Microsoft RM-106 User Manual

Nokia 6136 User Guide - FCC Draft

LEGAL INFORMATION

This device model is intended for sale only in the United States and has not been certified for use in the European Union and EFTA countries.

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of-life. This applies to your device but also to any enhancements m arked wi th th is sy mbol . Do not dispose of these products as unsorted municipal waste.

PART NO. 9247945, ISSUE NO. 1

Nokia, Nokia Connecting People, Pop-Port, PC Suite, and the Nokia Original Enhancements logos are trademarks or registered trademarks of Nokia Corporation. Other company and product names mentioned herein may be trademarks or trade names of their respective owners.

Nokia tune is a sound mark of Nokia Corporation.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.

The information contained in this user guide was written for the Nokia 6136 product. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This device may contain commodities, technology, or software subject to export laws and regulations from the U.S. and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

Contents

1. General information............. 8

2. Get started ......................... 11

3. Your phone......................... 17

4. Call functions..................... 23

5. Phone menus...................... 26

6. Messaging .......................... 27

7. Contacts ............................. 38

8. Call log ............................... 42

9. Settings .............................. 43

10. Operator menu................ 62

11. Gallery.............................. 63

12. Media............................... 64

13. Instant messaging........... 69

14. Organizer ......................... 73

15. Applications .................... 77

16. Web.................................. 79

17. SIM services..................... 87

18. Computer connectivity ... 88

19. Enhancements................. 89

20. Reference information.... 90

Index....................................... 99

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may get interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any regulations or rules. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Do not use the phone at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

For your safety

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACKUP COPIES

Remember to make back-up copies or keep a written record of all important information.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the end key as many times as needed to clear the display and return to the start screen. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

■ About your device

The wireless device described in this guide is approved for use on the EGSM 850, 900, 1800, and 1900 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

When taking and using images or video clips, obey all laws and respect local customs as well as privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the phone must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

■ Network services

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Your

For your safety

device may also have been specially configured. This configuration may include changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as multimedia messaging service (MMS), browsing, instant messaging, remote synchronization, and content downloading using the browser or MMS, require network support for these technologies.

■ Shared memory

The following features in this device may share memory: the Gallery, contacts, text messages, multimedia messages, instant messages, calendar, to-do notes,

and Java reduce the memory available for the remaining features sharing memory. For example, saving many Java Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features, such as text messages, may have a certain amount of memory specially allotted to them in addition to the memory shared with other features.

games and applications. Use of one or more of these features may

applications may use all of the available memory.

General information

1. General information

Congratulations on your purchase of this Nokia mobile phone. Some of its other features include a calendar, a clock, an alarm clock, a radio, and a built-in camera.

■ Access codes

Security code

The security code (5 to 10 digits) helps to protect your phone against unauthorized use. The preset code is 12345. To change the code, and to set the phone to request the code, see ”Security,” p. 59.

If you enter an incorrect security code five times in succession, the phone ignores further entries of the code. Wait for five minutes, and enter the code again.

PIN codes

The personal identification number (PIN) code and the universal personal identification number (UPIN) code (four to eight digits) help to protect your SIM card against unauthorized use. See ”Security,” p. 59. The PIN code is usually supplied with the SIM card. To set the phone to request the PIN code, see ”Security,” p. 59.

The PIN2 code (four to eight digits) may be supplied with the SIM card and is required for some functions.

The module PIN is required to access the information in the security module. See ”Security module,” p. 84. The module PIN is supplied with the SIM card if the SIM card has a security module in it.

The signing PIN is required for the digital signature. See ”Digital signature,” p. 85. The signing PIN is supplied with the SIM card if the SIM card has a security module in it.

PUK codes

The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (eight digits) is required to change a blocked PIN code and UPIN code, respectively. The PUK2 code is required to change a blocked PIN2 code.

General information

If the codes are not supplied with the SIM card, contact your service provider for the codes.

Call restrictions password

The call restrictions password (four digits) is required when using Call

restrictions. See ”Security,” p. 59. You can obtain the password from your service

provider.

If you enter an incorrect call restrictions password three times in succession, the password is blocked. Contact your service provider for assistance.

■ Copyright protection

Copyright protections may prevent some images, ringing tones, and other content from being copied, modified, transferred, or forwarded.

■ Configuration settings service

To use some of the network services, such as mobile Internet services, MMS, or remote Internet server synchronization, your phone needs the correct configuration settings. You may be able to receive the settings directly as a configuration message. After receiving the settings, you need to save them on your phone. The service provider may provide a PIN that is needed to save the settings. For more information on availability of the settings, contact your service provider.

When you have received a configuration message, Configuration sett. received is displayed.

To save the settings, select Show > Save. If the phone requests Enter settings'

PIN:, enter the PIN code for the settings, and select OK. To receive the PIN code,

contact the service provider who supplies the settings. If no settings are saved yet, these settings are saved and set as default configuration settings. Otherwise, the phone asks, Activate saved configuration settings?

To discard the received settings, select Show > Discard.

To edit the settings, see ”Configuration,” p. 58.

■ Download content and applications

You may be able to download content, such as themes, tones, and video clips, to the phone (network service). Select the download function (for example, in the

General information

Gallery menu). To access the downl oad function, see the respective menu

descriptions.

You may also be able to download updates of phone software (network service). See ”Phone software updates,” p. 60.

For availability of different services, pricing, and tariffs, contact your service provider.

Important: Use only services that you trust and that offer adequate security and protection against harmful software.

Get started

2. Get started

■ SIM card and battery installation

Keep all SIM cards out of the reach of small children. For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or another vendor. Before installing the SIM card and removing the battery, always switch the device off, and disconnect the charger.

The SIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

Always switch off the power, and disconnect the charger and any other device before removing the cover. Avoid touching electronic components while changing the cover. Always store and use the device with the cover attached.

To install the SIM card, do the following:

1. Press firmly and slide the top of the back cover to release it; then continue sliding the back cover to remove and lift it from the phone.

2. After you have removed the back cover, insert your finger under the battery, and lift it as shown.

3. Place a fingernail in the middle of the metal SIM card holder. Then, unlatch and swing the SIM card holder open.

4. Insert the SIM card into the holder as shown, beveled corner first, with the gold-colored contacts on the SIM card face up (away from the phone).

Get started

5. Swing the SIM card holder closed. The gold-colored contacts on the SIM card meet the gold-colored contacts on the inside of the phone. Gently press the SIM card holder into the phone until it clicks into place.

6. Replace the battery by positioning it (with the label side facing up) so the gold-colored contacts match up with those on the phone. Slide the battery in until it snaps into place.

7. Slide the back cover until it locks into place.

■ Charge the battery

Warning: Use only batteries, chargers, and enhancements approved by

Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

This device is intended for use with the BL-4C battery. Always use original Nokia batteries. See ”Nokia battery authentication guidelines,” p. 91.

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from the AC-4 charger.

For availability of approved enhancements, please check with your dealer.

1. Connect the charger to a standard wall outlet.

2. Insert the charger plug into the round jack in the bottom of the phone. If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

3. Disconnect the charger from the phone when the battery is fully charged.

Get started

You can use the phone while the charger is connected. The charging time depends on the charger and the battery used. For example, charging a BL-4C battery with the AC-4 charger takes approximately 1 hour and 10 minutes while the phone is in the standby mode.

■ Memory card installation

Use only compatible microSD cards with this device. Other memory cards do not fit in the memory card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted.

Use only microSD cards approved by Nokia for use with this device. Nokia utilizes the approved industry standards for memory cards but not all other brands may function correctly or be fully compatible with this device.

You can use a memory card to extend the memory of the Gallery. See ”Gallery,” p. 63. You can insert or change the memory card without turning the phone off.

Important: Do not remove the memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

To insert the memory card, use a fingernail as a lever, place it in the recessed area of the memory card holder and swing the holder open (1). Place the memory card in the card holder (2). Make sure that the memory card is properly inserted and that the gold-colored contacts on the card are facing upwards. Close the memory card holder (3).

Get started

You can use the memory card to save your multimedia files, such as video clips, sound files, and images, in the Gallery.

To remove the memory card, use a fingernail as a lever, place it in the recessed area of the memory card holder and swing the holder open. Push with a fingernail to loosen the memory card from the holder; then, pull the card out. Close the memory card holder.

To format the memory card, see ”Format memory card,” p. 63.

■ Turn the phone on and off

Press and hold the end key until the phone turns on or off. If the phone asks for a PIN, enter the code, and select OK.

Plug and play service

When you turn on your phone for the first time, and the phone is in the standby mode, you may be asked to get the configuration settings from your service provider (network service). Confirm or decline the query. See Connect to service

provider support in ”Configuration,” p. 58 and ”Configuration settings service,”

p. 9.

■ Open the fold

When you open the fold of the phone, it opens up to approximately 155 degrees. Do not try to force the fold open more.

■ Normal operating position

Use the phone only in its normal operating position.

Your device has an internal antenna.

Get started

Note: As with any other radio transmitting device, do not touch the

antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the device optimizes the antenna performance and the battery life.

Get started

■ Wrist strap

Remove the back cover from the phone and thread the wrist strap as shown in the picture.

3. Your phone

■ Keys and parts

• Earpiece (1)

• Main display (2)

• Call key (3)

• Left, middle, and right selection keys (4)

• Four-way navigation key (5)

• End key ends calls (short key press) and turns phone on and off (long key press) (6)

• Keypad (7)

• Camera lens (8)

• Mini display (9)

• Loudspeaker (10)

• Camera release key (11)

• Memory card holder (12)

Your phone

• Pop-Port connector

• Charger connector (14)

• Infrared (IR) port (15)

(13)

Your phone

• Volume is activated by volume down/up key (short key press) and voice dialing is activated by volume down key (long key press) (16)

■ Standby mode

When you turn on your phone, the first screen that appears is the start screen, which indicates your phone is in the standby mode. When your phone is in the standby mode, the selection keys access specific functions, and the indicators appear on the start screen. Indicators show the status of the phone.

• Network signal strength (1)

• Battery strength indicator (2)

• Clock (3) — if the time is set to appear on the display. See ”Time and date,” in ”Settings,” p.

51.

• The name of the service provider or the operator logo (4)

• Calendar (5) — the date is displayed if it is set to appear on the display and the active standby is not set. See ”Active standby mode,” p. 19 and ”Time and date,” p. 51.

• Active standby (6). See ”Active standby mode,” p. 19.

• The left selection key (7) is Go to or a shortcut to another function. See ”Left selection key,” p. 51.

• The middle selection key (8) mode is Menu.

• The right selection key (9) may be Names to access the list of contacts in the

Contacts menu, an operator specific name to access an operator specific Web

site, or a shortcut to a function that you selected. See ”Right selection key,” p. 51.

Your phone

Active standby mode

In the active standby mode, the phone can display separate content item windows, such as general indicators and and operator logo (1), shortcuts (2), audio functions (3), and the calendar (4). To select whether the active standby is shown, see Active standby in ”Standby mode settings,” p. 49.

The active standby is in passive mode when the middle selection key (5) is

Menu; you can only view content. To

activate the navigation mode and scroll through the content, use the navigation key. To change the key for accessing the navigation mode, see Enabling standby in ”Standby mode settings,” p. 49. When the arrow indicators are shown, you can scroll the item left and right.

To personalize and organize the active standby content, select Options > Active

standby. See ”Standby mode settings,” p. 49.

To exit the navigation mode, select Exit. If no keys are pressed after a certain period of time, the phone automatically returns to the passive mode.

Content items in navigation mode

Shortcut bar — To select a shortcut, scroll to the function you want and select it.

To change or organize the shortcuts when in the navigation mode, select

Options > Active standby > Options > Personalize, scroll to the shortcut

window, and select Options > Select links or Organize links.

Audio applications — To turn on the radio, scroll to and select it. To change a

channel in the radio, scroll left or right. To start the radio channel search, scroll and hold left or right.

Calendar — To view today’s notes, select the one you want. To view the notes for

the previous or next days, scroll left or right.

My note — To enter a note, select the content window, write your note, and save

it.

Timer — To start the countdown timer, select the content item. The remaining

time with a note is shown.

Your phone

General indicators — To show standby indicators, such as date, cell info display,

info messages, and closed user group index. The date is shown if the calendar is not selected as active standby content.

Standby mode shortcuts

To access the list of dialed numbers, press the call key once. See ”Make a call,” p.

23.

To call your voice mailbox (network service) when you have saved your voice mailbox number in the phone, press and hold 1.

To connect to a browser service, press and hold 0.

To set shortcut functions for the navigation key, see Navigation key in ”My shortcuts,” p. 51.

To make a call by pressing a number key with an assigned phone number, see ”1touch dialing,” p. 23.

To toggle between the Normal profile to the Silent profile, press and hold #.

Power saving screen saver

To save power, a digital clock screen saver overwrites the display when no function of the phone has been used for a certain period of time. See ”Power saver,” in ”Main display,” p. 50 or ”Power saver,” in ”Mini display,” p. 50 for information on activating the power screen saver.

■ Indicators and icons

Your phone has two types of identifiers: indicators and icons.

Indicators

See ”Standby mode,” p. 18 for information on indicators.

Icons

Icons are graphical representations of a specific item or situation. The following list describes each icon.

You have unread messages in the Inbox folder.

You have unsent, canceled, or failed messages in the Outbox folder.

Your phone

The phone registered a missed call.

You have received one or several instant messages, and you are connected to the instant messaging service.

The keypad is locked.

The alarm clock is set to On.

The phone does not ring for an incoming call or text message.

The countdown timer is running.

The stopwatch is running in the background.

/ The phone is registered to the GPRS or EGPRS network.

/ A GPRS or EGPRS connection is established.

/ The GPRS or EGPRS connection is suspended (on hold), for example, if

there is an incoming or outgoing call during an EGPRS or GPRS dial-up connection.

When the infrared connection is activated, the indicator is shown continuously.

If you have two phone lines, the second phone line is selected.

All incoming calls are diverted to another number.

The loudspeaker is activated, or the music stand is connected to the phone.

Calls are limited to a closed user group.

The timed profile is selected.

A call over local access connection through Wireless Fidelity (Wi-Fi) is active. See ”Wi-Fi,” p. 43.

■ Keypad lock (keyguard)

The keyguard disables your keypad to prevent accidental key presses.

• To lock the keypad, select Menu, and press * within 3.5 seconds.

• To unlock the keypad, select Unlock and press * within 1.5 seconds.

Your phone

If the Security keyguard is set to On, enter the security code if requested.

To answer a call when the keyguard is on, press the call key. When you end or reject the call, the keypad is automatically locked.

When the keyguard is on, calls still may be possible to the official emergency number programmed into your device. Enter the emergency number and press the call key.

For information about Security keyguard, see ”Phone,” p. 57.

Call functions

4. Call functions

■ Make a call

1. Enter the phone number, including the area code. To delete an incorrect character, select Clear.

For international calls, press * twice for the international prefix (the + character replaces the international access code); and then enter the country code, the area code without the leading 0, if necessary, and the phone number.

2. To call the number, press the call key.

3. To end the call or to cancel the call attempt, press the end key, or select

Options > End call.

■ 1-touch dialing

Assign a phone number to one of the 1-touch dialing keys, 2 to 9. Call the number by one of the following ways:

• Press a 1-touch dialing key, and then press the call key.

•If 1-touch dialing is set to On, press and hold a 1-touch dialing key until the call is started. See 1-touch dialing in ”Call,” p. 56.

■ Enhanced voice dialing

You can make a phone call by saying the name that is saved in the contact list of the phone. A voice command is added automatically to all entries in the contact list of the phone.

Make a voice dialing call

If an application is sending or receiving data using a packet data connection, end the application before you use voice dialing.

Voice commands are language-dependent. To set the language, see Voice

playback language in ”Phone,” p. 57.

Call functions

Note: Using voice tags may be difficult in a noisy environment or during

an emergency, so you should not rely solely upon voice dialing in all circumstances.

1. In the standby mode, press and hold the right selection key. A short tone is played, and Speak now is displayed.

If you are using a compatible headset with the headset key, press and hold the headset key to start the voice dialing.

2. Say the voice command clearly. If the voice recognition is successful, a list with matches is shown. The phone plays the voice command of the match on the top of the list. After about 1.5 seconds, the phone dials the number; or if the result is not the correct one, scroll to another entry, and select to dial the entry.

Using voice commands to carry out a selected phone function is similar to voice dialing. See Voice commands in ”My shortcuts,” p. 52.

■ Answer or reject a call

• Open the fold, or press the call key to answer the call. To mute the ringing tone, select Silence, if the fold is open or if the fold is closed, press the volume up or down key.

• To reject an incoming call when the fold is open, press the end key.

If Forward if busy is activated in your voice mailbox, the call is forwarded to your voice mail. If not, the call is rejected. If a compatible headset supplied with the headset key is connected to the phone, press the headset key to answer and end a call.

Call waiting

Call waiting is a network service. To answer the waiting call during an active call, press the call key. The first call is put on hold. To end the active call, press the end key.

To activate the Call waiting function, see ”Call,” p. 56.

■ Options during a call

Many of the options that you can use during a call are network services. For availability, contact your service provider.

Call functions

To increase or decrease the volume during a call, press the volume up or down key on the side of the phone.

Select Options during a call and the following options may be available.

Touch tones — to send tone strings

Swap — to switch between the active call and the call on hold

Transfer calls — to connect a call on hold to an active call and disconnect

yourself

Conference — to make a conference call that allows up to five persons to take

part in a conference call

Private call — to discuss privately in a conference call

Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

Phone menus

5. Phone menus

Phone features are grouped according to function and are accessed through the main menus of your phone. Each main menu contains submenus and lists from which you can select or view items and customize phone features. Scroll to access these menus and submenus.

Some menus may not be available, depending on your network. For more information, contact your service provider.

■ Menu views

Your phone may have two types of menu views: List and Grid.

In the List interface, images introduce every menu. Scroll to navigate through the menus. As you scroll through the menus, the menu number appears in the upper right corner of the display. Below the menu number is a scroll bar with a tab. The tab moves up or down as you scroll through the menus, providing a visual representation of your current position in the menu structure.

In the Grid interface, multiple menu icons appear on a single display. Use the four-way navigation key to scroll through the icons. The name of the menu appears at the top of the display and the icon for the selected menu is outlined.

To change the menu view, select Options > Main menu view > List or Grid.

■ Access a menu function

1. Select Menu and the menu you want.

2. If the menu contains submenus, select the one that you want.

3. If the selected menu contains further submenus, select the one that you want

4. To return to the previous menu level, select Back. To exit the menu, select

Exit.

Messaging

6. Messaging

You can use mobile messages to keep in touch with friends, family, and business associates by using the short message service (SMS), which is a network service. Not all messaging features are available in all wireless networks. Contact your service provider for availability and subscription information.

When sending messages, your phone may display the words Message sent. This is an indication that the message has been sent by your device to the message center number programmed into your device. This is not an indication that the message has been received at the intended destination. For more details about messaging services, check with your service provider.

■ Text messages

Your device supports the sending of text messages beyond the character limit for a single message. Longer messages are sent as a series of two or more messages. Your service provider may charge accordingly. A message length indicator appears at the top of the phone display. This indicator allows you to see how many characters are left in the message as you are entering text because it counts backwards from 913.

Characters that use accents or other marks, and characters from some language options like Chinese, take up more space limiting the number of characters that can be sent in a single message.

You can use predefined templates to help you write text messages. Before you can send any text message, you need to save some message settings. See ”Message settings,” p. 35.

Text entry

To enter text while writing messages, use traditional or predictive text input. When using traditional text input, press a number key, 1 to 9, repeatedly until the character you want is displayed. In predictive text input you can enter a letter with a single key press.

When you write text, appears at the top left of the display, indicating predictive text input, and is displayed, indicating traditional text input. ,

, or is displayed next to the text input indicator, indicating the

character case. To change the character case, press #. indicates number

Messaging

mode. To change from the letter to number mode, press and hold #, and select

Number mode.

Settings

To set the writing language to a language other than that selected, select

Options > Writing language. Predictive text input is only available for the

languages on the list.

To set the predictive text input option, select Options > Prediction on, or to set traditional text input option, select Options > Prediction off.

To quickly set predictive text input on or off when writing text, press # twice, or select and hold Options.

Predictive text input

Predictive text input allows you to write text quickly by using the phone keypad and a built-in dictionary.

1. Start writing a word, using the keys, 2 to 9, and press each key only once for one letter. The word changes after each keystroke.

2. When you finish writing the word and it is correct, press 0.

3. If a displayed word is not correct, press * repeatedly, or select Options >

Matches. When the word that you want is displayed, select Use.

4. If the ? character is displayed after the word, the word you intended to write is not in the dictionary. To add the word to the dictionary, select Spell. The phone displays the entered letters. Enter the word (traditional text input is used), and select Save.

Traditional text input

Press a number key, 1 to 9, repeatedly until the character you want is displayed. Not all characters available under a number key are printed on the key. The characters available depend on the selected writing language. See ”Settings,” p. 28.

If the next letter you want is located on the same key as the present one, wait until the cursor is displayed, or press any of the navigation keys, and enter the letter.

To access the most common punctuation marks and special characters, press 1. To insert a space, press 0.

If you want more characters, press *.

Messaging

Write and send

1. Select Menu > Messaging > Create message > Text message, and enter the recipient’s phone number in the To: field.

2. To retrieve a phone number from Contacts, select Add > Contact. To send the message to multiple recipients, add the contacts you want one by one.

3. To send the message to persons in a group, select Contact group and the group you want. To retrieve the contacts to which you recently sent messages, select Add > Recently used.

4. Scroll down and enter a message. See ”Text entry,” p. 27.

5. To insert a template to the text message, select Options > Use template and the template you want to insert.

6. To see how the message will look to the recipient, select Options > Preview.

7. To send the message, select Send.

Read and reply

When you receive messages, either 1 message received or N messages received is displayed, where N is the number of new messages.

1. To view a new message, select Show. To view it later, select Exit.

To read the message later, select Menu > Messaging > Inbox. If more than one message has been received, select the message that you want to read. indicates an unread message in Inbox.

2. While reading a message, select Options, and delete or forward the message, edit the message as a text message, move it to another folder, or view or extract message details. You can also copy text from the beginning of the message to your phone calendar as a reminder note.

3. To reply to a message, select Reply > Text message, Multimedia, or Voice

notes.

4. Scroll down and enter a message in the Message: field. See ”Text entry,” p. 27. If you want to change the message type for your reply message, select

Options > Change msg. type.

5. To send the message, select Send.

Messaging

■ SIM messages

SIM messages are text messages that are saved to your SIM card. You can copy or move those messages to the phone memory, but not vice versa. Received messages are saved to the phone memory.

To read SIM messages, select Menu > Messaging > Options > SIM messages.

■ Multimedia messages

Note: Only devices that have compatible multimedia message or e-mail

features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.

A multimedia message can contain text, sound, a picture, a calendar note, a business card, or a video clip. If the message is too large, the phone may not be able to receive it. Some networks allow text messages that include an Internet address where you can view the multimedia message.

Multimedia messaging (network service) supports the following formats:

• Picture: JPEG, GIF, animated GIF, and WBMP

• Sound: AMR and 13K audio

• Video clips: 3GPP and 3GPP2 formats or MPEG video and AMR audio or 13K audio

The phone may not support all variations of the file formats.

You cannot receive multimedia messages during a call, a game, another Java application, or an active browsing session over GSM data (for example, when the phone is used as a modem to access the internet). Because delivery of multimedia messages can fail for various reasons, do not rely solely upon them for essential communications.

Write and send

The wireless network may limit the size of multimedia messages. If the inserted picture exceeds this limit, the device may make it smaller so that it can be sent by MMS.

To set the settings for multimedia messaging, see ”Multimedia,” p. 36. To check availability and to subscribe to the multimedia messaging service, contact your service provider.

1. Select Menu > Messaging > Create message > Multimedia.

+ 74 hidden pages
