Microsoft RM-595 User Manual

RM-595 User Guide

Draft

Nokia, Nokia Connecting People, and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS" EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

Reverse engineering of any software in the Nokia device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on Nokia’s representations warranties, damages and

liabilities, such limitations shall likewise limit any representations,

Draft

warranties, damages and liabilities of Nokia’s licensors.

The availability of particular products and applications for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls

This device may contain commodities, technology, or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyright or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications.

BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

FCC NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC can require

you to stop using your telephone if such interference cannot be eliminated.

Draft

If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user’s authority to operate this equipment.

xxxxxxx/Issue 1

Contents

Draft

SAFETY........................................................................................ 7

1. Get started......................................................................... 11

Install the UIM card and battery........................................................................ 11

Insert and remove the microSD card................................................................. 13

Charge the battery.................................................................................................. 15

Switch your device on or off ............................................................................... 16

Normal operating position ................................................................................... 16

Access codes............................................................................................................. 17

Nokia support on the web.................................................................................... 18

2. Your device ........................................................................ 19

Keys and parts (front) ............................................................................................ 19

Keys and parts (back)............................................................................................. 20

Standby mode and shortcuts............................................................................... 21

Active Standby......................................................................................................... 22

Keyguard.................................................................................................................... 23

3. Call functions ..................................................................... 24

Make a call................................................................................................................ 24

Answer or reject a call........................................................................................... 24

Conference call........................................................................................................ 25

Loudspeaker.............................................................................................................. 25

Voice dialling............................................................................................................ 26

4. Write text .......................................................................... 28

Switch between input methods.......................................................................... 28

Pinyin input method............................................................................................... 29

Stroke input method .............................................................................................. 29

Phrase input.............................................................................................................. 31

Set predictive English input on and off............................................................ 33

Traditional English input....................................................................................... 33

Draft

Predictive English input ........................................................................................ 33

Tips for writing text................................................................................................ 34

5. Voice commands................................................................. 36

Activate and use voice commands..................................................................... 36

Voice commands settings ..................................................................................... 37

6. Menu functions ................................................................. 38

Messaging ................................................................................................................. 38

Contacts..................................................................................................................... 47

Log............................................................................................................................... 49

esurfing...................................................................................................................... 50

Web............................................................................................................................. 50

Best Tone................................................................................................................... 51

Customer Service .................................................................................................... 51

Settings...................................................................................................................... 51

Gallery ........................................................................................................................ 64

Media.......................................................................................................................... 65

Organiser ................................................................................................................... 71

Extras.......................................................................................................................... 75

7. Accessories .......................................................................... 76

8. Battery and charger information ..................................... 77

Battery information................................................................................................ 80

Nokia battery authentication guidelines.......................................................... 81

Care and maintenance ............................................................ 84

Additional safety information ............................................... 87

Index ........................................................................................ 95

SAFETY

Draft

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES AND BATTERIES

Draft

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

■About your device

The wireless device (RM-595) described in this guide is approved for use on the CDMA 800 MHz network. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Your device may have preinstalled bookmarks and links for thirdparty internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.

Warning: To use any features in this device, other than

Draft

the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

Remember to make back-up copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

■Network services

To use the device you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Using network services involves transmission of data. Check with your service provider for details about fees in your home network and when roaming in other networks. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be

Draft

disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as sending e-mail, browsing websites, or downloading files require network support for these technologies.

1. Get started

Draft

■Install the UIM card and battery

Note: Always switch the phone off and

disconnect the charger and any other device before removing the cover. Avoid touching electronic components while changing the cover. Always store and use the device with the cover attached.

Note: Always switch the device off and disconnect the charger before removing the battery.

Remove the back cover and battery

1. To remove the back cover, with the back of the device facing you, press the release button, and lift up the back cover.

2. To remove the battery,

BL-4C

Draft

insert your finger into the finger grip, and lift the battery from its compartment.

Insert the UIM card

Ensure that the contact area on the UIM card is facing downwards and the bevelled corner on the card is facing outwards from the top of the device, and insert the UIM card into the card slot.

Replace the battery and back cover

1. To insert the battery, position the battery by aligning the contacts with those on the device, and press down on the other end of the battery to snap the battery into place.

BL-4C

2. To replace the back cover,

Draft

insert the tabs at the top of the cover into the slots in the device, and press down on the other end of the back cover.

■Insert and remove the microSD card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Insert the microSD card

Draft

1. Remove the back cover. See step 1 in "Remove the back cover and battery", p. 11.

2. Ensure that the contact area on the microSD card is facing downwards, and insert the microSD card into the card slot until it clicks into place.

3. Replace the cover. See step 2 in "Replace the battery and back cover", p. 12.

Remove the microSD card

Important: Do not remove the memory card in

the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

1. Remove the back cover. See step 1 in cover and battery", p. 11.

"Remove the back

2. Press the microSD card slightly into the card slot,

Draft

release to eject the card, and remove it from the slot.

3. Replace the cover. See step 2 in "Replace the battery and back cover", p. 12.

■Charge the battery

Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:

1. Connect the charger to a wall socket.

2. Connect the charger to the device.

3. When the device indicates a full charge, disconnect the charger from the device, then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.

■Switch your device on or off

Draft

Press and hold the power key on the keypad for at least three seconds.

Warning: Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

■Normal operating position

Your device has an internal antenna. Use the device only in its normal operating position.

Note: Your device may have

Draft

internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.

■Access codes

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device. Making an emergency call in the offline profile or when the device is locked requires that the device recognise the number to be an official emergency number. It is advisable to change the profile or unlock the device by entering the lock code before you make the emergency call.

To activate the device when it is locked, enter the lock

Draft

code. The default lock code is 1234.

To define the security settings for your device, select

Menu > Settings > Security.

■Nokia support on the web

Check www.nokia.com/support or your local Nokia website for the latest guide, additional information, downloads, and services related to your Nokia product.

2. Your device

Draft

■Keys and parts (front)

1. Earpiece

2. Media keys

3. Left selection key

4. Call key

5. Navi™ key; hereafter referred to as scroll key

6. Keypad

7. Power/End key

8. Middle selection key

9. Right selection key

■Keys and parts (back)

Draft

1. Headset connector

2. Wrist strap eyelet

3. Flash

4. Volume keys

5. Camera key

6. Speaker

7. Release button

8. Microphone

9. Charger/USB port

10.Camera lens

■Standby mode and shortcuts

Draft

Generally, instructions in this guide start from the standby mode except when specifically indicated. To go to the standby mode, press the power/end key.

Depending on your wireless service provider, some or all of the following selection keys may appear in the standby mode.

1. Signal strength — The signal strength of the wireless network at your current location.

2. Battery level — The battery charge level.

3. Menu — Press the left selection key to access the main menu.

4. Go to — Press the right selection key to quickly access a certain feature.

5. Web — Press the middle selection key to access mobile internet service.

Shortcuts in the standby mode:

Go to Names

34 5

• To access the list of dialled numbers, press the call key

Draft

once.

• To switch between General profile and Silent profile, press and hold # for at least three seconds.

• To activate the radio function, press and hold * for at least three seconds.

• For shortcuts of scroll key, see "My shortcuts", p. 56.

■Active standby

To activate the active standby mode, scroll up in the standby mode. To access a feature, scroll left or right to select the feature and select Select. To end the active standby navigation mode, select Exit.

To switch on the mode, select Menu > Settings > Display > Active standby > Active standby mode.

To change the default application shortcuts, select

Menu > Settings > Display > Active standby > Personalise

view.

■Keyguard

Draft

Keyguard locks the keypad to prevent accidental key presses.

When the keypad is locked, calls still may be possible to the official emergency number programmed into your device. Enter the emergency number, and press the call key. The number is displayed only after you have entered its last digit.

To lock the keypad automatically when no keys are pressed for a certain time, in the standby mode, select

Menu > Settings > Phone > Automatic keyguard > On.

To lock the keypad, close the slide, and select Lock.

To unlock the keypad, open the slide or press Unlock then press * within 2 seconds.

If you receive a call when the keypad is locked, it is automatically unlocked, and then locked again when you end the call.

3. Call functions

Draft

■Make a call

1. In the standby mode, enter the phone number, including the country code and area code if necessary.

2. Press the call key.

3. To end the call or to cancel the call attempt, press the end key.

■Answer or reject a call

To answer a call, press the call key or open the slide. To reject an incoming call, press the end key.

■Conference call

Draft

Conference call (network service) allows you to take part in a call with another two participants.

1. To call a third party during a call, select Options > New

call.

2. Enter the number you want, and press the call key.

3. When the new call is answered, press the call key.

4. To end the conference call, select Options > End all

calls, or press the end key.

■Loudspeaker

Warning: Do not hold the device near your ear

when the loudspeaker is in use because the volume may be extremely loud.

To activate the loudspeaker during a call, select Loudsp. To deactivate the loudspeaker, select Normal. When a headset is connected, select Heads.

The loudspeaker is deactivated automatically when a call (or a call attempt) ends or when certain accessories are connected.

■Voice dialling

Draft

You can make a phone call by saying the name or the number that is saved in the contact list of the device. Voice tags are automatically created when a new contact is added.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialling in all circumstances.

As voice commands are language-dependent, before voice dialling, select Menu > Settings > Phone > Language

settings > Recogn. language and your language.

To activate voice dialling, press and hold the right selection key or the volume key down. A short tone sounds, and Say a command is displayed.

To deactivate voice dialling, press the end key.

To make a call by voice dialling, clearly say Call then the name or the number of the contact you want to dial. If the device recognises the name you spoke, it shows a list of matches.

To listen to a voice tag, select Menu > Contacts > Names

Draft

> a contact > Details > contact name > Options > Play

voice tag.

4. Write text

Draft

The input methods available in the phone are preset according to the market where it will be sold.

This phone supports simplified Chinese input methods.

To switch writing language, when writing text, press and hold #, and select Writing language and the desired language.

■Switch between input methods

Input method indicators are shown at the top of the display:

Pinyin Lower case

Stroke Number

Uppercase

Not all the methods may be available in all circumstances. Always check the indicator to see which input method is in use.

input

To switch between available input methods, press #

Draft

repeatedly until the indicator of the desired input method is displayed.

■Pinyin input method

The pinyin symbols are printed on the number keys. You only need to press a key once, regardless of the position of the symbol on the number key. The phone makes logical combinations of the pinyin symbols.

To input a character using the pinyin input method:

1. Press the number key once for each pinyin symbol you want to input (use "v" for "u").

2. Press 1 repeatedly until you get the desired tone mark.

3. If necessary, press * repeatedly to highlight the desired pinyin combination.

4. Scroll to the desired Chinese character, and select OK.

■Stroke input method

The strokes constituting Chinese characters have been divided into five categories: horizontal, vertical, left-

falling, dot, and turning. Each category corresponds to a

Draft

number key from 1 to 5, respectively.

The strokes are classified according to the following table:

+ 67 hidden pages
