RM-615
User Manual
52 pgs1.16 Mb0

Microsoft RM-615 User Manual

Cyan
Magenta
Yellow
Black
Nokia 5330 Mobile TV Edition User Guide
Cyan
5555555
Magenta
Issue 1
Yellow
Black
Cyan
Magenta
Yellow
Black
2
DECLARATION OF CONFORMITY
0434
Hereby, NOKIA CORPORATION declares that this RM-615 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at www.nokia.com/ phones/declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved.
Reproduction, transfer, distribution, or storage of part or all of the contents in this doc ument in any form without the prio r written permission of Nokia is prohibited. Nokia oper ates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
Includes RSA BSAFE cryptograp hic or security protocol software from RSA Security.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE. The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and availability of language options. This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
C / INDUSTRY CANADA NOTICE
FC
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the followin g two conditions: (1) Th is device may not cause harmful interference, and (2) this device must accept any interference received, including interfer ence that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
Model number: Nokia 5330-1d
5555555/Issue 1 EN
/Industry Canada can require you to stop
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No licens e is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Contents 3
Contents
Safety 5
1. Get started 6
Keys and parts 6 Insert the SIM card and battery 6 Insert and remove the memory card 7 Charge the battery 8 Antenna 8 Accessories 9
2. Switch it on 9
About your device 9 Network services 10 Access codes 10 Switch the device on and off 11 Standby mode 11 Touch music keys 12 Navigate the menus 13 Lock the keys 13 Functions without a SIM card 13 Flight profile 14
3. Make it your device 14
Basic settings 14 Personalise your phone 15 Connect 17 Network provider services 19
4. Stay in touch 21
Make calls 21 Text and messages 23 Nokia Messaging IM 26 Nokia Messaging Mail 27
5. Image and video 28
Capture images 28 Record video clips 29 Camera and video settings 29 Gallery 29
Print images 30 Memory card 30
6. Entertainment 31
Listen to music 31 Web 33 Games and applications 35
7. Mobile TV 36
About Mobile TV 36 First start-up 36 View and select a program 36 Change audio output 37 Electronic program guide (EPG) 37 Subscribe to a channel or program 37 Mobile TV settings 38 Start-up Mobile TV after changing SIM card 38
8. Maps 38
Download maps 39 Maps and GPS 39 Extra services 40
9. Organise 40
Manage contacts 40 Business cards 41 Date and time 41 Alarm clock 41 Calendar 42 To-do list 42 Notes 42 Nokia PC Suite 42 Calculator 42 Countdown timer 42 Stopwatch 43
10. Support and updates 43
Support 43 My Nokia 43 Download content 44 Update software using your PC 44
www.nokia.com/support 3
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
4Contents
Software updates over the air 44 Restore factory settings 45
11. Green tips 45
Save energy 45 Recycle 45 Learn more 45
Digital rights management 46
Third-party applications 46
Accessories 46
Battery 46
Battery and charger information 46 Nokia battery authentication guidelines 47
Take care of your device 47
Recycle 48
Additional safety information 48
Magnets and magnetic fields 48 Small children 48 Operating environment 48 Medical devices 48 Vehicles 48 Potentially explosive environments 49 Emergency calls 49 Certification information (SAR) 49
Index 50
4 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Safety 5
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.
WATER-RESISTANCE
Your device is not water­resistant. Keep it dry.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible products.
www.nokia.com/support 5
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
6Get started
1. Get started
Get to know your device, insert the battery, SIM card, and memory card, and learn some important information about your device.
Keys and parts
1 Earpiece 2 Touch music key (rewind) 3 Touch music key (play/pause) 4 Touch music key (fast-forward) 5 Left and right selection keys 6 Call key 7 Keypad 8 Display 9 Navi™ key (scroll key) 10 End/Power key
11 Microphone 12 Nokia AV Connector (3.5 mm) 13 Charger connector 14 Micro USB cable connector 15 Volume key 16 Lock switch 17 Camera flash 18 Camera lens 19 Wrist strap eyelet 20 Memory card slot 21 Loudspeaker
Insert the SIM card and battery Note: Switch off the power and
disconnect the charger and any other device before removing the covers. Avoid touching electronic components while changing the covers. Always store and use the device with the covers attached.
The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.
6 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Get started 7
1 Open the back cover, and remove it.
Remove the battery.
2 Open the SIM card holder. Insert the
SIM card into the holder with the contact surface facing down. Close the SIM card holder.
3 Line up the battery contacts, and
insert the battery. Replace the back cover.
Insert and remove the memory card
Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
Your device supports microSD cards with a capacity of up to 16 GB. The size of a single file must not exceed 2 GB.
Insert the memory card
1 Open the cover of the memory card
slot.
2 Insert the card into the memory card
slot with the contact surface facing down, and press until it locks into place.
3 Close the cover of the memory card
slot.
Remove the memory card Important: Do not remove the memory
card during an operation when the card is
www.nokia.com/support 7
Cyan
Magenta
Yellow
Black
8Get started
Cyan
Magenta
Yellow
Black
being accessed. Doing so may damage the memory card and the device, and corrupt data stored on the card.
You can remove or replace the memory card without switching the device off.
1 Ensure that no application is currently
accessing the memory card.
2 Open the cover of the memory card
slot.
3 Press the memory card slightly in to
release the lock, and remove the card.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device. 3 When the device indicates a full
charge, disconnect the charger from the device, then from the wall outlet.
You can also charge the battery with a USB cable with power from a computer.
1 Connect the USB cable to a USB port of
a computer and to your device.
2 When the battery is fully charged,
disconnect the USB cable.
You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.
Antenna
Your device may have internal and external antennas. Avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with antennas affects the communication quality and may cause a higher power level during operation and may reduce the battery life.
The figure shows the antenna area marked in grey.
8 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Switch it on 9
Accessories Connect a USB cable
Open the cover of the USB connector, and connect the USB cable to the device.
Headset
Warning:
Continuous exposure to high volume may damage your he ar ing. Listen to mu sic at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.
Warning:
When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.
Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.
Strap
1 Remove the back cover. 2 Attach a strap, and tighten it. 3 Replace the back cover.
2. Switch it on
Learn how to switch on your device, and how to use the basic functions.
About your device
The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, 1900 MHz and WCDMA 850, 1900, 2100 MHz networks. Contact your service provider for more information about networks.
Your device may have preinstalled bookmarks and links for third-party internet sites and may allow you to access third-party sites. These are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you access such sites, take precautions for security or content.
www.nokia.com/support 9
Cyan
Magenta
Yellow
Black
10 Switch it on
Cyan
Magenta
Yellow
Black
Warning:
To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.
Network services
To use the device you must have service from a wireless service provider. Some features are not available on all networks; other features may require that you make specific arrangements with your service provider to use them. Network services involve transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have customized items such as menu names, menu order, and icons.
Access codes
To set how your phone uses the access codes and security settings, select
Menu > Settings > Security > Access codes.
• The security code helps to protect your phone against unauthorised use. The preset code is 12345. You can change the code and set the phone to request the code. Some operations require the security code regardless of the settings, for example if you want to restore the factory settings. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your phone dealer.
• The PIN (UPIN) code, supplied with the SIM (USIM) card, helps to protect the card against unauthorised use.
• The PIN2 (UPIN2) code, supplied with some SIM (USIM) cards, is required to access certain services.
• PUK (UPUK) and PUK2 (UPUK2) codes may be supplied with the SIM (USIM) card. If you enter the PIN code incorrectly three times in succession, you are asked for the PUK code. If the codes are not supplied, contact your service provider.
10 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Switch it on 11
• The barring password is required when using the call barring service to restrict calls to and from your phone (network service).
Switch the device on and off
Switch on and off
Press and hold the power key.
Enter the PIN code
If requested, enter the PIN code (displayed as ****).
Set the time and date
If requested, enter the date, the local time, and the time zone and the daylight saving time of your location.
When you switch on your device for the first time, you may be prompted to get the configuration settings from your service provider (network service). For more information, contact your service provider.
Standby mode
When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.
Display
6
7
10
1 Signal strength of the cellular
network
2 Battery charge status 3 Indicators 4 Clock 5 Name of the network or the operator
logo
6 Date (only if the Home screen is
deactivated)
7 Display 8 Function of the left selection key 9 Function of the Navi key (scroll key) 10 Function of the right selection key
You may change the function of the left and right selection key. See " Left and right selection keys ", p. 16.
Power saving
Your phone has power saver and sleep mode features to save battery power in the standby mode when no keys are pressed. These features may be activated. See "Display", p. 16.
Home screen
The home screen displays a list of selected features and information that you can directly access.
www.nokia.com/support 11
Cyan
Magenta
Yellow
Black
12 Switch it on
Cyan
Magenta
Yellow
Black
Select Menu > Settings > Display >
Home screen.
Activate the home screen
Select Home screen mode.
Organise and personalise the home screen
Select Personalise view.
Select a key to activate the home screen
Select Home screen key.
Navigate in the home screen
Scroll up or down to navigate in the list, and select Select, View, or Edit. The arrows indicate that further information is available.
Stop navigating
Select Exit.
Shortcuts
When your device is in the standby or home screen mode, you can use the following shortcuts.
List missed, received, and dialled calls
Press the call key. To make a call, scroll to the number or name, and press the call key.
Start the web browser Press and hold 0.
Call the voice mailbox Press and hold 1.
Use other keys as shortcuts
See "Dialling shortcuts", p. 22.
Indicators
You have unread messages. You have unsent, cancelled, or
failed messages. The keypad is locked.
The device does not ring for incoming calls or text messages. An alarm is set.
The device is registered to the
/
GPRS or EGPRS network. A GPRS or EGPRS connection is
/
open. The GPRS or EGPRS connection is
/
suspended (on hold). Bluetooth connectivity is activated. A GPS signal is available. (external GPS antenna necessary). No GPS signal available. (external GPS antenna necessary). If you have two phone lines, the second line is in use. All incoming calls are diverted to another number. Calls are limited to a closed user group. The currently active profile is timed.
Touch music keys
When listening to the FM radio, or using the media player, to pause or resume playback, skip songs, or switch between saved stations, tap the touch music keys.
The figure shows the three touch­sensitive areas marked in grey.
12 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Activate the touch music keys
Select Menu > Settings > Phone >
Touch music keys.
Control the radio with the touch music keys
Select Menu > Media > Radio. Use the touch music keys to pause or resume playback, and to switch between saved radio stations.
Control the media player with the touch music keys
Select Menu > Media > Media player >
Go to Media player. Use the touch music
keys to pause or resume playback, and to skip songs.
Switch it on 13
3 If the selected menu contains further
submenus, select one (for example,
Call).
4 Select the setting of your choice. 5 To return to the previous menu level,
select Back. To exit the menu, select Exit.
To change the menu view, select
Options > Main menu view. Scroll right,
and select from the available options.
To rearrange the menu, select Options >
Organise. Scroll to the menu item to be
moved, and select Move. Scroll to where you want to move the menu item, and select OK. To save the change, select
Done > Yes.
Lock the keys
Lock the touch music keys and the keypad to prevent accidental keypresses.
Lock or unlock the keys
Slide the lock switch on the side of the device. Alternatively close or open the slide.
Handle calls when the keys are locked
To answer a call when the keypad is locked, press the call key. When you end or reject a call, the keypad locks automatically.
Navigate the menus
The phone offers you an extensive range of functions that are grouped into menus.
1 To access the menu, select Menu. 2 Scroll through the menu, and select an
option (for example, Settings).
www.nokia.com/support 13
Cyan
Magenta
When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.
Functions without a SIM card
Some functions of your phone may be used without inserting a SIM card, such as Organiser functions and games. Some
Yellow
Black
14 Make it your device
Cyan
Magenta
Yellow
Black
functions appear dimmed in the menus and cannot be used.
Flight profile
Use the Flight profile in radio sensitive environments to deactivate all radio frequency functions. You still have access to offline games, the calendar, and phone numbers. When the Flight profile is active,
is displayed.
Activate the Flight profile
Select Menu > Settings > Profiles >
Flight > Activate or Personalise.
Deactivate the Flight profile
Select any other profile.
Warning:
With the Flight profile you cannot make or receive any calls, including emergency calls, or use other features that require network coverage. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code.
If you need to make an emergency call while the device is locked and in the Flight profile, you may be also able to enter an official emergency number programmed in your device in the lock code field and select 'Call'. The device will confirm that you are about to exit Flight profile to start an emergency call.
3. Make it your device
Set up your device, personalise it, and connect it in several ways.
Basic settings Phone settings
Select Menu > Settings and Phone.
Select from the following: Language settings — To set the
language of your device, select Phone
language and a language. To set the
language of your device according to the information on the SIM card, select Phone
language > Automatic.
Touch music keys — Activate the touch
music keys. Memory status — View the memory
consumption. Automatic keyguard — Set the keypad
to lock automatically after a preset time delay when the device is in the home screen and no function has been used.
Security keyguard — Set the device to prompt for the security code to unlock the keypad.
Voice recognition — Set up voice commands, or start voice recognition training.
Flight query — Set the device to prompt for the flight profile when you switch the device on. In the flight profile, all radio connections are closed.
Phone updates — Allow software updates from your service provider (network service). The available options may vary.
Network mode — To use GSM and (when available) 3G networks, select Dual
mode. This option is not available during
an active call. Operator selection — Manually select
which network to use. Help text activation — Set the device to
display help text.
14 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Black
Make it your device 15
Start-up tone — Play a tone when you
switch the device on. Confirm SIM actions — Access additional
network services from your SIM card. This option may not be available, depending on your SIM card.
Security settings
Select Menu > Settings and Security.
When security features that restrict calls are in use (such as call barring, closed user group, and fixed dialling), calls may be possible to the official emergency number programmed into your device. Call barring and call diverting cannot be active at the same time.
Select from the following:
PIN code request or UPIN code request — Set the device to request for
the PIN or UPIN code every time the device is switched on. Some SIM cards do not allow the code request to be deactivated.
Call barring service — Restrict incoming calls to and outgoing calls from your device (network service). A barring password is required.
Fixed dialling — Restrict your outgoing calls to selected phone numbers if supported by your SIM card. When fixed dialling is activated, GPRS connections are not possible except while sending text messages over a GPRS connection. In this case, the recipient’s phone number and the message centre number must be included in the fixed dialling list.
Closed user group — Define a group of people whom you can call and who can call you (network service).
Security level — To request the security code whenever a new SIM card is inserted into the device, select Phone.
Access codes — Change the security code, PIN code, UPIN code, PIN2 code, or barring password.
PIN2 code request — Set the device to request the PIN2 code when using a specific device feature protected by the PIN2 code. Some SIM cards do not allow the code request to be deactivated. This option may not be available depending on your SIM card. For details, contact your service provider.
Code in use — Display and select the type of PIN code to be used.
Authority certificates or User certificates — View the list of the
authority or user certificates available on your device.
Security module sett. — View Secur. module details, activate Module PIN
request, or change the module PIN and
signing PIN.
Personalise your phone
Give your phone a personal touch with ringing tones, display backgrounds, and themes. Add shortcuts for your preferred features, and attach enhancements.
Profiles
Your phone has various setting groups called profiles, which you can customise with ringing tones for different events and environments.
Select Menu > Settings > Profiles, the desired profile, and from the following options:
Activate — to activate the selected profile
Personalise — to change the profile settings
www.nokia.com/support 15
Cyan
Magenta
Yellow
Black
16 Make it your device
Cyan
Magenta
Yellow
Black
Timed — to set the profile to be active for a certain time. When the time set for the profile expires, the previous profile that was not timed becomes active.
Themes
A theme contains elements for personalising your phone.
Select Menu > Settings > Themes and from the following options:
Select theme — Open the Themes folder, and select a theme.
Theme downloads — Open a lis t of link s to download more themes.
Tones
You can change the tone settings of the selected active profile.
Select Menu > Settings > Tones. You can find the same settings in the Profiles menu.
Lights
Personalise your device with light effects associated with different functions. Select
Menu > Settings andLights.
Choose a colour
Select Light colours and a colour.
Activate light effects
Select Light effects.
Display
Select Menu > Settings > Display and from the following:
Wallpaper — to add a background image for the home screen mode
Home screen — to activate, organise, and personalise the home screen mode
Home screen font col. — to select the font colour for the home screen mode
Navigation key icons — to display the scroll key icons in the home screen mode
Notification details — to display details in missed call and message notifications
Slide animation — to display an animation when you open or close the slide
Screen saver — to create and set a screen saver
Power saver — to dim the display automatically, and to display a clock when the phone is not used for a certain length of time
Sleep mode — to switch off the display automatically when the phone is not used for a certain length of time
Font size — to set the font size for messaging, contacts, and web pages
Operator logo — to display the operator logo
Cell info display — to display the cell identity, if available from the network
My shortcuts
With personal shortcuts, you get quick access to frequently used functions of your phone.
Left and right selection keys
To change the function assigned to the left or right selection key, select Menu >
Settings > My shortcuts > Left selection key or Right selection key,
and the desired function.
In the home screen mode, if the left selection key is Go to, to activate a function, select Go to > Options and from the following:
16 www.nokia.com/support
Cyan
Magenta
Yellow
Black
Loading...
+ 36 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
