Nokia 2680 User Guide
DRAFT
9210880
Issue 1
© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2008. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICAB LE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PRO VIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABL E LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NO KIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR W ITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.
Export controls
DRAFT
This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications. BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIN D, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NO T LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
FCC/INDUSTRY CANADA NOTICE Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
9210880/Issue 1
DRAFT
Contents
Safety........................................6
5. Navigate the menus...........16
1. General information.............7
About your device..................................7
Network services....................................7
Shared memory......................................8
Access codes...........................................8
Nokia support.........................................9
2. Get started............................9
Install SmartChip card and battery......9
Charge the battery...............................10
Antenna.................................................11
Magnets and magnetic fields..............11
Keys and parts......................................11
Switch the phone on and off..............12
Standby mode .....................................12
Keypad lock...........................................13
Functions without a SmartChip card..13 Applications running in
background..........................................13
3. Calls.....................................14
Make and answer a call.......................14
Loudspeaker.........................................14
Dialing shortcuts..................................14
4. Write text............................15
Text modes...........................................15
Traditional text input..........................15
Predictive text input............................15
DRAFT
6. Messaging...........................16
Text and multimedia messages.........16
Mobile E-mail........................................18
Flash messages....................................20
Audio messages.................................21
Instant messaging...............................21
Voice mail.............................................26
Message settings..................................27
7. Address book.......................27
8. Recent calls ........................28
9. Settings...............................29
Profiles..................................................29
Tones.....................................................29
Display...................................................29
Date and time.......................................29
Shortcuts...............................................30
Synchronization and backup..............30
Connectivity..........................................30
Calls and phone...................................32
Enhancements.....................................32
Configuration.......................................33
Restore factory settings......................33
10. Operator menu.................33
11. Tones and graphics............34
12. Multimedia........................34
Camera and video................................34
Voice recorder......................................35
Music player..........................................35
13.Games and applications.....36
14. Tools.................................36
Alarm clock...........................................36
Calendar and to-do list........................37
15. MEdia Net..........................37
Connect to a service.............................37
Appearance settings............................38
Cache memory......................................38
Browser security..................................38
16. SmartChip services............39
Enhancements........................39
Battery....................................40
Battery and charger
information..........................................40
Nokia battery authentication
guidelines.............................................41
Care and maintenance............43
Disposal.................................................44
DRAFT
Additional safety
information............................44
Small children.......................................44
Operating environment.......................44
Medical devices....................................45
Vehicles.................................................46
Potentially explosive
environments.......................................46
Emergency calls....................................47
Certification information (SAR)..........48
Index.......................................49
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect incompatible products.
DRAFT
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
© 2008 Nokia. All rights reserved.6
1. General information
About your device
The wireless device described in this guide is approved for use on the GSM 850 and 1900 networks. Contact your service provider for more information about networks.
When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.
Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred.
Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.
Warning: To use any features in this device, other than the alarm clock, the
device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
Remember to make back-up copies or keep a written record of all important information stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
Network services
To use the phone you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.
© 2008 Nokia. All rights reserved. 7
DRAFT
Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as multimedia messaging (MMS), browsing, and e-mail application, require network support for these technologies.
Shared memory
The following features in this device may share memory: multimedia messaging (MMS), e-mail application, instant messaging . Use of one or more of these features may reduce the memory available for the remaining features sharing memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing.
Access codes
The security code helps to protect your phone against unauthorized use. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your phone dealer.
The PIN code supplied with the SmartChip card protects the card against unauthorized use. The PIN2 code supplied with some SmartChip cards is required
to access certain services. If you enter the PIN or PIN2 code incorrectly three times in succession, you are asked for the PUK or PUK2 code. If you do not have them, contact your service provider.
The module PIN is required to access the information in the security module of your SmartChip card. The signing PIN may be required for the digital signature. The restriction password is required when using the call restriction service.
To set how your phone uses the access codes and security settings, select Menu SettingsSecurity.
DRAFT
© 2008 Nokia. All rights reserved.8
Nokia support
Check www.nokia.com/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.
Configuration settings service
Download free configuration settings such as MMS, GPRS, e-mail, and other services for your phone model at www.nokia.com/support.
Nokia PC Suite
You may find PC Suite and related information on the Nokia website at www.nokia.com/support.
Nokia Care services
If you need to contact Nokia Care services, check the list of local Nokia Care contact centers at www.nokia.com/customerservice.
Maintenance
For maintenance services, check your nearest Nokia Care point at www.nokia.com/ repair.
2. Get started
Install SmartChip card and battery
Battery removing
Always switch the device off and disconnect the charger before removing the battery.
The SmartChip card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.
DRAFT
© 2008 Nokia. All rights reserved. 9
1. Push the back cover from the top of the phone, and remove it (1).
2. Remove the battery (2), and insert the SmartChip card (3).
3. Insert the battery (4), and replace the back cover (5).
Charge the battery
Your battery has been precharged, but the charging levels may vary.
1. Connect the charger to a wall outlet.
2. Connect the charger to the device. You can use your device while it is charging.
3. When the battery is fully charged, disconnect the charger from the device, then from the wall outlet.
If the battery is completely discharged, it may take several minutes before the charging indicator appears on the display or before any calls can be made.
DRAFT
© 2008 Nokia. All rights reserved.10
Antenna
Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.
The figure shows the antenna area marked in grey.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields as they may cause some applications, such as the camera, to activate unexpectedly.
Keys and parts
1 Earpiece
2 Display
3 Selection keys
4 Navi™ key; hereafter referred to as scroll
key
5 Call key
6 End/Power key
7 Keypad
DRAFT
© 2008 Nokia. All rights reserved. 11
8 Camera lens
9 Loudspeaker
10 Microphone
11 Strap eyelet
12 Headset connector
13 Charger connector
Note: Avoid touching this connector as it is intended for use by authorized
service personnel only.
Switch the phone on and off
To switch the phone on or off, press and hold the power key.
Standby mode
When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.
1
Network signal strength
2 Battery charge level
3 Network name or operator logo
4 Functions of selection keys
DRAFT
© 2008 Nokia. All rights reserved.12
The left selection key is Go to for you to view the functions in your personal shortcut list. When viewing the list, select OptionsSelect options to view the available functions, or select OptionsOrganize to arrange the functions in your shortcut list.
Keypad lock
To prevent accidental keypresses, close the phone, and select Lock within 5 seconds to lock the keypad.
To unlock the keypad, select UnlockOK, or open the phone. If the security keyguard is on, enter the security code when requested.
To set the keypad to lock automatically after a preset time when the phone is in the standby mode, select MenuSettingsPhone settingsAutomatic keyguard On.
To answer a call when the keypad is locked, press the call key. When you end or reject the call, the keypad locks automatically.
When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.
Functions without a SmartChip card
Some functions of your phone may be used without inserting a SmartChip card, such as Tools functions and games. Some functions appear dimmed in the menus and cannot be used.
Applications running in background
Leaving applications running in the background increases the demand on battery power and reduces the battery life.
© 2008 Nokia. All rights reserved. 13
DRAFT
3. Calls
Make and answer a call
To make a call, enter the phone number, including the country code and area code if necessary. Press the call key to call the number. Scroll up to increase or down to decrease the volume of the earpiece or headset during the phone call.
To answer an incoming call, press the call key. To reject the call without answering, press the end key.
Loudspeaker
If available, you may select Phn/Spk to use the loudspeaker or the earpiece of the phone during a call.
Warning: Do not hold the device near your ear when the loudspeaker is in
use, because the volume may be extremely loud.
Dialing shortcuts
To assign a phone number to one of the number keys, 2 to 9, select Menu AddressbookSpeed dial list, scroll to a desired number, and select Assign.
Enter the desired phone number, or select Find and a saved contact.
To switch the speed dial function on, select MenuSettingsCall settingsSpeed dialingOn.
To make a call using speed dialing, in the standby mode, press and hold the desired number key.
DRAFT
© 2008 Nokia. All rights reserved.14
4. Write text
Text modes
To enter text (for example, when writing messages) you can use traditional or predictive text input.
When you write text, press and hold Options to toggle between traditional text input, indicated by languages are supported by predictive text input.
The character cases are indicated by press #. To change from the letter to number mode, indicated by
hold #, and select Number mode. To change from the number to the letter mode, press and hold #.
To set the writing language, select OptionsWriting language.
Traditional text input
Press a number key, 2 to 9, repeatedly until the desired character appears. The available characters depend on the selected writing language.
If the next letter you want is located on the same key as the present one, wait until the cursor appears and enter the letter.
To access the most common punctuation marks and special characters, repeatedly press the number key 1 or press * to select a special character.
Predictive text input
Predictive text input is based on a built-in dictionary to which you can also add new words.
1. Start writing a word, using the keys 2 to 9. Press each key only once for one letter.
2. To confirm a word, scroll right or add a space.
DRAFT
, and predictive text input, indicated by . Not all
, , and . To change the character case,
, press and
© 2008 Nokia. All rights reserved. 15
Loading...
+ 35 hidden pages
