Nokia 5800i XpressMusic User Guide
DRAFT 26 June 2009
DECLARATION OF CONFORMITY
0434
Nokia, Nokia Connecting People, Nokia Original Enhancements logos, Nokia Care, and Xp ressMusic are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
This software is based in part of the work of the FreeType Team. This product is covered by one or more of the following patents: United States Patent 5,155,805, United States Patent 5,325,479, United States Patent 5,159,668, United States Patent 2232861 and France Patent 9005712.
US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2009. Tegic Communications, Inc. All rights reserved.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com
.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
Hereby, NOKIA CORPORATION declares that this RM-602 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at www.nokia.com/phones/declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
This product includes software licensed from Symbian Software Ltd ©1998-2009. Symbian and Symbian OS are trademarks of Symbian Ltd.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
For the most current product information, please refer to www.nokia.com.cn.
Reverse engineering of any software in the Nokia device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on Nokia's representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties, damages and liabilities of Nokia's licensors. The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications. BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LA W. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPR ESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.
Export controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
DRAFT 26 June 2009
Contents
Safety...................................................................7
About your device......................................................................7
Network services.......................................................................8
1. Get started........................................................9
Keys and parts............................................................................9
Insert the SIM card...................................................................10
Insert battery ..........................................................................10
Charge the battery...................................................................11
Switch the device on...............................................................12
Stylus.........................................................................................12
Lock the keys and touch screen.............................................12
Home screen............................................................................12
Access the menu......................................................................13
Touch screen actions...............................................................13
Media key..................................................................................14
Change the ringing tone.........................................................15
Support.....................................................................................15
2. Find help.........................................................15
In-device help..........................................................................15
Extended user guide................................................................16
Software updates using your PC............................................16
Access codes.............................................................................16
3. Your device.....................................................17
Find an item with adaptive search........................................17
Memory card............................................................................17
Shortcuts..................................................................................18
Antenna locations....................................................................18
Contacts bar.............................................................................19
Offline profile...........................................................................19
Sensor settings and display rotation.....................................20
Headset.....................................................................................20
Remove the SIM card...............................................................20
Attach a wrist strap.................................................................21
4. Make calls.......................................................21
Proximity sensor......................................................................21
Voice calls ................................................................................21
5. Write text.......................................................21
Keys and functions..................................................................22
Chinese handwriting recognition..........................................23
Enter text with alphanumeric keypad...................................23
Chinese input with on-screen keyboard...............................25
Touch input settings...............................................................26
6. Messaging......................................................26
Messaging main view..............................................................26
Write and send messages.......................................................27
7. Music player....................................................28
Play a song or a podcast.........................................................28
Playlists.....................................................................................29
Transfer music from a computer...........................................29
8. Gallery............................................................29
View and organise files...........................................................30
View images and videos.........................................................30
9. Camera...........................................................31
Activate the camera................................................................31
Image capture..........................................................................31
Video recording.......................................................................34
10. Positioning (GPS)..........................................35
About GPS.................................................................................35
Assisted GPS (A-GPS)................................................................35
Hold your device correctly......................................................36
11. Connectivity..................................................36
12. Nokia Video Centre.......................................36
View and download video clips.............................................37
Video feeds...............................................................................38
My videos..................................................................................38
Transfer videos from your PC.................................................38
Video centre settings..............................................................39
13. Web browser................................................39
Browse the web.......................................................................39
Browser toolbar.......................................................................40
Bookmarks...............................................................................41
Empty the cache.......................................................................41
Connection security.................................................................41
14. Green tips.....................................................42
Save energy..............................................................................42
Contents
Recycle......................................................................................42
Save paper................................................................................42
Learn more...............................................................................43
Accessories.........................................................44
Battery................................................................46
Battery and charger information...........................................46
Nokia battery authentication guidelines..............................47
Care and maintenance.......................................48
Recycle......................................................................................49
China ROHS Table.....................................................................49
Additional safety information...........................49
Small children..........................................................................50
Operating environment..........................................................50
Medical devices........................................................................50
Vehicles.....................................................................................51
Potentially explosive environments......................................51
Emergency calls.......................................................................52
Certification information (SAR)..............................................52
MANUFACTURER’S LIMITED WARRANTY................53
Warranty period......................................................................53
How to get warranty service..................................................53
What is not covered?...............................................................54
Other important notices.........................................................55
Limitation of Nokia's liability.................................................55
Statutory obligations..............................................................56
Contents
How to obtain an English User Guide.................56
Index..................................................................58
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible products.
www.nokia.com/support 7
About your device
The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, 1900 and UMTS 900, 2100 networks. Contact your service provider for more information about networks.
When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.
Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, or transferred.
Your device supports several methods of connectivity. Like computers, your device may be exposed to viruses and other harmful content. Exercise caution with messages, connectivity requests, browsing, and downloads. Only install and use services and other software from trustworthy sources that offer adequate security and protection against harmful software, such as applications that are Symbian Signed or have passed the Java Verified™ testing. Consider installing antivirus and other security software on your device and any connected computer.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Safety
Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third­party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
Remember to make back-up copies or keep a written record of all important information stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
The images in this guide may differ from your device display. Refer to the user guide for other important information about
your device.
Network services
To use the device you must have service from a wireless service provider. Many of the features require special network
features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Using network services involves transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as MMS, browsing, and e-mail, require network support for these technologies.
8 www.nokia.com/support
1. Get started
Keys and parts
1 — Micro USB connector to connect to a compatible PC 2 — Nokia AV Connector (3.5 mm) for compatible headsets,
headphones, and TV-out connectors 3 — Charger connector 4 — Power key 5 — Earpiece 6 — Light sensor
www.nokia.com/support 9
7 — Proximity sensor 8 — Touch screen 9 — Secondary camera 10 — Volume/Zoom key 11 — Media key 12 — Screen and key lock switch 13 — Capture key 14 — End key 15 — Menu key 16 — Call key
17 — Pen stylus 18 — Camera lens 19 — Camera flash 20 — Loudspeakers
Get started
21 — Cover of the SIM card slot 22 — Cover of the memory card slot 23 — Wrist strap opening 24 — Microphone During extended operation such as an active video call and a
high speed data connection, the device may feel warm. In most cases, this condition is normal. If you suspect the device is not working properly, take it to the nearest authorised service facility.
Note: The surface of this device does not contain
nickel in the platings. The surface of this device contains stainless steel.
Do not cover the area above the touch screen, for example, with protective film or tape.
Insert the SIM card
Important: To prevent damage to the SIM card,
always remove the battery before you insert or remove the card.
A SIM card may be already inserted in the device. If not, do the following:
1. Open the cover of the SIM card slot.
2. Insert a SIM card in the slot. Ensure that the contact area on the card is facing up and the bevelled corner is facing toward the device. Push the card in.
3. Close the cover of the SIM card slot. Ensure that the cover is properly closed.
If the SIM card is not properly in place, the device can only be used in the offline profile.
Insert battery
Always switch the device off and disconnect the charger before removing the battery.
10 www.nokia.com/support
1. Remove the back cover by lifting it from the bottom end of the device.
2. Insert the battery.
3. To replace the cover, direct the top locking catches toward their slots first and then press down until the cover locks into place.
Charge the battery
1. Connect a compatible charger to a wall outlet.
Get started
2. Connect the power cord to the device. If the battery is completely discharged, it may take a while before the charging indicator starts scrolling.
3. When the battery is fully charged, the charging indicator stops scrolling. Disconnect the charger from the device, then from the wall outlet.
Tip: Disconnect the charger from the wall outlet when the charger is not in use. A charger that is connected to the outlet consumes power even when it is not connected to the device.
www.nokia.com/support 11
Get started
Switch the device on
1. Press and hold the power key.
2. If the device asks for a PIN code or
lock code, enter it, and select OK. To delete a number, select
. The factory setting for the
lock code is 12345.
3. Select your location. If you accidentally select the wrong location, select Back.
4. Enter the date and time. When using the 12-hour time format, to switch between a.m. and p.m., select any number.
Stylus
Some functions, such as handwriting recognition, are designed to be used with a stylus. The pen stylus is located in the back cover of the device.
Important: Use
only a stylus approved by Nokia for use with this device. Using any other stylus may invalidate any warranty applying to the device and may damage the touch screen. Avoid scratching
the touch screen. Never use an actual pen or pencil or other sharp objects to write on the touch screen.
Lock the keys and touch screen
To lock or unlock the touch screen and the keys, slide the lock switch on the side of the device.
When the touch screen and keys are locked, the touch screen is switched off and the keys are inactive.
The screen and keys may be locked automatically after a period of inactivity. To change settings for automatic screen and key locking, select Menu > Settings and Phone >
Phone mgmt. > Auto. keyguard > Keypad autolock period.
Home screen
Home screen is your starting point where you can collect all your important contacts or application shortcuts.
12 www.nokia.com/support
Interactive display elements
To open the clock application, tap the clock (1).
To open calendar or change profiles in the home screen, tap the date or the profile name (2).
To view or change
connectivity settings ( or to view the missed events, tap the top right corner (3).
To make a phone call, select
(4).
To open Contacts, select (5).
To open the main menu, press the menu key (6).
),
Start using the contacts bar
To start using the contacts bar and add your contacts to the home screen, in the home
screen, select contact to Home screen, and follow the instructions.
> Add
Get started
Change the home screen theme
To change the home screen theme or the shortcuts, select
Menu > Settings and Personal > Home screen.
Access the menu
To access the menu, press the menu key. To open an application or folder in the menu, tap it.
Touch screen actions
Tap and double-tap
To open an application or other element on the touch screen, you normally tap it with your finger or the stylus. However, to open the following items, you must tap them twice.
List items in an application, such as the Drafts folder in the folder list in Messaging
Tip: When you open a list view, the first item is already highlighted. To open the highlighted item, tap it once.
Applications and folders in the menu when using the list view type
Files in a file list, for example, an image in the images and videos view in Gallery.
If you tap a file or similar item once, it is not opened, it becomes highlighted. To see the options available for the item, select Options or, if available, select an icon from a toolbar.
www.nokia.com/support 13
Get started
Select
In this user documentation, opening applications or items by tapping them once or twice is called "selecting". If you need to select several items in a sequence, the display texts to select are separated by arrows.
Example: To select Options > Help, tap Options, and then tap Help.
Drag
To drag, place your finger or the stylus on the screen, and slide it across the screen.
Example: To scroll up or down on a web page, drag the page with your finger or stylus.
Swipe
To swipe, slide your finger quickly left or right on the screen.
Example: When viewing an image, to view the next or previous image, swipe the image left or right, respectively.
Scroll
To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.
In some list views, you can scroll by placing your finger or stylus on a list item and dragging up or down.
Example: To scroll through contacts, place your finger or stylus on a contact, and drag up or down.
Tip: To view a brief description of icons and buttons, place your finger or stylus on the icon or button. Descriptions are not available for all icons and buttons.
Touch screen light
The touch screen light is turned off after a period of inactivity. To turn the screen light on, tap it.
If the touch screen and keys are locked, tapping the screen does not turn the screen light on. To unlock the screen and keys, slide the lock switch.
Media key
To access applications such as the music player or browser, tap the
media key ( bar, and select the application.
) to open the media
Tip: Hold your finger or the stylus on the icon to see the name of the application.
14 www.nokia.com/support
Change the ringing tone
Select Menu > Settings and Personal > Profiles.
You can use profiles to set and customise the ringing tones, message alert tones, and other tones for different events, environments, or caller groups. To personalise a profile, scroll to the profile, and select Options > Personalise.
Support
When you want to learn more about how to use your product or you are unsure how your device should function, see the support pages at www.nokia.com/support or your local Nokia website, www.nokia.mobi/support (with a mobile device), the Help application in the device, or the user guide.
If this does not resolve your issue, do the following:
2. Find help
In-device help
Your device contains instructions to help to use the applications in your device.
To open help texts from the main menu, select Menu > Help and the application for which you want to read instructions.
When an application is open, to access the help text for the current view, select Options > Help.
Find help
Restart the device: switch off the device, and remove the battery. After about a minute, replace the battery, and switch on the device.
With the Nokia Software Updater application, update your device software regularly for optimum performance and possible new features. See www.nokia.com.cn/ softwareupdate or your local Nokia website. Remember to back up your device data before updating the device software.
Restore the original factory settings as explained in the user guide. Your documents and files are not deleted in the reset.
If the issue remains unsolved, contact Nokia for repair options. See www.nokia.com.cn/repair. Before sending your device for repair, always back up the data in your device.
When you are reading the instructions, to change the size of the help text, select Options > Decrease font size or Increase font size.
You can find links to related topics at the end of the help text. If you select an underlined word, a short explanation is
displayed. Help texts use the following indicators: a link to a related help topic.
application being discussed.
When you are reading the instructions, to switch between help texts and the application that is open in the background,
shows a link to the
shows
www.nokia.com/support 15
Find help
press and hold the menu key, and select from the list of open applications.
Software Updater application guides you to back up your files, update the software, and restore your files.
Extended user guide
An extended version of this user guide is available on the product support pages of the Nokia website. Some applications or functions are explained only in the extended user guide.
Software updates using your PC
Software updates may include new features and enhanced functions that were not available at the time of purchase of your device. Updating the software may also improve the device performance.
Nokia Software Updater is a PC application that enables you to update your device software. To update your device software, you need a compatible PC, broadband internet access, and a compatible USB data cable to connect your device to the PC.
To get more information, to check the release notes for the latest software versions, and to download the Nokia Software Updater application, see www.nokia.com.cn/ softwareupdate or your local Nokia website.
To update the device software, do the following:
1. Download and install the Nokia Software Updater application to your PC.
2. Connect your device to the PC using a USB data cable, and open the Nokia Software Updater application. The Nokia
16 www.nokia.com/support
Access codes
If you forget any of the access codes, contact your service provider.
Personal identification number (PIN) code — This code protects your SIM card against unauthorised use. The PIN code (4 to 8 digits) is usually supplied with the SIM card. After three consecutive incorrect PIN code entries, the code is blocked, and you need the PUK code to unblock it.
UPIN code — This code may be supplied with the USIM card. The USIM card is an enhanced version of the SIM card and is supported by UMTS mobile phones.
PIN2 code — This code (4 to 8 digits) is supplied with some SIM cards, and is required to access some functions in your device.
Lock code (also known as security code) — The lock code helps you to protect your device against unauthorised use. The preset code is 12345. You can create and change the code, and set the device to request the code. Keep the new code secret and in a safe place separate from your device. If you forget the code and your device is locked, your device will require service and additional charges may apply. For more information, contact a Nokia Care point or your device dealer.
Personal Unblocking Key (PUK) code and PUK2 code — These codes (8 digits) are required to change a blocked PIN code or PIN2 code, respectively. If the codes
are not supplied with the SIM card, contact the operator whose SIM card is in your device.
UPUK code — This code (8 digits) is required to change a blocked UPIN code. If the code is not supplied with the
3. Your device
Find an item with adaptive search
Adaptive search makes the characters, letters, numbers, and input symbols of the entries in your device available for searching.
To turn adaptive search on or off, select Menu > Settings and Phone > Touch input > Adaptive search.
To use adaptive search when a search field is available, tap the search field, and select the character, letter, number, or symbol of the entry you are searching for. To view more
characters, letters, numbers, or symbols, tap
To change the input method for adaptive search under the current writing language, select Menu > Settings and
Phone > Touch input > Chinese find method.
Memory card
Use only compatible microSD and microSDHC cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
.
Your device
USIM card, contact the operator whose USIM card is in your device.
Insert the memory card
A memory card may be already inserted in the device. If not, do the following:
1. Open the cover of the memory card slot.
2. Insert a compatible memory card in the slot. Ensure that the contact area is facing up. Push the card in. You can hear a click when the card locks into place.
www.nokia.com/support 17
Your device
3. Close the cover of the memory card slot. Ensure that the cover is properly closed.
Remove the memory card
Important: Do not remove the memory card in the
middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.
1. If the device is switched on, before you remove the card, press the power key, and select Remove memory card.
2. When Removing memory card will close all open
applications. Remove anyway? is displayed, select Yes. All applications are closed.
3. When Remove memory card and press 'OK' is displayed, open the cover of the memory card slot.
4. Press the memory card to release it from the slot.
5. Pull out the memory card. If the device is switched on, select OK.
Shortcuts
To switch between open applications, press and hold the menu key. Leaving applications running in the background increases the demand on battery power and reduces the battery life.
To start a web connection (network service), in the dialler, tap and hold 0.
To access applications available in the media bar, such as the music player and web browser, in any view, press the media key.
To change the profile, press the power key, and select a profile.
To call your voice mailbox (network service), in the dialler, tap and hold 1.
To open a list of last dialled numbers, in the home screen, press the call key.
To use voice commands, in the home screen, press and hold the call key.
Antenna locations
Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.
18 www.nokia.com/support
Loading...
+ 41 hidden pages
