Nokia C5–00 User Guide

Issue 1

2Contents

Safety 5

About your device 5 Office applications 6 Network services 6

1. Get started 7

Keys and parts 7 Insert SIM card and battery 7 Insert a memory card 8 Wrist strap 8 Charge the battery 9 Switch the device on and off 10 Keypad lock (keyguard) 10 Volume control 10 Connect a compatible headset 10 Connect a USB data cable 11 Antenna locations 11 Transfer content from another device 11 Install Ovi Suite 12 Visit Ovi 12 About Ovi Store 12 Remove a memory card 13 Remove battery and SIM card 13

2. Basic use 13

Write text 13 Menu 15 Display indicators 15 Shortcuts 16 Offline profile 17 Access codes 17 Configuration settings 18 Settings wizard 18 Remote lock 18

3. Personalise your device 19

Home screen 19 Contacts bar 19 Themes 19 Profiles 20

4. Telephone 21

Make a call 21 Answer a call 21 Make a video call 22 Answer or decline a video call 22 Video sharing requirements 22 Share live video or video clips 23 Make a conference call 24 Speed dialling 24 Voice dialling 24 Recorder 25 Call and data registers 25 Call barring 25 Fixed dialling 26 Call divert 26 Call settings 27 Network settings 28

5. Contacts 28

Stay connected with your online friends 28 Copy contacts 28 Manage names and numbers 29 Save and edit names and numbers 29 Ringing tones and images for contacts 29

6. Messaging 30

About messaging 30 Write and send messages 30 E-mail 32 About Chat 34 Ovi Contacts 35

7. Connectivity 40

Contents 3

Connect your computer to web 40 About Ovi Files 41 Transfer content from another device 41 Bluetooth 42 Data cable 45 Sync 45

8. Web 46

About Web browser 46 Browse the web 46 About Search 47 Browser toolbar 47 Navigate pages 47 Web feeds and blogs 48 Content search 48 Bookmarks 48 Empty the cache 48 End the connection 49 Connection security 49 Web settings 49

9. Positioning 50

About GPS 50 Assisted GPS (A-GPS) 51 Maps 51 Landmarks 60 GPS data 60

10. Music and audio 61

Ovi Music 61 Music player 61 FM Radio 63

11. Camera 64

Capture an image 64 Record a video clip 65

12. Images and videos 65

About Gallery 65

Share online 65 Nokia Video Centre 66

13. Time management 67

Calendar 67 Alarm clock 69 Clock settings 69

14. Office applications 70

PDF reader 70 Dictionary 70 About Quickoffice 70 Converter 70 Calculator 71 Active notes 71 Notes 72 Zip manager 72

15. Settings 73

Application settings 73 Device and SIM card security 73 Common accessory settings 73 Restore original settings 74

16. Data management 74

Install or remove applications 74 File manager 76 Device manager 76 Protected content 78

17. Find help 78

Support 78 Keep your device software up to date 79 In-device help 79

18. Green tips 80

Save energy 80 Recycle 80

4Contents

Accessories 81

Battery 81

Battery and charger information 81 Nokia battery authentication guidelines 81

Taking care of your device 82

Recycle 82

Additional safety information 82

Small children 82 Operating environment 82 Medical devices 83 Vehicles 83 Potentially explosive environments 83 Emergency calls 83 Certification information (SAR) 84

Index 85

Safety 5

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not waterresistant. Keep it dry.

About your device

The wireless device described in this guide is approved for use on the (E)GSM 850, 900, 1800 and 1900 networks, and UMTS 900 and 2100 HSDPA and HSUPA networks. Contact your service provider for more information about networks.

Your device supports several connectivity methods and like computers may be exposed to viruses and other harmful content. Exercise caution with messages, connectivity requests, browsing, and downloads. Only install and use services and software from trustworthy sources that offer adequate security and protection, such as applications that are Symbian Signed or have passed the Java Verified™ testing. Consider installing antivirus and other security software on your device and any connected computer.

Your device may have preinstalled bookmarks and links for third-party internet sites and may allow you to access third-party sites. These are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you access such sites, take precautions for security or content.

6Safety

Warning:

To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.

Make back-up copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

The images in this guide may differ from your device display.

Refer to the user guide for other important information about your device.

Office applications

The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and

2003). Not all file formats are supported.

provider to use them. Network services involve transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply. Some networks may have limitations that affect how you can use some features of this device requiring network support such as support for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/ IP protocols and language-dependent characters.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have customized items such as menu names, menu order, and icons.

Safe removal. Always switch the device off and disconnect the charger before removing the battery.

Network services

To use the device you must have service from a wireless service provider. Some features are not available on all networks; other features may require that you make specific arrangements with your service

1. Get started

Keys and parts

Get started 7

1 Earpiece 2 Display 3 Left selection key 4 Home key 5 Call key 6 Number keys 7 Secondary camera lens 8 Navi™ key (scroll key). Can also be

used to capture images.

9 Right selection key 10 Clear key C 11 End/Power key 12 Microphone

13 Charger connector 14 Micro USB connector 15 Nokia AV connector (3.5 mm) 16 Camera flash 17 Volume keys. Can also be used to

zoom when using the camera.

18 Memory card slot 19 Main camera lens 20 Back cover release button 21 Wrist strap eyelet 22 Loudspeaker

Note: The surface of this device does not

contain nickel in the platings. The surface of this device contains stainless steel.

Insert SIM card and battery

1 To remove the back cover of the

device, pull the release button (1) toward the bottom of the device, and lift the cover off (2).

8Get started

2 Slide the SIM card into the SIM card

holder. The battery must be removed before you can insert the SIM card.

Ensure that the contact area on the card is facing down on the device, and the bevelled corner is facing towards the card holder slot.

3 Insert the battery.

Insert a memory card

The memory card may be supplied with the device, and may already be inserted.

1 Open the memory card slot cover.

2 Place the card in the slot with the

contact area facing up.

3 Push the card gently to lock it into

place. Close the slot cover.

4 To replace the back cover, carefully

align the top lugs (1), and line up the back cover, then gently press down until the cover locks into place (2).

Wrist strap

Thread the wrist strap, and tighten it.

A wrist strap may not be included.

Charge the battery

Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:

1 Connect the charger to a wall outlet. 2 Connect the charger to the device.

3 When the battery is fully charged,

disconnect the charger from the device, then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.

Tip: If you have old compatible Nokia chargers, you can use them with your

Get started 9

device by attaching the CA-44 charger adapter to the old charger. The adapter is available as a separate accessory.

USB charging

You can use USB charging when a wall outlet is not available. When charging your device with the USB data cable, the charging time is longer. USB charging efficiency varies significantly. In some cases, it may take a very long time for charging to start and the device to start functioning.

With USB charging, you can also transfer data with the USB data cable while charging the device.

1 Connect a compatible USB device to

your device using a compatible USB data cable.

Depending on the type of the device that is used for charging, it may take a while for charging to start.

2 If the device is switched on, select

from the available USB mode options on the display of the device.

10 Get started

Switch the device on and off

Press and hold the power key to switch the device on and off. Press the power key briefly to end a call or close an application.

If the device asks for a PIN code, enter the PIN code, and select OK.

If the device asks for the lock code, enter the lock code, and select OK. The factory setting for the lock code is 12345.

To set the correct time zone, time, and date, select the country you are presently in, then enter the local time and date.

Keypad lock (keyguard)

To lock the keypad in the home screen, press the left selection key and * within

1.5 seconds.

To set the device to automatically lock the keypad after a certain time, select

Settings > Settings and General > Security > Phone and SIM card > Keypad autolock period > User defined, and select the desired time.

To unlock the keypad, select Unlock, and press *. When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.

Volume control

To adjust the earpiece or loudspeaker volume during a call or when listening to an audio file, use the volume keys.

To activate or deactivate the loudspeaker during a call, select Loudsp. or Handset.

Warning:

Continuous exposure to high volume may damage your hear ing. Listen to music at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Connect a compatible headset

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Get started 11

Connect a USB data cable

Connect a compatible USB data cable to the USB connector.

To select the default USB connection mode or change the active mode, select

Settings and Connectivity > USB > USB connection mode, and select the desired

mode.

To select whether the default mode is activated automatically, select Ask on

connection.

Antenna locations

Your device may have internal and external antennas. Avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with antennas affects the communication quality and may cause a higher power level during operation and may reduce the battery life.

Transfer content from another device

Select

> Settings > Switch.

With the Switch application, you can transfer content, such as contacts, between two compatible Nokia devices.

The type of content that can be transferred depends on the model of the device from which you want to transfer content. If the other device supports synchronisation, you can also synchronise data between the other device and your device. Your device notifies you if the other device is not compatible.

If the other device cannot be switched on without a SIM card, you can insert your SIM card in it. When your device is switched on without a SIM card, the offline profile is automatically activated.

The other device must support Bluetooth connectivity.

Transfer content

To retrieve data from your other device for the first time:

1 Activate Bluetooth connectivity in

both devices.

12 Get started

2 Select the device from which you want

to transfer content. You are asked to enter a code on your device. Enter a code (1-16 digits), and select OK. Enter the same code on the other device, and select OK. The devices are now paired.

For some device models, the Switch application is sent to the other device as a message. To install the Switch application on the other device, open the message, and follow the instructions.

3 From your device, select the content

you want to transfer from the other device.

Content is transferred from the memory of the other device to the corresponding location in your device.

Transfer time depends on the amount of data to be transferred. You can cancel the transfer and continue later.

The synchronisation is two-way, and the data in both devices is the same. If an item is deleted from either device, it is deleted from the other device when synchronising; you cannot restore deleted items by synchronising.

To view the log of the last transfer, select a shortcut in the main view and

Options > View log.

Install Ovi Suite

With the Nokia Ovi Suite application for PC, you can easily access the files on your Nokia C5-00, your other Nokia devices, and Ovi, all from a single view. You can

transfer and synchronise messages, contacts, images, music, and more between your computer and device. You can also register for a Nokia account, share your images on Ovi, update your device software, download maps, and keep your content secure and accessible.

For more information, go to the support area at www.ovi.com.

For information on how to install Ovi Suite, see the included Ovi Suite leaflet.

If you do not want to install Ovi Suite, you can delete the installation files from the memory card to increase the available memory on the card.

Visit Ovi

Ovi contains services provided by Nokia. With Ovi, you can create a mail account, share your images and video clips with friends and family, plan trips and view locations on a map, download games, applications, video clips, and tones to your device, and purchase music. The available services may vary by region, and not all languages are supported.

To access Ovi services, go to www.ovi.com, and register your own Nokia account.

For more information on how to use the services, see the support pages of each service.

About Ovi Store

In Ovi Store, you can download mobile games, applications, videos, images, themes, and ringing tones to your device. Some items are free of charge; others you

need to pay for with your credit card or in your phone bill. The availability of payment methods depends on your country of residence and your network service provider. Ovi Store offers content that is compatible with your mobile device and relevant to your tastes and location.

Remove a memory card Important: Do not remove the memory

card during an operation when the card is being accessed. Doing so may damage the memory card and the device, and corrupt data stored on the card.

1 Press the power key briefly, and select

Remove memory card > Yes.

2 Open the memory card slot cover. 3 Press the memory card gently to

release it.

4 Pull the card out, and select OK. 5 Close the slot cover.

Remove battery and SIM card

1 To remove the back cover of the

device, pull the release button (1) toward the bottom of the device, and lift the cover off (2).

Basic use 13

3 Carefully pull the SIM card out of the

SIM card holder.

2. Basic use

Write text Traditional text input

indicates traditional text input.

and indicate the uppercase and lowercase. sentence case, that is, the first letter of the

sentence is written in uppercase and all the other letters are automatically written in lowercase. mode.

indicates the

indicates number

2 Remove the battery.

To write text with the keypad, press a number key, 2-9, repeatedly until the desired character is displayed. There are more characters available for a number key than are printed on the key. If the next letter is located on the same key as the present one, wait until the cursor is displayed, and enter the letter.

14 Basic use

To insert a number, press and hold the number key.

To switch between the different character cases and modes, press #.

To erase a character, press the clear key. Press and hold the clear key to erase more than one character.

To enter the most common punctuation marks, press 1 repeatedly until the desired punctuation mark is displayed.

To add special characters, press and hold *.

To insert a space, press 0. To insert a line break, press 0 three times.

Predictive text input

1 To activate or deactivate predictive

text input, press # twice quickly. This activates or deactivates predictive text input for all editors in the device.

indicates that predictive text

input is activated.

2 To write the desired word, press the

keys 2-9. Press each key once for each letter.

3 When you have finished writing the

word, and it is correct, scroll right to confirm it, or press 0 to add a space.

If the word is not correct, press * repeatedly to view the matching words in the dictionary.

If the ? character is displayed after the word, the word you intended to write is not in the dictionary. To add a word to the dictionary, select Spell, enter

the word (up to 32 letters) using traditional text input, and select OK. The word is added to the dictionary. When the dictionary is full, the new word replaces the oldest added word.

Write the first part of a compound word; to confirm it, scroll right. Write the second part of the compound word. To complete the compound word, press 0 to add a space.

Change the writing language

When you are writing text, you can change the writing language. For example, if you press the 6 key repeatedly to reach a specific character, changing the writing language gives you access to characters in a different order.

If you are writing text using a non-Latin alphabet and want to write Latin characters, for example e-mail or web addresses, you may need to change the writing language. To change the writing language, select Options > Input

options > Writing language, and a

writing language that uses Latin characters.

Copy and delete text

1 To select letters and words, press and

hold #, and at the same time scroll left or right. To select lines of text, press and hold #, and at the same time scroll up or down.

2 To copy the text, press and hold #, and

at the same time select Copy. To delete the selected text, press the

clear key C.

Basic use 15

3 To paste the text, scroll to the desired

location, press and hold #, and at the same time select Paste.

Display indicators

The device is being used in a 3G network or a GSM network (network service). The bar next to the icon indicates the signal strength of the network at your current location. The higher the bar, the stronger the signal.

High-speed downlink packet access (HSDPA) / high-speed uplink packet access (HSUPA) (network service) in the 3G network is activated.

You have activated the offline profile, and the device is not connected to a cellular network.

The battery charge level. The higher the bar, the more charge remains in the battery.

You have unread messages in the Inbox folder in Messaging. If the indicator is blinking, your Inbox is full and you need to remove old messages from the Inbox before you can receive new messages.

You have received new e-mail in the remote mailbox.

There are messages waiting to be sent in the Outbox folder in Messaging.

You have missed calls.

The keys of the device are locked.

An alarm is active.

You have activated the silent profile, and the device does not ring for an incoming call or message.

Bluetooth connectivity is activated.

16 Basic use

A Bluetooth connection is established. When the indicator is blinking, your device is trying to connect with another device.

A GPRS packet data connection is available (network service). indicates that the connection is active.

indicates that the

connection is on hold.

An EGPRS packet data connection is available (network service). indicates that the connection is active.

indicates that the

connection is on hold.

A 3G packet data connection is available (network service). indicates that the connection is active.

indicates that the

connection is on hold.

HSDPA/HSUPA is supported and available (network service). The icon may vary between regions. indicates that the connection is active.

indicates that the

connection is on hold.

Your device is connected to a computer with a USB data cable.

The second phone line is being used (network service).

lines, a number indicates the active line.

A headset or a loopset is connected to the device.

A hands-free car kit is connected to the device.

Your device is synchronising.

Other indicators may also be displayed.

Shortcuts

Here are some of the available keyboard shortcuts in your device. Shortcuts can make the use of the applications more efficient.

General shortcuts

Power key

Press and hold to switch your device on and off.

Press once to switch between profiles.

* Press and hold to activate

or deactivate Bluetooth connectivity.

# Press and hold to activate

or deactivate the silent profile.

Call key Press once to view a list of

recently dialled numbers.

All calls are forwarded to another number. If you have two phone

Basic use 17

Home

key

Press to go to the home screen from an open application.

Press and hold to switch between open applications.

Home screen

Left selection

Lock and unlock the keypad and keyboard.

key + *

Call key Open the call log.

Home

Open the main menu.

key

0 Press and hold to open

your homepage in Web browser.

1 Press and hold to call your

voice mailbox.

Number key (2–9)

Call a phone number using speed dialling. To activate speed dialling, select

Settings > Settings and Phone > Call > Speed dialling.

Offline profile

To quickly activate the Offline profile, press the power key briefly, and select

Offline.

To switch to another profile, press the power key briefly, and select a profile.

When the Offline profile is active, all connections that use radio frequencies are closed. However, you can use your

device without the SIM card and listen to the radio or music. Remember to switch off your device when wireless phone use is prohibited.

Important: In the Offline profile you cannot make or receive any calls, or use other features that require cellular network coverage. Calls may still be possible to the official emergency number programmed into your device. To make calls, you must first activate the phone function by changing profiles. I f the device has been locked, enter the lock code.

Access codes

Select

> Settings > Settings.

To define how your device uses the access codes and security settings, select

General > Security > Phone and SIM card and from the following:

• The PIN (UPIN) code, supplied with the

SIM (USIM) card, helps to protect the card against unauthorised use.

• The PIN2 (UPIN2) code, supplied with

some SIM (USIM) cards, is required to access certain services.

• PUK (UPUK) and PUK2 (UPUK2) codes

may be supplied with the SIM (USIM) card. If you enter the PIN code incorrectly three times in succession, you are asked for the PUK code. If the codes are not supplied, contact your service provider.

• The security code helps to protect

your phone against unauthorised use. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If

18 Basic use

you forget the code and your phone is locked, your phone will require service. Additional charges may apply, and all the personal data in your device may be deleted. For more information, contact a Nokia Care point or your device dealer.

• The barring password is required when using the call barring service to restrict calls to and from your phone (network service).

Configuration settings

Before you can use multimedia messaging, e-mail, synchronisation, streaming, and the browser, you must have the proper configuration settings in your device. Your device may automatically configure browser, multimedia messaging, access point, and streaming settings based on the SIM card used. If not, you can use the Settings wizard application to configure the settings. You may receive the settings as a configuration message that yo u can save to your device. For more information on availability, contact your service provider or nearest authorised Nokia dealer.

When you receive a configuration message, and the settings are not automatically saved and activated, 1 new

message is displayed. To save the

settings, select Show > Options > Save. You may need to enter a PIN code provided by the service provider.

Settings wizard

With Settings wizard, you can define email and connection settings. The availability of the items in Settings wizard depends on the features of the device, SIM

card, service provider, and the data in the Settings wizard database.

Select

> Settings > Sett. wizard.

To get the best results when using Settings wizard, keep your SIM card inserted in the device. If the SIM card is not inserted, follow the instructions on the display.

Select from the following: Operator — Define the operator-specific

settings, such as MMS, internet, WAP, and streaming settings.

E-mail setup — Configure a POP, IMAP, or Mail for Exchange account.

Video sharing — Configure video sharing settings.

The settings available for editing may vary.

Remote lock

You can lock your device from another device using a text message. To enable your device to be locked remotely, and to define the lock message to be used, select

> Settings > General > Security

and Phone and SIM card > Remote

phone locking. When you have entered

the message, select OK. The message can be up to 20 characters long.

To lock your device, send the lock message as a text message to your mobile phone number. To unlock your device later, select Unlock, and enter the lock code.

Personalise your device 19

3. Personalise your device

Home screen

When you have switched on the device, and it is registered to a network, the device is in the home screen and ready for use.

To open a list of most recently dialled numbers, press the call key.

To call your voice mailbox, press and hold

To use voice commands or voice dialling, press and hold the right selection key.

To change the profile, press the power key briefly, and select a profile.

To open a connection to the web, press and hold 0.

To modify the home screen, select

Settings > Settings and General > Personalisation > Standby mode and

from the following: Standby theme — Select a home screen

theme. Shortcuts — Add shortcuts to

applications or events, or assign shortcuts to the scroll key, depending on the selected home screen theme.

Contacts bar

To add a contact to your home screen, select the Add contact icon and a contact from the list.

To create a new contact, select

Options > New contact, enter the

details, and select Done. You can also add an image to the contact information.

To add a web feed for a contact, select the Add feed icon, the desired feed from the list, and Done.

To create a new feed, select Options >

New feed.

To update a feed, select Refresh.

To remove a contact from the home screen, in the contact information view, select the Settings icon and Remove.

Themes Change the display theme

Select

Select from the following: General — Change the theme used in all

applications. Menu view — Change the theme used in

the main menu. Standby — Change the theme used in the

home screen. Wallpaper — Change the background

image of the home screen. Power saver — Select an animation for

the screen saver. Call image — Change the image

displayed during calls.

To activate or deactivate the theme effects, select General > Options >

Theme effects.

Download a theme

Select

To download a theme, select General >

Download themes > Options > Go to > New web page. Enter the web

> Settings > Themes.

20 Personalise your device

address from which you want to download your theme. Once the theme is downloaded, you can preview or activate the theme.

To preview a theme, select Options >

Preview.

To activate a theme, select Options >

Set.

Talking theme

Select

> Settings > Themes and

Standby > Talking theme.

When the talking theme is activated, a list of functions supported by the talking theme is displayed in the home screen.When the talking theme is activated, a list of functions supported by the talking theme is displayed in the active standby mode. As you scroll through the functions, the device reads the displayed functions aloud. Select the desired function.

To listen to the entries in your contacts list, select Call features > Contacts.

To listen to information on your missed and received calls, and dialled numbers, select Call features > Recent calls.

To make a call by entering the phone number, select Call features > Dialler and the desired numbers. To enter a phone number, scroll to the digits and select them one by one.

To call your voice mailbox, select Call

features > Voice mailbox.

To use voice commands to make a call, select Voice commands.

To have your received messages read aloud, select Message reader.

To listen to the current time, select

Clock. To listen to the current date, scroll

down.

If the calendar alarm expires when you are using voice aid, the application reads the calendar alarm content aloud.

To listen to the available options, select

Options.

Profiles

Select

> Settings > Profiles.

You can adjust and customise the ringing tones, alert tones, and other device tones for different events, environments, or caller groups. The active profile is shown at the top of the display in the home screen.The active profile is shown at the top of the display in the standby mode. However, if the active profile is General, only today's date is shown.

To create a new profile, select Options >

Create new, and define the settings.

To customise a profile, select a profile and

Options > Personalise.

To change a profile, select a profile and

Options > Activate. The Offline profile

prevents your device from accidentally switching on, sending or receiving messages, or using Bluetooth

Telephone 21

connectivity, GPS, or FM radio; it also closes any internet connection that may be in operation when the profile is selected. The Offline profile does not prevent you from establishing a Bluetooth connection at a later time, or from restarting the GPS or FM radio, so comply with any applicable safety requirements when establishing and using these features.

To set the profile to be active until a certain time within the next 24 hours, scroll to the profile, select Options >

Timed, and set the time. When the time

expires, the profile changes back to the previously active non-timed profile. When the profile is timed, home screen.When the profile is timed,

is displayed in the standby mode. The

Offline profile cannot be timed.

To delete a profile that you created, select

Options > Delete profile. You cannot

delete the predefined profiles.

is displayed in the

4. Telephone

Make a call

To make a call, enter the phone number, including the area code, and press the call key.

Tip: For international calls, add the + character that replaces the international access code, and enter the country code, area code (omit the leading 0, if necessary), and phone number.

To end the call or cancel the call attempt, press the end key.

To make a call using the saved contacts, open the contacts. Enter the first letters of the name, scroll to the name, and press the call key.

To make a call using the log, press the call key to view up to 20 numbers that you last called or attempted to call. Scroll to the desired number or name, and press the call key.

To adjust the volume of an active call, use the volume keys.

To switch from a voice call to a video call, select Options > Switch to video call. The device ends the voice call and makes a video call to the recipient.

Answer a call

To answer a call, press the call key.

22 Telephone

To reject a call, press the end key.

To mute the ringing tone instead of answering a call, select Silence.

When you have an active call and the call waiting feature (network service) is activated, to answer a new incoming call, press the call key. The first call is put on hold. To end the active call, press the end key.

Make a video call

To make a video call, enter the phone number or select the recipient from the contacts list and Options > Call > Video

call. When the video call starts, the

camera of the device is activated. If the camera is already in use, video sending is disabled. If the recipient of the call does not want to send video back to you, a still image is shown instead. To define the still image sent from your device instead of video, select

> Settings > Settings

and Phone > Call > Image in video

call.

To disable the sending of audio, video, or video and audio, select Options >

Disable > Sending audio, Sending video, or Sending aud. & video.

To adjust the volume of an active video call, use the volume keys.

To use the loudspeaker, select Options >

Activate loudspeaker. To mute the

loudspeaker and use the earpiece, select

Options > Activate handset.

To swap the places of images, select

Options > Swap images.

To zoom the image on the display, select

Options > Zoom and scroll up or down.

To end the video call and make a new voice call to the same recipient, select

Options > Switch to voice call.

Answer or decline a video call

When a video call arrives,

is displayed.

To answer the video call, press the call key.

Allow video image to be sent to caller? is displayed.

To start sending live video image, select

Yes.

If you do not activate the video call, you only hear the sound of the caller. A grey screen replaces the video image. To replace the grey screen with a still image captured by the camera in your device, select

> Settings > Settings and

Phone > Call > Image in video call.

To end the video call, press the end key.

Video sharing requirements

Video sharing requires a 3G connection for both parties. For more information on the service, 3G network availability, and fees associated with using this service, contact your service provider.

To use video sharing you must do the following:

Telephone 23

• Ensure that you have the correct person-to-person settings defined, and you have accepted a video sharing invitation, or are in an active call.

• Ensure you have an active 3G connection and remain within 3G network coverage. If you move outside the 3G network during a video sharing session, the sharing stops, but your voice call continues.

• Ensure that both the sender and recipient are registered to the 3G network. If you invite someone to a sharing session and the recipient’s device is not within 3G network coverage, does not have video sharing installed, or person-to-person connections set up, the recipient does not receive invitations. You receive an error message that indicates that the recipient cannot accept the invitation.

Share live video or video clips

During an active voice call, select

Options > Share video.

1 To share live video during the call,

select Live video. To share a video clip, select Video

clip and the clip you want to share.

You may need to convert the video clip into a suitable format to be able to share it. If your device notifies you that the video clip must be converted, select OK. Your device must have a video editor for the conversion to work.

2 If the recipient has several SIP

addresses or phone numbers including the country code saved in

the contacts list, select the desired address or number. If the SIP address or phone number of the recipient is not available, enter the address or number of the recipient including the country code, and select OK to send the invitation. Your device sends the invitation to the SIP address.

Sharing begins automatically when the recipient accepts the invitation.

Options during video sharing

Zoom the video (available for sender only). Adjust the brightness (available for sender only).

or Mute or unmute the

microphone.

or Turn the loudspeaker on and

off.

or Pause and resume video

sharing. Switch to full screen mode (available for receiver only).

3 To end the sharing session, select

Stop. To end the voice call, press the

end key. When you end the call, video sharing also ends.

To save the live video you shared, select

Yes when prompted. The device notifies

you of the memory location of the saved video. To define the preferred memory location, select

> Settings >

Settings and Connection > Video sharing > Preferred saving memory.

If you access other applications while you are sharing a video clip, the sharing is paused. To return to the video sharing

24 Telephone

view, and to continue sharing, in the home screen, select Options >

Continue.

If you access other applications while you are sharing a video clip, the sharing is paused. To return to the video sharing view, and to continue sharing, in the standby mode , select Options >

Continue.

Make a conference call

1 To make a conference call, enter a

participant's phone number, and press the call key.

2 When the participant answers, select

Options > New call.

3 When you have made a phone call to

all the participants, select Options >

Conference to merge the calls into a

conference call.

To mute the microphone of your device during the call, select Options > Mute.

To drop a participant from the conference call, select Options > Conference >

Drop participant and the participant.

To discuss privately with a conference call participant, select Options >

Conference > Private and the

participant.

Speed dialling

Select

> Settings > Settings and

Phone > Call > Speed dialling.

Speed dialling allows you to make a call by pressing and holding a number key in the standby mode.

Speed dialling allows you to make a call by pressing and holding a number key in the home screen.

To activate speed dialling, select On.

To assign a number key to a phone number, select

> Settings > Speed

dial.

Scroll to the number key (2 - 9) on the display, and select Options > Assign.

Select the desired number from the contacts list.

To delete the phone number assigned to a number key, scroll to the speed dialling key, and select Options > Remove.

To modify a phone number assigned to a number key, scroll to the speed dialling key, and select Options > Change.

Voice dialling

Make a phone call by saying the name that is saved in the contacts list.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialling in all circumstances.

1 In the home screen, press and hold

the right selection key.In the active standby, press and hold the right

Telephone 25

selection key.A short tone sounds, and

Speak now is displayed.

2 Say the name of the contact you want

to dial. If the voice recognition is successful, a list of proposed matches is displayed. The phone plays the voice command of the first match on the list. If it is not the correct command, scroll to another entry.

Recorder

You can use the recorder to record voice memos and telephone conversations. You can also send sound clips to your friends.

Select > Applications > Recorder.

Record a sound clip

Select

Stop recording a sound clip

Select

Listen to the sound clip

Select

Send a sound clip as a message

Select Options > Send.

Record a telephone conversation

Open the recorder during a voice call, and select

. Both parties hear a tone at

regular intervals during recording.

Select the recording quality or where to save sound clips

Select Options > Settings.

The recorder cannot be used when a data call or GPRS connection is active.

Call and data registers

Select

> Log.

To view recently missed, received, and dialled calls, select Recent calls.

Tip: To view the dialled numbers when in the home screen, press the call key. To view the dialled numbers when in the standby mode, press the call key.

To view the approximate duration of calls to and from your device, select Call

duration.

To view the amount of data transferred during packet data connections, select

Packet data.

Call barring

Select

> Settings > Settings and

Phone > Call barring.

You can bar the calls that can be made or received with the device (network service). To modify the settings, you need the barring password from your service provider. Call barring affects all call types.

Select from the following voice call barring settings:

Outgoing calls — Prevent making voice calls with your device.

Incoming calls — Prevent incoming calls. International calls — Prevent calling to

foreign countries or regions.

26 Telephone

Incoming calls when roaming

— Prevent incoming calls when outside your home country.

International calls except to home country — Prevent calls to foreign

countries or regions, but allow calls to your home country.

To check the status of voice call barrings, select the barring option and Options >

Check status.

To deactivate all voice call barrings, select a barring option and Options >

Deactivate all barrings.

To change the password used for barring voice and fax calls, select Options > Edit

barring password. Enter the current

code, then the new code twice. The barring password must be four digits long. For details, contact your service provider.

Fixed dialling

With the fixed dialling service, you can restrict calls from your device to certain phone numbers. Not all SIM cards support the fixed dialling service. For more information, contact your service provider.

Select

> Contacts and Options > SIM

numbers > Fixed dial contacts.

When security features that restrict calls are in use (such as call barring, closed user group, and fixed dialling), calls may be possible to the official emergency number programmed into your device. Call barring

and call diverting cannot be active at the same time.

You need your PIN2 code to activate and deactivate fixed dialling or edit your fixed dialling contacts. Contact your service provider for your PIN2 code.

Select Options and from the following:

Activate fixed dialling or Deactivate fixed dialling — Activate or deactivate

fixed dialling. New SIM contact — Enter the contact

name and phone number to which calls are allowed.

Add from Contacts — Copy a contact from the contacts list to the fixed dialling list.

To send text messages to the SIM contacts while the fixed dialling service is active, you need to add the text message centre number to the fixed dialling list.

Call divert

Select

> Settings > Settings and

Phone > Call divert.

Divert incoming calls to your voice mailbox or to another phone number. For details, contact your service provider.

Select the type of calls to divert and from the following:

All voice calls or All fax calls — Divert all incoming voice or fax calls. You cannot answer the calls, only divert the calls to another number.

If busy — Divert incoming calls if you have an active call.

Telephone 27

If not answered — Divert incoming calls

after your device rings for a specified length of time. Select the length of time for the device to ring before diverting the call.

If out of reach — Divert calls when the device is switched off or out of network coverage.

If not available — Divert calls if you have an active call, do not answer, or the device is switched off or out of network coverage.

To divert calls to your voice mailbox, select a call type, a diverting option, andOptions > Activate > To voice

mailbox.

To divert calls to another phone number, select a call type, a diverting option, and

Options > Activate > To other number. Enter the number, or select Find to retrieve a number saved in

Contacts.

To check the current diverting status, scroll to the diverting option, and select

Options > Check status.

To stop diverting calls, scroll to the diverting option, and select Options >

Deactivate.

Call settings

Select

> Settings > Settings and

Phone > Call.

Select from the following:

Send my caller ID — Display your phone number to the person you are calling.

Call waiting — Set the device to notify you of incoming calls while you are in a call (network service).

Reject call with message — Reject a call, and send a text message to the caller.

Message text — Write the standard text message that is sent when you reject a call.

Own video in recvd. call — Allow or deny video sending during a video call from your device.

Image in video call — Display a still image if video is not sent during a video call.

Automatic redial — Set your device to make a maximum of 10 attempts to connect the call after an unsuccessful call attempt. To stop automatic redialling, press the end key.

Show call duration — Display the length of a call during the call.

Summary after call — Display the length of a call after the call.

Speed dialling — Activate speed dialling. Anykey answer — Activate anykey

answer. Line in use — This setting (network

service) is shown only if the SIM card supports two subscriber numbers, that is, two phone lines. Select which phone line you want to use for making calls and sending text messages. Calls on both lines can be answered irrespective of the selected line. If you select Line 2 and have not subscribed to this network service, you are not able to make calls. When line 2 is selected,

is displayed in the home

screen.

28 Contacts

Line change — Prevent line selection

(network service), if supported by your SIM card. To change this setting, you need the PIN2 code.

Network settings

Select

Phone > Network.

To select the network mode, select

Network mode and Dual mode, UMTS,

or GSM. In dual mode, the device switches automatically between networks.

Tip: Selecting UMTS enables faster data transfer, but may increase the demand on battery power and reduce the battery life. In regions close to both GSM and UMTS networks, selecting Dual mode may cause constant jumping between the two networks, which also increases the demand on battery power.

To select the operator, select Operator

selection and Manual to select from

available networks, or Automatic to set the device to select the network automatically.

To set the device to indicate when it is used in a microcellular network (MCN), select Cell info display > On.

> Settings > Settings and

5. Contacts

Stay connected with your online friends

You can synchronise the contact information on your device with contacts

you have on social networking services, such as Facebook. When you allow synchronisation, you are able to view your contacts' Facebook profile information, such as their picture and status updates, in the Contacts application on your device.

Synchronising your contacts and retrieving status updates are network services. Roaming and data transfer charges may apply. If the social networking service is not available or functioning correctly, you may not be able to synchronise or retrieve status updates.

To start synchronising your contacts, go to the settings of the social networking application on your device, select an access point and set the frequency of the automatic synchronisation.

To deactivate the connection between Contacts and the social networking service, in the settings of the social networking service application on your device, clear the Enable check box.

This feature may not be available in certain regions.

Copy contacts

Select

When you open the contacts list for the first time, the device asks if you want to copy names and numbers from the SIM card to your device.

Start copying

Select OK.

Cancel copying

Select Cancel.

> Contacts.

+ 63 hidden pages
