Microsoft RM-430 User Manual

Draft

Nokia 1508i User Guide

Draft

© 2008 Nokia. All rights reserved. Navi and Nokia Connecting People are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE TH IS DO CUME NT OR WIT HDRA W IT A T ANY TIM E WIT HOUT PRIOR NOTI CE.

The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and availability of language options.

Draft

Export controls

This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user’s authority to operate this equipment.

xxxxxxx, Issue 1

Draft

Contents

SAFETY...................................................................................... 6

General information ................................................................ 9

Access codes.............................................................................................................. 9

Nokia support on the web.................................................................................. 10

1. Get started ......................................................................... 11

Install the UIM card and battery...................................................................... 11

Charge the battery................................................................................................ 13

Switch your device on or off ............................................................................. 14

Normal operating position ................................................................................. 15

2. Your phone ........................................................................ 16

Keys and parts (front).......................................................................................... 16

Keys and parts (side)............................................................................................ 17

Standby mode and shortcuts............................................................................. 17

Keyguard.................................................................................................................. 18

Data transfer .......................................................................................................... 19

3. Call functions .................................................................... 20

Make and answer a call ...................................................................................... 20

Make a conference call ....................................................................................... 20

Loudspeaker............................................................................................................ 21

4. Text entry........................................................................... 22

Traditional text input........................................................................................... 22

Predictive text input............................................................................................. 22

5. Menu functions ................................................................. 24

Messaging ............................................................................................................... 24

Draft

Contacts................................................................................................................... 30

Log............................................................................................................................. 34

Settings.................................................................................................................... 35

Gallery ...................................................................................................................... 43

Media........................................................................................................................ 44

Organiser ................................................................................................................. 47

Applications............................................................................................................ 50

Games....................................................................................................................... 50

UIM services ........................................................................................................... 51

6. Enhancements.................................................................... 52

7. Battery and charger information ..................................... 53

Nokia battery authentication guidelines........................................................ 56

Care and maintenance........................................................... 59

Additional safety information .............................................. 62

Index ....................................................................................... 71

Draft

SAFETY

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

Draft

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

■ About your device

The wireless device (RM-430) described in this guide is approved for use on the CDMA 1900 network. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Warning: To use any features in this device, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

Draft

■ Network services

To use the device you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

Draft

General information

■ Access codes

The security code supplied with the device helps to protect your device against unauthorised use. The preset code is

12345.

You can change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone.

If you forget the code and your phone is locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your device dealer.

The PIN code supplied with the UIM card helps to protect the card against unauthorised use. If you enter the PIN code incorrectly three times in succession, you are asked for the PUK code. If you do not have it, contact your service provider.

To set how your device uses the access codes and security settings, select Menu > Settings > Security.

Draft

■ Nokia support on the web

Check www.nokia.com/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

Draft

1. Get started

■ Install the UIM card and battery

Keep all UIM cards out of the reach of small children.

For availability and information on using UIM card services, contact your UIM card vendor. This may be the service provider or other vendor.

Note: Always switch off the power and disconnect the charger and any other device before removing the cover. Avoid touching electronic components while changing the cover. Always store and use the device with the cover attached.

1. To remove the back cover of the device, press the release button on the bottom, and lift the back cover.

Draft

2. Insert your finger into the finger grip and lift the battery from its compartment.

3. Keep the bevelled corner of the UIM card facing up and matching along the corresponding bevelled corner of the card holder.

4. Insert the UIM card into the holder with the gold-coloured contacts facing down, matching up with the gold-coloured contacts on the device.

Draft

5. Position the battery so the gold-coloured contacts match up with those on the device, and insert the battery into the battery slot.

6. Push down on the other end of the battery to snap the battery into place.

7. Align the back cover with the back of the device. To lock it, press the bottom of the back cover.

■ Charge the battery

Warning: Use only batteries, chargers, and

enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from an AC-6 charger. The battery intended for use with this device is the BL-4C.

Draft

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

1. Plug the charger transformer into a standard wall outlet.

2. Insert the charger output plug into the socket at the left side of the device.

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

■ Switch your device on or off

To switch your device on or off, press and hold the power key for at least 2 seconds.

Warning: Do not switch on the device when wireless device use is prohibited or when it may cause interference or danger.

Draft

■ Normal operating position

Your device has an internal antenna. Hold the device with the antenna pointed up and over your shoulder.

Note: As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.

Draft

2. Your phone

■ Keys and parts (front)

1 — Earpiece

2 — Display screen

3 — Left selection key

4 — Call key

5 — Keypad

6 — Power/End key

7 — Right selection key

8 — 4-way navigation key (hereafter referred to as scroll key)

9 — Middle selection key

10 — Press and hold the * key to activate the radio function (if headset is connected)

11 — Press and hold the # key to toggle between silent and general profiles

Draft

■ Keys and parts (side)

1 — Charger/USB port

2 — Headset port

3 — Device strap eyelet

4 — Loudspeaker

■ Standby mode and shortcuts

Depending on your wireless service provider and the model number of your device, some or all of the following selection keys may appear in the standby mode.

The start screen is home base and indicates your device is in the standby mode.

1 — Name of the network or operator logo

2 — Signal strength of the wireless network

3 — Battery charge level

Draft

4 — Left selection key (Go to)

5 — Middle selection key (Menu)

6 — Right selection key (Names)

For shortcuts of scroll key, see "My shortcuts," p. 38.

■ Keyguard

The keyguard locks the keypad to prevent keys from being pressed accidentally. If the keypad is locked, it unlocks when you receive a call. After the call, the keypad is automatically locked.

To set the keypad to lock automatically after a preset time delay when the device is in the standby mode and no function of the device has been used, select Menu >

Settings > Phone > Automatic keyguard > On, set the

delay time in mm:ss format, and then select OK. To deactivate the feature, select Off.

When the keyguard is on, calls may be possible to the official emergency number programmed into your device.

To unlock the keypad, select Unlock, and press * within 2 seconds.

Draft

To lock the keypad, select Menu, and press * within 5 seconds.

■ Data transfer

To use the USB data cable to transfer data and files between your device and a compatible PC, install Nokia PC Suite software on the PC first. Connect your device to the PC with the USB data cable, and start the synchronization from the PC.

You may find PC Suite and related information on the Nokia web site at http://www.nokia.com/pcsuite

Important: Do not make calls when the USB data cable is connected to the device.

Draft

3. Call functions

■ Make and answer a call

To make a call, enter the phone number, including the country code and area code if necessary. To call the number, press the call key. To increase or decrease the volume of the earpiece or headset during the phone call, use the scroll key.

To answer an incoming call, press the call key or the middle selection key. To reject the call without answering, press the end key.

■ Make a conference call

Conference calling (network service) allows you to talk to two other people at the same time.

1. Call the first participant.

2. Select Options > New call, and call the next participant.

3. When the call is answered, to set up the conference call, press the call key.

Draft

4. To end the conference call, select Options > End all

calls, or press the end key.

■ Loudspeaker

To use your device handsfree during a call, select Loudsp.

Warning: Do not hold the device near your ear when the loudspeaker is in use because the volume may be extremely loud.

To deactivate the loudspeaker during a call, select

Normal.

The loudspeaker is deactivated automatically when a call (or a call attempt) ends or when certain enhancements are connected.

Draft

4. Text entry

You can enter text using traditional text input , and predictive text input . To change the text input method and to switch between upper and lower case, press the # key. To set the writing language, select Options > Writing

language.

■ Traditional text input

To use traditional text input, press a number key, 1 to 9, repeatedly until the desired character appears. To add a space, press 0. To add a number, press and hold the desired number key. To get a list of special characters, press *.

■ Predictive text input

Predictive text input is based on a built-in dictionary to which you can add new words. To activate predictive text input, select Options > Prediction options > Prediction >

On. To set the prediction type, select Prediction type > Normal or Word sugg.
