Microsoft RM 1043 User Manual

Quick Guide

Nokia 225 Dual SIM

Issue 1 EN RM-1043

Psst...

This guide isn't all there is...

For the online user guide and troubleshooting
help, go to www.nokia.com/support.

The instructions in this user guide are based on
the latest available software version. If your
device has not been updated to the latest
available software, there may be differences in
the availability and functionality of some
features.

For info on Microsoft Mobile Service terms and
Privacy policy, go to www.nokia.com/privacy.

Contents

Safety 3

Get started 5

Keys and parts 5
Insert SIM, battery, and memory card 6
Charge the battery 10
Lock or unlock the keys 11
Change the volume 11

Basics 12

People & messaging 16

Internet 18

Camera 18

2

Entertainment 20

Phone management & connectivity 21

Product and safety info 22

Safety

We invite you to read the instructions on this guide before using the
device.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or

when it may cause interference o r danger, for example, in
aircraft, in hospitals or nea r medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the

vehicle while driving. Your first consideration while driving
should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which

could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved

by Microsoft Mobile for use with this device. Do not connect
incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high

volume levels for long periods. Exercise caution when holding
your device near your ear while the loudspeaker is in use.

3

SAR

This device meets RF exposure gui delines when used either in

the normal use position agai nst the ear or when positioned at
least 1.5 centimetre (5/8 inch) away from the body. The specific
maximum SAR values can be found in the Certification Information
(SAR) section of this user guide. For more info, go to www.sar-
tick.com.

When a carry case, belt clip or other form of device holder is used for
body-worn operation, it should not contain metal and should provide
at least the above-stated separatio n distance from the body. Note
that mobile devices may be transmitting even if you are not making
a voice call.

4

Get started

Get to grips with the basics, and have your phone
up and running in no time.

Keys and parts

Explore the keys and parts of your new phone.

1 Charger connector
2 Flashlight
3 Headset connector (3.5 mm)
4 Screen
5Scroll key
6End/Power key
7Microphone
8Keypad
9Call key

5

10 Selection keys
11 Earpiece
12 Camera lens. Before using the camera,

remove the protective tape from the lens.
13 Antenna area

You can set your phone to ask for the security
code that you define. The default security code is

12345.

Avoid touching the antenna area while the
antenna is in use. Contact with antennas affects
the communication quality and may reduce
battery life due to higher power level during
operation.

Do not connect to products that create an output
signal, as this may damage the device. Do not
connect any voltage source to the audio
connector. If you connect an external device or
headset, other than those approved for use with
this device, to the audio connector, pay special
attention to volume levels.

Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable,
may be sold separately.

Insert SIM, battery, and memory card

Learn how to insert the battery and SIM and
memory cards.

Important: This device is designed to be
used with a standard SIM card (see figure)

6

only. Use of incompatible SIM cards may
damage the card or the device, and may
corrupt data stored on the card. Please
consult your mobile operator for the use of
a SIM card that has a mini-UICC cutout.

Use only compatible memory cards approved for
use with this device. Incompatible cards may
damage the card and the device and corrupt data
stored on the card.

Note: Switch the device off and disconnect
the charger and any other device before
removing any covers. Avoid touching
electronic components while changing any
covers. Always store and use the device with
any covers attached.

1. Hold your phone by the top corners, and with
the thumb of your other hand, press the middle
of the back cover, and carefully remove the cover.

7

2. If the battery is in the phone, lift it out.

3. Push the SIM in with the contact area face down.

4. To insert a second SIM, push the SIM in with the

contact area face down until it locks into place.

8

5. Line up the battery contacts, and put the

battery in.

6. Push the memory card into the memory card
slot until it locks into place.

Important: Do not remove the memory card
when an app is using it. Doing so may
damage the memory card and the device
and corrupt data stored on the card.

7. Replace the back cover.

Remove the memory card

Open the back cover, and push the memory card
in until it's released.

Switch your phone on

Press and hold the power key.

9

Charge the battery

Your battery has been partially charged at the
factory, but you may need to recharge it before
you can use your phone.

1. Plug the charger into a wall outlet.

2. Connect the charger to the phone. When done,

unplug the charger from the phone, then from the
wall outlet.

If the battery is completely discharged, it may
take up to 20 minutes before the charging
indicator is displayed.

Tip: You can use USB charging when a wall
outlet is not available. Data can be
transferred while charging the device. The
efficiency of USB charging power varies
significantly, and it may take a long time for
charging to start and the device to start
functioning.

Make sure your computer is switched on.

10
