Microsoft RM-384 User Manual
RM-384 User Guide
draft
©2008 Nokia. All rights reserved.
draft
Nokia, Nokia Connecting People, and Navi are trademarks or registered trademarks of Nokia
Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company
names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Includes RSA BSAFE cryptographic or security protocol software from RSA security.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information,
including that related to promotional, internal, and commercial uses, may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com
The availability of particular products and applications and services for these products may
vary by region. Please check with your Nokia dealer for details, and availability of language
options.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES
SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY
APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES TH E RIGHT TO REVISE THIS DOCUMENT OR
WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
Export controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
The third-party applications provided with your device may have been created and may be
owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the
copyrights or intellectual property rights to the third-party applications. As such, Nokia does
not take any responsibility for end-user support, functionality of the applications, or the
information in the applications or these materials. Nokia does not provide any warranty for
the third-party applications.
>.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED
draft
AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR
ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, ME RCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRDPARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
FCC NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC can require you to stop using your telephone if
such interference cannot be eliminated. If you require assistance, contact your local service
facility. This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation. Any changes or modifications not expressly approved by Nokia could
void the user's authority to operate this equipment.
xxxxxxx/Issue 1
Contents
draft
SAFETY ............................................................................................... 7
General information.......................................................................... 9
Access code ......................................................................................................................... 9
Software updates............................................................................................................... 9
Getting help...................................................................................................................... 10
1. Get started ................................................................................... 11
Insert battery and UIM card ........................................................................................ 11
MicroSD card.................................................................................................................... 13
Charge the battery.......................................................................................................... 14
Switch your device on or off ....................................................................................... 14
Antenna ............................................................................................................................. 15
Connect the headset ...................................................................................................... 15
Wrist strap ........................................................................................................................ 16
2. Your device................................................................................... 17
Keys and parts.................................................................................................................. 17
Standby mode .................................................................................................................. 19
Indicators and icons....................................................................................................... 20
Keyguard............................................................................................................................ 21
3. Call functions............................................................................... 22
Make and answer calls.................................................................................................. 22
Speed dialling................................................................................................................... 23
Loudspeaker...................................................................................................................... 23
4. Write text..................................................................................... 24
English input .................................................................................................................... 24
Enter special characters and punctuation marks .................................................. 25
5. Messaging .................................................................................... 26
Text messages .................................................................................................................. 26
Distribution lists.............................................................................................................. 28
Voice messages................................................................................................................ 28
Minibrowser messages .................................................................................................. 29
E-mail messages.............................................................................................................. 29
6. Contacts ....................................................................................... 32
Names ................................................................................................................................ 32
Contacts settings............................................................................................................. 32
draft
Groups................................................................................................................................. 33
Speed dials ........................................................................................................................ 33
Service numbers............................................................................................................... 34
My number........................................................................................................................ 34
Delete contacts entries .................................................................................................. 34
Move contacts.................................................................................................................. 34
Copy contacts................................................................................................................... 34
7. Log ............................................................................................... 35
8. Settings........................................................................................ 36
Profiles................................................................................................................................ 36
My homescreen................................................................................................................ 36
Display ................................................................................................................................ 37
Themes................................................................................................................................ 39
Tones ................................................................................................................................... 39
Date and time settings .................................................................................................. 40
My shortcuts..................................................................................................................... 41
Call settings ...................................................................................................................... 42
Phone settings.................................................................................................................. 43
Carrier settings................................................................................................................. 44
Connectivity...................................................................................................................... 44
Accessory settings........................................................................................................... 46
Security settings .............................................................................................................. 47
Application settings........................................................................................................ 47
Network settings ............................................................................................................. 48
Network services.............................................................................................................. 48
Restore factory settings................................................................................................. 48
Phone details .................................................................................................................... 49
9. Gallery.......................................................................................... 50
Gallery folders .................................................................................................................. 51
Memory card..................................................................................................................... 51
Use files to personalise your device ........................................................................... 51
Work with files................................................................................................................. 51
10.Camera ....................................................................................... 53
Capture an image............................................................................................................ 53
Record a video clip.......................................................................................................... 53
Camera options................................................................................................................ 54
11.Media ......................................................................................... 56
Music player...................................................................................................................... 56
Media player..................................................................................................................... 58
draft
Stereo FM radio............................................................................................................... 59
Recorder............................................................................................................................. 60
Equaliser ............................................................................................................................ 60
Stereo widening .............................................................................................................. 60
12.Organiser .................................................................................... 61
Alarm clock ....................................................................................................................... 61
Calendar............................................................................................................................. 61
Notes .................................................................................................................................. 62
To-do list ........................................................................................................................... 62
Calculator.......................................................................................................................... 62
Countdown timer............................................................................................................ 63
Stopwatch......................................................................................................................... 64
13.Voice commands ........................................................................ 65
Activate and use voice commands............................................................................. 65
Voice Command Settings.............................................................................................. 65
14.Applications................................................................................ 68
15.Minibrowser................................................................................ 69
16.Extras .......................................................................................... 70
Games................................................................................................................................. 70
Converter........................................................................................................................... 70
World clock....................................................................................................................... 70
17.Accessories.................................................................................. 71
18.Battery and charger information.............................................. 72
Nokia battery authentication guidelines ................................................................. 73
Care and maintenance .................................................................... 75
Additional safety information........................................................ 77
Index................................................................................................. 82
SAFETY
draft
SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could
affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near
medical equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
■ About your device
The wireless device (RM-384) described in this guide is approved for use on the
CDMA 800 and 1900 MHz networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect local customs,
privacy and legitimate rights of others, including copyrights.
Copyright protection may prevent some images, music, and other content from
being copied, modified, or transferred.
7
SAFETY
draft
Your device may have preinstalled bookmarks and links for third-party internet
sites. You may also access other third-party sites through your device. Thirdparty sites are not affiliated with Nokia, and Nokia does not endorse or assume
liability for them. If you choose to access such sites, you should take precautions
for security or content.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
Remember to make back-up copies or keep a written record of all important
information stored in your device.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
■ Network services
To use the device you must have service from a wireless service provider. Many of
the features require special network features. These features are not available on
all networks; other networks may require that you make specific arrangements
with your service provider before you can use the network services. Using
network services involves transmission of data. Check with your service provider
for details about fees in your home network and when roaming in other
networks. Your service provider can give you instructions and explain what
charges will apply. Some networks may have limitations that affect how you can
use network services. For instance, some networks may not support all languagedependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device
menu. Your device may also have a special configuration such as changes in
menu names, menu order, and icons. Contact your service provider for more
information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as media and browser messages
require network support for these technologies.
8
General information
draft
General information
Congratulations on your purchase of the Nokia mobile device. It
provides several functions for practical daily use, such as a hands-free
loudspeaker, an alarm clock, a calculator, a calendar, and more. Your
device can connect to a PC, laptop, or other device using a data cable. To
personalise it, you can set your favourite ringing tones, wallpaper,
screensaver, and other features.
■ Access code
The PIN code protects your UIM card from unauthorised access. The PIN
code can be 4 to 8 digits in length. The default PIN code may vary
depending on your wireless service provider.
After three successive incorrect entries, the PIN code is blocked. To
unblock it, you must enter your Personal Unblocking Key (PUK) code.
To configure access code settings, select Menu > Settings > Security,
enter your default lock code, select OK and from the available options.
If you forget the code and your device is locked, your device will require
service and additional charges may apply. For more information, contact
a Nokia Care point or your device dealer.
■ Software updates
If software updates over the air are supported by your network, you may
also be able to request updates through the device. See "Phone
settings", p. 43.
Downloading software updates may involve the transmission of large
amounts of data through your service provider’s network. Contact your
service provider for information about data transmission charges.
Make sure that the device battery has enough power, or connect the
charger before starting the update.
9
General information
draft
Warning: If you install a software update, you cannot use the
device, even to make emergency calls, until the installation is
completed and the device is restarted. Be sure to back up data
before accepting installation of an update.
■ Getting help
Nokia support on the web
Check www.nokia.com/support or your local Nokia website for the latest
guides, additional information, downloads, and services related to your
Nokia product.
10
1. Get started
draft
■ Insert battery and UIM card
Remove the back cover and battery
Note: Always switch off the power and disconnect the charger
and any other device before removing the cover. Avoid touching
electronic components while changing the cover. Always store
and use the device with the cover attached.
1. Press the back cover release
button on the top of the device.
2. Lift the back cover off carefully.
Get started
3. Lift the battery up from its
compartment.
11
Get started
draft
Install the UIM card
The user identity module (UIM) card can be easily damaged by
scratching or bending, so be careful when handling, inserting, or
removing it. The UIM card slot is located under the battery. Keep the
UIM card out of the reach of small children.
1. Slide forward the card holder and lift it from the holder.
2. Hold the bevelled corner of the
UIM card facing up and aligned
with the bevelled corner of the
card holder.
3. Insert the UIM card into the
holder with the gold-coloured
contacts facing down, matching
up with the gold-coloured
contacts on the device.
4. Slide back the card holder and
lock it into place.
Replace the battery and back cover
1. Insert the battery, gold-coloured
contact end first, into the battery
slot.
2. Push down on the other end of the
battery to snap it into place.
12
Get started
draft
3. Replace the back cover so that the
cover tabs align with the slots in
the device. Press the cover down
gently until it clicks into place.
■ MicroSD card
Use only compatible microSD cards approved by Nokia for use with this
device. Your device supports microSD cards up to 32GB. Nokia uses
approved industry standards for memory cards, but some brands may
not be fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
To insert the microSD card:
1. Remove the back cover.
2. Lift open the microSD holder
cover.
3. Slide the card into the holder
carefully with the gold-coloured
contacts facing down, and close
the cover.
4. Replace the cover.
13
Get started
draft
Important: Do not remove the memory card in the middle of an
operation when the card is being accessed. Removing the card in
the middle of an operation may damage the memory card as well
as the device, and data stored on the card may be corrupted.
■ Charge the battery
Your battery has been precharged, but
the charging levels may vary.
1. Connect the charger to a wall
outlet.
2. Connect the charger to the device.
You can use your device while it is
charging.
3. When the battery is fully charged,
disconnect the charger from the
device, then from the wall outlet to
save energy.
■ Switch your device on or off
1. Press and hold the end key for at
least 4 seconds.
2. Enter the lock code or PIN code, if
necessary, and select OK. See "Security
settings", p. 47.
14
Get started
draft
■ Antenna
Your device may have internal and
external antennas. As with any radio
transmitting device, avoid touching
the antenna area unnecessarily while
the antenna is transmitting or
receiving. Contact with such an
antenna affects the communication
quality and may cause the device to
operate at a higher power level than
otherwise needed and may reduce the
battery life.
■ Connect the headset
Do not connect products that create an output signal as this may cause
damage to the device. Do not connect any voltage source to the Nokia
AV Connector.
When connecting any external device or any headset, other than those
approved by Nokia for use with this device, to the Nokia AV connector,
pay special attention to volume levels.
A compatible headset may be purchased with your device or separately
as an accessory. See "Accessory settings", p. 46.
1. Plug the headset connector into the
connector on the side of your device.
appears on the screen.
2. Position the headset on your ear.
With the headset connected, you can
make, answer, and end calls as usual.
15
Get started
draft
Warning: When you use the headset, your ability to hear
outside sounds may be affected. Do not use the headset where
it can endanger your safety.
■ Wrist strap
Note: The wrist strap does NOT come in the box.
Thread the wrist strap, and tighten it.
16
2. Your device
draft
■ Keys and parts
1. Earpiece
2. Display screen
3. Right selection key
4. Navi™ key; hereafter
referred to as scroll key
5. End key
6. Keypad
7. Silent key — Press and
hold to turn on the Silent
profile.
8. Wireless internet key —
Press and hold to access
internet services.
9. Radio key — Press and
hold to turn on the radio.
10.Call key
11.Middle selection key
12.Left selection key
Your device
17
Your device
draft
13.Voice command key
14.Headset connector
15.Charger/USB port
16.Microphone
17.Power button
18.Back cover release
button
19.Camera lens
20.Camera flash
21.Open the media keys
under the 2-way slide.
Rewind key — Press to
play the previous song
in your playlist, or press
and hold to rewind
through the current
song.
22.Play/Pause key — Press
to play or pause a song
in your playlist.
23.Fast forward key —
Press to play the next
song in your playlist, or
press and hold to fastforward through the
current song.
18
Your device
draft
24.Volume/Zoom key — Press to control audio volume or to zoom when
you are using the camera.
25.Camera button
26.Microphone
27.Wrist strap eyelet
■ Standby mode
Depending on your wireless service provider and the model number of
your device, some or all of the following indicators and shortcut keys
may be available in the standby mode.
Home screen
The home screen indicates that your device
is in the standby mode.
1. Signal strength — The number of bars
indicates the strength of the signal
received by the device.
2. Battery strength — Four bars indicate a
fully charged battery.
3. Time — The time of day is displayed.
4. The right selection key — Press the right
selection key to access your contacts list.
5. The middle selection key — Press the
middle selection key to access the main
menus.
6. The left selection key — Press the left selection key to access a list of
your favourite applications. To add items to the list, select Add and
from the available options.
7. Active standby — See "Active standby", p. 20.
19
Your device
draft
Active standby
The active standby displays a list of selected device features and
information that you can directly access, such as application shortcuts,
information from the radio and music player, calendar events, and a
customisable note.
To switch active standby on or off, select Menu > Settings > Display >
Active standby > Active standby mode > On or Off.
To view or customise the active standby key, see "Configure active
standby", p. 37. In the standby mode, select the active standby key to
activate the navigation, then scroll up or down in the list, and choose
Select or View. To stop navigation, select Exit. To organise and change
the active standby, select Options and from the available options. If no
keys are pressed in a certain time, the device automatically deactivates
the navigation.
■ Indicators and icons
Depending on your wireless service provider and the model number of
your device, some or all of the following indicators and icons may be
available in the standby mode and active standby mode.
An alarm is set. See "Alarm clock", p. 61.
A headset is connected to the device. See "Accessory settings", p.
46.
Your device keypad is locked. See "Keyguard", p. 21.
The loudspeaker is on.
Your device is set to the Silent profile. See "Profiles", p. 36.
The stopwatch timer is running in the background.
You have new text messages. See "Text messages", p. 26.
You have new voice messages. See "Voice messages", p. 28. This
icon shows only when the network supports this function.
You have missed a call. See "Log", p. 35.
The countdown timer is running.
20
Your device
draft
The current profile is timed. See "Profiles", p. 36.
■ Keyguard
With the keyguard, you can lock the keypad to prevent accidental
keypresses. When the keypad is locked, it unlocks if you receive a call.
When the call ends, it is automatically locked again.
To set the keypad to lock automatically when the device is in the
standby mode and no function of the device has been used for a certain
time, select Menu > Settings > Phone > Automatic keyguard > On.
To lock the keypad manually, select Menu, and press * within 4 seconds.
When the keyguard is on, calls may be possible to the official emergency
number programmed into your device.
To unlock the keypad, select Unlock, and then press * within 4 seconds.
21
Call functions
draft
3. Call functions
■ Make and answer calls
Make a call
To make a call, enter the phone number, including the country code and
area code, if necessary. To delete a character, press Clear. Press the call
key to call the number. Use the volume keys to adjust the volume of the
earpiece or headset during the phone call. To end the call, press the end
key.
Use voice commands to make a call
To start voice dialling, press the voice command key. If a compatible
headset with a headset key is attached, press and hold the headset key
to start voice dialling. A short tone sounds and the device prompts you
to say a command. Say clearly the name or number that is saved in your
contacts list. After about 2.5 seconds, the device dials the number. If the
recognised contact was not correct, press the end key to end the call,
and try again. See "Activate and use voice commands", p. 65.
Make a conference call
Conference calling (network service) allows you to take part in a
conference call with two other participants. During a call, to make a call
to a new participant, select Options > New call. Enter the number you
want, and press the call key. When the new call is answered, press the
call key to connect the calls. To end the conference call, select
Options > End all calls, or press the end key.
Answer or reject a call
To answer an incoming call, press the call key. To reject the call without
answering, press the end key. To reject the call and send the caller a text
message, select Send msg > Send to send the default message (see "Call
22
Call functions
draft
settings", p. 42), or Options and from the available options to send a
different message.
■ Speed dialling
Press and hold the assigned number key, 2-9, to start speed dialling one
of your contacts.
To use this feature, you need:
— Assign a speed dialling number key to the desired contact, see "Speed
dials", p. 33.
— Turn on the speed dial feature, see "Call settings", p. 42.
■ Loudspeaker
You can use your device as a loudspeaker during a call.
Warning: Do not hold the device near your ear when the
loudspeaker is in use, because the volume may be extremely
loud.
To activate the loudspeaker during a call, select Loudsp., and close the
fold.
To deactivate the loudspeaker during a call, open the fold, and select
Normal.
The loudspeaker is deactivated automatically when a call (or a call
attempt) ends or when certain accessories are connected.
23
Write text
draft
4. Write text
■ English input
To enter English, you can use either standard or predictive English input.
To switch between the standard English and predictive English input
modes, select Options > Prediction options > Prediction > On or Off.
In the standard English input mode, press # to switch between
uppercase , lowercase , and sentence case .
In the predictive English input mode, press # to switch between
lowercase , and sentence case .
To enter a number, press and hold # and select Number mode.
Standard English input
• Press a number key from 2 to 9 to enter the first letter on the key,
twice to enter the second letter, and so on.
If the next letter is located on the same key as the current one, wait
until the cursor appears.
•Press Clear to delete one letter to the left of the cursor. Press and
hold Clear to delete letters quickly.
• To insert a space, press 0.
Predictive English input
With predictive English input, you can use the built-in dictionary when
writing, and add new words to it. You can use predictive English input
only when the writing language is English.
1. Start writing a word using the keys from 2 to 9. Press each key once
for each letter.
24
Write text
draft
The following example shows what is displayed when you write
"Nokia" using predictive English input. Press 6-6-5-4-2.
2. Press 0 to confirm a word and insert a space after it.
If the word is not correct, press * repeatedly until the desired word
appears, and then confirm.
If * appears, enter an additional key to make a match with the builtin dictionary.
If the ? character is displayed after the word, the word you intend to
write is not in the dictionary. To add the word to the dictionary, select
Spell. Enter the word using standard English input, and select Save.
■ Enter special characters and punctuation marks
If you are using the standard English or number mode, press * to view
the list of special characters and punctuation marks. Scroll to the one
you want, and select Use.
If you are using the standard English input mode, press 1 repeatedly to
enter frequently used punctuation marks.
25
Loading...
