Microsoft RM-644 User Manual

Nokia C1-01/C1–02 User Guide

Cyan

Magenta

Yellow

Black

xxxxxxx

Issue 1

Cyan

Magenta

Yellow

Black

2 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Contents

Safety 5

Support 7

Get started 7

Insert the SIM card and
battery 7
Keys and parts 9
Switch on or off 10
Charge the battery 10
Antennas 10
Headset 11
Insert a memory card 12
Remove the microSD
card 13
Connect a USB data
cable 14
Attach the wrist strap 15
Access codes 15
Keypad lock 16
Use your device without
a SIM card 17

Applications running in
background 17

Calls 18

Make and answer a
call 18
Loudspeaker 18
Dialling shortcuts 19

Write text 19

Text modes 19
Traditional text input 20
Predictive text input 20

Navigate the
menus 21

Messaging 22

Text and multimedia
messages 22
Flash messages 24
Nokia Xpress audio
messages 25
Nokia Messaging
Service 25
Voice messages 26

Cyan

Magenta

Yellow

Black

www.nokia.com/support 3

Cyan

Magenta

Yellow

Black

Message settings 26

Contacts 27

Photos 29

Capture images and
record video clips 29
View your images and
video clips 30

Music 31

Music player 31
FM radio 32

Call log 34

Web or Internet 34

Connect to a web
service 35

Settings 35

Profiles 35
Tones 36
Display 36
Date and time 36
Shortcuts 37

Synchronisation and
backup 37
Connectivity 38
Call and phone 41
Accessories 42
Configuration 42
Restore factory
settings 43

Applications 43

Alarm clock 43
Gallery 44
Extras 44
Voice recorder 45
To-do list 46

Operator menu 46

SIM services 46

Green tips 47

Save energy 47
Recycle 47

Product and safety
information 48

Cyan

Magenta

Yellow

Black

4 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Index 63

Cyan

Magenta

Yellow

Black

Safety 5

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is
not allowed or when it may cause interference
or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.

INTERFERENCE

All wireless devices may be susceptible to
interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair
this product.

Cyan

Magenta

Yellow

Black

6Safety

Cyan

Magenta

Yellow

Black

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do
not hold the device near your ear when the
loudspeaker is in use.

Cyan

Magenta

Yellow

Black

Support 7

Cyan

Magenta

Yellow

Black

Support

When you want to learn more about how to use your
product or you are unsure how your device should
function, go to www.nokia.com/support, or using a mobile
device, nokia.mobi/support.

If this does not resolve your issue, do one of the following:

• Reboot your device. Switch off the device, and remove
the battery. After about a minute, replace the battery,
and switch on the device.

• Restore the original factory settings.

• Update your device software.

If your issue remains unsolved, contact Nokia for repair
options. Go to www.nokia.com/repair, or in Latin America,
www.nokia-latinoamerica.com/centrosdeservicio. Before
sending your device for repair, always back up the data in
your device.

Get started

Insert the SIM card and battery

The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.

Cyan

Magenta

Yellow

Black

8Get started

Cyan

Magenta

Yellow

Black

1 Place your finger in the recess at the bottom of the

device, and carefully lift and remove the back cover (1).

2 If the battery is inserted, lift the battery out (2).
3 Insert the SIM card. Make sure the contact area of the

card is facing down (3, 4).

4 Line up the contacts of the battery and the battery

compartment, and insert the battery (5). To replace the
back cover, direct the top locking catches toward their
slots (6), and press down until the cover locks into
place (7).

Safe removal. Always switch the device off and disconnect
the charger before removing the battery.

Cyan

Magenta

Yellow

Black

Keys and parts

Cyan

Magenta

Yellow

Black

Headset connector

1

(3.5 mm)

2 Earpiece

3 Display

4 Selection keys

5 Navi™ key (scroll key)

6 Call key

7 End/Power key

8 Keypad

9 Charger connector

10 Micro USB connector

11 Loudspeaker

12 Camera lens (Nokia

C1–01 only)

13 Microphone

Get started 9

Cyan

Magenta

Yellow

Black

10 Get started

Cyan

Magenta

Yellow

Black

Switch on or off

Press and hold the power key.

Charge the battery

Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the

charger from the device, then from the wall outlet.

You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.

Antennas

Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the

Cyan

Magenta

Yellow

Black

Get started 11

Cyan

Magenta

Yellow

Black

antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.

Headset

Warning:

When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.

When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
the Nokia AV Connector, pay special attention to volume
levels.

Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.

Cyan

Magenta

Yellow

Black

12 Get started

Cyan

Magenta

Yellow

Black

Insert a memory card

Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.

Your phone supports microSD cards with a capacity of up
to 32 GB.

Cyan

Magenta

Yellow

Black

Get started 13

Cyan

Magenta

Yellow

Black

A compatible memory card may be supplied with the
device, and may already be inserted in the device. If not,
do the following:

1 Open the back cover.
2 Make sure the contact area of the card is facing down.

Push the card in, until you hear a click.

3 Replace the back cover.

Remove the microSD card
Important: Do not remove the memory card during an

operation when the card is being accessed. Doing so may
damage the memory card and the device, and corrupt data
stored on the card.

You can remove or replace the memory card during phone
operation without switching the device off, but you need
to ensure that no application is currently accessing the
memory card.

Cyan

Magenta

Yellow

Black

14 Get started

Cyan

Magenta

Yellow

Black

Connect a USB data cable

Connect a compatible USB data cable to the USB connector.
You may need to purchase a USB data cable separately.

To modify the USB settings, select Menu > Settings >

Connectivity > USB data cable and the desired mode.

Cyan

Magenta

Yellow

Black

Get started 15

Cyan

Magenta

Yellow

Black

Attach the wrist strap

Thread the wrist strap, and tighten it.

Nokia C1–01:

Nokia C1–02:

Access codes

The security code helps to protect your device against
unauthorised use. The preset code is 12345. You can create
and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate
from your device. If you forget the code and your device is
locked, your device will require service. Additional charges
may apply, and all the personal data in your device may be

Cyan

Magenta

Yellow

Black

16 Get started

Cyan

Magenta

Yellow

Black

deleted. For more information, contact a Nokia Care point
or your device dealer.

The PIN code supplied with the SIM card protects the card
against unauthorised use. The PIN2 code supplied with
some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your service provider.

The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.

To set how your device uses the access codes and security
settings, select Menu > Settings > Security.

Keypad lock

To prevent accidental keypresses, select Menu, and press
* within 3.5 seconds to lock the keypad.

To unlock the keypad, select Unlock, and press * within 1.5
seconds. If the security keyguard is activated, enter the
security code when requested.

Cyan

Magenta

Yellow

Black

Get started 17

Cyan

Magenta

Yellow

Black

To set the keypad to lock automatically after a defined
length of time when the device is not being used, select

Menu > Settings > Phone > Automatic keyguard >
On.

To answer a call when the keypad is locked, press the call
key. When you end or reject a call, the keypad locks
automatically.

When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.

Use your device without a SIM card

Some features of your device may be used without
inserting a SIM card, such as games. Features that are
unavailable in the offline profile cannot be selected in
menus.

Applications running in background

Leaving applications running in the background increases
the demand on battery power and reduces the battery life.

Applications that usually run in the background are, for
example, the Radio and Music player applications.

Cyan

Magenta

Yellow

Black

18 Calls

Cyan

Magenta

Yellow

Black

Calls

Make and answer a call

Make a call

Enter the phone number, including the country and area
code if necessary, and press the call key.

Answer an incoming call

Press the call key.

Reject a call

Press the end key.

Adjust the volume

During a phone call, scroll up or down.

Loudspeaker

If available, you may select Loudsp. or Normal to use the
loudspeaker or the earpiece of the phone during a call.

Warning:

Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.

Cyan

Magenta

Yellow

Black

Write text 19

Cyan

Magenta

Yellow

Black

Dialling shortcuts

Assign a phone number to a number key

Select Menu > Contacts > More > Speed dials, scroll to
a desired number (2-9), and select Assign. Enter the
desired phone number, or select Search and a saved
contact.

Activate speed dialling

Select Menu > Settings > Call > Speed dialling > On.

Make a call using speed dialling

In the home screen, press and hold the desired number key.

Write text

Text modes

To enter text (for example, when writing messages) you
can use traditional or predictive text input.

When you write text, press and hold Options to switch
between traditional text input, indicated by
predictive text input, indicated by
are supported by predictive text input.

The character cases are indicated by

. Not all languages

, and

, , and .

Cyan

Magenta

Yellow

Black

20 Write text

Cyan

Magenta

Yellow

Black

To change the character case, press #. To change from the
letter to number mode, indicated by
#, and select Number mode. To change from the number
to the letter mode, press and hold #.

To set the writing language, select Options > Writing

language.

Traditional text input

Press a number key, 2-9, repeatedly until the desired
character appears. The available characters depend on the
selected writing language.

If the next letter you want is located on the same key as
the present one, wait until the cursor appears, and enter
the letter.

To access the most common punctuation marks and special
characters, press 1 repeatedly. To access the list of special
characters, press *. To insert a space, press 0.

Predictive text input

Predictive text input is based on a built-in dictionary to
which you can also add new words.

1 Start writing a word, using the keys 2 to 9. Press each

key only once for one letter.

2 To confirm a word, scroll right or add a space.

, press and hold

Cyan

Magenta

Yellow

Black
