication guidelines

Always use original Nokia batteries for your safety. To help
ensure that you are getting an original Nokia battery,

www.nokia.com/support

52 Product and safety information

purchase it from a Nokia authorised service centre or dealer,
and check the hologram label.

Authenticate hologram

1 Look at the hologram. You should see the Nokia

connecting hands symbol from one angle and the Nokia
Original Accessories logo from the other angle.

2 Angle the hologram left, right, down, and up. You

should see 1, 2, 3 and 4 dots on each side respectively.

However, this is not a total assurance of the authenticity of
the battery. If you cannot confirm authenticity or if you have
any reason to believe that your Nokia battery with the
hologram on the label is not an authentic Nokia battery, stop
using the battery an d take it to the nearest Nokia author ised
service centre or d ealer.

For additional informa tion, refer to the warra nty and
reference leaflet included with your Nokia device.

Take care of your device

Handle your device, battery, charger and accessories with
care. The following suggestions help you protect your
warranty coverage.

• Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals that
corrode electronic circuits. If your device gets wet,
remove the battery, and allow the device to dry.

• Do not use or store the device in dusty or dirty areas.
Moving parts and electronic co mponents can be
damaged.

• Do not store the device in high temperatures. High
temperatures can shorten the life of the device,
damage the battery, and warp or melt plastics.

• Do not store the device in cold temperatures. When the
device warms to its normal temperature, moisture can
form inside the device and damage electronic circuits.

• Do not attempt to open the device other than as
instructed in the user guide.

• Unauthorised modifications may damage the device
and violate regulations governing radio devices.

• Do not drop, knock, or shake the device. R ough
handling can break internal circuit boards and
mechanics.

• Only use a soft, clean, dry cloth to clean the surface of
the device.

• Do not paint the device. Paint can clog the moving parts
and prevent proper operatio n.

• Switch off the device and remove the battery from time
to time for optimum performance.

• Keep your device away from magnets or magnetic
fields.

• To keep your important data safe, store it in at least
two separate places, such as your device, memory card,
or computer, or write down important information.

Recycle

Always return your used electronic products, batteries, and
packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote
the recycling of materials. Check product environmental
information and how to recycle your Nokia products at
www.nokia.com/werecycle, or with a mobile device , http://
nokia.mobi/werecycle.

About Digital Rights Management

When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent you from
copying, modifying, or transferring images, music, and other
content.

Content owners may use different types of digital rights
management (DRM) technologies to protect their intellectual
property, including copyrights. This device uses vari ous types
of DRM software to access DRM-protected content. With this
device you can access content protected with WMDRM 10,
OMA DRM 1.0, OMA DRM 1.0 forward lock, and OMA DRM 2.0. If

www.nokia.com/support

Product and safety information 53

certain DRM software fails to protect the content, content
owners may ask that such DRM software's ability to access
new DRM-protected content be revoked. Revocation may also
prevent renewal of s uch DRM-protected content already in
your device. Revocation of such DRM software does not affect
the use of content protected with other types of DRM or the
use of non-DRM-protected content.

Digital rights management (DRM) protected content comes
with an associated licence that defines your rights to use the
content.

If your device has OMA DRM-protected content, to back up
both the licences and the content, use the backup feature of
Nokia Ovi Suite.

Other transfer methods may not transfer the licences which
need to be restored with the content for you to be able to
continue the use of OMA DRM-protected content after the
device memory is formatted. You may also need to restore
the licences in case the files on your device get corrupted.

If your device has WMDRM-protected content, both the
licences and the conte nt will be lost if the device memory is
formatted. You may also lose the licences and the content if
the files on your device get corrupted. Losing the licences or
the content may limit your ability to use the same content on
your device again. For more information, contact your service
provider.

Some licences may be connected to a specific SIM card, and
the protected content can be accessed only if the SIM card is
inserted in the device.

Additional safety information
Small children

Your device, it s battery and accesso ries are not toys. Th ey may
contain small parts. Keep them out of the reach of small
children.

Operating environment

This device meets RF exposure guidel ines in the normal use
position at the ear or at least 1.5 centimetres (5/8 inch) away
from the body. Any carry cas e, belt clip, or holder for body­worn operation should not contain metal and should position
the device the above-stated distance from your body.

To send data files or messages requires a quality connection
to the network. Data files or messages may be delayed until
such a connection is available. Follow the separation distance
instructions until the transmission is completed.

Medical devices

Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a physician
or the manufacturer of the medical device to determine
whether they are adequately shielded from external RF
energy. Switch off your device when regulations posted
instruct you to do so, for example, in hospitals.

Implanted medical devices

Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker
or implanted cardioverter defibr illator, to avoid potential
interference with the medical device. Persons who have such
devices should:

• Always keep the wireless devic e more than 15.3
centimetres (6 inches) from the medical device.

• Not carry the wireless device in a breast pocket.

• Hold the wireless device to the ear opposite the medical

device.

• Turn the wireless device off if there is any reason to
suspect that interference is taking place.

• Follow the manufacturer directions for the implanted
medical device.

If you have any questions about using your wireless device
with an implanted medical device, consult your health care
provider.

Hearing

Warning:

When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.

Some wireless devices may interfere with some hearing aids.

Vehicles

Radio signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic antilock braking,
electronic speed control, and air bag systems. For more
information, check with the manufacturer of your vehicle or
its equipment.

Only qualified personnel should install the device in a vehicle.
Faulty installation or service may be dangerous and may

www.nokia.com/support

54 Product and safety information

invalidate your warranty. Check regularly that all wireless
device equipment in your vehicle is mounted and operating
properly. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the device,
its parts, or accessories. Remember that air bags inflate with
great force. Do not place your device or accessories in the air
bag deployment area.

Switch off your device before boarding an aircraft. The use of
wireless devices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.

Potentially explosive environments

Switch off your device in any area with a potentially explosive
atmosphere. Obey all posted instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily
injury or death. Switch off the device at refuelling points such
as near gas pumps at service stations. Observe restrictions in
fuel depots, storage , and distribution areas; chemical pla nts;
or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always,
clearly marked. They include areas where you would be
advised to turn off your vehicle engine, below deck on boats,
chemical transfer or storage facilities and where the air
contains chemic als or particles s uch as grain, dust, o r metal
powders. You should check with the manufacturers of
vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their
vicinity.

Emergency calls
Make an emergency call

1 Ensure the device is switched on.

2 Check for adequate signal strength. You may also need

to do the following:

• Insert a SIM card.

• Remove call restrictions you have activated for

your device, such as call barring, fixed dialling, or
closed user group.

• Ensure your device is not in an offline or flight
profile.

• If the device screen and keys are locked, unlock
them.

3 To clear the display, press the end key as many times

as needed.

4 Select Call.

5 Enter the official emergency number for your present

location. Emergency call numbers vary by location.

6Press the call key.

7 Give the necessary information as accurately as

possible. Do not end the call until given permission to
do so.

Important: Activate both cellular and internet calls, if your
device supports internet calls. The device may attempt to
make emergency calls both through cellular networks and
through your internet call service provider. Connections in all
conditions cannot be guaranteed. Never rely solely on any
wireless device for essential communications like medical
emergencies.

Protect your device from harmful content

Your device may be exposed to viruses and other harmful
content. Take the following precautions:

• Be cautious when opening messages. They may contain
malicious software or otherwise be harmful to your
device or computer.

• Be cautious when accepting connectivity requests,
browsing the internet, or downloading content. Do not
accept Bluetooth connections from sources you do not
trust.

• Only install and use services and software from sources
that you trust and that offer adequate security and
protection.

• Install antivirus and other security software on your
device and any connected computer. Only use one
antivirus application at a time. Using more may affect
performance and operati on of the device and/or
computer.

• If you access preinstalled bookmarks and links to third
party internet sites , take the appropriate precautions.
Nokia does not endorse or assume liability for such
sites.

Certification information (SAR)
This mobile device meets guidelines for exposure to

radio waves.

Your mobile device is a radi o transmitter and receiver . It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the indepe ndent scientific organisatio n
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.

The exposure guidelines for mobile devices employ a unit of
measurement known as the Specific Absorption Rate or SAR.
The SAR limit stated in the ICNIRP guidelines is 2.0 watts/
kilogram (W/kg) averaged over 10 grams of tissue. Tests for
SAR are conducted using standard operating positions with

www.nokia.com/support

the device transmitting at its highest certified power level in
all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because
the device is designed to use only the power required to reach
the network. That amount changes depending on a number
of factors such as how close you are to a network base station.

The highest SAR value under the ICNIRP guidelines for use of
the device at the ear is 0.87 W/kg.

Use of device accessories may result in different SAR values.
SAR values may vary depending on national reporting and
testing requirements and the network band. Additional SAR
information may be provided under product information at
www.nokia.com.

Your mobile device is also designed to meet the requirements
for exposure to radio wav es established by the Federal
Communications Commission (USA) and Industry Canada.
These requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The hi ghest SAR value reported under thi s
standard during product certification for use at the ear is 0.99
W/kg and when properly worn on the body is 0.58 W/kg.

Product and safety information 55

www.nokia.com/support

56

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this RM-662
product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at www.nokia.com/
phones/declaration_of_conformity/.

© 2010 Nokia. All rights reserved.

Nokia, Nokia Connecting People, Ovi, Nokia Xpress print,
Nokia Xpress audio messaging, and Navi are trademarks or
registered trademarks of Nokia Corporation. Nokia tune is a
sound mark of Nokia Corporation. Other product and
company names mentioned herein may be trademarks or
tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all
of the contents in this doc ument in any form without the prio r
written permission of Nokia is prohibited. Nokia oper ates a
policy of continuous development. Nokia reserves the right
to make changes and improvements to any of the products
described in this document without prior notice.

Includes RSA BSAFE cryptograp hic or security protocol
software from RSA Security.

Java and all Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent
Portfolio License (i) for personal and noncommercial use in
connection with information which has been encoded in
compliance with the MPEG-4 Visual Standard by a consumer
engaged in a personal and noncommercial activity and (ii) for
use in connection with MPEG-4 video provided by a licensed
video provider. No licens e is granted or shall be implied for
any other use. Additional information, including that related
to promotional, internal, and commercial uses, may be
obtained from MPEG LA, LLC. See http://www.mpegla.com.

To the maximum extent permitted by applicable law, under
no circumstances shall Nokia or any of its licensors be
responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever
caused.

The contents of this document are provided "as is". Except as
required by applicable law, no warranties of any kind, either
express or implied, including, but not limi ted to, the implied
warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or
contents of this docu ment. Nokia reserves the right to re vise
this document or withdraw it a t any time without prior
notice.
The availability of products, features, applications and
services may vary by region. For more information, contact
your Nokia dealer or your service provider. This device may
contain commodities, technology or software subject to
export laws and regulations from the US and other countries.
Diversion contrary to law is prohibite d.
Nokia does not provide a warranty for or take any
responsibility for the functionality, content, or end-user
support of third-party applications provided with your
device. By using an application, you acknowledge that the
application is provided as is. Nokia does not make any
representations, provi de a warranty, or take any
responsibility for the functionality, content, or end-user
support of third-party applications provided with your
device.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example,
when using a telephone in close proximity to receiving
equipment). The FCC or Industry Canada can require you to
stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local
service facility. This device complies wit h part 15 of the FCC
rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation. Any
changes or modificat ions not expressly ap proved by Nokia
could void the user's authority to operate this equipment.

Nokia C3–01m customised for China Mobile

The instructions in this user guide only apply to Nokia C3–01m
customised for China Mobile.

The post-sales service point and service content are similar
for both customised and other non-customised devices. With
regards to the menus and features provided with the device
customised for China Mobile, see Monternet or contact China
Mobile customer service hotline for more information, post­sales service, and technical support.

Nokia does not provide any warranty on technical support for
the services rendered by any network service provider,
content provider, or service p rovider.

For information on the content and pricing of the services
provided by China Mobile, contact China Mobile cust omer
service hotline.

Model number: C3–01m

FCC-Draft/Issue 1 EN

57

58 Index

Index

A

access codes 9
accounts 27, 28
alarm clock 38, 0 , 38
alarms 38, 0 , 38
anniversary entries 39
antennas 8
applications 47

B

backing up data 14
battery

— charging 7, 8
— inserting 6

birthday entries 39
Bluetooth 31, 32, 33
browser 45

See

web browser

business cards 19, 32

C

cable connection 33
cache 45
calculator 48
Calendar 39
calendar 32
calls

— conference 17
— diverting 16
— internet calls 16
— log 15, 16
— making 15
— restricting 17

camera

— recording videos 40
— sending pictures and videos 41

— taking pictures 40

charging the battery 7, 8
chat services (IM) 27, 28
China Mobile

— customer service 15
— services 15

clock 38, 0 , 38
connectivity 31, 34
contacts

— adding 18
— copying 11, 19
— groups 19, 25
— saving 16, 18, 19
— sending 19
— widgets 29

conversations 26
converter 48
copying content 11, 33, 42
countdown timer 38

D

data connections

— Bluetooth 31
— WLAN 34

date and time 38
device
— switching on/off 9
dictionary 23
downloads

— applications 47
— games 47

E

e-mail

See

mail

e100 51
equaliser 42

www.nokia.com/support

Index 59

F

factory settings, restoring 13
file management 13, 49
flashlight 12
flight profile 12
FM radio 43, 44

G

games 47

H

handwriting recognition 24
home screen 11, 29, 30

I

IM (instant messaging) 27, 28
images

See

pictures

inbox, messages 26
indicators 11
input methods 20
internet 45
internet calls 16

K

keyguard 9
keys and parts 6

L

lock code 9, 49
locking

— device 49
— keys 9
— screen 9

loudspeaker 11, 43
lunar calendar 39

M

mail 27, 35

— accounts 27
— creating 27
— reading and replying to 27
— sending 27
— setup 27

mailbox
— voice 26
meeting entries 39
memory 49
memory card 7, 49
messages 26

— attachments 25
— audio 26
— sending 25

MMS (multimedia message service) 25
Monternet 45
multimedia messages 25
music 42
— copying 42
My favorites 46
My Nokia 13

N

Nokia Messaging

— chat services (IM) 27
— mail 27

Nokia Ovi Suite 36
Nokia support information 13
Nokia's Ovi services 35
Notes 39

O

offline profile 12
Ovi 35, 36
Ovi Contacts 35
Ovi Files 36
Ovi Mail 35

www.nokia.com/support

60 Index

Ovi Music 36
Ovi Organiser 36
Ovi Player 37
Ovi Store 35
Ovi Suite

See

Nokia Ovi Suite

P

personalising your device 29, 30
Phone switch 11
phonebook manager 20
photographs

See

pictures

pictures

— copying 11, 33
— editing 41
— organising 41
— printing 41
— sending 32, 41
— taking 40
— viewing 41

PIN code 9
PIN2 code 9
pinyin input 20
powering device on/off 9
predictive text input 22
printing 41
profiles

— creating 30
— personalising 30

PUK codes 9

R

radio 43, 44
recording

— calls 44
— sounds 44
— videos 40

restoring data 14

restoring settings 13
ringing tones 30

S

searching
— radio stations 44
security code 9, 49
settings
— restoring 13
shortcuts 11, 29
SIM card 12
— inserting 6
SMS (short message service) 25
social networks 47
software updates 13
speed dialling 18
stopwatch 38
strap 8
stroke input 21
support 13
switching device on/off 9
synchronisation 14

T

taking pictures

See

camera

tasks 39
text input 20, 22, 24
text messages 25
themes 30
time and date 38
tones 30
touch screen 10
transferring content 11, 33, 42
turning device on/off 9

U

updates
— device software 13

www.nokia.com/support

USB charging 8
USB connection 33

V

videos

— copying 11, 33
— playing 41, 42
— recording 40
— sending 32, 41

voice messages 26
volume 11

W

web 45
web browser 45

— browsing pages 45
— cache 45
— cookies 45

WLAN (wireless local area network) 34

Index 61

www.nokia.com/support
