Nokia 6585 User Guide

LEGAL INFORMATION

Part No. 9356692, Issue No. 1 Copyright ©2003 Nokia. All rights reserved. Nokia, Nokia 6585, Xpress-on Color Covers, Pop-Port, Nokia Connecting People, and the Nokia Original Enhancements logos are trademarks or registered trademarks of Nokia Corporation. Other company and product names mentioned herein may be trademarks or trade names of their respective owners. Printed in Canada 9/2003

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

The information contained in this user guide was written for the Nokia 6585 product. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice. UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your phone may cause TV or radio interference (for examp le, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

Java is a trademark of Sun Microsystems, Inc.

Contents

1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2 Welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

About your device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Shared memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Nokia 6585 phone at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Get the most out of this guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Phone menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3 Set up your phone. . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Make a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Answer calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Keyguard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Standard mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Predictive text input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5 Contacts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Add new contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Edit contacts list entries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Delete contacts list entries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

View the contacts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Send and receive contacts (business cards) . . . . . . . . . . . . . . . . . . . . . 20

6 Messages (Menu 1) . . . . . . . . . . . . . . . . . . . . . . . . . 21

Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Multimedia messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Voice messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Picture messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Minibrowser messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

E-mail messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Message folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Delete messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

7 Call log (Menu 2) . . . . . . . . . . . . . . . . . . . . . . . . . 33

View missed calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

View received calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Dialed numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Delete call logs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Duration of calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Duration of data/fax calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Duration of minibrowser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

8 Profiles (Menu 3) . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Activate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Customize a profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Set a timed profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

9 Settings (Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . 37

Right selection key settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Time and date settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Tone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Enhancement settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Restore factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

10 Network (Menu 5) . . . . . . . . . . . . . . . . . . . . . . . . . 52

Roaming options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

11 Radio (Menu 6) . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Turn on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Save a channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

12 Gallery (Menu 8). . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Open the gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

View folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

13 Games (Menu 9) . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Play a game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Game settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Game options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

14 Voice (Menu 10) . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Voice dialing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Voice commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Voice recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

15 Minibrowser (Menu 11). . . . . . . . . . . . . . . . . . . . . . 59

Mobile internet access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Sign on to the mobile internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Navigate the mobile internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

16 Organizer (Menu 12). . . . . . . . . . . . . . . . . . . . . . . . 61

The alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

The calendar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

The to-do list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

The calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

The countdown timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

The stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

The calorie calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

17 Applications (Menu 13). . . . . . . . . . . . . . . . . . . . . . 69

Launch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Download. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Memory status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

18 Enhancements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

19 Reference information. . . . . . . . . . . . . . . . . . . . . . . 71

Batteries and chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Additional safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Care and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Certification Information (SAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Battery information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Nokia One-Year Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Patent information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Appendix A: Message from the CTIA

to all users of mobile phones.. . . . . . . . . . . . . . . . . 81

Appendix B: Message from the FDA to all

users of mobile phones. . . . . . . . . . . . . . . . . . . . . . 85

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

For your safety

1 For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the phone at a refuelling point. Don't use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Don’t use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACKUP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the End key as many times as needed (e.g. to exit a call, to exit a menu, etc.) to clear the display and return to the main screen. Key in the emergency number, then press the Talk key. Give your location. Do not end the call until given permission to do so.

2Welcome

Congratulations on your purchase of the Nokia 6585 mobile phone. Your phone provides many functions which are practical for daily use, such as a radio, hands-free loudspeaker, alarm clock, calculator , calendar, and more. Your phone can also connect to a PC, laptop, or other device using a data cable or the built-in IR port. To personalize your phone, you can set your favorite ring tones, create a go-to-menu, and select an Xpress-on

• ABOUT YOUR DEVICE

The wireless phone described in this guide is approved for use on the AMPS 800, CDMA 800 and 1900, and 1XRTT networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the phone must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

• NETWORK SERVICES

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These Network Services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize Network Services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use Network Services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear in your device menu. Contact your service provider for more information.

• SHARED MEMORY

The following features in this device may share memory: contacts, text and multimedia messages, images and ringing tones in gallery, calendar and to-do notes, games and applications. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. For example, saving many calendar notes, may use all of the available memory. Your phone may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features, such as multimedia

color cover.

Welcome

messages, ring tones in gallery, images, and applications may have a certain amount of memory specially allotted to them in additi on to th e mem ory sh ared with other features.

• REGISTER YOUR PHONE

Make sure to register your phone at www.warranty.nokiausa.com or call 1-888-NOKIA-2U (1-888-665-4228) so tha t we can serve your needs better if you should need to call a customer center or to have your phone repaired.

•GET HELP

Find your phone label

If you need help, Nokia Customer Care is available for assistance. Before calling, we recommend that you write down the following information and have it available:

• Electronic Serial Number (ESN)

• Your zip code

The ESN is found on the type label, which is located beneath the battery on the back of the phone.

Contact Nokia

Please have your product with you when contacting either of the numbers below:

Nokia Customer Care Center, USA Customer Care Center, Canada

Nokia Inc. 7725 Woodland Center Boulevard Suite #150 Tampa, Florida 33614

Tel:1-888-NOKIA-2U (1-888-665-4228) Fax: 1-813-249-9619 TTY: 1-800-24-NOKIA (hearing impaired only)

Nokia Products Ltd. 601 Westney Road South Ajax, Ontario L1S 4N7

Tel:1-888-22NOKIA (1-888-226-6542) Fax:1-905-427-1070

Type Label

Updates

From time to time, Nokia updates this guide to reflect changes. The latest version may be available at www.nokia.com. An interactive tutorial for this product may be available at the web site www.nokiahowto.com.

Accessibility solutions

Nokia is committed to making mobile phones easy to use for all individuals. For more information about phone features, enhancements, alternate format user guides, and other Nokia products designed with your needs in mind, visit the web site www.nokiaaccessibility.com or call 1-888-665-4228 for more information.

• NOKIA 6585 PHONE AT A GLANCE

IR Port

Earpiece

Volume keys

Display screen

Welcome

Power key

Left selection key

Talk key

Number keys

* key

Charger port Pop-port™ Connector

Right

selection key

End key

Four-way scroll key

# key

Microphone

The start screen

The start screen is “home base” and indicates your phone is in idle mode.

Signal strength

Battery level

Contacts

Signal strength—A higher bar indicates a stronger network signal. Battery level—A higher bar indicates more power in the battery. Menu—Press the Left selection key to select this option. Contacts—Press the Right selection key to select this option.

Quick keys

At the start screen, the four-way scroll key instantly takes you to frequentlyaccessed menus:

• Scroll up key—Go to the contacts list.

• Scroll right key—View the calendar.

• Scroll down key—Go to the contacts list.

• Scroll left key—Create a message.

Indicators and icons

Icon Indicates...

You have one or more text or picture messages. See “Read and reply” on page 21.

You have one or more multimedia messages. See “Read and reply” on page 25.

You have attached a picture to a multimedia message. See “Write and send” on page 24.

You have one or more voice messages. See “Voice messages” on page 26.

Your phone’s keypad is locked, see “Lock the keypad” on page 13. Your phone is set to the Silent profile. See “Profiles (Menu 3)” on

page 36. The alarm clock is set to On. See “The alarm clock” on page 61. The countdown timer is running. See “The countdown timer” on

page 65.

Icon Indicates...

The stopwatch timing is running in the background, see “The stopwatch” on page 66.

When shown continuously, the IR connection is activated and your phone is ready to send or receive data via its IR port; when blinking, your phone is trying to connect to the other device or a connection has been lost. See

All calls are forwarded to another number. See “Call forwarding” on page 49.

Integrated handsfree is active, see “The loudspeaker” on page 13. The timed profile is selected, see “Profiles (Menu 3)” on page 36.

or An enhancement is connected to the phone. or Voice privacy encryption is active (or is not active) in the network.

or Location info sharing is set to Emergency or On. See “Set location info

sharing” on page 37. You are in a 1XRTT network. See “Network services” on page 3. You are in a digital network. See “Network services” on page 3. You are in an analog network. See “Network services” on page 3.

“Send and receive data using IR” on page 42.

• GET THE MOST OUT OF THIS GUIDE

The following sections illustrate the various components of your phone. Familiarize yourself with these sections to help you understand the instructions that follow.

This guide uses certain terms for the steps that you are asked to perform.

• Press means to press and release a key quickly. For example, Press 7 means press the key on the keypad that is labeled with the number 7 and the letters “p, q, r, s”.

• Press and hold means to press and hold a key for 2–3 seconds, then release the key.

• Selection keys are used to select a menu option. To select an option, press the selection key below the menu item on the phone’s screen.

• Scroll keys are used to move up, down, left, or right in the menus.

• Talk and End keys: Press the Talk key to place a call or to answer an incoming call. Press the End key to end a call or press and hold to return to the idle screen.

Welcome

• PHONE MENUS

Phone features are grouped according to function and are accessed through the main menus. Each main menu contains submenus and lists from which you can select or view items and customize your phone features. You can access these menus and submenus by using the scroll method or by using a shortcut.

Note: Some features may not be available, depending your network. For more information, contact your wireless provider.

The scroll method

1 At the start screen, select Menu and scroll

through the main menus using the up and down four-way Scroll key.

A scroll bar with a tab moves up or down on the display screen as you scroll through the menus, providing a visual representation of your current position in the menu structure.

2 When you arrive at a menu, press Select

(the Left selection key) to enter submenus.

•Press Back (the Right selection key) to return to the previous menu.

•Press the End key to return to the start screen from any menu or submenu.

Shortcuts

You can go directly to almost any menu or submenu, as well as activate most features by using a shortcut.

At the start screen, select Menu, then within 3 seconds, press the key or keys associated with the menu function you would like to view or activate.

For example, to select the Meeting profile, select Menu 3-3-1 from th e sta rt screen (Menu > profile is activated.

Profiles > 3Meeting > 1Select). After a brief pause, the Meeting

In-phone help

Many features have brief descriptions (help text) which can be viewed on the display. To view these descriptions, scroll to a feature and wait for about 10 seconds. Press More to view all of the description, or press Back to exit.

In order to view the descriptions, you must first activate help text .

1 At the start screen, select Menu > Settings > Phone settings > Help text

activation and press Select.

2 Scroll to On or Off and press Select.

Scroll up

Scroll

left

Scroll down

Scroll

right

Set up your phone

3 Set up your phone

The antenna

Your device has an internal antenna located towards the top of the phone. Hold the phone as you would any other telephone with the antenna area pointed up and over your shoulder.

Note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the phone optimizes the antenna performance and the battery life.

The battery

Always switch the device off and disconnect the charger before removing the battery.

REMOVE THE BACK COVER

1 Hold the phone upside down,

with the back of the phone facing you.

2 Push down on the back cover

release button and pull the bottom of the back cover away from the phone to remove it.

REMOVE THE BATTERY

3 After you have removed the back cover, insert

your finger into the finger grip and lift the battery from its compartment.

REPLACE THE BATTERY

1 Position the battery so the gold-colored

contacts match up with those on the phone. The battery label should be facing away from the phone.

2 Insert the battery, gold-colored contact end

first, into the battery slot.

3 Push down on the other end of the battery to snap the battery into place.

REPLACE THE BACK COVER

1 Place the top of the back cover to the locking

catch in the top of the phone.

2 Position the back cover over the locking

catches on the both sides of the phone and press down at the top and bottom to lock the cover into place.

CHARGE THE BATTERY

1 Plug the charger transformer in to a standard

ac outlet.

2 Insert the charger output plug into the

round jack at the bottom end of the phone.

After a few seconds, the battery indicator in the display starts to scroll from bottom to top. If the battery is completely flat, it may take a few minutes before the charging indicator appears on the display or any calls can be made.

Turn your phone on or off

1 To turn your phone on or off, press and hold the power

key on top of the phone for at least 3 seconds.

2 Enter the security code if necessary and press OK. See

“Security code” on page 48 for more information.

Connect the headset

A compatible headset may be purchased with your phone or separately as an enhancement. (See

1 Plug the headset connector into the Pop-Port™

connector at the bottom end of your phone.

2 Position the headset on your ear.

With the headset connected, you can make, answer, and end calls as usual.

• Use the keypad to enter numbers.

•Press the Talk key to place a call.

•Press the End key to end a call.

“Enhancements” on page 70 for information.)

Set up your phone

Change the Xpress-on™ covers

Note: Before removing the cover, always switch off the power and

disconnect the charger and any other device. Avoid touching electronic components while changing the covers. Always store and use the device with the covers attached.

REMOVE THE BACK COVER AND THE BATTERY

See “Remove the back cover” and “Remove the battery” on page 9 for instructions on removing the back cover and battery.

REMOVE THE FRONT COVER

1 Press the front cover latch on the top of the

phone while gently pulling the top of the front cover away from the rest of the phone.

INSTALL THE KEYMAT AND FRONT COVER

2 Remove the key mat from the old front cover

and place it into the new front cover as shown.

3 Insert the side latches towards the bottom

of the new front cover into the matching holes towards the bottom of the phone.

4 Gently push the latches from the middle of the front

cover into the matching holes in the middle of the phone.

5 Gently push the cover latch on the top of the front

cover through the locking hole in the top of the phone, and snap the front cover into place.

REPLACE THE BATTERY AND BACK COVER

See “Replace the battery” on page 9 and “Replace the back cover” on page 10 for instructions on replacing the battery and back cover.

• MAKE A CALL

Using the keypad

1 Enter the phone number (including the area code), and press the Talk key.

(To delete a character to the left of the cursor, press Clear.)

2 Press the End key to end the call or to cancel the call attempt.

Using the contacts list

1 At the start screen, scroll to the entry you wish to view. 2 Press the Talk key to make the call, or press Details to view details of the entry.

Using the last dialed number

1 At the start screen, press the Talk key to display the last 20 numbers dialed. 2 Scroll to the number (or name) you wish to redial and press the Talk key.

Conference calling

Conference calling is a Network Service that allows you to take part in a conference call with two other participants.

1 Make a call to the first participant. 2 With the first participant on the line, select Options > New call and

press Select.

3 Enter the phone number of the second participant, or press Find to retrieve a

number from the contacts list.

4 Press Flash.

The first participant is put on hold.

5 When the second participant picks up, press the Talk key to connect the calls. 6 To end the conference call, press Options > End all c alls or press the End key.

• ANSWER CALLS

Answer or silence an incoming call

1 Press the Talk key to answer the call. 2 Press the End key or Silence to mute the ringing tone; you can then press

Answer to answer the call or press Reject (or do nothing) and the call is eventually diverted to voicemail.

Answer a call with the keypad locked

To answer a call with the keypad locked, simply press the Talk key. Du ring the call, all features function as normal. When you end or reject the call, the keypad automatically re-locks. See

When the phone is locked, calls still may be possible to the official emergency number programmed into your phone.

“Keyguard” on page 13 for details.

Set up your phone

Adjust the earpiece volume

• To increase the volume of a call, press the top of the volume key on the left side of the phone.

• To decrease the volume of a call, press the bottom of the volume key on the left side of the phone.

• When adjusting the volume, a bar chart appears in the display indicating the volume level.

Volume

key

The loudspeaker

You can use your phone as a loudspeaker during a call. Do not hold the phone to your ear during the loudspeaker operation.

• To activate the loudspeaker, press Loudsp.

• To deactivate the loudspeaker during a call, press Handset.

The loudspeaker is deactivated automatically when a call (or a call attempt) ends or when certain enhancements are connected.

Options during a call

Many of the options that you can use during a call, are Network Services. Check with your wireless service provider for more information.

1 Press Options during a call to display a list of options available during a call. 2 Scroll to an option and press Select to activate the option or enter its

submenu.

• KEYGUARD

With keyguard, you can lock the keypad to prevent keys from being pressed accidentally. Remember to lock your phone keypad to prevent accidental calls. If the keypad is locked, it unlocks when you receive a call. After the call, the lock automatically reactivates.

When the keyguard is on, calls still may be possible to the official emergency number programmed into your phone. Key in the emergency number and press the Talk key.

Lock the keypad

Select Menu with the Left selection key, then press the * key within two seconds.

Unlock the keypad

Select Unlock with the Left selection key, then press the * key within two seconds.

4 Text entry

You can use two methods for entering text and numbers:

• Standard mode is the only way to enter text into such things as the contacts list, calendar notes, and to rename caller groups.

• Predictive text input is a quick and easy method for writing messages, creating a calendar note, or making a to-do list.

• STANDARD MODE

Text (Abc)

• Press a key once to insert the first letter on the key, twice for the second letter, etc. If you pause briefly, the last letter in the display is accepted and your phone awaits the next entry.

•Press the 0 key to enter a space thereby accepting a completed word

•Press the 1 key to enter a period (.)

•Press the * key to display special characters. See more about special characters on the following pages

Numbers (123)

To switch to 123 mode from Abc mode, press and hold the # key at any message entry screen until the icon in the upper left corner of the display switches from Abc to 123 (or vice versa).

•Press Clear to backspace the cursor and delete a character

•Press and hold Clear to backspace continuously and delete characters

Punctuation and special characters

While at any text entry screen, press the * key to display special characters (press and hold the * key if predictive text is on). The following special characters are available:

, ‘ ? ! “ - ( )

@ / : _ ; + &

= < > £ $ ] { } \ ~ ^ ¡ ¿ § # l

¤ [

You can navigate through the list of special characters by using the four-way scroll key. Once a character is highlighted, press Insert to insert the character into your message.

• PREDICTIVE TEXT INPUT

Predictive text input allows you to write messages quickly using your keypad and the phone’s built-in dictionary. It is much faster the standard mode method, because for each letter, you only press the corresponding key on your keypad once.

Activate/deactivate

At any text entry screen, press and hold Options. Predictive text is turned on and off, depending on its previous mode.

1 At any text entry screen, select Options > Predictive text and press Select. 2 Scroll to the language of your choice and press Select.

Note: The language setting affects the time and date formats of the clock,

alarm clock, and calendar.

Text entry

The illustration below simulates your display each time a key is pressed. For example, to write Nokia with predictive text on and with the English dictionary selected, press each of the following keys once:

the 6 key the 6 key the 5 key the 4 key the 2 key

•Press the 0 key to enter a space and begin writing the next word.

• If a displayed word is not correct, press the * key to see other matches. To return to the previous word in the list of matches, press Previous.

•If ? appears after a word, press Spell to add the word to th e dictionary.

•Press the 1 key to insert a period into your message.

•Press and hold the * key to display special characters. Press the * key again to cycle through all available characters.

•Press the # key to switch predictive text on or off and to use predictive text in various modes. As you press the # key, the following icons (not the descriptions) appear in the upper left of the display screen:

Uppercase text; standard mode is On Lowercase text; standard mode is On Sentence case text; standard mode is On

Sentence case text; predictive text is On Lowercase text; predictive text is On

Text entry

5 Contacts list

The contacts list can hold up to 500 contacts, with multiple numbers and text notes for each contact. The amount of numbers and text entries that you can save may vary, depending on length and the total number of entries in the contacts list.

• ADD NEW CONTACTS

Save a name and number

1 At the start screen, enter the phone number you wish to save. 2 Select Options > Save and press Select. 3 Enter the name and press OK.

Save (only) a number

1 At the start screen, enter the phone number you wish to save. 2 Press and hold Options.

Save an entry

1 At the start screen, select Contacts > Add contact and press Select. 2 Enter the name and press OK. 3 Enter the phone number , and press OK > Done.

Save addresses and notes

To save an address or note, you need to add it to an existing entry (contact).

1 Scroll down to the entry to which you would like to add an address or note. 2 With the entry highlighted, press Details. 3 Select Options > Add detail and press Select.

You can add an E-mail address, Web address, Street address, or Note to the entry.

4 Scroll to the address or note of your choice and press Select. 5 Enter the text for the note or address and press OK.

Save multiple numbers and text items

You can save different types of phone numbers and short text items per name to the contacts list. The first number you save for any entry is automatically set as the default, or primary number, but the primary number can always be changed.

1 At the start screen, scroll down to the entry to which you wish to add a phone

number or text item.

2 Press Details > Options > Add number or Add detail and press Select. 3 Scroll to General, Mobile, Home, Work, Fax, E-mail address, Web address,

Street address, or Note and press Select.

4 Enter the number or text for the type you have selected and press OK. 5 To change the type, select Change type in the options list.

Contacts list

You can also change which phone number is the default (primary) number for the contact entry.

1 At the start screen, scroll down to the entry you wish to change, and press

Details.

2 Scroll to the number you wish to set as default, elect Options > As primary

no. and press Select.

Set up voice tags

For more information on setting up voice tags and other voice features, see “Voice (Menu 10)” on page 56.

Caller groups

You can add contacts list entries to any of five caller groups, and then assign a unique ringing tone or graphic to that group. This enables you to identify callers from the group by their unique ringing tone or graphic.

SETUP A GROUP

1 At the start screen, press the Scroll down key to display a list of entries in your

contacts list.

2 Scroll to a name you would like to add to a caller group and press Details. 3 Select Options > Caller groups and press Select. 4 Scroll to the caller group to which you would like to add the name and

press Select.

OPTIONS

1 At the start screen, select Contacts > Caller groups and press Select.

Family, VIP, Friends, Business, and Other are the available caller groups.

2 Use the four-way Scroll key to highlight a group and press Select to display

the following caller group options:

Rename group—Rename the group to your preference. Group ringing tone—Set the ringing tone for the group. Group logo—Turn the graphic for the caller group on or off. Group members—Add or remove members from the caller group.

Set up 1-touch dialing

You can associate any entry in the contacts list with a key from 2–9; then dial those entries by pressing and holding the assigned key.

ASSIGN A KEY TO 1-TOUCH DIALING

1 At the start screen, select Contacts > 1-touch dialing and press Select. 2 Scroll to any empty slot and press Assign. 3 Enter the number (including the area code) and press OK, or press Find to

retrieve a number from the contacts list.

4 Enter a name for the number and press OK.

If 1-touch dialing is off, the phone displays a prompt asking if you would like to turn 1-touch dialing on.

5 Press Yes to activate 1-touch dialing.

CHANGE 1-TOUCH DIALING NUMBERS

1 At the start screen, select Contacts > 1-touch dialing and press Select. 2 Scroll to the 1-touch dialing entry you wish to change and select Options >

Change and press Select.

3 Enter the new number, or press Find to retrieve a number from the contacts

list, and press OK.

4 Enter a name for the entry and press OK.

DELETE 1-TOUCH DIALING NUMBERS

1 At the start screen, select Contacts > 1-touch dialing and press Select. 2 Scroll to the 1-touch dialing location you wish to delete and press Options. 3 Scroll to Delete and press Select. 4 Press OK to delete the key assignment.

• EDIT CONTACTS LIST ENTRIES

1 Scroll to the entry you would like to edit and press Details. 2 Scroll to the phone number you wish to edit and press Options. 3 Scroll to one of the following options and press Select:

Add voice tag—Add a voice tag to the contact. Edit number—Edit an existing phone number of the contact. Delete number—Delete a phone number from the contact. View—View the details of the contact. Change type—Change the number type to General, Mobile, Home, Work, or Fax or the detail type to E-mail, Web address, Street address, or Note. As primary no.—Change the default number of the contact. Add number—Add a number to the contact. Add detail—Add an address or note to the contact. Add image—Add an image or photo from the gallery to the contact. Caller groups—Add the contact to an existing caller group. Custom tone—Add a custom ring tone to the contact. Send bus. card—Send the contact as a business card to another phone. Send message—Create and send the contact a message. 1-touch dialing—Add the contact to your 1-touch dialing list. Edit name—Edit the name of the contact. View name—View the name of the contact. Delete—Delete the entire contact entry from your contacts list.

4 Edit the option to your preference and press OK.

• DELETE CONTACTS LIST ENTRIES

1 At the start screen, select Contacts > Delete and press Select. 2 To delete individual entries, scroll to One by one and press Select. 3 Scroll to the entry you wish to delete, press Delete > OK to confirm. 4 To delete the entire contents of your contacts list, scroll to Delete all. 5 Press Select, then press OK to confirm. 6 Enter the security code and press OK. See “Security code” on page 48 for more

information.

• VIEW THE CONTACTS LIST

1 At the start screen, select Contacts. The following menu items appear:

Search—Find a name or select from a list. Add new—Add a contact to your contacts list. Edit name—Edit an existing name. Delete—Delete a name and its associated numbers. Add number—Add a number to an existing name. Settings—Change the contacts list view or check the memory status of your

phone.

1-touch dialing—View or modify the list of 1-touch dialing numbers. Voice tags—Attach, listen to, or modify a voice tag to a contact in the

contacts list.

Own number—View your own phone number. Caller groups—View and edit the properties for any of the caller groups,

including Family, VIP, Friends, Business, or Other.

2 Scroll to an item and press Select to activate the feature or enter its submenu.

Search for a name

1 At the start screen, press the Scroll down key to display the contents of your

contacts list.

2 Press the key which corresponds to the first letter of the name for which you

are performing a search.

3 Scroll up and down to select a contact and press Details to view the details.

Configure settings

You can select how the contacts appear in your contacts list and view the amount of memory used or available in your phone.

1 At the start screen, select Contacts > Settings and press Select. 2 Scroll to one of the following options and press Select to enter the submenu:

Scrolling view—Select Name list, Name and number, or Name and image view.

Contacts list

Memory status—View the amount of phone memory used as well as the amount of phone memory available

Note: For more information on used and available memory, see “Shared memory” on page 3.

• SEND AND RECEIVE CONTACTS (BUSINESS CARDS)

You can send and receive an entry in your contacts list using IR or text message, if supported by your wireless provider.

Send a business card

You can send a business card using IR or as an text message to a compatible phone or other handheld device.

1 Highlight an entry from the contacts list that you wish to send and select

Details > Options > Send bus. card and press Select.

• To send the business card using IR, make sure the receiving device is set up to receive data using its IR port and select Via infrared .

• To send the business card as a message, select Via text message.

2 If you selected Via infrared (and the entry has multiple subentries), select

Primary no. or All details and press Select.

3 If you selected Via text message (and the entry has multiple subentries), select

Primary no. or All details and press Select.

4 Enter the number for your recipient or press Find to retrieve a number from

your contacts list.

5 Press OK and the business card is sent.

Receive a business card using IR

1 At the start screen, select Menu > Settings > Phone Settings > Infrared and

press Select to ensure IR is activated. When you receive the business card, your phone beeps and a message appears in the display.

2 Press Show > Save to save the business card in phone memory, or press Exit

> OK to discard the business card.

Messages (Menu 1)

6 Messages (Menu 1)

If you have subscribed to a mes sag ing ser vic e t hro ug h your wireless provider, you can send and receive messages to compatible phones that also subscribe to a compatible message service. enhanced messages, multimedia messages and e-mail messages.

• TEXT MESSAGES

Write and send

1 At the start screen, select Menu > Messages > Text messages > Create

message > Text > Edit message and press Select.

2 After a brief pause, the message entry screen appears in the display. 3 Compose a message using the keypad and press Options. 4 Scroll to Send and press Select. 5 Scroll to Add number and press Select. 6 Enter the recipient’s phone number, or press Find to retrieve a number from

your contacts list, and press OK.

TEMPLATES

Templates are short, pre-written messages which can be recalled and inserted into new text messages when you’re short on time.

1 At the start screen, select Menu > Messages > Text messages > Create

message > Text > Edit message and press Select.

2 Press Options, scroll to Use template and press Select. 3 Scroll to one of the available templates and press Select. 4 Enter the te xt into your new message and press Options > Send > Add

number and press Select.

5 Enter the recipient’s phone number, or press Find to retrieve a number from

your contacts list, and press OK.

Read and reply

When you receive a message, your phone beeps, and Message received and the unopened letter icon (

You may also be able to send and receive picture messages,

When sending messages, your device may display the words “Message Sent.” This is an indication that the message has been sent by your device to the message center number programmed into your device. This is not an indication that the message has been received at the intended destination. For more details, about messaging services, check with your service provider.

Note: To go quickly to the Create message display, press the Scroll left key from the start screen.

) appears in the display.

1 Press Show to read the message, or Exit to move it to your inbox.

When you have unopened messages in your inbox, is shown in the upper left corner of the start screen as a reminder.

Use the scroll keys (the Scroll up key or the Scroll down key) to view the whole message if necessary.

2 Select Options > Reply and press Select. 3 Select a Start reply with option, then compose your reply using the keypad. 4 Select Options > Send and press Select.

Options

When you create a text message, depending on the mode of text input you are using and the features supported by your wireless service provider, some or all of the following options are available:

Send—Send the message to one recipient. List recipients—Send the message to more than one recipient. Settings—Set the priority of the message. Save message—Select Archive to save the message in your archive; select

Templates to save the me ssage as one of your predefined templates. Clear text—Erase the text clipboard. Exit editor—Save the message to your archive automatically and leave the

message editor.

Insert contact—Insert a name from your contacts list into your message. Insert number—Insert a phone number or find a phone number in the

contacts list.

Use template—Insert a predefined template into your message. Insert picture—Insert a picture from the Gallery folder. Insert/Edit word—Enter or edit the text of a new word that might not appear

in the predictive text dictionary.

Insert symbol—Insert a special character into your message. Predictive text—Choose a predictive text language and turn predictive text on

or off. Matches—View matches found in the dictionary for the word you want to use.

When you read or reply to a text message, the following options are available:

Delete—Discard the message. Reply—Reply to the message. Create the message and press Options, then

Send. The sender’s phone number or e-mail is used as the default Use number—Choose Save, Add to contact, Send message, or Call. Save—Save the message to a folder. Forward—Forward the message to another phone number. Rename—Edit the title of the message.

Messages (Menu 1)

Change sending options

1 At the start screen, select Menu > Messages > Text messages > Message

Settings > Sending options and press Select.

2 Scroll to the setting you wish to change and press Select:

Priority—Set the priority of the note as Urgent or Normal and press Select. Delivery note—A note is sent to you confirming delivery of the message. Scroll

to On or Off and press Select. Send callback number—A callback number is sent to the recipient. Scroll to

Off or your phone number and press Select.

Settings

When the message memory is full, your phone cannot send or receive any new messages. However, you can set your phone to automatically replace old messages in the Inbox and Outbox folders when new ones arrive.

1 At the start screen, select Menu > Messages > Text Messages > Message

settings > Other settings and press Select.

2 Scroll to the setting you wish to change and press Select.

Message font size—Scroll to Small font or Large font and press Select. Message overwriting—Scroll to Outbox only, Inbox only, Outbox and inbox,

or Off and press Select. Save to outbox when sending—Scroll to Always save, Always prompt, or Off and press Select.

Enhanced messages

Enhanced messaging is a Network Service. If your wireless service provider supports this feature, enhanced messaging functions in the same manner as text messaging, but it offers additional options for the style and content of the message.

While creating an enhanced message, the following options are available:

Add-ins—Select Sound, Animation, or Picture to add to the message. Styles—Select Font type, Font size, or Text alignment of the message.

Note: If you try to send an enhanced message to a phone that does not support enhanced messaging, the enhanced messaging content will be stripped from the message, leaving only the text you have entered.

While viewing a received enhanced message, the following options are available:

Sound—Select Play sound or Save sound. Picture—Select Save picture. Animation—Select Save animation.

LINKED MESSAGES

You can send messages that exceed 160 characters, which will be sent as a series of two or more messages, also known as a linked message. In the navigation bar, you can see the message length indicator counting backwards from 160. For example, 10 (2) means that you can still add 10 characters for the text to be sent as two messages.

Using special (Unicode) characters take up more space. If there are special characters in your message, the indicator may not show the message length correctly. Before the message is sent, the phone will tell you if the message exceeds the maximum length allowed for one message. Cancel sending by pressing Cancel or save the message in the inbox.

• MULTIMEDIA MESSAGES

A multimedia message (MMS) is a Network Service. If your wireless service provider supports this feature, then the message can contain text, sound, and a picture. Your phone supports multimedia messages that are up to 45 kB. If the maximum size is exceeded, the phone may not be able to receive the message. Once you save the multimedia message, you can use the image as a screen saver or the sound as a ringing tone. In some networks, you may receive a message that includes an internet address where you can view the multimedia message.

Note: Only devices that offer compatible multimedia message or e-mail features can receive and display multimedia messages. Multimedia message objects may contain viruses or otherwise be harmful to your device or PC. Do not open any attachment if you are not sure of the trustworthiness of the sender.

Note: When your phone is dedicated to a call in progress, an application (such as a game), or an active web browser connection, the phone cannot

receive multimedia messages. The default setting of the multimedia message service is generally on. Multimedia messaging supports JPEG, GIF, PNG, OTA-BMP and WBMP picture

formats, and SP-MIDI and monophonic ringing tones. The appearance of a multimedia message may vary depending on the receiving

device. Copyright protections may prevent some images, ringing tones, and other content

from being copied, modified, transferred, or forwarded.

Write and send

1 At the start screen, select Menu > Messages > Multimedia msgs. > Create

message and press Select.

2 Enter the te xt of your message and press Options > Insert image or Insert

sound clip and press Select.

+ 70 hidden pages
