Nokia 5630 User Guide
DRAF
T
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-431 product
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and Nokia Care are trademarks or registered trademarks of Nokia
Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
This product includes software licensed from Symbian Software Ltd (c) 1998-2009.
Symbian and Symbian OS are trademarks of Symbian Ltd.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2009. Tegic
Communications, Inc. All rights reserved.
T
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems,
Inc.
Portions of the Nokia Maps software are © 1996-2009 The FreeType Project. All rights reserved
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance with the
MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use
in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be
implied for any other use. Additional information, including that related to promotional, internal, and
commercial uses, may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA
OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS ". EX CEPT AS REQUI RED B Y APP LICABLE LAW,
NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE
RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may vary by region.
Please check with your Nokia dealer for details, and availability of language options.
Export controls
DRAF
.
This device may contain commodities, technology or software subject to export laws and regulations from
the US and other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to
receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such
interference cannot be eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Any changes or modifications not expressly
approved by Nokia could void the user's authority to operate this equipment.
NO WARRANTY
The third-party applications provided with your device may have been created and may be
owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the
copyrights or intellectual property rights to the third-party applications. As such, Nokia does
not take any responsibility for end-user support, functionality of the applications, or the
information in the applications or these materials. Nokia does not provide any warranty for
the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED
AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR
ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRDPARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
T
DRAF
Contents
SAFETY.............................................. 6
Support ............................................. 8
Help ...................................................................... 8
Nokia support and contact information .... 8
1. Get started.................................... 9
Insert a (U)SIM card and battery ................. 9
Memory card...................................................... 9
Charge the battery ........................................ 10
Switch the device on and off..................... 11
Configuration settings ................................. 12
Transfer data................................................... 12
2. Your device ................................. 13
Keys and parts ................................................ 13
Standby mode and home screen ............... 14
Indicators ......................................................... 15
Power saver ..................................................... 16
Menu ................................................................. 16
Volume control............................................... 16
Keypad lock (keyguard)................................ 17
Access codes ................................................... 17
Download!........................................................ 18
Installed applications ................................... 18
Connect a compatible headset .................. 18
Connect a USB data cable .......................... 19
Energy efficiency ........................................... 19
Sustainable materials ................................... 19
Environmental software & services.......... 19
Recycling.......................................................... 19
3. Call functions ............................. 20
Make a voice call........................................... 20
Answer or reject a call ................................. 22
Video calls........................................................ 22
Call settings..................................................... 23
Video sharing .................................................. 24
Log ..................................................................... 26
4. Music .......................................... 26
Music player.................................................... 26
Music keys ....................................................... 28
DRAF
Music search.................................................... 28
Nokia Podcasting ........................................... 29
FM Radio........................................................... 31
5. Games ......................................... 32
6. Positioning ................................. 32
Position requests ............................................ 33
Landmarks ........................................................ 33
GPS data ........................................................... 33
7. Write text................................... 34
Traditional and predictive text input........ 34
Copy and delete text ..................................... 35
8. Messaging .................................. 35
Write and send messages ............................ 36
Inbox.................................................................. 36
Service messages............................................ 37
E-mail................................................................ 37
Mail for Exchange.......................................... 38
Outbox............................................................... 39
Message reader............................................... 39
View messages on the SIM card ................ 40
Cell broadcast ................................................. 40
Service commands ......................................... 40
Messaging settings ........................................ 40
9. Contacts ..................................... 41
Save and manage contact information ... 41
Contact groups ............................................... 41
Add a ringing tone......................................... 42
10. Gallery...................................... 42
Main view......................................................... 42
Images ............................................................... 42
Sounds............................................................... 43
Streaming links............................................... 44
Presentations................................................... 44
11. Home media ............................ 44
Home media settings .................................... 45
12. Camera..................................... 46
T
4
Full focus.......................................................... 46
Capture images .............................................. 47
Record videos.................................................. 49
Camera settings ............................................. 50
13. Media ....................................... 51
RealPlayer ........................................................ 51
Flash Player ..................................................... 51
Recorder ........................................................... 52
14. Internet .................................... 52
Browse the web.............................................. 52
Search ............................................................... 55
15. Personalisation ........................ 55
Themes.............................................................. 55
Profiles.............................................................. 55
16. Time management................... 56
Clock.................................................................. 56
Calendar ........................................................... 56
17. Office applications .................. 56
Active notes..................................................... 56
Notes................................................................. 57
Mobile dictionary........................................... 57
Adobe Reader.................................................. 57
Quickoffice ...................................................... 58
DRAF
18. Settings.................................... 58
Voice commands ............................................ 58
Phone settings ................................................ 59
Speech............................................................... 60
19. Data management................... 61
Install or remove applications.................... 61
File manager.................................................... 62
Licences............................................................. 63
Device manager .............................................. 64
20. Connectivity ............................ 65
Wireless LAN.................................................... 65
Data transfer ................................................... 65
PC Suite............................................................. 66
Bluetooth connectivity ................................. 66
Remote synchronisation............................... 68
Connection manager..................................... 68
21. Enhancements ......................... 68
22. Battery and charger information
Nokia battery authentication guidelines. 70
Care and maintenance................... 71
Additional safety information ...... 72
Index............................................... 76
T
.................................................... 69
5
SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal. Read the
complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it
may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
T
■ About your device
The wireless device described in this guide is approved for use on the GSM 850, 900, 1800,
and 1900 and UMTS 900 and 2100 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect local customs, privacy and
legitimate rights of others, including copyrights.
Copyright protection may prevent some images, music, and other content from being
copied, modified, or transferred.
Your device supports several methods of connectivity. Like computers, your device may be
exposed to viruses and other harmful content. Exercise caution with messages, connectivity
requests, browsing, and downloads. Only install and use services and other software from
trustworthy sources that offer adequate security and protection against harmful software,
such as applications that are Symbian Signed or have passed the Java Verified
6
DRAF
™ testing.
SAFETY
Consider installing antivirus and other security software on your device and any connected
computer.
Your device may have preinstalled bookmarks and links for third-party internet sites. You
may also access other third-party sites through your device. Third-party sites are not
affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose
to access such sites, you should take precautions for security or content.
Warning: To use any features in this device, other than the alarm clock, the device
must be switched on. Do not switch the device on when wireless device use may
cause interference or danger.
The office applications support common features of Microsoft Word, PowerPoint, and Excel
(Microsoft Office 2000, XP, and 2003). Not all file formats can be viewed or modified.
Remember to make back-up copies or keep a written record of all important information
stored in your device.
During extended operation, such as an active video call and high speed data connection, the
device may feel warm. In most cases, this condition is normal. If you suspect the device is
not working properly, take it to the nearest authorised service facility.
When connecting to any other device, read its user guide for detailed safety instructions. Do
not connect incompatible products.
T
■ Network services
To use the phone you must have service from a wireless service provider. Many of the
features require special network features. These features are not available on all networks;
other networks may require that you make specific arrangements with your service provider
before you can use the network services. Your service provider can give you instructions and
explain what charges will apply. Some networks may have limitations that affect how you
can use network services. For instance, some networks may not support all languagedependent characters and services.
Your service provider may have requested that certain features be disabled or not activated
in your device. If so, these features will not appear on your device menu. Your device may
also have a special configuration such as changes in menu names, menu order, and icons.
Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some
features of this device, such as web browsing, e-mail, push to talk, and multimedia
messaging, require network support for these technologies.
DRAF
■ Battery removing
Always switch the device off and disconnect the charger before removing the battery.
SAFETY
7
Support
■ Help
Your device has context-sensitive help. To access help when an application is
open, select Options > Help. To switch between help and the application that is
open in the background, select and hold , and select from the list of open
applications.
To open help from the main menu, select > Help > Help. Select an application
to view a list of help topics, and select the related help text. To open a keyword
list, select Options > Search.
■ Nokia support and contact information
Check www.nokia.com/support or your local Nokia website for the latest guides, additional
information, downloads, and services related to your Nokia product.
On the website, you can get information on the use of Nokia products and
services. If you need to contact customer service, check the list of local Nokia Care
contact centres at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia care point at www.nokia.com/
repair.
Software updates
Nokia may produce software updates that may offer new features, enhanced functions, or
improved performance. You may be able to request these updates through the Nokia
Software Updater PC application. To update the device software, you need the Nokia
Software Updater application and a compatible PC with Microsoft Windows 2000, XP or
Vista operating system, broadband internet access, and a compatible data cable to connect
your device to the PC.
To get more information and to download the Nokia Software Updater application, visit
www.nokia.com/softwareupdate or your local Nokia web site.
If software updates over the air are supported by your network, you may also be able to
request updates through the device. See ‘Update software,’ page 64.
Downloading software updates may involve the transmission of large amounts of data
through your service provider's network. Contact your service provider for information about
data transmission charges.
Make sure that the device battery has enough power, or connect the charger before starting
the update.
DRAF
T
8
Support
1. Get started
■ Insert a (U)SIM card and battery
This device uses BL-4CT batteries.
1. To open the back cover of the
device, with the back of the device
facing you slide the cover toward
the bottom of the device (1), and
remove it. To remove the battery,
lift it from the end (2).
2. Slide the (U)SIM card in the SIM
card holder (3).
Make sure that the gold-coloured
contact area on the card is facing
downward on the device, and the
bevelled corner is facing downwards.
3. Replace the battery (4). Replace the
back cover (5).
T
■ Memory card
Use only compatible microSD and microSDHC cards approved by Nokia for use
with this device. Nokia uses approved industry standards for memory cards, but
some brands may not be fully compatible with this device. Incompatible cards
may damage the card and the device and corrupt data stored on the card.
Insert a memory card
The memory card may be supplied with the device, and may already be inserted.
DRAF
Get started
9
1. Open the memory card slot door (1).
2. Place the memory card in the slot
with the gold-coloured area facing
down (2).
3. Push the card gently to lock it into
place. Close tight the slot door (3).
Remove a memory card
Important: Do not remove the
memory card in the middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may damage the memory card as
well as the device, and data stored on the card may be corrupted.
1. Press briefly the power key.
2. Scroll to Remove memory card, and select OK > Yes.
3. Open the memory card slot door.
4. Push the card gently to release it.
5. Pull the card out, and select OK.
6. Close the slot door.
T
■ Charge the battery
1. Connect the charger to the wall socket.
2. Connect the charger plug to the USB port
in the device.
If the battery is completely discharged, it
may take a few minutes before the charging
indicator appears on the display or before
any calls can be made. The charging indicator blinks until it is possible to make
calls, and after that it is continuously on until the battery is fully charged.
The charging time depends on the charger and the battery used.
DRAF
USB charging
You can use USB charging when a wall socket is not available. With USB charging,
you can also transfer data while charging the device. USB charging may be slower
than charging through a wall socket. Charging may not work if you use a USB hub.
USB hubs may be incompatible for charging a USB device.
10
Get started
1. Connect a compatible USB cable between a compatible USB device and your
device. Depending on the type of device that is used for charging, it may take a
while for charging to start.
2. If the device is switched on, you can select from the USB mode options on the
display of the device.
■ Switch the device on and off
Press and hold the power key.
If the device asks for a PIN code, enter the PIN code,
and select OK.
If the device asks for the lock code, enter the lock
code, and select OK. The factory setting for the lock
code is 12345.
For more information about access codes, see ‘Access
codes,’ p. 17.
To set the time zone, time, and date, select the
country you are presently in, then enter the local
time and date. See also ‘Clock,’ p. 56.
My Nokia
My Nokia is a free service that sends you tips, tricks, and support for your Nokia
device regularly as text messages. If My Nokia is available in your country and
supported by your service provider, your device invites you to join the My Nokia
service after you have set the time and the date.
Select the language for the service. If you change the language, the device
restarts. To sign-up to My Nokia , select Accept, and follow the instructions.
To sign-up to My Nokia later, select > Applications > My Nokia.
After the invitation to join My Nokia, the Welcome application opens. With the
Welcome application, you can access the following applications:
Sett. wizard — Configure connection settings. See ‘Settings wizard,’ p. 12.
Switch — Copy or synchronise data from other compatible devices.
Tutorial — Learn about the features of your device and how to use them. To start
the tutorial later, select > Help > Tutorial and a tutorial item.
To open the Welcome application later, select > Help > Welcome.
DRAF
T
Get started
11
Antenna locations
Bluetooth antenna (1)
Cellular antenna (2)
Your device may have internal and external antennas. As with
any radio transmitting device, avoid touching the antenna
area unnecessarily while the antenna is transmitting or
receiving. Contact with such an antenna affects the
communication quality and may cause the device to operate
at a higher power level than otherwise needed and may
reduce the battery life.
■ Configuration settings
Before you can use multimedia messaging, e-mail, synchronisation, streaming,
and the browser, you must have the proper configuration settings on your device.
Your device may automatically configure browser, multimedia messaging, access
point, and streaming settings based on the SIM card used. If not, you can use the
Settings wizard application to configure the settings. You may receive the settings
directly as a configuration message, which you can save to your device. For
availability, contact your service provider or nearest authorised Nokia dealer.
When you receive a configuration message, and the settings are not automatically
saved and activated, 1 new message is displayed. To save the settings, select
Show > Options > Save. You may need to enter a PIN code provided by the service
provider.
T
Settings wizard
The Settings wizard application configures your device for operator and e-mail
settings based on your service provider. Configuring other settings may also be
possible.
To use these services, you may have to contact your service provider to activate a
data connection or other services.
Select > Settings > Sett. wizard.
DRAF
■ Transfer data
To transfer information, such as contacts, from your old device, see ‘Data transfer,’
p. 65.
12
Get started
2. Your device
■ Keys and parts
Earpiece (1)
Secondary camera lens (2)
Ambient light sensor (3)
Display (4)
Left and right selection keys (5)
Clear key (6)
Menu key (7), hereafter referred to as
Call key (8)
End/Power key (9)
Navi™ scroll key, hereafter referred to as scroll key,
and status light around it (10)
Number keys (11)
Microphone (12)
Micro USB connector (13)
Charging indicator (14)
Nokia AV Connector (2.5 mm) (15)
Camera flash (16)
Main camera lens (17)
Volume up key (18)
Volume down key (19)
Memory card slot (20)
Loudspeaker (21)
Camera key (22)
Event indicator LED (23)
Rewind key (24)
Play/pause key (25)
Forward key (26)
Hole for a wrist strap (27)
DRAF
Your device
T
13
■ Standby mode and home screen
When you have switched on the device, and it is registered to a network, the
device is in the standby mode in home screen view.
The home screen is your starting point where you can collect your most important
contacts and application shortcuts.
The home screen consists of:
• Contacts bar where you can add your most used contacts, quickly make calls or
send messages to the contacts, view the contacts' web feeds, or access the
contact information and settings. To add a contact to your home screen, select
Add contact and a contact from the list. To create a new contact, select
Options > New contact, enter the details, and select Done. You can also add
an image to the contact information. To add a web feed for a contact, select
Add feed, the desired feed from the list, and Done. To create a new feed, select
Options > New feed. To update a feed, select Refresh. To remove a contact
from the home screen, in the contact information view, select Settings and
Remove.
• Application plug-ins. To customise the plug-ins in your home screen view,
select > Settings > Settings > General > Personalisation > Standby mode >
Homescreen applications.
• Application shortcuts which you can customise. You can also customise the
left and right selection keys. To customise the shortcuts in your home screen,
select > Settings > Settings > General > Personalisation > Standby mode >
Shortcuts.
To change the standby theme, select > Settings > Settings > General >
Personalisation > Standby mode > Standby theme.
To open a list of most recently dialled numbers, press the call key.
To use the voice commands or voice dialling, press and hold the right
selection key.
To change the profile, press the power key, and select a profile.
To start a connection to the web, press and hold 0.
DRAF
T
Offline profile
To quickly activate the offline profile, press briefly the power key, and select
Offline. To leave the offline profile, press briefly the power key, and select another
profile.
14
Your device
When the offline profile is active, all the connections to a cellular network are
turned off. However, you can use your device without a SIM card, and listen to the
radio or music using the music player. Remember to switch off your device when
wireless phone use is prohibited.
Important: In the offline profile you cannot make or receive any calls, or use other
features that require cellular network coverage. Calls may still be possible to the
official emergency number programmed into your device. To make calls, you must
first activate the phone function by changing profiles. If the device has been
locked, enter the lock code.
■ Indicators
Icons
or — The device is connected to a UMTS or GSM network.
— HSDPA (network service) in the UMTS network is activated.
— The device is in the offline mode and not connected to a cellular network.
— A memory card is inserted in the device.
— You have unread messages in the inbox in Messaging.
— You received new e-mail in your remote mailbox.
— You have messages waiting to be sent in outbox.
— You have missed calls.
— Ringing type is set to Silent and Message alert tone and E-mail alert tone are
deactivated.
— The device keypad is locked.
— The loudspeaker is activated.
— An alarm is active.
— All calls to the device are diverted to another number.
or — A headset or a loopset is connected to the device.
or or — A GPRS packet data connection is active, the connection is on
hold, or a connection is available.
DRAF
T
or or — A packet data connection is active in a part of the network that
supports EGPRS; the connection is on hold; a connection is available. Your device
may not use EGPRS in the data transfer.
Your device
15
or or — A UMTS packet data connection is active; the connection is on
hold; a connection is available.
or — Bluetooth connectivity is activated; data is being transmitted using
Bluetooth technology.
— A USB connection is active.
Other indicators may also be displayed.
■ Power saver
To set the timeout period after which the power saver is activated, select >
Settings > Settings > General > Personalisation > Display > Power saver timeout.
■ Menu
In the menu you can access the functions in your device. To access the main menu,
select .
To open an application or a folder, scroll to it, and press the scroll key.
If you change the order of the functions in the menu, the order may differ from
the default order described in this user guide.
To mark or unmark an item in applications, press #. To mark or unmark several
consecutive items, press and hold #, and scroll up or down.
To change the menu view, select Options > Change Menu view and a view type.
To close an application or a folder, select Back and Exit as many times as needed
to return to the standby mode, or select Options > Exit.
To display and switch between open applications, press and hold . Scroll to an
application, and select it.
Leaving applications running in the background increases the demand on battery power and
reduces the battery life.
DRAF
T
■ Volume control
To adjust the earpiece or loudspeaker volume during a call or when listening to an
audio file, press the volume keys. To activate or deactivate the loudspeaker during
a call, select Loudsp. or Handset.
Warning: Do not hold the device near your ear when the loudspeaker is in use,
because the volume may be extremely loud.
16
Your device
■ Keypad lock (keyguard)
To lock the keypad in the standby mode, press the left selection key and * within
1.5 seconds. To set the device to automatically lock the keypad after a certain
time, select > Settings > Settings > General > Security > Phone and SIM card >
Keypad autolock period > User defined and the desired time.
To unlock the keypad, select Unlock, and press * within 1.5 seconds.
When the device or keypad is locked, calls may be possible to the official emergency number
programmed into your device.
■ Access codes
To set how your device uses the access codes, select > Settings > Settings >
General > Security > Phone and SIM card.
Lock code
The lock code (5 digits) helps to lock your device. The preset code is 12345. Change
the code, and set the device to request the code. If you forget the code and your
device is locked, your device will require service and additional charges may apply.
For more information, contact a Nokia Care point or your device dealer.
When the device or keypad is locked, calls may be possible to the official emergency number
programmed into your device.
PIN codes
The personal identification number (PIN) code or the universal personal
identification number (UPIN) code (4 to 8 digits) help to protect your SIM card.
The (U)PIN code is usually supplied with the SIM card. Set the device to request
the code each time the device is switched on.
The PIN2 code may be supplied with the SIM card and is required for some
functions.
The module PIN is required to access the information in the security module. The
signing PIN is required for the digital signature. The module PIN and the signing
PIN are supplied with the SIM card if the SIM card has a security module in it.
DRAF
T
PUK codes
The personal unblocking key (PUK) code or the universal personal unblocking key
(UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code,
respectively. The PUK2 code is required to change a blocked PIN2 code.
If needed, contact your local service provider for the codes.
Your device
17
Barring password
The barring password (4 digits) is required when using call barring. You can obtain
the password from your service provider. If the password is blocked, contact your
service provider.
■ Download!
Download! (network service) is a mobile content shop available for your device.
With Download! you can discover, preview, buy, download, and upgrade content,
services, and applications. The items are categorised under catalogs and folders
provided by different service providers. The available content depends on your
service provider.
Select > Download!.
Download! uses your network services to access the most up-to-date content. For
information on additional items available through Download!, contact your
service provider, or the supplier or manufacturer of the item.
T
■ Installed applications
You can download applications to your device. To access the applications installed
to your device, select > Applications > Installations.
Important: Only install and use applications and other software from trusted
sources, such as applications that are Symbian Signed or have passed the Java
TM
Verified
testing.
■ Connect a compatible
headset
Do not connect products that create an output
signal as this may cause damage to the device.
Do not connect any voltage source to the
Nokia AV Connector.
When connecting any external device or any
headset, other than those approved by Nokia
for use with this device, to the Nokia AV Connector, pay special attention to volume levels.
18
DRAF
Your device
■ Connect a USB data cable
Connect a compatible USB data cable to the
USB connector.
To select the default USB connection mode
or change the active mode, select >
Settings > Connectivity > USB > USB
connection mode and the desired mode. To
set the device to activate the default mode
automatically, select Ask on connection > No.
■ Energy efficiency
Your device features Power Save which saves energy and prolongs the device
operating time. Your charger is energy efficient and minimises the use of no-load
energy that is consumed when the device is fully charged but still connected to
the wall socket. However, unplug your charger after the device is fully charged in
any case. Your device gives you a visual reminder of this.
■ Sustainable materials
Your device, its accessories and packaging have been manufactured from
sustainable materials according to Nokia’s criteria.
T
DRAF
■ Environmental software & services
This product comes with Eco catalogue. It is a downloadable service that lets you
easily access up-to-date environmental services and content. For more
information on the Eco catalogue, see http://www.nokia.com/ecocatalogue.
Your device
19
■ Recycling
65-80% of the materials in a Nokia mobile phone can be recycled. There are
collection points for devices and accessories that are no longer in use. For
information on recycling points close to you, see www.nokia.com/werecycle.
3. Call functions
To adjust the volume during a call, press the volume keys.
■ Make a voice call
1. In the standby mode, enter the phone number, including the area code. Press
the clear key to remove a number.
For international calls, press * twice for the international prefix (the +
character replaces the international access code), and enter the country code,
area code (omit the leading zero if necessary), and phone number.
2. To call the number, press the call key.
3. To end the call, or to cancel the call attempt, press the end key.
To make a call from Contacts, select > Contacts. Scroll to the desired name; or
enter the first letters of the name, and scroll to the desired name. To call the
number, press the call key.
To call a recently dialled number from the standby mode, press the call key.
Speed dialling
Speed dialling is a quick way to call frequently used numbers from the standby
mode. You need to assign a phone number to the speed dialling keys 3 to 9 (the 1
and 2 keys are reserved for the voice and video call mailboxes), and set Speed
dialling to On.
To assign a phone number to a speed dialling key, select > Settings > Speed
dial. Scroll to a key icon, and select Assign and the contact. To change the
number, select Options > Change.
To activate the speed dialling, select > Settings > Settings > Phone > Call >
Speed dialling > On.
DRAF
T
20
Call functions
To call a speed dialling number, press and hold the speed dialling key until the call
begins.
Call mailbox
To call your call mailboxes (network service), from the standby mode, press and
hold 1 or 2. You can have call mailboxes for voice calls, video calls, and multiple
phone lines.
To define the call mailbox number if no number is set, select > Settings > Call
mailbox. Scroll to Voice mailbox (or Video mailbox), and enter the corresponding
mailbox number. To change the call mailbox number, select Options > Change
number. Contact your service provider for the call mailbox number.
Voice dialling
A voice tag is added automatically to all entries in Contacts. Use long names, and
avoid similar names for different numbers.
Make a voice dialling call
Voice tags are sensitive to background noise. Use voice tags in a quiet environment.
Note: Using voice tags may be difficult in a noisy environment or during an
emergency, so you should not rely solely upon voice dialling in all circumstances.
1. In the standby mode, press and hold the right selection key.
If you are using a compatible headset with the headset key, press and hold the
headset key.
2. When Speak now is displayed, speak the voice command clearly. The device
plays the voice command of the best match. After 1.5 seconds, the device dials
the number; if the result is not the correct one, before dialling select another
entry.
Make a conference call
Your device supports conference calls (network service) between a maximum of
six participants, including yourself.
1. Make a call to the first participant.
2. To make a call to another participant, select Options > New call.
3. To create the conference call when the new call is answered, select Options >
Conference.
To add another person to the conference call, repeat step 2, and select
Options > Conference > Add to conference.
DRAF
Call functions
T
21
4. To end the conference call, press the end key.
■ Answer or reject a call
To answer a call, press the call key.
To mute the ringing tone, select Silence.
To reject the call, press the end key, or select Options > Reject. If you have
activated Call divert > If busy, rejecting the call diverts the call.
To send a text message as a reply to the caller instead of answering the call, select
Options > Send message. To activate the text message reply and edit the message,
select > Settings > Settings > Phone > Call > Reject call with message and
Message text.
Call waiting
During a call, to answer the waiting call, press the call key. The first call is put on
hold. To switch between the two calls, select Swap. To end the active call, press
the end key.
To activate the call waiting function (network service), select > Settings >
Settings > Phone > Call > Call waiting > Activate.
■ Video calls
Make a video call
To make a video call, you may need to have a USIM card and be within the
coverage of a UMTS network. For availability of and subscription to video call
services, contact your service provider. A video call can only be made between two
parties and when no other voice, video, or data calls are active. The video call can
be made to a compatible mobile phone or an ISDN client.
You have captured a still image to be sent instead of video sending.
You have denied video sending from your device.
1. Enter the phone number in the standby mode and select Video call. Or, select
> Contacts, scroll to the desired contact, and select Options > Video call.
2. To change between showing video or only hearing sound during a video call,
select from the toolbar Enable video sending or Disable video sending.
If you have denied video sending during a video call, the call is still charged as
a video call. Check the pricing with your network operator or service provider.
3. To end the video call, press the end key.
DRAF
T
22
Call functions
Answer a video call
When a video call arrives, is displayed.
To answer the video call, press the call key. Allow video image to be sent to caller?
is shown. If you select Yes, the image captured by the camera in your device is
shown to the caller. Otherwise, video sending is not activated.
If you have denied video sending during a video call, the call is still charged as a
video call. Check the pricing with your service provider.
To end the video call, press the end key.
■ Call settings
Call
Select > Settings > Settings > Phone > Call and from the following:
Send my caller ID (network service) — to display or hide your phone number from
the person to whom you are calling
Call waiting (network service) — See ‘Call waiting,’ p. 22.
Reject call with message and Message text — See ‘Answer or reject a call,’ p. 22.
Own video in recvd. call— to set whether you allow to send your own video image
when you receive a video call
Image in video call — to select a still image to be shown when you deny a video
call
Automatic redial — to set your device to make a maximum of 10 attempts to
connect the call after an unsuccessful call attempt
Show call duration and Summary after call — to set the device to display the call
duration during a call and the approximate duration of the last call
Speed dialling — See ‘Speed dialling,’ p. 20.
Anykey answer — to answer an incoming call by briefly pressing any key, except
the left and right selection keys, volume keys, power key, end key, and
camera key.
Line in use (network service) — to select the phone lines for making calls and
sending short messages. This is shown only if the SIM card supports two phone
lines.
Line change (network service) — to enable or disable the line selection
DRAF
T
Call functions
23
Call divert
1. Select > Settings > Settings > Phone > Call divert (network service).
2. Select which calls you want to divert, for example, Voice calls.
3. Select the desired option. For example, to divert voice calls when your number
is busy or when you reject an incoming call, select If busy.
4. Select Options > Activate and the phone number to which you want to divert
the calls. Several divert options can be active at the same time.
Call barring and call diverting cannot be active at the same time.
Call barring
1. Select > Settings > Settings > Phone > Call barring (network service) to
restrict the calls that you make and receive with your device.
2. Scroll to the desired barring option, and select Options > Activate. To change
the settings, you need the barring password given by your service provider.
Call barring and call diverting cannot be active at the same time.
When calls are barred, calls may be possible to certain official emergency numbers.
Network
Select > Settings > Settings > Phone > Network and from the following:
Network mode — to select which network to use (this is shown only if it is
supported by the service provider). If you select Dual mode, the device uses the
GSM or UMTS network automatically.
Operator selection — to set the device to search for and automatically select one
of the available networks, select Automatic. To select the desired network
manually from a list of networks, select Manual. The selected network must have
a roaming agreement with your home network.
Cell info display (network service) — to set the device to indicate when it is used in
a cellular network based on microcellular network (MCN) technology, and to
activate cell info reception
DRAF
T
■ Video sharing
Use video sharing to send live video from your mobile device to another
compatible mobile device during a voice call.
24
Call functions
Loading...
