Microsoft RM 1025 Users Manual

Quick Guide

Nokia XXX

Issue 1 EN RM-1025

Psst...

This guide isn't all there is... There's a user guide in your phone – it's always

with you, available when needed. On the start screen, tap

For the online user guide, even more info, and troubleshooting help, go to www.nokia.com/ support.

The instructions in this user guide are based on the latest available software version. If your device has not been updated to the latest available software, there may be differences in the availability and functionality of some features.

For info about writing text on your phone, see the user guide in your phone or the online user guide.

For info on Microsoft Mobile Service terms and Privacy policy, go to www.nokia.com/privacy.

Care.

Contents

For your safety 3

Get started 5

Keys and parts 5 Insert SIM, battery and memory card 6 Charge the battery 9 Copy contacts from your old phone 9

Basics 10

Explore your phone 11 Switch between views 13 Find your favourites 14 Change settings quickly 15 Switch Glance screen on 16

Camera 16

Take a photo 16

Phone management & connectivity 17

Connect your computer to the web 17 Sync your content with an Android phone 17

Find your model number and serial number (IMEI) 18

Product and safety info 18

MANUFACTURER’S LIMITED WARRANTY 28

NOKIA — MANUFACTURER’S LIMITED WARRANTY 32

For your safety

We invite you to read the instructions on this guide before using the device.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or

when it may cause interference o r danger, for example, in aircraft, in hospitals or nea r medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the

vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which

could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved

by Microsoft Mobile for use with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high

volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

SAR

This device meets RF exposure gui delines when used either in

the normal use position agai nst the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar- tick.com.

When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separatio n distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call.

Get started

Get started with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone.

1Micro-USB connector 2 Audio connector (3.5 mm) 3Earpiece 4 Volume/Zoom keys 5 Lock/Power key 6 Back key 7End key

8Microphone 9Scroll key 10 Call key 11 Options key 12 Screen 13 Camera lens. Before using the camera,

remove the protective tape from the lens. 14 Antenna area 15 Speaker

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

Do not connect to products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.

Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately.

Insert SIM, battery and memory card

Learn how to insert a battery and SIM and memory cards.

Important: Your device uses a micro-SIM

card, also known as a mini-UICC SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

1. Place your finger on the logo and gently lift the back cover.

2. If the battery is in the phone, lift it out.

3. Open the SIM holder, and slide the SIM into the

holder. Close the holder, and lock it into place. Make sure the SIM contact area is face down.

4. Insert the memory card into the memory card

holder. Close the holder, and lock it into place.

Tip: To remove the memory card, unlock the holder, then pull the memory card out.

5. Line up the battery contacts, and push the battery in.

6. Replace the back cover.

7. To switch your phone on, press and hold the

power key until the phone vibrates.

Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.

1. Plug the charger into a wall outlet.

2. Connect the charger to the phone. When done,

unplug the charger from the phone, then from the wall outlet.

If the battery is completely discharged, it may take up to 20 minutes before the charging indicator is displayed.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

Make sure your computer is switched on.

Copy contacts from your old phone

Get all your contacts to your new phone in one go.

Your old phone must have Bluetooth, and the contacts must be stored in the phone memory, not on the SIM.

1. On both your new and old phone, switch Bluetooth on, and make sure both phones are visible to others.

2. On your new phone, select options key, and select Import contacts >

Another phone.

Tip: If you already have contacts on your

phone, select key, and select Import and export > Another

phone.

3. Move the phones close to each other. When the

phones are connected using Bluetooth, the contacts transfer starts.

If your contacts are written in a language that is not supported by your new phone, the contact info may not show correctly.

Tip: If you have an Android phone, you can keep your contacts and text messages in sync on both your phones using the Sync app. Switch on Bluetooth on your Android phone, and select phone.

People, press the

People, press the options

Sync on your new

Basics

Learn how to get the most out of your new phone.

Explore your phone

Explore the views and features of your phone.

See the apps and features of your phone

Press the end key.

Go to an app or feature

Press the scroll key up, down, left, or right.

Tip: In most lists, you can delete list items quickly by using the scroll key. Select the item you want to delete, scroll left, and press the scroll key.

Open an app or select a feature

Press the scroll key.
