Microsoft RM-1116 User Guide

Quick Guide
Lumia 950 XL Dual SIM

x Issue x EN RM-1116

Keys and parts

1Microphone
2 Audio connector
3Earpiece
4 Front camera
5 Volume up key
6 Power/Lock key
7Volume down key
8 Camera key
9 Charger connector
10 Main camera
11 Loudspeaker

Remove the back cover and
battery

1. With the phone facing down, at the bottom right

corner of the phone, put your fingernail in the small
recess.

2. Press the middle of the back cover, bend the cover
open, and remove it.

3. If the battery is in, put your fingernail in the recess
on its bottom edge, and lift it out.

Insert the SIM and memory card

Note: Your SIM card has an effect on important

settings. Insert the SIM card before switching the
phone on.

1. Slide the nano-SIM card into the SIM slot with the
metal contact area down until it locks into place.

2. If you have a second SIM card, slide it into the
SIM2 slot.

3. If you have a memory card, slide the card into the
memory card slot.

The blue cards shown in the picture are in actual size.

Use only original nano-SIM cards. Use of
incompatible SIM cards may damage the card or the
device, and may corrupt data stored on the card.

Replace the battery and back cover

1. Line up the battery contacts, and put the battery

in.

2. Press the top edge of the back cover against the
top edge of your phone, and snap the cover into
place.
