Microsoft RM-1045 User Guide

Quick Guide

Nokia Lumia 930

[ERROR: book part number not defined]

Issue 1.1 EN-US RM-1045

Keys and parts

1SIM card holder
2Earpiece
3 Audio connector (3.5 mm)
4 Front camera
5 Light sensor
6Volume keys
7 Power/Lock key
8 Camera key
9Search key
10 Start key
11 Microphone
12 Back key
13 Antenna area
14 Camera flash
15 Back camera
16 NFC area
17 Wireless charging area
18 Speakerphone
19 Micro-USB connector

Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable,
may be sold separately.

Avoid touching the antenna area while the
antenna is in use. Contact with antennas affects
the communication quality and may reduce
battery life due to higher power level during
operation.

Get started

Make sure the phone is switched off.

1. Hold your phone face down, and pull out the
tab.

2. Pull the SIM card holder out.

3. Place the SIM card into the holder with the

contacts facing up.

Use of incompatible SIM cards, or use of SIM card
adapters, may damage the card or the device, and
may corrupt data stored on the card.

4. Slide the holder back into the phone.

If you need to reopen the SIM holder after you
have removed the tab, use your fingernail to slide
out the holder. Do not use any sharp tools, as they
may damage the phone.

Charge the battery

Plug a compatible charger into a wall outlet, and
connect the micro-USB end to your phone. You
can also charge your phone from a computer with
a USB cable.

If the battery is completely discharged, it may
need to charge for up to 20 minutes before you
can use your device. The charging indicator may
not be displayed in this time.
