RM-328 User Guide

F T

D R

RM-328_FCC-draft_en_1.fm Page 2 Tuesday, March 11, 2008 9:35 AM

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this RM-328 product is in

0434

Nokia, Nokia Connecting People, N-Gage, Navi and Visual Radio are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCID ENTAL, CONSEQUENTIAL O R INDIRECT DAMAG ES HOWSOEVE R CAUSED.

TH E CONTE NTS O F THI S DO CUMENT ARE P ROVIDED "A S IS" . EXC EPT A S RE QUIR ED BY APPLICA BLE L AW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the

D R

F T

RM-328_FCC-draft_en_1.fm Page 3 Tuesday, March 11, 2008 9:35 AM

information in the applications or these materials. Nokia does not provide any warranty for the third-party applications.

BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRDPARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

The availability of particular products and applications and servi ces for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls

This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not c ause ha rmful interference, and (2) th is device must accept an y interference receiv ed, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

F T

D R

RM-328_FCC-draft_en_1.fm Page 4 Tuesday, March 11, 2008 9:35 AM

Contents

SAFETY.............................................. 6

Support ............................................. 8

Help ...................................................................... 8

Nokia support and contact information .... 8

1. Get started.................................... 9

Insert a (U)SIM card and battery ................. 9

MicroSD card ..................................................... 9

Charge the battery ........................................ 10

Switch the device on and off ..................... 10

Configuration settings ................................. 11

Transfer data................................................... 12

2. Your device ................................. 12

Keys and parts................................................ 12

Standby mode................................................. 13

Indicators......................................................... 14

Screen saver.................................................... 15

Menu................................................................. 15

Volume control............................................... 16

My own key..................................................... 16

Keypad lock (keyguard)................................ 16

Access codes ................................................... 16

Remote lock..................................................... 17

Download!........................................................ 17

My own............................................................. 18

Connect a compatible headset.................. 18

Connect a USB data cable .......................... 18

3. Call functions ............................. 18

Make a voice call........................................... 18

Answer or reject a call ................................. 20

Video calls........................................................ 21

Call settings..................................................... 21

Video sharing.................................................. 23

Log ..................................................................... 24

4. Positioning.................................. 25

About GPS........................................................ 25

Assisted GPS.................................................... 25

Set up GPS connection ................................ 25

Position requests............................................ 26

D R

Maps .................................................................. 27

Landmarks ........................................................ 31

GPS data........................................................... 32

5. Write text................................... 33

Traditional and predictive text input........ 33

Copy and delete text..................................... 34

6. Messaging .................................. 34

Write and send messages ............................ 34

Inbox.................................................................. 35

Service messages............................................ 35

E-mail................................................................ 36

Outbox............................................................... 37

Message reader............................................... 37

View messages on the SIM card................ 37

Cell broadcast ................................................. 37

Service commands......................................... 37

Messaging settings........................................ 38

F T

7. Contacts ..................................... 38

Save and manage contact information ... 38

Contact groups ............................................... 39

Add a ringing tone ......................................... 39

8. Gallery ........................................ 39

Main view......................................................... 39

Download files................................................ 40

Edit images ...................................................... 40

Edit video clips................................................ 40

Watch images and video clips on TV........ 41

Print images..................................................... 41

Print online ...................................................... 41

Share online..................................................... 42

9. Camera........................................ 43

Capture images............................................... 44

Record videos .................................................. 47

Camera settings.............................................. 48

10.Media ........................................ 49

Music player.................................................... 49

Nokia Podcasting ........................................... 51

FM Radio........................................................... 53

RM-328_FCC-draft_en_1.fm Page 5 Tuesday, March 11, 2008 9:35 AM

RealPlayer........................................................ 54

Flash Player..................................................... 55

Recorder........................................................... 55

11.Internet...................................... 55

Browse the web.............................................. 55

Search ............................................................... 58

12.Personalisation.......................... 58

Themes.............................................................. 58

Profiles.............................................................. 58

13.Time management .................... 59

Clock.................................................................. 59

Calendar ........................................................... 59

14.Office applications ................... 60

Active notes..................................................... 60

Calculator......................................................... 60

Converter.......................................................... 60

Mobile dictionary........................................... 61

Adobe Reader.................................................. 61

Quickoffice ...................................................... 62

15.Settings ..................................... 62

Voice commands............................................ 62

Phone settings................................................ 62

Speech............................................................... 64

D R

16.Data management .................... 65

Install or remove applications.................... 65

File manager.................................................... 66

Licences............................................................. 67

Device manager.............................................. 68

17.Connectivity.............................. 69

Data transfer ................................................... 69

PC Suite............................................................. 69

Bluetooth connectivity................................. 69

USB connection .............................................. 71

Remote synchronisation............................... 72

Push to talk...................................................... 72

Connection manager..................................... 74

18.Enhancements .......................... 74

19.Battery and charger information 74

Nokia battery authentication guidelines. 75

F T

Care and maintenance................... 76

Additional safety information ...... 77

Index ............................................... 81

RM-328_FCC-draft_en_1.fm Page 6 Tuesday, March 11, 2008 9:35 AM

SAFETY

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY C OMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERF ERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIF IED SERVICE

Only qualified personnel may install or repair this product.

F T

ENHANC EMENTS AND BAT TERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER- RESISTANCE

Your device is not water-resistant. Keep it dry.

■ About your device

The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, and 1900 and UMTS900 and 2100 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Your device supports several methods of connectivity. Like computers, your device may be exposed to viruses and other harmful content. Exercise caution with messages, connectivity requests, browsing, and downloads. Only install and use services and other software from trustworthy sources that offer adequate security and protection against harmful software, such as applications that are Symbian Signed or have passed the Java Verified

D R

™testing.

SAFETY

RM-328_FCC-draft_en_1.fm Page 7 Tuesday, March 11, 2008 9:35 AM

Consider installing antivirus and other security software on your device and any connected computer.

Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and 2003). Not all file formats can be viewed or modified.

Remember to make back-up copies or keep a written record of all important information stored in your device.

During extended operation, such as an active video call and high speed data connection, the device may feel warm. In most cases, this condition is normal. If you suspect the device is not working properly, take it to the nearest authorised service facility.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

■ Network services

To use the phone you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all languagedependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as web browsing, e-mail, push to talk, iand multimedia messaging, require network support for these technologies.

D R

F T

■ Battery removing

Always switch the device off and disconnect the charger before removing the battery.

SAFETY

RM-328_FCC-draft_en_1.fm Page 8 Tuesday, March 11, 2008 9:35 AM

Support

■ Help

Your device has context-sensitive help. To access help when an application is open, select Options > Help. To switch between help and the application that is open in the background, select and hold , and select from the list of open applications.

To open help from the main menu, select > Help > Help. Select an application to view a list of help topics, and select the related help text. To open a keyword list, select Options > Search.

■ Nokia support and contact information

Check www.nokia.com/support or your local Nokia website for the latest guides, additional information, downloads, and services related to your Nokia product.

On the website, you can get information on the use of Nokia products and services. If you need to contact customer service, check the list of local Nokia contact centres at www.nokia.com/customerservice.

For maintenance services, check your nearest Nokia service centre at www.nokia.com/repair.

F T

Software updates

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. You may be able to request these updates through the Nokia Software Updater PC application. To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000 or XP operating system, broadband internet access, and a compatible data cable to connect your device to the PC.

To get more information and to download the Nokia Software Updater application, visit www.nokia.com/softwareupdate or your local Nokia web site.

If software updates over the air are supported by your network, you may also be able to request updates through the device.

Downloading software updates may involve the transmission of large amounts of data through your service provider's network. Contact your service provider for information about data transmission charges.

Make sure that the device battery has enough power, or connect the charger before starting the update.

D R

Support

RM-328_FCC-draft_en_1.fm Page 9 Tuesday, March 11, 2008 9:35 AM

1. Get started

■ Insert a (U)SIM card and battery

This device uses BP-5M batteries.

1. To open the back cover of the device, with the back of the device facing you slide the cover toward the bottom of the device (1), and remove it (2). To remove the battery, lift it from the end (3).

2. Slide the (U)SIM card in the SIM card holder (4).

Make sure that the gold-coloured contact area on the card is facing downward on the device, and the bevelled corner faces toward the card holder slot.

3. Replace the battery (5). Replace the back cover (6).

F T

■ MicroSD card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Important: Do not remove the memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

Keep microSD cards out of the reach of small children.

You can extend the available memory with a microSD memory card. You can insert or remove a microSD card without switching the device off.

D R

Get started

RM-328_FCC-draft_en_1.fm Page 10 Tuesday, March 11, 2008 9:35 AM

Insert a microSD card

Note that the memory card may be supplied with the device, and may already be inserted.

1. Open the cover (1).

2. Place the microSD card in the slot with gold-coloured area facing down (2).

3. Push the card gently to lock it into place. Close tight the cover (3).

Remove a microSD card

Open the cover. Push the card gently to release it. Remove memory card and press

'OK' is displayed. Pull the card out, and select OK. Close the cover.

■ Charge the battery

1. Connect the charger to the wall socket.

2. Connect the charger plug to the charger connector in the device.

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The charging time depends on the charger and the battery used.

F T

■ Switch the device on and off

Press and hold the power key.

If the device asks for a PIN code, enter the PIN code, and select OK.

If the device asks for the lock code, enter the lock code, and select

OK. The factory setting for the lock code is 12345.

For more information about access codes, see ‘Access codes,’ p. 16.

To set the correct time zone, time, and date, select the country you are presently in, then enter the local time and date. See also ‘Clock,’ p. 59.

D R

Get started

RM-328_FCC-draft_en_1.fm Page 11 Tuesday, March 11, 2008 9:35 AM

My Nokia

My Nokia is a free service that sends you tips, tricks, and support for your Nokia device regularly as text messages. If My Nokia is available in your country and supported by your service provider, your device invites you to join the My Nokia service after you have set the time and the date.

Select the language for the service. If you change the language, the device restarts. To sign-up to My Nokia , select Accept and follow the instructions on the display.

To sign-up to My Nokia later, select > Applications > My Nokia.

After the invitation to join My Nokia, the Welcome application starts. With the Welcome application, you can access the following applications:

Sett. wizard — Configure connection settings. See ‘Settings wizard,’ p. 12.

Switch — Copy or synchronise data from other compatible devices.

Tutorial — Learn about the features of your device and how to use them. To start

the tutorial later, select > Help > Tutorial and a tutorial item.

To open Welcome later, select > Help > Welcome.

Antenna locations

Cellular antenna (1)

GPS antenna (2)

Bluetooth antenna (3)

Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.

D R

F T

■ Configuration settings

Before you can use multimedia messaging, push to talk, e-mail, synchronisation, streaming, and the browser, you must have the proper configuration settings on your device. Your device may automatically configure browser, multimedia messaging, access point, and streaming settings based on the SIM card used. If not, you can use the setting wizard application to configure the settings. You may receive the settings directly as a configuration message, which you can save to

Get started

RM-328_FCC-draft_en_1.fm Page 12 Tuesday, March 11, 2008 9:35 AM

your device. For more information on availability, contact your service provider or nearest authorised Nokia dealer.

When you receive a configuration message, and the settings are not automatically saved and activated, 1 new message is displayed. To save the settings, select

Show > Options > Save. You may need to enter a PIN code provided by the service

provider.

Settings wizard

The setting wizard application configures your device for operator and e-mail settings based on your service provider. Configuring other settings may also be possible.

To use these services, you may have to contact your service provider to activate a data connection or other services.

Select > Settings > Sett. wizard.

■ Transfer data

To transfer information, such as contacts, from your old device, see ‘Data transfer,’ p. 69.

F T

2. Your device

■ Keys and parts

Earpiece (1)

Secondary camera lens (2)

Display (3)

Left and right selection keys (4)

Menu key (5), hereafter described as "select "

Clear key (6)

Call key (7)

End key (8)

Number keys (9)

Navi™ scroll key, hereafter referred to as scroll key, and status light around it (10)

D R

Your device

RM-328_FCC-draft_en_1.fm Page 13 Tuesday, March 11, 2008 9:35 AM

GPS light (11)

My own key (12)

microSD card slot (13)

Microphone (14)

Micro USB connector (15)

Charger connector (16)

Nokia AV Connector (2.5 mm) (17)

Loudspeaker (18)

Camera flash (19)

Main camera lens (20)

Camera lens cover opening slide (21)

Power key (22)

Volume key (23)

Camera key (24)

F T

■ Standby mode

When you have switched on the device, and it is registered to a network, the device is in the standby mode and ready for use.

To open a list of most recently dialled numbers, press the call key.

To use the voice commands or voice dialling, press and hold the right selection key.

To change the profile, press the power key, and select a profile.

To start a connection to the web, press and hold 0.

To select the view for the standby mode, select > Settings > Phone sett. >

General > Personalisation > Standby mode > Standby theme.

Depending on the selected standby theme, you can select applications or events to add to a shortcut list in the standby mode or the scroll keys. To select the applications or events, select > Settings > Phone sett. > General >

Personalisation > Standby mode > Shortcuts.

D R

Offline profile

To quickly activate the offline profile, press the power key, and select Offline. To leave the offline profile, press the power key, and select another profile.

Your device

RM-328_FCC-draft_en_1.fm Page 14 Tuesday, March 11, 2008 9:35 AM

When the offline profile is active, all the connections to a cellular network are turned off. However, you can use your device without a SIM card, and listen to the radio or music using the music player. Remember to switch off your device when wireless phone use is prohibited.

Important: In the offline profile you cannot make or receive any calls, or use other features that require cellular network coverage. Calls may still be possible to the official emergency number programmed into your device. To make calls, you must first activate the phone function by changing profiles. If the device has been locked, enter the lock code.

■ Indicators

Icons

or — The device is connected to a UMTS or GSM network.

— HSDPA (network service) in the UMTS network is activated.

— The device is in the offline mode and not connected to a cellular network.

— A memory card is inserted in the device.

— You have unread messages in the inbox in Messaging.

— You received new e-mail in your remote mailbox.

— You have messages waiting to be sent in outbox.

— You have missed calls.

— Ringing type is set to Silent and Message alert tone and E-ma il alert tone are

set to Off.

— The device keypad is locked.

— The loudspeaker is activated.

— An alarm is active.

— All calls to the device are diverted to another number.

or — A headset or a loopset is connected to the device.

or or — A GPRS packet data connection is active, the connection is on

hold, or a connection is available.

or or — A packet data connection is active in a part of the network that supports EGPRS; the connection is on hold; a connection is available. Your device may not use EGPRS in the data transfer.

or or — A UMTS packet data connection is active; the connection is on hold; a connection is available.

D R

Your device

F T

RM-328_FCC-draft_en_1.fm Page 15 Tuesday, March 11, 2008 9:35 AM

or — Bluetooth connectivity is switched on; data is being transmitted using Bluetooth technology.

— A USB connection is active.

Other indicators may also be shown.

GPS light

The GPS light blinks when your device is trying to establish a GPS connection, and remains on when the GPS connection is established.

Status light

You can set the light around the scroll key to blink slowly to indicate the standby mode. The light turns on for a few second at intervals of approximately 20 seconds. To indicate missed events, the light blinks faster for an hour after the missed event.

To activate the light indicator, select > Settings > Phone sett. > General >

Personalisation > Standby mode > Status light > On.

■ Screen saver

To set the screen saver settings, select > Settings > Phone sett. > General >

Personalisation > Display > Screen saver. To set the timeout period after which

the screen saver is activated, select Screen saver time-out. To set for how long the screen saver is active, select Screen saver duration.

■ Menu

In the menu you can access the functions in your device. To access the main menu, select .

To open an application or a folder, scroll to it, and press the scroll key.

If you change the order of the functions in the menu, the order may differ from the default order described in this user guide.

To mark or unmark an item in applications, press #. To mark or unmark several consecutive items, press and hold #, and scroll up or down.

To change the menu view, select Options > Change Menu view and a view type.

To close an application or a folder, select Back and Exit as many times as needed to return to the standby mode, or select Options > Exit.

To display and switch between open applications, press and hold . Scroll to an application, and select it.

D R

Your device

F T

RM-328_FCC-draft_en_1.fm Page 16 Tuesday, March 11, 2008 9:35 AM

Leaving applications running in the background increases the demand on battery power and reduces the battery life.

■ Volume control

To adjust the earpiece or loudspeaker volume during a call or when listening to an audio file, press the volume keys. To activate or deactivate the loudspeaker during a call, select Loudsp. or Handset.

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

■ My own key

By default, the Maps application opens when you press the my own key. To set another application to open, select > Settings > Phone sett. > General > My

own k ey > My own key and an application.

■ Keypad lock (keyguard)

To lock the keypad in the standby mode, press the left selection key and * within

1.5 seconds. To set the device to automatically lock the keypad after a certain time, select > Settings > Phone sett. > General > Security > Phone and SIM

card > Keypad autolock period > User defined and the desired time.

To unlock the keypad, select Unlock, and press * within 1.5 seconds.

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.

F T

■ Access codes

To set how your device uses the access codes, select > Settings > Phone sett. >

General > Security > Phone and SIM card.

Lock code

The lock code (5 digits) helps to lock your device. The preset code is 12345. Change the code, and set the device to request the code.

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.

PIN codes

The personal identification number (PIN) code or the universal personal identification number (UPIN) code (4 to 8 digits) help to protect your SIM card. The (U)PIN code is usually supplied with the SIM card. Set the device to request the code each time the device is switched on.

D R

Your device

RM-328_FCC-draft_en_1.fm Page 17 Tuesday, March 11, 2008 9:35 AM

The PIN2 code may be supplied with the SIM card and is required for some functions.

The module PIN is required to access the information in the security module. The signing PIN is required for the digital signature. The module PIN and the signing PIN are supplied with the SIM card if the SIM card has a security module in it.

PUK codes

The personal unblocking key (PUK) code or the universal personal unblocking key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code, respectively. The PUK2 code is required to change a blocked PIN2 code.

If needed, contact your local service provider for the codes.

Barring password

The barring password (4 digits) is required when using call barring. You can obtain the password from your service provider. If the password is blocked, contact your service provider.

■ Remote lock

You can lock your device from another device using a text message. To enable your device to be locked remotely, and to define the message text to be used, select

> Settings > Phone sett. > General > Security > Phone and SIM card > Remote

phone locking. The message can be up to 20 characters long.

To lock your device, send the text message to your mobile phone number. To open your device later, select Unlock, and enter the lock code.

■ Download!

Download! (network service) is a mobile content shop available on your device.

With Download! you can discover, preview, buy, download, and upgrade content, services, and applications. The items are categorised under catalogs and folders provided by different service providers. The available content depends on your service provider.

Select > Applications > Download!.

Download! uses your network services to access the most up-to-date content. For information on additional items available through Download!, contact your service provider, or the supplier or manufacturer of the item.

D R

Your device

F T

RM-328_FCC-draft_en_1.fm Page 18 Tuesday, March 11, 2008 9:35 AM

■ My own

You can download applications to your device. To access the applications, select

> Applications > My own.

Important: Only install and use applications and other software from trusted sources, such as applications that are Symbian Signed or have passed the Java

Verified

■ Connect a compatible headset

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

■ Connect a USB data cable

Connect a compatible USB data cable to the USB connector.

To select the default USB connection mode or change the active mode, select > Settings >

Connectivity > USB > USB connection mode and

the desired mode. To set whether the default mode is activated automatically, select Ask on

connection > No.

testing.

F T

3. Call functions

D R

To adjust the volume during a call, press the volume keys.

■ Make a voice call

1. In the standby mode, enter the phone number, including the area code. Press

the clear key to remove a number.

For international calls, press * twice for the international prefix (the + character replaces the international access code), and enter the country code, area code (omit the leading zero if necessary), and phone number.

Call functions

RM-328_FCC-draft_en_1.fm Page 19 Tuesday, March 11, 2008 9:35 AM

2. To call the number, press the call key.

3. To end the call, or to cancel the call attempt, press the end key.

To make a call from Contacts, select > Contacts. Scroll to the desired name; or enter the first letters of the name, and scroll to the desired name. To call the number, press the call key.

To call a recently dialled number from the standby mode, press the call key.

Speed dialling

Speed dialling is a quick way to call frequently used numbers from the standby mode. You need to assign a phone number to the speed dialling keys 3 to 9 (the 1 and 2 keys are reserved for the voice and video call mailboxes), and set Speed

dialling to On.

To assign a phone number to a speed dialling key, select > Settings > Speed

dial. Scroll to a key icon, and select Assign. Select the contact and the relevant

speed dialling key. To change the number, select Options > Change.

To activate the speed dialling, select > Settings > Phone sett. > Phone > Call >

Speed dialling > On.

To call a speed dialling number, press and hold the speed dialling key until the call begins.

Call mailbox

To call your call mailboxes (network service), from the standby mode, press and hold 1 or 2. You can have call mailboxes for voice calls, video calls, and multiple phone lines.

To define the call mailbox number if no number is set, select > Settings > Call

mailbox. Scroll to Voice mailbox (or Video mailbox), and enter the corresponding

mailbox number. To change the call mailbox number, select Options > Change

number. Contact your service provider for the call mailbox number.

D R

F T

Voice dialling

A voice tag is added automatically to all entries in Contacts. Use long names, and avoid similar names for different numbers.

Make a voice dialling call

Voice tags are sensitive to background noise. Use voice tags in a quiet environment.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialling in all circumstances.

Call functions

RM-328_FCC-draft_en_1.fm Page 20 Tuesday, March 11, 2008 9:35 AM

1. In the standby mode, press and hold the right selection key.

If you are using a compatible headset with the headset key, press and hold the headset key.

2. When Speak now is displayed, speak the voice command clearly. The device

plays the voice command of the best match. After 1.5 seconds, the device dials the number; if the result is not the correct one, before dialling select another entry.

Make a conference call

Your device supports conference calls (network service) between a maximum of six participants, including yourself.

1. Make a call to the first participant.

2. To make a call to another participant, select Options > New call.

3. To create the conference call when the new call is answered, select Options >

Conference.

To add another person to the conference call, repeat step 2, and select

Options > Conference > Add to conference.

4. To end the conference call, press the end key.

■ Answer or reject a call

To answer a call, press the call key.

To mute the ringing tone, select Silence.

To reject the call, press the end key, or select Options > Reject. If you have activated Call divert > If busy, rejecting the call diverts the call.

To send a text message as a reply to the caller instead of answering the call, select

Options > Send message. To activate the text message reply and edit the message,

select > Settings > Phone sett. > Phone > Call > Reject call with message and

Message text.

D R

F T

Call waiting

During a call, to answer the waiting call, press the call key. The first call is put on hold. To switch between the two calls, select Swap. To end the active call, press the end key.

To activate the call waiting function (network service), select > Settings >

Phone sett. > Phone > Call > Call waiting > Activate.

Call functions

RM-328_FCC-draft_en_1.fm Page 21 Tuesday, March 11, 2008 9:35 AM

■ Video calls

Make a video call

To make a video call, you may need to have a USIM card and be within the coverage of a UMTS network. For availability of and subscription to video call services, contact your service provider. A video call can only be made between two parties and when no other voice, video, or data calls are active. The video call can be made to a compatible mobile phone or an ISDN client.

You have captured a still image to be sent instead of video sending.

You have denied video sending from your device.

1. Enter the phone number in the standby mode and select Video call. Or, select

> Contacts, scroll to the desired contact, and select Options > Video call.

2. To change between showing video or only hearing sound during a video call,

select from the toolbar Enable video sending or Disable video sending.

If you have denied video sending during a video call, the call is still charged as a video call. Check the pricing with your network operator or service provider.

3. To end the video call, press the end key.

Answer a video call

When a video call arrives, is displayed.

To answer the video call, press the call key. Allow video image to be sent to caller? is shown. If you select Yes, the image captured by the camera in your device is shown to the caller. Otherwise, video sending is not activated.

If you have denied video sending during a video call, the call is still charged as a video call. Check the pricing with your service provider.

To end the video call, press the end key.

D R

F T

■ Call settings

Call

Select > Settings > Phone sett. > Phone > Call and from the following:

Send my caller ID (network service) — to display or hide your phone number from

the person to whom you are calling

Call waiting (network service) — See ‘Call waiting,’ p. 20.

Reject call with message and Message text — See ‘Answer or reject a call,’ p. 20.

Call functions

RM-328_FCC-draft_en_1.fm Page 22 Tuesday, March 11, 2008 9:35 AM

Own video in recvd. call— to set whether you allow to send your own video image

when you receive a video call

Image in video call — to select a still image to be shown when you deny a video

call

Automatic redial — to set your device to make a maximum of 10 attempts to

connect the call after an unsuccessful call attempt

Show call duration and Summary after call — to set the device to display the call

duration during a call and the approximate duration of the last call

Speed dialling — See ‘Speed dialling,’ p. 19.

Anykey answer — to answer an incoming call by briefly pressing any key, except

the left and right selection keys, volume keys, power key, and end key.

Line in use (network service) — to select the phone lines for making calls and

sending short messages. This is shown only if the SIM card supports two phone lines.

Line change (network service) — to enable or disable the line selection

Call divert

1. Select > Settings > Phone sett. > Phone > Call divert (network service).

2. Select which calls you want to divert, for example, Voice calls.

3. Select the desired option. For example, to divert voice calls when your number

is busy or when you reject an incoming call, select If busy.

4. Select Options > Activate and the phone number to which you want to divert

the calls. Several divert options can be active at the same time.

Call barring and call diverting cannot be active at the same time.

Call barring

1. Select > Settings > Phone sett. > Phone > Call barring (network service) to

restrict the calls that you make and receive with your device.

2. Scroll to the desired barring option, and select Options > Activate. To change

the settings, you need the barring password given by your service provider.

Call barring and call diverting cannot be active at the same time.

When calls are barred, calls may be possible to certain official emergency numbers.

Network

Select > Settings > Phone sett. > Phone > Network and from the following:

D R

Call functions

F T

RM-328_FCC-draft_en_1.fm Page 23 Tuesday, March 11, 2008 9:35 AM

Network mode — to select which network to use (this is shown only if it is

supported by the service provider). If you select Dual mode, the device uses the GSM or UMTS network automatically.

Operator selection — To set the device to search for and automatically select one

of the available networks, select Automatic. To select the desired network manually from a list of networks, select Manual. The selected network must have a roaming agreement with your home network.

Cell info display ( network service) — to set th e dev ice t o indicat e w hen it is used in

a cellular network based on microcellular network (MCN) technology, and to activate cell info reception

■ Video sharing

Use video sharing to send live video from your mobile device to another compatible mobile device during a voice call.

Video sharing requirements

Video sharing requires a 3G universal mobile telecommunications system (UMTS) connection. For information about network availability and the fees associated with this application, contact your service provider.

To use video sharing you must do the following:

• Ensure that your device is set up for person-to-person connections.

• Ensure that both the sender and recipient are registered to the UMTS network.

• Ensure you have an active UMTS connection and you are within UMTS network

coverage. If you move away from a UMTS network during the sharing session, the sharing session is discontinued, but your voice call continues.

Video sharing settings

A person-to-person connection is also known as a session initiation protocol (SIP) connection. Before you can use video sharing, ask your service provider for the configured SIP profile to be used in your device.

Select > Settings > Phone sett. > Connection > Video sharing and from the following:

Video sharing — to select whether the video sharing is enabled

SIP profile — to select a SIP profile

Video saving — to set whether the live videos are automatically saved

D R

F T

Call functions

RM-328_FCC-draft_en_1.fm Page 24 Tuesday, March 11, 2008 9:35 AM

Preferred saving memory — to select whether to save the videos to the device

memory or to a memory card

Capability alert tone — to set an alert tone to sound when video sharing is

available during a call

If you know a recipient’s SIP address, you can save it to Contacts. Select >

Contacts, the contact, and Options > Edit > Options > Add detail > SIP or Share video. Enter the SIP address (username@domainname). You can use an IP address

instead of a domain name.

Share live video or video clip

1. To share live video you are recording with the device camera, select Options >

Share video > Live video during a voice call. To share a saved video clip, select Video clip and the clip you want to share.

2. The device sends the invitation to the SIP address you saved to Contacts.

If necessary, to send the invitation, select the SIP address of the recipient; or enter a SIP address, and select OK.

3. Sharing begins automatically when the recipient accepts the invitation, and

the loudspeaker is active. Use the toolbar buttons to control the video sharing.

4. To end the sharing session, select Stop. To end the voice call, press the end key.

Accept an invitation

Your device rings when you receive an invitation. The invitation shows the sender’s name or SIP address. Select Yes to begin the sharing session. To decline the invitation and to return to the voice call, select No.

F T

■ Log

To view missed, received, or dialled calls; text messages; packet data connections; and fax and data calls registered by the device, select > Log.

In the standby mode, you can use the call key as a shortcut to Dialled numbers in the Recent calls log (network service).

Note: The actual invoice for calls and services from your service provider may vary, depending on network features, rounding off for billing, taxes, and so forth.

Note: Some timers, including the life timer, may be reset during service or software upgrades.

D R

Call functions

RM-328_FCC-draft_en_1.fm Page 25 Tuesday, March 11, 2008 9:35 AM

4. Positioning

You can use applications such as Maps and GPS data to find out your location, or measure distances and coordinates. These applications require a GPS connection.

■ About GPS

Your device has an internal GPS receiver.

The Global Positioning System (GPS) is operated by the government of the United States, which is solely responsible for its accuracy and maintenance. The accuracy of location data can be affected by adjustments to GPS satellites made by the United States government and is subject to change with the United States Department of Defense civil GPS policy and the Federal Radionavigation Plan. Accuracy can also be affected by poor satellite geometry. Availability and quality of GPS signals may be affected by your location, buildings, natural obstacles, and weather conditions. The GPS receiver should only be used outdoors to allow reception of GPS signals.

Any GPS should not be used for precise location measurement, and you should never rely solely on location data from the GPS receiver and cellular radio networks for positioning or navigation.

■ Assisted GPS

Assisted GPS (A-GPS) is used to retrieve assistance data over a packet data connection, which assists in calculating the coordinates of your current location when your device is receiving signals from satellites.

Your network operator may charge you for this connection according to your network subscription. Contact your service provider for the correct internet access point and charges related to the service.

Your device is preconfigured to use the Nokia A-GPS service, if no service provider-specific A-GPS settings are available. The assistance data is retrieved from the Nokia A-GPS service server only when needed. To disable different positioning methods, see ‘Positioning settings,’ p. 25.

To use A-GPS, you must have a packet data internet access point defined. See ‘Positioning settings,’ p. 25.

D R

F T

■ Set up GPS connection

Positioning settings

Select > Settings > Phone sett. > General > Posit ion ing and from the following:

Positioning methods — to enable or disable different positioning methods

Positioning

+ 57 hidden pages
