User Guide for Nokia 6810

9311563

Issue 1 DRAFT

rm-2_en1_FCC.fm Page 2 Monday, February 16, 2004 8:14 AM

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Nokia tune is a sound mark of Nokia Corporation.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

Export Controls

This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion to U.S. law is prohibited.

FCC Notice - Industry Canada Notice

Your phone may cause TV or radio interference (e.g. when using a telephone in close proximity to receiving equipment). The FCC/Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility.This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

9311563/Issue 1 DRAFT

rm-2_en1_FCC.fm Page 3 Monday, February 16, 2004 8:14 AM

Tips and hints

Tips and hints for using your new Nokia 6810 phone and for transferring data from your previous phone to your new phone.

■ Transferring data from the previous phone

• If your old phone has no PC Suite support, the only way to transfer

data is via the SIM card.

1. Transfer all the contact information (names and phone numbers) in the old phone to the SIM card. For more information, refer to the user guide of the old phone.

2. Remove the SIM card and install it in your Nokia 6810 phone.

3. Press Menu and select Contacts, Copy, From SIM card to phone and All to copy the contacts to the new phone.

• If your old phone has PC Suite support, you may be able to

transfer data using the Nokia Content Copier feature of PC Suite.

You can copy data directly from the old phone to the new phone. If you no longer have the old phone, but you have backed it up to a compatible PC at some stage, you may still be able to transfer the backup data to your new phone. Note that only the data that was saved in the old phone when you last backed it up with the PC can be transferred. For more information, refer to the PC Suite documentation.

1. Install the PC Suite version delivered with your 6810 phone.

Note: You have to uninstall the old phone’s PC Suite version before you can install the new version.

2. Start Nokia Content Copier.

3. If you still have the old phone, connect it to the PC and copy the data from the phone to the PC, if you have not done it recently.

4. Connect your new phone to the PC and copy the old phone’s data from the PC to the phone.

✁

rm-2_en1_FCC.fm Page 4 Monday, February 16, 2004 8:14 AM

Tips and hints

Note: Even if you no longer have the old phone, the old backup

data is still on your PC and you may be able to transfer it to your new phone.

With Nokia Content Copier, you can transfer the following data from the following Nokia phones:

• All stored data from

• Nokia 3100 phone

• Nokia 3200 phone

• Nokia 5100 phone

• Nokia 6100 phone

• Nokia 6220 phone

• Nokia 6230 phone

• Nokia 6310i phone

• Nokia 6510 phone

• Nokia 6610 phone

• Nokia 6650 phone

• Nokia 6800 phone

• Nokia 6820 phone

• Nokia 7200 phone

• Nokia 7210 phone

• Nokia 7250 phone

• Nokia 7250i phone

• Nokia 7600 phone

• Nokia 8310 phone

• Nokia 8910 phone

• Nokia 8910i phone

• Contacts and items in the Calendar from the Nokia 6210, 6250 and 7110 phones

•Only Contacts from the Nokia 5210, 8210 and 8850 phones

✁

rm-2_en1_FCC.fm Page 5 Monday, February 16, 2004 8:14 AM

Tips and hints

Note that you cannot back up the e-mail settings of the phone and thus cannot transfer them from your old phone.

■ Returning to standby mode

• Press to return to standby mode from anywhere in the menu.

■ Using the phone in standby mode

• Move the joystick to the left to start writing a message.

• Move the joystick to the right to view the current Calendar month.

• Move the joystick up or down to access the list of contacts.

• Press to access the list of upto 20 last numbers you have called. Select the number you require and press again to make a call.

• Press to open a connection to a browser service (network service).

• Press and hold to call your voice mailbox (network service).

Note that the speed dialling function must be set on. Press Menu, and select Settings, More settings,Call settings and Speed dialling.

• Key in the phone number and press Save to save a new contact. Then key in the name, press OK and Done.

• Change the profile: press , scroll to the profile that you want to activate and press Select.

■ Using the security keyguard

• The security keyguard locks the keypad of the phone with a security code, see Security code (5 to 10 digits) on page 13. The keypad lock remains active, if you open the flip. Press Menu and select Settings,

More settings, Phone settings and Security keyguard.

Enter the security code. To set the security keyguard, select On.

To activate the security keyguard, press Menu and within 1.5 seconds, when the flip is closed. To deactivate the keyguard when the flip is open, press Unlock and OK, then key in the security code. If the flip is closed, press Unlock and within 1.5 seconds, then key in the security code.

✁

rm-2_en1_FCC.fm Page 6 Monday, February 16, 2004 8:14 AM

Tips and hints

■ Turning on the phone lights

• When the keypad is locked, press the power key ( ) to turn on the keypad and display lights.

• When the flip is open, press the keyboard light key ( ) to turn on and off the keyboard lights.

■ Using the e-mail application

• To use your phone’s e-mail application, you have to configure the email and connection settings. For more information, see Settings for the e-mail application on page 64, or the Guide for e-mail application settings leaflet in the phone’s sales package.

To set up the e-mail service with your operator, refer to www.nokia.com/phonesettings.

■ Setting up a Bluetooth connection

1. Press Menu, and select Settings, Connectivity and Bluetooth.

2. To activate the Bluetooth connection, select Bluetooth and On.

3. Select Search for audio enhancements to search for compatible devices and select the device that you want to connect to the phone.

4. Enter the passcode of the selected device.

■ Writing text

• To set the predictive text input on or off, press twice, or press and hold Options.

• To insert a special character when using traditional text input, press

or when using predictive text input, press and hold .

Move the cursor with the joystick to a character and press Use.

• To change the font size of the SMS messages, press Menu and select

Messages, Message settings, Other settings, and Font size.

✁

rm-2_en1_FCC.fm Page 7 Monday, February 16, 2004 8:14 AM

Tips and hints

■ Viewing contacts

• To view a contact name with the default number, press and hold at the name while scrolling through Contacts.

■ Viewing the calendar and calendar notes

• To quickly view the current Calendar month, move the joystick to the

right in standby mode.

• When viewing the calendar notes, move the joystick to the right to

scroll through the notes.

■ Customising personal shortcuts

•Press Go to and select Select options to select the functions you

want as shortcuts.

•Press Go to and select Organise to rearrange the functions within

the shortcut list.

■ Using the radio

• Return to standby mode by pressing briefly; turn off the radio by

pressing and holding .

• The lead of the headset functions as the radio antenna, so let it hang

freely.

• Save the channel in locations 1 to 9 by pressing and holding the

corresponding number key, then keying in the name of the channel and pressing OK.

■ Using the calculator

• When using the calculator with the flip closed, press once to

add, twice to subtract, three times to multiply or four times to divide.

✁

rm-2_en1_FCC.fm Page 8 Monday, February 16, 2004 8:14 AM

Contents

FOR YOUR SAFETY................. 10

General information.............. 13

Access codes......................................... 13

Security code (5 to 10 digits)....... 13

PIN and PIN2 codes (4 to 8 digits),

Module PIN and Signing PIN........ 13

PUK and PUK2 codes (8 digits) .... 14

Barring password (4 digits)........... 14

Wallet code (4 to 10 digits).......... 14

Overview of the phone functions... 14

Shared memory ................................ 15

1. Getting started .................. 16

Installing the SIM card and

the battery ............................................ 16

Charging the battery.......................... 18

Switching the phone on and off..... 18

Opening the flip............................... 19

Switching the keyboard lights

on or off ............................................. 20

2. Your phone......................... 21

Keys (flip closed) ................................. 21

Connectors............................................ 22

Headset.................................................. 22

Keys (flip open).................................... 23

Standby mode ...................................... 24

Screen saver...................................... 26

Wallpaper........................................... 26

Essential indicators

in standby mode .............................. 26

Keypad lock (Keyguard)..................... 28

Over-the-air settings service........... 28

3. Call functions..................... 30

Making a call........................................ 30

Speed dialling a phone number... 31 Answering or rejecting an incoming

call........................................................... 32

Call waiting....................................... 32

Options during a call.......................... 32

4. Writing text........................ 34

Writing text using the messaging

keyboard ................................................ 34

Typing accented characters.......... 35

Writing text when the flip is closed 35

Setting predictive text input

on or off ............................................. 35

Using predictive text input........... 35

Using traditional text input.......... 36

Tips for writing text........................ 37

5. Using the menu .................. 39

Accessing a menu function.............. 39

List of menu functions ...................... 40

6. Menu functions .................. 42

Messages (Menu 1) ............................ 42

Text messages (SMS)...................... 42

Archive folder and my folders...... 45

Templates........................................... 45

Distribution lists .............................. 46

Text message counter .................... 47

Multimedia messages..................... 47

Deleting messages........................... 51

E-mail application........................... 52

Chat..................................................... 55

Voice messages ................................ 61

Info messages................................... 62

Message settings............................. 62

Settings for the e-mail

application......................................... 64

Font size setting .............................. 67

Service commands .......................... 68

Call register (Menu 2)........................ 68

Recent calls lists .............................. 68

Timers and counters ....................... 69

Contacts (Menu 3).............................. 69

Selecting settings for contacts.... 70

rm-2_en1_FCC.fm Page 9 Monday, February 16, 2004 8:14 AM

Saving names and phone numbers

(Add contact)..................................... 70

Adding an image to a name or

number in contacts ......................... 71

Searching for a contact.................. 72

Deleting contacts............................. 72

Editing or deleting details

in contacts ......................................... 73

My presence ...................................... 73

Subscribed contacts ........................ 75

Copying contacts ............................. 77

Sending and receiving a business

card ...................................................... 77

Speed dials......................................... 77

Voice dialling..................................... 78

Info numbers and service

numbers.............................................. 79

My numbers....................................... 79

Caller groups ..................................... 79

Settings (Menu 4)................................ 80

Profiles ................................................ 80

Chat and my presence settings.... 81

Tone settings ..................................... 81

Display settings ................................ 82

Time and date settings ................... 83

Personal shortcuts ........................... 84

Connectivity....................................... 84

More settings .................................... 89

Security settings............................... 92

Restore factory settings ................. 93

Gallery (Menu 5).................................. 94

Radio (Menu 6) .................................... 96

Tuning a radio channel................... 96

Using the radio ................................. 97

Organiser (Menu 7)............................. 98

Alarm clock ........................................ 98

Calendar.............................................. 99

To-do list ......................................... 100

Notes ................................................ 101

Wallet............................................... 102

Synchronisation............................. 105

Applications (Menu 8)..................... 107

Games............................................... 108

Collection ........................................ 108

Extras................................................ 110

Services (Menu 9)............................. 113

Basic steps for accessing and

using services................................. 113

Setting up the phone for

a service........................................... 113

Connecting to a service .............. 114

Browsing the pages of a service 115

Disconnecting from a service .... 116

Appearance settings of

the multi-mode browser............. 116

Cookies............................................. 117

Bookmarks....................................... 117

Downloading .................................. 118

Service inbox.................................. 118

Cache memory ............................... 119

Browser security............................ 119

SIM services (Menu 10).................. 122

7. PC Connectivity ............... 123

PC Suite............................................... 123

EGPRS, HSCSD and CSD .............. 124

Using data communications

applications........................................ 124

8. Battery information ........ 125

Charging and Discharging.............. 125

CARE AND MAINTENANCE. 126

IMPORTANT SAFETY

INFORMATION..................... 127

rm-2_en1_FCC.fm Page 10 Monday, February 16, 2004 8:14 AM

FOR YOUR SAFETY

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual.

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Don't use a hand-held phone while driving.

INTERFERENCE

All wireless phones may get interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any regulations or rules. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELLING

Don't use the phone at a refuelling point. Don't use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Don't use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules.

USE SENSIBLY

Use only in the normal position. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user's guide for detailed safety instructions. Do not connect incompatible products.

rm-2_en1_FCC.fm Page 11 Monday, February 16, 2004 8:14 AM

FOR YOUR SAFETY

BACKUP COPIES

Remember to make backup copies of all important data .

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

CALLING

Ensure the phone is switched on and in service. Enter the phone number, including the area code, then press To end a call, press

. To answer a call, press .

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press as many times as needed (e.g. to exit a call, to exit a menu, etc.) to clear the display. Enter the emergency number, then press . Give your location. Do not end the call until told to do so.

■ Network Services

The wireless phone described in this guide is approved for use on the EGSM 900, GSM1800 and GSM 1900 networks.

Triband is a network dependent feature. Check with your local service provider if you can subscribe to and use this feature.

This phone supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this phone, such as MMS, browsing, e-mail, chat, presence-enhanced contacts, remote OMA Data Syncronization, and content downloading via browser or over MMS, require network support for these technologies.

A number of features included in this guide are called Network Services. These are special services that you arrange through your wireless service provider. Before you can take advantage of any of these Network Services, you must subscribe to them through your service provider and obtain instructions for their use from your service provider.

Note: Some networks may not support all language-dependent characters and/or services.

■ About enhancements

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from ACP-7, ACP-8, ACP-9, ACP-12, LCH-8, LCH-9, LCH-12 and AC-1.

rm-2_en1_FCC.fm Page 12 Monday, February 16, 2004 8:14 AM

FOR YOUR SAFETY

Warning: Use only batteries, chargers and accessories approved by the

phone manufacturer for use with this particular phone model. The use of any other types may invalidate any approval or warranty applying to the phone, and may be dangerous.

For availability of approved accessories, please check with your dealer.

A few practical rules for enhancements operation

• Keep all accessories out of the reach of small children.

• When you disconnect the power cord of any accessory, grasp and pull the plug, not the cord.

• Check regularly that any vehicle-installed accessories are mounted and are operating properly.

• Installation of any complex car accessories must be made by qualified personnel only.

rm-2_en1_FCC.fm Page 13 Monday, February 16, 2004 8:14 AM

General information

■ Access codes

Security code (5 to 10 digits)

The security code helps to protect your phone against unauthorised use. The preset code is 12345. When you have changed the code, keep the new code secret and in a safe place separate from your phone. To change the code, and to set the phone to request it, see Security settings on page 92.

If you key in an incorrect security code five times in succession, the phone may display Code error. Wait for five minutes and key in the code again.

PIN and PIN2 codes (4 to 8 digits), Module PIN and Signing PIN

• The PIN (Personal Identification Number) code protects your SIM card against unauthorised use. The PIN code is usually supplied with the SIM card. Set the phone to request the PIN code each time the phone is switched on, see Security settings on page 92.

• The PIN2 code may be supplied with the SIM card and is required to access some functions.

• The module PIN is required to access the information in the security module. See Security module on page 119. The module PIN is supplied with the SIM card if the SIM card has a security module in it.

• The signing PIN is required for the digital signature. See Digital signature on page 121. The signing PIN is supplied with the SIM card if the SIM card has a security module in it.

If you key in an incorrect PIN code three times in succession, the phone may display PIN blocked or PIN code blocked and ask you to key in the PUK code.

rm-2_en1_FCC.fm Page 14 Monday, February 16, 2004 8:14 AM

General information

PUK and PUK2 codes (8 digits)

The PUK (Personal Unblocking Key) code is required to change a blocked PIN code. The PUK2 code is required to change a blocked PIN2 code.

If the codes are not supplied with the SIM card, contact your network operator or service provider.

Barring password (4 digits)

The barring password is required when using the Call barring service, see Security settings on page 92. You can obtain the password from your service provider.

Wallet code (4 to 10 digits)

The wallet code is required to access the wallet services. If you key in an incorrect wallet code several times, the wallet application is blocked for five minutes. For further information, see Wallet on page 102.

■ Overview of the phone functions

Your Nokia 6810 phone is approved for use on EGSM 900,GSM 1800 and GSM 1900 networks. It provides many functions that are practical for daily use, such as calendar, radio, loudspeaker, clock and alarm clock. Your phone also supports the following functions (many of which are network services):

• EDGE (Enhanced Data rates for GSM Evolution), see EGPRS on page

87. EDGE packet transmission networks enable faster connection than GPRS.

• The xHTML browser, which allows you to retrieve and view colourful and rich graphical content from service providers’ web servers. See Services (Menu 9) on page 113.

• Presence-enhanced contacts, which allow you to conveniently share your availability information with your colleagues, family and friends with compatible devices and services. See My presence on page 73.

• Chat, which is a way of sending short text messages that are delivered to online users. See Chat on page 55.

rm-2_en1_FCC.fm Page 15 Monday, February 16, 2004 8:14 AM

General information

• The messaging keyboard for writing text comfortably, see Writing and sending messages on page 42.

• The e-mail function, which allows you to write, send and retrieve emails from your e-mail account. See E-mail application on page 52.

• The multimedia messaging service (MMS), which allows you to send and receive multimedia messages that contain text, picture, sound or video clips to and from compatible devices. You can save the pictures and ringing tones for personalising your phone, see Multimedia messages on page 47.

• Polyphonic sound (MIDI), which consists of several sound components that are played at the same time. The phone has sound components from over 40 instruments and it can play up to 16 instruments at the same time. The phone supports Scalable Polyphonic MIDI (SP-MIDI) format.

• Java 2 Micro Edition, J2METM includes some JavaTM applications and games that have been specially designed for mobile phones. You can download new applications and games to your phone, see Applications (Menu 8) on page 107.

• An integrated stereo radio. You can listen to the radio using a headset or via the loudspeaker, see Radio (Menu 6) on page 96.

Shared memory

The following features in this phone may share memory: contacts, text, chat and multimedia messages, the e-mail application, voice tags and SMS distribution lists, images, ringing tones, video and sound clips in the gallery, calendar, to-do notes, Java games, applications, and the note application. Using any oif these features may reduce the memory available for applications that require shared memory. This is especially true with heavy use of any of the features (although some of them may have a certain amount of memory specially allotted to them in addition to the amount of memory shared with other features). For example, saving many images, Java applications, etc. may take all of the shared memory and your phone may display a message that the memory is full. In this case, delete some of the information or entries stored in the shared memory features before continuing.

rm-2_en1_FCC.fm Page 16 Monday, February 16, 2004 8:14 AM

Getting started

1. Getting started

■ Installing the SIM card and the battery

• Keep all miniature SIM cards out of the reach of small children.

• The SIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting or removing the card.

• Before installing the SIM card, always make sure that the phone is switched off and disconnected from any enhancement and then remove the battery.

1. With the back of the phone facing you, push the back cover release button (1) and, at the same time, slide the back cover off the phone. If the battery is in place, remove it by lifting it up.

2. To release the SIM card holder, slide the card holder backwards (2) and lift it up (3). Insert the SIM card into the SIM card holder (4). Make sure that the SIM card is properly inserted and that the golden contact area on the card is facing downwards.

rm-2_en1_FCC.fm Page 17 Monday, February 16, 2004 8:14 AM

Getting started

3. Close the SIM card holder (5) and slide it back into place (6).

4. Replace the battery (7).

5. Direct the back cover towards the locking catches on the phone (8) and slide the back cover until it locks into place (9).

rm-2_en1_FCC.fm Page 18 Monday, February 16, 2004 8:14 AM

Getting started

■ Charging the battery

1. Connect the lead from the charger to the socket on the bottom of your phone.

2. Connect the charger to an AC wall socket.

The text Charging is displayed briefly if the phone is switched on. If the battery is completely flat, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

You can use the phone while the charger is connected.

The charging time depends on the charger and the battery used. For example, charging a BLC-2 battery with the ACP-12 charger takes about 1 hour and 30 minutes while the phone is in standby mode.

■ Switching the phone on and off

Warning: Do not switch the phone on when wireless phone use is

prohibited or when it may cause interference or danger.

Press and hold the power key .

• If the phone requests a PIN code or a security code, key in the code, and press OK.

See also Security settings on page 92 and General information on page 13.

• If the phone displays Insert SIM card even though the SIM card is properly inserted, or

SIM card not supported, contact your network

operator or service provider. Your phone does not support 5-Volt SIM cards and the card may need to be changed.

rm-2_en1_FCC.fm Page 19 Monday, February 16, 2004 8:14 AM

TIPS ON EFFICIENT OPERATION: Your phone has a built-in antenna. As with any other radio transmitting device, do not touch the antenna unnecessarily when the phone is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Not touching the antenna area during a phone call optimises the antenna performance and the talktime of your phone.

Opening the flip

1. Hold the phone with both hands and open the flip as shown in picture (1).

Getting started

2. Turn the flip until you hear it click into place (2). Make sure that the golden contacts of the flip and the phone touch each other.

rm-2_en1_FCC.fm Page 20 Monday, February 16, 2004 8:14 AM

Getting started

3. Turn the phone to a horizontal position and hold it as shown in picture (3). The loudspeaker function automatically activates when the flip is open.

Switching the keyboard lights on or off

• The keyboard lights are not lit automatically, when you open the flip. To turn on the lights, press the light key on the top left corner of the keyboard. The keyboard lights are switched off after a certain time, but they are turned on again as soon as you press any key.

• To switch the keyboard lights off, press the keyboard light key or close the flip.

rm-2_en1_FCC.fm Page 21 Monday, February 16, 2004 8:14 AM

2. Your phone

■ Keys (flip closed)

1. Power key

Switches the phone on and off.

When the keypad is locked, pressing the power key turns the phone’s display lights on for approximately 15 seconds.

2. Volume key

Adjusts the volume of the earpiece, the headset and the loudspeaker.

3. Selection keys and

The function of the keys depends on the guiding text shown on the display above the keys, see Standby mode on page 24.

4. 5-way joystick

Enables scrolling through names, phone numbers, menus or settings. The 5-way joystick is also used to move the cursor up and down, right and left when writing text, using the calendar, and in some game applications. Pressing the joystick also functions as the middle selection key, and pressing it briefly selects the function shown on the display above the joystick.

In standby mode, the joystick functions as a shortcut. Press the joystick

• right to access the Calendar.

Your phone

rm-2_en1_FCC.fm Page 22 Monday, February 16, 2004 8:14 AM

Your phone

• left to start writing an SMS message.

• up or down to access the list of contacts.

5. dials a phone number, and answers a call. In standby mode it shows the list of the most recently called numbers.

6. ends an active call. Exits from any function.

7. - enter numbers and characters.

and are used for various purposes in different functions.

8. Ear piece

■ Connectors

1. Charger connector

2. Pop-Port for headsets, data cable and other enhancements. Connect an enhancement to the Pop-Port connector as shown in the picture.

connector

3.Infrared (IR) port

4.Loudspeaker

5.Microphone

■ Headset

Connect the compatible headset to the Pop-Port connector of your phone.

Warning: This headset may affect your ability to hear sounds around you. Do not use this headset in situations that may endanger your safety.

rm-2_en1_FCC.fm Page 23 Monday, February 16, 2004 8:14 AM

You can carry the headset as shown in the picture.

■ Keys (flip open)

When you open the flip, the display graphics are rotated 90 degrees and the left, middle and right selection keys change positions, but the guiding texts above the selection keys do not change. To use the keys to write and edit text, see Writing text using the messaging keyboard on page 34.

Your phone

1. Keyboard light key switches the keyboard light on or off to provide additional lighting while using the keyboard. See also Switching the keyboard lights on or off on page 20.

rm-2_en1_FCC.fm Page 24 Monday, February 16, 2004 8:14 AM

Your phone

2. Profile key opens a list of profiles when pressed briefly. Pressing and holding down the key switches the phone off.

3. ends an active call. Exits from any function.

4. Backspace deletes characters.

5. Enter key forces a line feed when editing text.

6. Shift keys and enter upper-case letters and symbols. You can either press the shift key first and then the desired key or press both keys at the same time.

7. Space bar keys and enter a space.

8. 5-way joystick . For usage, see Keys (flip closed) on page 21. To select a function as shown in the picture, press the joystick when the flip is open.

9. dials a phone number, and answers a call. In standby mode it shows the list of most recently called numbers.

10.Right selection key . The function of the key depends on the guiding text shown on the display above the key.

11.Power key/Left selection key switches the power on and off. When the phone’s messaging keyboard is open and the phone is on, the function of the left selection key depends on the guiding text shown on the display above the key.

12.Character key opens a set of characters and symbols during text writing.

■ Standby mode

When the phone is ready for use (the flip can be either closed or open), and you have not keyed in any characters, the phone is in standby mode.

rm-2_en1_FCC.fm Page 25 Monday, February 16, 2004 8:14 AM

1. Shows the name of the network or the operator logo to indicate in which cellular network the phone is currently being used.

2.Shows the signal strength of the cellular network at your current location. The higher the bar, the stronger the signal.

3.Shows the battery charge level. The higher the bar, the more power in the battery

4. The left selection key in standby mode is Go to.

Press Go to to view the list of available functions that you can add to your personal shortcut list. Press Options and select

• Select options to view the list of available functions that you can add.

Scroll to the desired function and press Mark to add it to the shortcut list. To remove a function from the list, press Unmark.

• Organise to rearrange the functions within the list. Select the desired function and press Move, then select where you want to move the function.

If for some reason you have deleted the content of the Go to menu, press Add to add a function.

5. The middle selection key in standby mode is Menu.

6. The right selection key in standby mode is Names, an operatorspecific key or a shortcut to a function that you have selected. If you press the right selection key when the text is

• Names, you can access the Contacts menu.

• the operator-specific key, you can access an operator-specific

web site.

• a specific function that you have selected and activated in Right

selection key, you can access it directly. See Personal shortcuts on

page 84.

Your phone

rm-2_en1_FCC.fm Page 26 Monday, February 16, 2004 8:14 AM

Your phone

See also Essential indicators in standby mode on page 26.

Screen saver

The phone automatically activates a screen saver after a certain length of time when none of the phone functions have been used, see Display settings on page 82.

When the screen saver is on, the phone still displays the icons indicating missed calls , keypad lock , silent mode , received messages

and received multimedia messages .

Wallpaper

You can set your phone to display a background picture as wallpaper when the phone is in standby mode, see Display settings on page 82.

Essential indicators in standby mode

You have received one or several text or picture messages. See Reading and replying to an SMS message or an SMS e-mail on page 44.

You have received one or several multimedia messages. See Reading and replying to a multimedia message on page 50.

Your phone is connected to the chat service and the availability status is online or offline, respectively. See Connecting to and disconnecting from the chat service on page 57.

You have received one or several chat messages and you are connected to the chat service. See Connecting to and disconnecting from the chat service on page 57.

The phone’s keypad is locked. See Keypad lock (Keyguard) on page 28 and Automatic keyguard and Security keyguard in Phone settings on page 90.

The phone does not ring for an incoming call or a text message because Incoming call alert is set to Off and Message alert tone is set to Off. See Tone settings on page 81.

rm-2_en1_FCC.fm Page 27 Monday, February 16, 2004 8:14 AM

The alarm clock is set to On. See Alarm clock on page 98.

The countdown timer is running. See Countdown timer on page

112.

The stopwatch is running in the background. See Stopwatch on page 112.

When the EGPRS connection mode Always online is selected and the EGPRS service is available, the indicator is shown on the top left of the display. See EGPRS connection on page 88.

When an EGPRS connection is established, this indicator is shown on the top left of the display. See EGPRS connection on page 88 and Browsing the pages of a service on page 115.

The EGPRS connection is suspended (on hold), for example, if there is an incoming or outgoing call during an EGPRS dial-up connection.

The infrared connection indicator. See Infrared on page 86.

The Bluetooth connection indicator. See Bluetooth wireless technology on page 84.

All your calls are diverted to another number. If you have two phone lines, the divert indicator for the first line is and for the second line is . See Call settings on page 89.

or If you have two phone lines, the indicator displays the selected

phone line. See Call settings on page 89.

The loudspeaker has been activated. See Options during a call on page 32.

Calls are limited to a closed user group. See Security settings on page 92.

The timed profile is selected. See Profiles on page 80.

Your phone

, , or

A headset, handsfree, loopset or music stand enhancement is connected to the phone.

rm-2_en1_FCC.fm Page 28 Monday, February 16, 2004 8:14 AM

Your phone

Time and date

See Time and date settings on page 83.

■ Keypad lock (Keyguard)

You can lock the keypad to prevent the keys being accidentally pressed, for example, when your phone is in your handbag. You can only lock the keypad when the flip is closed.

• Locking the keypad

In standby mode, press Menu and then within 1.5 seconds.

• Unlocking the keypad

Press Unlock and then within 1.5 seconds or open the flip. Note that the keyguard will not be activated when if you close the flip, if the automatic keyguard is not activated.

To answer a call when the keyguard is on, press . During a call, the phone can be operated normally. When you end or reject the call, the keypad will automatically lock, if the display is empty.

For locking the keypad during a call, see Options during a call on page 32, and for setting the security keyguard, see Security keyguard in Phone settings on page 90.

Note: When Keyguard is on, calls may be possible to the emergency number programmed into your phone (e.g. 112 or other official emergency number). Key in the emergency number and press . The number is displayed only after you have keyed in its last digit.

■ Over-the-air settings service

In order to use MMS, EGPRS, and other wireless services, you need to have proper connection settings on your phone. You may be able to receive the settings directly as an over-the-air message and then save them on your phone. For more information on the availability of the settings, contact your network operator, service provider or the nearest authorised Nokia dealer.

You may be able to receive the connection settings for EGPRS, multimedia messages, synchronisation, chat and presence, e-mail and

rm-2_en1_FCC.fm Page 29 Monday, February 16, 2004 8:14 AM

for the multi-mode browser. For more information about receiving the settings, see Settings for the e-mail application on page 52.

When you have received the connection settings as an over-the-air message Connection settings received is displayed.

• To save the settings, press Options and select Save. If the phone asks you to Enter settings’ PIN:, key in the PIN code for the settings and press OK. For the availability of the PIN code, contact the service provider that supplies the settings.

If no settings have been saved yet, the settings are saved under the first free connection set.

• To view the received settings first, press Options and select View. To save the settings, press Save.

• To discard the received settings, press Options and select Discard.

To activate the settings, see Connecting to a service on page 114.

If you want to delete a connection set from the phone, key in *#335738# (*#delset# in letters) in standby mode, select a connection set that you want to delete and press Delete. Then confirm your selection and the phone returns to standby mode.

Your phone

rm-2_en1_FCC.fm Page 30 Monday, February 16, 2004 8:14 AM

Call functions

3. Call functions

■ Making a call

1. Key in the phone number, including the area code. If you key in an incorrect character, press Clear to delete it. To make a call when the flip is open, key in the phone number using the number keys. The loudspeaker is always activated, when you open the flip.

For international calls, press twice for the international prefix or + if the flip is open, (the + character replaces the international access code) and then key in the country code, the area code without the leading 0, if necessary, and finally the phone number.

2. Press to call the number.

To adjust the volume during a call, use the volume key on the side of the phone.

3. Press to end the call or to cancel the call attempt.

See also Options during a call on page 32.

Making a call using contacts

• To search for a name/phone number that you have saved in Contacts See Searching for a contact on page 72. Press to call the number on the display.

Last number redialling

• In standby mode, press once to access the list of upto 20 last numbers you called or attempted to call. Scroll to the number or name that you want, and press to call the number.

Calling your voice mailbox (network service)

• In standby mode when the flip is closed, press and hold , or press and . When the flip is open, press and hold the corresponding number key on the keyboard.

If the phone requests the voice mailbox number, key it in and press

OK. See also Voice messages on page 61.

+ 102 hidden pages
