Microsoft RM-414 User Manual
Nokia 6600 Slide User Guide
5555555
Issue 1
2Contents
Contents
3Safety
4 Make it your phone
4 Start up
12 Personalise your phone
14 Connect
17 Network provider services
18 Stay in touch
18 Make calls
21 Text and messages
26 Image and video
26 Capture an image
26 Record a video clip
26 Camera and video options
27 Gallery
28 Entertainment
28 Listen to music
31 Web
33 Games and applications
34 Maps
34 Download maps
34 Maps and GPS
35 Extra services
36 Organise
36 Manage contacts
37 Business cards
37 Date and time
37 Alarm clock
37 Calendar
38 To-do list
38 Notes
38 Nokia PC Suite
38 Calculator
38 Countdown timer
39 Stopwatch
39 Support and phone software
updates
39 Helpful hints
39 Nokia support
40 My Nokia
40 Download content
40 Software updates
41 Software updates over the air
41 Configuration setting service
41 Restore factory settings
43 Digital rights management
43 Enhancements
43 Battery
43 Battery and charger information
44 Nokia battery authentication
guidelines
44 Authenticate hologram
44 What if your battery is not authentic?
44 Care and maintenance
44 Disposal
45 Additional safety information
45 Small children
45 Operating environment
45 Medical devices
45 Vehicles
45 Potentially explosive environments
46 Emergency calls
46 CERTIFICATION INFORMATION (SAR)
47 Index
2
Safety 3
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on
when wireless phone use is
prohibited or when it may
cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch
the device off in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ENHANCEMENTS
Use only approved
enhancements. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not waterresistant. Keep it dry.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved
enhancements and batteries.
Do not connect incompatible
products.
3
4Make it your phone
Looking for a little selfexpression? Give your
phone its own look and feel
by choosing your own
ringtones, display
background and theme.
Make it your phone
Start up
Get to know your phone, insert the
battery, SIM card, and memory card, and
learn some important information about
your phone.
Keys and parts
10 Front camera
11 Charger connector
12 Strap eyelet
13 Back cover release button
14 USB cable connector
15 Camera flash
16 Main camera
17 Loudspeaker
Install SIM card and battery
Always switch the device off and
disconnect the charger before removing
the battery.
This phone is intended for use with a
BL-4U battery. Always use original Nokia
batteries. See "Nokia battery
authentication guidelines", p. 44.
The SIM card and its contacts can be easily
damaged by scratches or bending, so be
careful when handling, inserting, or
removing the card.
1 Push the release button, and open the
back cover. Remove the battery.
1 Earpiece
2 Display
3 Navi™ key (scroll key)
4 Left selection key
5 Call key
6 Keypad
7 End/Power key
8 Right selection key
9 Light sensor
4
2 Open the SIM card holder. Insert the
SIM card into the holder with the
contact surface facing down. Close the
SIM card holder.
Make it your phone 5
3 Observe the battery contacts, and
insert the battery. Replace the back
cover.
Insert a memory card
Use only compatible microSD cards
approved by Nokia for use with this
device. Nokia uses approved industry
standards for memory cards, but some
brands may not be fully compatible with
this device. Incompatible cards may
damage the card and the device and
corrupt data stored on the card.
You phone supports microSD cards of up
to 4 GB.
1 Switch the device off, and remove the
back cover and battery.
4 Close the card holder, and slide it to
lock.
5 Replace the battery and back cover.
Charge the battery
Your battery has been precharged, but the
charging levels may vary.
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the battery is fully charged,
disconnect the charger from the
device, then from the wall outlet.
You also may charge the battery with a
USB cable with power from a computer.
1 Connect the USB cable to the USB port
of a computer and to your device.
2 When the battery is full charged,
disconnect the USB cable.
If the battery is completely discharged, it
may take a few minutes before the
charging indicator appears on the display
or before any calls can be made.
2 Slide the memory card holder to
unlock.
3 Open the card holder, and insert the
memory card into the holder with the
contact surface facing inwards.
The charging time depends on the charger
used. Charging a BL-4U battery with the
AC-8 charger takes approximately 1 hour
30 minutes while the phone is in the
standby mode.
5
6Make it your phone
Antenna
Your device may have internal and
external antennas. As with any radio
transmitting device, avoid touching the
antenna area unnecessarily while the
antenna is transmitting or receiving.
Contact with such an antenna affects the
communication quality and may cause the
device to operate at a higher power level
than otherwise needed and may reduce
the battery life.
The figure shows the antenna area
marked in grey.
Headset
Warning: Listen to music at a
moderate level. Continuous exposure to
high volume may damage your hearing.
Warning: When you use the headset,
your ability to hear outside sounds may be
affected. Do not use the headset where it
can endanger your safety.
When connecting any external device or
any headset, other than those approved
by Nokia for use with this device, to the
USB connector, pay special attention to
volume levels.
Strap
1Open the back cover.
2 Hook a strap behind the clamp, and
close the back cover.
About your phone
The wireless device described in this guide
is approved for use on the WCDMA 850 and
2100 and GSM 850, 900, 1800, and 1900.
Contact your service provider for more
information about networks.
When using the features in this device,
obey all laws and respect local customs,
privacy and legitimate rights of others,
including copyrights.
Copyright protection may prevent some
images, music, and other content from
being copied, modified, or transferred.
Your device may have preinstalled
bookmarks and links for third-party
internet sites. You may also access other
third-party sites through your device.
Third-party sites are not affiliated with
Nokia, and Nokia does not endorse or
assume liability for them. If you choose to
access such sites, you should take
precautions for security or content.
6
Make it your phone 7
Warning: To use any features in this
device, other than the alarm clock, the
device must be switched on. Do not switch
the device on when wireless device use
may cause interference or danger.
Remember to make back-up copies or
keep a written record of all important
information stored in your device.
When connecting to any other device,
read its user guide for detailed safety
instructions. Do not connect incompatible
products.
Important: Use only services that you
trust and that offer adequate security and
protection against harmful software.
Network services
To use the phone you must have service
from a wireless service provider. Many of
the features require special network
features. These features are not available
on all networks; other networks may
require that you make specific
arrangements with your service provider
before you can use the network services.
Your service provider can give you
instructions and explain what charges w ill
apply. Some networks may have
limitations that affect how you can use
network services. For instance, some
networks may not support all languagedependent characters and services.
Your service provider may have requested
that certain features be disabled or not
activated in your device. If so, these
features will not appear on your device
menu. Your device may also have a special
configuration such as changes in menu
names, menu order, and icons. Contact
your service provider for more
information.
Functions without a SIM card
Some functions of your phone may be
used without inserting a SIM card, such as
Organiser functions and games. Some
functions appear dimmed in the menus
and cannot be used.
Keypad lock
• To lock the keypad to prevent
accidental keypresses, select Menu,
and press * within 3 seconds.
• To unlock the keypad, select Unlock,
and press * within 1.5 seconds. If
requested, enter the lock code.
• To answer a call when the keypad is
locked, press the call key. When you
end or reject the call, the keypad locks
automatically.
Further features are Automatic
keyguard and Security keyguard. See
"Phone settings", p. 10.
When the device or keypad is locked, calls
may be possible to the official emergency
number programmed into your device.
Access codes
To set how your phone uses the access
codes and security settings, select
Menu > Settings > Security > Access
codes.
• The PIN (UPIN) code, supplied with the
SIM (USIM) card, helps to protect the
card against unauthorised use.
• The PIN2 (UPIN2) code, supplied with
some SIM (USIM) cards, is required to
access certain services.
7
8Make it your phone
• PUK (UPUK) and PUK2 (UPUK2) codes
may be supplied with the SIM (USIM)
card. If you enter the PIN code
incorrectly three times in succession,
you are asked for the PUK code. If the
codes are not supplied, contact your
service provider.
• The security code helps to protect
your phone against unauthorised use.
You can create and change the code,
and set the phone to request the code.
Keep the code secret and in a safe
place separate from your phone. If
you forget the code and your phone is
locked, your phone will require
service and additional charges may
apply. For more information, contact
a Nokia Care point or your phone
dealer.
• The barring password is required
when using the call barring service to
restrict calls to and from your phone
(network service).
• To view or change the security
module settings for the web browser,
select Menu > Settings >
Security > Security module sett..
Switch the phone on and off
• To switch the phone on or off, press
and hold the power key.
• If the phone prompts for a PIN code,
enter the code (displayed as ****).
• If the phone prompts you for the time
and date, enter the local time, select
the time zone of your location in
terms of the time difference with
respect to Greenwich Mean Time
(GMT), and enter the date. See "Date
and time", p. 37.
When you switch on your phone for the
first time, you may be prompted to get the
configuration settings from your service
provider (network service). For more
information, refer to Connect to
support. See "Configuration", p. 17, and
"Configuration setting service", p. 41.
Standby mode
When the phone is ready for use, and you
have not entered any characters, the
phone is in the standby mode.
Display
1 Network type indicator and signal
strength of the cellular network
2 Battery charge status
3 Indicators
4 Name of the network or the operator
logo
5 Clock
6 Display
7 Function of the left selection key
8 Function of the scroll key
9 Function of the right selection key
You can change the function of the left and
right selection key. See "Left and right
selection keys", p. 13.
8
Make it your phone 9
Power saving
Your phone has a Power saver and a
Sleep mode feature in order to save
battery power in the standby mode when
no keys are pressed. These features may
be activated. See "Display", p. 13.
Active standby
The active standby mode displays a list of
selected phone features and information
that you can access directly.
• To activate or deactivate the active
standby mode, select Menu >
Settings > Display > Active
standby > Active standby mode.
• In the active standby mode, scroll up
or down to navigate in the list, and
select Select or View. The arrows
indicate that further information is
available. To stop navigation, select
Exit.
• To organise and change the active
standby mode, select Options and
from the available options.
Shortcuts in the standby mode
List of dialled numbers
Press the call key once. To make a call,
scroll to the number or name, and press
the call key.
Start the web browser
Press and hold 0.
Call the voice mailbox
Press and hold 1.
Use other keys as shortcuts
See "Dialling shortcuts", p. 19.
Indicators
You have unread messages.
You have unsent, cancelled, or
failed messages.
You have missed calls.
The keypad is locked.
The phone does not ring for
incoming calls or text messages.
An alarm is set.
The phone is registered to the
/
GPRS or EGPRS network.
The phone has an open GPRS or
/
EGPRS connection.
The GPRS or EGPRS connection is
/
suspended (on hold).
Bluetooth connectivity is turned
on.
If you have two phone lines, the
second phone line is selected.
All incoming calls are diverted to
another number.
Calls are limited to a closed user
group.
The currently active profile is
timed.
Flight mode
Use the flight mode in radio sensitive
environments — on board aircraft or in
hospitals — to deactivate all radio
frequency functions. You can still access
your calendar, phone numbers, and
offline games. When the flight mode is
active,
is displayed.
• To activate or set up the flight mode,
select Menu > Settings > Profiles >
Flight > Activate or Personalise.
9
10 Make it your phone
• To deactivate the flight mode, select
any other profile.
Emergency call in flight mode
• Enter the emergency number, press
the call key, and when Exit flight
profile? is displayed, select Yes.
Warning: With the flight profile you
cannot make or receive any calls,
including emergency calls, or use other
features that require network coverage.
To make calls, you must first activate the
phone function by changing profiles. If the
device has been locked, enter the lock
code. If you need to make an emergency
call while the device is locked and in the
flight profile, you may be also able to
enter an official emergency number
programmed in your device in the lock
code field and select 'Call'. The device will
confirm that you are about to exit flight
profile to start an emergency call.
Tapping
The tap function allows you to quickly
mute and reject calls and alarm tones, and
to display a clock just by double-tapping
the back or front of the phone when the
slide is closed.
Select Menu > Settings > Phone >
Sensor settings to activate the tap
function and vibration feedback.
Mute calls or alarms
Double-tap the phone.
Reject a call or snooze an alarm after
muting it
Double-tap the phone again.
Display the clock
Double-tap the phone.
If you have missed calls or received new
messages, you must view them before you
can see the clock.
Phone settings
Select Menu > Settings > Phone and
from the following:
Language settings
• to set the display language of your
phone, select Phone language. . To
set a language for the voice
commands, select Recognition
lang..
Memory status
• to check the memory consumption
Automatic keyguard
• to lock the keypad automatically after
a preset time when the phone is in the
standby mode and no function has
been used.
Security keyguard
• to ask for the security code when you
unlock the keyguard
Sensor settings
• to activate and adjust the tapping
function
Voice recognition
• See "Voice commands", p. 14.
Flight query
• to be asked whether to use the flight
mode when you switch the phone on.
10
Make it your phone 11
With the flight mode, all radio
connections are switched off.
Phone updates
• to receive software updates from your
service provider (network service).
This option may not be available,
depending on your phone. See
"Software updates over the
air", p. 41.
Network mode
• to use both the UMTS and the GSM
network. You cannot access this
option during an active call.
Operator selection
• to set a cellular network available in
your area
Help text activation
• to select whether the phone shows
help texts
Start-up tone
• to play a tone when you switch the
phone on
Confirm SIM actions
• See "SIM services", p. 17.
Security settings
When security features that restrict calls
are in use (such as call barring, closed user
group, and fixed dialling), calls may be
possible to the official emergency number
programmed into your device.
Select Menu > Settings > Security and
from the following:
PIN code request or UPIN code request
• to request for your PIN or UPIN code
every time the phone is switched on.
Some SIM cards do not allow the code
request to be turned off.
PIN2 code request
• to select whether the PIN2 code is
required when using a specific phone
feature which is protected by the PIN2
code. Some SIM cards do not allow the
code request to be turned off.
Call barring service
• to restrict incoming calls to and
outgoing calls from your phone
(network service). A barring password
is required.
Fixed dialling
• to restrict your outgoing calls to
selected phone numbers if supported
by your SIM card. When the fixed
dialling is on, GPRS connections are
not possible except while sending
text messages over a GPRS
connection. In this case, the
recipient’s phone number and the
message centre number must be
included in the fixed dialling list.
Closed user group
• to specify a group of people whom
you can call and who can call you
(network service)
Security level
• To request the security code when a
new SIM card is inserted, select
Phone. To request the security code
when the SIM card memory is
11
12 Make it your phone
selected, and you want to change the
memory in use, select Memory.
Access codes
• to change the security code, PIN code,
UPIN code, PIN2 code, or barring
password
Code in use
• to select whether the PIN code or UPIN
code should be active
Authority certificates or User
certificates
• to view the list of the authority or user
certificates downloaded into your
phone. See "Browser
security", p. 32.
Security module sett.
• to view security module details,
activate the module PIN request, or
change the module PIN and signing
PIN. See "Access codes", p. 7.
Personalise your phone
Give your phone a personal touch with
ringing tones, display backgrounds, and
themes. Add shortcuts for your preferred
features, and attach enhancements.
Profiles
Your phone has various setting groups
called profiles, which you can customise
with ringing tones for different events
and environments.
Select Menu > Settings > Profiles, the
desired profile, and from the following
options:
Activate
• to activate the selected profile
Personalise
• to change the profile settings
Timed
• to set the profile to be active for a
certain time. When the time set for
the profile expires, the previous
profile that was not timed becomes
active.
Themes
A theme contains elements for
personalising your phone.
Select Menu > Settings > Themes and
from the following options:
Select theme
• Open the Themes folder, and select a
theme.
Theme downloads
• Open a list of links to download more
themes.
Tones
You can change the tone settings of the
selected active profile.
Select Menu > Settings > Tones. You can
find the same settings in the Profiles
menu.
If you select the highest ringing tone level,
the ringing tone reaches its highest level
after a few seconds.
12
Make it your phone 13
Lights
To activate or deactivate light effects
associated with different phone
functions, select Menu > Settings >
Lights.
Display
Select Menu > Settings > Display and
from the available options:
Wallpaper
• to add a background image for the
standby mode
Active standby
• to activate, organise, and personalise
the active standby mode
Standby font colour
• to select the font colour for the
standby mode
Navigation key icons
• to display the icons of the scroll key
shortcuts in the standby mode when
active standby is off
Notification details
• to display details in missed call and
message notifications
Transition effects
• to activate a smoother and more
organic navigation experience
Slide animation
• to display an animation and sound a
tone when you open or close the slide
Screen saver
• to create and set a screen saver
Power saver
• to dim the display automatically and
to display a clock when the phone is
not used for a certain time
Sleep mode
• to switch off the display automatically
when the phone is not used for a
certain time
Font size
• to set the font size for messaging,
contacts, and web pages
Operator logo
• to display the operator logo
Cell info display
• to display the cell identity, if available
from the network
My shortcuts
With personal shortcuts, you get quick
access to frequently used functions of
your phone.
Left and right selection keys
• To change the function assigned to
the left or right selection key, select
Menu > Settings > My shortcuts >
Left selection key or Right selection
key and the function.
In the standby mode, if the left selection
key is Go to, to activate a function, select
Go to > Options and from the following:
Select options
• to add or remove a function
13
14 Make it your phone
Organise
• to rearrange the functions
Other shortcuts
Select Menu > Settings > My shortcuts
and from the following options:
Navigation key
• to assign other functions from a
predefined list to the navigation key
(scroll key).
Active standby key
• to select the movement of the
navigation key to activate the active
standby mode
Assign dialling shortcuts
Create shortcuts by assigning phone
numbers to the number keys 3-9.
1 Select Menu > Contacts > Speed
dials, and scroll to a number key.
2 Select Assign, or, if a number has
already been assigned to the key,
select Options > Change.
3 Enter a number or search for a
contact.
Voice commands
Call contacts and use your phone by
speaking a voice command.
Voice commands are languagedependent.
• To set the language, select Menu >
Settings > Phone > Language
settings > Recognition lang. and
your language.
• To train the voice recognition to your
voice, select Menu > Settings >
Phone > Voice recognition > Voice
recog. training.
• To activate a voice command for a
function, select Menu > Settings >
Phone > Voice recognition > Voice
commands, a feature, and the
function.
indicates that the voice
command is activated.
• To activate the voice command, select
Add.
• To play the activated voice command,
select Play.
To use voice commands, see "Voice
dialling", p. 19.
To manage the voice commands, scroll to
a function, select Options and from the
following:
Edit or Remove
• to rename or deactivate the voice
command
Add all or Remove all
• to activate or deactivate voice
commands for all functions in the
voice commands list
Connect
Your phone provides several features to
connect to other devices to transmit and
receive data.
Bluetooth wireless technology
Bluetooth technology allows you to
connect your phone, using radio waves, to
14
Make it your phone 15
a compatible Bluetooth device within 10
metres (32 feet).
This device is compliant with Bluetooth
Specification 2.0 + EDR supporting the
following profiles: 2.0 + EDRgeneric
access, network access, generic object
exchange, advanced audio distribution,
audio video remote control, handsfree,
headset, object push, file transfer, dial-up
networking, service discovery application,
SIM access, and serial port. To ensure
interoperability between other devices
supporting Bluetooth technology, use
Nokia approved enhancements for this
model. Check with the manufacturers of
other devices to determine their
compatibility with this device.
Features using Bluetooth technology
increase the demand on battery power
and reduce the battery life.
Set up a Bluetooth connection
Select Menu > Settings >
Connectivity > Bluetooth and take the
following steps:
1 Select My phone's name and enter a
name for your phone.
2 To activate Bluetooth connectivity
select Bluetooth > On.
indicates
that Bluetooth is active.
3 To connect your phone with an audio
enhancement, select Connect audio
enhan. and the device that you want
to connect to.
4 To pair your phone with any
Bluetooth device in range, select
Paired devices > Add new device.
Scroll to a found device, and select
Add.
Enter a passcode (up to 16 characters)
on your phone and allow the
connection on the other Bluetooth
device.
If you are concerned about security, turn
off the Bluetooth function, or set My
phone's visibility to Hidden. Accept
Bluetooth communication only from
those you trust.
PC connection to the internet
Use Bluetooth technology to connect your
compatible PC to the internet without PC
Suite software. Your phone must have
activated a service provider that supports
internet access, and your PC has to suppo rt
Bluetooth personal area network (PAN).
After connecting to the network access
point (NAP) service of the phone, and
pairing with your PC, your phone
automatically opens a packet data
connection to the internet.
Packet data
General packet radio service (GPRS) is a
network service that allows mobile
phones to send and receive data over an
internet protocol (IP)-based network.
To define how to use the service, select
Menu > Settings > Connectivity >
Packet data > Packet data conn. and
from the following options:
When needed
• to set the packet data connection to
established when required by an
application. The connection will be
cut when the application is closed.
15
Loading...
