Microsoft RM-24 User Guide

Nokia E70 User Guide
9242084
Issue 1
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-24 is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from www.nokia.com/ phones/declaration_of_conformity/.
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trade marks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
This product includes software licensed from Symbian Software Ltd (c) 1998-2004. Symbian and Symbian OS are trademarks of Symbi an Ltd.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2004. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice
The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.
EXPORT CONTROLS This device may contain commodities, technology, or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
9242084/Issue 1

Contents

Contents
For your safety..................................................................7
About your device........................................................................8
NETWORK SERVICES.......................................................................8
Enhancements, batteries, and chargers................................8
Get started..........................................................................9
Charge the battery.......................................................................9
Enter basic settings......................................................................9
CD-ROM.............................................................................................9
Get started (part 2).......................................................10
Insert the SIM card and battery.............................................10
Insert a memory card...............................................................11
Switch on your device..............................................................12
Your device......................................................................13
Settings.........................................................................................13
Menu..............................................................................................13
Help and tutorial........................................................................13
Scroll and make selections......................................................14
Common actions in several applications............................14
Write text.....................................................................................15
Your device (part 2)......................................................17
Keys and parts.............................................................................17
Keypad lock (Keyguard)...........................................................19
Volume control...........................................................................19
Connectors...................................................................................20
Type label.....................................................................................20
Antennas.......................................................................................20
About the display.......................................................................21
Standby modes...........................................................................21
Display regions...........................................................................22
Display indicators.......................................................................23
Memory.........................................................................................24
Transfer content between devices.......................................25
Make calls.........................................................................27
Speed dial.....................................................................................27
Answer a call...............................................................................28
Forward calls...............................................................................28
Call restriction.............................................................................28
Log..................................................................................................29
Push to talk..................................................................................29
Voice over IP................................................................................33
Phone security ...........................................................................33
Contacts............................................................................36
Manage contact groups...........................................................36
Manage default information..................................................36
Copy contacts between SIM and device memory............37
Select ringing tones for contacts..........................................37
Business cards.............................................................................37
Messages..........................................................................39
Messaging folders......................................................................39
Messaging settings....................................................................40
Text messages............................................................................40
Multimedia messages...............................................................42
E-mail messages.........................................................................45
Instant messaging.....................................................................50
Special messages.......................................................................53
Sync e-mail...................................................................................53
Camera..............................................................................54
Take a picture.............................................................................54
Record a video clip....................................................................54
Camera settings..........................................................................54
Connectivity.....................................................................56
Cable connection........................................................................56
Wireless local area network (WLAN)....................................56
Mobile VPN ..................................................................................57
Bluetooth......................................................................................57
SIM access profile.......................................................................60
Infrared.........................................................................................61
Modem..........................................................................................61
Data connections.......................................................................62
Connection manager................................................................62
Web....................................................................................64
Set preferences for browsing.................................................64
Bookmarks...................................................................................65
News feeds and blogs..............................................................66
Web in applications..................................................................66
Flash player..................................................................................73
Office applications.........................................................77
File manager................................................................................77
Documents...................................................................................77
Sheet..............................................................................................79
Presentation................................................................................80
Screen export..............................................................................82
Zip Manager.................................................................................83
Print................................................................................................83
Settings.............................................................................84
Phone settings............................................................................84
Call settings..................................................................................85
Connection settings..................................................................86
Date and time settings.............................................................91
Security settings.........................................................................91
Enhancement settings..............................................................91
Organiser..........................................................................92
Calendar........................................................................................92
Notes..............................................................................................93
Calculator......................................................................................93
Converter......................................................................................94
Clock...............................................................................................94
Contents
Services.............................................................................67
Internet access points..............................................................67
Media applications........................................................69
Gallery............................................................................................69
RealPlayer ....................................................................................70
Music player.................................................................................72
Voice recorder.............................................................................73
Tools..................................................................................96
Positioning...................................................................................96
Navigator......................................................................................96
Landmarks....................................................................................96
Voice commands........................................................................97
Activation Keys...........................................................................98
Application manager................................................................98
Device manager...........................................................100
Remote configuration network service...........................100
Data synchronization.............................................................100
Contents
Personalization............................................................101
Profiles........................................................................................101
Themes.......................................................................................102
Nokia original enhancements.................................103
Enhancements..........................................................................103
Battery information...................................................104
1150 mAh Li-Ion battery (BL-6C) information................104
Nokia battery authentication guidelines.........................104
Care and maintenance..............................................106
Additional safety information................................107
Operating environment.........................................................107
Medical devices........................................................................107
Vehicles.......................................................................................108
Potentially explosive environments..................................108
Emergency calls........................................................................108
CERTIFICATION INFORMATION(SAR).....................................109
Technical information...............................................110
Nokia One-Year Limited Warranty.........................111
Appendices ...................................................................115
Appendix A Message from the CTIA ..................................115
Appendix B Message from the FDA....................................116
Index...............................................................................121

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELLING
Do not use the device at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product documentation. Do not touch the antennas unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all important information.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
For your safety
7
EMERGENCY CALLS
Ensure the phone function of the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the standby mode. Enter the
For your safety
emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

About your device

The wireless device described in this guide is approved for use on the EGSM850/1800/1900 networks. Contact your service provider for more information about networks.
When using the features in this device, obey all laws, and respect privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

NETWORK SERVICES

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what
8
charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language­dependent characters and services.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Your device may also have been specially configured. This configuration may include changes in menu names, menu order and icons. Contact your service provider for more information.

Enhancements, batteries, and chargers

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from the LCH-12, ACP-12, and AC-1 chargers.
Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.
Your device and its enhancements may contain small parts. Keep them out of reach of small children.

Get started

Note: Your service provider may have requested that certain features be disabled or not activated in your device. If so, they do not appear on your device menu. Your device may also have been specially configured for your network provider. This configuration may include changes in menu names, menu order and icons. Contact your service provider for more information.

Charge the battery

1. Connect the charger to an AC wall outlet.
2. Connect the power cord to the bottom of the device.
The battery indicator bar starts scrolling on the display. If the battery is completely discharged, it may take a few minutes before the charging indicator is shown. The device can be used while charging.
3. When the battery is fully charged, the bar stops
scrolling. Disconnect the charger from the device, then from the AC outlet.
When the battery charge level is too low for operation, the device switches itself off.

Enter basic settings

When you power on the device for the first time, and when you power on the device after battery installation,
your device asks for home city, time, and date. You can change the settings later.
1. Select your home city from the list and OK. To browse for a city, start to type the name of the city, or scroll to a city. It is important to select the correct city, because scheduled calendar entries that you create can change when the home city is changed.
2. Set the time, and select OK.
3. Set the date, and select OK.

CD-ROM

The sales package CD-ROM is compatible with Windows 98SE, Windows ME, Windows 2000, and Windows XP.
You can install Nokia PC Suite and read the user documentation from the CD-ROM. Nokia PC Suite can be used only with Windows 2000 and Windows XP.
Get started
9

Get started (part 2)

Insert the SIM card and battery

1. Always switch the device off, and disconnect the
Get started (part 2)
charger before removing the battery. With the back of the device facing you, press the cover
release button (1), and slide the back cover in the direction of the arrow (2).
2. If the battery is installed, lift the battery from the battery compartment in the direction of the arrow to remove it .
3. To release the SIM card holder, slide it in the direction of the arrow (1), and lift it (2). Insert the SIM card into the SIM card slot (3).
Ensure that the beveled corner of the SIM card is pointing up and the contact area on the card is facing the device. Lower the SIM card holder (4), and slide it until it locks into place (5).
10
4. To insert the battery, align the contacts of the battery with the corresponding connectors on the battery compartment, insert in the direction of the arrow, and gently click the battery into place.
Get started (part 2)
5. Insert the locking catches of the back cover into the corresponding slots (1), and slide the cover in the direction of the arrow (2).

Insert a memory card

See "Memory," p. 24.
1. If necessary, remove the battery cover.
2. Slide the memory card into the memory card slot. Ensure that the beveled corner of the memory card is pointing towards the device and the contact area is facing up.
11
Get started (part 2)
3. Replace the battery cover.
Important: Do not remove the MMC card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

Switch on your device

1. To switch the device on, press the power key.
2. If the device asks for a PIN code, lock code or security code, enter the code, and select OK.
3. To switch the device off, press the power key.
Tip: When you switch the device on, it may recognize the SIM card provider and configure the correct text message, multimedia message, and GPRS settings automatically. If not, contact your service provider for the correct settings.
The device can be used without the phone functions when a SIM card is not inserted or when the Offline profile is selected.
The picture shows the location of the power key.
12

Your device

Settings

When you switch the device on, it may recognize the SIM card provider and configure the correct text message, multimedia message, and GPRS settings automatically. You may also receive the settings as a special text message from your service provider.

Menu

Menu is a starting point from which you can open all
applications in the device or on a memory card. The
Menu contains applications and folders, which are groups
of similar applications. Use the joystick to move up and down on the screen.
Applications that you install are saved in the Installat. folder by default.
To open an application, scroll to it, and press the joystick.
To view the applications in a list, select Options > Change
view > List. To return back to the grid view, select Options > Change view > Grid.
To view the memory consumption of different applications and data stored on the phone or memory card and to check the amount of free memory, select
Options > Memory details, and select the memory.
To rearrange the folder, scroll to the application you want to move, and select Options > Move. A check mark is
placed beside the application. Scroll to a new location, and select OK.
To move an application to a different folder, scroll to the application you want to move to another folder, and select Options > Move to folder. Select the new folder, and OK.
To download applications from the Web, select
Options > App. downloads.
To create a new folder, select Options > New folder. You cannot create folders inside folders.
To rename a new folder, select Options > Rename.
Tip: To switch between several open applications, press and hold the Menu key. The application-switching window opens and displays the open applications. Scroll to an application, and press the joystick to switch to it.
When you switch off the device, all applications are closed and unsaved data is saved automatically.

Help and tutorial

Need help? Search for keywords or get a list of help topics. Also, your device has a tutorial and application help preinstalled.
Your device
13

Help topics

To open help from the main menu, select Menu > Help >
Help.
Your device
To search for help topics using keywords, select
Options > Search by keyword.
To display a list of help topics, select from the application drop-down list. As you read a help topic, scroll left or right to view related topics.

Application help

To get help inside an application, select Options > Help. As you read the instructions, press and hold the Menu key to switch between Help and an application open in the background.

Tutorial

To learn about key features, select Menu > Help >
Tutorial.

Scroll and make selections

Use the joystick to move and make selections. With the joystick, you can move up, down, left and right in the
Menu or in different applications or lists. You can also
press the joystick to open applications or files or edit settings.
To select text, press and hold the edit key, and scroll left or right until you have selected the text.
14
To select different items, such as messages, files, or contacts, scroll up, down, left or right to highlight to the item you want to select. Select Options > Mark/
Unmark > Mark to select one item, or Options > Mark/ Unmark > Mark all to select all items.
To select an object, for example an attachment in a document, scroll onto the object so that square markers appear on each side of the object.

Common actions in several applications

You can find the following actions in several applications:
To switch between open applications, press and hold
Menu to see a list of open applications. Scroll to the
application, and select Select.
To change the profile or switch off or lock the device, press the power key briefly.
To save a file, select Options > Save. There are different save options depending on the application you use.
To send a file, select Options > Send. For example, you can send a file in an e-mail or multimedia message; or send them using infrared or Bluetooth.
To print to a compatible printer, select Options > Print. You can preview items that you want to print, or edit the way printed pages look. Before you can print, you must define a compatible printer to your device. See "Print," p. 83.
To copy, press the edit key and select the text with the joystick. Press and hold the edit key and select Copy. To
paste, scroll to where you want to paste the text, press and hold the edit key and select Paste. This method may not work in applications such as Documents that have their own copy and paste commands.
To delete a file, press the clear key, or select Options >
Delete.
To insert characters such as question marks or parenthesis to text, press *.

Write text

To erase a character, press the clear key. Press and hold the clear key to clear more than one character.
The most common punctuation marks are available under the 1 key. Press 1 repeatedly to reach the desired punctuation mark. Press * to open a list of special characters. Use the joystick to move through the list, and select a character.
To insert a space, press 0. To move the cursor to the next line, press 0 three times.
To switch between the different character cases, press #.
Your device

Traditional text input

The indicator is shown on the to p right of the display when you are writing text using traditional text input.
and indicate the selected case. indicates that the first letter of the word is written in upperca se and all the other letters will automatically be written in lowercase.
Press a number key 1-9 repeatedly until the desired
character appears. There are more characters available for a number key than are printed on the key.
To insert a number, press and hold the number key.
To switch between letter and number mode, press and
hold #.
If the next letter is located on the same key as the
present one, wait until the cursor appears, and enter the letter.
indicates number mode.

Predictive text input

1. To activate predictive text input, press the edit key, and select Predictive text on. This activates predictive text input for all editors in the device. The indicator
is shown on the top right of the display when
you are writing text using predictive text input.
2. To write the desired word, press 2-9. Press each key only once for one letter.
3. When you have finished writing the word and it is correct, to confirm it, press the joystick, or press 0 to add a space.
If the word is not correct, press * repeatedly to view the matching words the dictionary has found one by one.
If the ? character is shown after the word, the word you intended to write is not in the dictionary. To add a word to the dictionary, select Spell, enter the word (up to 32 letters) using traditional text input, and select OK. The word is added to the dictionary. When
15
the dictionary is full, a new word replaces the oldest added word.
4. Start writing the next word.
Your device
Tip: To set predictive text input on or off, press # twice quickly.
Write the first half of a compound word; to confirm it, press the joystick. Write the last part of the compound word. To complete the compound word, press 0 to add a space.
To turn predictive text input off for all editors in the device, press the edit key, and select Predictive text > Off.

Copy text to the clipboard

1. To select letters and words, press and hold the edit key. At the same time, scroll in the direction necessary to highlight the word, phrase, or line of text you want to copy. As the selection moves, the text is highlighted.
2. To copy the text to the clipboard, while still holding the edit key, select Copy. To insert the text into a document, press and hold the edit key, and select
Paste.
16

Your device (part 2)

You can use your device with the cover keypad closed or open.
1. To open the cover, lift the keypad into the direction of the arrow (1). When you open the front cover, you can use the full-size QWERTY keyboard (2).
2. The device changes the orientation of the display to portrait or landscape, depending on whether you use the device with front cover open or closed.

Keys and parts

Full keyboard open

1 — Keypad light key. Press the key to illuminate your keypad for a period of time.
2 — Power key 3 — Selection keys 4 — Sync key 5 — Clear (backspace) key 6 — Chr key. Press the Chr key to open a character table
where you can select special characters.
Your device (part 2)
17
7 — Menu key. Press the Menu key to access the applications installed in your device. With a long keypress, you can see a list of the active applications and switch between them. In this User Guide, "select Menu" refers to pressing this key.
8 — Shift key. Press Shift+character key to produce uppercase letters.
9 — Space bar
Your device (part 2)
10 — Call key 11 — Light sensor and earpiece 12 — Joystick. Press the joystick to enter a selection. Use
the joystick to scroll left, right, up, down, or to move around on the screen.
13 — End key Press the end key to reject a call, end active calls and held
calls, close applications, and with a long keypress, end data connections (GPRS, data call).
14 — Space bar 15 — Shift key. Press shift and character key to produce
uppercase letters. 16 — Ctrl key 17 — Enter key The display changes from portrait to landscape when you
open the cover. The application that was active the last time the device was used is shown on the display. When you close the cover, the display changes from landscape to portrait.

Full keyboard closed

1 — Power key 2 — Loudspeaker 3 — Infrared port 4 — Left selection key, joystick, and right selection key.
Press either selection key to perform the function shown above it on the display. Press the joystick to enter a selection or access most commonly used functions in different applications. Use the joystick to scroll left, right, up, down, or to move around on the screen. During a call, scroll left or right with the joystick to change volume.
5 — End key
18
6 — Clear key 7 — Menu key. Press the Menu key to access the menu. In
this User Guide, "select Menu" refers to pressing this key. 8 — Sync key 9 — Microphone. Do not cover the microphone with your
hand during phone calls. 10 — PopPort™ connector for the USB data cable,
headset, and loopset 11 — Charger connector 12 — Edit key 13 — Call key 14 — Voice key/push to talk (PTT) key. 15 — Display 16 — Earpiece 17 — Light sensor

Keypad lock (Keyguard)

When the keypad lock is on, calls may be possible to the official emergency number programmed into your device.
Use the keypad lock (keyguard) to prevent the keys on the phone from being accidentally pressed.
To lock the keypad in the standby mode, press the left selection key and *. To unlock, press the left selection key and * again.
Tip: To lock the keypad in the Menu or in an open application, press the power key briefly, and select Lock keypad. To unlock, press the left selection key and *.
To lock the device in the standby mode, press the left selection key and #, and enter your lock code. To unlock, press the left selection key and *. Enter your lock code, and press the joystick.

Volume control

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.
To adjust the volume during a call, scroll left or right, or press the voice keys.
To adjust the volume when using the loudspeaker, scroll left or right, or press the voice keys.
Your device (part 2)
19

Connectors

Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
Your device (part 2)

Antennas

Your device has two internal antennas.
Battery charger connector
Connector for headset and
other enhancements

Type label

The diagram shows the location of the type label.
20
Note: As with any other radio transmitting device, do not touch either of the antennas unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Not touching the antenna area during a phone call optimises the antenna performance and the talktime of your device.
The picture shows the normal use of the device at the ear for voice
calls. See "Operating environment," p. 107.

About the display

A small number of missing, discolored, or bright dots may appear on the screen. This is a characteristic of this type of display. Some displays may contain pixels or dots that remain on or off. This is normal, not a fault.

Standby modes

Standby mode

After you have switched on your device and it is ready for use, but you have not entered any characters or made other selections, the phone is in the standby mode. In the standby mode, you can see different information, such as your service provider, time, and different indicators, such as indicators for alarms.
Your device has two different standby modes: standby mode, and active standby mode.
Your device (part 2)
1 — Battery indicator 2 — Message display 3 — Right selection text 4 — Left selection text 5 — Active standby applications 6 — Signal indicator 7 — Time and date

Shortcuts in standby mode

In the standby mode, you can use the following shortcuts. These shortcuts are usually not available in the active standby mode.
21
To view the most recently dialed numbers, press the call key. Scroll to a number or name, and press the call key again to call the number.
To call your voice mailbox (network service), press and hold 1.
To view calendar information, scroll right.
To write and send text messages, scroll left.
To open the contacts list, scroll up or down.
Your device (part 2)
To change the profile, press the power key briefly, scroll to the profile you want, and press the joystick to activate the profile.
To switch between two phone lines (network service), press and hold #.
To change these shortcuts, select Menu > Settings >
Phone sett. > Standby mode.

Active standby mode

In the active standby mode, you can view similar information as in the standby mode, but you can also define up to five applications you want to access fast.
To activate active standby, select Menu > Tools >
Settings > Phone sett. > Standby mode > Active standby > On.
To select applications that you want to access from active standby, scroll to the different shortcut settings and press the joystick. Scroll to the desired application and press the joystick.

Display regions

The figures show regions of the display in the Applications and Settings screens, as these regions are referred to in this guide.
Applications screen 1 — Menu title 2 — Scroll bar 3 — Folder 4 — Application
22
Settings screen 1 — Scroll to more pages (tabs) 2 — Active page (tab) 3 — Inactive page (tab) 4 — Setting option 5 — Current setting option

Display indicators

The signal strength of the cellular network at your
current location. The higher the bar, the stronger the signal.
The battery charge level. The higher the bar, the
stronger the charge in the battery.
The application is open. This icon is shown in the
Menu.
You have received a message.
You have locked the cover phone keypad.
You have locked the device.
You have selected the silent profile, and the device
does not ring for an incoming call or message.
Bluetooth is activated.
Wireless LAN is available.
Wireless LAN is active.
An infrared connection is active. If the indicator
blinks, your device is trying to connect to the other device, or the connection has been lost.
Your device is connected to a PC with a USB data
cable.
All calls are forwarded to another number.
and Indicate the phone line that you have selected,
if you have subscribed to two phone lines (network service).
You have missed a phone call.
An alarm is active.
, , A headset, music stand, hands-free car kit,
or loopset is connected.
Your device (part 2)
23
A GPRS connection is active.
A data call is active.
IP passthrough is active.
Your device is synchronizing.
You have an ongoing push to talk connection.
Your device (part 2)

Memory

There are two types of memory into which you can save data or install applications: device memory and removable memory.
Select Menu > Tools > Options > Memory details. You can see how much memory is currently in use, how
much free memory remains, and how much memory is consumed by each data type. For example, you can see how much memory your e-mail messages, text documents, or calendar appointments consume.
Tip: To ensure that you have adequate memory, you should regularly delete or transfer data to a memory card or PC.

Memory card

Use only compatible miniSD MultiMediaCards (MMC) with this device. Other memory cards, such as Reduced Size MultiMediaCards, do not fit in the MMC card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as
24
the device, and data stored on the incompatible card may be corrupted.
Your Nokia device only supports the FAT16 file system for memory cards. If you use a memory card from another device or if you want to ensure compatibility of the memory card with your Nokia device, you may need to format the memory card with your Nokia device. However, all data in the memory card is permanently deleted if you format the memory card.
It is recommended to back up device memory regularly to the memory card. The information can be restored to your device later. To back up information from phone memory to a memory card, select Menu > Tools >
Memory card > Options > Backup phone mem. To
restore information from the memory card to the phone memory, select Menu > Tools > Memory card >
Options > Restore from card.
Do not remove a memory card when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.
If you cannot use a memory card in your device, you may have the wrong type of memory card, the card may not be formatted for your device, or the card has a corrupted file system.
Mini SD
This device uses a mini Secure Digital (SD) card. To ensure interoperability, use only the correct voltage
mini SD. Check the compatibility of a mini SD with its manufacturer or provider. Use only compatible mini SD cards with this device. Other memory cards, such as
MultiMediaCards (MMC) or full-size SD cards, do not fit in the mini SD card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted. Keep all memory cards out of the reach of small children.

Transfer content between devices

Transfer data from another device

You can transfer content, such as contacts, from a compatible Nokia device to your Nokia 6830 using Bluetooth connectivity or infrared. The type of content that can be transferred depends on the phone model. If the other device supports synchronization, you can also synchronize data between the other device and your Nokia 6830.
1. To start transferring data from a compatible device,
select MenuTools > Switch > Transfer.
2. In the information view, select Continue.
3. Select whether you want to use Bluetooth
connectivity or infrared to transfer the data. Both devices must support the selected connection type.
4. If you select Via Bluetooth:
Activate Bluetooth in your other device and select
Continue in your Nokia 6830 to start searching for
devices with active Bluetooth connectivity. Select
Stop when your Nokia 6830 has found your other
device. Select your other device from the list. You are
asked to enter a passcode (1-16 digits) on your Nokia
6830. The passcode will be used only once to confirm this connection. Enter the code on your Nokia 6830, and select OK. Enter the passcode on your other device, and select OK. The devices are now paired. See "Pair devices," p. 59.
For some phone models, the Transfer application is sent to your other device as a message. To install
Transfer on your other device, open the message, and
follow the instructions on the display. If you select Via infrared: Connect the two devices. See "Infrared," p. 61.
5. From your Nokia 6830, select the content you want to transfer from your other device, and OK.
Content is copied from the memory of the other device to the corresponding location in your device. Copying time depends on the amount of data to be t ransferred. You can also cancel and continue later.
The necessary steps for data transfer may vary depending on your device, and whether you have interrupted data transfer earlier. The items that you can transfer vary depending on the other device.

Synchronize data with another device

If you have previously transferred data to your Nokia 6830, and your other device supports synchronization, you can use Switch to keep the data of the two devices up to date.
1. Select Menu > Tools > Switch.
Your device (part 2)
25
2. Select Device, and press the joystick.
3. Scroll to the device from which you transferred data, and press the joystick.
4. Select Sync and press the joystick. The devices start synchronizing using the same connection type that you selected when you originally transferred data and synchronize only the data that you originally selected for data transfer.
Your device (part 2)
To modify the data transfer and synchronization settings, select Sync, scroll to a device, press the joystick, and select
Edit.
26

Make calls

When the device is locked, calls still may be possible to the official emergency number programmed into your device.
In the offline profile, you may need to enter the lock code and change the device to a calling profile before making any call, including a call to an emergency number.
To make and receive calls, the phone must be switched on, the device must have a valid SIM card installed, and you must be located in a service area of the cellular network. The GPRS connection is put on hold during voice calls unless the network supports dual transfer mode.
Enter the phone number, including the area code, and press the call key. If you enter an incorrect character, press the clear key.
Tip: For international calls, press the * key twice to add the + character that replaces the international access code, and enter the country code, area code (omit the leading 0, if necessary), and phone number.
To end the call or cancel the call attempt, press the end key.
To make a call using the saved contacts, press Contacts in standby mode. Enter the first letters of the name, scroll to the name, and press the call key. See "Contacts," p. 36.
Press the call key to view up to 20 numbers that you last called or attempted to call. Scroll to the desired number
or name, and press the call key to dial the number.See "Log," p. 29.
To adjust the volume of an active call, scroll left or right with the joystick.
To call your voice mailbox (network service) in standby mode, press and hold the 1 key, or press the 1 key then the call key.

Speed dial

1-touch dialing allows you to make a call by pressing and holding a number key.
Before using 1-touch dialing, select Menu > Tools >
Settings > Call settings > Speed dialling, and ensure that Speed dialling is set to On.
To assign a number key to a phone number, select
Menu > Tools > Speed dial. Scroll to the number key (2
- 9) on the screen, and select Options > Assign. Select the desired number from the Contacts directory.
To delete the phone number assigned to a number key, scroll to the speed dialing key, and select Options > Undo.
To modify a phone number assigned to a number key, scroll to the 1-touch dialing key, and select Options >
Change.
Make calls
27

Answer a call

Make calls
Note: The actual invoice for calls and services from your service provider may vary, depending on network features, rounding off for billing, taxes, and so forth.
To answer a call, press the call key.
To decline the call, press the end key.
To mute a ringing tone instead of answering a call, select
Silence.
To answer a new call during a call when the Call waiting function is activated, press the call key. The first call is put on hold. To end the active call, press the end key.

Forward calls

Select Menu > Tools > Settings > Call divert. Forward incoming calls to your voice mailbox or to
another phone number. For details, contact your service provider.
1. Select a call type from the following:
Voice calls — Incoming phone calls
Data and video calls — Incoming data and video
calls
Fax calls — Incoming fax calls
2. Select one of the following call forwarding options:
All voice calls, All data and vid. calls, or All fax
calls. — Forward all incoming voice, data and
video, or fax calls.
If busy — Forward incoming calls when you have an active call.
If not answered — Forward incoming calls after your device rings for a specified period of time. Define the time you let the phone ring before forwarding the call in the Delay time: field.
If out of reach — Forward calls when the phone is switched off or out of network coverage.
If not available — Activate the last three settings at the same time. This option forwards calls if your device is busy, not answered, or out of reach.
3. Select Activate.
To check the current forwarding status, scroll to the forwarding option, and select Options > Check status.
To stop forwarding voice calls, scroll to the forwarding option, and select Options > Cancel.
Call restriction and call forwarding c an not be a ct ive at t he same time.

Call restriction

When calls are restricted, calls still may be possible to the official emergency number programmed into your device.
Select Menu > Tools > Settings > Call barring. You can restrict the calls that c an b e m ad e o r r e c ei v e d w i t h
the device (network service). To change the settings, you need the restriction password from your service provider. Call restriction affects all calls, including data calls. Call restriction and call forwarding cannot be active at the same time.
28
To restrict calls, select Cellular call barring, and select from the following options:
Outgoing calls — Prevent making voice calls with your device.
Incoming calls — Restrict incoming calls.
International calls — Prevent calling to foreign
countries or regions.
Incoming if abroad — Restrict incoming calls when outside your home country.
Intern. except home — Prevent calls to foreign countries or regions, but to allow calls to your home country.
To check the status of voice call restriction, scroll to the restriction option, and select Options > Check status.
To stop all voice call restrictions, scroll to a restriction option, and select Options > Cancel all barrings.

Internet call restriction

To restrict Internet calls, select Menu > Tools >
Settings > Call barring > Internet call barring.
To reject Internet calls from anonymous callers, select
Anon. call barring > On.
Log
Select Menu > Log. In the Log, you can view information about the
communication history of the device.
To view the logs for recent voice calls, their approximate duration, and packed data connections, select Recent
calls, Call duration, or Packet data and press the joystick.
To sort the events by type or direction, scroll right to open the general log, and select Options > Filter. Scroll to a filter type and press the joystick, then select the type or direction, and press the joystick.
To set the time how long all communication events are held in the log, select Options > Settings > Log
duration. Select an option and OK.
To clear missed calls, received calls and dialed numbers, select Recent calls > Options > Clear recent calls.

Push to talk

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.
Select Menu > Connect. > PTT. Push to talk (PTT) (network service) is a real-time voice
over IP service implemented over a GSM/GPRS network. Push to talk provides direct voice communication connected with the push of a key. With push to talk, you can use your device as you would use a walkie-talkie.
You can use push to talk to have a conversation with one person or with a group of people, or join a channel. A channel is like a chat room: you can call the channel to see if anyone is online. The channel call does not alert the other participants; the participants just join the channel and start speaking with each other.
In push to talk communication, one person talks while the others listen through the built-in loudspeaker. Speakers take turns responding to each other. Because only one speaker can talk at a time, the maximum duration of a
Make calls
29
speech turn is limited. For details of the speech turn duration for your network, contact your network operator or service provider.
Remember to hold the device in front of you during a push
Make calls
to talk call so you can see the display. Speak towards the microphone, and do not cover the loudspeaker with your hands.
Phone calls always take priority over push to talk. Before you can use push to talk, you must define the push
to talk access point and push to talk settings. You may receive the settings in a special text message from the service provider that offers the push to talk service.
User settings
Select Options > Settings > User settings. Define the following:
Incoming PTT calls — Select Notify if you want to see a notification of incoming calls. Select Auto-accept if you want push to talk calls to be answered automatically. Select Not allowed if you want push to talk calls to be rejected automatically.
PTT call alert tone — Select Set by profile if you want the incoming call alert setting for push to talk to follow your profile settings. If your profile is silent, you are not available to others using push to talk, except for callback requests.
Callback req. tone — Define the ringing tone for callback requests.
Application start-up — Select if you want to log in to the push to talk service when you switch on your device.
Default nickname — Enter your default nickname (20 characters maximum) that is displayed to other users.
30
Show my PTT address — Define if you want callers to see your push to talk address. You can let all callers see the address, show the address only to one-to-one callers or channel participants, or hide the address from all callers.
Show my login status — Define if your login to the push to talk server is shown or hidden from other users.
Connection settings
Select Options > Settings > Connection settings. Define the following:
Domain — Enter the domain name obtained from your service provider.
Access point name — Enter the push to talk access point name.
Server address — Enter the IP address or domain name of the push to talk server obtained from your service provider.
User name — Enter your user name obtained from your service provider.
PTT password — Enter a password, if required, to make a data connection. The password is usually provided by the service provider.

Log in to push to talk service

If you have set Application start-up on in User settings, push to talk automatically logs in to the service when started. If not, you must log in manually.
1. To log in to a push to talk service, select Options >
Switch PTT on.
Loading...
+ 94 hidden pages
