Page 1

Nokia 7610 User Guide

Phone information Numbers Where is the number?

My number

Voice mail number

Wireless provider’s number

Provider’s customer care

Model number

Type number

IMEI number

PRELIMINARY DRAFT FOR FCC APPROVAL

APRIL 8, 2004

Wireless service provider Wireless service provider Wireless service provider Wireless service provider Label on back of phone (under

battery) Label on back of phone (under

battery)

Page 2

FCC DRAFT

IMINARY

Page 3

LEGAL INFORMATION

DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the products RH-51 and RH52

are in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity

168

PART NO. 9230217, ISS UE NO. 1

are trademarks or registered trademarks of Nokia Corporation. Other company and product names mentioned herein may be trademarks or trade names of their respective owners.

Printed in Canada, May 2004

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

FCC DRAFT

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

IMINARY

USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO (A) DAT A OR INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY; AND (B) OTHER USES SPECIFICALLY AND SEPARATELY LICENSED BY MPEG LA, L.L.C.

The information contained in this user guide was written for the Nokia 7610 a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice.

product. Nokia operates

Page 4

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

Manufactured or sold under one or more of the following US patents:

4868846 4945633 5001372 5101175 5151946 5173927 5212834 5230091 5241583 5311151 5317283 5331638 5335362 5353328 5371481 5378935 5384782 5396657 5400949 5416435 5442521 5446364 5479476 5526366 5553125 5557639 5565821 5570369 5581244 5600708 5625274 5677620 5692032 5729541 5760568 5794142 5802465 5809413 5827082 5839101 5844884 5845219 5870683 5884103 5889770 5907823 5912570 5914690 5914796 5917868 5920826 5956332 5956625 5956633 5966378 5977887 5987137 5991857 6006114 6011853 6014551 6014573 6026161 6035189 6038238 6043760 6047196 6049796 6050415 6055439 6060193 6069923 6072787 6081732 6084920 6084962 6094587 6097964 6105784 6112099

FCC DRAFT

6115617 6119180 6121846 6128509 6138091 6140966 6144243 6144676 6148209 6151485 6151507 6163609 6164547 6167248 6185295 6188909 6249584 6259312 6266330 6272361 6282436 6292668 6295286 6311054 6314166 6324389 6324412 6347218 6363259 6370362 6370389 6377820 6381468 6392660 6400958 6453179 6463278 6470470 6487397 6522670 6198928 4969192 5266782 5390223 5444816 5487084 5640395 5664053 5699482 5701392 5722074 5754976 5805301 5835889 5857151 5859843 5862178 5898925 5930233 5946651 5960354 5960389 5963901 6005857 6011971 6031827 6118775 6128322 6137789 6167248 6170073 6178535 6195338 6199035 6240076 6266321 6285888 6356759 6377803 6430163 6438370 6456237 RE32580 5818437 5953541 6011554 4558302

IMINARY

Page 5

Nokia 7610 phone at a glance

Power key (on top)

Earpiece

Speaker (on side)

Camera lens

Display

Left selection key

Send key

FCC DRAFT

Five-way scroll key

Right selection key

End key

IMINARY

Edit key

Menu key

Clear key

Note: The internet symbol on the 0 key does not appear on all phones.

Charger connector, Pop-Port connector,

and microphone (on bottom)

Page 6

Quick guide

Make a call Enter a phone number, and press the Send key. Answer a call Press the Send key. Answer call during call Select Options > Answer. End a call Press the End key. Decline a call Press the End key Mute a call Select Options > Mute during a call. Redial Press the Send key twice. Adjust call volume Scroll left or right with the scroll key during a call. Use the in-call menu Select Options during a call. Save a name and number Enter a number, select Options > Add to contacts >

Look up a name Select Menu > Contacts, and in the search field at the

Use 1-touch dialing Press and hold a key (2–9). You must assign a key to a

Check voice mail Press and hold the 1 key (contact your service provider

FCC DRAFT

Write and send text messages

Send a picture Capture a picture, allow the picture time to save, and

Read a new message If a new message arrives, select Show to display the

Press Press a key briefly and release it. Press and hold Press and hold a key for 2 to 3 seconds and release it.

Create new, choose a category, enter a name, and select Done. See "Write text," p. 47.

bottom of the screen, key in the first letters of the name you want to find.

number in Contacts. See "Assign 1-touch dialing keys," p. 27.

for details). Select Menu > Messages > New message > Text

message. Enter the recipient in the To field. Enter the text message, and select Options > Send.

then select Options > Send > Via multimedia. Enter the recipient in the To field. Enter the text message, and select Options > Send.

message.

IMINARY

Page 7

Nokia 7610 phone at a glance . . . . . . . . . . . . . . . . . v

Quick guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

1 FOR YOUR SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . 1

About your phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Network services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Shared memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2 General information . . . . . . . . . . . . . . . . . . . . . . . . . 4

E-newsletters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Follow graphic clues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Find the phone label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Contact Nokia. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Accessibility solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Remove the back cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

FCC DRAFT

Insert the SIM card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Insert the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Insert the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Charge the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Switch the phone on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Attach the wrist strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Tips on efficient operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

If the phone requests a PIN code . . . . . . . . . . . . . . . . . . . . . . . . 10

If the phone requests a lock code . . . . . . . . . . . . . . . . . . . . . . . . 11

Set the time and date. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

IMINARY

[ vii ]

Page 8

Make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Standby mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Options lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Common actions for all applications . . . . . . . . . . . . . . . . . . . . . 15

Search for items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Volume control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Keyguard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4 Your phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Answer a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5 Personal information . . . . . . . . . . . . . . . . . . . . . . . 25

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

FCC DRAFT

Presence (network service) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Positioning (network service) . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

To-do . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Copy content from compatible Nokia phones . . . . . . . . . . . . . . 35

IMINARY

6 Multimedia. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

View images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

RealPlayer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Movie director. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

[ viii ]

Page 9

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

7 Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Write text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Write and send messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Create a multimedia presentation. . . . . . . . . . . . . . . . . . . . . . . . 52

Inbox—receive messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

My folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Remote mailbox (network service) . . . . . . . . . . . . . . . . . . . . . . . 55

Outbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

View messages on a SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Cell broadcast (network service) . . . . . . . . . . . . . . . . . . . . . . . . . 57

Service command editor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Messaging settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

8 Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

FCC DRAFT

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Call restriction (network service). . . . . . . . . . . . . . . . . . . . . . . . . 72

Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Enhancement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

IMINARY

9 Tools and applications . . . . . . . . . . . . . . . . . . . . . . . 74

Application manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

File manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Voice commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

[ ix ]

Page 10

Device manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

10 Personalization. . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Themes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Go to . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

11 Extras. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Converter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Voice recorder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Memory card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Wallet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

12 Instant messaging (IM) (network service) . . . . . . . . 94

IM service provider icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

FCC DRAFT

Before using IM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

IM settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

IM conversations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

IM contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Group chat sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Log off service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

IMINARY

13 Web (mobile browser) . . . . . . . . . . . . . . . . . . . . . 104

[ x ]

Page 11

Basic steps for web access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Browser service set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

Make a connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

Bookmarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Browse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

End a connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

Clear the cache. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

Browser settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

14 Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Bluetooth connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

USB connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115

Connection manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115

Connect your phone to a computer . . . . . . . . . . . . . . . . . . . . . 116

Use the CD-ROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116

FCC DRAFT

15 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . 119

SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Memory low . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Different ways to store data . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Phone display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Bluetooth connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Multimedia messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Browser services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

IMINARY

[ xi ]

Page 12

PC connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Application not responding . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

16 Reference information . . . . . . . . . . . . . . . . . . . . . 123

Battery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Enhancements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123

Enhancements, batteries, and chargers . . . . . . . . . . . . . . . . . .124

Care and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Additional safety information . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

Certification information (SAR). . . . . . . . . . . . . . . . . . . . . . . . . 129

Nokia 7610 technical information . . . . . . . . . . . . . . . . . . . . . . 131

Message from the CTIA . . . . . . . . . . . . . . . . . . . . 137

Message from the FDA. . . . . . . . . . . . . . . . . . . . . 141

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

FCC DRAFT

IMINARY

[ xii ]

Page 13

FOR YOUR SAFETY

1 FOR YOUR SAFETY

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the phone at a refueling point. Don't use near fuel or

FCC DRAFT

chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Don't use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

IMINARY

Page 14

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the End key as many times as needed to clear the display and return to the main screen. Enter the emergency number, then press the Send key. Give your location. Do not end the call until given permission to do so.

•ABOUT YOUR PHONE

The Nokia 7610 phone comes in two model types—the Nokia 761 0 phone, which is approved for use in 900, 1800, and 1900 MHz GSM networks, and the Nokia 7610 b phone, which is approved for use in 850, 1800, and 1900 MHz GSM networks.

FCC DRAFT

To view your model type, refer to the information label under the battery. For more information about where this label is located, see “Find the phone label” on page 5.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the phone must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

IMINARY

•NETWORK SERVICES

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These Network Services may not be available on all networks, or you may have to make specific arrangements with your service provider before you can utilize

Page 15

FOR YOUR SAFETY

Network Services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use Network Services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Contact your service provider for more information.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

•SHARED MEMORY

The following features in this device may share memory: contacts, text messages, e-mail messages, multimedia messages, instant messages, images and ringing tones, video recorder, RealPlayer, calendar and to-do notes, themes, and downloaded applications. The use of one or more of these features may reduce the memory available for the remaining features sharing memory. For example, saving many images may use all of the available memory. Your phone may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features may have a certain amount of memory specially allotted to them in addition to the amount of memory shared with other features.

FCC DRAFT

IMINARY

Page 16

2 General information

Congratulations on your purchase of a Nokia mobile phone. Your phone provides many functions that are practical for daily use, such as a digital camera, a video recorder, messaging, e-mail, a clock, an alarm clock, a calculator, and a calendar. Your phone can connect to a PC, laptop, or other device using a data cable, or Bluet oo th te chn ol ogy. For more information on connectivity, refer to the User Guide

for Nokia PC Suite on the CD-ROM supplied with your phone. The User Guide for Nokia PC Suite, Nokia PC Suite, and all related software can be downloaded from

the U.S. Mobile Phone products section of www.nokia.com.

•REGISTER YOUR PHONE

Make sure to register your phone at www.warranty.nokiausa.com or 1-888-NOKIA-2U (1-888-665-4228) if you need to call the center or have your phone repaired.

•E-NEWSLETTERS

When you register your phone, you may sign up for Nokia's e-newsletter Nokia Connections. You will receive tips and tricks on using your phone, accessory

information, and special offers.

•FOLLOW GRAPHIC CLUES

FCC DRAFT

This guide uses certain icons to alert you to important information.

Note: Explains a feature or points out an important concept. Important: Indicates critical information on using a feature. Warning: Helps you avoid personal injury, damage to the phone, or

property damage.

IMINARY

Page 17

•FIND THE PHONE LABEL

General information

If you ever need to call the Nokia Customer Care Center or your service provider, you will need to provide specific information about your phone. This information is located on the phone labels, which are found on the back of the phone beneath the battery.

The inside cover of this guide has a chart in which you can enter the information from your phone label so that you can refer to it easily.

Information label under battery

•CONTACT NOKIA

To help Nokia promptly answer your questions, please have the following information available before contacting the Nokia Customer Care Center (see “Find the phone label” on page 5 to locate this information):

• Your phone model number (such as Nokia 7610 or Nokia 7610 b)

• Type number (such as RH-51)

• IMEI number

• Your local zip code

• The phone or enhancement in question

FCC DRAFT

Nokia Customer Care Center, USA Customer Care, Canada

Nokia Mobile Phones 7725 Woodland Center Blvd. Suite #150 Tampa, Florida 33614

Tel:1-888-NOKIA-2U (1-888-665-4228)

Fax:1-813-249-9619 For TTY/TDD users: 1-800-24-NOKIA

(1-800-246-6542)

IMINARY

Nokia Products Ltd. 601 Westney Road South Ajax, Ontario L1S 4N7

Tel:1-888-22-NOKIA (1-888-226-6542)

Website: www.nokia.ca

Page 18

•ACCESSIBILITY SOLUTIONS

Nokia is committed to making mobile phones easy to use for all users including those with disabilities. For more information, visit www.nokiaaccessibility.com

For more information on accessibility enhancements, see also “Phone adapter HDA-10 accessibility enhancement” on page 125.

FCC DRAFT

IMINARY

Page 19

Getting started

3 Getting started

To begin using your Nokia 7610 phone, a SIM card must be inserted into the phone. You may also use a memory card with the phone. Before you attempt to insert or remove a SIM card or memory card, review the following procedures to become familiar with the inside of your phone.

“Nokia 7610 phone at a glance” on page v identifies other features on your phone.

•REMOVE THE BACK COVER

Note: Before removing the phone cover,

always switch off the power and disconnect the phone from the charger or any other device. Always store and use the phone with the cover attached.

1 To open the cover , with the back of the phone

facing you, press the locking catch in the direction of the arrow (1).

2 While pressing the locking catch, slide the back cover off of the phone (2). 3 Remove the battery from the phone if necessary.

•INSERT THE SIM CARD

Keep all SIM cards out of the reach of small children. For availability and

FCC DRAFT

information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator , or other vendor . For a better understanding of your SIM card, see “SIM card” on page 119.

1 Locate the SIM card slot. 2 Open the SIM card holder by doing the

following:

• Slide the holder in the open direction

(1).

• Lift the holder up (2).

3 Position the bottom of the SIM card in the

top of the holder, and carefully slide the SIM card down into the holder, until the bottom of the card fits in the base of the slot.

IMINARY

SIM card holde

SIM card slot

Page 20

Make sure that the bevelled corner on the SIM card is at the top of the holder and that the gold-colored contact area on the card is facing the inside of the phone.

4 Secure the SIM card by doing the

following:

• Fold the SIM card holder back

down into the phone (1).

• Slide the holder into the closed position (2) until it firmly snaps into place.

bevelled corner

•INSERT THE MEMORY CARD

The Nokia 7610 phone uses a reduced size multimedia card (RS-MMC). Only use RS-MMCs with this device. For more information on the memory card adapter, see “Attach and remove the memory card adapter” on page 88.

Other memory cards, such as secure digital (SD) cards, do not fit in the memory card slot and are not compatible with this device. Attempts to use a noncompatible memory card may damage the memory card as well as the phone, and data stored on the noncompatible card may be corrupted. See “Memory card” on page 87 for further information.

Keep all memory cards out of the reach of small children. See “Remove the back cover” on page 7 for details on removing the phone cover.

1 Locate the memory card slot. 2 Insert the top of the memory card under

FCC DRAFT

the hood at the right side of the slot and carefully slide the memory card to the right until it fits in the slot.

Make sure that the bevelled corner on the memory card is facing toward the bottom right side of the phone and that the gold-colored contact area on the card is facing downward.

3 Press the memory card into place.

Memory card slot

IMINARY

bevelled corner

Page 21

•INSERT THE BATTERY

Warning: Use only batteries

approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

1 Align the gold-colored contacts of the

battery with the corresponding connectors on the phone, and push the opposite end of the battery until it snaps into place.

2 Slide the cover back onto the phone. You w ill hear it click into place.

•CHARGE THE BATTERY

Warning: Use only chargers approved by Nokia for use with this particular

model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from ACP-12.

1 Connect the charger to an ac wall outlet. 2 Connect the power cord from the charger to

the base of the phone. (You will hear it click into place.)

FCC DRAFT

The battery indicator bar starts scrolling. Note that you can use the phone while charging. When the battery is fully charged, the bar stops scrolling.

3 Disconnect the charger from the ac outlet and from the phone.

See "Battery information" on page 123. See also “Other compatible Nokia enhancements” on page 124 for a list of other compatible chargers.

IMINARY

Getting started

Page 22

•SWITCH THE PHONE ON OR OFF

Press and hold the Power key. After it is switched on, the phone goes through

various start-up stages while it is loading software. It may be more than thirty seconds before the phone is ready for use.

•ATTACH THE WRIST STRAP

You can attach the wrist strap at the top left corner or bottom right corner of the phone. Thread the strap through the holder and tighten it.

Note: Only connect the strap to one fixture at a time. Use only Nokia approved enhancements.

•TIPS ON EFFICIENT OPERATION

Your phone has an internal antenna on the back of the phone above the camera lens.

Note: As with any other radio transmitting

FCC DRAFT

device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the phone optimizes the antenna performance and the battery life.

IMINARY

•IF THE PHONE REQUESTS A PIN CODE

The PIN code is usually supplied with the SIM card.

Page 23

Getting started

Key in the code (displayed as ****), and press OK. For more information on PIN codes, see “Security” on page 69.

•IF THE PHONE REQUESTS A LOCK CODE

Key in the lock code (displayed as *****), and press OK. The factory setting for the lock code is 12345. For more information on security codes, see “Security” on page 69.

•SET THE TIME AND DATE

If you are prompted to enter the time and date when you turn your phone on, use the number keys 0–9 to key in the current time and then the date. Press OK to accept the settings. See also “Date and time” on page 69.

•MAKE A CALL

1 In the standby mode, key in the phone number, including the area code. 2 If you make a mistake, press the Clear key to clear numbers. 3 Press the Send key and wait for the answer. 4 Press the End key to finish the call or to cancel the call attempt.

•STANDBY MODE

FCC DRAFT

Indicators are shown when the phone is ready for use, with no characters keyed in. In this state, the phone is in the standby mode.

The graduated bar (A) shows the signal strength of the cellular network at your current location. The higher the bar, the stronger the signal. The antenna symbol is replaced with the GPRS symbol when the GPRS connection has been set to When available and a connection is available in the network or in the current cell. See "GPRS" on page 68.

IMINARY

Page 24

The area to the right of the signal bar (B) shows an analog or a digital clock. See "Date and time" on page 69.

The area above the date (C) indicates in which cellular network the phone is currently being used.

The graduated bar (D) shows the battery charge level. The higher the bar, the more power left in the battery.

The navigation bar (E) shows the currently active profile. If the selected profile is Normal, the current date is displayed instead of the profile name.

Current shortcuts (F) are assigned to the Left and Right sel ectio n keys. The background image (G) may be any image you select in the standby mode. See

"Themes" on page 81. Your phone has a screen saver. If there are no actions for five minutes, the display

is cleared and a screen saver becomes visible. To deactivate the screen saver, press any key. Y ou can also modify the screen saver display and the amount of time that elapses before the screen saver starts. See “Themes” on page 81 and “Standby mode” on page 64.

•ICONS

Several icons may be displayed while the phone is in the standby mode. The icons are related to activity, data connections, enhancements, or voice volume.

Activity indicators

One or more of the following icons may be shown when the phone is in the standby mode:

FCC DRAFT

You have received new messages to Inbox in Messaging. If the indicator is blinking, the phone memory is low, and you must delete some data. See "Memory low" on page 119.

You have received one or more voice messages. See "Call voice mail" on page 18.

There are messages waiting to be sent in Outbox. See "Outbox" on page 57.

The ringing type has been set to Silent,message alert tone toOff, and IM alert tone to Off in the currently active profile. See "Profiles" on page 80.

The phone keypad is locked. To unlock, press the Left selection key and then the * key.

IMINARY

Page 25

Getting started

You have an active alarm. See "Clock" on page86. See "Calendar" on page 33.

A Bluetooth connection is active. All call forwarding is turned on.

Indicates that all calls to the phone are forwarded to voice mail. See "Call forwarding (network service)" on page 21. If you have two phone lines, the forward indicator for the first line is and for the second line . See “Line in use (network service)” on page 65.

You can make calls using phone line 2 only (network service). See "Line in use (network service)" on page 65.

Data connection indicators

When an application is establishing a data connection, one of the indicators below blinks in the standby mode. When an indicator is shown continuously, the connection is active.

Data call GPRS connection. The GPRS symbol is shown instead of the antenna

symbol when there is an active GPRS connection, when there are multiple GPRS connections, and for when the GPRS connection is put on hold during voice calls.

Bluetooth connection USB connection

FCC DRAFT

IMINARY

Enhancement indicators

A headset is connected A loopset is connected

Voice volume indicators

Earpiece mode Loudspeaker mode

Page 26

•MENU

Press the Menu key to display the main menu. In the menu, you can access all the applications in your phone.

Menu options are Open, List view or Grid view, Move, Move to folder, New folder,

Rename, App. downloads, Memory details, Help, and Exit.

Move in the menu

Use the scroll key as follows to navigate the menu:

• Scroll up by pressing the scroll key up (1).

• Scroll down by pressing the scroll key

down (2).

• Scroll left by pressing the scroll key left

(3).

• Scroll right by pressing the scroll key right

(4).

• Press the center of the scroll key to open a selected application or folder (5).

Close applications

Backstep by pressing Back or Exit as many times as needed to return to the standby mode, or select Options > Exit.

If you press the End key, the phone returns to the standby mode and the application is left open in the background. Pressing the End key will always end a

FCC DRAFT

call, even if another application is active and displayed. When you switch the phone off correctly, using the Power key, the phone will

attempt to save any unsaved data and close any applications that are still open. Hence the process may take a short time.

Rearrange the menu

You can rearrange the menu icons as required. You can place more rarely used applications in folders and move applications that you use more often from a folder to the main menu. You can also create new folders.

1 Scroll to the item you want to move, and select Options > Move.

A check mark is placed beside the application. 2 Scroll to where you want the applicat ion, and select OK. To move an item to a folder or from a folder to the menu, see “Common actions for

all applications” on page 15.

IMINARY

Page 27

Getting started

Switch between applications

If you have several applications open and want to switch from one application to another, press and hold the Menu key. The application switching window opens showing a list of applications that are currently open. Scroll to an application and press the middle of the scroll key to go to it.

If memory is getting low, the phone may close some applications. The phone saves any unsaved data before an application is closed.

•OPTIONS LISTS

Options lists tell you which commands are available in different views and situations. The available commands change depending on the view you are in. In some situations, when you press the middle of the scroll key, a shorter options list appears listing the main commands available in the view.

• COMMON ACTIONS FOR ALL APPLICATIONS

Open items for viewing—When you are viewing a list of files or folders and want

to open an item, scroll to the item and press the middle of the scroll key, or select

Options > Open.

Edit items—To change the contents of an item, open it for viewing and select

Options > Edit. Use the scroll key to scroll through all fields of the item.

FCC DRAFT

Rename items—To give an item a new name, scroll to the file or folder and select

Options > Rename.

Remove, delete items—Scroll to the item and select Options > Delete, or press the

Clear key. To delete many items at a time, you need to mark them.

Mark an item—There are several ways to select items in a list.

• To select one item at a time, scroll to it, and select Options > Mark/Unmark >

Mark; or press the Edit key and the scroll key at the same time. A check mark

is placed next to the item.

• To select all items in the list, select Options > Mark/Unmark > Mark all.

Mark multiple items—Press and hold the Edit key; then press the scroll key down

or up. As the selection moves, a check mark is placed next to the items. To end the selection, stop scrolling with the scroll key, and release the Edit key.

• After you have selected all the items you want, move or delete them by

IMINARY

Page 28

selecting Options > Move to folder or Delete.

• To unmark an item, scroll to it, and select Options > Mark/Unmark > Unmark;

or press the Edit key and the scroll key at the same time.

Create folders—To create a new folder, select Options > New folder. You are asked

to give a name to the folder (up to 35 letters).

Move items to a folder—To move items to a folder or between folders, select

Options > Move to folder (not shown if there are no folders available). When you

select Move to folder , a list of available folders opens and you can also see the root level of the application (for moving an item out of a folder). Select the location to which you want to move the item, and select OK.

Send items—To send items to compatible devices, scroll to the item that you want

to send, and select Options > Send > Via multimedia or Via Bluetooth.

• If you select to send the item in a multimedia message, an editor opens. Press

the middle of the scroll key to select the recipients from the contacts directory

or write the phone number or e-mail address of the recipient in the To field.

Add text or sound and select Options > Send. See "Write and send messages"

on page 50.

• If you select Via Bluetooth, see “Send data by Bluetooth connection” on

page 112.

•SEARCH FOR ITEMS

You can search for a name, file, folder, or shortcut by using the search field. In some situations the search field is not visible automatically, but you can activate it by selecting Options > Find or just by starting to key in letters.

FCC DRAFT

1 To search for an item, start to key in text in the search field.

The phone immediately starts to search for matches and moves the selection

to the best match. 2 To make the search more accurate, key in more letters and the selection moves

to the item that best matches the letters. 3 When the correct item is found, press the middle of the scroll key to open it.

IMINARY

•VOLUME CONTROL

When you have an active call or are listening to a sound, scroll right or left to increase or decrease the volume level, respectively. See also “Voice volume indicators” on page 13.

Page 29

Getting started

•LOUDSPEAKER

The loudspeaker allows you to speak and listen to the phone from a short distance without having to hold the phone to your ear . The loudspeaker can be used during a call, with sound and video applications, and when viewing multimedia messages. Sound and video applications use the loudspeaker by default. Using the loudspeaker makes it easier to use other applications while in a call.

To activate the loudspeaker during an active call, press Loudsp. or select Options > Activate loudsp. A tone is played,

is shown in the navigation bar, and the volume indicator

changes. The loudspeaker cannot be activated when a headset is connected to the phone. To turn off the loudspeaker during an active call, press Handset or select Options >

Activate handset.

Important:Do not hold the phone near your ear when the loudspeaker is in use because the volume may be extremely loud.

•KEYGUARD

Use the keyguard (keypad lock) feature to help prevent accidental key presses. In the standby mode, press the Left selection key; then quickly press the * key.

When the keys are locked, appears on the display. Press the Left selection key; then quickly press the * key to unlock the keys.

When keyguard is on, press the Send key to answer a call. During a call, the phone

FCC DRAFT

can be operated in the normal way. When the keyguard is on, calls still may be possible to the official emergency

number programmed into your phone. Enter the emergency number (for example,

911) and press the Send key.

IMINARY

Page 30

4 Your phone

•MAKE A CALL

1 In the standby mode, key in the phone number, including the area code.

Scroll right or left to move the cursor. Press the

Clear key to remove a number.

For international calls, press the * key twice for

the international prefix (the + character

replaces the international access code), and key

in the country code, the area code without 0,

and the phone number.

Calls described here as international may be

made between regions of the same nation.

2 Press the Send key to call the number. 3 Press the End key to end the call (or to cancel

the call attempt). Pressing the End key will always end a call, even if another application is active

and displayed. You can make a call using your voice so that you do not need to key in the number.

See "Voice dialing" on page 26.

Use Contacts to make a call

FCC DRAFT

1 To open the contacts directory, select Menu > Contacts, or press the middle

of the scroll key in the standby mode. 2 To find a contact, scroll to the desired name, or key in the first letters of the

name. The search field opens automatically and matching contacts are listed. 3 Press the Send key to start the call.

If the contact has more than one phone number, scroll to the number and

press the Send key to start the call.

Call voice mail

Voice mail (network service) is an answering service where callers can leave voice messages.

• To call voice mail, press the 1 key and the Send key in the standby mode, or

press and hold the 1 key.

• If the phone asks for the voice mail number, key it in and press OK. Obtain this

IMINARY

Page 31

Your phone

number from your service provider.

To forward calls to your voice mail, see “Call forwarding (network service)” on page 21.

Each phone line may have its own voice mail number. See "Line in use (network service)" on page 65.

CHANGE THE VOICE MAIL NUMBER

To change the phone number of your voice mail, select Menu > Tools > Voice mail > Options > Change number. Key in the number (obtained from your service provider), and press OK.

1-touch dialing

To view the 1-touch dialing grid, select Menu > Tools > 1-touch. To assign a phone number to one of the 1-touch dialing keys (2–9), select

Options > Assign. See also “Assign 1-touch dialing keys” on page 27. To call the number in the standby mode, press the corresponding 1-touch dialing key and the Send key.

To turn the 1-touch dialing function on, select Menu > Settings > Call > 1-touch dialing > On. If the 1-touch dialing function is set to On, press and hold the corresponding 1-touch dialing key until the call is started.

Make a conference call (network service)

Conference calling is a network service that allows you to make a conference call with up to six participants, depending on network limitations.

1 Make a call to the first participant.

FCC DRAFT

2 To make a call to a new participant, select

Options > New call.

3 Key in or search the memory for the phone

number of the participant and press OK. The first call is automatically put on hold.

4 When the new call has been answered, select

Options > Confer ence to join the first

participant in the conference call. 5 To end the active conference call, press the End key. To add a new person to the call, repeat step 2.

IMINARY

Page 32

To have a private conversation with one of the participants, select Options > Conference > Pr ivate. Scroll to the desired participant and press Private. The conference call is put on hold in your phone, and the other participants can still continue talking with each other while you have a private discussion with one participant only. Once you have finished the private conversation, select Options > Conference to return to the conference call.

To drop one participant from the conference call, select Options > Conference > Drop participant; then scroll to the participant and press Drop.

The quickest way to make a new call is to dial the number, and press the Send key to start the call. The existing call is automatically put on hold.

•ANSWER A CALL

To answer an incoming call, press the Send key. To end the call, press the End key. If you do not want to answer a call, press the

End key. When a call comes in, press Silence to quickly mute

the ringing tone.

Options during a call

Press Options during a call for some of the following options: Answer, Decline, Swap, Activate loudsp. or

Activate handset, End active call, End all calls, Hold

or Unhold, Mute or Unmute, Conference, Transfer, Send touch tones, and Help.

FCC DRAFT

You might not have all of these options. Contact your service provider for more details.

Loudspeaker and Handset may be displayed as options for the Right selection key and can be used as shortcuts for Activate handsfree and Deactivate handsfree, respectively.

Swap is used to switch between the active call and the call on hold. Transfer is used to connect an incoming call or a call on hold with an active call

and to disconnect yourself from both calls. Send touch tones is used to send DTMF tone sequences, for example, passwords or

bank account numbers: 1 Key in th e digits with the 0–9 keys.

Each keystroke generates a DTMF tone, which is transmitted while the call is active. Press the * key repeatedly to produce *, p (inserts a pause of

IMINARY

Page 33

Your phone

approximately two seconds before, or between DTMF characters), and w (if you

use this character, the remaining sequence is not sent until you press the

Send key again during the call). Press the # key to produce #.

2 To send the tone, press OK.

Call waiting (network service)

If you have activated the call waiting service, the network will notify you of a new incoming call while you have a call in progress.

1 During a call, press the Send key to answer the waiting call.

The first call is put on hold.

2 To switch between the two calls, press Swap. 3 To end the active call, press the End key, or to end both calls at the same time,

select Options > End all calls.

Call forwarding (network service)

When this network service is activated, you can direct your incoming calls to another number, for example, to your voice mail number. For details, contact your service provider.

Select Menu > Settings > Call forwarding.

• Select one of the forwarding options, for example, select If busy to forward

voice calls when your number is busy or when you reject incoming calls.

• Select Options > Activate to turn the forwarding setting on, Cancel to turn

the forwarding setting off, or Check status to check whether the forwarding

is activated or not.

FCC DRAFT

• To cancel all active forwarding, select Options > Cancel all forwarding.

See also “Activity indicators” on page 12. Call restriction and call forwarding cannot be active at the same time. See "Call

restriction (network service)" on page 72.

IMINARY

•CALL LOG

Select Menu > Log. You can use the log to monitor phone calls, text messages, data calls, and packet

data connections registered by the phone. Filter the log to view just one type of event and create new contact cards based on the log information.

Page 34

Connections to your remote mailbox, multimedia messaging center, or browser pages are shown as data calls or packet data connections in the general communications log.

Recent calls log

Select Menu > Log > Recent calls. The phone registers the phone numbers of missed, received, and dialed calls, and

the date and time of your calls. The phone registers missed and received calls only if the network supports these functions and if the phone is switched on and is within the network service area.

Options in the Missed, Received, and Dialed views are Call, Create message, Use

number, Delete, Clear list, Add to Contacts, Help, and Exit.

MISSED CALLS AND RECEIVED CALLS

To view a list of the last 20 phone numbers received but not answered (network service), select Log > Recent calls > Missed calls.

If you receive indication of missed calls while in the standby mode, press Show to access the list of numbers. To call back, scroll to the number or name you want to call and press the Send key.

To view a list of the 20 numbers for calls most recently accepted (network service), select Log > Recent calls > Received calls.

DIALED NUMBERS

To view the 20 phone numbers for the most recently called or attempted, select Log > Recent calls >

FCC DRAFT

Dialed numbers.

ERASE RECENT CALL LISTS

To clear all recent call lists, select Options > Clear recent calls in the Recent calls main view.

To clear one of the call logs, open the log you want to erase and select Options > Clear list.

To clear an individual event, open a log, scroll to the event, and press the Clear key. Confirm by pressing Yes.

IMINARY

Call timers

Select Menu > Log > Call timers to view the duration of your incoming and outgoing calls.

Note: The actual time invoiced for calls by your service provider may vary, depending upon network features, rounding-off for billing, and so forth.

Page 35

Your phone

To erase call duration timers, select Options > Clear timers. For this you need the lock code. See "Security" on page 69.

Note:Some timers may be reset during service or software upgrades.

GPRS data counter

Select Menu > Log > GPRS counter. The GPRS data counter allows you to check the amount of data sent and received

during packet data (GPRS) connections. This may be helpful if your service provider charges for GPRS connections based on the amount of data sent and received. The actual amount invoiced by your service provider may vary depending on rounding, taxes, or other factors.

View the general log

Select Menu > Log and scroll right. In the general log, the sender or recipient name,

phone number, name of the service provider, or access point is displayed for each communication event.

Events such as a text message sent in more than one part and packet data connections, are logged as one communication event.

FILTER THE GENERAL LOG

1 Select Options > Filter. A list of filters opens.

FCC DRAFT

2 Scroll to a filter and press Select.

ERASE THE CONTENTS OF THE GENERAL LOG

To erase all the log contents, recent calls log, and messaging delivery reports permanently, select Options > Clear log. Confirm by pressing Yes.

PACKET DATA COUNTER AND CONNECTION TIMER

To view how much data, measured in kilobytes, has been transferred and how long a certain GPRS connection has lasted, scroll to an incoming or outgoing event labeled GPRS and select Options > View details.

IMINARY

Log settings

Select Menu > Log > Options > Settings to open the list of settings. Log duration—The log events remain in the phone memory for a set number of days

after which they are automatically erased to free memory.

Page 36

If you select No log, all the log contents, recent calls log, and messaging delivery reports are permanently deleted.

Show call duration—Set to Yes or No. See "Call timers" on page 22.

FCC DRAFT

IMINARY

Page 37

Personal information

5 Personal information

•CONTACTS

To open Contacts, press the middle of the scroll key in the standby mode, or select Menu > Contacts.

In Contacts, you can store and manage contact information, such as names, phone numbers, and addresses.

You can also add a personal ringing tone, voice tag, or a thumbnail image to a contact card. You can create contact groups, which allow you to send text messages or e-mail to many recipients with compatible devices at the same time.

Options in Contacts are Open, Call, Create message, New contact, Open

conversation, Edit, Delete, Duplicate, Add to group, Belongs to groups, Mark/ Unmark, Copy to SIM direct., Go to web address, Send, Contacts info, SIM directory, Service numbers, Settings, Help, and Exit.

Create and edit contact cards

1 Open Contacts and select Options > New contact. An empty contact card

opens. 2 Fill in the fields you want and press Done.

The contact card is saved in the phone memory and closed, after which you

can see it in the contacts directory. To edit contact cards, see “Common actions for all applications” on page 15.

Options when editing a contact card are Add thumbnail or Remove thumbnail, Add

FCC DRAFT

detail, Delete detail, Edit label, Help, and Exit.

To delete contact cards, in the contacts directory, scroll to the contact card and select Options > Delete.

To attach a small thumbnail image to a contact card, open a contact card, and select Options > Edit > Options > Add thumbnail. The thumbnail image is also shown when the contact is calling you. After you attach a thumbnail image to a contact card, select Add thumbnail to replace the image with a different thumbnail or Remove thumbnail to remove the thumbnail from the contact card.

To assign default numbers and addresses to a contact card, open the contact card, and select Options > Defaults. A pop-up window opens, listing the different options.

IMINARY

Page 38

Copy between SIM card and phone memory

To copy names and numbers from a SIM card to your phone, open Contacts, select Options > SIM directory, scroll to the names you want to copy, and select Options > Copy to Contacts.

If you want to copy a phone, fax, or pager number from Contacts to your SIM card, select Contacts, open a contact card, scroll to the number, and select Options >

Copy to SIM direct.

Add a ringing tone for a contact card or group

You can set a ringing tone for each contact card and group. When that contact or group member calls you, the phone plays the chosen ringing tone (if the caller’s telephone number is sent with the call and your phone recognizes it).

1 Press the middle of the scroll key to open a contact card; or scroll right to go

to groups, and select a contact group.

2 Select Options > Ringing tone.

A list of ringing tones opens.

3 Use the scroll key to select the ringing tone you wish to use for the contact or

group, and press Select. 4 To remove the ringing tone, select Default tone from the list of ringing tones. For an individual contact, the phone will always use the ringing tone that was

assigned last. If you first change a group ringing tone and then the ringing tone of a single contact that belongs to that group, the ringing tone of the single contact is used.

FCC DRAFT

Voice dialing

You can make a phone call by saying a voice tag that has been added to a contact card. Any spoken words can be a voice tag.

When recording, hold the phone at a short distance away from your mouth. After the starting tone, say clearly the word, or words, you want to record as a voice tag.

REQUIREMENTS FOR VOICE TAGS

Before using voice dialing, note the following:

• Voice tags are not language-dependent. They are dependent on the speaker's

voice.

• You must say the name exactly as you said it when you recorded it.

• Voice tags are sensitive to background noise. Record voice tags, and use them

in a quiet environment.

• Very short names are not accepted. Use long names, and avoid similar names

IMINARY

Page 39

Personal information

for different numbers.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialing in all circumstances.

ADD A VOICE TAG TO A PHONE NUMBER

Voice tags can only be added to phone numbers stored in phone memory . See "Copy between SIM card and phone memory" on page 26.

1 In Contacts, scroll to the contact to which you want to add a voice tag, and

press the middle of the scroll key to open the contact card.

2 Scroll to the number to which you want to add the voice tag, and select

Options > Add voice tag .

3 Press Start to record a voice tag. 4 After the starting tone, clearly say the words you want to use as a voice tag.

After recording, the phone plays the recorded tag and Playing voice tag is displayed.

When the voice tag has been successfully saved, Voice tag saved is displayed and a beep sounds. A symbol can be seen next to the number in the contact card.

To replay, erase, or change a voice tag, scroll to the item that has a voice tag (indicated by ), and select Options > Voice tag > Playback, Delete, or Change.

MAKE A CALL USING A VOICE TAG

1 In the standby mode, press and hold the Right selection key.

A short tone is played and Speak now is displayed.

FCC DRAFT

2 When you make a call by using a voice tag, hold the phone at a short distance

from your mouth, and say the voice tag clearly. The phone plays the original voice tag, displays the name and number, and

dials the number of the recognized voice tag.

If the phone plays the wrong voice tag or if you want to retry voice dialing, press Retry.

Voice dialing should not be used when a data call or a GPRS connection is active because the voice call will interrupt the connection.

IMINARY

Assign 1-touch dialing keys

1-touch dialing is a quick way to call frequently used numbers. You can assign 1-touch dialing keys to eight phone numbers. Number 1 is reserved for voice mail.

Page 40

1 Open the contact card for which you want a 1-touch dialing key, and scroll to

the phone number you want to add to 1-touch dialing. 2 Select Options > Assign 1-touch no.

The 1-touch dialing grid opens, showing you the numbers from 2–9. 3 Scroll to a number and press Assign. When you return to the contact

information view, the 1-touch dialing icon is displayed next to the number. 4 To call the contact by 1-touch dialing, go to the standby mode, and press the

1-touch dialing key and Send key, or press and hold the 1-touch dialing key.

View subscribed contacts

Select Menu > Contacts, and scroll to the second tab to open the subscribed contacts list. This list allows you to view presence data, including availability and IM status, for all subscribed contacts. See also “Presence (network service)” on page 29 and “Instant messaging (IM) (network service)” on page 94.

Options in the subscribed contacts view are Open, Call, Create message, Switch

tracking on, Open conversation, Unsubscribe, Subscribe new, Mark/Unmark, My presence, Help, and Exit. If you are not logged in to the presence service, you will

see only a few of these options.

Manage contact groups

SelectMenu > Contacts, and scroll to the third tab to open the contact groups list. Options in the groups list view are Open,New group,Delete,Rename,Ringing tone,

Contacts info, Settings, Help, and Exit.

CREATE CONTACT GROUPS

FCC DRAFT

1 In the contacts directory, scroll to the groups tab. 2 Select Options > New group. 3 Write a name for the group, or use the default name Group 1, and press OK.

ADD MEMBERS TO A GROUP

1 In the contacts directory, scroll to the contact you want to add to a group, and

select Options > Add to group.

A list of available groups opens. 2 Select a group, and press the middle of the scroll key to add the contact.

IMINARY

Page 41

Personal information

•PRESENCE (NETWORK SERVICE)

Select Menu > Presence. Options in Presence are Open, My availability, Viewers, Update presence, Login or

Logout, Settings, Help, and Exit.

Use the presence service to inform others when, where, and how you want to be contacted. Presence allows you to view and create a dynamic profile and share information or control services. Presence information is visible to other users of the service and can include your availability, whether you prefer for people to call or send messages, where you are, and what you are doing.

Before you can use the presence service, you must choose a service provider and save the settings of that service. You may receive the settings in a special text message, called a smart message, from the service provider that offers the presence service. See "Smart messages" on page 54. For more information, contact your service provider.

Select Options > Login or Logout to log in and out of the presence service. The presence application on your phone allows you to change your own published

information and manage who is authorized to see your presence. To view the presence information of others, you must use the Contacts application. See "View subscribed contacts" on page 28.

Change your availability

Select Options > My availability and one of the following:

Available—You are available for people to call or

FCC DRAFT

send you messages, for example, your phone is set to

Normal profile. See "Profiles" on page 80. Busy—You may be available for people to call or

send you messages, for example, your phone is in

Meeting profile. Not available—You are not available for people to

call or send you messages, for example, your phone is in Silent profile.

IMINARY

Change your presence information

You can set up public, private, and blocked presence information and define who can view your information.

Page 42

PUBLIC PRESENCE

Select Menu > Presence > Public pres. to change your public presence information. This information is available to anyone you have not blocked. Select

Options and one of the following: My availability—Select Available, Busy, or Not available. Viewers—Open the Current viewers list to see the names, phone numbers, or user

IDs of the viewers whom you do not allow to view your private presence messages, but who are currently viewing your public presence. You can scroll to a viewer, press Options, and select from the following options:

• Add to private list—Allow the viewer to also see your private presence.

• Block—Prevent the viewer from seeing your presence information.

• Add to contacts—Add the viewer to your contacts directory.

• Refresh lists—Update the viewer lists. This option is only available when you

are not logged in to the presence service.

Login or Logout—Connect to or disconnect from the presence service. Update presence—Update your presence information to the presence service. Settings—Manage the publishing of your presence information.

PRIVATE PRESENCE

Select Menu > Presence > Private pres. to change your private presence information. This information is only available to those whom you have authorized to view your private information. Select Options and one of the following:

My availability—Select Available, Busy, or Not available. My presence msg.—Write a text message of up to 40 characters to describe your

FCC DRAFT

current availability. My presence logo—Add a logo to your availability information. Logo files are

stored in Gallery. See "Gallery" on page 42. Viewers—Open your private presence viewers list to see the names, phone numbers,

or user IDs of the viewers whom you allow to view your private presence messages. You can scroll to a viewer, press Options, and select from the following options:

• Add new—Add a new viewer manually or from your contacts directory. You

can only select a contact who has a user ID in the contact card.

• Block—Prevent the viewer from seeing your presence information.

• Add to contacts—Add the viewer to your contacts directory.

• Remove from list—Remove the viewer from the private list. This option is

available also when you mark several viewers in the list. If the list is empty, the

option is not available. You can also scroll to a viewer and press the Clear key

IMINARY

Page 43

Personal information

to prevent that viewer from seeing your private presence messages.

• View details—Show the user ID information of the viewer.

• Refresh lists—Update the viewer lists. This option is only available when you

are not logged in to the presence service.

Update presence—Update your presence information to the presence service. Login or Logout—Connect to or disconnect from the presence service. Settings—Manage the publishing of your presence.

BLOCKED PRESENCE

Select Menu > Presence > Blocked pres. to change your blocked presence information. Blocked viewers will see a screen containing no personal details. Select Options and one of the following:

Viewers—Open your blocked viewers list to see the names, phone numbers, or user IDs of the viewers whom you have blocked from seeing your public or private presence information. You can scroll to a viewer, press Options, and select from the following options:

• Unblock—Remove the viewer from the blocked list. You can also unblock a

viewer by scrolling to the viewer and pressing the Clear key.

• Add to private list—Allow the viewer to also see your private presence.

• Add new—Add a new blocked viewer manually or from your contacts directory.

You can only select a contact who has a user ID in the contact card.

• Add to contacts—Add the viewer to your contacts directory.

• View details—Show the user ID information of the viewer.

• Refresh lists—Connect to the presence service to update the viewer lists. This

FCC DRAFT

option is only available when you are not logged in to the presence service.

Update presence—Update your presence information to the presence service. Login or Logout—Connect to or disconnect from the presence service. Settings—Manage the publishing of your presence.

IMINARY

Update your information

Select Menu > Presence > Options > Update presence. This option is only available when you are logged in to the presence service and

have changed your information in the Private Presence or Public Presence view and have not updated that presence information yet.

Page 44

Presence settings

Select Options > Settings from the Presence main menu, and select from the following:

Show presence to—Select from the following:

• Private & public—Both public and private presence is published.

• Private viewers—Only private viewers can see your presence information.

• Public viewers—Both public and private viewers see your public presence

information.

• No one—Your presence information is not published.

Sync. with Profiles—Defines whether your published presence information is linked to your phone profile settings. When you choose an option other than Off, be sure to define your profile presence information as well (see “Create and customize profiles” on page 80). Select from the following:

• Off—Your presence information is not changed, even if you change your phone

profile setting.

• Presen. msg. only—Both Availability and Private message are changed when

you change your phone profile setting.

• Availability only—Private message is not changed when you change your

profile.

• Private msg. only—Availability is not changed when you change your profile

setting.

Server settings—Opens the Server settings menu in the IM feature. Select Presence login type from this menu to designate when you want to log in to the

FCC DRAFT

presence service. See “IM settings” on page 95 for further information on the login types.

IMINARY

•POSITIONING (NETWORK SERVICE)

Select Menu > Positioning. Positioning allows the network to detect the position of your phone. By enabling

or disabling Positioning, you choose when your position information is provided to the network.

To enable positioning in your phone, select Settings > Positioning > On.

Page 45

Personal information

When you receive a position request, a message is displayed showing the service that is making the request. Press Accept to allow your position information to be sent, or press Reject to deny the request.

Position request messages are logged in the Recv.

requests list. To view them, select Menu > Positioning > Recv. requests. The icon beside each

request indicates whether the request is new, rejected, or accepted. If you want to see details of a request, scroll to the request and press the middle of the scroll key. If you want to clear the Recv. requests list, select Options > Clear list.

•CALENDAR

In Calendar, you can keep track of your appointments, meetings, birthdays, anniversaries, and other events. You can also set a calendar alarm to remind you of upcoming events.

Create entries

1 Select Menu > Calendar. 2 Select Options > New entry and select from the following options:

Meeting—Creates an appointment that has a specific date and time. Memo—Creates a general entry for a day.

FCC DRAFT

Anniversary—Creates a reminder for birthdays or special dates. Anniversary entries are repeated every year.

3 Fill in the fields. Use the scroll key to move between fields.

Subject or Occasion—Write a description of the event. Location—Indicates the place of a meeting (optional). Start time, End time, Start date, and End date. Alarm—Select On to display the Alarm time and Alarm date fields. Repeat—Press the middle of the scroll key to change the entry to be repeating.

Shown with in the day view. Repeat until—Set an ending date for the repeated entry, for example, the

ending date of a weekly course you are taking. This option is shown only if you have selected to repeat the event.

Synchronization:

IMINARY

Page 46

• Private—After synchronization the calendar entry can be seen only by you

and it will not be shown to others, even if they have online access to view the calendar.

• Public—The calendar entry is shown to others who have access to view

your calendar online.

• None—The calendar entry will not be copied when you synchronize your

calendar. 4 To save the entry, press Done. When editing or deleting a repeated entry, choose how you want the changes to

take effect: All occurrences—all repeated entries are changed, or This entry only— only the current entry will be changed.

Calendar views

Press the # key in the month, week, or day views to automatically highlight today’s date.

To key in a calendar entry, press any number key (1–0) in any calendar view. A meeting entry is opened and the characters you keyed in are added to the Subject field.

To go to a certain date, select Options > Go to date. Write the date, and press OK. Icons in the day view are —Memo and —Anniversary. Synchronization icons in the week and month views are red for private

synchronization, blue for public synchronization, pink for no synchronization, and black for more than one synchronization entry in a day.

Calendar settings

FCC DRAFT

Select Options > Settings and select one of the following options: Calendar alarm tone—Select a personalized alarm tone, or no tone at all. Default view—Select the view that is shown first when you open Calendar. Week starts on—Change the starting day of the week. If you change the settings

so that the week starts on a day other than Sunday, the week numbers will not be shown.

Week view title—Change the title of the week view to be the week number or the week dates.

IMINARY

Clear calendar memory

To remove more than one event at a time, go to the month view, and sele ct Options > Delete entry and one of the following:

Page 47

Personal information

Before date—Delete all calendar entries that take place before a certain date. Enter the date before which all calendar entries will be deleted.

All entries—Delete all calendar entries.

•TO-DO

In the To-do list you can keep a list of tasks that you need to do. The to-do list uses shared memory. See "Shared memory" on page 3.

1 Select Menu > To-do. 2 To start entering a to-do note, press any number key (1–0).

The editor opens and the cursor blinks after the letters you have entered in the Subject field.

3 Finish entering the task in the Subject field. 4 Scroll to the Due date field, and key in a date. 5 To set a priority for the task, scroll to the Priority field, and select High,

Normal, or Low.

6 To save the to-do note, press Done.

If you remove all characters from the Subject field and press Done, the note

will be deleted, even if you are editing a previously saved note. To open a to-do note, scroll to it and press the middle of the scroll key. To delete a to-do note, scroll to it and select Options > Delete; or press the

Clear key, and select Yes to confirm. To mark a to-do note as completed, scroll to it and select Options > Mark as done.

FCC DRAFT

To restore a to-do note, select Options > Mark as not done.

IMINARY

• COPY CONTENT FROM COMPATIBLE NOKIA PHONES

You can move calendar , contacts, and to-do data from compatible Nokia phones to your Nokia 7610 phone using your PC and the PC Suite Nokia Content Co p ier application. Instructions for using the application can be found in the help function of PC Suite on the CD-ROM.

Page 48

6 Multimedia

•CAMERA

You can use the camera to take pictures and record videos while on the move. The images are automatically saved in Gallery, where you can rename them and organize them in folders. You can also send images and video recordings in a multimedia message, as an e-mail attachment, or by Bluetooth connection. The camera produces JPEG images, and video clips are recorded in the 3GPP file format with the .3gp file extension.

Take pictures

1 Press Camera in the standby mode, or select Menu > Camera, and scroll left

to make sure you are on the Image tab. The camera opens, and you can see the viewfinder and the cropping lines,

which show you the image area to be captured. You can also see the image counter, which shows you how many images, depending on the selected picture quality, fit in the memory of your phone or memory card, if you use one.

Options before taking a picture are Capture, New,Activate night mode or

Deact. night mode, Self-timer, Go to Gallery, Settings, Help, and Exit.

2 Scroll up to zoom in on your subject before taking the picture; scroll down to

zoom out again. The zoom indicator to the right of the display shows the zoom level.

FCC DRAFT

3 To take a picture, press the middle of the scroll key.

Do not move the phone before the camera application starts to save the image. The image is saved automatically in Gallery. See "Gallery" on page 42.

The resolution of a zoomed picture is lower than that of a non-zoomed picture, but the image remains the same size. You may notice the difference in image quality if viewed on a PC, for example. If camera images look smudgy, check that the camera lens protection window is clean. See "Care and maintenance" on page 125.

The camera goes into battery saving mode if there have been no key presses within a minute. To continue taking pictures, press the middle of the scroll key.

OPTIONS AFTER CAPTURING AN IMAGE

Options after a picture has been taken are New, Delete, Send, Set as wallpaper,

Rename image, Go to Gallery, Settings, Help, and Exit.

If you do not want to save the image, select Options > Delete.

IMINARY

Page 49

Multimedia

To return to the viewfinder to take a new picture, press the middle of the scroll key. You can insert an image into a contact card. See "Create and edit contact cards"

on page 25.

SELF-TIMER

To include yourself in the picture, use the self-timer to delay the taking of a picture.

1 Select Options > Self-timer. 2 Select the delay 10 seconds, 20 seconds, or 30 seconds. 3 Press Activate.

The camera takes the picture after the selected delay has elapsed.

IMAGES AND MEMORY CONSUMPTION

Your phone has approximately 8 MB of free memory for images, contact information, calendar, messages, and so on. See "Shared memory" on page 3. Images taken using the high-quality setting and those taken in night mode take up the most memory.

By using a memory card with your phone you can increase the number of images you can store. To see how much memory is available on your phone and memory card, see “View memory consumption” on page 76.

The following table shows approximately how many images would fit in 1 MB of memory, depending on image type and quality

Image quality

Image type Basic Normal High

FCC DRAFT

Standard 55 22 15 Night 502518

IMINARY

Record videos

1 Press Camera in the standby mode, or select Menu > Camera, and scroll right

to move to the Video tab. Options before recording a video are Record, New, Activate night mode or

Deact. night mode, Mute, Go to Gallery, Settings, Help, and Exit.

2 Press the middle of the scroll key to start recording.

• To pause recording at any time, press Pause. Press Continue to resume

recording.

Page 50

• Scroll up to zoom in on your subject before or during recording;

scroll down to zoom out again.

3 Press Stop to stop recording. The video clip is saved to either phone memory or the memory card, depending on

the Memory in use setting. See "Camera and video settings" on page 38. To immediately play the video clip you just recorded, select Opti ons > Pl ay. To play previously saved video clips, go to Gallery. See "Gallery" on page 42. Options after you have recorded a video are New, Play, Delete, Send, Rename, Go

to Gallery, Settings, Help, and Exit.

Camera and video settings

Select Menu > Camera > Options > Settings to adjust the settings for still image captures and video recording. Select the following options:

Image—Adjust the settings for still images:

• Image quality—High, Normal, and Basic. The better the image quality, the

more memory the image consumes. See "Images and memory consumption" on page 37.

• Default image name—By default, Camera names images in the Image.jpg

format. Default image name allows you to set a name for the images stored.

• Memory in use—Select whether you want to save your images in phone

memory or on the memory card, if you use one.

Video—Adjust the settings for recording videos:

• Length—Available recording time is displayed above the top right corner of the

viewfinder. Select one of the following video length options:

FCC DRAFT

• Maximum—Recorded video length is restricted by available memory.

Recordings can last up to 10 minutes, depending on available memory.

• Short—Restricts video length to optimize it for MMS sending.

• Video resolution—Select 128x96 or 176x144.

• Default video name—Define a default name. For example, if you set Holiday

as the default video clip name, the video recorder will name all video clips Holiday(001), Holiday(002), and so on, until you change the setting again.

• Memory in use—Select whether you want to save your videos in phone

memory or on the memory card, if you use one.

IMINARY

Page 51

•VIEW IMAGES

Pictures taken with the camera are stored as images in Gallery. See "Gallery" on page 42.

Select Menu > Gallery > Images, and select an image. Press the middle of the scroll key to start the image viewer and display the image.

In the images thumbnail view:

1 Scroll right or left to move between the phone and memory card. 2 To browse the list of images, scroll up and down. 3 Press the middle of the scroll key to open an image. When the image is open,

you can see the name of the image.

When viewing an image, scroll right or left to go to the next or previous image in the current folder.

Options when viewing an image are Send, Set as wallpaper, Rotate, Zoom in, Zoom

out, Full screen, Delete, Rename, View details, Add to ’Go to’, Help, and Exit.

You can view animated GIF files in the same way as other images.

Zoom on a saved image

1 Select Options > Zoom in or Zoom out.

You can see the zooming ratio at the top of the display. See "Keyboard shortcuts" on page 39.

2 Press Back to return to the initial view.

The zooming ratio is not stored permanently.

FCC DRAFT

If you zoom in on GIF animations while they are playing, the animation will freeze until normal zoom is resumed, when play will continue.

FULL SCREEN

When you select Options > Full screen, the panes around the image are removed so that you can see more of the image. Press the Right selection key to return to the initial view.

MOVE THE FOCUS

When you are zooming an image, use the scroll key to move the focus to the left, right, up, or down, so that you can take a closer look at one part of the image, for example, its upper right corner.

Keyboard shortcuts

1 key—Rot ate image 90 degrees counterclockwise.

IMINARY

Multimedia

Page 52

3 key—Rotate image 90 degrees clockwise. 5 key—Zoom in. 0 key—Zoom out. * key—Change between full screen and normal view. Scroll key—Scroll up, down, left, right.

When you rotate an image, the rotation status is not stored permanently.

•REALPLAYER

Select Menu > RealPlayer. With RealPlayer, you can play local media files stored in the phone memory or

memory card, or stream media files over the air from a streaming link. The streaming link can be activated during a browsing session or stored in the phone memory or memory card.

Media files are video, music, or audio clips. Files with the extensions .3gp, .amr, .mp4, .rm, and .ram are supported by RealPlayer.

RealPlayer does not support all file formats or all the variations of a file format. For example, RealPlayer will attempt to open all .mp4 files. However, some .mp4 files may include content that is not compliant with 3GPP standards and, therefore, is not supported by this phone. In this case, the operation might fail and result in partial playback or in an error message.

Play media files

Options in RealPlayer when a clip is playing are Play, Pause, Continue, Stop, Mute,

FCC DRAFT

Unmute, Clip details, Settings, Help, and Exit.

To play a media file, select Menu > RealPlayer > Options > Open and one of the following:

Most recent clips—Play one of the last 6 files played

in RealPlayer. Saved clip—Scroll to a file in phone memory or on

memory card, and press the middle of the scroll key to play the file.

Mem. card sound clips—Create a track list from all sound files on the memory card. When you create a track list this way, the first song in the list automatically begins playing.

IMINARY

Page 53

STREAM CONTENT OVER THE AIR

• Select a streaming link saved in Gallery. Before your live content begins

streaming, your phone will connect to the site and load the file.

• Open the link to a file in the browser.

To stream live content, you must first configure your default access point. See "Access points" on page 66. For the default access point, some service providers will require you to use an access point defined in your phone. Other service providers allow you to use a WAP access point. Contact your service provider for more information.

In RealPlayer, you can only open an rtsp:// URL address. You cannot open an http:// URL address. However, RealPlayer will recognize an http link to a .ram file since a .ram file is a text file containing an rtsp link.

SHORTCUTS DURING PLAY

When a media file is playing, use the scroll key to seek (move quickly through the media file), and to mute the sound, as follows:

Scroll up and hold to seek forward, or scroll down and hold to seek backward through the media file.

Scroll left and hold until the indicator is displayed to mute the sound. Scroll right and hold until you see the indicator to turn on the sound.

Change settings

Select Options > Settings > Video, Audio, or Connection. Scroll right or left to move between the different setting tabs for Video, Audio,

and Connection, and select the settings you would like to modify.

FCC DRAFT

IMINARY

•MOVIE DIRECTOR

Multimedia

Select Menu > Movie director. Use Movie director to create edited video clips that may contain video, sound, and

text. Editing is carried out automatically according to the style that you select. The style determines the transitions and visual effects that are used in the video clip.

OpenMovie director and scroll right or left to move between the tab and the

tab. In the tab, you can select the following options: Quick muvee—Create video clips suitable to be sent by multimedia message. You

can select several video clips and the style you want to apply to them. The duration of the Quick muvee video clip is typically less than 10 seconds.

Page 54

Custom muvee—Select video clips and apply a style, music, and message; set the duration; and preview the video clip before saving. When you scroll through the list, the options become available:

• Select video—Select the source file or files you want to use. Select Mark/

Unmark, Play, or Capture.

• Select style—Select a style from the list. Styles determine the effects and

message caption. Each style is associated with default music and message text.

• Select music—Select a music clip from the list.

• Select message—Add a caption to the beginning and end of the video clip. You

can enter a message or select one from the template. You can edit the default message text.

• Create muvee—Set the duration for the video clip. Select Multimedia message

to create a video size suitable to be sent by MMS, Same as music to create a video of the same duration as the selected music clip, or User defined to enter the video duration manually.

After the video preview is prepared the Preview muvee view opens, where you can Play,Recreate (to make a new variation of the video clip), and Save the new video clip.

Style downloads—Download and install new styles. Settings—Select the setting you want to chan ge:

• Memory in use—Select Phone memory or Memory card.

• Resolution—Select High, Low or Automatic.

• Default muvee name—Enter a default name for your video clips.

FCC DRAFT

The tab contains a list of video clips that you can Play, Send, Rename, and

Delete.

IMINARY

•GALLERY

Select Menu > Gallery. Options in Gallery are Open (folder or item), Send, Delete, Create new, Move to

folder,Copy to folder,New folder, Mark/Unmark, Edit, Rename, Gallery downloads, Image uploader, View details, Add to ’Go to’, Settings, Help, and Exit.

Use Gallery to store and organize your images, sound clips, video clips, and streaming links.

Open Gallery to see a list of the folders in the phone memory. Scroll right to see the folders on the memory card, if you use one.

Page 55

Multimedia

Scroll to Images, Sound clips, Video clips, or another folder that you have created, and press the middle of the scroll key to open it.

In the open folder you can see:

• An icon depicting the type of each file in the folder, or in the case of an image,

a small thumbnail picture giving a preview of the image

• The name of the file

• The date and time a file was saved, or the size of the file

• Subfolders, if present

You can browse, open, and create folders, and you can mark, copy, and move items to folders. See "Common actions for all applications" on page 15.

Open files

Select any file and press the middle of the scroll key to open it. Each file will open in its corresponding application as follows:

• Images files open in the image viewer. See "View images" on page39.

• Sound clips open and play in the music player.

• Video clips and streaming links open and play in RealPlayer. See "RealPlayer"

on page 40.

• Subfolders open to display contents.

Default images folders

Select Gallery > Images. The Images folder is the default location where your phone saves images taken with the camera. Within the Images folder, there are additional default folders called Picture msgs., Presence logos, and Wallapers.

FCC DRAFT

PICTURE MESSAGES FOLDER

Select Gallery > Images > Picture msgs. Use this folder to store pictures sent to you in picture messages. To save a picture

that you have received in a picture message, select Messaging > Inbox, open the message, and select Options > Save picture.

Options in the picture messages folder are Open, Send, Delete, Mark/Unmark,

Rename, View details, Help, and Exit.

PRESENCE LOGOS FOLDER

Select Gallery > Images > Presence logos. Use this folder to store logos for Presence. See "Presence (network service)" on

page 29.

IMINARY

Page 56

WALLPAPERS FOLDER

Select Gallery > Images > Wallpapers. Use this folder to store pictures that you want to use as background images.

Download files

To download files into Gallery using the browser, select Options > Gallery downloads > Graphic downloads, Video downloads, or Tone downloads. The

browser opens and you can choose a bookmark for the site from which to download. See "Bookmarks" on page 105.

To download files, you must configure your default access point. See "Access points" on page 66.

Once items have been downloaded, the browser closes and the phone returns to Gallery.

Upload images to an image server (network service)

You can send your pictures to an image server to allow others to share your pictures online. Before you can upload images, you must set up the image server; you can get the specific settings from your service provider:

1 Select Settings > Image servers, and press the Left selection key. 2 Fill in the details for each field. (See “Access points” on page 66.) 3 Press the Right selection key.

To upload images:

1 Select Options > Image uploader. 2 To begin an upload, mark the images that you want to upload, and select

FCC DRAFT

Upload.

3 Enter a name for the folder on the image server in which the images will be

stored, and press the Left selection key.

Track lists for audio files

You can create a track list to play audio files on your phone. Select Menu > Gallery > Create new > Track list, and follow the screen prompts to select sound

clips for the track list. To add multiple tracks at one time, press the Edit key and the scroll key simultaneously to place a checkmark beside each track you want to add, and select Options > Select marked items.

To play a track list, select Menu > Gallery and locate the track list in phone memory or on the memory card. Scroll to the track list and press the middle of the scroll key to begin playing it.

IMINARY

Page 57

Multimedia

To modify a track list, locate the track list in Gallery, and select Options > Edit track list > Options > Add sound clip.

To delete clips, open the track list, scroll to a clip, and select Options > Delete. Options in the track list are Pause, Edit track list, Clip details, Settings, Help, and

Exit.

FCC DRAFT

IMINARY

Page 58

7 Messaging

Note: This function can only be used if it is supported by

your network operator or service provider. Only devices that offer compatible picture message, multimedia message, or e-mail features can receive and display these messages. Devices that do not have multimedia

features may receive details of a link to a web page. Select Menu > Messaging. In Messaging you can create, send, receive, view, edit, and organize:

• Text messages

• Multimedia messages (MMS)

• E-mail messages

Options in the Messaging main view are Create message, Connect (shown if you have defined settings for the mailbox) or Disconnect (shown if there is an active connection to the mailbox), SIM messages, Cell broadcast, Service command,

Settings, Help, and Exit.

When you open Messaging, you can see the New message selection and a list of default folders:

Inbox—Contains received messages except e-mail and cell broadcast messages. E-mail messages are stored in Mailbox. You can read cell broadcast messages by selecting Options > Cell broadcast.

My folders—For organizing your messages into folders.

FCC DRAFT

Mailbox—When you open this folder, you can either connect to your remote mailbox to retrieve your new e-mail messages, or you can view your previously retrieved e-mail messages without logging in to the e-mail server. After you have defined settings for a new mailbox, the name given to that mailbox will replace Mailbox in the main view. See "E-mail" on page 60.

Drafts—Stores drafts of messages that have not been sent. Sent—Stores the last 15 messages that have been sent. To change the

number of messages to be saved, see “Other settings” on page 62. Messages or data that have been sent by a Bluetooth connection are

not saved in the Draft or Sent folders. Outbox—Temporary storage place for messages waiting to be sent.

IMINARY

Page 59

Reports (network service)—You can request that the network send you a delivery report of the text messages, smart messages, and multimedia messages you have sent. To turn on delivery report reception, go to the

Messaging main menu, select Options > Settings > Text message or Multimedia message, and select Receive report > Yes.

It might not be possible to receive a delivery report of a multimedia message that has been sent to an e-mail address.

Note:When sending messages, your device may display the words Message Sent. This is an indication that the message has been sent by your device to the message center number programmed into your device. This is not an indication that the message has been received at the intended destination. For more details about messaging services, check with your service provider.

Before you create a multimedia message, write an e-mail, or connect to your remote mailbox, you must have the correct connection settings in place. See "Write and send messages" on page 50. See "Settings needed for multimedia messaging" on page 51.

•WRITE TEXT

You can key in text in two different ways, using the method traditionally used in mobile phones or another method called predictive text input.

Traditional text input

FCC DRAFT

The indicator is shown on the top right of the display when you are writing text using traditional text input.

Press a number key (1–9), repeatedly until the desired character appears. Note that there are more characters available for a number key than are printed on the key.

Icons: and indicate the selected case. means that the first letter of the next word is written in upper case, and all other letters will automatically be written in lower case. indicates number mode.

To insert a number, press and hold the corresponding number key . To switch between letter and number mode, press and hold the # key. If the next letter is located on the same key as the present one, wait until the cursor

appears (or scroll right to end the time-out period), and then key in the letter. If you make a mistake, press the Clear key to remove a character. Press and hold

the Clear key to clear more than one character.

IMINARY

Messaging

Page 60

The most common punctuation marks are available under the 1 key. Press the 1 key repeatedly to reach the desired punctuation mark. You can also press the * key to open a list of special characters. Use the scroll key to move through the list and press Select to select a character.

To insert a space, press the 0 key. To move the cursor to the next line, press the 0 key three times.

To switch between upper and lower case, press the # key.

Predictive text input

To activate predictive text input, press the Edit key and select Predictive text on, or press the # key twice quickly when writing text. This will activate predictive text input for all editors in the phone. The indicator is shown at the top of the display.

1 Write the desired word by pressing the keys 2–9. Press each key only once for

one letter. The word changes after every key press. For example, to write Nokia when the English

dictionary is selected, press the following keys:

6 key for N 6 key for o 5 key for k 4 key for i 2 key for a

The word suggestion changes after each key press.

FCC DRAFT

2 When you have finished the word, check that it is correct.

If the word is correct, you can confirm it by scrolling right or by pressing the 0 key to insert a space. The underlining disappears and you can begin to write a new word.

If the word is not correct, you have the following options:

• Press the * key repeatedly to view the matching words the dictionary has

found one by one.

• Press the Edit key, and select Predictive text > Matches to view a list of

matching words. Scroll to the word you want to use and press the middle

of the scroll key to select it. If the ? character is shown after the word, the word you intended to write is not in the dictionary. To add a word to the dictionary, press Spell, key in the word (up to 32 letters) using traditional text input, and press OK. The word is added to the dictionary. When the dictionary becomes full, a new word

IMINARY

Page 61

Messaging

replaces the oldest added word. To remove the ? and clear characters one by one from the word, press the

Clear key.

TIPS ON PREDICTIVE TEXT INPUT

Erase a character—Press the Clear key. Press and hold the Clear key to clear more

than one character. Change between the different character cases—Press the # key to change

between the character cases Abc (), abc (), and ABC (). Note that if you press the # key twice quickly the predictive text input is turned off.

Insert a number in letter mode—Press and hold the desired number key, or press the Edit key and select number mode, key in the numbers you want, and press OK.

Insert symbols and punctuation marks:

• The most common symbols and punctuation marks are available under the

1 key. Press the 1 key repeatedly to find the desired entry.

• Press and hold the * key to open a list of special characters. Use the scroll key

to scroll through the list, and press Select to select a character; or press the Edit key, and select Insert symbol.

The predictive text input will try to guess which commonly used punctuation mark (.,?!‘) is needed. The order and availability of the punctuation marks depend on the language of the dictionary.

Choose from multiple entries—Press the *key repeatedly to view the matching words the dictionary has found one by one.

Choose predictive text options—When a word has been entered with predictive text on, you can press the Edit key, select Predictive text, and select one of the

FCC DRAFT

following:

• Matches—View a list of words that correspond to your key presses. Scroll to

the desired word and press the middle of the scroll key.

• Insert word—Add a word (up to 32 letters) to the dictionary by using

traditional text input. When the dictionary becomes full, a new word replaces the oldest added word.

• Edit word—Open a view where you can edit the word. This option is available

only if the word is active (underlined).

• Off—Turn off predictive text input for all editors in the phone.

WRITE COMPOUND WORDS

Write the first half of a compound word and confirm it by scrolling right. Write the last part of the compound word and complete the compound word by pressing the 0 key to add a space.

IMINARY

Page 62

Copy and paste text

If you want to copy text to the clipboard, the following is the easiest method: 1 To select letters and words, press and hold the Edit key.

At the same time, scroll right or left. As the selection moves, text is highlighted.

To select lines of text, press and hold the Edit key. At the same time scroll down or up.

2 To end the selection, release the scroll key while holding the Edit key. 3 To copy the text to the clipboard, while still holding the Edit key, press Copy,

or release the Edit key, and press it once to open a list of editing commands, for example, Copy or Cut.

If you want to remove the selected text from the document, press the Clear key.

4 To paste the text into a document, press and hold the Edit key, and press Paste;

or press the Edit key once, and select Paste.

•WRITE AND SEND MESSAGES

Before you can create a multimedia message, write an e-mail message, or connect to your remote mailbox, you must have the correct con ne ct i on settings in place. See “Write and send messages” on page 50 and “Settings needed for multimedia messaging” on page 51.

Options in the text message editor are Send, Add recipient, Insert, Delete, Check

FCC DRAFT

names, Message details, Sending options, Help, and Exit.

1 Select New message, and select one of the following options:

Text message—Create and send a text message.

To send a picture message, select Options > Insert > Picture. Each picture message is made up of several text messages. Therefore, sending one picture message may cost more than sending one text message.

Multimedia message—Create and send a multimedia message (MMS). Each picture message is made up o fseveral text messages. Therefore, sending

one picture message may cost more than sending one text message. Copyright protections may prevent some images, ringtones, and other content

from being copied, modified, transferred, or forwarded. E-mail—Create and send an e-mail. If you have not set up your e-mail

account, you will be prompted to do so.

IMINARY

Page 63

Messaging

2 Press the middle of the scroll key to select recipients from the contacts

directory, or write the phone number or e-mail address of the recipient in the To field if you are sending an MMS or e-mail to the recipient. Press the # key to add a semicolon (;) to separate each recipient.

3 Scroll down to move to the message field. 4 Write the message.

To add an existing media object to a multimedia message, select Options > Insert object > Image, Sound clip, or Video clip; then select an item .

To insert a new media object into a multimedia message, select Options > Insert new > Image, Sound clip, Video clip, or Slide; then create the new

item. When sound has been added, the icon is shown in the navigation bar. If

you select Insert new > Sound clip, the voice recorder opens and you can record a new sound. The sound is automatically saved and a copy is inserted in the message.

5 To send the message, select Options > Send, or press the Send key.

SETTINGS NEEDED FOR MULTIMEDIA MESSAGING

You may receive the settings as a smart message from your network operator or service provider. See "Smart messages" on page 54.

For availability of and subscription to data services, contact your network operator or service provider.

SelectMessaging > Options > Settings > Multimedia message > Access point in use and select the access point you created. See "Multimedia messages" on page 59.

FCC DRAFT

SETTINGS NEEDED FOR E-MAIL

Before you can send, receive, retrieve, reply to, and forward e-mail to a separate e-mail account, you must:

• Configure an Internet access point (IAP). See "Connection" on page 65.

• Define your e-mail settings. See "E-mail" on page 60.

Follow the instructions given by your remote mailbox and Internet service provider.

IMINARY

Page 64

•CREATE A MULTIMEDIA PRESENTATION

When you create a multimedia message, you can insert a presentation on one or more slides. The presentation displays the items in the multimedia message with transitions (wipes) between each slide.

1 Select Menu > Messaging > New message >

Multimedia message > Options > Create presentation.

Options in a presentation are Send, Full screen,

Insert, Edit text, Preview message, Remove, Backgrnd. settings, Effect settings, Help, and Exit.

2 Scroll to the template on which you want to base your presentation, and press

Select. You are not restricted to the number of slides/format in the template, it is just

a framework to get started.

3 Insert text, video clips, images, and sound clips onto the slides as with a

multimedia message.

4 Use the scroll key to navigate around the elements of a slide and to move from

one slide to another.

5 When you finish creating the presentation and composing the multimedia

message, select Options > Send to send the message.

FCC DRAFT

Background settings

Each of the following settings, when applied, affect the whole presentation:

Set colour—Choose a color for the background. Add image—Select an image from the Gallery. See "Gallery" on page 42. Remove image—Removes a previously added image, and returns to the template

default. Remove sound clip—Removes a previously added sound clip.

Effects settings

The effects settings allow a transition to be applied to an image or to a slide. For example, a slide wipe will give the appearance of the image, or slide, moving into the display. The effects settings, when applied, affect the whole presentation.

IMINARY

Page 65

View a presentation

When you receive a multimedia message that includes a presentation, select Play presentation. The presentation will open and start.

A multimedia message containing presentation content can still be viewed as a standard multimedia message.

Objects within the presentation may not start automatically. If, for example, a video does not play when the presentation starts, move to the video clip object and press the middle of the scroll key. All objects can be selected individually and opened.

•INBOX—RECEIVE MESSAGES

Options in Inbox are Open, Create message, Reply,Delete, Message

details, Move to folder, Mark/Unmark, Help, and Exit.

When there are unread messages in Inbox, the icon changes to . In Inbox, the message icons tell you what kind of a message it is. Here are some of

the icons that may appear:

An unread text message An unread smart message An unread multimedia message An unread service message

FCC DRAFT

Data received by Bluetooth connection An unknown message type

View multimedia objects

Options in Objects are Open, Save, Send, Call, and Exit. To see the available media objects in the multimedia message, open the message

and select Options > Objects. In Objects you can view files that have been included in the multimedia message. You can choose to save the file in your phone or to send it, for example, by Bluetooth connection to another compatible device.

Important: Multimedia message objects may contain viruses or be harmful to your device or PC. Do not open any attachment if you are not sure of the trustworthiness of the sender.

IMINARY

Messaging

Page 66

See "Certif. management" on page 71.

Smart messages

Your phone can receive many kinds of smart messages, text messages that contain data (also called over-the-air (OTA) messages). To open a received smart message, open Inbox, scroll to the smart message ( ), and press the middle of the scroll key.

Picture message—Saves the picture in the Picture messages folder in Gallery for later use, select Options > Save picture. If you receive a business card file that has a picture attached, the picture will be saved to Contacts as well.

Business card—Saves the contact information, select Options > Save busi ness card. If certificates or sound files are attached to business cards, they will not be

saved.

Ringing tone—Saves the ringing tone to Gallery, select Options > Save. Operator logo—Saves the logo, select Options > Save. The operator logo can now

be seen in the standby mode instead of the network operator’s own identification.

Calendar entry—Saves the entry to Calendar, select Options > Save to Calendar. Web message—Saves the bookmark, select Options > Save to bookmarks. The

bookmark is added to the Bookmarks list in browser services. If a message contains both browser access point settings and bookmarks, to save

the data select Options > Save all, or select Options > View details to view the bookmark and access point information separately. If you do not want to save all data, select a setting or bookmark, open the details, and select Options > Save to

Settings or Save to bookmarks, depending on what you are viewing. E-mail notification—Tells you how many new e-mails you have in your remote

FCC DRAFT

mailbox. An extended notification may list more detailed information such as subject, sender, attachments, and so on.

Wallet—You can receive payment cards, loyalty cards, access cards, address cards, RFIDs, and tickets.

In addition, you can receive a text message service number; voice mail number; profile settings for remote synchronization; access point settings for the browser, multimedia messaging, or e-mail; presence and IM settings; access point login script settings; or e-mail settings. To save the settings, select Options > Save to SMS sett., Save to Voice mail, Save to Settings, or Save to e-mail sett.

IMINARY

Service messages (network service)

Service messages can be, for example, notifications of news headlines, and they may contain a text message or address of a browser service. For availability and subscription, contact your service provider.

Page 67

Messaging

•MY FOLDERS

In My folders you can organize your messages into folders, create new folders, and rename and delete folders.

You can use Templates to create text templates for messages that you send often. To create a new template, select Options > New template.

•REMOTE MAILBOX (NETWORK SERVICE)

When you open this folder, you can connect to your remote mailbox to do the following:

• Retrieve new e-mail headings or messages.

• View your previously retrieved e-mail headings or messages without logging

in to the e-mail server.

If you select New message > E-mail in Messaging, and you have not set up your e-mail account, you will be prompted to do so. See "Write and send messages" on page 50.

When you create a new mailbox, the name you give to the mailbox automatically replaces Mailbox in Messaging. You can have up to six mailboxes.

Open the mailbox

When you open the mailbox, you can choose whether you want to view the previously retrieved e-mail messages and e-mail headings with or without

FCC DRAFT

connecting to the e-mail server. When you scroll to your mailbox and press the middle of the scroll key, Connect to

mailbox? appears. Select Yes to connect to your mailbox or No to view previously retrieved e-mail messages while not logged in to the e-mail server.

Another way to start a connection is to select Options > Connect.

Retrieve e-mail messages

If you are not logged in to the e-mail server, select Options > Connect to start a connection to a remote mailbox.

1 When you have an open connection to a remote mailbox, select Options >

Retrieve e-mail and one of the following:

• New—Retrieve all new e-mail messages to your phone.

• Selected—Retrieve only the e-mail messages that have been marked. Use

the Mark/Unmark > Mark or Unmark commands to select messages one

IMINARY

Page 68

by one. See "Common actions for all applications" on page 15.

• All—Retrieve all messages from the mailbox.

To cancel retrieving, press Cancel. After you have retrieved the e-mail messages, you can continue viewing them online.

2 Select Options > Disconnect to close the connection and view the messages

offline from the e-mail server.

3 To open an e-mail message, scroll to the e-mail you want to view and press

the middle of the scroll key. If the e-mail message has not been retrieved (arrow in the icon is pointing

outwards) and you are offline from the e-mail server and select Open, you will be asked if you want to retrieve this message from the mailbox.

To view e-mail attachments, open a message that has the attachment indicator and select Options > Attachments. In Attachments, yo u can retrieve, open, or save attachments, in supported formats. You can also send attachments by Bluetooth connection.

Important: E-mail attachments may contain viruses or otherwise be harmful to your device or PC. Do not open any attachment if you are not sure of the trustworthiness of the sender.

If your mailbox uses the IMAP4 protocol, you can decide whether to retrieve e-mail headings only, messages only, or messages and attachments. With the POP3 protocol, the options are e-mail headings only or messages and attachments. See "E-mail" on page 60.

Delete e-mail messages

To delete an e-mail from the phone while still retaining it in the remote mailbox,

FCC DRAFT

select Options > Delete > Phone only. The phone mirrors the e-mail headings in the remote mailbox. If you delete the

message content, the e-mail heading stays in your phone. If you want to remove the heading, delete the e-mail message from your remote mailbox first; then make a connection from your phone to the remote mailbox again to update the status.

To delete an e-mail from both the phone and the remote mailbox, select Options > Delete > Phone and server.

If you are not logged in to the e-mail server, the e-mail will be deleted from your phone. During the next connection to the remote mailbox, it will be automatically deleted from the remote mailbox. If you are using the POP3 protocol, messages marked to be deleted are removed only after you have closed the connection to the remote mailbox.

IMINARY

Page 69

UNDELETE MESSAGES WHEN OFFLINE FROM THE E-MAIL SERVER

To undelete an e-mail from both the phone and server, scroll to an e-mail that has been marked to be deleted during the next connection ( ), and select Options > Undelete.

Disconnect

When you are online, select Options > Disconnect to end the data call or GPRS connection to the remote mailbox.

•OUTBOX

Outbox is a temporary storage place for messages that are waiting to be sent. Status of the messages in Outbox are as follows:

Sending—A connection is being made and the message is being sent. Waiting or Queued—When there are two similar types of messages in Outbox, one

of them is waiting until the first one is sent. Resend at (time)—Sending has failed. The phone will try to send the message again

after a time-out period. Press Send if you want to restart the sending immediately. Deferred—You can set documents to be on hold while they are in Outbox. Scroll to

a message that is being sent, and select Options > Defer sending. Failed—The maximum number of sending attempts has been reached. If you were

trying to send a text message, open the message and check that the sending settings are correct.

FCC DRAFT

•VIEW MESSAGES ON A SIM CARD

Select Messaging > Options > SIM messages.

•CELL BROADCAST (NETWORK

IMINARY

SERVICE)

Select Messaging > Options > Cell broadcast. You may be able to receive messages on various topics, such as weather or traffic

conditions, from your service provider. For available topics and relevant topic numbers, contact your service provider. In the main view you can see:

• The status of the topic: for new, subscribed messages and for new ,

unsubscribed messages.

Messaging

Page 70

• The topic number, topic name, and whether it has been flagged ( ) for

follow-up. You will be notified when messages belonging to a flagged topic have arrived.

Options in Cell broadcast are Open,Subscribe or Unsubscribe, Hotmark or Remove

hotmark, Topic, Settings, Help, and Exit.

Note: A packet data (GPRS) connection may prevent cell broadcast reception. Contact your network operator for the correct GPRS settings. See "GPRS" on page 68.

•SERVICE COMMAND EDITOR

Select Messaging > Options > Service command. Key in and send service requests (also known as USSD commands) for network services to your service provider (for example, a request for activation commands).

•MESSAGING SETTINGS

Messaging settings have been divided into groups according to the different message types. Scroll to the settings you want to edit and press the middle of the scroll key.

Text messages

SelectMessaging > Options > Settings > Text message to open the following list of settings:

Message centers—Lists all the message centers that have been defined.

FCC DRAFT

Msg. center in use (message center in use)—Defines which message center is used for delivering text messages and smart messages such as picture messages.

Options when editing message center settings are Edit, New msg. center,Delete,

Help, and Exit.

Receive report (delivery report)—When this network service is set to Yes, the status of the sent message (Pending, Failed, or Delivered) is shown in the reports (network service).

Message validity—If the recipient of a message cannot be reached within the validity period, the message is removed from the message service center. Note that the network must support this feature. Maximum time is the maximum amount of time allowed by the network.

Message sent as—The options are Text, Fax, Paging, and E-mail. For further information, contact your network operator. Change this option only if you are sure that your message center is able to convert text messages into these other formats.

IMINARY

Page 71

Messaging

Preferred connection—You can send text messages over the normal GSM network or by GPRS, if supported by the network.

Reply via same ctr. (network service)—By setting this option to Yes, if the recipient replies to your message, the return message is sent using the same message service center number. Note that this may not work between all operators.

Multimedia messages

Select Messaging > Options > Settings > Multimedia message to open the following list of settings:

Access point in use—Select which access point is used as the preferred connection for the multimedia message center. See "Settings needed for multimedia messaging" on page 51.

If you receive multimedia message settings in a smart message and save them, the received settings are automatically used for the access point. See "Smart messages" on page 54.

Multimedia reception—Select from the following:

• Only in home net.—Receive multimedia messages only when you are in your

home network. When you are outside your home network, multimedia message reception is turned off.

• Always on—Allow your phone to receive multimedia messages.

• Off—Do not receive multimedia messages or advertisements at all.

If Only in home net. or Always on is selected, your phone can make an active data call or GPRS connection without your knowledge.

On receiving msg.—Select from the following:

FCC DRAFT

• Retr. immediately—The phone will try to retrieve multimedia messages

instantly. If there are messages with Deferred status, they will be retrieved as well.

• Defer retrieval—The multimedia messaging center will save the message to be

retrieved later. When you want to retrieve the message, set On receiving msg. to Retr. immediately.

• Reject message—Reject multimedia messages. The multimedia message

center will delete the messages.

Allow anon. messages—Select No, if you want to reject messages coming from an anonymous sender.

Receive ads—Define whether you want to allow reception of multimedia message advertisements or not.

IMINARY

Page 72

Receive report—Set to Yes if you want the status of the sent message (Pending, Failed, or Delivered) to be shown in the reports. Receiving a delivery report of a

multimedia message that has been sent to an e-mail address might not be possible. Deny report sending—Choose Yes if you do not want your phone to send delivery

reports of received multimedia messages. Message validity (network service)—If the recipient of a message cannot be

reached within the validity period, the message is removed from the multimedia message center. Maximum time is the maximum amount of time allowed by the network.

Image size—Define the size of the image in a multimedia message. The options are Small (up to 160x120 pixels) and Large (up to 640x480 pixels).

E-mail

SelectMessaging > Options > Settings > E-mail. Select Mailbox in use to choose which mailbox you want to use.

Select Mailboxes to open a list of mailboxes that have been defined. Options when editing Mailbox settings are Editing options, New ma ilbox , Delete,

Help, and Exit.

If no mailboxes have been defined, you will be prompted to do so. The following list of settings is shown (this information is available from your e-mail service provider):

Mailbox name—Write a descriptive name for the mailbox. Access point in use (must be defined)—The Internet Access Point (IAP) used for the

mailbox. Choose an IAP from the list. See "Connection" on page 65.

FCC DRAFT

My e-mail address (must be defined)—Write the e-mail address given to you by your service provider. The address must contain the @ character. Replies to your messages are sent to this address.

Outgoing mail server (must be defined)—Write the IP address or host name of the computer that sends your e-mail.

Send message (network service)—Define how e-mail is sent from your phone:

• Immediately—A connection to the mailbox is started immediately after you

have selected Send.

• During next conn.—E-mail is sent when you connect to your remote mailbox

the next time.

Send copy to self—Select Yes to save a copy of the e-mail to your remote mailbox and to the address defined in My e-mail address.

IMINARY

Page 73

Messaging

Include signature—Select Yes if you want to attach a signature to your e-mail messages and to start to write or edit your signature text.

User name—Write your user name, given to you by your service provider. Password—Write your password. If you leave this field blank, you will be prompted

for the password when you try to connect to your remote mailbox. Incoming mail server (must be defined)—Write the IP address or host name of the

computer that receives your e-mail. Mailbox type—Defines the e-mail protocol your remote mailbox service provider

recommends. The options are POP3 and IMAP4. This setting can be selected only once and cannot be changed if you have saved or exited from the mailbox settings.

Security—Used with the POP3, IMAP4, and SMTP protocols to secure the connection to the remote mailbox.

APOP secure login—Used with the POP3 protocol to encrypt the sending of passwords to the remote e-mail server. This option is only shown if POP3 is selected for Mailbox type.

Retrieve attachment—Retrieve e-mail with or without attachments. This option is only shown if the Mailbox type is set to IMAP4.

Retrieve headers—Limit the number of e-mail headers you want to retrieve to your phone. The options are All and User defined. Used with the IMAP4 protocol only.

Service messages

When you select Messaging > Options > Settings > Service message, the following list of settings opens:

Service messages—Choose whether or not you want to allow reception of service

FCC DRAFT

messages. Download messages—Choose if you want to receive service messages only from

authorized sources.

Cell broadcast (network service)

Check with your service provider about whether Cell broadcast is available and what the available topics and related topic numbers are. Select Messaging >

Options > Settings > Cell broadcast to change the settings: Reception—On or Off. Language—All allows you to receive cell broadcast messages in every possible

language. Selected allows you to choose in which languages you wish to receive cell broadcast messages. If the language you prefer is not in the list, select Other.

IMINARY

Page 74

Topic detection—If you receive a message that does not belong to any of the existing topics, select On to save the topic number automatically. The topic number is saved to the topic list and shown without a name. Select Off if you do not want to save new topic numbers automatically.

Other settings

Select Messaging > Options > Settings > Other to open the following list of settings:

Save sent messages—Choose if you want to save a copy of every text message, multimedia message, or e-mail that you have sent to the Sent folder.

No. of saved msgs.—Define how many sent messages will be saved to the Sent folder at a time. The default limit is 20 messages. When the limit is reached, the oldest message is deleted.

Memory in use—Define the memory store. Choices are phone memory or memory card, if one is used.

FCC DRAFT

IMINARY

Page 75

8 Settings

Select Menu > Settings. 1 Scroll to a setting group and press the middle of

the scroll key to open it.

2 Scroll to a setting you want to change and press

the middle of the scroll key to do the following:

• Switch between options if there are only

two (On/Off).

• Open a list of options or an editor.

• Open a slider view (scroll right or left to

increase or decrease the value,

respectively). You may be able to receive some settings from your service provider in a smart message, or some settings may already be preprogramed into the phone. See "Smart messages" on page 54.

•PHONE

Select Menu > Settings > Phone > General, Standby mode, or Display.

General

Phone language—You can change the language for the display texts in your phone. This change may also affect the format used for date and time and the separators

FCC DRAFT

used, for example, in calculations. If you select Automatic, the phone selects the language according to the information on your SIM card. After you have changed the display text language, you must restart the phone.

Note: Changing the settings for Phone language or Writing language affects every application in your phone and the change remains effective until you change these settings again.

Writing language—You can change the writing language of your phone. Changing the language affects the following features:

• The characters available when you press any key (1–9)

• The predictive text dictionary used

• The special characters that are available when you press the * and 1 keys

IMINARY

Settings

Page 76

Predictive text—Set predictive text input On or Off for all editors in the phone. Select a language for entering predictive text from the list available. You can also change this setting when you are in an editor. Press the Edit key, and select

Predictive text > On or Off. Welcome note or logo— The welcome note or logo is displayed briefly each time

you switch on the phone. Select Default if you want to use the default image or animation. Select Text to write a welcome note (up to 50 letters). Select Image to choose a photo or picture from Gallery.

Orig. phone settings—You can reset some of the settings to their original values. To do this, you need the lock code. See "Security" on page 69. After resetting the settings, the phone may take a longer time to power on. All documents and files that you have created are left as they are.

Standby mode

Left selection key and Right selection key—You can change the shortcuts that appear over the Left selection key and Right selection key in the standby mode. In addition to the applications, you can have the shortcut point to a function, for example, New message.

You can only have shortcuts to pre-installed applications and functions.

Display

Brightness—Adjust the slide bar between Dark and Bright. Screen saver timeout—The screen saver is activated when the screen saver

time-out period is over. When the screen saver is active, the display is cleared and you can see the screen saver bar.

FCC DRAFT

To deactivate the screen saver press any key.

IMINARY

•CALL

Select Menu > Settings > Call > Send my caller ID, Call waiting, Automatic redial, Summary after call, 1-touch dialing, Anykey answer, or Line in use.

Send my caller ID (network service)

This service allows you to set your phone number to be displayed (Yes) or hidden (No) from the person to whom you are calling. This option may also be set by your network operator or service provider when you make a subscription.

Page 77

Settings

Call waiting (network service)

The network will notify you of a new incoming call while you have a call in progress. Select Activate to request the network to activate call waiting, Cancel to request the network to deactivate call waiting, or Check status to check if the function is active or not.

Automatic redial

When this setting is activated, your phone will make a maximum of ten attempts to connect the call after an unsuccessful call attempt. Press the End key to stop automatic redialing.

Summary after call

Activate this setting if you want the phone to briefly display the approximate duration of the last call.

1-touch dialing

Select On, and the numbers assigned to the 1-touch dialing keys (2–9) can be dialed by pressing and holding the key. See "Assign 1-touch dialing keys" on page 27.

Anykey answer

Select On, and you can answer an incoming call by briefly pressing any key, except the Right selection key, the Power key, and the End key.

Line in use (network service)

FCC DRAFT

This setting is shown only if the SIM card supports two subscriber numbers, that is, two phone lines. Select which phone line (Line 1 or Line 2) you want to use for making calls and sending short messages. Calls on both lines can be answered regardless of the selected line.

You will not be able to make calls if you select Line 2 and have not subscribed to this network service.

To prevent line selection, select Line change > Disable if supported by your SIM card. To change this setting, you need the PIN2 code.

IMINARY

•CONNECTION

Select Menu > Settings > Connection > Access points, GPRS, Data call, or Configurations.

Page 78

Access points

An access point is the point where your phone connects to the mobile Internet by way of a data call or packet data connection. An access point can be provided, for example, by a commercial Internet service provider (ISP), service provider, or network operator.

Many service providers will require you to use an Internet access point (IAP) for your default access point. Other service providers allow you to use a browser access point. Contact your service provider for more information.

To define access point settings, select Menu > Settings > Connection > Access points. If you have not yet used your phone to make a WAP connection, you may need to contact your service provider for assistance with the first-time connection, or visit www.nokia.com/phonesettings

Start to fill in the following settings from the top because depending on what data connection you select in the Data bearer option only certain setting fields are available:

Connection name—Give a descriptive name for the connection. Data bearer—The options are GPRS and Data call. Depending on which data

connection you select, only certain setting fields are available. Fill in all fields marked with Must be defined, or with an asterisk. Other fields can be left empty, unless you have been instructed otherwise by your service provider.

To be able to use a data connection, the network operator or service provider must support this feature, and if necessary, activate it for your SIM card.

Access point name (for packet data only)—The access point name is needed to establish a connection to the GPRS network. You obtain the access point name

FCC DRAFT

from your network operator or service provider. Dial-up number (for Data call only)—The modem telephone number of the access

point. User name—Write a user name if required by the service provider. The user name

may be needed to make a data connection and is usually provided by the service provider. The user name is often case-sensitive.

Prompt password—If you must key in a new password every time you log on to a server or if you do not want to save your password to the phone, choose Yes.

Password—A password may be needed to make a data connection and is usually provided by the service provider. The password is often case-sensitive. When you are writing the password, the characters you enter are shown briefly and then changed to asterisks (*). The easiest way to enter numbers is to press and hold the digit you want to enter and then continue entering letters.

Authentication—Normal or Secure.

IMINARY

Page 79

Settings

Homepage—Depending on what you are setting up, write either:

• The service address.

• The address of the multimedia messaging center.

Data call type (for data call only)—Analog, ISDN v.110, or ISDN v.120 defines whether the phone uses an analog or digital connection. This setting depends on both your GSM network operator and Internet service provider (ISP) because some GSM networks do not support certain types of ISDN connections. For details, contact your ISP. If ISDN connections are available, they establish connections more quickly than analog methods.

Maximum data speed (for data call only)—The options are Automatic, 9600, or 14400, depending on what you have chosen in Data call type. This option allows

you to limit the maximum connection speed when GSM data is used. Higher data rates may cost more, depending on the service provider.

The speeds above represent the maximum speed at which your connection will operate. During the connection, the operating speed may be less, depending on network conditions.

ADVANCED ACCESS POINT SETTINGS

If you need to enter advanced settings, contact your Internet service provider. To access advanced access point settings, select Menu > Settings > Connection >

Access points, select the access point you want to modify, and select Options > Advanced settings. You can then define the following settings:

Phone IP address—The IP address of your phone Primary name server—The IP address of the primary DNS server Second. name server—The IP address of the secondary DNS server

FCC DRAFT

Proxy serv. address—The IP address of the proxy server Proxy port number—The port number of the proxy server

The following advanced settings options are shown if you have selected Data call as the Data bearer type in the general access point settings:

Use callback—This option allows a server to call you back once you have made the initial call. Contact your service provider to subscribe to this service.

The phone expects the callback call to use the same data call settings that were used in the callback-requesting call. The network must support that type of call in both directions, to and from the phone.

Callback type—The options are Use server no. or Use other no. Ask your service provider for the correct setting to use; it will depend on the service provider’s configuration.

IMINARY

Page 80

Callback number—Key in the phone data phone number that the dial back server uses. Usually, this number is the data call phone number of your phone.

Use PPP compression—When set to Yes, this option speeds up the data transfer, if supported by the remote PPP server. If you have problems with establishing a connection, try setting this to No. Contact your service provider for guidance.

Use login script—The options are Yes or No. Login script—Insert the login script. Modem initialization (modem initialization string)—Controls your phone using

modem AT commands. If required, enter characters specified by your service provider or Internet service provider.

GPRS

GPRS (general packet radio service) is a network service that allows mobile phones to be used for sending and receiving data over an IP-based network. GPRS is a data bearer that enables wireless access to data networks, such as the mobile Internet.

The applications that may use GPRS are multimedia, IM and text messaging, presence, streaming, browsing sessions, e-mail, data sync, Java™ application downloading, and the PC dial-up (such as Internet and e-mail).

To use GPRS technology, you must first do the following:

• Contact your service provider for availability and subscription to the GPRS service.

• Save the GPRS settings for each of the applications used over GPRS.

For information on pricing, contact your service provider. To define GPRS connection settings, select Menu > Settings > Connection >

FCC DRAFT

GPRS, and the following: GPRS connection—If you select When available and you are in a network that

supports packet data, the phone registers to the GPRS network. Also, starting an active packet data connection, for example, to send and receive e-mail, is quicker. If you select When needed, the phone will use a packet data connection only if you start an application or action that needs it. The GPRS connection can be closed after it is not used by any application.

If there is no GPRS coverage and you have chosen When available, the phone will periodically try to establish a packet data connection.

Access point—The access point name is needed when you want to use your phone as a packet data modem to your computer.

IMINARY

Page 81

Data call

Online time—This setting affects all access points using a GSM data call. If there are no actions, the data call is dropped automatically after a time-out period. Select User defined (in which case you enter a time) or Unlimited.

Configurations

When you open a message that contains configuration settings for your phone, the message is displayed in this viewer. If you do not have any configuration settings messages, this screen will be empty. To delete a message from this screen, press the Clear key.

Options in the configurations viewer are Save, Message details, and Move to folder.

•DATE AND TIME

Select Menu > Settings > Date and time. The Date and time settings allow you to define the date and time used in your

phone, as well as change the date and time format and separators. You can also change the following settings:

Clock type—Select Analog or Digital to change how the clock is displayed in the standby mode. See "Clock" on page 86.

Clock alarm tone—Changes the tone played when the clock reaches an alarm time. Auto time update—Allows the network to update time, date, and time zone

information to your phone (network service). For the auto time update setting to take effect, the phone needs to be restarted. Check any alarms because they may

FCC DRAFT

be affected by the auto time update.

GMT offset—Changes the time zone for the clock time. Daylight-saving—Sets daylight saving time on or off.

IMINARY

•SECURITY

Settings

Select Menu > Settings > Security > Phone and SIM or Certif. m anagement.

Phone and SIM

If your phone requests a security code, refer to the following explanations to determine what you should enter. If you forget or lose a PIN or PUK code or if you have not received such a code, contact your service provider.

Page 82

You can change the following codes: lock code, PIN code, and PIN2 code. These codes can only include the numbers from 0 to 9.

The PUK (personal unblocking key) code is required to change a blocked PIN code. The PUK2 code is required to change a blocked PIN2 code. If the codes are not supplied with the SIM card, contact your service provider for the codes. The PUK and PUK2 codes are 8 digits long.

Avoid using security codes similar to emergency numbers, such as 911, to prevent accidental dialing of the emergency number .

PIN code request—When the PIN code request is active, the code is requested each time the phone is switched on. Note that deactivating the PIN code request may not be allowed by some SIM cards.

PIN code (4 to 8 digits)—The PIN code protects your SIM card against unauthorized use. The PIN code is usually supplied with the SIM card.

After three consecutive incorrect PIN code entries, the PIN code is blocked. If the PIN code is blocked, you need to unblock the PIN code before you can use the SIM card again. See also the information below about the PUK code.

PIN2 code (4 to 8 digits)—The PIN2 code is supplied with some SIM cards and is required to access some functions, such as fixed dialing numbers (FDN).

Autolock period—You can set an autolock period, a time-out after which the phone is automatically locked and can be used only if the correct lock code is entered. Key in a number for the time-out in minutes, or select None to turn off the autolock period.

To unlock the phone, key in the lock code. When the phone is locked, calls may still be possible to the official emergency

FCC DRAFT

number programmed into your phone. Lock code (5 digits)—The lock code can be used to lock the phone and keypad to

avoid unauthorized use. The factory setting for the lock code is 12345. To prevent unauthorized use of your phone, change the lock code. Keep the new code secret and in a safe place separate from your phone. If you forget or lose the lock code, contact your service provider.

Lock if SIM changed—Select Yes if you want the phone to prompt for the lock code when an unknown, new SIM card is inserted into your phone. The phone maintains a list of SIM cards that are recognized as the owner’s cards.

Fixed dialing—You can restrict your outgoing calls to selected phone numbers, if supported by your SIM card. You need the PIN2 code for this function. When this function is active, you can only call those phone numbers that are included in the fixed dialing list or which begin with the same digits as a phone number on the list.

IMINARY

Page 83

Settings

Press the middle of the scroll key to set fixed dialing on. When fixed dialing is activated, calls still may be possible to the official emergency number programmed into your phone. To add new numbers to the fixed dialing list, select Options > New contact or Add from Contacts.

Options in fixed dialing are Open, Call, Activ. fixed dialing or Deact. fixed dialing,

New contact,Edit,Delete,Add to Contacts,Add from Contacts, Find, Mark/Unmark, Help, and Exit.

Closed user group (network service)—You can specify a group of people whom you can call and who can call you. For more information, contact your network operator or service provider. Select one of the following:

• Default—Activate the default group agreed on with the network operator.

• On—Use another group (you need to know the group index number).

• Off—Do not use closed user groups.

When calls are limited to closed user groups, calls still may be possible to the official emergency number programmed into your phone.

Confirm SIM services (network service)—Sets the phone to display confirmation messages when you are using a SIM card service.

Restore server—Reset your connection settings allowing you to receive new settings from your service provider.

Certif. management

Options in Certif. management are Certificate details,Delete, Trust settings, Mark/

Unmark, Help, and Exit.

In the certificate management main view, you can see a list of authority

FCC DRAFT

certificates that have been stored in your phone. Scroll right to see a list of personal certificates, if available.

Authority certificates are used by some browser services, such as banking services, for checking signatures or server certificates or other authority certificates.

Server certificates are used to improve security in the connection between the phone and the gateway. The phone receives the server certificate from the service provider before the connection is established, and its validity is checked using the authority certificates saved in the phone. Server certificates are not saved.

Server certificates may be needed, for example, when you want to do the following:

• Connect to an online bank or another site or remote server for actions that

involve transferring confidential information.

• Decrease the risk of viruses or other malicious software and be sure of the

authenticity of software when downloading and installing software.

IMINARY

Page 84

Important:Note that even if the use of certificates makes the risks involved in remote connections and software installation considerably smaller, they must be used correctly in order to benefit from increased security. The existence of a certificate does not offer any protection by itself; the certificate manager must contain correct, authentic, or trusted certificates for increased security to be available. Certificates have a restricted lifetime. If Expired certificate or Certificate not valid yet is shown even if the certificate should be valid, check that the current date and time in your device are correct.

Before changing any certificate settings, you must make sure that you really trust the owner of the certificate and that the certificate really belongs to the listed owner.

CHANGE THE TRUST SETTINGS OF AN AUTHORITY CERTIFICATE

Scroll to an authority certificate, and select Options > Trust settings. Depending on the certificate, a list of the applications that can use the selected certificate is shown. For example:

• Internet—The certificate is able to certify e-mail and imaging servers.

• App. installation—The certificate is able to certify the origin of new software.

•CALL RESTRICTION (NETWORK SERVICE)

Select Menu > Settings > Call restriction. Call restriction allows you to restrict outgoing and incoming calls with your phone.

FCC DRAFT

For this function, you need the restriction password, which you can obtain from your service provider.

Select Options, and choose one of the following:

Activate—Request the network to set call restriction on. Cancel—Set the selected call restriction off. Check status—Check if the calls are blocked or not. Edit restr. passw.—Change the restriction password. Cancel all restrict.—Cancel all active call restrictions.

You cannot restrict incoming calls while call forwarding or fixed dialing is active. See "Call forwarding (network service)" on page 21. See also “Security” on page 69. When calls are restricted, calls still may be possible to certain official emergency numbers.

IMINARY

Page 85

•NETWORK

Select Menu > Settings > Network > Operator selection or Cell info display.

Operator selection

Automatic—Set the phone to automatically search for and select one of the cellular networks available in your area.

Manual—Select the desired network manually from a list of networks. If the connection to the manually selected network is lost, the phone will sound an error tone and ask you to select a network again. The selected network must have a roaming agreement with your home network, that is, the operator whose SIM card is in your phone.

Cell info display

On or Off—Set the phone to indicate when it is used in a cellular network based on microcellular network (MCN) technology and to activate cell info reception (network service).

•ENHANCEMENT

Select Menu > Settings > Enhancement and one of the following: Enhancement in use—If you are using an enhancement such as a loopset, headset,

or TTY adapter, you must activate it by selecting Headset, Loopset, or TTY. If you have activated a loopset, the headset will use the same settings as the loopset.

FCC DRAFT

Headset, Loopset, TTY, and Handsfree—For each of these items, define the following settings:

• Default profile—Select the profile you want to be activated each time you

connect a certain enhancement to your phone. See "Change the profile" on page 80.

• Automatic answer—Set the phone to answer an incoming call automatically

after 5 seconds time when you connect a certain enhancement to your phone. If the incoming call alert is set to Beep once or Silent, automatic answer cannot be used, and you must answer the phone manually. This option is not available for TTY.

See also “Enhancement indicators” on page 13.

IMINARY

Settings

Page 86

9 Tools and applications

Select Menu > Tools to access common tools and applications. For instructions on voice mail and 1-touch dialing, see “Call voice mail” on page 18 and “1-touch dialing” on page 19.

•APPLICATION MANAGER

Select Menu > Tools > Manager. In App. manager you can install new compatible Symbian operating system

applications (SIS files) and Java applications (Java MIDlets and MIDlet suites). You can also update and uninstall applications from the phone and monitor the installation history.

Applications in App. manager use shared memory. See "Shared memory" on page 3. Options in App. manager are Install, View details, View certificate, Update, Go to

web address, Remove, View log, Send log, Settings, App. downloads, Help, and Exit.

When you open App. manager, you can see a list of:

• Applications saved in App. manager

• Partially installed applications (indicated by

)

• Fully installed applications that you can remove

(indicated by )

You can only use Symbian operating system applications with a .SIS extension.

FCC DRAFT

Your phone supports J2ME™Java applications. Do not download PersonalJava™ applications to your phone; they cannot be installed.

Install applications

You can install applications that are specifically intended for this phone and suitable for the Symbian operating system.

If you install an application that is not intended specifically for this phone, it may function and look different from what was originally intended.

Applications may be downloaded to your phone during browsing, received as attachments in multimedia messages or e-mails, or received by Bluetooth connection from another device, for example, a phone or a compatible PC.

IMINARY

Page 87

Tools and applications

Important: Only install applications from sources that offer adequate protection against harmful software.

To increase protection, the application installation system uses digital signatures and certificates for applications. Do not install the application if App. manager gives a security warning during installation.

If you install an application that contains an update or repair to an existing application, you can only restore the original application if you have the original application or a full backup copy of the removed application. To restore the original application, first remove the updated or repaired application and then install again from the original application or the backup copy.

During installation, the phone checks the integrity of the application to be installed. The phone shows information about the checks being carried out, and you are given options on whether to continue or cancel the installation. Once the phone has checked the integrity of the application, it is installed on your phone.

INSTALL APPLICATIONS

Open App. manager, scroll to the application, and select Options > Install to start the installation.

You can also search the phone memory or the memory card, select the application, and press the middle of the scroll key to start the installation.

Some applications may give the option of partial installation, allowing you to select the particular components of an application that you want to install. If you are installing an application without a digital signature or a certificate, the phone warns you of the risks. Continue installation only if you are absolutely sure of the origin and contents of the application.

FCC DRAFT

INSTALL JAVA™ APPLICATIONS

The .JAR file is required for installation. If it is missing, the phone may ask you to download it. If there is no access point defined for App. manager, you will be asked to select one. When you are downloading the .JAR file, you may need to enter a user name and password to access the server. You obtain these from the supplier or manufacturer of the application.

• To start a data connection and to view extra information about the

application, scroll to it and select Options > Go to web address.

• To start a data connection and check if there is an update available for the

application, scroll to it and select Options > Update.

JAVA SETTINGS

To change the default access point that a Java application uses for downloading extra data, select Options > Settings > Access point. See "Access points" on page 66.

IMINARY

Page 88

To change the security settings that determine the actions that a Java application is permitted to do, select Options > Settings. Not all Java applications permit you to change the security settings.

Remove an application

1 Scroll to the application and select Options > Remove. 2 Press Yes to confirm the removal.

If you remove an application, you can only re-install it if you have the original application or a full backup of the removed application. If you remove an application, you may no longer be able to open documents created with that application. If another application depends on the application that you removed, the other application may stop working. Refer to the documentation of the installed application for details.

•FILE MANAGER

Select Menu > Tools > File mngr. Options in File manager are Open, Send, Delete, Move to folder, Copy

to folder, New folder, Mark/Unmark, Rename, Find, View details, Memory details, Help, and Exit.

In File manager, you can browse, open, and manage files and folders in the phone memory or on the memory card, if you use one.

Open File manager to see a list of the folders in the phone memory. Scroll right to see the folders on the memory card, if you use one.

You can browse, open, and create folders, mark, copy and move items to folders.

FCC DRAFT

See "Common actions for all applications" on page 15. Not all folders are visible in File manager (for example, system folders are not

visible).

View memory consumption

If you have a memory card installed on your phone, you will have a choice of two memory views, one for the phone memory and one for the memory card.

Scroll right or left to move from one memory tab to another. To check memory consumption of the current memory, select Options > Memory

details. The phone calculates the approximate amount of free memory for storing data and

installing new applications.

IMINARY

Page 89

Tools and applications

In the memory views, you can view the memory consumption of the different data groups: Calendar, Contacts, Documents, Messages, Images, Sound files, Video clips, Applications, Mem. in use, and Free memory.

•VOICE COMMANDS

Select Menu > Tools > Voice com. Options in Voi ce commands are Add voice command, Open, New application,

Playback, Change, Delete, Delete all, Help, and Exit.

You can use voice commands to start applications and profiles, and to dial numbers from Contacts, without having to look at the phone display. You record a word, or words, (voice command) and then say this voice command to open an application, activate a profile, or dial a number.

You can have only one voice command per item. Any spoken words can be a voice command.

When recording, hold the phone at a short distance away from your mouth. After the starting tone, say clearly the word, or words, you want to record as a voice command.

Voice commands have the same requirements as voice tags. Before recording a voice command, see “Requirements for voice tags” on page 26.

Note: You must say the voice command exactly as you said it when you recorded it. This may be difficult in, for example, a noisy environment or during an emergency, so you should not rely solely upon voice commands in all circumstances.

FCC DRAFT

Add a voice command to an application

1 In Voice commands, scroll to the application to which you want to add a voice

command, and select Options > Add voice command. To add a voice command to a profile, the Profiles folder must be opened and a specific profile selected.

Press ’Start’, then speak after tone is displ a ye d.

2 Press Start to record a voice command.

The phone sounds a starting tone, and the note Speak now is displayed.

3 Say the voice comman d.

The phone will stop recording after approximately 5 seconds. After recording, the phone plays the recorded command. Voice command saved is displayed, and a beep sounds. A symbol can be seen next to the application.

If you do not want to save the recording, press Quit before the recording stops.

IMINARY

Page 90

Add an application to the list

You can assign voice commands to other applications that are not listed in the Voice commands main view.

1 In the Voice c ommands main view, select Options > New application.

Available applications are displayed.

2 Scroll to the application that you want to add, and press Select. 3 Add a voice command to the new application. See "Add a voice command to

an application" on page 77.

Use a voice command to start an application

1 In the standby mode, press and hold the Right selection key.

A short tone is played, and Speak now is displayed.

2 When you start an application by saying a voice command, hold the phone a

short distance from your mouth, and say the voice command clearly. The phone plays the original voice command and starts the application.

3 If the phone plays the wrong voice command, press Retry.

Replay, erase, or change a voice command

To replay, erase, or change a voice command, scroll to the item that has a voice command (indicated by ), and select Options and one of the following:

Playback—Listen to the voice command again. Delete—Erase the voice command.

FCC DRAFT

Change—Record a new voice command. Press Start to record.

IMINARY

•DEVICE MANAGER

This feature is operator dependent and may not be available on all phones. Contact your service provider for information and availability.

Select Menu > Tools > Dev. mgr. Options in Device manager are Connect, New profile, Edit profile, Delete profile,

Enable or Disable configurations, View log, Help, and Exit.

When you need help with difficult phone configurations, Device manager allows a third party, such as your service provider , to assist you directly with phone settings. To allow device management, your phone must establish a connection and

Page 91

Tools and applications

synchronize with the third party’s server . Yo u can start the synchronization session from your phone, and you can accept or reject server-initiated synchronization attempts.

A device manager profile must be defined before you can connect to a server. The third party who is assisting you can help define the profile settings:

Server name—Display name of the server. Server ID—Remote device manager server ID. Server password—Password used in server alerts. Enter the password that must be

provided by the device manager server when synchronizing with your phone. Access point—Internet access point your phone uses to establish the server

connection. Choose from the list of access points defined in your phone. See "Access points" on page 66.

Host address—Device management server URL. Port—Device management server port. User name—Your user name for this profile. Password—Your password for this profile. Allow configuration—Device management allowed on this server. Select Yes or No. Auto-accept all reqs.—Automatic or approved device management on this server.

Select Yes to allow synchronization without your verification, or select No to verify each synchronization attempt.

FCC DRAFT

IMINARY

Page 92

1 0 Personalization

•PROFILES

Select Menu > Profiles. Use Profiles to adjust and customize sound tones for different events,

environments, or caller groups. The currently selected profile is defined at the top of the display in the standby

mode. If the Normal profile is in use, only the current date is shown. Options in Profiles are Activate, Customize, Create new, Delete profile, Help, and

Exit.

Change the profile

1 Select Menu > Profiles.

A list of profiles opens. 2 Scroll to a profile, and select Options > Activate. Shortcut: To change the profile in the standby mode, press the Power key briefly,

scroll to the profile you want to activate, and press OK.

Create and customize profiles

To create a new profile, select Options > Create new. To modify a profile, select Options > Customize.

Scroll to the setting you want to change and press the middle of the scroll key to

FCC DRAFT

open the choices: Ringing tone—Set the ringing tone for voice calls. Choose a ringing tone from the

list. Press any key to stop the sound. If a memory card is used, tones stored on it have the icon next to the tone name. Ringing tones use shared memory. See "Shared memory" on page 3. You can also change ringing tones in Contacts. See "Add a ringing tone for a contact card or group" on page 26.

Ringing type—When Ascending is selected, the ringing tone volume starts from level one and increases level by level to the set volume level.

Ringing volume—Set the volume level for the ringing and message alert tones. Message alert tone—Set the tone for messages. IM alert tone—Set the tone for instant messages. Vibrating alert—Set the phone to vibrate at incoming voice calls and messages. Keypad tones—Set the volume level for keypad tones.

IMINARY

Page 93

Personalization

Warning tones—Instruct the phone to sound a warning tone, for example, when the battery is running low on power.

Alert for—Set the phone to ring only with calls from phone numbers that belong to a selected contact group. Phone calls coming from people outside the selected group will have a silent alert. You can select All calls, or you can select items from a list of contact groups, if you have created them. See "Create contact groups" on page 28.

Availability—Choose Available, Busy, or Not available to be displayed as your presence information for the selected profile. This option is displayed only if you activate the proper Sync. with Profiles setting in the Presence application. See "Presence settings" on page 32.

User availab. alerts—Enter a customized message (up to 40 characters) to display your current presence status for the selected profile. This option is displayed only if you activate the proper Sync. with Profiles setting in the Presence application. See "Presence settings" on page 32.

Profile name—If you are creating a new profile, use this setting to give it a name. You can rename a profile and give it any name you want. The Normal profile cannot be renamed.

•THEMES

Select Menu > Themes. You can change the look of your phone display by

activating a theme. A theme can include the idle screen wallpaper, color palette, screen saver, and

FCC DRAFT

icons and background image in Go to. Edit a theme for more detailed personalization.

When you open Themes you will see a list of the available themes. The currently active theme is indicated by a check mark. Scroll right to see the themes on the memory card, if you use one.

To preview a theme, scroll to the theme, and select Options > Preview. Press Select to activate the theme. You can activate the theme without previewing it by selecting Options > Apply from the main view.

Options in Themes are Preview,Apply,Edit,Copy to mem. card,Copy to phone mem.,

Theme downloads, Delete, Help, and Exit.

IMINARY

Page 94

Edit themes

To personalize themes further, you can group together elements from other themes or images from Gallery:

1 Scroll to a theme, and select Options > Edit to change the following options:

Wallpaper—Choose an image to use as a background image in the standby

mode. Select an image from one of the available themes or from Gallery,

where your own images are saved.

Color palette—Change the color used on the display.

Screen saver—Select what is shown on the screen saver bar. Choose to display

the time and date or write the text you want displayed. The location and

background color of the screen saver bar changes in one minute intervals.

Also, the screen saver changes to indicate the number of new messages and

missed calls. You can set the time that elapses before the screen saver is

activated. See "Standby mode" on page 64.

Image in ‘Go to’—Choose an image to use as a background image in Go to.

You can select an image from one of the available themes or from Gallery,

where your own images are saved.

2 Select Back to accept the changes. 3 Select Options > Set to select the current theme. You can preview the

updated theme by selecting Options > Preview. Note that you cannot preview

all elements.

Restore themes

To restore the currently selected theme to its original settings, select Options >

FCC DRAFT

Restore orig. theme when editing a theme.

IMINARY

•GO TO

Press Go to (Right selection key) in the standby mode, or select Menu > Go to.

Use Go to to store shortcuts, links to your favorite photos, video clips, notes, recorder sound files, browser bookmarks, and saved browser pages.

Options in Go to are Open, Edit shortcut name, Shortcut icon, Delete shortcut,

Move, List view or Grid view, Help, and Exit.

Default shortcuts in Go to: —opens Calendar to the current date, —opens the Messaging inbox, and —opens the Notes editor.

Page 95

Personalization

Shortcuts can be added only from pre-installed applications and functions. Not all applications have this functionality.

1 Open the application and scroll to the item that

you want to add as a shortcut. 2 Select Options > Add to ’Go to’, and press OK. A shortcut in Go to is automatically updated if you

move the item to which it is pointing, for example, from one folder to another.

Hints on using shortcuts:

• To open a shortcut, scroll to the icon and press

the middle of the scroll key. The file is opened in the corresponding application.

• To delete a shortcut, scroll to the shortcut you want to remove, and select

Options > Delete shortcut. Removing a shortcut does not affect the file to

which it refers.

• To change the shortcut name, select Options > Edit shortcut name. Write the

new name. This change affects only the shortcut, not the file or item to which

the shortcut refers.

FCC DRAFT

IMINARY

Page 96

11 Extras

•NOTES

Select Menu > Extras > Notes. You can link notes to Go to and send them to other devices. Plain text files (TXT

format) you receive can be saved to Notes. Press any key from 1 to 0 to start to write. Press the Clear key to clear letters. Press

Done to save.

•CALCULATOR

Select Menu > Extras > Calculator. Options in the calculator are Last result,Memory,Clear screen, Help, and Exit. 1 Enter the first number of your calculation.

To add a decimal, press the # key. If you make a mistake, press the Clear key to erase it.

2 Scroll to an arithmetic function and press the middle of the scroll key to select

it.

3 Enter the second number. 4 To execute the calculation, scroll to and press the middle of the scroll key.

Press and hold the Clear key to clear the result of the previous calculation.

FCC DRAFT

Use and to view previous calculations and move in the sheet.

This calculator has limited accuracy and is designed for simple

Note:

calculations. Rounding errors may occur, especially in long division.

IMINARY

•CONVERTER

Select Menu > Extras > Converter. In Converter, you can convert measures from one unit to another; for example, you

can convert length from yards to meters. Converter has limited accuracy and rounding errors may occur.

Page 97

Extras

Convert units

Options in Converter are Conversion type, Currency rates (not applicable to other units), Help, and Exit.

To make currency conversions, you must first set the exchange rate. See "Set a base currency and exchange rates" on page 85.

1 Scroll to Type, and press the middle of the scroll key to open a list of measures. 2 Scroll to the measure you want to use, and press OK. 3 Scroll to the first Unit field, and press the middle of the scroll key to open a

list of available units.

4 Select the unit from which you want to convert, and press OK. 5 Scroll to the next Unit field, and select the unit to which you want to convert. 6 Scroll to the first Amount field, and ke y in the value you want to convert.

Press the # key to add a decimal, and press the * key to insert the +, - (for

temperature), and E (exponent) symbols.

The second Amount field changes automatically to show the converted value.

The conversion order changes if you write a value in the second Amount field.

The result is shown in the first Amount field.

Set a base currency and exchange rates

Before you can make currency conversions, you must choose a base currency (usually your domestic currency) and add exchange rates. The rate of the base currency is always 1. The base currency determines the conversion rates of the other currencies.

FCC DRAFT

1 Select Currency as the measure type, and select Options > Currency rates.

A list of currencies opens with the current base currency at the top. 2 To change the base currency, scroll to the currency (usually your domestic

currency), and select Options > Set as base curr.

When you change base currency, all previously set exchange rates are reset to

zero, and you must enter new rates. 3 Add exchange rates, scroll to the currency, and key in a new rate, that is, how

many units of the currency equal one unit of the base currency you have

selected. 4 After you have inserted all the required exchange rates, make the currency

conversions. See "Convert units" on page 85.

IMINARY

Page 98

•VOICE RECORDER

Select Menu > Extras > Recorder. Options in Voice recorder are Record sound clip, Delete, Rename sound clip, Send,

Go to Gallery, Settings, Add to ’Go to’, Help, and Exit.

The voice recorder allows you to record telephone conversations and voice memos. If you are recording a telephone conversation, both parties will hear a tone every 5 seconds during recording. Voice recorder cannot be used when a data call or GPRS connection is active.

Recorded files are stored in Gallery. See "Gallery" on page 42. Select Options > Record sound clip, scroll to a function, and press the middle of

the scroll key to select it:

Record Pause Stop Fast forward Fast rewind Play an opened sound file

•CLOCK

Select Menu > Extras > Clock.

FCC DRAFT

Options in Clock are Set alarm,Reset alarm,Remove alarm,Settings,Help, and Exit.

Change settings

To change the time or date, select Options > Settings. See also “Date and time” on page 69.

Set an alarm

1 To set a new alarm, select Options > Set alarm. 2 Enter the alarm time, and press OK.

When the alarm is active, the indicator is shown.

To cancel an alarm, select Clock > Options > Remove alarm.

IMINARY

Page 99

Stop an alarm

Press Stop to turn off the alarm. Press any key or select Snooze to stop the alarm for 5 minutes, after which it will

resume. You can do this a maximum of 5 times. If the alarm time is reached while the phone is switched off, the phone switches

on and starts sounding the alarm tone. If you press Stop, you receive a message asking whether you want to activate the phone for calls. Press No to switch off the phone or Yes to make and receive calls.

Do not press Yes when wireless phone use is prohibited or when it may cause interference or danger.

Personalize the alarm tone

1 To personalize the alarm tone, select Options > Settings > Clock alarm tone.

When you scroll through the list of tones, you can stop on a tone to listen to

it before you make your selection.

2 Press Select to select the current tone.

•MEMORY CARD

Select Menu > Extras > Memory. Options in Memory card are Backup phone mem., Restore from card, Format mem.

card, Memory card name, Set password, Change password, Remove password, Memory details, Help, and Exit.

FCC DRAFT

Keep all memory cards out of the reach of small children. For details on inserting a memory card into the phone, see “Insert the memory card”

on page 8. You can use the memory card to back up information from phone memory and to store your multimedia files such as video clips, sound files, photos, messaging data, etc.

Your phone may come with a RS-MMC containing applications from other companies that are designed for use on your phone. Nokia does not provide any warranty or support for these applications. Contact the content provider for any assistance needed.

BY USING THE APPLICATIONS PROVIDED ON THE RS-MMC, YOU ACKNOWLEDGE THE SOFTWARE AND/OR APPLICATIONS (COLLECTIVELY, THE "SOFTWARE") ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND EXPRESS OR IMPLIED AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR

IMINARY

Extras

Page 100

IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR THAT THE SOFTWARE WILL NOT INFRINGE ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADEMARKS OR OTHER RIGHTS.

THERE IS NO WARRANTY BY NOKIA OR BY ITS AFFILIATES THAT ANY ASPECT OF THE SOFTWARE WILL MEET YOUR REQUIREMENTS OR THAT THE OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED OR ERROR-FREE. YOU ASSUME ALL RESPONSIBILITY AND RISK FOR THE SELECTION OF THE SOFTWARE TO ACHIEVE YOUR INTENDED RESULTS AND FOR THE INSTALLATION, USE AND RESULTS OBTAINED FROM IT. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL NOKIA, ITS EMPLOYEES OR AFFILIAT ES BE LIABLE FOR ANY LOST PROFITS, REVENUE, SALES, DATA, INFORMATION OR COSTS OF PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, PROPERTY DAMAGE, PERSONAL INJURY, INTE RR UPTION OF BUSINESS, OR FOR ANY DIRECT, INDIR ECT, INCIDENTAL, ECONOMIC, COVER, PUNITIVE, SPECIAL OR CONSEQUENTIAL DAMAGES, HOWEVER CAUSED AND WHETHER ARISING UNDER CONTRACT, TORT, NEGLIGENCE, OR OTHER THEORY OF LIABILITY ARISING OUT OF THE INSTALLATION OR USE OF OR INABILITY TO USE THE SOFTWARE, EVEN IF NOKIA OR ITS AFFILIATES ARE ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME COUNTRIES/STATES/JURISDICTIONS DO NOT ALLOW THE ABOVE EXCLUSION OR LIMITATION OF LIABILITY, BUT MAY ALLOW LIABILITY TO BE LIMITED, IN SUCH CASES, NOKIA, ITS EMPLOYEES’ OR AFFILIATES' LIABILITY SHALL BE LIMITED TO U.S.$50. Nothing contained in this disclaimer shall prejudice the statutory rights of any party dealing as a consumer.

Attach and remove the memory card adapter

The RS-MMC comes with an adapter attachment that allows you to use the card

FCC DRAFT

in regular sized MMC slots (for instance, in other Nokia phones or in a card reader). Be sure to remove the adapter when you use

the RS-MMC in your Nokia 7610 phone. To remove the adapter, press the arrow labeled

Push to release the catch (1), and gently pull the RS-MMC away from the adapter (2).

To reattach the adapter, locate the long side of the RS-MMC opposite from the side with the bevelled corner, and slide the notched corners into the metal slots of the adapter.

Make sure the RS-MMC is attached securely to the adapter before you attempt to use the card in another Nokia phone or in a card reader.

IMINARY

Microsoft RH-52, RH-51 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
