Nokia 6066 User Guide

N6066_UG_EN_FCC_060831.fm Page 1 Friday, September 1, 2006 11:26 AM

LEGAL INFORMATION

PART NO. 9249063, ISSUE NO. 1

Copyright ©2006 Nokia. All rights reserved. Nokia, Nokia Connecting People, Nokia 6066, Pop-Port™, and the Nokia Original Enhancements logos are trademarks or registered trademarks of Nokia Corporation. Other company and product names mentioned herein may be trademarks or trade names of their respective owners.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

The information contained in this user guide was written for the Nokia 6066 products. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANYTIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This device may contain commodities, technology, or software subject to export laws and regulations from the U.S. and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user’s authority to operate this equipment.

N6066_UG_EN_FCC_060831.fm Page 2 Friday, September 1, 2006 11:26 AM

Contents

1. Phone at a glance........................................................................ 7

2. Set up your phone..................................................................... 12

3. Text entry................................................................................... 20

4. Uni .............................................................................................. 27

5. Messages .................................................................................... 31

6. Log.............................................................................................. 41

7. Contacts ..................................................................................... 44

8. Gallery ........................................................................................ 52

9. Media.......................................................................................... 55

10.Settings..................................................................................... 60

11.Organiser .................................................................................. 77

12.Games ....................................................................................... 87

13.Enhancements .......................................................................... 88

14.Battery information ................................................................. 90

N6066_UG_EN_FCC_060831.fm Page 3 Friday, September 1, 2006 11:26 AM

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the device off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the device where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

N6066_UG_EN_FCC_060831.fm Page 4 Friday, September 1, 2006 11:26 AM

For your safety

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the main screen. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

N6066_UG_EN_FCC_060831.fm Page 5 Friday, September 1, 2006 11:26 AM

Welcome

Congratulations on your purchase of the Nokia 6066 mobile phone. Your phone provides many functions practical for daily use, such as a hands-free loudspeaker, alarm clock, calculator, calendar, and more. Your phone can also connect to a PC, laptop, or other device using a data cable. To personalise your phone, you can set your favorite ring tones.

■ About your device

The wireless devices described in this guide are approved for use on the CDMA 800 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect privacy and the legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

■ Network Services

To use the device you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize them. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Contact your service provider for more information.

■ Shared memory

The following device features may share memory: contacts; text messages; photos, images, and tones in gallery; calendar notes; games; and applications. Use of one or more of these features may reduce the memory available for the

N6066_UG_EN_FCC_060831.fm Page 6 Friday, September 1, 2006 11:26 AM

Welcome

remaining features sharing memory. If your phone displays a message that the memory is full when you try to use a shared memory feature, delete some of the information or entries stored in the shared memory features before continuing. Some of the features, such as photos, images, and tones in gallery; text messages; and applications may have a certain amount of memory specially allotted to them in addition to the memory shared with other features.

N6066_UG_EN_FCC_060831.fm Page 7 Friday, September 1, 2006 11:26 AM

Phone at a glance

1. Phone at a glance

• Earpiece port (1)

• Display screen (2)

• Left selection key (3)

• Call key (4)

• Keypad (5)

• Microphone (6)

• Four-way scroll and center selection key (7)

• Right selection key (8)

• Power key and end key (9)

• Charger port (10)

• Connector (USB port for service only) (11)

■ Keys and parts

•Headset connector(1)

• Volume key (2)

• Loudspeaker (3)

• Mini display (4)

• Camera flash (5)

• Camera lens (6)

N6066_UG_EN_FCC_060831.fm Page 8 Friday, September 1, 2006 11:26 AM

Phone at a glance

• Voice command key (7)

• Camera and Video key (8)

The voice key functions are as follows:

• Short press—Answer an incoming call.

• Long press—Answer or make a voice call.

■ Standby mode

Depending on your wireless service provider and the model number of your phone, some or all of the following selection keys may appear in the standby mode.

The standby mode is home base and indicates your phone is in the idle state.

Signal strength—A higher bar (at the upper left corner) indicates a stronger network signal.

Uni —Press the center selection key to select this

option.

Menu—Press the left selection key to select this option.

Go to—Press the right selection key to select this option.

Battery level—A higher bar (at the upper right corner) indicates more power in the battery.

Menu Go to

■ Quick keys

Note: Depending on your wireless service provider and the model

number of your phone, some or all of the following Quick keys may appear in the standby mode.

In the standby mode, the four-way scroll key instantly takes you to frequently-accessed menus:

Scroll up key—Go to Calendar.

Scroll right key—Go to U-Mail.

Scroll down key—Go to the contacts list.

Scroll left key—Quickly create a text message.

Center selection key—Go to Uni.

N6066_UG_EN_FCC_060831.fm Page 9 Friday, September 1, 2006 11:26 AM

Phone at a glance

■ Indicators and icons

Depending on your wireless service provider and the model number of your phone, some or all of the following indicators and icons may appear in the standby mode.

You have new text or picture messages. See "Text messages," p. 31.

You have missed a call. See "View missed calls," p. 41.

You have new voice messages. See "Voice messages," p. 38. This icon shows

only when network supports this function.

Your phone keypad is locked. See "Keyguard," p. 19.

Your phone is set to the silent profile. See "Profiles," p. 60.

The alarm clock is set to on. See "Alarm clock," p. 77.

The countdown timer is running.

The stopwatch timer is running in the background.

Integrated hands-free is active. See "Loudspeaker," p. 18.

The timed profile is selected. See "Profiles," p. 60.

An headset is connected to the phone. See "Enhancement settings," p. 72.

■ Phone menus

Phone features are grouped according to function and are accessed through the main menus. Each main menu contains submenus and lists from which you can select or view items and customise your phone features. To access these menus and submenus, use the scroll method or a shortcut.

You can change your menu view from list to grid. Select Menu > Options > Main

menu view > List or Grid.

Note: Some features may not be available, depending on your network. For more information, contact your wireless service provider.

Scroll method

You can use the four-way scroll key to scroll up, down, left, and right through the options.

1. In the standby mode, select Menu, to scroll through the main menus.

N6066_UG_EN_FCC_060831.fm Page 10 Friday, September 1, 2006 11:26 AM

Phone at a glance

As you scroll through the menus, the menu number appears in the upper right corner of the display. Below the battery level indicator is a scroll bar with a tab that moves up or down on the right side of the display screen as you scroll through the menus, providing a visual representation of your current position in the menu structure.

2. When you arrive at a menu, press the center selection key to select submenus.

• Select Back (the right selection key) to return to the previous menu.

• Press the end key to return to the standby mode from any menu or submenu.

In-phone help

Many features have brief descriptions (help text) you can view on the display. To view these descriptions, you must first activate help text as follows.

In the standby mode, select Menu > Settings > Phone > Help text activation > On or Off.

Scroll to a feature and wait about 14 seconds. Scroll down to view all of the description, or select Back to exit.

■ Security code settings

Your device has a security option allowing you to lock your phone with a PIN code. When the PIN code is set and turned on, no outgoing calls are allowed and the menu cannot be accessed without entering the correct code first. This prevents unauthorized outgoing calls or access to any information stored on your device.

The PIN code option is in the Settings menu. The first time you access the Security option, you must enter a PIN code. The default PIN code may vary depending on your wireless service provider who provided your UIM card.

The PIN code protects the UIM card from unauthorized access. The PIN code can be 4–8 digits in length. After three successive incorrect entries, the PIN code is blocked. You need to enter the personal unblocking key (PUK) code. See "Personal unblocking key (PUK) code," p. 72.

N6066_UG_EN_FCC_060831.fm Page 11 Friday, September 1, 2006 11:26 AM

Phone at a glance

■ Go to functions

The Go to menu enables you to change the function of the right selection key on your phone. With this function, you can quickly access your most frequently used functions from the Go to menu in the standby mode.

Choose Go to functions

1. In the standby mode, select Go to > Options > Select options.

2. Scroll up or down to highlight the desired function.

3. Select Mark to add a function or Unmark to remove a function.

4. Select Done when you have added all desired functions.

5. Select Yes to save the changes.

6. In the standby mode, select Go to to display a list of the functions you selected in step 2.

Organise functions

1. In the standby mode, select Go to > Options > Organise.

2. Scroll up or down to highlight the function you want to rearrange, and select

Move > Move up, Move down, Move totop, or Move to bottom.

3. Select Done > Yes to save the changes.

N6066_UG_EN_FCC_060831.fm Page 12 Friday, September 1, 2006 11:26 AM

Set up your phone

2. Set up your phone

■ Antenna

Your device has a fixed antenna located at the top of the phone with the fold closed. Hold the phone with the antenna area pointed up and over your shoulder.

Note: Do not touch the antenna unnecessarily with the device switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Not touching the antenna area during a phone call optimizes the antenna performance and battery life.

■ Battery

Note: Always switch off the power, and disconnect

the charger and any other device before removing the cover. Avoid touching electronic components while changing the cover. Always store and use the device with the cover attached.

Remove the back cover

1. With the back of the phone facing you, push down on the back cover.

2. Slide the back cover toward the bottom of the phone and remove.

N6066_UG_EN_FCC_060831.fm Page 13 Friday, September 1, 2006 11:26 AM

Set up your phone

Remove the battery

1. After you have removed the back cover, insert your finger into the finger grip.

2. Lift the battery upward from it’s compartment.

Note: Always switch off the device, and disconnect the charger before removing the battery.

UIM (CDMA SIM) card installation

The User Identity Module (UIM), also called the CDMA Subscriber Identity Module (SIM), card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card. The UIM card slot is built into the mechanics, located under the battery.

Before installing the UIM card, always make sure that the phone is switched off and that you have removed the cover and battery.

Keep all UIM cards out of the reach of small children.

1. Remove the back cover and battery first.

2. Keep the beveled corner of the UIM card facing up and matching along the corresponding beveled corner of the card holder.

N6066_UG_EN_FCC_060831.fm Page 14 Friday, September 1, 2006 11:26 AM

Set up your phone

3. Insert the UIM card into the holder with the gold-coloured contacts facing down, matching up with the gold-coloured contacts on the phone.

Replace the battery

1. Insert the battery, gold-coloured contact end first, into the battery slot.

2. Push down on the other end of the battery to snap the battery into place.

Replace the back cover

1. Set the back cover on the phone with the cover tabs aligned with the slots in the phone.

2. Slide the back cover toward the top of the phone until the back cover is securely in place.

Charge the battery

Note: Before you use a charger with this device, check its model number.

This device is intended for use when supplied with power from the AC-3 or AC-4 charger.

1. Plug the charger transformer into a standard ac outlet.

N6066_UG_EN_FCC_060831.fm Page 15 Friday, September 1, 2006 11:26 AM

Set up your phone

2. Insert the charger output plug into the round jack at the bottom end of the phone.

After a few seconds, the battery indicator in the display starts to scroll from bottom to top. If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The ACP-7 can also be used to charge the phone, but must be used with the CA44 adaptor included in the box.

1. Plug the charger transformer into a standard ac outlet.

2. Insert the charger output plug into the CA-44 adapter jack. Insert the CA-44 plug into the jack on the bottom of the phone.

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

■ Turn your phone on or off

1. To turn your phone on or off, press and hold the end key on the keypad for at least 4 seconds.

2. Enter the security code, if necessary, and select OK. See "Security settings," p.

70.

N6066_UG_EN_FCC_060831.fm Page 16 Friday, September 1, 2006 11:26 AM

Set up your phone

Warning: Do not switch the phone on when wireless phone use is

prohibited or when it may cause interference or danger.

■ Connect the headset

A compatible headset may be purchased with your phone or separately as an enhancement. See "Enhancement settings," p. 72.

1. Plug the headset connector into the connector at the top of your phone. appears in the standby mode.

2. Position the headset on your ear.

With the headset connected, you can make, answer, and end calls as usual.

• Use the keypad to enter numbers.

• Press the call key to place a call. See "Phone at a glance," p. 7.

• Press the end key to end a call.

You can also plug a compatible headset, such as a standard universal headset, into the 2.5-mm headset jack on the right side of your phone to allow hands-free operation. See "Enhancement settings," p.

72.

■ Make a call

Keypad

1. Enter the phone number (including the area code), and press the call key. (To delete a character to the left of the cursor, select Clear.)

2. Press the end key to end the call, or select End call to cancel the call attempt.

Contacts list

1. In the standby mode, scroll down to display your contacts list and highlight your desired entry.

2. Select Details to highlight your desired number, and then select Call.

N6066_UG_EN_FCC_060831.fm Page 17 Friday, September 1, 2006 11:26 AM

Set up your phone

Last dialled number

1. In the standby mode, press the call key to display the last 30 numbers dialled.

2. Scroll to the number (or name) you want to redial, and press the call key.

Conference calling

Conference calling is a network service that allows you to take part in a conference call with two other participants.

1. Make a call to the first participant.

2. With the first participant on the line, select Options > New call.

3. Enter the phone number of the second participant, or select Search to retrieve a number from the contacts list. Select Call. The first participant is put on hold.

4. When the second participant picks up, press the call key to connect the calls.

5. To end the conference call, select Options > End all calls, or press the end key.

■ Answer calls

An incoming call

1. With the fold open, press the call key, or select Answer to answer the call.

2. Press the end key to reject the call.

Select Silence to mute the ringing tone, then Dismiss, or do nothing.

With your phone set to silent in the profiles menu, select Dismiss to reject the incoming call.

3. With the fold closed, press the volume key to mute the ringing tone.

A short press of the voice key answers an incoming call with the loudspeaker.

By default, your phone answers an incoming call when you open the fold. You can change the setting to not answer the call when the fold opens.

In the standby mode, select Menu > Settings > Call > Answer when fold is

opened > On or Off.

N6066_UG_EN_FCC_060831.fm Page 18 Friday, September 1, 2006 11:26 AM

Set up your phone

Adjust the earpiece volume

Whether in or out of a call, you can scroll the volume key located on the left side of your device up or down to adjust the volume of the earpiece. When you adjust the volume, a bar chart indicates the volume level.

Answer a call with the keypad locked

To answer a call with the keypad locked, press the call key with the fold open. To answer a call with the fold closed and the keypad locked, press and hold the voice key to answer with the loudspeaker. During the call, all features function as normal. When you end or reject the call, the keypad automatically relocks. See "Keyguard," p. 19.

When the keypad lock is on, calls still may be possible to the official emergency number programmed into your device. Enter the emergency number, and press the call key.

Loudspeaker

Warning: Do not hold the device near your ear when the loudspeaker is

in use, because the volume may be extremely loud.

You can use your phone as a loudspeaker during a call.

• To activate the loudspeaker while in a call with the fold open, select Loudsp..

• To activate the loudspeaker when answering a call with the fold closed, press the voice key.

• To deactivate the loudspeaker during a call, with the fold open, select Normal.

The loudspeaker is deactivated automatically when a call (or a call attempt) ends or when certain enhancements are connected.

Call options

Many of the options you can use during a call are network services. Check with your wireless service provider for more information.

1. Select Options during a call to display the following options:

Loudspeaker —Activate or deactivate the loudspeaker while in a call.

New call—Initiate a conference call. See "Conference calling," p. 17.

Save—Save a number while in a call to your contacts list. This option is

available only when entering numbers during a call.

N6066_UG_EN_FCC_060831.fm Page 19 Friday, September 1, 2006 11:26 AM

Set up your phone

Add to contact—Add a phone number to an existing contact in your contacts

list while in a call. This option is available only when entering numbers during a call.

End all calls—Disconnect from all active calls.

Send DTMF—Enter the numbers, and select DTMF to send the numbers as

tones.

Contacts—View the contacts menu.

Menu—View the phone menu.

2. Select an option to activate the option or enter its submenu.

■ Keyguard

With keyguard, you can lock the keypad to prevent keys from being pressed accidentally. The locked keypad unlocks when you receive a call. After the call, the lock automatically reactivates.

With the keyguard on, calls still may be possible to the official emergency number programmed into your phone. Enter the emergency number, and press the call key.

Lock the keypad

Select Menu with the left selection key; then press * within 2 seconds.

Unlock the keypad

Select Unlock with the center selection key; then press * within 2 seconds.

N6066_UG_EN_FCC_060831.fm Page 20 Friday, September 1, 2006 11:26 AM

Text entry

3. Text entry

The input methods available in the phone are preset according to the market where it will be sold.

This phone supports simplified Chinese input methods.

When the phone’s language is set to simplified Chinese, you can use predictive Pinyin and Stroke input methods to enter simplified Chinese.

You can also activate predictive English input method to edit English message. This method reduces times of pressing key rather than traditional English input method, so enhances the speed of entry extremely.

■ Input method indicators

Input method indicators are shown at the upper left corner of the display. The names of the input methods and the corresponding indicators on the display are shown below.

Pinyin

Stroke

Upper case

Lower case

Number input

Note that the default input method and the input methods available in specific circumstance have been presetted in the phone. Always check the indicator on the display to see which input method is in use.

■ Switch between input methods

• Activate the predictive English input method:

1. When editing text message (Create message), press Options, then select

Dictionary on;

2. Zi Dictionary On will be displayed briefly on your phone screen.

• Deactivate the predictive English input method:

N6066_UG_EN_FCC_060831.fm Page 21 Friday, September 1, 2006 11:26 AM

Text entry

1. When editing text message (Create message), press Options, then select

Dictionary off;

2. Zi Dict ionary Off will be displayed briefly on your phone screen.

• Press # repeatedly to switch between these input methods;

• Press and hold # to quickly switch between Number input method and other input methods;

■ Predictive pinyin input method

With predictive pinyin input method, you only need press the number keys on which pinyin symbols are printed to input the pinyin of Chinese characters.

For example, to input "kuai", you only need to press 5, 8, 2, 4.

The pinyin letters (pinyin letters combinations) displayed on the screen change with pressing the number keys. Ignore these changes before you finish inputting the last pinyin letter.

Use predictive pinyin input method

1. Input pinyin letters and tone marks:

Press the corresponding number keys to input pinyin letters for each Chinese character. Press the key 1 repeatedly to enter your desired tone mark.

2. Find different matching items: If there are several pinyin combinations matching the number key you pressing, press * to find other possible matching items.

You can enter tone mark firstly, or find matching item firstly, both are OK.

3. Clear pinyin letters or tone marks: Press Clear to delete pinyin letters or tone marks to the left of the cursor. Press and hold Clear to delete pinyin letters or tone marks to the left of the cursor more quickly.

4. Input Chinese characters: Press 0 to flip the candidate list; Press the left or right scroll key to highlight the desired Chinese character, then press OK to select the highlighted Chinese character.

5. Predictive: Your phone can predictive the next Chinese character which could make up a phrase with the first inputted Chinese character. Press 0 to flip the candidate list; Press the left or right scroll key to highlight the desired

N6066_UG_EN_FCC_060831.fm Page 22 Friday, September 1, 2006 11:26 AM

Text entry

candidate character, then press OK to select the highlighted Chinese character.

6. Exit predictive: You phone will keep predictive function until you select Back. You need to input pinyin letter for the next Chinese character.

If all predictive Chinese characters are not your desired, press Back to delete the predictive characters, or input the pinyin letter for the next Chinese character directly.

7. Clear inputted characters: After clearing all pinyin letters and tone marks, press Clear to delete the character to the left of the cursor; Press and hold

Clear to delete the character to the left of the cursor more quickly. Use the

down and up scroll keys to move the cursor.

Predictive pinyin input example: To input 生日快乐

1. Enter into Create message.

2. Input pinyin letter sheng for 生 : Press 7, 4, 3, 6, 4 in sequence, and finally press 1 once for the first tone.

3. Select 生 from candidate list, then press OK.

4. Press right scroll key to select 日 from predictive character list, then press OK.

5. Input pinyin letter kuai for 快 : Press 5, 8, 2, 4 in sequence, and finally press [1] twice for the fourth tone.

6. Select 快 from candidate list, then press OK.

7. Select 乐 from predictive character list, then press OK.

8. You phone will keep predictive function until you select Back.

■ Stroke input method

The strokes constituting Chinese characters have been divided into five categories: horizontal, vertical, left-falling, dot, and turning. Each category corresponds to a number key from 1 to 5, respectively.

N6066_UG_EN_FCC_060831.fm Page 23 Friday, September 1, 2006 11:26 AM

Text entry

The strokes are classified according to the following table.

Use Stroke input method

1. Input strokes: You could press the number keys to input the strokes according to the standard stroke order.

Tip! If you are not sure about a certain stroke classification, press 6 as a substitution for that stroke, then continue with the subsequent strokes. A question mark appears in the input area to represent that stroke.

2. Clear the strokes you just inputed: selecting Clear deletes the Chinese character to the left of the cursor; selecting and holding Clear deletes the inputted Chinese characters more quickly.

N6066_UG_EN_FCC_060831.fm Page 24 Friday, September 1, 2006 11:26 AM

Text entry

3. Character input: Press 0 to go through in the candidate list; press left scroll key or right scroll key to highlight the Chinese character you want in the candidate list. Press OK to select the highlighted character.

4. Prediction: You phone will keep predictive function until you select Back. Press 0 to go through in the candidate list; press left scroll key or right scroll key to highlight the Chinese character you want in the candidate list. Press

OK to select the highlighted character.

5. End prediction: You phone will keep predictive function until you select

Back. You can continue enter strokes for the next character.

If the current predictive list does not show your desired character, press Back to delete predictive character, or enter the new strokes for the next character.

6. Clear all strings you entered: After deleting all strokes of a character, press

Clear to delete the characters to the left of the cursor; press and hold Clear to

delete the inputted characters more quickly. Press down scroll key and up scroll key to move the cursor.

Stroke input example: To input 你好

1. Enter into the Creat message.

2. Input the stroke for 你 : Press 3, 2, 3, 5 and 2.

3. Select 你 from the candidate list, and then press OK.

4. Select the character 好 from the predictive list, and then press OK.

5. You phone will keep predictive function until you select Clear.

■ Traditional English input

1. Switch the input method to Upper Case status or Lower Case status, please see "Switch between input methods" on page 20.

2. Press a number key (2 - 9) to enter the first letter on the key, press twice to enter the second letter on the key and so on.

If the next letter is located on the same key as the present one, press the down scroll key or upward scroll key to finish the previous letter; or wait until the cursor appears.

N6066_UG_EN_FCC_060831.fm Page 25 Friday, September 1, 2006 11:26 AM

Text entry

3. Press Clear to delete one letter to the left of the cursor. Press and hold Clear to delete letters to the left of the cursor more quickly.

■ Enter space

To insert a space, press 0.

If you are under number mode, please switch to any other input mode first. (See "Switch between input methods" on page 20.)

■ Enter number

• Switch the input method to number mode (See "Switch between input methods" on page 20.), and then enter the number directly by pressing the responding number key.

• If you are under "Predictive English" or "Traditional English" input mode, you can enter number by pressing the responding number key.

• If you are under "Traditional English" input mode, press the responding number key till the number you desired appears on the display.

■ Enter special characters and punctuation marks

• If you are under Pinyin, Stroke, Traditional English or Number input method, press * to view the list of special characters and punctuation marks, scroll to the desired one, then press OK.

To scroll through the list more quickly, press 2, 4, 6 or 8 and then press OK to enter.

• If you are under Pinyin or Traditional English input mode, press 1 repeatedly to enter some frequently used Chinese or English punctuation marks.

■ Predictive English input

With predictive English input, you can enter any letter in the word you want by simply pressing the responding number key. The predictive English input is based on a built-in dictionary to which you can also add new words.

1. At text entry screen, select Options and then select Dictionary on or

Dictionary off to activate or deactivate predictive English input.

If the predictive English input is on, select the desired language.

N6066_UG_EN_FCC_060831.fm Page 26 Friday, September 1, 2006 11:26 AM

Text entry

2. Start writing a word using the keys 2 to 9. Press each key only once for one letter. You must switch to the input method that the first letter is capital, then you can enter out the word Nokia.

The following illustration shows your text entry of the word Nokia in predictive text mode. With the English dictionary selected, press each of the following number keys once, and the screen will display Nokia by predicting the appropriate letter to use based on your keypad entry:

6 6 5 4 2

No Onl Noki

3. When you finish writing the word and it is correct, to confirm it and add a space, press 0 to insert a space for confirmation.

If the word is not correct, press * repeatedly until the desired word appears, and confirm it; or select Options > Matches and the word you want.

Nokia

If the ? character is displayed after the word, the word you intended to write is not in the dictionary. To add the word to the dictionary,

Spell. The phone displays the entered letters. Complete the word using

select

traditional text input, and select Save.

■ Change case and mode

Press # to switch between uppercase, lowercase, and sentence case text. As you press #, the following icons (not the descriptions) appear in the upper left of the display screen:.

Uppercase text: standard mode is on.

Lowercase text: standard mode is on.

Sentence case text: standard mode is on. This option is available only

at the beginning of a sentence.

Note: You can press # within 2 seconds to switch between standard mode and predictive text mode.

Lowercase text: predictive text is on.

Sentence case text: predictive text is on. This option is available only

at the beginning of a sentence.

N6066_UG_EN_FCC_060831.fm Page 27 Friday, September 1, 2006 11:26 AM

Favourites

4. Favourites

All features and options under the Favou rites menu are network services. Their availability and operation depend entirely on your service provider. Always check with your service provider for detailed information about availability, subscription, and charging rates of the services. See "Network services," p. 73.

Your device may have some bookmarks loaded for sites not affiliated with Nokia. Nokia does not warrant or endorse these sites. If you choose to access them, you should take the same precautions, for security or content, as you would with any Internet site.

■ Sign on to the mobile Internet

In the standby mode, select Menu > Favourites > Services.

After a brief pause, your device attempts to connect to your wireless service provider’s home page. If you receive an error message, your device may not be set up for browsing. Contact your wireless service provider to make sure that your device is configured properly.

■ Navigate the mobile Internet

Since your device screen is much smaller than a computer screen, mobile Internet content is displayed differently than you may be accustomed to seeing. This section contains guidelines to use phone keys to navigate a WAP site.

Phone keys

• To browse the WAP site, scroll up or down.

• To select a highlighted item, press Select.

• To enter letters and numbers, press a key from 0–9.

• To enter special characters, press *.

Receive a call while online

Depending on your wireless service provider, you may still be able to receive a voice call while using the WAP browser.

• To answer the incoming call, press the call key.

N6066_UG_EN_FCC_060831.fm Page 28 Friday, September 1, 2006 11:26 AM

Favourites

• To reject the incoming call, press the end key.

After you end your voice call, the mobile Internet connection automatically resumes.

Disconnect

To close your mobile Internet connection, press the end key.

■ U-Mail

U-Mail enables you to receive e-mail with a multimedia attachment between mobile phone and mobile phone, or mobile phone and Internet e-mail address. Apply CDMA 1X data service from your service provider before using U-Mail.

Account registration

In the standby mode, select Menu > Favourites > U-Mail > E-mail settings >

Check with your service provider for detailed U-Mail function and operation.

■ U-Info access

Because mobile Internet content is designed to be viewed from your device, your wireless service provider is now your mobile Internet service provider as well.

It is likely that your wireless service provider has created a home page and set up your browser to go to this page when you log on to the mobile Internet. At your service provider’s home page, you may find links to a number of other sites.

It should not be necessary to manually configure the browser on your device. Normally this is done by your wireless service provider after you subscribe to the feature. Contact your wireless service provider if you have problems using the browser.

■ UNI-INFO

If your wireless service provider supports this feature, then you can view weather reports, check flight times, view financial information, and much more. Check with your service provider for details. In the standby mode, select Menu >

Favourites > Info.

N6066_UG_EN_FCC_060831.fm Page 29 Friday, September 1, 2006 11:26 AM

Favourites

■ Online calls

Receive a call while online

If your data connection is not active, you may still be able to receive a voice call while you use the WAP browser.

• To answer the incoming call, press the call key.

• To reject the incoming call, press the end key (a network-dependent feature).

While in the voice call, you are not able to load new pages in the browser. After you end your voice call, you must initiate activation of your Internet connection.

Note: If your data connection is active, the incoming calls are automatically diverted to voice mail, depending on your network service.

Make an emergency call while online

You can end your data connection and make an emergency call.

1. To close your mobile Internet connection, press the end key.

2. Press the end key as many times as needed to clear the display and ready the device for calls.

3. Enter the emergency number for your present location (for example, 911). Emergency numbers vary by location.

4. Press the call key.

■ Clear the cache and disconnect

A cache is a memory location that is used to store data temporarily. If you have tried to access or have accessed confidential information requiring passwords, empty the cache after each use. The information or services you have accessed are stored in the cache. To empty the cache while in the browser menu, select

Browser menu > Advanced > Cache > Clear disk Cache from the home page. The

cache is also cleared when you power off your device.

To close your mobile Internet connection while browsing, press the end key.

+ 67 hidden pages
