Microsoft RM-160 User Manual

Draft

Nokia N95 User guide

9249884

ISSUE 2 EN

DECLARATION OF CONFORMITY

Draft

Hereby, NOKIA CORPORATION declares that this RM-160 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/ EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/ phones/declaration_of_conformity/.

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of-life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal

waste. For more information, see product Eco-Declaration or country specific information at www.nokia.com. © 2007 Nokia. All rights reserved. Nokia, Nokia Connecting People, Nseries, N95, and Visual Radio are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2007. Tegic Communications, Inc. All rights reserved. Portions of the Maps software are copyright © 2007 The FreeType Project. All rights reserved. This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with

trademarks of Symbian Ltd. Java and all Java-based marks are trademarks or registered trade marks of Sun Microsystems, Inc.

MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls This device may contain commodities, technology or software subject to export

laws and regulations from the US and other countries. Diversion contrary to law is prohibited. FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support,

functionality of the applications, or the information in the applications or these

Draft

materials. Nokia does not provide any warranty for the third-party applications. BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE

MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

Nokia Care contact information

US: Nokia Inc. 4630 Woodland Corporate Blvd. Suite 160 Tampa FL 33614 Telephone: 1-888-NOKIA-2U (1-888-665-4228) Facsimile: 1-813-249-9619 TTY/TDD Users: 1-800-24-NOKIA (1-800-246-6542) www.nokiausa.com

Canada: Nokia Products Ltd., 601 Westney Rd. S., Ajax, ON L1S 4N7

Issue 2 EN, 9249884

Contents

Draft

For your safety........................................... 7

Support.....................................................10

Help ........................................................................................10

Nokia support and contact information .......................10

Get started ............................................................................10

Additional applications......................................................10

Your Nokia N95.......................................11

Software updates ................................................................11

Settings ..................................................................................11

Welcome................................................................................11

Transfer content from another device...........................11

Essential indicators.............................................................12

Fast downloading................................................................14

Volume and loudspeaker control ....................................14

Multimedia menu................................................................14

Keypad lock (keyguard)......................................................15

Headset ..................................................................................15

Memory card.........................................................................16

File manager ........................................................................17

Download! ............................................................................18

Web browser ...........................................19

Connection security............................................................19

Bookmarks view...................................................................19

Browse the web...................................................................20

End connection....................................................................23

Settings..................................................................................23

Connections..............................................25

Wireless LAN ........................................................................25

Connection manager .........................................................27

Bluetooth connectivity .....................................................27

Infrared connection ........................................................... 31

USB ........................................................................................31

PC connections ....................................................................32

Synchronization .................................................................32

Device manager ..................................................................32

Modem ..................................................................................33

Media applications ..................................34

Music player ........................................................................34

Radio .....................................................................................38

Video center ........................................................................39

RealPlayer ............................................................................41

Adobe Flash Player .............................................................42

Draft

Nokia Lifeblog .....................................................................42

Camera..................................................... 46

Take pictures.........................................................................46

Take pictures in a sequence..............................................51

You in the picture—self-timer .........................................51

Record videos........................................................................52

Gallery ..................................................... 55

View and browse files ........................................................55

Print Basket...........................................................................57

Albums....................................................................................57

Free memory .........................................................................58

Back-up files.........................................................................58

Edit images............................................................................58

Edit video clips .....................................................................59

Slide show .............................................................................61

TV out mode..........................................................................61

Presentations........................................................................62

Image print............................................................................63

Movie director......................................................................63

Print online............................................................................65

Online sharing ......................................................................65

Home network .....................................................................66

Positioning................................................70

GPS receiver..........................................................................71

About satellite signals .......................................................71

Position requests.................................................................72

Maps ......................................................................................72

Landmarks ............................................................................75

GPS data ...............................................................................76

Personalize your device...........................78

Profiles—set tones ..............................................................78

3-D tones .............................................................................79

Change the look of your device .....................................80

Active standby mode..........................................................80

Time management ...................................82

Clock ......................................................................................82

Calendar ...............................................................................82

Messaging ...............................................85

Write text..............................................................................86

Write and send messages.................................................86

Inbox—receive messages ..................................................87

Mailbox .................................................................................88

View messages on a SIM card.........................................90

Messaging settings.............................................................90

Make calls ................................................95

Draft

Voice calls..............................................................................95

Answer or decline a call....................................................98

Log ..........................................................................................98

Tools....................................................... 108

Application manager .......................................................108

Digital rights management ...........................................110

Voice commands ..............................................................111

Contacts (Phonebook) ......................... 100

Save and edit names and numbers ............................. 100

Copy contacts....................................................................101

Add ringing tones for contacts.....................................102

Create contact groups .................................................... 102

Office..................................................... 103

Quickoffice ........................................................................103

Notes ................................................................................... 104

Recorder .............................................................................104

Adobe Reader ...................................................................104

Calculator ..........................................................................105

Converter ...........................................................................105

Zip manager ...................................................................... 105

Wireless Keyboard ........................................................... 106

Barcode reader .................................................................106

Settings ................................................ 112

General ................................................................................112

Phone ..................................................................................117

Connection ........................................................................119

Applications .......................................................................123

Troubleshooting: Q&A ......................... 124

Battery information ............................. 127

Charging and discharging...............................................127

Nokia battery authentication guidelines ...................127

Care and maintenance ......................... 129

Additional safety information............. 130

Index ...................................................... 133

For your safety

Draft

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS Follow any restrictions. Switch the device off near medical equipment.

SWITCH OFF IN AIRCRAFT Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING Follow any restrictions. Do not use the device where blasting is in progress.

USE SENSIBLY Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE Your device is not water-resistant. Keep it dry.

BACK-UP COPIES Remember to make backup copies or keep a written record of all important information stored in your device.

CONNECTING TO OTHER DEVICES When

Draft

connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS Ensure the phone function of the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the standby mode. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

About your device

The wireless device described in this guide is approved for use on the (E)GSM 850, 900, 1800 and 1900 MHz, and WCDMA (HSDPA) 850 and 1900 MHz networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred, or forwarded.

Your device supports internet connections and other methods of connectivity. Like computers, your device may

be exposed to viruses, malicious messages and applications, and other harmful content. Exercise caution and open messages, accept connectivity requests, download content, and accept installations only from trustworthy sources. To increase the security of your device, consider installing antivirus software with a regular update service and using a firewall application.

Warning: To use any features in this device, other

than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and 2003). Not all file formats can be viewed or modified.

During operation, such as an active high-speed data connection, the device may feel warm. In most cases, this condition is normal. If you suspect the device is not working properly, take it to the nearest authorized service facility.

Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other thirdparty sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.

The images in this guide may differ from your device

Draft

display.

Network services

To use the phone you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as MMS, browsing, and e-mail require network support for these technologies.

Enhancements, batteries, and chargers

Always switch the device off and disconnect the charger before removing the battery.

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from a DC-4, AC-4, or AC-5 charger and from an AC-1, ACP-8, ACP-9, ACP-12U, or LCH-12 charger when used with the CA-44 charger adapter.

The battery intended for use with this device is BL-5F.

Warning: Use only batteries, chargers, and

enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

Support

Draft

Model number: Nokia N95-3

Support

Hereinafter referred to as Nokia N95.

Help

Your device has context-sensitive help. When an application is open, select Options > Help to access help for the current view.

When you are reading the instructions, to switch between help and the application that is open in the background, press and hold .

To open help from the main menu, select Applications >

Help. Select the desired application to view its help topics.

Nokia support and contact information

Check www.nseries.com/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

On the website, you can get information on the use of Nokia products and services. If you need to contact customer service, check the list of local Nokia contact centers at www.nokia.com/customerservice

For maintenance services, check your nearest Nokia service center at www.nokia.com/repair

Get started

See the Get started guide for keys and parts information and instructions for setting up the device for use.

Additional applications

There are various applications provided by Nokia and different third-party software developers to help you do more with your Nokia N95. These applications are explained in the Additional applications leaflet which is available at the Nokia N95 product support pages at

www.nseries.com/support

or your local Nokia web site.

Your Nokia N95

Draft

Software updates

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. You may be able to request these updates through the Nokia Software Updater PC application. To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000 or XP operating system, broadband internet access, and a compatible data cable to connect your device to the PC.

To get more information and to download the Nokia Software Updater application, visit www.nokia.com/

softwareupdate or your local Nokia web site.

Settings

Your device normally has MMS, GPRS, streaming, and mobile internet settings automatically configured in the device, based upon your wireless service provider information. You may have settings from your service providers already installed in your device, or you may receive or request the settings from the service providers as a special message.

Welcome

When you switch on your device for the first time,

Welcome opens. Select from the following:

• Sett. wizard—to configure various settings. See the

Additional applications leaflet.

• Transfer—to transfer content, such as contacts and

calendar entries, from a compatible Nokia device. See ‘Transfer content from another device’, p. 11.

To open the Welcome later, press , and select

Applications > Welcome. You can also access the

individual applications in their own menu locations.

Transfer content from another device

You can transfer content, such as contacts, from a compatible Nokia device to your Nokia N95 using Bluetooth connectivity or infrared. Your device notifies you if the other device is not compatible.

The type of content that can be transferred depends on the model of the device from which you want to transfer content. If the other device supports synchronization, you

Your Nokia N95

can also synchronize data between the other device and

Draft

your Nokia N95.

If the other device cannot be powered on without a SIM card, you can insert your SIM card in it. When Nokia N95 is switched on without a SIM card, the offline profile is automatically activated.

Transfer content

Your Nokia N95

1 To use the application for the first time, on your Nokia

N95, select it in the Welcome application, or press , and select Tools > Transfer. If you have used the application before and want to start a new transfer, select Transfer data.

2 Select whether you want to use Bluetooth connectivity

or infrared to transfer the data. Both devices must support the selected connection type.

3 If you select Bluetooth connectivity:

To have Nokia N95 search for devices with Bluetooth connectivity, select Continue. Select the device from which you want to transfer content from the list. You are asked to enter a code on your Nokia N95. Enter a code (1-16 digits), and select OK. Enter the same code on the other device, and select OK. The devices are now paired. See ‘Pair devices’, p. 29. For some phone models, the Data transfer application is sent to the other device as a message. To install Data

transfer on the other device, open the message, and

follow the instructions on the display.

If you select infrared, connect the two devices. See ‘Infrared connection’, p. 31.

4 From your Nokia N95, select the content you want to

transfer from the other device.

Content is transferred from the memory of the other device to the corresponding location in your Nokia N95. Transferring time depends on the amount of data to be transferred. You can cancel transferring and continue later.

If the other device supports synchronization, you can keep the data up-to-date in both devices. To start a synchronization with a compatible Nokia device, select

Phones, scroll to the device, and select Options > Synchronize. Follow the instructions on the display.

The synchronization is two-way, and the data in both devices is made the same. If an item is deleted from either device, it is deleted from the other device as well when synchronizing; you cannot restore deleted items with synchronization.

To view the log of a previous transfer, select Transfer log.

Essential indicators

The device is being used in a GSM network.

The device is being used in a WCDMA network

(network service).

HSDPA support in the device is activated and the

Draft

device being used in a WCDMA network that supports HSDPA (network service).

You have one or more unread messages in the Inbox

folder in Messaging.

You have received new e-mail in the remote mailbox.

There are messages waiting to be sent in the Outbox

folder.

You have missed calls.

Shown if Ringing type is set to Silent and Message

alert tone, and E-mail alert tone are set to Off.

The device keypad is locked.

A clock alarm is active.

The second phone line is being used (network service).

All calls to the device are forwarded to another number. If you have two phone lines (network service), a number indicates the active line.

A compatible headset is connected to the device.

indicates the connection has been lost.

A compatible TV out cable is connected to the device.

A compatible TTY is connected to the device.

A data call is active.

A GPRS packet data connection is active. indicates the connection is on hold and that a connection is available.

A packet data connection is active in a part of the network that supports EDGE. indicates the connection is on hold and that a connection is available. The icons indicate that EDGE is available in the network, but your device is not necessarily using EDGE in the data transfer.

A WCDMA packet data connection is active. indicates the connection is on hold and that a connection is available.

You have set the device to scan for WLANs, and a

WLAN is available. See ‘Wireless LAN’, p. 25.

A WLAN connection is active in a network that has

encryption.

A WLAN connection is active in a network that does

not have encryption.

Bluetooth connectivity is on.

Data is being transmitted using Bluetooth connectivity. When the indicator is blinking, your device is trying to connect with another device.

A USB connection is active.

Your Nokia N95

An infrared connection is active. If the indicator is

Draft

blinking, the device is trying to connect to the other device or the connection has been lost.

Fast downloading

You can activate or deactivate support for high-speed downlink packet access (HSDPA, also called 3.5G) in the

Your Nokia N95

device settings. See ‘Packet data’, p. 122.

HSDPA is a network service in WCDMA networks and it provides high data download speed. When HSDPA support in the device is activated and the device is connected to a WCDMA network that supports HSDPA, downloading data such as messages, e-mail, and browser pages through the cellular network may be faster.

For availability and subscription to data connection services, contact your service provider.

HSDPA only affects the download speed; sending data to the network, such as sending messages and e-mail, is not affected.

Volume and loudspeaker control

To increase or decrease the volume level when you have

an active call or are listening to a sound, press the volume key.

The built-in loudspeaker allows you to speak and listen from a short distance without having to hold the device to your ear.

Warning: Do not hold the device near your ear when

the loudspeaker is in use, because the volume may be

extremely loud.

To use the loudspeaker during a call, select Options >

Activate loudspeaker.

To turn off the loudspeaker, select Options > Activate

handset.

Multimedia menu

The multimedia menu provides quick access to multimedia content and predefined applications.

To open the multimedia menu, press , or when the device is in the standby mode, open the media keys under the 2-way slide.

To scroll in the multimedia menu, use the scroll key. To

Draft

scroll faster, press and hold the key. To open an application, press .

To change the shown shortcuts, select Options > Menu

items. You can delete, add, or rearrange shortcuts to

applications, browser bookmarks, and radio channels defined in Radio.

You can customize the appearance of the multimedia menu. To change the images shown in the background, select Options > Background images and the desired option. To set zooming and panning on or off, select

Options > Image effects. To set sounds on or off, select Options > Menu sounds.

Keypad lock (keyguard)

To lock the keys, press , then .

To unlock the keys, open the 2-way slide, or press , then

You can have the keypad lock activated automatically after a time-out or when the 2-way slide is closed. See ‘Security’, p. 114

When the keypad lock is on, calls may be possible to the official emergency number programmed into your device.

Headset

You can connect a compatible headset or compatible headphones to the Nokia AV Connector (3.5 mm) of your device. You may need to select the cable mode.

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Warning: When you use the headset, your ability to

hear outside sounds may be affected. Do not use the headset where it can endanger your safety.

To use a headset or headphones with a remote control unit, for example, the Nokia Audio Controller AD-43, connect the unit to the connector in the device, then connect the headset or headphones to the unit.

Some headsets do not include a microphone. For phone calls, use such a headset with a remote control unit or the microphone of the device.

Your Nokia N95

When using certain headset enhancements, for example,

Draft

the Nokia Audio Controller AD-43, to adjust the volume during a call, use the volume key in the device. The Nokia Audio Controller AD-43 has multimedia volume controls that are used to adjust the volume only for music or video playback.

Your Nokia N95

Memory card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Keep all memory cards out of the reach of small children.

Insert the memory card

1 Place your finger

in the recess

below the door of

the memory card

slot, and lift the

door. Pull the

door to the right

to reveal the

hinge, and swing

the door to the

side.

2 Insert a compatible

memory card in the

slot. Make sure that

the contact area on

the card is facing up

and towards the slot.

3 Push the card in. You

can hear a click when the card

locks into place.

4 Push the hinge back in, and close

Draft

the door. Ensure that the door is properly closed.

Eject the memory card

Important: Do not remove the

memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

1 Before you eject the card, press , and select

Remove memory card. All applications are closed.

2 When Removing memory card will close all open

applications. Remove anyway? is displayed, select Yes.

3 When Remove memory card and press 'OK' is

displayed, open the door of the memory card slot.

4 Press the memory card to release it from the slot. 5 Pull out the memory card. If the device is switched on,

select OK.

Memory card tool

Press , and select Tools > Memory.

To back up information from the device memory to a compatible memory card (if available), select Options >

Back up phone memory. The device notifies you if the

memory card does not have enough free space to create a back-up.

To restore information from the compatible memory card to the device memory, select Options > Restore from

card.

When a memory card is reformatted, all data on the card is permanently lost. Some memory cards are supplied preformatted and others require formatting. Consult your retailer to find out if you must format the memory card before you can use it.

To format a memory card, select Options > Format

memory card. Select Yes to confirm.

File manager

To browse files and folders in the device memory or on a compatible memory card (if inserted), press , and select

Tools > File mgr.. The device memory view ( ) opens.

Press to open the memory card view ( ), if available.

To mark several files, press and hold while you press

, , or . To move or copy the files to a folder, select

Options > Move to folder or Copy to folder.

To find a file, select Options > Find and the memory from which to search. Enter a search text that matches the file name.

Your Nokia N95

To view what types of data you have in the device and how

Draft

much memory the different data types consume, select

Options > Memory details. The amount of available free

memory is shown in Free memory.

Memory low—free memory

Many features of the device use memory to store data. The

Your Nokia N95

device notifies you if the device or the memory card memory is low.

To free device memory, transfer data to a compatible memory card (if available) or to a compatible PC.

To remove data to free memory, use File mgr. to delete files you no longer need, or go to the respective application. For example, you can remove the following:

• Messages in the folders in Messaging and retrieved

e-mail messages from the mailbox

• Saved web pages

• Contact information

• Calendar notes

• Applications shown in App. mgr. that you do not need

• Installation files (.sis) of applications you have installed

to a compatible memory card; first back up the installation files to a compatible PC

Download!

With Download!, you can browse, download, and install items, such as applications and media files, to your device from the internet.

Press , and select Download!. The items are categorized under catalogs and folders provided by different service providers. Some items may be chargeable, but you can usually preview them free of charge.

Web browser

Draft

Press , and select Web (network service).

Shortcut: To start Web, press and hold in the

standby mode.

With Web, you can view hypertext markup language (HTML) web pages on the internet as originally designed. You can also browse web pages that are designed specifically for mobile devices, and use extensible hypertext markup language (XHTML), or the wireless markup language (WML).

With Web, you can zoom in and out on a page, use Mini

map and Page overview to navigate on pages, read web

feeds and blogs, bookmark web pages, and download content, for example.

Check the availability of services, pricing, and fees with your service provider. Service providers will also give you instructions on how to use their services.

To use Web, you need an access point to connect to internet. See ‘Access points’, p. 120.

Connection security

If the security indicator is displayed during a connection, the data transmission between the device and the internet gateway or server is encrypted.

The security icon does not indicate that the data transmission between the gateway and the content server (or place where the requested resource is stored) is secure. The service provider secures the data transmission between the gateway and the content server.

Security certificates may be required for some services, such as banking services. You are notified if the identity of the server is not authentic or if you do not have the correct security certificate in your device. For more information, contact your service provider. See also ‘Certificate management’, p. 115 for more information on the certificates and certificate details.

Bookmarks view

The bookmarks view allows you to select web addresses from a list or from a collection of bookmarks in the Auto.

Bookmarks folder. You can also enter the URL address of

the web page you want to visit directly into the field ( ).

Web browser

indicates the starting page defined for the default

Draft

access point.

You can save URL addresses as bookmarks while browsing on the internet. You can also save addresses received in messages to your bookmarks and send saved bookmarks.

Web browser

To open the bookmarks view while browsing, press , or select Options > Bookmarks.

To edit the details of a bookmark, such as the title, select

Options > Bookmark manager > Edit.

In the bookmarks view, you can also enter other browser folders. Web allows you to save web pages during browsing. In the Saved pages folder, you can view the content of the pages you have saved offline.

Web also keeps track of the web pages you visit during

browsing. In the Auto. Bookmarks folder, you can view the list of visited web pages.

In Web Feeds, you can view saved links to web feeds and blogs to which you have subscribed. Web feeds are commonly found on major news organization web pages,

personal weblogs, online communities that offer latest headlines, and article summaries. Web feeds use RSS and ATOM technologies.

Browse the web

Important: Use only services that you trust and that

offer adequate security and protection against harmful software.

With Web, you can view web pages as they are originally designed. To browse a web page, in the bookmarks view, select a bookmark, or enter the address in the field ( ). Then press .

Some web pages may contain material, such as graphics and sounds, that requires a large amount of memory to view. If your device runs out of memory while loading such a page, the graphics on the page are not shown. To browse web pages without graphics to save memory, select

Options > Settings > Page > Load content > Text only.

Tip! To return to the standby mode with the browser

open in the background, press twice or . To

return to the browser, press and hold , and select

the browser from the list.

To open links and make selections, press .

To enter a new web page address you want to visit, select

Options > Go to web address.

Tip! To visit a web page saved as bookmark in the

Draft

bookmarks view, while browsing, press , and select a bookmark.

To retrieve the latest content of the page from the server, select Options > Navigation options > Reload.

To save the web address of the current page as bookmark, select Options > Save as bookmark.

To use Visual history to view snapshots of the pages you have visited during the current browsing session, select

Back (available if History list is set on in the browser

settings). To go to a previously visited page, select the page.

To save a page while browsing, select Options > Tools >

Save page. You can save pages to the device memory or

compatible memory card (if inserted), and browse them when offline. You can also group the pages into folders. To access the pages later, in the bookmarks view, select Saved

pages.

To open a sublist of commands or actions for the currently open page, select Options > Service options (if supported by the web page).

To allow or prevent the automatic opening of multiple windows, select Options > Window > Block pop-ups or

Allow pop-ups.

Shortcuts while browsing are as follows:

• Press to open your bookmarks.

• Press to search for keywords in the current page.

• Press to return to the previous page.

• Press to list all open windows.

• Press to show the page overview of the current

page. Press again to zoom in and view the desired section of the page.

• Press to enter a new web address.

• Press to go to the start page.

• Press or to zoom the page in or out.

Text search

To search for keywords within the current web page, select

Options > Find > Text, and enter a keyword. To go to the

previous match, press . To go to the next match, press

Tip! To search for keywords within the page, press

Browser toolbar

With the toolbar, you can select most frequently used features in the browser. To open the toolbar, press on an empty spot on a web page. To move within the toolbar, press or , To select a feature, press .

In the toolbar, select from the following:

Web browser

• Frequently used links to view a list of the web

Draft

addresses you visit frequently

• Page overview to view the overview of the current web

page

• Find to search for keywords within the current page

• Reload to refresh the page

Web browser

• Subscribe (if available) to view a list of available web

feeds on the current web page, and subscribe to a web feed

Download and purchase items

You can download items such as ringing tones, images, operator logos, themes, and video clips. These items can be provided free of charge, or you can purchase them. Downloaded items are handled by the respective applications in your device, for example, a downloaded photo or an .mp3 file can be saved in Gallery.

Important: Only install and use applications and

other software from trusted sources, such as applications that are Symbian Signed or have passed the Java Verified testing.

1 To download the item, select the link. 2 Select the appropriate option to purchase the item (for

example, “Buy”).

3 Carefully read all the information provided.

To continue the download, select Accept. To cancel the

download, select Cancel.

When you start a download, a list of ongoing and completed downloads from the current browsing session is displayed. To also view the list, select Options >

Downloads. In the list, scroll to an item, and select Options

to cancel ongoing downloads, or open, save, or delete completed downloads.

Mini map

Mini map helps you to navigate on web pages that contain

large amount of information. When Mini map is set on in the browser settings and you scroll through a large web page, Mini map opens and shows an overview of the web page you browse. To scroll in Mini map, press , , , or . When you find the desired location, stop scrolling, and Mini map disappears and leaves you at the selected location.

To set Mini map on, select Options > Settings >

General > Mini map > On.

Page overview

When you are browsing a web page that contains a large amount of information, you can use Page overview to view what kind of information the page contains.

To show the page overview of the current page, press .

Draft

To find the desired spot on the page, press , , , or

. Press again to zoom in and view the desired

section of the page.

Web feeds and blogs

Web feeds are xml files on web pages that are widely used by the weblog community and news organizations to share the latest entry headlines or full text, for example, recent news in the form of news feeds. Blogs or weblogs are web diaries. Most of the web feeds use RSS and ATOM technologies. It is common to find web feeds on web, blog, and wiki pages.

Web automatically detects if a web page contains web

feeds. To subscribe to a web feed, select Options >

Subscribe, or click on the link. To view the web feeds to

which you have subscribed, in the bookmarks view, select

Web feeds.

To update a web feed, select it, and Options > Refresh.

To define how the web feeds are updated, select Options >

Settings > Web feeds. See ‘Settings’, p. 23.

End connection

To end the connection and view the browser page offline, select Options > Tools > Disconnect; or to end the connection and close the browser, select Options > Exit.

Pressing does not end the connection but takes the browser to the background.

To delete the information the network server collects about your visits to various web pages, select Options >

Clear privacy data > Delete cookies.

Empty the cache

The information or services you have accessed are stored in the cache memory of the device.

A cache is a memory location that is used to store data temporarily. If you have tried to access or have accessed confidential information requiring passwords, empty the cache after each use. The information or services you have accessed are stored in the cache. To empty the cache, select Options > Clear privacy data > Clear cache.

Settings

Select Options > Settings and from the following:

General settings

Web browser

Access point—Change the default access point. See

Draft

‘Connection’, p. 119. Some or all access points may be preset for your device by your service provider; you may not be able to change, create, edit, or remove them.

Homepage—Define the home page.

Web browser

Mini map—Set Mini map on or off. See ‘Mini map’, p. 22.

History list—While browsing, to use the selection key Back

to see a list of the pages you have visited during the current browsing session, set History list on.

Security warnings—Hide or show security notifications.

Java/ECMA script—Enable or disable the use of scripts.

Page settings

Load images and sounds—Select whether you want to

load images and other objects while browsing. If you select

Text only, to load images or objects later during browsing,

select Options > Tools > Load images.

Screen size—Select between Full screen and the normal

view with the options list.

Default encoding—If text characters are not shown

correctly, you can select another encoding according to language for the current page.

Block pop-ups—Allow or block automatic opening of

different pop-ups while browsing.

Automatic reload—If you want the web pages to be

refreshed automatically while browsing, select On.

Font size—Define the font size that is used for web pages.

Privacy settings

Auto. bookmarks—Enable or disable automatic bookmark

collecting. If you want to continue saving the addresses of the visited web pages into the Auto. Bookmarks folder, but hide the folder from the bookmarks view, select Hide

folder.

Form data saving—If you do not want the data you enter

to different forms on a web page to be saved and used next time the page is entered, select Off.

Cookies—Enable or disable the receiving and sending of

cookies.

Web feeds settings

Automatic updates—Define whether you want the web

feeds to be updated automatically or not, and how often you want to update them. Setting the application to retrieve web feeds automatically may involve the transmission of large amounts of data through your service provider's network. Contact your service provider for information about data transmission charges.

Acc. point for auto-update (only available when Automatic updates is on)—Select the desired access point

for updating.

Connections

Draft

Wireless LAN

Your device supports wireless local area network (WLAN). With WLAN, you can connect your device to the internet and compatible devices that have WLAN. For information about using your device with other compatible Universal Plug and Play (UPnP) devices through WLAN, see ‘Home network’, p. 66.

To use WLAN, it must be available in the location and your device must be connected to the WLAN.

Some places, like France, have restrictions on the use of WLAN. Check with your local authorities for more information.

Features using WLAN, or allowing such features to run in the background while using other features, increase the demand on battery power and reduce the battery life.

Your device supports the following WLAN features:

• IEEE 802.11b/g standard

• Operation at a frequency of 2.4 GHz

• Wired equivalent privacy (WEP) with keys up to 128

bits, Wi-Fi protected access (WPA), and 802.1x encryption methods. These functions can be used only if they are supported by the network.

Wireless LAN connections

To use WLAN, you must create an internet access point (IAP) in a WLAN. Use the access point for applications that need to connect to the internet. See ‘WLAN internet access points’, p. 26.

Important: Always enable one of the available

encryption methods to increase the security of your WLAN connection. Using encryption reduces the risk of unauthorized access to your data.

A WLAN connection is established when you create a data connection using a WLAN internet access point. The active WLAN connection ends when you end the data connection. To end the connection, see ‘Connection manager’, p. 27.

You can use WLAN during a voice call or when packet data is active. You can only be connected to one WLAN access point device at a time, but several applications can use the same internet access point.

When the device is in the Offline profile, you can still use WLAN (if available). Remember to comply with any applicable safety requirements when establishing and using a WLAN connection.

Connections

Tip! To check the unique media access control (MAC)

Draft

address that identifies your device, enter

*#62209526# in the standby mode.

WLAN wizard

Connections

The WLAN wizard helps you to connect to a WLAN and manage your WLAN connections.

The WLAN wizard shows the status of your WLAN connections in the active standby mode. To view the available options, scroll to the row showing the status, and press .

If the search results of found WLANs, for example, WLAN

network found are displayed, to create an internet access

point and start the web browser using this IAP, select the status, the option Start web browsing, and the network.

If you select a secured WLAN network, you are asked to enter the relevant passcodes. To connect to a hidden network, you must enter the correct network name (service set identifier, SSID). To create a new access point for hidden WLAN, select New WLAN.

If you are connected to a WLAN, the IAP name is displayed. To start the web browser using this IAP, select the status and the option Cont. Web browsing. To end the connection in the WLAN, select the status and the option

Disconnect WLAN.

If WLAN scanning is off and you are not connected to any WLAN, WLAN scanning off is displayed. To set scanning on and search for available WLANs, select the status and press .

To start a search for available WLANs, select a status and the option Search for WLAN. To set WLAN scanning off, select a status and the option Switch WLAN scan off.

To access the WLAN wizard in the menu, press , and select Tools > WLAN wiz.

WLAN internet access points

To search for WLANs available within range, press , and select Tools > WLAN wiz..

Select Options and select from the following:

• Filter WLAN networks— Filter out WLANs in the list of

found networks. The selected networks are filtered out

the next time the application searches for WLANs.

• Details — View the details of a network shown in the

list. If you select an active connection, the connection

details are displayed.

• Define access point— Create an internet access point

(IAP) in a WLAN.

• Edit access point — Edit the details of an existing IAP.

You can also use Conn. mgr. to create internet access points. See ‘Wireless LAN’, p. 27.

Operating modes

Draft

There are two operating modes in WLAN: infrastructure and ad hoc.

The infrastructure operating mode allows two kinds of communication: wireless devices are connected to each other through a WLAN access point device, or wireless devices are connected to a wired LAN through a WLAN access point device.

In the ad hoc operating mode, devices can send and receive data directly with each other. To create an internet access point for an ad hoc network, see ‘Access points’, p. 120.

Connection manager

Data connections

Press , and select Tools > Conn. mgr. > Active data

connections. In the active connections view, you can see

the open data connections: data calls ( ), packet data connections ( or ), and WLAN connections ( ).

Note: The actual time invoiced for calls by your

service provider may vary, depending on network features, rounding off for billing, and so forth.

To end a connection, select Options > Disconnect. To close all open connections, select Options > Disconnect all.

To view the details of a connection, select Options >

Details. The details shown depend on the connection type.

Wireless LAN

To search for WLANs available within range, press , and select Tools > Conn. mgr. > Available WLAN networks.

The available WLAN view shows a list of WLANs within range, their network mode (Infrastructure or Ad-hoc), and signal strength indicator. is shown for networks with encryption, and if your device has an active connection in the network.

To view the details of a network, select Options > Details.

To create an internet access point in a network, select

Options > Define access point.

Bluetooth connectivity

You can connect wirelessly to other compatible devices with wireless Bluetooth technology. Compatible devices may include mobile phones, computers, and enhancements such as headsets and car kits. You can use Bluetooth connectivity to send images, video clips, music and sound clips, and notes; connect wirelessly to your compatible PC (for example, to transfer files); connect to a compatible printer to print images with Image print. See ‘Image print’, p. 63.

Connections

Since devices with Bluetooth wireless technology

Draft

communicate using radio waves, your device and the other device do not need to be in direct line-of-sight. The two devices only need to be within 10 meters (33 feet) of each other, but the connection may be subject to interference from obstructions such as walls or from other electronic

Connections

devices.

This device is compliant with Bluetooth Specification 2.0 supporting the following profiles: Advanced Audio Distribution Profile, Audio/Video Remote Control Profile, Generic Audio/Video Distribution Profile, Basic Imaging Profile, Basic Printing Profile, Dial-up Networking Profile, File transfer Profile, Hands-Free Profile, Headset Profile, Human Interface Device Profile, Object Push Profile, Remote SIM Access profile, and Synchronization Profile.

To ensure interoperability between other devices supporting Bluetooth technology, use Nokia approved enhancements for this model. Check with the manufacturers of other devices to determine their compatibility with this device.

There may be restrictions on using Bluetooth technology in some locations. Check with your local authorities or service provider.

Features using Bluetooth technology, or allowing such features to run in the background while using other

features, increase the demand on battery power and reduce the battery life.

When the device is locked, you cannot use Bluetooth connectivity. See ‘Phone and SIM card’, p. 114 for more information on locking the device.

Settings

Press , and select Tools > Bluetooth. When you open the application for the first time, you are asked to define a name for your device.

Select from the following:

Bluetooth—To connect wirelessly to another compatible

device, first set Bluetooth connectivity On, then establish a connection. To switch off Bluetooth connectivity, select

Off.

My phone's visibility—To allow your device to be found by

other devices with Bluetooth wireless technology, select

Shown to all. To set a time after which the visibility is set

from shown to hidden, select Define period. To hide your device from other devices, select Hidden.

My phone's name—Edit the name shown to other devices

using Bluetooth wireless technology.

Remote SIM mode—To enable another device, such as a

compatible car kit enhancement, to use the SIM card in

your device to connect to the network, select On. For more

Draft

information, see ‘Remote SIM mode’, p. 30.

Security tips

When you are not using Bluetooth connectivity, select

Bluetooth > Off or My phone's visibility > Hidden. In this

way, you can better control who can find your device with Bluetooth wireless technology, and connect to it.

Do not pair with or accept connection requests from an unknown device. In this way, you can better protect your device from harmful content.

Send data using Bluetooth connectivity

Several Bluetooth connections can be active at a time. For example, if you are connected to a compatible headset, you can also transfer files to another compatible device at the same time.

For Bluetooth connectivity indicators, see ‘Essential indicators’, p. 27.

Tip! To send text using Bluetooth connectivity, open

Notes, write the text, and select Options > Send > Via Bluetooth.

1 Open the application where the item you want to send

is stored. For example, to send an image to another compatible device, open Gallery.

2 Select the item and Options > Send > Via Bluetooth.

Devices with Bluetooth wireless technology within range start to appear on the display. Device icons: computer, phone, audio or video device, and other device. To interrupt the search, select Stop.

3 Select the device with which you want to connect. 4 If the other device requires pairing before data can be

transmitted, a tone sounds, and you are asked to enter a passcode. See ‘Pair devices’, p. 29.

5 When the connection has been established, Sending

data is shown.

Tip! When searching for devices, some devices may

show only the unique address (device address). To find the unique address of your device, enter the code

*#2820# in the standby mode.

Pair devices

To pair with compatible devices and view your paired devices, in the Bluetooth application main view, press .

Before pairing, create your own passcode (1-16 digits), and agree with the owner of the other device to use the same code. Devices that do not have a user interface have a factory-set passcode. The passcode is used only once.

Connections

1 To pair with a device, select Options > New paired

Draft

device. Devices with Bluetooth wireless technology

within range start to appear on the display.

2 Select the device, and enter the passcode. The same

passcode must be entered on the other device as well.

Connections

Some audio enhancements connect automatically to your device after pairing. Otherwise, scroll to the enhancement, and select Options > Connect.

Paired devices are indicated by in the device search.

To set a device as authorized or unauthorized, scroll to a device, select Options, and select from the following:

Set as authorized—Connections between your device and

this device can be made without your knowledge. No separate acceptance or authorization is needed. Use this status for your own devices, such as your compatible headset or PC, or devices that belong to someone you trust.

indicates authorized devices in the paired devices view.

Set as unauthorized—Connection requests from this

device must be accepted separately every time.

To cancel a pairing, scroll to the device, and select

Options > Delete. If you want to cancel all pairings, select Options > Delete all.

Receive data using Bluetooth connectivity

When you receive data through Bluetooth connectivity, a tone sounds, and you are asked if you want to accept the message. If you accept, is shown, and the item is placed in the Inbox folder in Messaging. Messages received through Bluetooth connectivity are indicated by

. See ‘Inbox—receive messages’, p. 87.

Remote SIM mode

To use the remote SIM mode with a compatible car kit enhancement, set Bluetooth connectivity on, and enable the use of the remote SIM mode with your device. See ‘Settings’, p. 28. Before the mode can be activated, the two devices must be paired and the pairing initiated from the other device. When pairing, use a 16-digit passcode, and set the other device as authorized. See ‘Pair devices’, p. 29. Activate the remote SIM mode from the other device.

When remote SIM mode is on in your device, Remote SIM is displayed in the standby mode. The connection to the wireless network is turned off, as indicated by in the signal strength indicator area, and you cannot use SIM card services or features requiring cellular network coverage.

+ 107 hidden pages
