Address book
Press , and select Addr. Book. Addr. Book holds details
of your contacts, such as phone numbers and e-mail
addresses. Each contact’s details are stored on a contact
card, which can include a personal ringing tone (see "Add
ringing tones for addresses," p. 70) or a thumbnail image
for the contact. You can also create contact groups, which
allow you to send text messages or e-mail to many
recipients at the same time. See "Contact groups," p. 70.
You can add received address information (business cards)
to Addr. Book. See "Data and settings," p. 61. Address
information can only be sent to or received from
compatible devices.
Contact cards
To add details of a new contact in Addr. Book, select
Options > New contact.
To edit a contact card in Addr. Book, select it
and Options > Edit. You can search for the desired
contact by entering the first letters of the name to the
search field. A list of contacts, starting with the letters,
appears on the display.
Tip! To add or edit several contact cards, use Nokia
Contacts Editor available in Nokia PC Suite.
To attach a small thumbnail image to a contact card, open
the contact card, and select Options > Edit > Options >
Add thumbnail. The thumbnail image is shown when the
contact calls.
To delete a contact card in Addr. Book, select a card, and
press . To delete several contact cards at the same time,
press and to mark the contact cards , and press
to delete.
Tip! 1-touch dialing is a quick way to call frequently
used numbers. You can assign 1-touch dialing keys to
eight phone numbers. See "1-touch dial a phone
number," p. 73.
Tip! To send contact information, select the contact
card you want to send. Select Options > Send > Via
text message, Via multimedia, Via Bluetooth, or Via
infrared. See "Messaging," p. 55 and "Send data using
Bluetooth connectivity," p. 114.
To view the amount of addresses, groups, and the
available memory in Addr. Book, select Options > Check
memory.
Address book
69
R1114_en.book Page 70 Thursday, October 19, 2006 3:43 PM
Default numbers and addresses
You can assign default numbers or addresses to a contact
card. In this way if a contact has several numbers or
addresses, you can easily call or send a message to the
contact to a certain number or address. The default
number is also used in voice dialing.
Address book
1 In Addr. Book, select a contact, and press .
2 Select Options > Defaults.
3 Select the number or address to which you want to
add a default value, and select Assign.
4 Select a number or an address you want to set as a
default.
The default number or address is underlined in the contact
card.
Contact groups
To create a contact group, do the following:
1 In Addr. Book, press to open the groups list.
2 Select Options > New group.
3 Write a name for the group or use the default name
Group %N, and select OK.
4 Open the group, and select Options > Add members.
5 Scroll to a contact, and press to mark it. To add
multiple members at a time, repeat this action on all
the contacts you want to add.
6 Select OK to add the contact to the group.
To rename a group, select Options > Rename, enter the
new name, and select OK.
To add a contact to an existing contact group, select
Options > Add to group: .
To remove contacts from a group, do the following:
1 In the groups list, open the group you want to modify.
2 Select the contact and Options > Remove from group.
3 Select Yes to remove the contact from the group.
Tip! To check to which groups a contact belongs,
scroll to the contact, and select Options > Belongs to
groups.
Add ringing tones for addresses
When a contact or group member calls you, the device
plays the chosen ringing tone (if the caller’s telephone
number is sent with the call and your device recognizes it).
1 Press to open a contact card or go to the groups list,
and select a contact group.
2 Select Options > Ringing tone. A list of ringing tones
opens.
3 Select the ringing tone you want to use for the
individual contact or the selected group.
70
R1114_en.book Page 71 Thursday, October 19, 2006 3:43 PM
You can also use a song as a ringing tone. See "Set a song
as a ringing tone," p. 39.
To remove the ringing tone, select Default tone from the
list of ringing tones.
Copy contacts
To copy names and numbers from a SmartChip to your
device, press , and select Addr. Book > Options >
SmartChip contacts > SmartChip directory. Select the
names you want to copy and Options > Copy to Address
Book.
To copy addresses to your SmartChip, press , and select
Addr. Book. Select the names you want to copy and
Options > Copy to SChip direct. or Options > Copy > To
SmartChip directory. Only the contact card fields
supported by your SmartChip are copied.
SChip directory and other SmartChip
services
For availability and information on using SmartChip
services, contact your service provider.
Press , and select Addr. Book > Options > SmartChip
contacts > SChip directory to see the names and numbers
stored on the SmartChip. In the SmartChip directory you
can add, edit, or copy numbers to Addr. Book, and make
calls.
To view the list of fixed dialing numbers, select Options >
SmartChip contacts > Fixed dialing contacts. This
setting is only shown if supported by your SmartChip.
To restrict calls from your device to selected phone
numbers, select Options > Activ. fixed dialing. To add
new numbers to the fixed dialing list, select Options >
New SmartChip contact. You need the PIN2 code for
these functions.
When you use Fixed dialing, packet data connections are
not possible, except when sending text messages over a
packet data connection. In this case, the message center
number and the recipient’s phone number must be
included on the fixed dialing list.
When fixed dialing is activated, calls may be possible to
the official emergency number programmed into your
device.
Address book
71
R1114_en.book Page 72 Thursday, October 19, 2006 3:43 PM
Make calls
72
Voice calls
Make calls
Tip! To increase or decrease the volume during a
call, use the volume keys, or scroll left and right. If you
have set the volume to Mute, select Unmute first, and
then scroll left or right.
1 In the idle mode, enter the phone number, including
the area code. To remove a number, press .
For international calls, press twice for the +
character (replaces the international access code), and
enter the country code, area code (omit the leading
zero if necessary), and phone number.
2 Press to call the number.
3 Press to end the call (or to cancel the call
attempt).
Pressing always ends a call, even if another
application is active.
To make a call from Addr. Book, press , and select
Addr. Book. Scroll to the desired name, or enter the first
letters of the name to the search field. Matching
addresses are listed. To call, press . Select the call type
Voice call.
You must copy the address from your SmartChip to Addr.
Book before you can make a call this way. See "Copy
contacts," p. 71.
To call your voice mailbox (network service), press and hold
in the idle mode. See also "Call forwarding," p. 107.
Tip! To change the phone number of your voice
mailbox, press , and select Settings > Voice mail >
Options > Change number. Enter the number
(obtained from your service provider), and select OK.
To call a recently dialed number in the idle mode, press
. Scroll to the number, and press .
Make a conference call
1 Make a call to the first participant.
2 To make a call to another participant, select Options >
New call. The first call is automatically put on hold.
3 When the new call is answered, to join the first
participant in the conference call, select Options >
Conference (network service).
To add a new person to the call, repeat step 2, and
select Options > Conference > Add to conference.
Your device supports conference calls between a
maximum of six participants, including yourself.
R1114_en.book Page 73 Thursday, October 19, 2006 3:43 PM
To have a private conversation with one of the
participants, select Options > Conference > Private.
Select a participant and Private. The conference call is
put on hold on your device. The other participants can
still continue the conference call. After you finish the
private conversation, select Options > Add to
conference to return to the conference call.
To drop a participant, select Options > Conference >
Drop participant, scroll to the participant, and select
Drop.
4 To end the active conference call, press .
1-touch dial a phone number
To activate 1-touch dialing, press , and select
Settings > Config. > Call > 1-touch dialing> On.
To assign a phone number to one of the 1-touch dialing
keys ( — ), press , and select Settings > Spd. dial.
Scroll to the key to which you want to assign the phone
number, and select Options > Assign. is reserved for
the voice mailbox.
To call in the idle mode, press the 1-touch dial key and
.
Voice dialing
Your device supports enhanced voice commands.
Enhanced voice commands are not dependent on the
speaker’s voice, so the user does not record voice tags in
advance. Instead, the device creates a voice tag for the
entries in Addr. Book, and compares the spoken voice tag
to it. The voice recognition in the device adapts to the
main user’s voice to recognize the voice commands better.
The voice tag for an address is the name or nickname that
is saved on the contact card. To listen to the synthesized
voice tag, open the contact card, and select Options >
Play voice tag.
Make a call with a voice tag
Note: Using voice tags may be difficult in a noisy
environment or during an emergency, so you should
not rely solely upon voice dialing in all circumstances.
When you use voice dialing, the loudspeaker is in use. Hold
the device at a short distance away when you say the
voice tag.
1 To start voice dialing, in the idle mode, press and hold
. To start voice dialing with the fold closed, press
and hold . If you are using a compatible headset
with the headset key, press and hold the headset key
to start voice dialing.
2 A short tone is played, and Speak now is displayed. Say
clearly the name or nickname that is saved on the
address card.
3 The device plays a synthesized voice tag for the
recognized address in the selected device language,
Make calls
73
R1114_en.book Page 74 Thursday, October 19, 2006 3:43 PM
and displays the name and number. After a timeout of
approximate 2.5 seconds, the device dials the number.
If the recognized address is not correct, select Next to
view a list of other matches, or Quit to cancel voice
Make calls
dialing.
If several numbers are saved under the name, the device
selects the default number, if it has been set. Otherwise,
the device selects the first available number of the
following: Mobile, Mobile (home), Mobile (work),
Telephone, Tel. (home), and Tel. (work).
Answer or decline a call
To answer a call, press .
To mute the ringing tone when a call comes in, select
Silence.
If you do not w ant to answer a ca ll, press . If you have
activated the Call forward > If busy function to forward
calls, declining an incoming call also forwards the call.
See "Call forwarding," p. 107.
When you decline an incoming call, you can send a text
message to the caller informing why you cannot answer
the call. Select Options > Send text message. You can
edit the text before sending it. To set up this option and
write a standard text message, see "Call config.," p. 101.
Call waiting
You can answer a call while you have another call in
progess if you have activated Call waiting in Settings >
Configuration > Call > Call waiting. Call waiting is a
network service.
Tip! To change the device tones for different
environments and events, for example, when you want
your device to be silent, see "Profiles—set tones," p. 95.
To answer the waiting call, press . The first call is put
on hold.
To switch between the two calls, select Swap. To connect
an incoming call or a call on hold with an active call and
to disconnect yourself from the calls, select Options >
Transfer. To end the active call, press . The first call
remains active. To end both calls, select Options > End all
calls.
Options during a voice call
Many of the options that you can use during a voice call
are network services. Select Options > Mute or Unmute,
Answer, Decline, Swap, Hold or Unhold, Activate
handset, Activate loudsp., or Activate handsfree (if a
compatible headset with Bluetooth connectivity is
attached), End active call or End all calls, New call,
74
R1114_en.book Page 75 Thursday, October 19, 2006 3:43 PM
Conference, Transfer, and Open active idle. Select from
the following:
Replace—to end an active call and replace it by answering
the waiting call
Send MMS (in UMTS networks only)—to send an image or
a video in a multimedia message to the other participant
of the call. You can edit the message and change the
recipient before sending. Press to send the file to a
compatible device (network service).
Send touch tones—to send touch tone strings, for
example, a password. Enter the touch tone string or search
for it in Address Book. To enter a wait character (w) or a
pause character (p), press repeatedly. Select OK to
send the tone.
Tip! You can add touch tones to the Phone number
or Touch tones fields in a contact card.
Log
To monitor the phone numbers of missed, received, and
dialed voice calls, press , and select Log. The device
registers missed and received calls only if the network
supports these functions, the device is switched on, and
within the network service area.
To clear all recent call lists, select Options > Delete
recent calls in the recent calls main view. To clear one of
the call logs, open the register you want to erase, and
select Options > Clear list. To clear an individual event,
open a register, scroll to the event, and press .
Call time
To monitor the approximate duration of your incoming
and outgoing calls, press , and select Log> Call time.
To set the display of the call timers while a call is active,
select Log > Options > Settings > Show call time > Yes
or No.
Note: The actual time invoiced for calls by your
service provider may vary, depending on network
features, rounding off for billing, and so forth.
To clear call duration timers, select Options > Clear
timers. For this you need the lock code. See "Phone and
SmartChip," p. 104.
Data counter
To check the amount of data sent and received during
packet data connections, press , and select Log > Data
counter. For example, you may be charged for your packet
data connections by the amount of data sent and received.
Make calls
75
R1114_en.book Page 76 Thursday, October 19, 2006 3:43 PM
Note: The packet data charges invoiced by your
service provider may vary, depending on network
features, rounding off for billing, and so forth.
Monitor all communication events
Make calls
To monitor all voice calls, text
messages, or data connections
registered by the device, press
, select Log, and scroll right
to open the general log. For
each communication event,
you can see the sender or
recipient name, phone
number, name of the service
provider, or access point, and
one of the following icons:
Incoming
Outgoing
Missed
You can filter the general log to view just one type of
event, and create new contact cards based on the log
information.
Tip! To view a list of sent messages, press , and
select Messaging > Sent.
Subevents, such as a text message sent in more than one
part and packet data connections, are logged as one
communication event. Connections to your mailbox,
multimedia messaging center, or Web pages are shown as
packet data connections.
To add an unknown phone number from Log to Addr.
Book, select Options > Add to Address Book.
To erase the contents of the log, recent calls register, and
messaging delivery reports permanently, select Options >
Clear log. Select Yes to confirm. To remove a single event
from the log, press .
To set the Log duration, select Options > Settings > Log
duration. The log events remain in the device memory for
a set number of days after which they are automatically
erased to free memory. If you select No log, all the log
contents, recent calls register, and messaging delivery
reports are permanently deleted.
To view the details of a communication event, in the
general log view, select an event.
Tip! In the details view you can copy a phone number
to the clipboard and paste it to a text message. Select
Options > Copy Number.
Packet data counter and connection timer: To view how
much data, measured in kilobytes, is transferred and how
long a certain packet data connection lasts, scroll to an
76
R1114_en.book Page 77 Thursday, October 19, 2006 3:43 PM
incoming or outgoing event indicated by Pack., and select
Options > View details.
Make calls
77
R1114_en.book Page 78 Thursday, October 19, 2006 3:43 PM
MEdia Net
78
To access MEdia Net, press , and select MEdia Net
(network service). Alternatively, press .
MEdia Net
MEdia Net provides wireless internet access to your
device.
Various service providers maintain pages specifically
designed for mobile devices that you can view with the
MEdia Net browser. These pages use the wireless markup
language (WML), extensible hypertext markup language
(XHTML), or hypertext markup language (HTML).
Check the availability of services, pricing, and fees with
your network operator or service provider. Service
providers will also give you instructions on how to use
their services.
Shortcut: To start a connection, press and hold
or in the idle mode.
Access point
To access pages, you need service settings for the page
that you want to use. You may receive the settings in a
special text message from the network operator or service
provider that offers the page. See "Data and settings,"
p. 61. For more information, contact your network
operator or service provider.
Tip! Settings may be available on the Web site of a
network operator or service provider.
Enter settings manually
1 Press , select Settings > Config. > Connection >
Access points, and define the settings for an access
point. Follow the instructions given to you by your
service provider. See "Connection," p. 102.
2 Press , and select MEdia Net > Options >
Bookmark manager > Add bookmark. Write a name
for the bookmark and the address of the page defined
for the current access point.
3 To set the created access point as the default access
point, select Options > Settings > Access point.
Bookmarks view
The bookmarks view opens when you open MEdia Net.
Your device may have some bookmarks loaded for sites not
affiliated with Nokia. Nokia does not warrant or endorse
these sites. If you choose to access them, you should take
R1114_en.book Page 79 Thursday, October 19, 2006 3:43 PM
the same precautions, for security or content, as you would
with any Internet site.
indicates the starting page defined for the default
access point.
Connection security
If the security indicator is displayed during a
connection, the data transmission between the device and
the Internet gateway or server is encrypted.
The security icon does not indicate that the data
transmission between the gateway and the content server
(or place where the requested resource is stored) is secure.
The service provider secures the data transmission
between the gateway and the content server.
Select Options > Details > Security to view details about
the connection, encryption status, and information about
server and user authentication.
Security certificates may be required for some services,
such as banking services. For more information, contact
your service provider. See also "Certif. management,"
p. 105.
Browse
Important: Use only services that you trust and that
offer adequate security and protection against harmful
software.
To download a page, select a bookmark, or enter the
address in the field ( ).
On a browser page, new links appear underlined in blue
and previously visited links in purple. Images that act as
links have a blue border around them.
To open links and make selections, press .
Shortcut: Press to jump to the end of a page and
to the beginning of a page.
To go to the previous page while browsing, select Back. If
Back is not available, select Options > Navigation
options > History to view a chronological list of the pages
you visited during a browsing session.
To retrieve the latest content from the server, select
Options > Navigation options > Reload.
To save a bookmark, select Options > Save as bookmark.
Tip! To access the bookmarks view while browsing,
press and hold . To return to the browser view,
select Options > Back to page.
MEdia Net
79
R1114_en.book Page 80 Thursday, October 19, 2006 3:43 PM
To save a page while browsing, select Options >
Advanced options > Save page. You can save pages to
the device memory or compatible memory card (if
inserted), and browse them when offline. To access the
pages later, press in the bookmarks view to open the
MEdia Net
Saved pages view.
To enter a new URL address, select Options > Navigation
options > Go to web address.
To open a sublist of commands or actions for the currently
open page, select Options > Service options.
You can download files that cannot be shown on the
browser page, such as ringing tones, images, operator
logos, themes, and video clips. To download an item,
select the link.
When you start a download, a list of ongoing, paused, and
completed downloads from the current browsing session
is displayed. To view the list, select Options > Downloads.
In the list, scroll to an item, and select Options to pause,
resume, or cancel ongoing downloads, or open, save, or
delete completed downloads.
Download and purchase items
You can download items such as ringing tones, images,
operator logos, themes, and video clips. These items can
be provided free, or you can purchase them. Downloaded
items are handled by the respective applications in your
device, for example, a downloaded photo can be saved in
My Stuff.
Important: Only install and use applications and
other software from sources that offer adequate security
and protection against harmful software.
1 To download the item, select the link.
2 Select the appropriate option to purchase the item (for
example, ‘Buy’).
3 Carefully read all the information provided.
To continue the download, select Accept. To cancel the
download, select Cancel.
End a connection
To end the connection and view the browser page offline,
select Options > Advanced options > Disconnect. To end
the connection and close the browser, select Options >
Exit.
Empty the cache
The information or services you have accessed are stored in
the cache memory of the device.
A cache is a memory location that is used to store data
temporarily. If you have tried to access or have accessed
confidential information requiring passwords, empty the
80
R1114_en.book Page 81 Thursday, October 19, 2006 3:43 PM
cache after each use. The information or services you have
accessed are stored in the cache. To empty the cache,
select Options > Advanced options > Clear cache.
Settings
Select Options > Settings and from the following:
Access point—Change the default access point. See
"Connection," p. 102. Some or all access points may be
preset for your device by your service provider or network
operator, and you may not be able to change, create, edit,
or remove them.
Homepage—Define the home page.
Load imgs. & audio—Select whether you want to load
images while browsing. If you select No, to load images
later during browsing, select Options > Show images.
Font size—Select the text size.
Default encoding—If text characters are not shown
correctly, you can select another encoding according to
language.
Auto. bookmarks—Enable or disable automatic bookmark
collecting. If you want to continue collecting automatic
bookmarks but hide the folder from the bookmarks view,
select Hide folder.
Screen size—Select what is shown when you are
browsing: Select. keys only or Full screen.
Search page—Define a Web page that is downloaded
when you select Navigation options > Open search page
in the bookmarks view or when browsing.
Rendering—If you want the page layout shown as
accurately as possible when in Small screen mode, select
By quality. If you do not want external cascading style
sheets to be downloaded, select By speed.
Cookies—Enable or disable the receiving and sending of
cookies.
Java/ECMA script—Enable or disable the use of scripts.
Security warnings—Hide or show security notifications.
Confirm touch tones—Select whether you want to
confirm before the device sends touch tones during a
voice call. See also "Options during a voice call," p. 74.
MEdia Net
81
R1114_en.book Page 82 Thursday, October 19, 2006 3:43 PM
Calendar
Calendar
82
The Calendar reminds you of meetings and anniversaries,
and keeps track of your tasks and other notes.
Create calendar entries
Shortcut: In the day, week, or month calendar view,
press any key ( — ). An appointment entry opens,
and the characters you enter are added to the Subject
field. In the to-do view, a to-do note entry opens.
1 Press , and select
Tools > Calendar >
Options > New entry
and one of the following:
Meeting—to remind you
of an appointment that
has a specific date and
time
Memo—to write a
general entry for a day
Anniversary—to remind
you of birthdays or
special dates (entries are repeated every year)
To-do—to remind you of a task that needs doing by a
specific date
2 Fill in the fields.
3 To set an alarm, select Alarm > On, and enter the
Alarm time and Alarm date.
4 To add a description for an appointment or a meeting,
select Options > Add description.
5 To save the entry, select Done.
When the calendar alarm sounds, select Silence to t urn of f
the calendar alarm tone. The reminder text stays on the
screen. To end the calendar alarm, select Stop. To set the
alarm to snooze, select Snooze.
To modify the calendar alarm tone select Options >
Settings > Calendar alarm tone.
Tip! You can synchronize your calendar with a
compatible PC using Nokia PC Suite. When creating a
calendar entry, set the desired Synchronization option.
Calendar views
Tip! Select Options > Settings and Week starts on
or Default view to change the starting day of the week
or the view that is shown when you open the calendar.
In the month view, dates that have calendar entries are
marked with a small triangle in the right bottom corner. In
R1114_en.book Page 83 Thursday, October 19, 2006 3:43 PM
the week view, memos and anniversaries are placed before
8 a.m. To switch between the month view, week view, day
view, and to-do view, press .
To go to a certain date, select Options > Go to date. To
jump to today, press .
Tip! To see today’s calendar with the fold closed, press
on the side of the device. To return to the idle
mode, press again twice.
To send a calendar entry to a compatible device, select
Options > Send.
To print calendar entries on a compatible Basic Print
Profile (BPP) equipped printer with Bluetooth connectivity
(such as HP Deskjet 450 Mobile Printer or HP Photosmart
8150), select Options > Print.
Manage your calendar entries
Deleting past entries in Calendar saves space in your
device memory.
To delete more than one entry at a time, go to the month
view, and select Options > Delete entry > Before date or
All entries.
To mark a task as completed, scroll to it in the to-do view,
and select Options > Mark as done.
Calendar
83
R1114_en.book Page 84 Thursday, October 19, 2006 3:43 PM
Games&Apps
Games
Games&Apps
Press , and select Games&Apps and a game. For
instructions on how to play the game, select Options >
Help.
MobiTV
MobiTV allows you to watch live TV on your
device. To open the application, press , and
select Games&Apps > MobiTV.
To change channels, press or . Pause for a moment
to allow the device to respond.
To enter a channel number directly, press to open the
channel guide, followed by the channel number, and then
press OK.
To change the volume, press or .
Warnin g: Do n ot hold t he d evice ne ar yo ur ear w hen
the loudspeaker is in use, because the volume may be
extremely loud.
For more information, visit www.mobitv.com
84
R1114_en.book Page 85 Thursday, October 19, 2006 3:43 PM
Instant Messaging & Email
Instant messaging
Press , and select IM & Email > IM.
Instant messaging (IM) (network service) allows you to
converse with other people using instant messages and
join discussion forums (IM groups) with specific topics.
Various service providers maintain instant IM servers that
you can log in to after you register to an IM service. Service
providers may differ in their support of IM features. When
you log into an IM service for the first time, you may be
required to accept the Terms of Use of the service.
Select Conversations to start or continue a conversation
with an IM user; IM contacts to create, edit, or view the
online status of your IM contacts; IM groups to start or
continue a group conversation with multiple IM users; or
Record. chats to view a previous IM session that you
saved.
Receive IM settings
You must save the settings to access the service that you
want to use. You may receive the settings in a special text
message from the network operator or service provider
that offers the IM service. See "Data and settings," p. 61.
You can also enter the settings manually. See "IM server
settings," p. 87.
Connect to an IM server
1 To connect to an IM server, select IM > Options >
Login. To change the IM server in use and save new IM
servers, see "IM server settings," p. 87.
2 Enter your user ID and password, and press to log
in. You obtain the user ID and password from your
service provider.
3 To log out, select Options > Logout.
To log in automatically when you start IM, select
Options > Settings > Server settings > On app. startup.
Modify your IM settings
Select Options > Settings > IM settings and from the
following:
Use screen name (shown only if IM groups are supported
by the server)—To enter a nickname, select Yes.
Instant Messaging & Email
85
R1114_en.book Page 86 Thursday, October 19, 2006 3:43 PM
Show my availability—To allow others to see if you are
online, select To everyone.
Allow messages from—To allow messages from all, select
All.
Allow invitations from—To allow invitations only from
your IM contacts, select IM contacts only. IM invitations
are sent by IM contacts who want you to join their groups.
Msg. scrolling speed—Select the speed at which new
messages are displayed.
Sort IM contacts—Select how your IM contacts are
sorted: Alphabetically or By online status.
Instant Messaging & Email
Availabil. reloading—To select how to update
information about whether your IM contacts are online or
offline, select Automatic or Manual.
Offline contacts—Select whether IM contacts with an
offline status are shown in the IM contacts list.
Own message color—Select the color of the instant
messages you send.
Received msg color—Select the color of the instant
messages you receive.
IM alert tone—Change the tone played when you receive
a new instant message.
Search for IM groups and users
To search for groups, in the IM groups view, select
Options > Search. You can search by Group name, Topic,
and Members (user ID).
To search for users, in the IM contacts view, select
Options > New IM contact > Search from server. You
can search by User's name, User ID, Phone number, and
E-mail address.
Join IM groups
The IM groups view shows a list of the IM groups that you
have saved or are currently joined to.
To join a saved IM group, press .
To join an IM group that is not on the list, but for which
you know the group ID, select Options > Join new group.
To leave the IM group, select Options > Leave IM group.
Instant messaging
After you join an IM group, you can view the messages that
are exchanged there, and send your own messages.
To send a message, write the message in the message
editor field, and press .
86
R1114_en.book Page 87 Thursday, October 19, 2006 3:43 PM
To send a private message to a participant, select
Options > Send private msg..
To reply to a private message sent to you, select the
message and Options > Reply.
To invite IM contacts who are online to join the IM group,
select Options > Send invitation.
Record chats
To record the messages that are exchanged during a
conversation or while you are joined in a IM group, select
Options > Record chat. To stop recording, select
Options > Stop recording. To view the recorded chats, in
the main view, select Record. chats.
View and start conversations
The Conversations view shows a list of the individual
conversation participants that you have an ongoing
conversation with. Ongoing conversations are
automatically closed when you exit IM.
To view a conversation, select a participant.
To continue the conversation, write your message, and
press .
To return to the conversations list without closing the
conversation, select Back. To close the conversation, select
Options > End conversation.
To start a new conversation, select Options > New
conversation.
To save a conversation participant to your IM contacts,
select Options > Add to IM contacts.
To prevent receiving messages from certain participants,
select Options > Blocking options.
IM contacts
In the IM contacts view, you can retrieve instant
messaging contact lists from the server, or add a new
instant messaging contact to a contact list. When you log
in to the server, the previously used instant messaging
contact list is retrieved from the server automatically.
Select Options > Change own availab. to change the
online status that is shown to other IM users. You can
select a predefined message that shows to other IM users,
or type your o wn. If you sel ect your s tat us to be Hidden or
Away, no status message is shown to other IM users.
IM server settings
Select Options > Settings > Server settings. You may
receive the settings in a special text message from the
network operator or service provider that offers the
instant messaging service. You obtain the user ID and
password from your service provider when you register to
Instant Messaging & Email
87
R1114_en.book Page 88 Thursday, October 19, 2006 3:43 PM
the service. If you do not know your user ID or password,
contact your service provider.
Servers—View a list of all defined IM servers.
Default server—Change the IM server to which you want
to connect.
IM login type—To log in automatically when you start IM,
select On app. start-up.
To add a new server to your list of IM servers, select
Servers > Options > New server. Enter the following
settings:
Server name—the name for the IM server
Instant Messaging & Email
Access point in use—the access point you want to use for
the server
Web address—the URL address of the IM server
User ID—your user ID
Password—your login password
Mobile email
Press , and select IM & Email > Mobile email.
Mobile email (network service) allows you to access your
home email. Selected email services allow you to receive
“new mail” alerts with shortcut access to your inbox
enabling you to read, delete, and respond to your email
from your device.
For details of supported email providers and further
information, please contact your service provider.
88
R1114_en.book Page 89 Thursday, October 19, 2006 3:43 PM
Tools
Tools
Web
Various service providers maintain pages specifically
designed for mobile devices. These pages use the wireless
markup language (WML), extensible hypertext markup
language (XHTML), or hypertext markup language (HTML).
Check the availability of services, pricing, and fees with
your network operator or service provider. Service
providers will also give you instructions on how to use their
services.
Press , and select Tools > Web.
With this additional browser, you are able to view normal
Web pages, to zoom in and out on a page (Mini Map), to
view Web pages that contain only text in narrow form so
that text wraps, and to read feeds and blogs.
To turn the Mini Map on or off for the current page, press
. When the Mini Map is on, an overview of the
complete page is shown when you press and hold the scroll
key right, left, up, or down to move on the page.
Calculator
To add, substract, multiply, divide, and calculate square
roots and percentages, press , and select Tools >
Calculator.
Note: This calculator has limited accuracy and is
designed for simple calculations.
Converter
To convert measures from one unit to another, press ,
and select Tools > Converter.
Converter has limited accuracy, and rounding errors may
occur.
1 In the Type field, select the measure you want to use.
2 In first Unit field, select the unit from which you want
to convert. In the next Unit field, select the unit to
which you want to convert.
89
Loading...
