Microsoft RH-48 Users Manual

User’s Guide

9311244

Issue 1

The wireless phone described in this guide is approved for use in CDMA 800 networks.

LEGAL INFORMATION Part No. 9311244 Issue No. 1 Copyright ©2003 Nokia. All rights reserved. Nokia is a registered trademark of Nokia Corporation. Nokia, Nokia Connecting People, Xpress-on, Pop-Port, the Original Accessories logos, Space Impact, Snake II, and Bumper are trademarks of Nokia Corporation and/or its affiliates.

rights reserved.

Includes RSA BSAFE cryptographic or security protocol software from RSA

Security.

Java is a trademark of Sun Microsystems, Inc.

The information contained in this user guide was written for the Nokia phone FCC ID QMNRH-48. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

LEARN ABOUT ACCESSIBILITY SOLUTIONS

Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. Nokia maintains a Web site that is dedicated to accessibility solutions. For more information about phone features, accessories, and other Nokia products designed with your needs in mind, please visit the following Web site: www.nokiaaccessibility.com

CONTACT NOKIA

When you need help, the Nokia Care Center can provide information about Nokia products. Please refer to the table on the following page for more information on how to contact Nokia.

Customer Care Center, USA

Nokia Mobile Phones 7725 Woodland Center Blvd., Suite #150 Tampa, Florida 33614 Tel: 1-888-NOKIA-2U (1-888-665-4228) Fax: 1-813-249-9619 TTY/TDD Users Only: 1-800-24-NOKIA (1-800-246-6542)

Customer Interaction Centre, Canada

Nokia Products Ltd. 601 Westney Road South Ajax, Ontario L1S 4N7 Tel: 1-888-22-NOKIA (1-888-226-6542) Fax: 1-905-427-1070 If you ever need to call Nokia Customer Care, Nokia Customer Interaction Center, or your wireless service provider, you will need to provide specific information about your phone. This information is provided on the phone’s label.

Your phone’s label

The label is inside the back cover of your phone (under the battery). It contains important information about your phone, including the model and electronic serial numbers (ESN). Nokia recommends that you note this information on the title page of this guide. Please do not remove or deface the label.

Contents

FOR YOUR SAFETY.................... 7

General information................. 9

Access codes............................................ 9

Overview of the functions

in the phone .......................... 10

Shared memory.................................... 10

1. Your phone......................... 11

Keys and connectors .......................... 11

Standby mode ...................................... 11

Power saving..................................... 12

Essential indicators......................... 12

2. Getting started .................. 13

Installing the UIM card and

the battery ............................................ 13

Charging the battery.......................... 14

Switching the phone on and off..... 14

Normal operating position ............... 15

Keypad lock (Keyguard) ..................... 15

Changing the front and back cover 16 Charging the glow-in-the-dark

cover ....................................................... 17

3. Basic functions .................. 18

Making a call........................................ 18

Speed dialling a phone number... 18 Answering or rejecting an

incoming call........................................ 18

Call waiting ....................................... 19

Options during a call.......................... 19

Loudspeaker ...................................... 19

Writing text .......................................... 19

Setting predictive text input

on or off ............................................. 20

Using predictive text input ........... 20

Writing compound words .......... 21

Using traditional text input.......... 21

4. Using the menu.................. 22

List of menu functions ...................... 22

Messages (Menu 1) ............................ 25

Text messages................................... 25

Writing and sending SMS

or e-mail messages ..................... 25

Reading and replying to

a message or a SMS e-mail ...... 26

Inbox and Sent Items folders.... 26

Archive folder and my folders .. 26

Templates ....................................... 27

Distribution lists ........................... 27

Multimedia messages..................... 27

Reading and replying to

a multimedia message................ 28

Multimedia messages Inbox,

Outbox and Saved items folders 28 Multimedia messages

memory full....................................... 28

Deleting messages........................... 29

Message settings ............................. 29

Settings for text and

e-mail messages........................... 29

Settings for multimedia

messages ........................................ 29

Voice messages ................................ 30

Minibrowser messages................... 30

Call register (Menu 2)........................ 30

Recent call lists................................ 31

Call timers, Data/fax calls

and Minibrowser.............................. 31

Contacts (Menu 3).............................. 32

Searching for a name in contacts 32 Saving multiple numbers, text items and an image

per contact ........................................ 33

Voice dialling .................................... 34

Assign a voice tag to

a phone number ........................... 34

Dialling a number using

voice dialling.................................. 35

Profiles (Menu 4) ................................. 36

Settings (Menu 5)................................ 36

Personal short-cuts ......................... 36

Call settings ....................................... 37

Anykey answer............................... 37

Automatic redial ........................... 37

Speed dialling ................................ 37

Automatic update of service..... 37

Calling card .................................... 37

Phone settings .................................. 38

Phone language ............................ 38

Automatic keyguard .................... 39

Security keyguard ......................... 39

DTMF tones..................................... 39

Welcome note ............................... 39

Help text activation ..................... 40

Time and date settings ................... 40

Display settings ............................... 40

Wallpaper........................................ 40

Colour schemes ............................. 40

Banner ............................................. 41

Display brightness ........................ 41

Tone settings ..................................... 41

Enhancement settings .................... 41

Security settings............................... 42

Call restrictions ............................. 42

Access codes .................................. 42

Voice Privacy.................................. 42

Network .............................................. 43

Roaming .......................................... 43

Roaming indicators ...................... 43

Network choice ............................. 43

Network services .............................. 43

Call divert ....................................... 44

Call waiting .................................... 44

Send my caller identity ............... 44

Network feature setting ............. 45

Own number selection ................ 45

Restore factory settings................. 45

Gallery (Menu 6).................................. 45

Voice (Menu 7) ..................................... 46

Voice tags........................................... 46

Voice commands .............................. 46

Voice recorder ................................... 46

Organiser (Menu 8) ............................. 47

Alarm clock ........................................ 47

Calendar.............................................. 47

Making a calendar note.............. 48

When the phone alarms

for a note........................................ 48

To-do list ............................................ 48

Calculator........................................... 49

Making calculations .................... 49

Making a currency conversion.. 49

Countdown timer ............................. 49

Calorie counter ................................. 50

Mobile Web (Menu 9) ........................ 50

Browsing sessions and indicators 50 Launching and terminating

the Minibrowser ............................... 51

Minibrowser menu........................... 51

Navigate in the minibrowser ........ 52

Bookmarks.......................................... 52

Minibrowser messages ................... 53

Notification of new

minibrowser messages................ 53

Weblinks in minibrowser

messages......................................... 53

Games (Menu 10)................................ 53

Launching a game ........................... 54

Memory............................................... 54

Game settings ................................... 54

Applications (Menu 11) ..................... 54

Launching an application .............. 54

Other options available for

an application................................ 54

Downloading an application......... 55

Go to (Menu 12) .................................. 56

5. PC Connectivity .................. 57

PC Suite.................................................. 57

6. Battery statements............. 58

Contents

Charging and Discharging ................ 58

7. Technical Information....... 59

8. Patents ............................... 60

CARE AND MAINTENANCE... 61

IMPORTANT SAFETY

INFORMATION ....................... 62

APPENDIX ................................ 68

A message from the CTIA ...................68

A message from the U.S. Food

and Drug Administration ....................71

FOR YOUR SAFETY

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual.

Do not switch on the phone when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Do not use a hand-held phone while driving.

INTERFERENCE

All wireless phones may get interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any regulations or rules. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELLING

Do not use the phone at a refuelling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Do not use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules.

USE SENSIBLY

Use only in the normal position. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not waterresistant. Keep it dry.

BACKUP COPIES

Remember to make backup copies of all important data.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user’s guide for detailed safety instructions. Do not connect incompatible products.

CALLING

Ensure the phone is switched on and in service. Enter the phone number, including the area code, th en press . To end a call, press . To answer a call, press .

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press as many times as needed (e.g. to exit a call, to exit a menu, etc.) to clear the display. Enter the emergency number, then press . Give your location. Do not end the call until told to do so.

FOR YOUR SAFETY

■ Network Services

The wireless phone described in this guide is approved for use on the CDMA network.

A number of features included in this guide are called Network Services. These are special services that you arrange through your wireless service provider. Before you can take advantage of any of these Network Services, you must subscribe to them through your service provider and obtain instructions for their use from your service provider.

Note: Some networks may not support all language-dependent characters and/or services.

■ About accessories

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from ACP-7, ACP-12 and LCH-12.

Warning: Use only batteries, chargers and accessories approved by the phone manufacturer for use with this particular phone model. The use of any other types may invalidate any approval or warranty applying to the phone, and may be dangerous.

For availability of approved accessories, please check with your dealer.

When you disconnect the power cord of any accessory, grasp and pull the plug, not the cord.

General information

■ Access codes

• Security code: This code, supplied with the phone, protects your phone against unauthorised use. The preset code is 12345.

Refer to Security settings on page 42 to see how it works.

• PIN code: This code, supplied with the UIM card, protects the card against unauthorised use.

Set on the PIN code request in the Security settings menu (see Security settings on page 42), so that the code is requested each time the phone is switched on.

If you key in an incorrect PIN code three times in succession, the UIM card is blocked. You must key in the PUK code to unblock the UIM card and set a new PIN code.

• PIN2 code: This code is supplied with some UIM cards and is required to access certain services, such as charging unit counters. If you key in an incorrect PIN2 code three times in succession, PIN2 code

blocked appears on the display, and you will be asked for the PUK2

code.

Change the security code, PIN code and PIN2 code in Change of

access codes in the Security settings menu (see Security settings on

page 42). Keep the new codes secret and in a safe place separate from your phone.

• PUK and PUK2 code: These codes may be supplied with the UIM card. If this is not the case, contact your local service provider.

Overview of the functions in the phone

The Nokia 3105 phone provides many functions which are practical for daily use, such as Calendar, Clock, Alarm clock, Profiles, and many more. Some functions are

• MMS - Multimedia Messaging Service, see Multimedia messages on page 27.

• Polyphonic MIDI ringing tones enable richer ringing tones with a wide variety of sounds.

• CDMA - Code Division Multiple Access is used for sending and receiving data over the mobile network.

• MIDP Java™ applications specially designed for mobile phones. See Applications (Menu 11) on page 54.

• Nokia OTA settings service. Several services need proper settings in your phone. You may receive the settings directly as an OTA (Over the Air) message, and you only need to save the settings. Contact your nearest authorised Nokia dealer for more information.

■ Shared memory

The following features in this phone share memory: phone’s contacts directory, text and multimedia messages, images and ringing tones in gallery, calendar, bookmarks, and Java™ games and applications. Using any such features may reduce the memory available for any features sharing memory. This is especially true with heavy use of any of the features. For example, saving many images, Java™ applications, etc. may take all of the shared memory and your phone may display a message that the memory is full. In this case, delete some of the information or entries stored in the shared memory features before continuing.

Your phone

1. Your phone

■ Keys and connectors

1. Power key

2. Selection keys and

3. 4-way scroll key with , , and

4. dials a phone number, and answers a call. In standby mode it shows the most recently called number.

5. ends an active call. Exits from any

function.

6. - enter numbers and characters.

and are used for various purposes

in different functions.

7. Charger connector

8. Pop-Port™ connector for headset and data cable, for example

■ Standby mode

When the phone is ready for use, and you have not keyed in any characters, the phone is in standby mode.

1. Indicates the operator "text".

2. Shows the signal strength of the cellular network at your current location.

3. Shows the battery charge level.

4. The left selection key in standby mode is Menu.

5. The softkey in standby mode is Contacts or Go

to (personal short-cut). To set the functions for your Personal short-

cut, see Personal short-cuts on page 36.

Your phone

Power saving

For power saving a digital clock view overwrites the display when no function of the phone has been used for a certain period of time.

Essential indicators

You have received one or several text or picture messages. See Reading and replying to a message or a SMS e-mail on page 26.

You have received one or several minibrowser messages. See Minibrowser messages on page 53.

You have received one or several multimedia messages. See Reading and replying to a multimedia message on page 28.

The phone’s keypad is locked. See Keypad lock (Keyguard) on page 15.

The phone does not ring at an incoming call or text message when Incoming call alert is set to Off and Message alert tone is set to Off. See Tone settings on page 41.

The alarm clock is set to On. See Alarm clock on page 47.

All your calls are diverted to another number, Divert all calls. If you have two phone lines, the diverting indicator for the first line is and for the second line . See Call divert on page 44.

The loudspeaker has been activated. See Loudspeaker on page 19.

The phone has registered a missed call. See Call register (Menu

2) on page 30.

Getting started

2. Getting started

■ Installing the UIM card and the battery

Keep all miniature UIM cards out of the reach of small children.

• The UIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting or removing the card.

• Before installing the UIM card, always make sure that the phone is switched off and disconnected from any enhancement.

1. Remove the back cover from the phone. With the back of the phone facing you, push the back cover release button (1) and slide the back cover off (2).

Remove the battery by lifting it with the finger grip (3).

2. Release the UIM card holder. Gently pull the locking clip of the card holder (4) and open it (5).

3. Insert the UIM card into the UIM card holder (6). Make sure that the UIM card is properly inserted and that the golden contact area on the card is positioned as shown.

Getting started

4. Close the UIM card holder (7) and press it until it snaps into position.

5. Insert the battery (8).

6. Slide the back cover into its place (9).

■ Charging the battery

1. Connect the lead from the charger to the socket on the bottom of your phone.

2. Connect the charger to an AC wall socket.

The text Charging is displayed briefly if the phone is switched on. If the battery is completely empty, it may take a few minutes before the charging indicator appears on the display or any calls can be made.

The charging time depends on the charger and the battery used. For example, charging a BL-5C battery with the ACP-7 charger takes up to 3 hours in standby mode.

■ Switching the phone on and off

Warning: Do not switch the phone on when wireless phone use is

prohibited or when it may cause interference or danger.

Press and hold the power key .

If the phone asks for a PIN code, key in the PIN code (displayed as ****).

Getting started

■ Normal operating position

Use the phone only in its normal operating position.

Your phone has a built-in antenna. As with any other radio transmitting device, do not touch the antenna unnecessarily when the phone is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Not touching the antenna area during a phone call optimises the antenna performance and the talktime of your phone.

■ Keypad lock (Keyguard)

You can lock the keypad to prevent the keys being accidentally pressed.

Press (Menu or Unlock) and then within 1.5 seconds to lock or unlock the keypad.

An incoming call can be handled normally. When you end or reject the call, the keypad will automatically be locked again.

For automatic keypad lock, see Automatic keyguard on page 39.

Note: When the keypad is locked, calls may be possible to the emergency number programmed into your phone (e.g. 112, 911 or other official emergency number). Key in the emergency number and press

. The number is displayed only after you have keyed in its last

digit.

Getting started

■ Changing the front and back cover

Before changing the covers, always switch off the power and disconnect the phone from the charger or any other device. Always store and use the phone with the covers attached.

1. Remove the back cover of the phone.

With the back of the phone facing you, push the back cover release button (1) and slide the back cover off (2).

2. To remove the front cover, gently prise the back part of the phone away from the front cover beginning at the bottom of the phone.

3. Insert the key mat on the new front cover.

4. To attach the front cover, first place the phone and the front cover properly together and then gently push on the top and bottom of the phone until the catch is locked properly.

Getting started

5. Place the back cover and the phone properly together (1) and slide the back cover into its place (2) until the back cover release button is properly locked.

■ Charging the glow-in-the-dark cover

The front cover of your Nokia 3105 phone has a glow-in-the-dark element. To make the cover glow you need to expose it to a bright light source for at least 12 minutes, for full charge 18 minutes.

Basic functions

3. Basic functions

■ Making a call

1. Key in the phone number, including the area code. If you key in a wrong character, press Clear to delete it.

2. Press to call the number.

3. Press to end the call or to cancel the call attempt.

Making a call using the contacts list

In standby mode, press or to find the name or key in the first character(s) of the name you are looking for. See also Searching for a name in contacts on page 32. Press to call the number on the display.

Last number redialling

In standby mode, press once to access the list of up to 20 numbers you last called or attempted to call. Scroll to the number or name you want, and press to call the number.

Speed dialling a phone number

Assign a phone number to one of the speed dialling keys, from to

, see menu option Speed dials in chapter Contacts (Menu 3) on

page 32. Call the number in either of the following ways:

• Press the speed dialling key you want and then press .

•If Speed dialling is set to on, press and hold a speed dialling key until the call is started. See Speed dialling on page 37.

■ Answering or rejecting an incoming call

Press to answer the incoming call and press to end the call.

Press to reject the incoming call.

Press Silence, if available, to mute the ringing tone. Then either answer or reject the call.

Basic functions

Tip: If the Divert if busy function is activated to divert the calls,

for example to your voice mailbox, rejecting an incoming call will also divert the call. See Call divert on page 44.

Call waiting

During a call, press to answer the waiting call. The first call is put on hold. Press to end the active call.

To activate the Call waiting function, see Call waiting on page 44.

■ Options during a call

Many of the options that you can use during a call are network services. Press Options during a call for some of the following options:

End call, Mute or Unmute, Loudspeaker or Handset, New call, Save, Add to contact, End all calls, Send DTMF, Contacts, Menu,

Loudspeaker

You can use your phone as a loudspeaker during a call.

Warning: Do not hold the phone near to your ear when the loudspeaker is in use, because the volume may be extremely loud.

To activate the loudspeaker, press Options and select Loudspeaker, or press selection key Loudsp., if available.

To deactivate the loudspeaker during a call, press Options and select

Handset, or press selection key Handset, if available.

■ Writing text

You can key in text in two different ways, using the traditional text input, indicated with , or using the predictive text input indicated with at the top left of the display. The character case is indicated by , , or next to the text input indicator. You can change the character case by pressing . The number mode is indicated by

, and you can change between the letter and number mode by

pressing and holding .

Basic functions

Setting predictive text input on or off

When writing text, press Options and select Dictionary.

• To set the predictive text input on, select a language in the dictionary options list.

• To change back to the traditional text input, select Dictionary off.

Tip: To quickly set the predictive text input on or off when writing text, press twice, or press and hold Options.

Using predictive text input

Predictive text input is an easy way to write text.

The predictive text input is based on a built-in dictionary to which you can also add new words.

1. Key in the word you want by pressing each key once for one letter. The word changes after each keystroke. For example, to write ‘Nokia’ when the English dictionary is selected, press , , ,

, .

• To delete the character to the left of the cursor, press Clear. Press

and hold Clear to delete the characters more quickly.

• To switch between upper and lower cases, or between traditional

and predictive text input, press repeatedly and check the indicator at the top of the display.

• To insert a number, press and hold the desired key. To switch

between letters and numbers, press and hold .

• To insert a period ".", press .

• To get a list of special characters, press and hold and select

the character you want. Press Use to insert the selected special character.

2. If the displayed word is the one you want, press and start writing the next word.

• If you want to change the word, press repeatedly to the word

you want.

Basic functions

• If the "?" is displayed after the word, the word is not in the dictionary. To add the word to the dictionary, press Spell, key in the word (traditional text input is used) and press OK.

Writing compound words

Key in the first half of the word, press , and then key in the second half.

Using traditional text input

Press the key marked with the letter that you want repeatedly until the letter appears.

Use the following functions to edit the text:

• To add a space, press .

• To add a punctuation mark or special character, press repeatedly, or press , select the desired character, and press Use.

• To move the cursor to the left, right, down or up, press the scroll keys

, , or , respectively.

• To delete a character to the left of the cursor, press Clear. Press and hold Clear to delete the characters more quickly.

• To switch between upper and lower case, press .

• To add a number, press and hold the desired key. To switch between letters and numbers, press and hold .

• To key in a letter which is on the same key as the previous one, wait until the cursor appears or, press or and key in the new letter.

Using the menu

4. Using the menu

The phone offers you an extensive range of functions which are grouped in menus.

To access the menu, press Menu. Scroll with or through the menus and select the menu by pressing Select. Select submenus and settings of your choice in the same way.

Press Back to return to the previous menu level, and Exit to exit the menu.

■ List of menu functions

1. Messages

1. Text messages

2. Multimedia msgs.

3. Voice messages

4. Minibrowser messages

2. Call register

1. Missed calls

2. Received calls

3. Dialled numbers

4. Delete recent call lists

5. Call duration

6. Data/FAX calls

7. Minibrowser calls

3. Contacts

1. Search

2. Add contact

3. Edit name

4. Delete

5. Add number

6. Settings

7. Speed dials

8. Voice tags

9. Own number

10.Caller groups

4. Profiles

1. General

2. Silent

3. Meeting

4. Outdoor

5. Pager

5. Settings

1. Right selection key settings

2. Call settings

3. Phone settings

4. Time settings

5. Display settings

6. Tone settings

7. Enhancement settings

8. Security settings

9. System

10.Network services

11.Restore factory settings

6. Gallery

1. View folders

2. Add folder

3. Delete folder

4. Rename folder

5. Gallery downloads

7. Voice

1. Voice tags

2. Voice commands

3. Voice Recorder

8. Organiser

Using the menu

1. This menu is shown only if the phone is or has been connected to a compatible headset, handsfree unit or loopset available for the phone.

Using the menu

1. Alarm clock

2. Calendar

3. To-do list

4. Calculator

5. Countdown timer

6. Calorie counter

9. Mobile web

1. Home

2. Back

3. Add bookmark

4. View bookmarks

5. Search

6. Go to URL

7. Show URL

8. Instructions

9. Save items

10.Other options

11.Refresh

12.Exit web

10.Games

1. Select game

2. Memory

3. Settings

11.Applications

1. Select application

2. Browser downloads

3. Memory

12.Go to

+ 54 hidden pages
