Nokia xxx User Guide

DRAFT AUG-12

DECLARATION OF CONFORMITY

www.nokia.com/phones/declaration_of_conformity/.

Nokia, Nokia Connecting People, Nokia Original Enhanc ements logos, Navi, and Nokia Care are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and

Hereby, NOKIA CORPORATION declares that this RM-356 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at

company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Symbian OS are trademarks of Symbian Ltd.

This software is based in part of the work of the FreeType Team. This product is covered by one or more of the following patents: United States Patent 5,155,805, United States Patent 5,325,479, United States Patent 5,159,668, United States Patent 2232861 and France Patent 9005712.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http:// www.mpegla.com

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPL IED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

Reverse engineering of any software in the Nokia device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on Nokia's representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties, damages and liabilities of Nokia's licensors.

The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

DRAFT AUG-12

Contents

Safety...........................................6

About your device......................................6

Network services.......................................7

1. Find help..................................8

Instructions inside - In-device

help.............................................................8

Get started..................................................8

Accessibility solutions...............................8

Extended user guide.................................8

Software updates......................................8

Access codes...............................................9

2. Your device..............................9

Memory card............................................10

Antenna locations...................................10

Contacts bar.............................................11

Offline profile...........................................11

Sensor settings........................................12

Headset.....................................................12

Remove the SIM card...............................13

3. Make calls..............................13

Voice calls ................................................13

4. Write text..............................14

On-screen keyboard................................14

Handwriting recognition........................15

On-screen keypad....................................15

Touch input settings...............................16

5. Messaging..............................17

Messaging main view.............................17

Write and send messages.......................17

6. Personalise your device........18

Profiles......................................................19

Modify the main menu............................19

7. Music player...........................19

Play a song or a podcast.........................20

Music menu..............................................20

Playlists.....................................................21

Transfer music from a computer...........21

8. Gallery...................................21

View images and videos.........................21

Organise images and videos..................22

9. Camera...................................22

Activate the camera................................22

Image capture.........................................22

Video recording.......................................25

10. Positioning (GPS).................26

About GPS.................................................26

Assisted GPS (A-GPS)................................27

Hold your device correctly......................27

11. Connectivity.........................27

Wireless LAN............................................27

12. Share online........................28

Share online.............................................28

Subscribe to services...............................29

Manage your accounts............................29

Create a post............................................29

Post files from Gallery.............................30

13. Nokia Video Centre..............30

View and download video clips.............30

Video feeds...............................................31

My videos..................................................31

Transfer videos from your PC.................32

Video centre settings..............................32

14. Web browser.......................32

Browse the web.......................................32

Browser toolbar.......................................33

Bookmarks...............................................34

Empty the cache......................................35

Connection security.................................35

15. Office applications...............35

Notes.........................................................35

Converter..................................................35

Enhancements...........................37

Battery.......................................37

Battery and charger information...........37

Nokia battery authentication

guidelines.................................................38

Care and maintenance..............39

Recycle......................................................40

Additional safety

information...............................40

Small children..........................................40

Operating environment..........................40

Medical devices........................................40

Vehicles.....................................................41

Potentially explosive

environments...........................................42

Emergency calls.......................................42

CERTIFICATION INFORMATION

(SAR)..........................................................42

Index.........................................44

Contents

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

About your device

The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, 1900 and UMTS 900, 2100 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.

Safety

Warning: To use any features in this device, other than the alarm clock, the device

must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

Remember to make back-up copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

The images in this guide may differ from your device display.

Network services

To use the device you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Using network services involves transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as such as MMS, browsing, and e- mail, require network support for these technologies.

1. Find help

For local services and warranty information, please refer to the separate booklet. For more information on access codes, settings, battery power, and freeing memory,

see the extended user guide on the product support pages of the Nokia website.

Instructions inside - In-device help

Your device contains instructions to help you use it.

When an application is open, to access the help text for the current view, select

Options > Help. To open help from the main menu, select Menu > Help, and the

relevant application.

When you are reading the instructions, to change the size of the help text, select

Options > Decrease font size or Increase font size.

You can find links to related topics at the end of the help text. If you select an underlined word, a short explanation is displayed. Help uses the following indicators: link to a related help topic.

When you are reading the instructions, to switch between help and the application that is open in the background, press and hold the menu key, and select from the list of open applications.

shows a link to the application being discussed.

Get started

See the quick start guide for keys and parts information, instructions for setting up the device and for other essential information.

Accessibility solutions

Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. For more information, visit the Nokia website at www.nokiaaccessibility.com.

shows a

Extended user guide

An extended version of this user guide is available on the product support pages of the Nokia website. Some applications or functions are explained only in the extended user guide.

Software updates

Nokia may produce software updates that offer new features, enhanced functions, and improved performance. You may be able to request these updates through the Nokia Software Updater PC application. Software updates may not be available for all products or their variants. Not all operators may endorse the latest software versions available.

Your device

To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000, XP, or Vista operating system, broadband internet access, and a compatible data cable to connect your device to the PC.

Warning: If you install a software update, you cannot use the device, even to

make emergency calls, until the installation is completed and the device is restarted. Be sure to back up data before accepting installation of an update.

To get more information and to download the Nokia Software Updater application, visit www.nokiausa.com/softwareupdate in the United States or www.nokialatinoamerica.com/nsu in Latin America.

If software updates over the air are supported by your network, you may also be able to request updates through the device.

Tip: To check the software version in your device, select Menu > Ctrl. panel, and Phone > Phone mgmt. > Device updates.

Access codes

If you forget any of the access codes, contact your service provider.

● Personal identification number (PIN) code — This code protects your SIM card against unauthorised use. The PIN code (4 to 8 digits) is usually supplied with the SIM card. After three consecutive incorrect PIN code entries, the code is blocked, and you need the PUK code to unblock it.

● UPIN code — This code may be supplied with the USIM card. The USIM card is an enhanced version of the SIM card and is supported by UMTS mobile phones.

● PI N2 co de — Th is c ode (4 to 8 digi ts) is sup pli ed wit h so me SIM card s, a nd is r equ ir ed to access some functions in your device.

● Lock code (also known as security code) — The lock code (5 digits) helps you to protect your device against unauthorised use. The preset code is 12345. You can create and change the code, and set the device to request the code. Keep the new code secret and in a safe place separate from your device. If you forget the code and your device is locked, your device will require service and additional charges may apply. For more information, contact a Nokia Care point or your device dealer.

● Personal Unblocking Key (PUK) code and PUK2 code — These codes (8 digits) are required to change a blocked PIN code or PIN2 code, respectively. If the codes are not supplied with the SIM card, contact the operator whose SIM card is in your device.

● UPUK code — This code (8 digits) is required to change a blocked UPIN code. If the code is not supplied with the USIM card, contact the operator whose USIM card is in your device.

2. Your device

Model number: xxx. Hereinafter referred to as xxx.

Your device

Memory card

Use only compatible microSD and microSDHC cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Insert the memory card

A memory card may be already inserted in the device. If not, do the following:

1. Open the memory card slot door.

2. Insert a compatible memory card in the slot. Push the card in. You can hear a click when the card locks into place.

3. Close the memory card slot door. Ensure that the door is properly closed.

Remove the memory card

Important: Do not remove the memory card in the middle of an operation when

the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

1. If the device is switched on, before you remove the card, press the power key, and select Remove memory card.

2. When Removing memory card will close all open applications. Remove

anyway? is displayed, select Yes. All applications are closed.

3. When Remove memory card and press 'OK' is displayed, open the cover of the memory card slot.

4. Press the memory card to release it from the slot.

5. Pull out the memory card. If the device is switched on, select OK.

Antenna locations

Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may

Your device

cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.

Cellular antenna

Bluetooth and WLAN antenna

Contacts bar

To add a contact to your home screen in contact bar mode, select and either select a contact from your contacts, or create a new contact, and add a photo to the contact information.

To communicate with your contact, select the contact and from the following:

●

— make a phone call — Send a message

●

— Modify contact information

●

To view the communication events with a contact, select a contact. Select a communication event to open log application.

To close the view, select

Offline profile

To activate the offline profile, press the power key briefly, and select Offline. The offline profile lets you use the device without connecting to the wireless network.

When you activate the offline profile, the connection to the wireless network is turned

Your device

off, as indicated by in the signal strength indicator area. All wireless RF signals to and from the device are prevented. If you try to send messages, they are placed in the outbox to be sent later.

When the offline profile is active, you can use your device without a SIM card.

Important: In the offline profile you cannot make or receive any calls, or use

other features that require cellular network coverage. Calls may still be possible to the official emergency number programmed into your device. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code.

To leave the offline profile, press the power key briefly, and select another profile. The device re-enables wireless transmissions (providing there is sufficient signal strength).

Sensor settings

When you activate the sensors in your device, you can control certain functions by turning the device.

Select Menu > Ctrl. panel. Select Phone > Sensor settings and from the following:

● Sensors — Activate the sensors.

● Turning control — Mark Silencing calls and Snoozing alarms to silence calls and

snooze alarms by turning your device so that the display faces down. Mark Auto-

rotate display to rotate the display content automatically when you turn the device

on its left side or back to a vertical position.

Headset

You can connect a compatible headset or compatible headphones to your device. You may need to select the cable mode.

Warning: When you use the headset, your ability to hear

outside sounds may be affected. Do not use the headset where it can endanger your safety.

Some headsets come in two parts, a remote control unit and headphones. A remote control unit has a microphone and keys to answer or end a phone call, adjust the volume, and play music or video files. To use the headphones with a remote control unit, connect the unit to the Nokia AV Connector in the device, then connect the headphones to the unit.

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

When connecting any external device or any headset, other than

Make calls

those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Remove the SIM card

1. Remove the back cover by lifting it from the bottom end of the device.

2. Remove the battery.

3. Open the SIM card slot door. Place the tip of the stylus in the opening under the battery, and push the SIM card sideways to slide it out of the slot. Pull the SIM card out.

4. Replace the battery and the back cover.

3. Make calls

For more information on different call types, options during calls, speed dialling, voice dialling, call waiting, video sharing, and log, see the extended user guide on the product support pages of the Nokia website.

Voice calls

1. In the home screen, open the dialler, and enter the phone number, including the area code. To remove a number, select C.

For international calls, select * twice for the + character (which replaces the international access code), and enter the country code, area code (omit the leading zero if necessary), and phone number. The + character as a replacement for the international access code may not work in all regions. In this case, enter the international access code directly.

2. To make the call, press the call key.

3. To end the call (or to cancel the call attempt), press the end key. Pressing the end key always ends a call, even if another application is active.

Write text

To make a call from Contacts, select Menu > Contacts. Scroll to the desired name. Or, tap the search field to enter the first letters of the name, and scroll to the name. To call the contact, press the call key. If you have saved several numbers for a contact, select the desired number from the list, and press the call key.

4. Write text

You can enter letters, numbers, and special characters in several different ways. The virtual keyboards allow you to tap characters with the stylus or your fingers. Handwriting recognition allows you to write characters directly onto the screen using the stylus as a pen.

To enter letters, numbers, and special characters, tap any text input field. Your device can complete words based on the built-in dictionary for the selected text

input language. The device also learns new words from your input.

On-screen keyboard

To use the on-screen keyboard, tap on the keys of the keyboard with the stylus or with your fingers when using the full-screen keyboard.

● Close key (1) - Closes the on-screen keyboard view.

● Input menu key (2) - Opens touch input options menu,

which includes commands such as Writing language.

● On-screen keyboard (3)

● Shift key and caps lock (4) - Allows you to enter an

uppercase character in the on-screen keyboard mode when you write in lowercase. When you tap this key in the handwriting recognition mode, the last lowercase character switches to uppercase, and vice versa. You can toggle caps lock on by tapping the key twice and the key will have a line under it.

● Numbers and symbols key (5) - Toggles between numbers, most commonly used special characters and the alphabet characters in the on-screen keyboard area.

● Character accents key (6) - Opens a pop-up view, in which you can select language character accents.

● Space bar (7) - Inserts a space.

● Enter key (8) - Moves the cursor to the next row or text input field. Additional functions

are based on the current context (for example, in the web address field of the web browser, it acts as a go button).

● Move key (9) - Moves the touch input window. Drag the key to move the touch input window around the screen.

● Backspace key (10) - Deletes the character to the left of the cursor.

+ 31 hidden pages
