Microsoft RM-598 User Manual
Nokia 7230-1c User Guide
Cyan
Magenta
Yellow
Black
92188951234567
Issue 1
Cyan
Magenta
Yellow
Black
2Contents
Cyan
Magenta
Yellow
Black
Contents
Safety 5
General
information 7
About your device 7
Network mode 8
Network services 8
Shared memory 9
Access codes 9
Software updates using
your PC 10
Support 11
Get started 12
Keys and parts 12
Install SIM card 13
Insert a memory card 14
Insert battery 16
Charge the battery 16
Switch on and off 18
Display 18
Keypad lock 19
GSM antenna 20
Accessories 20
Calls 22
Make and answer a
call 22
Loudspeaker 23
Dialling shortcuts 23
Write text 24
Text modes 24
Traditional text input 25
Predictive text input 25
Navigate the
menus 26
Messaging 26
Text and multimedia
messages 27
Flash messages 29
Nokia Xpress audio
messages 29
Nokia Mail 30
Instant messaging 32
Voice messages 33
Message settings 33
Cyan
Magenta
Yellow
Black
Contents 3
Cyan
Magenta
Yellow
Black
Contacts 34
Call log 36
Settings 36
Profiles 36
Tones 37
Display 37
Date and time 37
Shortcuts 38
Synchronisation and
backup 38
Connectivity 39
Call and phone 42
Accessories 43
Configuration 44
Restore factory
settings 44
Gallery 45
Applications 45
Alarm clock 45
Calendar and to-do
list 46
Extras 47
Camera and video 48
FM radio 49
Voice recorder 51
Media player 51
Maps 53
Web or Internet 59
Connect to a web
service 59
SIM services 60
Green tips 60
Save energy 60
Recycle 61
Learn more 61
Accessories 62
Battery 62
Battery and charger
information 62
Nokia battery
authentication
guidelines 63
Cyan
Magenta
Yellow
Black
4Contents
Cyan
Magenta
Yellow
Black
Taking care of your
device 64
Recycle 65
Additional safety
information 66
Small children 66
Operating
environment 66
Medical devices 66
Vehicles 67
Potentially explosive
environments 67
Emergency calls 68
Certification information
(SAR) 68
Index 70
Cyan
Magenta
Yellow
Black
Safety 5
Cyan
Magenta
Yellow
Black
Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
Cyan
Magenta
Yellow
Black
6Safety
Cyan
Magenta
Yellow
Black
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Cyan
Magenta
Yellow
Black
General information 7
Cyan
Magenta
Yellow
Black
General information
About your device
The wireless device described in this guide is approved for
use on the GSM 850, 900, 1800, 1900 and WCDMA 850, 1900,
and 2100 MHz networks. Contact your service provider for
more information about networks.
Your device may have preinstalled bookmarks and links for
third-party internet sites and may allow you to access
third-party sites. These are not affiliated with Nokia, and
Nokia does not endorse or assume liability for them. If you
access such sites, take precautions for security or content.
Warning:
To use any features in this device, other than the alarm
clock, the device must be switched on. Do not switch the
device on when wireless device use may cause interference
or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some
images, music, and other content from being copied,
modified, or transferred.
Cyan
Magenta
Yellow
Black
8 General information
Cyan
Magenta
Yellow
Black
Make back-up copies or keep a written record of all
important information stored in your device.
When connecting to any other device, read its user guide
for detailed safety instructions. Do not connect
incompatible products.
The images in this guide may differ from your device
display.
Refer to the user guide for other important information
about your device.
Network mode
To select the type of network to use, select Menu >
Settings > Phone > Network mode. You cannot access
this option during an active call.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make
specific arrangements with your service provider to use
them. Network services involve transmission of data. Check
with your service provider for details about fees in your
home network and when roaming on other networks. Your
service provider can explain what charges will apply. Some
networks may have limitations that affect how you can use
Cyan
Magenta
Yellow
Black
General information 9
Cyan
Magenta
Yellow
Black
some features of this device requiring network support
such as support for specific technologies like WAP 2.0
protocols (HTTP and SSL) that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu
names, menu order, and icons.
Shared memory
The following features in this device may share memory:
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may
reduce the memory available for the remaining features.
If your device displays a message that the memory is full,
delete some of the information stored in the shared
memory.
Access codes
The security code helps to protect your device against
unauthorised use. The preset code is 12345. You can create
and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate
from your device. If you forget the code and your device is
locked, your device will require service. Additional charges
may apply, and all the personal data in your device may be
Cyan
Magenta
Yellow
Black
10 General information
Cyan
Magenta
Yellow
Black
deleted. For more information, contact a Nokia Care point
or your device dealer.
The PIN code supplied with the SIM card protects the card
against unauthorised use. The PIN2 code supplied with
some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your service provider.
The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
To set how your device uses the access codes and security
settings, select Menu > Settings > Security.
Software updates using your PC
Nokia Software Updater is a PC application that enables you
to update your device software. To update your device
software, you need a compatible PC, broadband internet
access, and a compatible USB data cable to connect your
device to the PC.
To get more information, to check the release notes for the
latest software versions, and to download the Nokia
Cyan
Magenta
Yellow
Black
General information 11
Cyan
Magenta
Yellow
Black
Software Updater application, see www.nokia.com/
softwareupdate or your local Nokia website.
To update the device software, do the following:
1 Download and install the Nokia Software Updater
application to your PC.
2 Connect your device to the PC using a USB data cable,
and select PC Suite.
3 Open the Nokia Software Updater application. The
Nokia Software Updater application guides you to back
up your files, update the software, and restore your
files.
Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, see the user guide or see the support pages at
www.nokia.com/support or your local Nokia website, or
with a mobile device, www.nokia.mobi/support.
If this does not resolve your issue, do one of the following:
• Restart the device: switch off the device, and remove
the battery. After about a minute, replace the battery,
and switch on the device.
• Restore the original factory settings as explained in the
user guide.
Cyan
Magenta
Yellow
Black
12 Get started
Cyan
Magenta
Yellow
Black
• Update your device software regularly for optimum
performance and possible new features, as explained
in the user guide.
If your issue remains unsolved, contact Nokia for repair
options. See www.nokia.com/repair. Before sending your
device for repair, always back up the data in your device.
Get started
Keys and parts
Display
1
2 Navi™ key (scroll key)
3 Selection keys
4 Call key
5 Keypad
6 Earpiece
7 End/Power key
Cyan
Magenta
Yellow
Black
Get started 13
Cyan
Magenta
Yellow
Black
8 Charger
connector
9 USB port
10 Headset
connector
11 Lens
12 Capture key
13 Wrist strap
eyelet
Install SIM card
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
Cyan
Magenta
Yellow
Black
14 Get started
Cyan
Magenta
Yellow
Black
1 Remove the battery if inserted, and slide the SIM card
holder to unlock.
2 Open the card holder.
3 Insert the SIM card into the holder with the contact
surface facing down.
4 Close the card holder.
5 Slide the card holder to lock.
Insert a memory card
Use only compatible MicroSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
Cyan
Magenta
Yellow
Black
Get started 15
Cyan
Magenta
Yellow
Black
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.
Your device supports microSD cards with a capacity of up
to 16 GB. The size of a single file must not exceed 2 GB.
Insert a memory card
1 Remove the battery if inserted, and slide the memory
card holder to unlock.
2 Swing the card holder open.
3 Insert the memory card into the card holder with the
contact surface facing down.
4 Close the card holder.
5 Slide the card holder to lock.
Cyan
Magenta
Yellow
Black
16 Get started
Cyan
Magenta
Yellow
Black
Insert battery
1 Remove the back cover if in place, observe the battery
contacts, and insert the battery.
2 Replace the back cover.
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
Cyan
Magenta
Yellow
Black
Get started 17
Cyan
Magenta
Yellow
Black
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You can also charge the battery with a USB cable with
power from a computer.
1 Connect the USB cable to a USB port of a computer and
to your device.
2 When the battery is fully charged, disconnect the USB
cable.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
Charging the device while listening to the radio may affect
the quality of reception.
Cyan
Magenta
Yellow
Black
18 Get started
Cyan
Magenta
Yellow
Black
Switch on and off
Press and hold the power key.
Display
6
7
10
1 Signal strength of the cellular network
2 Battery charge status
3 Indicators
4 Name of the network or the operator logo
5 Clock
6 Date (only if the enhanced home screen is deactivated)
7 Display
8 Function of the left selection key
9 Function of the scroll key
Cyan
Magenta
Yellow
Black
Get started 19
Cyan
Magenta
Yellow
Black
10 Function of the right selection key
You can change the function of the left and right selection
key. See "Shortcuts", p. 38.
Keypad lock
To prevent accidental keypresses, close the phone, and
select Lock within 5 seconds to lock the keypad.
To unlock the keypad, select Unlock > OK, or open the
phone. If the security keyguard is on, enter the security
code when requested.
To set the keypad to lock automatically after a preset time
when the phone is in the standby mode, select Menu >
Settings > Phone > Automatic keyguard > On.
To answer a call when the keypad is locked, press the call
key. When you end or reject the call, the keypad locks
automatically.
When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.
Cyan
Magenta
Yellow
Black
20 Get started
Cyan
Magenta
Yellow
Black
GSM antenna
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
The figure shows the GSM antenna area marked in grey.
Accessories
Connect a USB cable
Open the cover of the USB connector, and connect the USB
cable to the device.
Cyan
Magenta
Yellow
Black
Get started 21
Cyan
Magenta
Yellow
Black
Headset
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.
Cyan
Magenta
Yellow
Black
22 Calls
Cyan
Magenta
Yellow
Black
Strap
1 Open the back cover.
2 Thread the strap, and tighten it.
3 Close the back cover.
Calls
Make and answer a call
To make a call, enter the phone number, including the
country and area code if necessary, and press the call key.
Cyan
Magenta
Yellow
Black
Calls 23
Cyan
Magenta
Yellow
Black
To adjust the volume of the earpiece or headset during the
phone call, scroll up or down.
To ans wer an inc omi ng c all, p res s th e ca ll key . To rejec t th e
call without answering, press the end key.
Loudspeaker
If available, you may select Loudsp. or Handset to use the
loudspeaker or the earpiece of the phone during a call.
Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Dialling shortcuts
Assign a phone number to a number key
Select Menu > Contacts > Speed dials, scroll to a desired
number (2-9), and select Assign. Enter the desired phone
number, or select Search and a saved contact.
Activate speed dialling
Select Menu > Settings > Call > Speed dialling > On.
Cyan
Magenta
Yellow
Black
Loading...
