Nokia E52 User Guide
Cyan
Magenta
Yellow
Black
2222222
Issue 1
Cyan
Magenta
Yellow
Black
Contents
Cyan
Magenta
Yellow
Black
Safety...................................................................5
About your device......................................................................5
Network services.......................................................................6
Find help...............................................................7
Support.......................................................................................7
Keep your device software up to date.....................................7
In-device help.............................................................................9
Extended user guide..................................................................9
Get started............................................................9
SIM card, battery, charging, memory card............................10
Keys and parts..........................................................................12
First start-up.............................................................................14
Lock the keys............................................................................15
Accessories...............................................................................15
Volume control........................................................................16
Home screen............................................................................16
Transfer content from another device..................................16
Set up your e-mail...................................................................17
Antennas...................................................................................18
Nokia PC Suite..........................................................................18
Access codes.............................................................................19
Tips for efficient use................................................................19
Visit Ovi by Nokia.....................................................................20
Nokia E52 – The basics .......................................20
Phone setup.............................................................................20
Settings wizard........................................................................20
Menu.........................................................................................21
Display indicators....................................................................21
Write text.................................................................................23
Search.......................................................................................24
Common actions in several applications...............................24
Free memory............................................................................25
Personalisation..................................................25
Profiles .....................................................................................25
Select ringing tones.................................................................26
Customise profiles...................................................................26
Personalise the home screen.................................................27
Change the display theme......................................................27
Change audio themes.............................................................28
New from Nokia Eseries.....................................28
Key features.............................................................................28
Home screen............................................................................29
One-touch keys........................................................................30
Turn to silence calls or alarms................................................31
Calendar....................................................................................31
Contacts....................................................................................33
Multitasking.............................................................................35
Messaging..........................................................35
Nokia Messaging......................................................................36
E-mail........................................................................................36
Cyan
Magenta
Yellow
Black
Write and send messages.......................................................39
Cyan
Magenta
Yellow
Black
Phone.................................................................40
Voice calls.................................................................................41
Voice mail ................................................................................42
Video calls.................................................................................42
Video sharing...........................................................................43
Internet calls............................................................................45
Voice functions........................................................................46
Internet..............................................................46
Browser....................................................................................47
Browse the intranet ...............................................................51
Ovi Store...................................................................................51
Connect your computer to web..............................................51
Travelling...........................................................52
Positioning (GPS).....................................................................52
Maps..........................................................................................54
Nokia Office Tools..............................................59
Active notes..............................................................................59
Calculator..................................................................................59
File manager............................................................................60
Quickoffice................................................................................61
Converter..................................................................................61
Zip manager.............................................................................62
PDF reader................................................................................62
Printing.....................................................................................62
Clock..........................................................................................62
Dictionary.................................................................................63
Media..................................................................64
Camera......................................................................................64
Gallery.......................................................................................65
Photos.......................................................................................66
Share online.............................................................................67
Nokia Video Centre..................................................................69
Music player..............................................................................71
Recorder...................................................................................71
Flash player..............................................................................72
FM radio....................................................................................72
Nokia Internet Radio...............................................................73
Connectivity.......................................................74
Fast packet data.......................................................................74
Data cable.................................................................................74
Bluetooth..................................................................................75
Wireless LAN ............................................................................78
Connection manager...............................................................80
Security and data management.........................80
Lock the device........................................................................81
Memory card security..............................................................81
Encryption................................................................................81
Certificate manager.................................................................82
Application manager...............................................................83
Sync...........................................................................................85
Mobile VPN...............................................................................86
Settings..............................................................87
General settings.......................................................................87
Telephone settings..................................................................91
Connection settings.................................................................92
Cyan
Magenta
Yellow
Black
Application settings................................................................97
Cyan
Magenta
Yellow
Black
Nokia original accessories.................................97
Practical rules about accessories...........................................98
Battery......................................................................................98
Green tips...........................................................99
Save energy..............................................................................99
Recycle......................................................................................99
Product and safety information.........................99
Index................................................................112
Cyan
Magenta
Yellow
Black
Safety
Cyan
Magenta
Yellow
Black
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for further
information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when it may cause interference
or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to
operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel, chemicals,
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this
product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
www.nokia.com/support
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for
use on the UMTS 850 and 2100 MHz networks, and GSM 850,
900, 1800, and 1900 MHz networks. Contact your service
provider for more information about networks.
Your device supports several connectivity methods and like
computers may be exposed to viruses and other harmful
content. Exercise caution with messages, connectivity
requests, browsing, and downloads. Only install and use
services and software from trustworthy sources that offer
adequate security and protection, such as applications that
are Symbian Signed or have passed the Java Verified™ testing.
Consider installing antivirus and other security software on
your device and any connected computer.
Your device may have preinstalled bookmarks and links for
third-party internet sites and may allow you to access thirdparty sites. These are not affiliated with Nokia, and Nokia
does not endorse or assume liability for them. If you access
such sites, take precautions for security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do not
Cyan
Magenta
Yellow
Black
switch the device on when wireless device use may cause
Cyan
Magenta
Yellow
Black
interference or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some images,
music, and other content from being copied, modified, or
transferred.
Make back-up copies or keep a written record of all important
information stored in your device.
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible
products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about
your device.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make specific
arrangements with your service provider to use them.
Network services involve transmission of data. Check with
your service provider for details about fees in your home
network and when roaming on other networks. Your service
provider can explain what charges will apply. Some networks
may have limitations that affect how you can use some
features of this device requiring network support such as
support for specif ic technologies like WAP 2.0 protocols (HTTP
and SSL) that run on TCP/IP protocols and languagedependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu names,
menu order, and icons.
Cyan
Magenta
Yellow
www.nokia.com/support
Black
Find help
Cyan
Magenta
Yellow
Black
Support
When you want to learn more about how to use your product
or you are unsure how your device should function, go to
www.nokia.com/support, or using a mobile device,
nokia.mobi/support. You can also select Menu > Help >
Help in your device.
If this does not resolve your issue, do one of the following:
• Switch off the device, and remove the battery. After about
a minute, replace the battery, and switch on the device.
• Restore the original factory settings.
• Update your device software.
If your issue remains unsolved, contact Nokia for repair
options. Go to . Before sending your device for repair, always
back up the data in your device.
www.nokia.com/support
Keep your device
software up to date
About device software and
application updates
With device software updates and application updates, you
can get new features and enhanced functions for your device.
Updating the software may also improve your device
performance.
Cyan
Magenta
Yellow
Black
It is recommended that you
Cyan
Magenta
Yellow
Black
back up your personal data
before updating your device
software.
Downloading software upd ates may involve the transmission
of large amounts of data (network service).
Make sure that the device battery has enough power, or
connect the charger before starting the update.
Warning: If you install
a software update, you
cannot use the device, even
to make emergency calls,
until the installation is
completed and the device is
restarted. Be sure to back up
data before accepting
installation of an update.
Downloading software
updates may involve the
transmission of large
amounts of data (network service).
Make sure that the device battery has enough power, or
connect the charger before starting the update.
After you update your device software or applications, the
instructions in the user guide may no longer be up to date.
Software updates over the air
Select Menu > Ctrl. panel > Phone > SW update.
With Software update (network service), you can check if
there are updates available for your device software or
applications, and download them to your device.
Warning: If you install a software update, you cannot
use the device, even to make emergency calls, until the
installation is completed and the device is restarted. Be sure
to back up data before accepting installation of an update.
After updating your device software or applications using
Software update, the instructions related to the updated
applications in the user guide or the helps may no longer be
up to date.
Select Options and from the following:
• Start update — Download the available updates. To
unmark specific updates that you do not want to
download, select the updates from the list.
• Update via PC — Update your device using a PC. This
option replaces the Start update option when updates are
only available using the Nokia Software Updater PC
application.
• View details — View information on an update.
• View update history — View the status of previous
updates.
• Settings — Change the setting s, such as the default access
point used for downloading updates.
• Disclaimer — View the Nokia licence agreement.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
Update software using your PC
Cyan
Magenta
Yellow
Black
Nokia Software Updater is a PC application that enables you
to update your device software. To update your device
software, you need a compatible PC, broadband internet
access, and a compatible USB data cable to connect your
device to the PC.
To get more information and to download the Nokia
Software Updater application, go to .
In-device help
Your device contains instructions to help to use the
applications in your device.
To open help texts from the main menu, select Menu >
Help > Help and the application for which you want to read
instructions.
When an application is open, to access the help text for the
current view, select Options > Help.
Get started
Your Nokia E52 is a business device that adapts to your free
time as well.
Read these first pages to get started, then use the rest of the
guide to explore what new features Nokia E52 brings to you.
When you are reading the instructions, to change the size of
the help text, select Options > Decrease font size or
Increase font size.
You may find links to related topics at the end of the help text.
If you select an underlined word, a short explanation is
displayed. Help texts use the following indicators:
a related help topic.
discussed.
When you are reading the instructions, to switch between
help texts and the application that is open in the background,
select Options > Show open apps. and the desired
application.
Link to the application being
Link to
Extended user guide
For more information on applications or functions in your
device, see the extended version of this user guide, which is
available on the product support pages of the Nokia website.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
SIM card, battery,
Cyan
Magenta
Yellow
Black
charging, memory card
Put the pieces together, and get started with your Nokia
E52.
Insert the SIM card and battery
1. To open the back cover of the device, with the back facing
you, unlock the back cover release latch, and lift the back
cover.
3. Insert the SIM card. Ensure the contact area on the card is
facing the connectors on the device and that the bevelled
corner is facing the bottom of the device.
4. Align the contacts of the battery with the corresponding
connectors on the battery compartment, and insert the
battery in the direction of the arrow.
2. If the battery is inserted, lift the battery in the direction
of the arrow to remove it.
Cyan
Magenta
5. To replace the back cover, direct the top locking catches
toward their slots, and press down until the cover locks
into place.
www.nokia.com/support
Yellow
Black
Charge the battery
Cyan
Magenta
Yellow
Black
Your battery has been partially charged at the factory. If the
device indicates a low charge, do the following:
1. Connect the charger to a wall outlet.
2. Connect the charger plug to the USB port in the device.
3. When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of
time, and you can use the device while it is charging. If the
battery is completely discharged, it may take several minutes
before the charging indicator appears on the display or
before any calls can be made.
Charging with the USB data cable
Charging with the USB data cable is slower than charging with
the charger. Charging with the USB data cable may not work
if you use a USB hub. USB hubs may be incompatible for
charging a USB device.
Charging with the USB data cable may take a long time if the
battery is completely discharged.
When the USB data cable is connected, you can transfer data
at the same time as charging.
1. Connect a compatible USB device to your device using a
compatible USB data cable.
Depending on the type of the device that is used for
charging, it may take a while for charging to start.
2. If the device is switched on, select from the available USB
modes.
Insert the memory card
Use a memory card to save the memory on your device. You
ca n a ls o bac k up i n fo rm at io n f ro m y ou r d ev ic e to th e m em or y
card.
Use only compatible microSD and microSDHC cards approved
by Nokia for use with this device. Nokia uses approved
industry standards for memory cards, but some brands may
not be fully compatible with this device. Incompatible cards
may damage the card and the device and corrupt data stored
on the card.
Keep all memory cards out of the reach of small
children.
Check the compatibility of a memory card with its
manufacturer or provider.
A compatible memory card may be included in the
sales package. The memory card may be already
inserted in the device. If not, do the following:
1. To prevent the battery from coming loose, place the
device so that the back cover is facing up.
2. Remove the back cover.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
3. Insert the memory card in the slot with the contact area
Cyan
Magenta
Yellow
Black
first. Ensure the contact area is facing the connectors on
the device.
4. Push the card in until it locks into place.
5. Replace the back cover.
Remove the memory card
Important: Do not remove the memory card during
an operation when the card is being accessed. Doing so may
damage the memory card and the device, and corrupt data
stored on the card.
1. Press the power key briefly, and select Remove memory
card.
2. To prevent the battery from coming loose, place the
device so that the back cover is facing up.
3. Remove the back cover.
4. Press the end of the memory card to release it from the
memory card slot, and remove the card.
5. Replace the back cover.
Keys and parts
Keys and parts
1 — Power key
2 — Light sensor
3 — Selection key. Press the selection key to perform the
function displayed above it.
4 — Home key
5 — Call key
6 — Calendar key
7 — Microphone
8 — E-mail key
9 — End key
Cyan
Magenta
Yellow
www.nokia.com/support
Black
10 — Backspace key. Press the key to delete items.
Cyan
Magenta
Yellow
Black
11 — Selection key
12 — Navi™ key; hereafter referred to as scroll key. Press the
scroll key to make a selection, or to scroll left, right, up, or
down on the display. Press and hold the scroll key to
accelerate the scrolling.
13 — Earpiece
14 — Secondary camera
15 — Headset connector
1 — Flash
2 — Main camera
3 — Loudspeaker
Keys and parts (sides)
1 — Micro USB connector
2 — Volume up/Zoom in key
3 — Mute key/Push to talk key
4 — Volume down/Zoom out key
5 — Capture key
The surface of this device is nickel-free.
During extended operation such as an active video call and
high speed data connection, the device may feel warm. In
most cases, this condition is normal. If you suspect the device
is not working properly, take it to the nearest authorised
service facility.
Keep your device away from magnets or magnetic fields.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
One-touch keys
Cyan
Magenta
Yellow
Black
With One-touch keys, you can access applications and tasks
quickly.
To change the assigned application or task, select Menu >
Ctrl. panel > Settings and General > Personalisation >
One-touch keys. Your service provider may have assigned
applications to the keys, in which case you cannot change
them.
1 — Home key
2 — E-mail key
3 — Calendar key
Key
Home key (1) Access the home
E-mail key (2) Open your default
Calendar key (3) Open the Calendar
Press quickly Press and hold
screen
mailbox
application
View the list of
active applications
Create a new email message
Create a new
meeting entry
First start-up
1. Press and hold the power key until you
feel the device vibrate.
2. If prompted, enter the PIN code or lock
code, and select OK.
3. When prompted, enter the country in
which you are located and the current
date and time. To find your country,
enter the first letters of the country
name. It is important to select the
correct country, because scheduled
calendar entries may change if you
change the country later and the new
country is located in a different time
zone.
4. The Phone setup application opens. To set up an
application, select Start. To bypass setting up
applications, select Skip repeatedly. To open the Phone
setup application later, select Menu > Help > Phone
setup.
To configure the various settings in your device, use the
wizards available in the home screen and the Settings wizard
application. When you switch the device on, it may recognise
the SIM card provider and configure some settings
automatically. You can also contact your service provider for
the correct settings.
You can switch the device on without inserting a SIM card.
The device starts up in the Offline profile, and you cannot use
the network-dependent phone functions.
Cyan
Magenta
Yellow
www.nokia.com/support
Black
To switch the device off, press and hold the power key.
Cyan
Magenta
Yellow
Black
Connect the headset
Lock the keys
When the device or keypad is locked, calls may be possible to
the official emergency number programmed into your
device.
The keypad of your device locks automatically to prevent
accidental keypresses.
To change the length of time after which the keypad is locked,
select Menu > Ctrl. panel > Settings and General >
Security > Phone and SIM card > Keypad autolock
period.
To lock the keys manually in the home
screen, press the left selection key and
then the right selection key.
To lock the keys manually in the menu
or in an open application, press the
power key briefly, and select Lock
keypad.
To unlock the keys, press the left selection key and then the
right selection key.
Accessories
You can connect your device to a range of compatible
accessories. Check the availability of the approved
accessories with your dealer.
www.nokia.com/support
Warning: When you use the headset, your ability to
hear outside sounds may be affected. Do not use the headset
where it can endanger your safety.
Connect the compatible headset to the headset connector of
your device.
Cyan
Magenta
Yellow
Black
Attach a wrist strap
Cyan
Magenta
Yellow
Black
Thread the wrist strap, and tighten it.
Volume control
To adjust the earpiece volume during a phone call or the
volume of the media applications, use the volume keys.
Home screen
In the home screen, you can quickly access your most
frequently used applications, and view at a glance if you have
missed calls or new messages.
Whenever you see the
available actions. To close the list, scroll left.
icon, scroll right to access a list of
The home screen consists of the
following:
1. Application shortcuts. To
access an application, select
the shortcut of the application.
2. Information area. To check an
item displayed in the
information area, select the
item.
3. Notification area. To view the
notifications, scroll to a box. A
box is only visible if there are
items in it.
You can define two separate home screens for different
purposes, for example, one screen to show your business email and notifications, and another to show your personal email. This way, you do not have to see business-related
messages outside office hours.
To switch between the home screens, select
To define which items and shortcuts you want in the home
screen, and to set the appearance of the home screen, select
Menu > Ctrl. panel and Modes.
.
Transfer content from
another device
Select Menu > Ctrl. panel > Switch.
Cyan
Magenta
Yellow
www.nokia.com/support
Black
With the Switch application, you can transfer content, such
Cyan
Magenta
Yellow
Black
as contacts, between two compatible Nokia devices.
The type of content that can be transferred depends on the
model of the device from which you want to transfer content.
If the other device supports synchronisation, you can also
synchronise data between the other device and your Nokia
E52. Your device notifies you if the other device is not
compatible.
If the other device cannot be switched on without a SIM card,
you can insert your SIM card in it. When the Nokia E52 is
switched on without a SIM card, the Offline profile is
automatically activated.
Transfer content
To retrieve data from your other device for the first time:
1. Select the connection type you want to use to transfer the
data. Both devices must support the selected connection
type.
2. Select the device from which you want to trans fer content.
You are asked to enter a code on your Nokia E52. Enter a
code (1-16 digits), and select OK. Enter the same code on
the other device, and select OK. The devices are now
paired.
For some device models, the Switch application is sent to
the other device as a message. To install the Switch
application on the other device, open the message, and
follow the instructions on the display.
3. From your Nokia E52, select the content you want to
transfer from the other device.
Content is transferred from the memory of the other device
to the corresponding location in your Nokia E52.
Transfer time depends on the amount of data to be
transferred. You can cancel the transfer and continue later.
The synchronisation is two-way, and the data in both devices
is the same. If an item is deleted from either device, it is
deleted from the other device when synchronising; you
cannot restore deleted items by synchronising.
To view the log of the last transfer, select a shortcut in the
main view and Options > View log.
Set up your e-mail
Your Nokia Eseries device works the same hours as you, and
at the same speed. Keep your e-mail, contacts, and calendar
synchronised - quickly and conveniently with high speed
connections.
When setting up your e-mail, you may be prompted for the
following information: user name, e-mail type, incoming
mail server, incoming mail server port, outgoing mail server,
outgoing mail server port, password, or access point.
With the E-mail wizard, you can set up business e-mail
accounts, such as Microsoft Exchange, or internet e-mail
accounts, such as Google's e-mail services. The wizard
supports POP/IMAP, and ActiveSync protocols.
If you are setting up your business e-mail, ask your company
IT department for details. If you are setting up your internet
e-mail, see your e-mail service provider’s website for details.
To start the E-mail wizard:
1. In the home screen, scroll to the E-mail wizard.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
2. Enter your e-mail address and password. If the wizard is
Cyan
Magenta
Yellow
Black
not able to configure your e-mail settings automatically,
select your e-mail account type, and enter the related
settings.
Tip: If you have not configured your mailbox, press the
e-mail key to start the E-mail wizard.
If your device contains additional e-mail clients, those are
offered to you when you start the E-mail wizard.
the applications. Nokia PC Suite may be included on a memory
card if one is provided with your device.
You can use Nokia PC Suite to synchronise contacts, calendar,
and to-do and other notes between your device and a
compatible PC application, such as Microsoft Outlook or Lotus
Notes. You can also use Nokia PC Suite to transfer bookmarks
between your device and compatible browsers, and transfer
images and video clips between your device and compatible
PCs.
Antennas
Your device may have internal and external antennas. Avoid
touching the antenna area unnecessarily while the antenna
is transmitting or receiving. Contact with antennas affects the
communication quality and may cause a higher power level
during operation and may reduce the battery life.
Nokia PC Suite
Nokia PC Suite is a set of applications that you can install to
a compatible PC. Nokia PC Suite groups all available
applications in a launcher window from which you can run
Note: Pay attention to synchronisation settings. Data
deletion as part of normal synchronisation process is
determined by the settings selected.
To use Nokia PC Suite, you need a PC that runs Microsoft
Windows XP (SP2) or Windows Vista, and is compatible with
a USB data cable or with Bluetooth connectivity.
Nokia PC Suite does not work with Macintosh.
For further information on Nokia PC Suite, see its help
function or the Nokia website.
To install Nokia PC Suite:
1. Ensure the memory card is inserted in your Nokia E52.
2. Connect the USB cable. Your PC recognises the new device
and installs the necessary drivers. This can take several
minutes to complete.
3. Select Mass storage as the USB connection mode in your
device. Your device is displayed in Windows file browser
as a Removable Disk.
4. Open the root of the memory card drive with the Windows
file browser, and select the PC Suite installation.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
5. The installation is started. Follow the displayed
Cyan
Magenta
Yellow
Black
instructions.
Tip: To update Nokia PC Suite, or if you have problems
when installing Nokia PC Suite from the memory card,
copy the installation file to your PC, and start the
installation from your PC.
Access codes
If you forget any of the access codes, contact your service
provider.
• Personal identification number (PIN) code — This code
protects your SIM card against unauthorised use. The PIN
code (4 - 8 digits) is usually supplied with the SIM card.
After three consecutive incorrect PIN code entries, the
code is blocked, and you need the PUK code to unblock it.
• UPIN code — This code may be supplied with the USIM
card. The USIM card is an enhanced version of the SIM card
and is supported by 3G mobile phones.
• PIN2 code — This code (4 - 8 digits) is supplied with some
SIM cards, and is required to access some functions in your
device.
• Lock code (also known as security code) — The lock code
helps you to protect your device against unauthorised use.
The preset code is 12345. You can create and change the
code, and set the device to request the code. Keep the new
code secret and in a safe place separate from your device.
If you forget the code and your device is locked, your
device will require service. Additional charges may apply,
and all the personal data in your device may be deleted.
For more information, contact a Nokia Care point or your
device dealer.
• Personal Unblocking Key (PUK) code and PUK2
code — These codes (8 digits) are required to change a
blocked PIN code or PIN2 code, respectively. If the codes
are not supplied with the SIM card, contact the network
service provider whose SIM card is in your device.
• UPUK code — This code (8 digits) is required to change a
blocked UPIN code. If the code is not supplied with the
USIM card, contact the network service provider whose
USIM card is in your device.
• International Mobile Equipment Identity (IMEI)
number — This number (15 or 17 digits) is used to identify
valid devices on the GSM network. Devices that are, for
example, stolen, can be blocked from accessing the
network. The IMEI number for your device can be found
under the battery.
Tips for efficient use
To switch profiles, press the power key briefly.
To switch to the Silent profile, press and hold #.
To search for items in your device or on the internet (network
service), select Menu > Applications > Search.
When browsing web pages with the Web browser application
or maps in the Maps application, press * to zoom in and # to
zoom out.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
Visit Ovi by Nokia
Cyan
Magenta
Yellow
Black
With Ovi by Nokia, you can find new places and services,
and stay in touch with your friends. You can do, for example,
the following:
• Create a mail account
• Plan trips and view locations on a map
• Download games, applications, videos, and ringing tones
to your device
Nokia E52 – The basics
• Purchase music
Some downloadable items are free of charge, others you may
need to pay for.
The available services may vary by country or region, and not
all languages are supported.
To access Nokia's Ovi services, go to www.ovi.com, and
register your own Nokia account.
For more information, go to www.ovi.com/support.
Phone setup
When you switch on your device for the first time, the Phone
setup application opens.
To access the Phone setup application later, select Menu >
Help > Phone setup.
To set up the device connections, select Sett. wizard.
To transfer data to your device from a compatible Nokia
device, select Switch.
The available options may vary.
Cyan
Magenta
Settings wizard
Select Menu > Ctrl. panel > Sett. wizard.
Us e Se ttin gs wi zar d to defi ne e-mail and connection settings.
The availability of the items in Settings wizard depends on
the features of the device, SIM card, service provider, and the
data in the Settings wizard database.
To start Settings wizard, select Start.
To get the best results when using the settings wizard, keep
your SIM card inserted in the device. If the SIM card is not
inserted, follow the instructions on the display.
Select from the following:
www.nokia.com/support
Yellow
Black
• Operator — Define the operator-specific settings, such as
Cyan
Magenta
Yellow
Black
MMS, internet, WAP, and streaming settings.
• E-mail setup — Configure a POP, IMAP, or Mail for
Exchange account.
• Push to talk — Configure push to talk settings.
• Video sharing — Configure video sharing settings.
The settings available for editing may vary.
Menu
Select Menu.
The menu is a starting point from
which you can open all
applications in the device or on a
memory card.
The menu contains applications
and folders, which are groups of
similar applications. All
applications you install in the
device yourself are by default
saved in the Applications folder.
To open an application, select the
application, that is, scroll to it, and press the scroll key.
To switch between the open applications, press and hold the
home key, and select an application. Leaving applications
running in the background increases the demand on battery
power and reduces the battery life.
Select Options and from the following:
• Change Menu view — View applications in a list or a grid.
• Memory details — View the memory consumption of
different applications and data stored on the device or
memory card and to check the amount of free memory.
• New folder — Create a new folder.
• Rename — Rename a new folder.
• Move — Rearrange the folder. Scroll to the application
you want to move, and select Move. A check mark is placed
beside the application. Scroll to a new location, and select
OK.
• Move to folder — Move an application to a different
folder. Scroll to the application you want to move, and
select Move to folder, the new folder, and OK.
• Download applications — Download applications from
the web.
Display indicators
The device is being used in a UMTS network (network
service).
The battery charge level. The higher the bar, the
stronger the charge in the battery.
You have one or more unread messages in the Inbox
folder in Messaging.
You have received new e-mail in the remote
mailbox.
There are messages waiting to be sent in the Outbox
folder in Messaging.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
You have one or more missed phone calls.
Cyan
Magenta
Yellow
Black
The keys of the device are locked.
An alarm is active.
You have activated the Silent profile, and the device
does not ring for an incoming call or message.
Bluetooth connectivity is activated.
A Bluetooth connection is established. When the
indicator is blinking, your device is trying to connect
with another device.
A GPRS packet data connection is available (network
service).
indicates that the connection is on hold.
An EGPRS packet data connection is available
(network service).
is active.
A UMTS packet data connection is available (network
service).
indicates that the connection is on hold.
High-speed packet access (HSPA) is supported and
available (network service). The icon may vary
between regions.
active.
indicates that the connection is active.
indicates that the connection
indicates that the connection is on hold.
indicates that the connection is active.
indicates that the connection is
indicates that the connection is on hold.
You have set the device to scan for wireless LANs
(WLAN), and a WLAN is available.
A WLAN connection is active in a network that does
not have encryption.
A WLAN connection is active in a network that has
encryption.
Your device is connected to a computer with a USB
data cable.
The second phone line is being used (network
service).
All calls are forwarded to another number. If you
have two phone lines, a number indicates the active
line.
A headset is connected to the device.
A handsfree car kit is connected to the device.
A loopset is connected to the device.
A text phone is connected to the device.
Your device is synchronising.
You have an ongoing push to talk (PTT) connection.
Cyan
Magenta
Yellow
www.nokia.com/support
Black
Your push to talk connection is in do not disturb
Cyan
Magenta
Yellow
Black
mode, because the ringing type of your device is set
to Beep once or Silent, or you have an incoming or
ongoing phone call. In this mode, you cannot make
PTT calls.
Write text
The input methods provided in the device may vary according
to different sales markets.
Traditional text input
indicates traditional text input.
and indicate the uppercase and lowercase.
indicates the sentence case, that is, the first letter of
the sentence is written in uppercase and all the other letters
are automatically written in lowercase.
number mode.
To write text with the keypad, press a number key, 2-9,
repeatedly until the desired character is displayed. There are
more characters available for a number key than are printed
on the key. If the next letter is located on the same key as the
present one, wait until the cursor is displayed, and enter the
letter.
To insert a number, press and hold the number key.
To switch between the different character cases and modes,
press #.
indicates
To erase a character, press the backspace key. Press and hold
the backspace key to erase more than one character.
To enter the most common punctuation marks, press 1
repeatedly until the desired punctuation mark is displayed.
To add special characters, press and hold *.
To insert a space, press 0. To insert a line bre ak, pr ess 0 three
times.
Predictive text input
With predictive input, you can enter any letter with a single
keypress. Predictive text input is based on a built-in
dictionary.
To activate or deactivate predictive text input, select
Options > Input options. The indicator
When you start writing a word, your device suggests possible
words. When the correct word is found, press the space key
(0) to confirm it and to add a space. While writing, you can
scroll down to access a list of suggested words. If the desired
word is on the list, select the word. If the ? character is
displayed after the word, the word you intended to write is
not in the dictionary. To add a word to the dictionary, select
Spell, enter the word using traditional text input, and select
OK. When the dictionary is full, the new word replaces the
oldest added word.
To deactivate automatic word completion, select Options >
Input options > Settings.
To change the writing language, select Options > Input
options > Writing language.
is displayed.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
Search
Cyan
Magenta
Yellow
Black
Common actions in
About Search
Select Menu > Applications > Search.
Search (network service) enables you to use various internet-
based search services to find, for example, websites and
images. The content and availability of the services may vary.
Start a search
Select Menu > Applications > Search.
To search the contents of your mobile device, enter search
terms in the search field, or browse the content categories.
While you enter the search terms, the results are organised
into categories.
To search for web pages on the internet, select Search the
Internet or a search provider, and enter your search terms
in the search field. The search provider you selected is set as
your default internet search provider.
To change the default search provider, select Options >
Settings > Search services.
To change the country or region setting to find more search
providers, select Options > Settings > Country or
region.
several applications
You can find the following actions in several applications:
To change the profile, or switch off or lock the device, press
the power key briefly.
If an application consists of several
tabs (see figure), open a tab by
scrolling right or left.
To save the settings that you have
configured in an application,
select Back.
To save a file, select Options > Save. There are different
saving options depending on the application you use.
To send a file, select Options > Send. You can send a file in
an e-mail or multimedia message, or using different
connectivity methods.
To copy, press and hold the shift key, and select the text with
the scroll key. Press and hold the shift key, and select Copy.
To paste, scroll to where you want to paste the text, press
and hold the shift key, and select Paste. This method may not
work in applications that have their own copy and paste
commands.
To select different items, such as messages, files, or contacts,
scroll to the item you want to select. Select Options > Mark/
Unmark > Mark to select one item or Options > Mark/
Unmark > Mark all to select all items.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
Tip: To select almost all items, first select Options >
Cyan
Magenta
Yellow
Black
Mark/Unmark > Mark all, then select the items you
do not want, and Options > Mark/Unmark >
Unmark.
To select an object (for example, an attachment in a
document) scroll to the object so that square markers appear
on each side of the object.
Free memory
To view how much memory is available for different data
types, select Menu > Office > File mgr..
Many features of the device use memory to store data. The
device notifies you if available memory is low.
To free memory, transfer data to an alternative memory (if
available) or compatible computer.
Personalisation
To remove data you no longer need, use File manager or the
respective application. You can remove the following:
• Messages in the folders in Messaging and retrieved e-mail
messages from the mailbox
• Saved web pages
• Contact information
• Calendar notes
• Applications shown in Application manager that you do
not need
• Installation files (with .sis or .sisx file extensions) of
installed applications. Back up the installation files to a
compatible computer.
• Images and video clips in Photos. Back up the files to a
compatible computer using Nokia PC Suite.
You can personalise your device by, for example, adjusting
the various tones, background images, and screen savers.
Profiles
Select Menu > Ctrl. panel > Profiles.
www.nokia.com/support
Cyan
Magenta
You can adjust and customise the ringing tones, alert tones,
and other device tones for different events, environments, or
caller groups. The active profile is shown at the top of the
display in the home screen. However, if the active profile is
General, only today's date is shown.
To create a new profile, select Options > Create new, and
define the settings.
Yellow
Black
To customise a profile, select a profile and Options >
Cyan
Magenta
Yellow
Black
Personalise.
To activate a profile, select a profile and Options >
Activate.
To set the profile to be active until a certain time within the
next 24 hours, scroll to the profile, select Options >
Timed, and set the time. When the time expires, the profile
changes back to the previously active non-timed profile.
When the profile is timed,
The Offline profile cannot be timed.
To delete a profile that you created, select Options > Delete
profile. You cannot delete the predefined profiles.
When the Offline profile is activated, your connection to the
cellular network is closed. All radio frequency signals
between the device and the cellular network are prevented.
If you try to send a message, it is placed in the Outbox folder,
and is sent only when another profile is activated.
You can also use your device without a SIM card. If you remove
the SIM card, the Offline profile is activated.
Important: In the Offline profile you cannot make or
receive any calls, or use other features that require cellular
network coverage. Calls may still be possible to the official
emergency number programmed into your device. To make
calls, you must first activate the phone function by changing
profiles. If the device has been locked, enter the lock code.
When you use the Offline profile, you can still use a wireless
LAN (WLAN), for example, to read your mail or browse the
internet. You can also use Bluetooth connectivity. Remember
is displayed in the home screen.
to comply with any applicable safety requirements when you
establish and use WLAN or Bluetooth connections.
Select ringing tones
To set a ringing tone for a profile, select Options >
Personalise > Ringing tone. Select a ringing tone from the
list, or select Download sounds to open a bookmark folder
containing a list of bookmarks for downloading tones using
the browser. Any downloaded tones are saved to Gallery.
To play the ringing tone for a selected contact group only,
select Options > Personalise > Alert for, and select the
desired group. Phone calls coming from outside that group
have a silent alert.
To change the message tone, select Options >
Personalise > Message alert tone.
Customise profiles
Select Menu > Ctrl. panel > Profiles.
Select Options > Personalise and from the following:
• Ringing tone — Select a ringing tone from the list, or
select Download sounds to open a bookmark folder
containing a list of bookmarks for downloading tones
using the browser. If you have two alternate phone lines
in use, you can specify a ringing tone for each line.
• Video call tone — Select a ringing tone for video calls.
• Say caller's name — When you select this option and
someone from your contacts list calls you, the device
Cyan
Magenta
Yellow
www.nokia.com/support
Black
sounds a ringing tone that is a combination of the spoken
Cyan
Magenta
Yellow
Black
name of the contact and the selected ringing tone.
• Ringing type — Select how you want the ringing tone to
alert.
• Ringing volume — Select the volume level of the ringing
tone.
• Message alert tone — Select a tone for received text
messages.
• E-mail alert tone — Select a tone for received e-mail
messages.
• Vibrating alert — Set the device to vibrate when you
receive a call or message.
• Keypad tones — Select the volume level of the keypad
tones.
• Warning tones — Deactivate the warning tones. This
setting also affects the tones of some games and Java™
applications.
• Alert for — Set the device to ring only upon calls from
phone numbers that belong to a selected contact group.
Phone calls coming from outside that group have a silent
alert.
• PTT call alert tone — Select a ringing tone for PTT calls.
• Push to talk status — Set the PTT status to each profile.
• Profile name — You can give a name to a new profile or
rename an existing profile. The General and Offline profiles
cannot be renamed.
Personalise the home
screen
Select Menu > Ctrl. panel > Modes.
To change the name of the current home screen, select
Options > Rename mode.
To select which applications and notifications you want to
see in the home screen, select Home screen applications.
To change the theme of the home screen currently in use,
select General theme.
To change the background image of the home screen
currently in use, select Wallpaper.
To change from one home screen to another, scroll to Current
mode, and select Options > Change.
Change the display
theme
Select Menu > Ctrl. panel > Themes.
Select from the following:
• General — Change the theme used in all applications.
• Menu view — Change the theme used in the main menu.
• Standby — Change the theme used in the home screen.
• Wallpaper — Change the background image of the home
screen.
• Power saver — Select an animation for the power saver.
www.nokia.com/support
Cyan
Magenta
Yellow
Black
• Call image — Change the image displayed during calls.
Cyan
Magenta
Yellow
Black
To activate or deactivate the theme effects, select General >
Options > Theme effects.
Change audio themes
You can set sounds for various device events. The sounds can
be tones, speech, or a combination of both.
Select Menu > Ctrl. panel > Themes and Audio themes.
To change the current audio theme, select Active audio
theme.
To add 3-D effects to the audio theme, select Options > 3-
D ringing tones.
To create a new audio theme, select Options > Save
theme.
New from Nokia Eseries
To set a sound for an event, select an event group, such as
Messaging events. Select the desired event and from the
following:
• Silent — Deactivate the sound of the device event.
• Tone — Set a tone as the sound for the device event.
• Speech — Set a synthesised voice tag as the sound for the
device event. Enter the desired text, and select OK.
Select an event group, such as Messaging events. Select the
desired event, Options, and from the following:
• Play — Play the sound before activating it.
• Activate sounds — Activate all the sounds in the event
group.
• Deactivate sounds — Deactivate all the sounds in the
event group.
Your new Nokia Eseries device contains new versions of the
Calendar, Contacts, and E-mail applications, as well as a new
home screen.
Cyan
Magenta
Key features
Your new Nokia E52 helps you manage your business and
personal information. Some of the key features are
highlighted here:
Read and reply to your e-mail while on the move.
www.nokia.com/support
Yellow
Black
Stay up-to-date and plan your meetings with the
Cyan
Magenta
Yellow
Black
Calendar application.
Manage your business partners and free time
friends with the Contacts application.
Connect to a wireless LAN (WLAN) with the WLAN
wizard application.
Work with documents, spreadsheets, and
presentations with the Quickoffice application.
Find points of interest with the Maps application.
Switch from business to personal mode.
Edit the appearance and setup of your home
screen with the Modes application.
Browse your company intranet with the Intranet
application.
Move your contact and calendar information from
a previous device to your Nokia E52 with the
Switch application.
Check the available updates for applications and
download them to your device with the Software
update application.
Encrypt your device or memory card to prevent
outsiders from accessing your important
information.
Home screen
In the home screen, you can quickly access your most
frequently used features and applications, and view at a
glance if you have missed calls or new messages.
Home screen
In the home screen, you can quickly access your most
frequently used applications, and view at a glance if you have
missed calls or new messages.
Whenever you see the
available actions. To close the list, scroll left.
icon, scroll right to access a list of
www.nokia.com/support
Cyan
Magenta
Yellow
Black
The home screen consists of the
Cyan
Magenta
Yellow
Black
following:
1. Application shortcuts. To
access an application, select
the shortcut of the application.
2. Information area. To check an
item displayed in the
information area, select the
item.
3. Notification area. To view the
notifications, scroll to a box. A
box is only visible if there are
items in it.
You can define two separate home screens for different
purposes, for example, one screen to show your business email and notifications, and another to show your personal email. This way, you do not have to see business-related
messages outside office hours.
To switch between the home screens, select
To define which items and shortcuts you want in the home
screen, and to set the appearance of the home screen, select
Menu > Ctrl. panel and Modes.
.
Work on the home screen
To search for contacts in the home screen, start entering the
contact's name. When entering the characters, press each key
once. For example, to enter "Eric", press 3742. The device
suggests matching contacts. To switch between the
alphabetic and number modes, select Options > Alpha
mode or Number mode. Select the desired contact from the
list of proposed matches. This feature may not be available
in all languages.
To call the contact, press the call key.
To disable the contact search, select Options > Contact
search off.
To check your received messages, select the message box in
the notification area. To read a message, select the message.
To access other tasks, scroll right.
To view your missed calls, select the calls box in the
notification area. To return a call, select a call, and press the
call key. To send a text message to a caller, select a call, scroll
right, and select Send message from the list of available
actions.
To listen to your voice mail, select the voice mail box in the
notification area. Select the desired voice mailbox, and press
the call key.
One-touch keys
With the One-touch keys, you can access applications and
tasks quickly. Each key has been assigned an application or a
task. To change these, select Menu > Ctrl. panel >
Settings and General > Personalisation > One-touch
keys. Your service provider may have assigned applications
to the keys, in which case you cannot change them.
Cyan
Magenta
Yellow
www.nokia.com/support
Black
Loading...
