Nokia 7510 Supernova User Guide

FCC DRAFT

Issue 1

Nokia, Nokia Connecting People and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia t une is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http:// www.mpegla.com

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVI DED "A S IS". E XCEPT A S REQU IRED BY APPLI CABLE L AW, NO WARRAN TIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

Model number: 7510a-b

FCC DRAFT/Issue 1

Contents

Safety...........................................6

1. General information................7

About your device......................................7

Network services.......................................7

Access codes...............................................7

Configuration setting service...................8

My Nokia.....................................................8

Download content.....................................8

Helpful hints...............................................9

Software updates......................................9

Nokia support............................................9

Digital rights management....................10

2. Get started.............................10

Install SIM card and battery....................10

Insert a microSD card..............................11

Remove the memory card......................12

Change the covers...................................12

Charge the battery..................................12

Antenna....................................................13

Connect a USB cable................................13

Headset.....................................................13

Strap.........................................................14

Keys and parts.........................................14

Switch the phone on and off..................15

Navigate the menus................................15

Standby mode..........................................16

Flight mode..............................................17

Keypad lock..............................................18

Functions without a SIM card.................18

3. Calls.......................................18

Make a call................................................18

Answer and end a call ............................19

Dialling shortcuts....................................19

Voice dialling...........................................19

Options during a call...............................20

4. Write text..............................20

Text modes...............................................20

Traditional text input..............................20

Predictive text input...............................21

5. Messaging..............................21

Text and multimedia messages.............21

E-mail........................................................23

Flash messages........................................24

Nokia Xpress audio messages................24

Instant messaging...................................24

Info messages, SIM messages, and

service commands...................................25

Voice messages........................................25

Message settings.....................................25

6. Contacts.................................26

Manage contacts......................................26

Business cards..........................................27

Assign dialling shortcuts........................27

7. Call log ..................................27

8. Position log...........................27

9. Connectivity...........................28

Wi-Fi/WLAN connection..........................28

Bluetooth wireless technology..............30

Packet data..............................................31

USB data cable.........................................31

Synchronisation and backup..................32

Nokia PC Suite..........................................32

10. Settings...............................32

Profiles......................................................32

Themes.....................................................32

Tones........................................................33

Lights........................................................33

Display......................................................33

Date and time..........................................33

My shortcuts.............................................34

Call.............................................................34

Phone........................................................35

Voice commands.....................................35

Accessories...............................................36

Configuration...........................................36

Software updates over the air...............36

Security.....................................................37

Restore factory settings..........................38

11. Operator menu....................38

12. Gallery.................................38

Folders and files......................................38

Print images.............................................38

Share images and videos online............39

Memory card............................................39

13. Media...................................39

Camera and video....................................39

Media player.............................................40

Radio.........................................................42

Voice recorder..........................................43

Equaliser...................................................43

Stereo widening......................................44

14. Organiser.............................44

Alarm clock...............................................44

Calendar....................................................44

Maps..........................................................45

To-do list..................................................46

Notes.........................................................46

Calculator.................................................47

Countdown timer....................................47

Stopwatch................................................47

15. Applications.........................48

Launch an application.............................48

Download an application.......................48

Contents

Nokia battery authentication

guidelines.................................................52

Care and maintenance..............53

Disposal....................................................54

Additional safety

information...............................54

Small children..........................................54

Operating environment..........................54

Medical devices........................................55

Vehicles.....................................................55

Potentially explosive

environments...........................................56

Emergency calls.......................................56

Certification information (SAR)..............57

Index.........................................58

16. Web ....................................48

Connect to a service................................49

Web uploads............................................49

Appearance settings...............................49

Cache memory.........................................50

Browser security......................................50

17. SIM services.........................50

Enhancements...........................51

Battery.......................................51

Battery and charger information...........51

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

1. General information

About your device

The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, and 1900 MHz networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.

Warning: To use any features in this device, other than the alarm clock, the device

must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

Remember to make back-up copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

Network services

To use the device you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Using network services involves transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

Access codes

To set how your phone uses the access codes and security settings, select Menu > Settings > Security > Access codes.

General information

● The PIN (UPIN) code, supplied with the SIM (USIM) card, helps to protect the card against unauthorised use.

● The PIN2 (UPIN2) code, supplied with some SIM (USIM) cards, is required to access certain services.

● PUK (UPUK) and PUK2 (UPUK2) codes may be supplied with the SIM (USIM) card. If you enter the PIN code incorrectly three times in succession, you are asked for the PUK code. If the codes are not supplied, contact your service provider.

● The security code helps to protect your phone against unauthorised use. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your phone dealer.

● The barring password is required when using the call barring service to restrict calls to and from your phone (network service).

● To view or change the security module settings for the web browser, select Menu > Settings > Security > Security module sett..

Configuration setting service

To use some of the network services, such as mobile internet services, the multimedia messaging service (MMS), Nokia Xpress audio messaging, or remote internet server synchronisation, your phone needs the correct configuration settings. For more information on availability, contact your service provider or the nearest authorised Nokia dealer, or visit the support area on the Nokia website. See "Nokia support", p. 9.

When you have received the settings as a configuration message and the settings are not automatically saved and activated,

To save the settings, select Show > Save. If required, enter the PIN code supplied by the service provider.

Configuration settings received is displayed.

My Nokia

Receive free tips, tricks, and support for your Nokia phone, plus free trial content, interactive demonstrations, a personalised web page, and news about the latest Nokia products and services.

Get the most out of your Nokia phone and register to My Nokia today! For more information and availability in your region, see www.nokia.com/mynokia.

Download content

You may be able to download new content (for example, themes) to your phone (network service).

General information

Important: Use only services that you trust and that offer adequate security and

protection against harmful software. For the availability of different services and pricing, contact your service provider.

Helpful hints

If you have queries with your phone, or you are unsure how your phone should function, refer to the user guide. If this does not help, try the following:

● Reset the phone: switch off the phone, and remove the battery. After a few seconds, insert the battery, and switch on the phone.

● Restore the factory settings. See "Restore factory settings", p. 38.

● Update your phone software with the Nokia Software Updater application, if

available. See "Software updates", p. 9.

● Visit a Nokia website, or contact Nokia Care. See "Nokia support", p. 9.

If a query remains unresolved, contact your local Nokia Care point for repair options. Before sending your phone for repair, always back up or make a record of data in your phone.

Software updates

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. You may be able to request these updates through the Nokia Software Updater PC application. To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000, XP or Vista operating system, broadband internet access, and a compatible data cable to connect your device to the PC.

To get more information and to download the Nokia Software Updater application, visit www.nokia.com/softwareupdate or your local Nokia website.

If software updates over the air are supported by your network, you may also be able to request updates through the phone. See "Software updates over the air", p. 36.

Important: Use only services that you trust and that offer adequate security and

protection against harmful software.

Nokia support

Check www.nokia.com/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

Configuration settings service

Download free configuration settings such as MMS, GPRS, e-mail, and other services for your phone model at www.nokia.com/support.

Get started

Nokia PC Suite

You may find PC Suite and related information on the Nokia website at www.nokia.com/ support.

Nokia Care services

If you need to contact Nokia Care services, check the list of local Nokia Care contact centres at www.nokia.com/customerservice.

Maintenance

For maintenance services, check your nearest Nokia Care point at www.nokia.com/ repair.

Digital rights management

Content owners may use different types of digital rights management (DRM) technologies to protect their intellectual property, including copyrights. This device uses various types of DRM software to access DRM-protected content. With this device you can access content protected with WMDRM 10, OMA DRM 1.0, OMA DRM 1.0 forward lock, and OMA DRM 2.0. If certain DRM software fails to protect the content, content owners may ask that such DRM software's ability to access new DRM-protected content be revoked. Revocation may also prevent renewal of such DRM-protected content already in your device. Revocation of such DRM software does not affect the use of content protected with other types of DRM or the use of non-DRM-protected content.

Digital rights management (DRM) protected content comes with an associated activation key that defines your rights to use the content.

If your device has OMA DRM-protected content, to back up both the activation keys and the content, use the backup feature of Nokia PC Suite. Other transfer methods may not transfer the activation keys which need to be restored with the content for you to be able to continue the use of OMA DRM-protected content after the device memory is formatted. You may also need to restore the activation keys in case the files on your device get corrupted.

If your device has WMDRM-protected content, both the activation keys and the content will be lost if the device memory is formatted. You may also lose the activation keys and the content if the files on your device get corrupted. Losing the activation keys or the content may limit your ability to use the same content on your device again. For more information, contact your service provider.

2. Get started

Install SIM card and battery

Always switch the device off and disconnect the charger before removing the battery.

This phone is intended for use with a BL-5BT battery. Always use original Nokia batteries. See "Nokia battery authentication guidelines", p. 52.

Get started

The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

1. Slide the cover (1), and

remove it. Remove the battery (2).

2. Open the SIM card holder (3).

Insert the SIM card with the contact surface facing down into the holder (4). Close the SIM card holder (5).

3. Observe the battery contacts (6), and insert the battery

(7). Replace the back cover (8).

Insert a microSD card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

You phone supports microSD cards of up to 8 GB.

1. Remove the back cover.

2. Insert the card into the memory card slot with the

contact surface facing down, and press until it locks into place.

3. Replace the back cover.

Get started

Remove the memory card

Important: Do not remove the m emor y card in the midd le of an operation when

the card is being accessed. Removing the card in the m iddle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

You can remove or replace the memory card during phone operation without switching the device off.

1. Ensure that no application is currently accessing the memory card.

2. Remove the back cover.

3. Press the memory card slightly in to release the lock, and remove it.

4. Replace the back cover.

Change the covers

Note: Always switch off the power and disconnect the charger and any other

device before removing the covers. Avoid touching electronic components while changing the covers. Always store and use the device with the covers attached.

Remove covers

Slide the cover until it unlocks, and remove it.

Replace covers

Place the cover on the device, and slide it until it locks.

Charge the battery

Your battery has been precharged, but the charging levels may vary.

1. Connect the charger to a wall outlet.

Get started

2. Connect the charger to the device. During charging,

the reminder light flashes up about every 30 seconds.

3. When the battery is fully charged, disconnect the

charger from the device, then from the wall outlet.

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The charging time depends on the charger used. Charging a BL-5BT battery with the AC-3 charger takes approximately 2 hours 40 minutes while the phone is in the standby mode.

Antenna

Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.

The figure shows the antenna area marked in grey.

Connect a USB cable

Open the cover of the USB connector, and connect the USB cable to the device.

Headset

Warning: Listen to music at a moderate level. Continuous exposure to high

volume may damage your hearing. Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

Warning: When you use the headset, your ability to hear outside sounds may be

affected. Do not use the headset where it can endanger your safety.

Get started

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

Strap

Thread a strap as shown in the picture and tighten it.

Keys and parts

1 Earpiece 2 Display

3 Navi™ key; hereafter referred to as

scroll key

5 Call key 6 Keypad

7 Right selection key 8 Power/End key

4 Left selection key

Get started

9 Microphone 10 Charger connector

11 Reminder light 12 Camera lens

13 Camera flash 14 Hidden cover display

15 Mini USB cable connector 16 Wrist strap eyelet

17 Nokia AV Connector (2.5 mm) 18 Fold release button

19 Volume keys 20 Loudspeaker

Switch the phone on and off

To switch the phone on or off, press and hold the power key.

If the phone prompts for a PIN code, enter the code (displayed as ****).

If the phone prompts you for the time and date, enter the local time, select the time zone of your location in terms of the time difference with respect to Greenwich Mean Time (GMT), and enter the date. See "Date and time", p. 33.

When you switch on your phone for the first time, you may be prompted to get the configuration settings from your service provider (network service). For more information, refer to Connect to support. See "Configuration", p. 36, and "Configuration setting service", p. 8.

Navigate the menus

The phone offers you an extensive range of functions that are grouped into menus.

1. To access the menu, select Menu.

2. Scroll through the menu, and select an option (for example, Settings).

3. If the selected menu contains further submenus, select one (for example, Call).

4. If the selected menu contains further submenus, repeat step 3.

5. Select the setting of your choice.

6. To return to the previous menu level, select Back.

To exit the menu, select Exit.

To change the menu view, select Options > Main menu view. Scroll right, and select from the available options.

To rearrange the menu, select Options > Organise. Scroll to the menu item to be moved, and select Move. Scroll to where you want to move the menu item, and select

OK. To save the change, select Done > Yes.

Get started

Standby mode

When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.

Display

Signal strength of the cellular network ,or the UMA network

Battery charge status

3 Indicators

4 Name of the network or the operator logo

5 Clock

6 Display

7 Function of the left selection key

8 Function of the Navi key

9 Function of the right selection key

You may change the function of the left and right selection key. See "Left and right selection keys", p. 34.

Home screen

The home screen mode displays a list of selected phone features and information that you can directly access.

To activate or deactivate the home screen mode, select Menu > Settings > Display > Home screen > Home screen mode.

To organise and change the home screen mode, select Menu > Settings > Display > Home screen > Personalise view and from the available options.

To select the key that is used to activate the home screen mode, select Menu > Settings > Display > Home screen > Home screen key and from the available options.

Depending on the setting, in the home screen mode, scroll up or down to navigate in the list, and select Select, View, or Edit. The arrows indicate that further information is available. To stop navigation, select Exit.

Get started

Shortcuts in the standby mode

To access a list of numbers you have dialled, press the call key once. To call a number from the list, scroll to the number or name, and press the call key.

To open the web browser, press and hold 0.

To call your voice mailbox, press and hold 1.

You can use keys as shortcuts. See "Dialling shortcuts", p. 19.

Indicators

You have unread messages.

You have unsent, cancelled, or failed messages.

You have missed calls.

The keypad is locked.

The phone does not ring for incoming calls or text messages.

An alarm is set.

/ The phone is registered to the GPRS or EGPRS network.

/ The phone has an open GPRS or EGPRS connection.

/ The GPRS or EGPRS connection is suspended (on hold).

Bluetooth connectivity is turned on.

Wireless LAN connectivity is turned on.

/ A wireless connection or a UMA connection is active.

If you have two phone lines, the second phone line is selected.

All incoming calls are diverted to another number.

Calls are limited to a closed user group.

The currently active profile is timed.

Flight mode

Use the flight mode in radio sensitive environments—on board aircraft or in hospitals —to deactivate all radio frequency functions. You still have access to offline games, the calendar, and phone numbers. When the flight mode is active,

To activate or set up the flight mode, select Menu > Settings > Profiles > Flight > Activate or Personalise.

To deactivate the flight mode, select any other profile.

is displayed.

Calls

Make an emergency call in flight mode

Enter the emergency number, press the call key, and when Exit flight profile? is displayed, select Yes.

Warning: With the flight profile you cannot make or receive any calls, including

emergency calls, or use other features that require network coverage. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code. If you need to make an emergency call while the device is locked and in the flight profile, you may be also able to enter an official emergency number programmed in your device in the lock code field and select 'Call'. The device will confirm that you are about to exit flight profile to start an emergency call.

Keypad lock

To lock the keypad to prevent accidental keypresses, select Menu, and press * within

3.5 seconds.

To unlock the keypad, select Unlock, and press * within 1.5 seconds. If requested, enter the lock code.

To answer a call when the keypad is locked, press the call key. When you end or reject the call, the keypad locks automatically.

Further features are Automatic keyguard and Security keyguard. See "Phone", p. 35.

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.

Functions without a SIM card

Some functions of your phone may be used without inserting a SIM card, such as Organiser functions and games. Some functions appear dimmed in the menus and cannot be used.

3. Calls

You can make and receive phone calls using a mobile network or a wireless fidelity (WiFi) wireless local area network (WLAN). Wi-Fi is used for voice calls over the internet. See "Wi-Fi/WLAN connection", p. 28.

Make a call

You can make a call in several ways:

● Enter the phone number, including the area code, and press the call key.

+ 41 hidden pages
