Microsoft RM-1020 User Guide

Quick Guide

Nokia Lumia 530

123123 Issue 1 EN RM-1020

Keys and parts

Important: For important info on the safe use
of your device and battery, read “Safety” and
“Product and safety info” in the device user guide
at www.nokia.com/support and in the in-device
user guide before you take your device into use.

Nokia Care.

Select

1Earpiece
2Volume keys
3 Power/Lock key
4Microphone
5 Antenna areas
6Camera
7 Audio connector 3.5 mm
8Micro-USB connector
9 Loudspeaker

Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable,
may be sold separately.

Avoid touching the antenna area while the
antenna is in use. Contact with antennas affects
the communication quality and may reduce
battery life due to higher power level during
operation.

Insert the SIM and memory cards

Make sure the phone is switched off.

1. At the top of the phone, put your fingernails in
the seam between the screen frame and the back
cover. Do not use any sharp tools, as they may
damage the phone.

2. Place your thumb in the middle of the back
cover and bend the cover to remove it.

3. If the battery is in, lift it out from the upper right
corner.

4. Slide the micro-SIM card into the SIM1 slot with
the metal contact area down.

5. Slide the memory card into the memory card
slot.

6. If you have a second SIM card, slide the SIM2
holder out, place the second SIM on the holder
with the metal contact area up, and slide the
holder back in.

Important: Your device uses a micro-SIM card,
also known as a mini-UICC SIM card. Use of
incompatible SIM cards, or use of SIM card
adapters, may damage the card or the device, and
may corrupt data stored on the card.

Tip: For best performance, it is recommended
that you use a fast 4–128GB memory card by a
well-known manufacturer.
