Microsoft RM-561 User Manual

Nokia 2700 classic User Guide
9215116
Issue 1
DECLARATION OF CONFORMITY
0434
essential requirements and other relevant provisions of Directive 1999/5/ EC. A copy of the Declaration of Conformity can be found at www.nokia.com/phones/declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2008. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information
Hereby, NOKIA CORPORATION declares that this RM-561 product is in compliance with the
which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http:// www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE TH IS DO CUME NT OR WITHD RAW I T AT A NY TI ME WIT HOUT PRIO R NOTICE .
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.
Export controls
This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any
changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
9215116/Issue 1 EN
5
Contents
Safety........................................................................................ 9
General information .............................................................. 13
Access codes........................................................................................................... 13
Nokia PC Suite ....................................................................................................... 14
Nokia support......................................................................................................... 14
1. Get started ......................................................................... 15
Insertl SIM card and battery.............................................................................. 15
Remove the SIM card........................................................................................... 16
Insert a microSD card .......................................................................................... 16
Remove the microSD card .................................................................................. 17
Charge the battery................................................................................................ 18
Antenna ................................................................................................................... 19
Headset .................................................................................................................... 19
Magnets and magnetic fields............................................................................ 20
2. Your phone ........................................................................ 20
Keys and parts........................................................................................................ 20
Switch the phone on and off............................................................................. 21
Standby mode ........................................................................................................ 21
Keypad lock............................................................................................................. 22
Functions without a SIM card........................................................................... 22
Applications running in background ............................................................... 23
3. Calls.................................................................................... 23
Make and answer a call ...................................................................................... 23
Loudspeaker............................................................................................................ 23
Dialling shortcuts.................................................................................................. 24
6
4. Write text........................................................................... 24
Text modes.............................................................................................................. 24
Traditional text input........................................................................................... 25
Predictive text input............................................................................................. 25
5. Navigate the menus .......................................................... 26
6. Messaging .......................................................................... 27
Text and multimedia messages......................................................................... 27
E-mail....................................................................................................................... 30
Flash messages ...................................................................................................... 31
Nokia Xpress audio messages............................................................................ 32
Instant messaging................................................................................................. 32
Voice messages...................................................................................................... 33
Message settings................................................................................................... 33
7. Contacts ............................................................................. 34
8. Call log............................................................................... 35
9. Settings .............................................................................. 36
Profiles ..................................................................................................................... 36
Tones......................................................................................................................... 36
Display...................................................................................................................... 37
Date and time ........................................................................................................ 37
Shortcuts ................................................................................................................. 37
Synchronisation and backup.............................................................................. 38
Connectivity............................................................................................................ 39
Calls and phone..................................................................................................... 41
Voice commands and voice dialling ................................................................ 42
Enhancements........................................................................................................ 44
Configuration ......................................................................................................... 44
Restore factory settings...................................................................................... 45
7
10.Operator menu ................................................................. 46
11.Gallery ............................................................................... 46
12.Media ................................................................................ 48
Camera and video ................................................................................................. 48
FM radio................................................................................................................... 49
Voice recorder........................................................................................................ 50
Music player ........................................................................................................... 50
13.Applications...................................................................... 52
14.Organiser........................................................................... 53
Alarm clock ............................................................................................................. 53
Calendar and to-do list ....................................................................................... 53
15.Web or Internet ................................................................ 54
Connect to a web service ................................................................................... 55
16.SIM services ...................................................................... 55
17.Green tips.......................................................................... 56
Save energy............................................................................................................. 56
Recycle..................................................................................................................... 57
Learn more.............................................................................................................. 57
18.Accessories........................................................................ 57
19.Battery and charger information .................................... 58
Nokia battery authentication guidelines........................................................ 60
Care and maintenance........................................................... 62
Additional safety information .............................................. 65
Index ....................................................................................... 74
8
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
9
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for use on the (E)GSM 850, 900, 1800, and 1900 MHz networks. Contact your service provider for more information about networks.
When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.
Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.
Your device may have preinstalled bookmarks and links for third­party internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.
Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do
10
not switch the device on when wireless device use may cause interference or danger.
Remember to make back-up copies or keep a written record of all important information stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Network services
To use the device you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Using network services involves transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a
11
special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as multimedia messaging (MMS), browsing, and e-mail application require network support for these technologies.
Shared memory
The following features in this device may share memory: multimedia messaging (MMS), e-mail application, instant messaging. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing.
12
General information
Access codes
The security code helps to protect your phone against unauthorised use. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your phone dealer.
The PIN code supplied with the SIM card protects the card against unauthorized use. The PIN2 code supplied with some SIM cards is required to access certain services. If you enter the PIN or PIN2 code incorrectly three times in succession, you are asked for the PUK or PUK2 code. If you do not have them, contact your service provider.
The module PIN is required to access the information in the security module of your SIM card. The signing PIN may be required for the digital signature. The barring password is required when using the call barring service.
13
To set how your phone uses the access codes and security settings, select Menu > Settings > Security.
Nokia PC Suite
You can find Nokia PC Suite and related information on the Nokia website at www.nokia.com/support.
Nokia support
Check www.nokia.com/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.
Configuration settings service
Download free configuration settings such as MMS, GPRS, e-mail, and other services for your phone model at www.nokia.com/support.
Nokia Care services
If you need to contact Nokia Care services, check the list of local Nokia Care contact centres at www.nokia.com/customerservice.
14
Maintenance
For maintenance services, check your nearest Nokia Care point at www.nokia.com/repair.
1. Get started
Insert SIM card and battery
Always switch the device off and disconnect the charger before removing the battery.
The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.
1. Press and slide the back cover towards the bottom of the phone, and remove it (1).
2. Remove the battery (2).
15
3. Insert the SIM card into the holder with the contact surface facing down (3).
4. Insert the battery (4), and replace the back cover (5).
Remove the SIM card
Press the release spring (1), and slide out the SIM card (2).
Insert a microSD card
Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
16
Your phone supports microSD cards with a capacity of up to 2 GB.
1. Open the cover of the memory card slot.
2. Insert the card into the memory card slot with the contact surface facing up, and press until it locks into place.
3. Close the cover of the memory card slot.
Remove the microSD card
Important: Do not remove the memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as
the device, and data stored on the card may be corrupted.
You can remove or replace the memory card during phone operation without switching the device off, but you need
17
to ensure that no application is currently accessing the memory card.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low charge, do the following:
1. Connect the charger to a wall outlet.
2. Connect the charger to the device.
3. When the device indicates a full charge, disconnect the charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the device while it is charging. If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.
18
Antenna
Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contac t with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.
The figure shows the antenna area marked in grey.
Headset
Warning: Listen to music at a moderate level. Continuous exposure to high volume may damage your hearing. Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.
Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.
19
When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields .
2. Your phone
Keys and parts
• End/Power key (1)
• Earpiece (2)
• Display (3)
• Selection keys (4)
•Navi™ key; hereafter referred to as scroll key (5)
• Call key (6)
• Keypad (7)
• Microphone (8)
• Headset connector/Nokia AV Connector (3.5 mm) (9)
20
• Charger connector (10)
• Micro USB connector (11)
• Camera lens (12)
• Memory card slot (13)
• Loudspeaker (14)
• Wrist strap eyelet (15)
Switch the phone on
and off
To switch the phone on or off, press and hold the power key.
Standby mode
When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.
21
Network signal strength (1)
Battery charge level (2)
Network name or operator logo (3)
Functions of selection keys (4)
The left selection key, Go to, allows you to access the functions in your personal shortcut list. When viewing the list, select Options > Select options to view the available functions, or select Options > Organise to arrange the functions in your shortcut list.
Keypad lock
To prevent accidental keypresses, select Menu, and press * within 3.5 seconds to lock the keypad.
To unlock the keypad, select Unlock, and press * within 1.5 seconds.If the security keyguard is on, enter the security code when requested.
To set the keypad to lock automatically after a preset time when the phone is in the standby mode, select Menu > Settings > Phone > Automatic keyguard > On.
22
To answer a call when the keypad is locked, press the call key. When you end or reject the call, the keypad locks automatically.
When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.
Functions without a SIM card
Some functions of your phone may be used without inserting a SIM card, such as Organiser functions and games. Some functions appear dimmed in the menus and cannot be used.
Applications running in background
Leaving applications running in the background increases the demand on battery power and reduces the battery life.
3. Calls
Make and answer a call
To make a call, enter the phone number, including the country code and area code if necessary. Press the call key to call the number. Scroll up to increase or down to decrease the volume of the earpiece or headset during the phone call.
23
Loading...
+ 53 hidden pages
