Nokia 1616 User Guide

Cyan

Magenta

Yellow

Black

xxxxxxx

Issue 1

Cyan

Magenta

Yellow

Black

2Contents

Cyan

Magenta

Yellow

Black

Contents

Safety 3

Get started 5

Insert the SIM card and
battery 5
Remove the SIM card 6
Charge the battery 6
Switch on and off 7

Your phone 8

Keys and parts 8
Main features 8
Calls 9
Write text 10
Message 11
Contacts 12
Multi-phonebook 13
FM Radio 14
Flashlight shortcuts in
standby mode 15

General
information 16

Accessories 17

Battery 17

Battery and charger
information 17
Nokia battery
authentication
guidelines 19

Taking care of your
device 19

Recycle 20

Additional safety
information 21

Small children 21
Operating
environment 21
Medical devices 21
Vehicles 22
Potentially explosive
environments 22
Emergency calls 23
Certification information
(SAR) 23

Cyan

Magenta

Yellow

Black

Safety 3

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.

SWITCH ON SAFELY

Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.

INTERFERENCE

All wireless devices may be susceptible to
interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.

Cyan

Magenta

Yellow

Black

4Safety

Cyan

Magenta

Yellow

Black

QUALIFIED SERVICE

Only qualified personnel may install or repair
this product.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do
not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

Cyan

Magenta

Yellow

Black

Get started 5

Cyan

Magenta

Yellow

Black

Get started

Insert the SIM card and battery

This phone is intended for use with the BL-5CB battery.

Safe removal. Always switch the device off and disconnect
the charger before removing the battery.

1 Place your finger in the recess at the bottom of the

device, and carefully lift and open the back cover (1).
2 Lift the battery, and remove it (2).
3 Insert the SIM card (3). Ensure the contact surface area

is facing down and the bevelled corner of the SIM card

is facing the bottom of the device.
4 Replace the battery (4) and back cover (5, 6, 7).

Cyan

Magenta

Yellow

Black

6Get started

Cyan

Magenta

Yellow

Black

Remove the SIM card

Press the release spring (1), and slide out the SIM card (2).

Charge the battery

Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the

charger from the device, then from the wall outlet.

Tip: To save energy, unplug the charger when the battery
is fully charged.

Cyan

Magenta

Yellow

Black

Get started 7

Cyan

Magenta

Yellow

Black

You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.

Switch on and off

Press and hold the end key.

Use the phone only in its normal operating position.

Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.

Cyan

Magenta

Yellow

Black

8 Your phone

Cyan

Magenta

Yellow

Black

Your phone

Keys and parts

Earpiece

1

2 Display

3 Selection keys

4 Navi™ key (scroll key)

5 Call key

6 End/Power key

7 Keypad

8 Microphone

9 Flashlight

10 Headset connector

(3.5mm)

11 Wrist strap eyelet

12 Charger connector

Main features

Select Menu and from the following:
