Microsoft RM-639 User Manual
X3–02 User Guide
FCC Draft
Issue 1
2Contents
Contents
Safety 5
Get started 6
Keys and parts 6
Insert the SIM card and battery 6
Insert or remove a memory card 7
Charge the battery 7
Charge the battery over USB 8
GSM antenna 8
Attach a strap 9
Switch it on 9
Network services and costs 9
Access codes 9
Switch the device on or off 10
Lock the keys and screen 10
Touch screen actions 10
Touch screen settings 11
Interactive home screen elements 11
Change the volume of a call, song, or
video 11
Indicators 12
Media key 12
Messaging key 12
Copy contacts or pictures from your old
device 12
Functions without a SIM card 13
Use your device offline 13
Device management 13
Support 13
My Nokia 13
Update device software using your
device 14
Update device software using your
PC 14
Restore original settings 14
Organise files 15
Back up your pictures and other content
to a memory card 15
Telephone 16
Make a call 16
View your missed calls 16
Call the last dialled number 16
Divert calls to your voice mailbox or
another phone number 16
Save a number from a received call or
message 16
About internet calls 17
Make an internet call 17
Make a conference call 17
Allow calls only to certain numbers 18
Prevent making or receiving calls 18
Contacts 19
Save a name and phone number 19
Use speed dial 19
Send your contact information 19
Create a contact group 19
Move or copy contacts to your SIM
card 19
Write text 20
Switch between text input modes 20
Traditional text input 20
Predictive text input 21
Messaging 21
Send a message 21
Send a message to a group of
people 22
Save an attachment 22
View a conversation 22
Listen to voice messages 22
Send an audio message 23
www.nokia.com/support
Contents 3
Nokia Messaging mail and IM 23
About Nokia Messaging mail 23
Sign in to a mail account 23
Send a mail 24
Read and reply to mail 24
About Chat 24
Sign in to a chat service 24
Chat with your friends 24
Hide the Chat application 24
Personalisation 25
About the home screen 25
Add a shortcut to the home screen 25
Add your important contacts to the
home screen 25
Personalise the Go to menu 26
Personalise the home screen 26
Change the look of your device 26
Create your own profile 27
Personalise your tones 27
Connectivity 27
Bluetooth 27
USB data cable 29
Connect to a WLAN 30
Nokia's Ovi services 32
Ovi by Nokia 32
Access Nokia's Ovi services 33
About Nokia Ovi Suite 33
Install Nokia Ovi Suite on your PC 33
Ovi Player 33
Time management 34
Change the time and date 34
Set an alarm 34
Snooze an alarm 34
Time your workout 34
Set the countdown timer 34
Calendar 35
Make a shopping list 35
Pictures and videos 36
Take a picture 36
Record a video 36
Send a picture or video 36
Photos 36
Print a picture 37
Music and audio 37
Media player 37
FM radio 38
Use voice recorder 39
Web 40
About the web browser 40
Browse the web 40
Clear browsing history 40
Games and applications 41
About games and applications 41
Improve your gaming experience 41
Download a game or application 41
About Communities 42
Use the calculator 42
Convert currency and
measurements 42
Protect your device 43
Lock your device 43
Password protect your memory
card 43
Format a memory card 44
Prepare your device for recycling 44
Green tips 45
Save energy 45
Recycle 45
Product and safety information 45
www.nokia.com/support
4Contents
Index 51
www.nokia.com/support
Safety 5
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not waterresistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not hold
the device near your ear when
the loudspeaker is in use.
BATTERIES AND OTHER ACCESSORIES
Use only batteries, chargers
and other accessories approved
by Nokia for use with this
device. Do not connect
incompatible products.
www.nokia.com/support
6Get started
Get started
Keys and parts
1 Earpiece
2 Display
3 Messaging key
4 Call key
5 Keypad
6 Microphone
7 End key/power key
8 Media key
9 Light sensor
10 Loudspeaker
11 Micro USB connector
12 Charger connector
13 Wrist strap hole
14 Volume keys
15 Keylock button
16 Camera lens
17 Nokia AV connector (3.5 mm)
Insert the SIM card and battery
Note: Switch the device off and
disconnect the charger and any other
device before removing any covers. Avoid
touching electronic components while
changing any covers. Always store and use
the device with any covers attached.
This device is intended for use with a
BL-4S battery. Always use original Nokia
batteries.
The SIM card and its contacts can be easily
damaged by scratches or bending, so be
careful when handling, inserting, or
removing the card.
1 Press the release buttons, and remove
the cover. If the battery is inserted, lift
the battery out.
www.nokia.com/support
2 Insert a SIM card. Make sure the
contact area of the card is facing
down.
3 Line up the contacts of the battery and
the battery compartment, and insert
the battery. To replace the back cover,
direct the top locking catches toward
their slots, and press down until the
cover locks into place.
Get started 7
Your device supports memory cards with
a capacity of up to 16 GB.
Insert a memory card
1 Remove the back cover.
2 Make sure the contact area of the card
is facing down. Push the card in, until
you hear a click.
3 Replace the back cover.
Remove the memory card
Important: Do not remove the memory
card when an application is using it. Doing
so may damage the memory card and the
device, and corrupt data stored on the
card.
You can remove or replace the memory
card without switching the device off.
1 Remove the back cover.
2 Push the card in, until you hear a click,
and pull the card out.
3 Replace the back cover.
Insert or remove a memory card
Use only compatible memory cards
approved by Nokia for use with this
device. Incompatible cards may damage
the card and the device and corrupt data
stored on the card.
www.nokia.com/support
Charge the battery
Your battery has been partially charged at
the factory, but you may need to recharge
it before you can switch on your device for
the first time.
If the device indicates a low charge, do the
following:
8Get started
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full
charge, disconnect the charger from
the device, then from the wall outlet.
You do not need to charge the battery for
a specific length of time, and you can use
the device while it is charging.
If the battery is completely discharged, it
may take several minutes before the
charging indicator appears on the display
or before any calls can be made.
If the battery has not been used for a long
time, to begin charging, you may need to
connect the charger, then disconnect and
reconnect it.
Charging the device while listening to the
radio may affect the quality of reception.
Charge the battery over USB
Battery low, but you don't have a charger
with you? You can use a compatible USB
cable to connect to a compatible device,
such as a computer.
To avoid breaking the charger connector,
be careful when connecting or
disconnecting the charger cable.
Charging over USB can take longer to start,
and may not work if you connect through
a non-powered USB hub. Your device
charges more quickly when connected to
a wall outlet.
If connected to a computer, you can
synchronise your device while charging.
GSM antenna
The figure shows the GSM antenna area
marked in grey.
Avoid touching the antenna area
unnecessarily while the antenna is
transmitting or receiving. Contact with
antennas affects the communication
quality and may cause a higher power
www.nokia.com/support
Switch it on 9
level during operation and may reduce the
battery life.
Attach a strap
Switch it on
Network services and costs
Your device is approved for use on the GSM
850/900/1800/1900 MHz networks and
WCDMA 850/900/1900/2100 MHz
networks. To use the device, you need a
subscription with a service provider.
Using network services and downloading
content to your device may result in data
traffic costs. Some product features
require support from the network, and
you may need to subscribe to them.
Access codes
PIN code — This code protects your SIM
card against unauthorised use. The PIN
code (4 - 8 digits) is usually supplied with
the SIM card.
PIN2 code — This code (4 - 8 digits) is
supplied with some SIM cards, and is
required to access some functions in your
device.
If you forget an access code, contact the
network service provider whose SIM card
is in your device. After three consecutive
incorrect PIN or PIN2 code entries, the
code is blocked, and you need the PUK
code to unblock it.
PUK code and PUK2 code — These codes (8
digits) are required to change a blocked
PIN code or PIN2 code, respectively. If the
codes are not supplied with the SIM card,
contact the network service provider
whose SIM card is in your device.
IMEI number — This number (15 or 17
digits) is used to identify valid devices in
the GSM network. Devices that are, for
example, stolen, can be blocked from
www.nokia.com/support
10 Switch it on
accessing the network. The IMEI number
for your device can be found under the
battery.
Lock code (also known as security
code) — The lock code helps you to protect
your device against unauthorised use. You
can create and change the code, and set
the device to request the code. Keep the
new code secret and in a safe place
separate from your device. If you forget
the code and your device is locked, your
device will require service. Additional
charges may apply, and all the personal
data in your device may be deleted. For
more information, contact a Nokia Care
Point or your device dealer.
Switch the device on or off
Press and hold the power key
.
You may be prompted to get the
configuration settings from your service
provider (network service). For more
information, contact your service
provider.
Lock the keys and screen
To avoid accidentally making a call when
your device is in your pocket or bag, lock
the keys and screen of your device.
Press the keylock button
.
Unlock the keys and screen
Press the keylock button
, and select
Unlock.
Touch screen actions
To interact with the touch screen user
interface, tap or tap and hold the touch
screen.
Open an application or other screen
element
Tap the application or element.
Access item-specific options
Tap and hold the item. A pop-up menu
with available options opens.
Scroll in a list or menu
Place your finger on the screen, slide it
quickly up or down the screen, and then
lift your finger. The content of the screen
scrolls with the speed and direction it had
at the moment of release. To select an
item from a scrolling list and to stop the
movement, tap the item.
www.nokia.com/support
Swipe
Place a finger on the screen, and steadily
slide your finger in the desired direction.
For example, when you are viewing a
picture, to view the next picture, swipe
left. To quickly browse through your
pictures, swipe the screen quickly, and
then scroll left or right through the
thumbnails.
Touch screen settings
Calibrate the touch screen and activate
vibration feedback.
Select Menu > Settings > Phone >
Touch settings.
Calibrate the touch screen
Select Screen calibration, and follow the
instructions.
Switch it on 11
Activate vibration feedback
Select Vibration feedback > On.
When you tap an icon, the device vibrates
shortly.
Interactive home screen elements
The home screen elements are interactive.
For example, you can change the date and
time, set alarms, or write calendar entries
directly in the home screen.
Set an alarm
Select the clock (1).
View or edit your schedule
Select the date (2).
Change the volume of a call, song, or
video
Use the volume keys.
The built-in loudspeaker allows you to
speak and listen from a short distance
without having to hold the device to your
ear.
Activate the loudspeaker during a call
Select Loudsp..
www.nokia.com/support
12 Switch it on
Indicators
You have unread messages.
You have unsent, cancelled,
or failed messages.
The keypad is locked.
The device does not ring for
incoming calls or text
messages.
An alarm is set.
/ The device is registered to the
GPRS or EGPRS network.
/ A GPRS or EGPRS connection is
open.
/ The GPRS or EGPRS connection
is suspended (on hold).
The device is registered to a
3G (UMTS) network.
The device is registered to a
3.5G (HSDPA) network.
Bluetooth is activated.
WLAN is activated.
If you have two phone lines,
the second line is in use.
All incoming calls are diverted
to another number.
Calls are limited to a closed
user group.
The currently active profile is
timed.
A headset is connected to the
device.
The device is connected to
another device, using a USB
data cable.
Media key
To open either the media player or the
radio, depending on which was last used,
press the media key
.
Messaging key
To write a message or check your message
inbox, press the messaging key
.
Copy contacts or pictures from your old
device
Want to copy important information from
your previous compatible Nokia device
and start using your new device quickly?
Use the Phone switch application to copy,
for example, contacts, calendar entries,
and pictures to your new device, free of
charge.
Select Menu > Settings > Sync &
backup.
Both devices must have Bluetooth
activated.
1 Select Phone switch > Copy to this.
2 Select the content to copy and Done.
3 Select your previous device from the
list. If the device is not listed, make
sure Bluetooth is activated in the
device.
www.nokia.com/support
Device management 13
4 If the other device requires a
passcode, enter the passcode. The
passcode, which you can define
yourself, must be entered in both
devices. The passcode in some devices
is fixed. For details, see the user guide
of the device.
The passcode is valid only for the
current connection.
5 If prompted, allow connection and
copying requests.
Functions without a SIM card
Some functions of your device may be
used without inserting a SIM card, such as
Organiser functions and games. Some
functions appear dimmed in the menus
and cannot be used.
Use your device offline
In places where you are not allowed to
make or receive calls, you can activate the
flight profile and play games or listen to
music.
Select Menu > Settings > Profiles.
Select Flight > Activate.
indicates that the flight profile is
active.
Tip: You can add a profiles shortcut to the
shortcut widget in the home screen.
Warning:
When the flight profile is activated, you
cannot make or receive any calls,
including emergency calls, or use other
features that require network coverage.
To make a call, activate another profile.
Device management
Support
When you want to learn more about how
to use your product or you are u nsure how
your device should function, go to
www.nokia.com/support, or using a
mobile device, nokia.mobi/support.
If this does not resolve your issue, do one
of the following:
• Reboot your device. Switch off the
device, and remove the battery. After
about a minute, replace the battery,
and switch on the device.
• Restore the original factory settings.
• Update your device software.
If your issue remains unsolved, contact
Nokia for repair options. Go to
www.nokia.com/repair, or in Latin
America, www.nokia-latinoamerica.com/
centrosdeservicio. Before sending your
device for repair, always back up the data
in your device.
My Nokia
Select Menu > Applications > Extras >
Collection > My Nokia.
My Nokia is a free service that regularly
sends you text messages containing tips,
tricks, and support for your Nokia device.
It also allows you to browse the My Nokia
site where you can find details about
Nokia devices and download tones,
graphics, games, and applications.
To use the My Nokia service, it must be
available in your country and supported
by your service provider. You must sign up
www.nokia.com/support
14 Device management
to use the service. Text message charges
apply when you send messages to sign up
or unsubscribe. For terms and conditions,
see the documentation supplied with
your device, or go to www.nokia.com/
mynokia.
Update device software using your
device
Want to improve the performance of your
device and get application updates and
great new features? Update the software
regularly to get the most out of your
device. You can also set your device to
automatically check for updates.
Select Menu > Settings.
1 Select Phone > Phone updates.
2 To display the current software
version and check whether an update
is available, select Current sw
details.
3 To download and install a software
update, select Downl. phone sw.
Follow the instructions.
4 If the installation was cancelled after
the download, select Install sw
update.
The software update may take several
minutes. If there are problems with the
installation, contact your service provider.
Check for software updates
automatically
Select Auto sw update, and define how
often to check for new software updates.
Your service provider may send device
software updates over the air directly to
your device (network service).
Update device software using your PC
You can use the Nokia Software Updater
PC application to update your device
software. To update your device software,
you need a compatible PC, a high-speed
internet connection, and a compatible
USB data cable to connect your device to
the PC.
To get more information and to download
the Nokia Software Updater application,
go to www.nokia.com/softwareupdate,
or in Latin America, www.nokialatinoamerica.com/nsu.
Restore original settings
If your device is not working properly, you
can reset some settings to their original
values.
1 End all calls and connections.
www.nokia.com/support
Device management 15
2 Select Menu > Settings and Rest.
fact. sett. > Settings only.
3 Enter the security code.
This does not affect documents or files
stored on your device.
After restoring the original settings, your
device switches off and then on again.
This may take longer than usual.
Organise files
You can move, copy, delete, or create new
files and folders in your device memory or
on the memory card. If you organise your
files into their own folders, it might help
you find the files in future.
Select Menu > Applications > Gallery.
Create a new folder
In the folder where you want to create a
sub-folder, select Options > Add folder.
Copy or move a file to a folder
Select and hold the file, and from the popup menu, select the appropriate option.
Tip: You can also play music or videos, or
view pictures in Gallery.
Back up your pictures and other
content to a memory card
Want to make sure you will not lose any
important files? You can back up your
device memory to a compatible memory
card.
Select Menu > Settings > Sync &
backup.
Select Create backup.
Restore a backup
Select Restore backup.
www.nokia.com/support
16 Telephone
Telephone
Make a call
1 Enter the phone number, including
the country and area code if
necessary.
2 Press the call key.
Answer an incoming call
Press the call key.
End a call
Press the end key.
Reject a call
Press the end key.
View your missed calls
In the home screen, you can see when you
have missed calls. To view the phone
number, select View. The caller's name is
displayed if stored in the contacts list.
Missed and received calls are logged only
if supported by the network, and the
device is switched on and within the
network service area.
Call back the contact or number
Select the contact or number, and press
the call key.
View the missed calls later
Select Menu > Contacts > Log and
Missed calls.
Call the last dialled number
Trying to call someone, but they are not
answering? It is easy to call them again.
In the home screen, press the call key,
select the number from the list, and press
the call key again.
Divert calls to your voice mailbox or
another phone number
When you cannot answer, you can divert
your calls to your voice mailbox or to
another number (network service).
1 Select Menu > Settings and Call >
Call divert.
2 Select If busy or If not answered.
3 Select Activate and To voice
mailbox or To other number.
Save a number from a received call or
message
Have you received a call or message from
a person whose phone number is not yet
saved in the contacts list? You can easily
save the number to your contacts.
Save a number from a received call
1 Select Menu > Contacts > Log and
Received calls.
2 Select the number and Options >
Save.
3 Enter a name for the contact, and
select Save.
Save a number from a received
message
1 Select Menu > Messaging.
2 Select Conversations or Inbox and a
message.
3 Press the call key.
4 Select the number and Save.
5 Enter a name for the contact, and
select Save.
www.nokia.com/support
Telephone 17
Tip: To add a new number to an existing
contact, select the number and Add to
contact.
About internet calls
You can make and receive calls over the
internet (network service). Internet call
services may support calls between
computers, between mobile devices, and
between a VoIP device and a traditional
telephone.
Some internet call service providers allow
free internet calls. For availability and
connectivity costs, contact your internet
call service provider.
To make or receive an internet call, you
must be in the service area of a WLAN or
have a packet data (GPRS) connection in a
3G network, and be signed in to an
internet call service.
Make an internet call
When you are signed into an internet call
service, you can make internet calls.
For availability and costs of internet calls,
contact your internet call service provider.
The Net phone wizard helps you set up
your account. Have your account
information from your internet call
service provider available before you start
the wizard.
Set up your internet telephone account
1 Make sure a valid SIM card is inserted,
and that your device is connected to a
WLAN.
2 Select Menu > Settings and
Connectivity > Internet
telephone > Accounts.
3 Select Add new.
4 Select an account and Connect, and
follow the instructions.
When the wizard has finished, your
account is displayed in the accounts list.
If the internet telephone settings do not
work, contact your service provider.
Call a contact
1 Select Menu > Contacts and a
contact.
2 Select Internet call.
Call a phone number
Enter the phone number, and select
Options > Internet call.
For emergency calls, only the cellular
network is used.
Make a conference call
www.nokia.com/support
Loading...
