Nokia 6230 phone at a glance

Volume keys

Display screen

Power key

Earpiece

Loudspeaker

IR port

Left selection key

Talk key

Right

selection key

End key

Five-way scroll and selection key

Charger port

Keypad

Pop-Port

connector

Microphone

6230.ENv1_9310059.book Page 2 Friday, January 30, 2004 2:33 PM

Quick guide

Make a call Enter a phone number, and press the Talk key. Answer a call Press the Talk key. Answer call during call Select Options > Answer call.

End a call Press the End key.

Decline a call Press the End key

Mute a call Select Mute during a call.

Redial Press the Talk key twice.

Adjust call volume Press the Volume keys on the left side of the phone

Use the in-call menu Select Options during a call.

Save a name and number Enter a number, select Save, enter a name, and select OK.

Use 1-touch dialing Press and hold a key (2–8). You must assign a key to a

Look up a name Select Contacts > Find.

Check voice mail Press and hold the 1 key (contact your service provider

Write and send text messages

Send a picture message Select Menu > Messages > Text messages > Create

Read a new message If New Message appears, select Read, highlight the

Press Press a key briefly and release it.

Press and hold Press and hold a key for 2 to 3 seconds and release it.

during a call.

number in Contacts.

for details).

Select Menu > Messages > Text messages > Create message. Enter the message and select Send. Enter the number and select OK.

message > Options > Insert picture. Scroll to the picture you want and select View > Insert. Enter the text message and select Send. Enter the number and select OK.

message, and select Read again.

6230.ENv1_9310059.book Page 3 Friday, January 30, 2004 2:33 PM

LEGAL INFORMATION

Enhancements, Nokia 6230, and the Nokia Original Enhancements logos are trademarks or registered trademarks of Nokia Corporation. Other company and product names mentioned herein may be trademarks or trade names of their respective owners.

rights reserved.

Bluetooth is a registered trademark of Bluetooth SIG, inc.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO (A) DATA OR INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY; AND (B) OTHER USES SPECIFICALLY AND SEPARATELY LICENSED BY MPEG LA, L.L.C.

The information contained in this user guide was written for the Nokia 6230 product. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

6230.ENv1_9310059.book Page 4 Friday, January 30, 2004 2:33 PM

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This device may contain commodities, technology, or software that may only be exported in accordance with the U.S. Export Administration Regulations. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

6230.ENv1_9310059.book Page 5 Friday, January 30, 2004 2:33 PM

Manufactured or sold under one or more following US Patents. Asterisk (*) indicates design patents pending.

4868846 5519885 5827082 5966378 6112099 6266330

4969192 5526366 5835889 5970059 6115617 6282436

5001372 5553125 5839101 5987137 6118775 6285888

5045973 5557639 584884 5991716 6121846 6292668

5101175 5565821 5845219 5991857 6122498 6295286

5212834 5570369 5857151 5999523 6128322 6308084

5230091 5581244 5862178 6005857 6128509 6310609

5233634 5597102 5870683 6011853 6138091 6311054

5241284 5625274 5887266 6014573 6140966 6314166

5241583 5640395 5889770 6018277 6144243 6324412

5266782 5664004 5892475 6026161 6144676 6347218

5 3111 51 5664053 5898925 6028567 6148209 6356759

5311179 5669069 5907823 6029128 6151485 6359904

5317283 5677620 5914690 6038238 6151507 6363259

5331638 5678224 5914796 6043760 6163609 6370362

5335362 5692032 5915440 6047196 6164547 6370390

5353328 5699406 5917868 6049796 6167248 6377803

5378935 5699482 5920826 6050415 6170073 6393121

5384782 5701392 5926138 6055439 6178535 6430721

5390223 5729534 5926769 6060193 6185295 6434133

5396657 5729541 5930233 6069923 6188909 *29/170210

5400949 5734683 5946651 6072787 6195338 *29/170229

5416435 5754976 5956332 6081534 6199035 *29/170245

5442521 5760568 5956625 6084962 6201876 *29/170246

5444816 5782646 5956633 6088746 6219560

5446364 5794142 5960354 6094587 6240076

5479476 5802465 5960389 6097964 6240079

5487084 5805084 5963901 6105784 6249584

5493255 5805301 5966374 6108553 6259312

6230.ENv1_9310059.book Page 6 Friday, January 30, 2004 2:33 PM

6230.ENv1_9310059.book Page vii Friday, January 30, 2004 2:33 PM

Contents

Quick guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii

1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

ABOUT YOUR DEVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

NETWORK SERVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Shared memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2 Overview of functions . . . . . . . . . . . . . . . . . . . . . . . . 4

Multimedia messaging service (MMS). . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Camera, camcorder, and video player . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

MultiMediaCard memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Presence-enhanced contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

General packet radio service (GPRS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Java™ applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Polyphonic sound (MIDI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 About your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Find information about your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Start screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Accessibility solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Nokia PC Suite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connection settings service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Phone menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4 Basic operations . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Install the SIM card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Install the MultiMediaCard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Switch the phone on or off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Set the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

6230.ENv1_9310059.book Page viii Friday, January 30, 2004 2:33 PM

Make and answer calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Earpiece volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Options during a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5 Text entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Standard mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Predictive text input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Special characters and smileys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6 Phone security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Keyguard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

PIN code request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Call restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Fixed dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Closed user groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Security levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Access codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

7 Messages (Menu 1) . . . . . . . . . . . . . . . . . . . . . . . . 35

Linked messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Before you can send and receive messages. . . . . . . . . . . . . . . . . . . . . . 35

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Font size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Text and picture messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Multimedia messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Instant messages (IM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Voice messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Info message service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Service commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

8 Call log (Menu 2) . . . . . . . . . . . . . . . . . . . . . . . . . 60

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

View calls options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Missed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Received calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

6230.ENv1_9310059.book Page ix Friday, January 30, 2004 2:33 PM

Dialed numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Call times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Delete call lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Call duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

9 Contacts (Menu 3) . . . . . . . . . . . . . . . . . . . . . . . . . 63

Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Types of information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Save information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Change the primary number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Search for an entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Make a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Add an image to a name or number . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Edit an entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Delete names and numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Presence service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Subscribed names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Copy entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Business cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

1-touch dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Voice dialing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Info, service, and my numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Caller groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Select contacts view and memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

10 Settings (Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Tone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Time and date settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Personal shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

IM and presence settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Enhancement settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

6230.ENv1_9310059.book Page x Friday, January 30, 2004 2:33 PM

Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Restore factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

11 Gallery (Menu 5) . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Folders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Folder items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Edit an image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

12 Media (Menu 6) . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Media player. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Music player. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Voice recorder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

Media equalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

13 Organizer (Menu 7) . . . . . . . . . . . . . . . . . . . . . . . .112

Alarm clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

To-do list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Wallet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

14 Applications (Menu 8) . . . . . . . . . . . . . . . . . . . . . 127

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Countdown timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132

15 Services (Menu 9) . . . . . . . . . . . . . . . . . . . . . . . . 135

Set up for browsing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135

Sign on to the mobile Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Navigate the mobile Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Example of a mobile Internet site . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Appearance settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

6230.ENv1_9310059.book Page xi Friday, January 30, 2004 2:33 PM

Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Service inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

File upload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

File download. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Disconnect from the mobile Internet. . . . . . . . . . . . . . . . . . . . . . . . . . 140

Receive a call while online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Make a call while online. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Make an emergency call while online . . . . . . . . . . . . . . . . . . . . . . . . . 140

Options while online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

16 SIM services (Menu 10). . . . . . . . . . . . . . . . . . . . . 145

17 Hardware and enhancements. . . . . . . . . . . . . . . . . 146

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Enhancements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

18 Reference Information. . . . . . . . . . . . . . . . . . . . . . 151

Battery information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Enhancements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Enhancements, Batteries, and Chargers . . . . . . . . . . . . . . . . . . . . . . . 152

CARE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

ADDITIONAL SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Nokia one-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Appendix A Message from the CTIA. . . . . . . . . . . . . . . 163

Appendix B Message from the FDA . . . . . . . . . . . . . . . 167

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

6230.ENv1_9310059.book Page xii Friday, January 30, 2004 2:33 PM

6230.ENv1_9310059.book Page 1 Friday, January 30, 2004 2:33 PM

For your safety

1 For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the phone at a refueling point. Don't use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Don't use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

6230.ENv1_9310059.book Page 2 Friday, January 30, 2004 2:33 PM

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the End key as many times as needed to clear the display and return to the main screen. Enter the emergency number, then press the Talk key. Give your location. Do not end the call until given permission to do so.

• ABOUT YOUR DEVICE

The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, and 1900 MHz network. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the phone must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

• NETWORK SERVICES

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These Network Services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize Network Services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use Network Services. For instance, some networks may not support all language-dependent characters and services.

6230.ENv1_9310059.book Page 3 Friday, January 30, 2004 2:33 PM

For your safety

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Contact your service provider for more information.

• SHARED MEMORY

The following features in this device may share memory: contacts, text and multimedia messages, e-mails, voice tags, SMS distribution lists, calendar, to-do notes, Java™ games and applications, and the note application. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. For example, saving many contact entries may use all of the available memory. Your phone may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features may have a certain amount of memory specially allotted to them in addition to the memory shared with other features.

Note: Gallery files such as images, ringing tones, and video clips share a different memory. See “Gallery (Menu 5)” on page 98.

6230.ENv1_9310059.book Page 4 Friday, January 30, 2004 2:33 PM

2 Overview of functions

The Nokia 6230 phone provides many useful functions, such as a radio, alarm clock, calculator, wallet, calendar, and more. Your phone can also connect to a PC, laptop, or other device using the data cable, Bluetooth connection, or built-in infrared (IR) port. To personalize your phone, you can set your favorite ringing tones, configure the Go to menu, and select an Xpress-on™ color cover.

In addition, your phone has the following advanced features.

• MULTIMEDIA MESSAGING SERVICE (MMS)

Your phone is able to send and receive multimedia messages containing text, a picture or video clip, and sound such as polyphonic ringing tones. You can save pictures, video clips, and ringing tones to personalize your phone. In addition, you can easily send text messages and multimedia messages to multiple recipients.

See “Multimedia messages” on page 46 for more information.

• CAMERA, CAMCORDER, AND VIDEO PLAYER

Your phone has a built-in camera for taking still pictures and video clips. After you have taken a picture or video, you can attach it to a multimedia message and send it with MMS, save it as wallpaper in the standby mode, save it in a compatible PC using Nokia PC Suite software, and upload it to a Web address with the content image uploader. When you attach a picture to an entry in your list of contacts, the picture is displayed when your contact calls you.

See “Camera” on page 103 for more information.

• MULTIMEDIACARD MEMORY CARD

You can install a MultiMediaCard in your phone to provide up to 256 MB of extra memory. You can store images, video clips, music, and other data on the MultiMediaCard. The MultiMediaCard can be used as a folder in the Gallery menu.

See “Install the MultiMediaCard” on page 20 for more information.

6230.ENv1_9310059.book Page 5 Friday, January 30, 2004 2:33 PM

Overview of functions

• BLUETOOTH

Bluetooth wireless technology allows you to connect the phone to a compatible device with Bluetooth connectivity within 30 feet. You can use a Bluetooth connection to send business cards, calendar notes, images, video clips, and sound clips.

See “Bluetooth connectivity” on page 84 for more information.

• PRESENCE-ENHANCED CONTACTS

Presence-enhanced contacts enable you to conveniently share your availability information with your colleagues, family, and friends.

See “Presence service” on page 68 for more information.

• GENERAL PACKET RADIO SERVICE (GPRS)

GPRS technology allows mobile phones to send and receive data over a mobile network. Applications such as browsers, MMS, text messaging, and Java use GPRS. Your phone supports up to three simultaneous GPRS connections.

For more information on GPRS, see “GPRS, EDGE, CSD, HSCSD” on page 87.

Also, consult the Nokia PC Suite online help. Nokia PC Suite and all related software can be downloaded from the U.S. Mobile Phone products section of

www.nokia.com.

• JAVA™ APPLICATIONS

Your phone supports Java 2 Micro Edition, J2METM, and includes some Java applications and games that have been specially designed for mobile phones.

You may be able to download new applications and games to your phone from a PC with Java installer software or from some mobile Internet services.

See “Applications (Menu 8)” on page 127 for more information.

6230.ENv1_9310059.book Page 6 Friday, January 30, 2004 2:33 PM

• POLYPHONIC SOUND (MIDI)

Polyphonic sounds can be used in ringing tones, gaming sounds, and message alert tones. They consist of several sound components played at the same time, like an actual melody through a speaker. Your phone has sound components from over 128 instruments and it can play up to 24 instruments at once. The phone supports scalable polyphonic MIDI (SP-MIDI) format.

You can receive polyphonic ringing tones using a multimedia service (see “Read and reply” on page 50) or download them using the gallery menu [see “Gallery (Menu

5)” on page 98].

• BROWSER

Your phone has a built-in browser you can use to connect to selected services on the mobile Internet. You can view weather reports, check news or flight times, view financial information, and much more.

See “Services (Menu 9)” on page 135 for more information.

6230.ENv1_9310059.book Page 7 Friday, January 30, 2004 2:33 PM

About your phone

3 About your phone

Congratulations on your purchase of the Nokia 6230 mobile phone.

• REGISTER YOUR PHONE

Be sure to register your phone at www.warranty.nokiausa.com or call 1-888-NOKIA-2U (1-888-665-4228) so that we can serve you better if you need to call a customer center or to have your phone repaired.

•TERMS

This guide uses certain terms for the parts of the phone and the steps that you are asked to perform.

• Highlighted options on the screen are enclosed within a colored bar. The selection keys are used to act on the highlighted option.

• Left selection key and Right selection key are used to select the options on the left and right bottom corners of the screen.

• Five-way scroll and selection key is used to navigate through names, phone numbers, menus, and settings. It is also used to move the cursor up, down, right, and left when writing text, using the calendar, and in some game applications. Pressing the key briefly in the middle selects the item in the bottom center of the screen. The middle of the Five-way scroll and selection key is also called the Middle selection key. The top, bottom, left, and right edges of the

Five-way scroll and selection key are also called the Scroll up, Scroll down, Scroll left, and Scroll right keys.

• Select means to press the Left selection key or the Right selection

key, or to press the center of the Five-way scroll and selection key (the Middle selection key). To select an option, press the selection key below the menu item on the phone screen. In the illustration, press the Left selection key to select Go to, press the Middle selection key to select Menu, or press the Right selection

6230.ENv1_9310059.book Page 8 Friday, January 30, 2004 2:33 PM

key to select Names.

• Talk and End keys. Press the Talk key to place a call or to answer an incoming call. Press the End key to end a call or to return to the start screen.

• FIND INFORMATION ABOUT YOUR PHONE

The label on the back of your phone, underneath the battery and MultiMediaCard, contains the following information:

• Model number

• Phone type and FCC ID

• International mobile equipment identity (IMEI)

To access the phone label: 1 With the back of the phone facing you,

push the back cover release button.

2 Slide the back cover toward the top of

the phone to remove.

3 Remove the battery by lifting it as

shown.

Information label

6230.ENv1_9310059.book Page 9 Friday, January 30, 2004 2:33 PM

About your phone

4 Slide the MultiMediaCard to the left and

lift it out of the holder as shown.

•GET HELP

If you need help, Nokia Customer Care is available for assistance. We recommend that you write down the following information and have it available if you call.

• The IMEI printed on the back of the phone, beneath the battery

• Your zip code

Contact Nokia

Please have your phone or enhancement with you when contacting either of the numbers below.

Nokia Customer Care Center, USA Customer Care, Canada

Nokia Inc. 7725 Woodland Center Boulevard Suite 150 Tampa, Florida 33614

Tel: 1-888-NOKIA-2U (1-888-665-4228)

Fax: 1-813-249-9619

TTY: 1-800-24-NOKIA (1-800-246-6542) (hearing impaired only)

Nokia Products Ltd. 601 Westney Road South Ajax, Ontario L1S 4N7

Tel: 1-888-22-NOKIA (1-888-226-6542)

Fax: 1-905-427-1070

6230.ENv1_9310059.book Page 10 Friday, January 30, 2004 2:33 PM

Contact your service provider

To use the network services available in your phone, you will need to sign up with a service provider. In many cases, the service provider will make available descriptions of their services and instructions for using features such as:

•Voice mail

• Call waiting, call forwarding, and caller ID

•Messaging

• News and information services

• Selected mobile Internet services

Service providers may differ in their support of features. Before you sign up, make sure a service provider supports the features that you need.

Guide updates

From time to time, Nokia updates this guide to reflect changes. The latest version may be available at www.nokia.com/us.

Online tutorials

An interactive tutorial for this product may be available at the Web site

www.nokiahowto.com.

In-phone help

Many features have brief descriptions (help text) that can be viewed on the display. To view these descriptions, scroll to a feature and wait for about 15 seconds to allow the help text to appear. Select More to view all of the description (if necessary), or select Back to return to the menu.

To activate or deactivate help text: From the menus, select Settings > Phone settings > Help text activation > On or

Off. A confirmation message appears in the display indicating your selection.

6230.ENv1_9310059.book Page 11 Friday, January 30, 2004 2:33 PM

About your phone

• START SCREEN

The start screen is home base and indicates that the phone is in the standby mode.

Home

Signal strength

Left selection

Middle selection

Home—The name of your service provider may appear here.

Signal strength—A higher bar indicates a stronger network signal.

Battery level—A higher bar indicates more power in the battery.

Left selection key—Accesses the Go to menu from the start screen. See “Go to menu”

on page 11.

Middle selection key—Accesses the phone main menu from the start screen.

Right selection key—Accesses various functions:

• Names—Accesses the Contacts menu.

• A shortcut to a function that you have selected. See “Personal shortcuts” on page 83 to configure this shortcut.

Various indicators and icons may also appear on the start screen. See “Indicators and icons” on page 12 for more information.

Battery level

Right selection

Go to menu

The Go to menu gives you quick access to selected functions.

CHOOSE FUNCTIONS

1 From the start screen, select Go to > Options > Select options. 2 Scroll to the desired function from the list, and select Mark.

A mark appears in the box next to the selected function indicating that you have selected the function. Select Unmark to remove a function from the list.

3 Repeat the previous step to select or remove as many functions as you wish. 4 Select Done when you have added all desired functions. 5 At the confirmation prompt, select Yes.

6230.ENv1_9310059.book Page 12 Friday, January 30, 2004 2:33 PM

ORGANIZE FUNCTIONS

1 From the start screen, select Go to > Options > Organize. 2 Scroll to the function you wish to rearrange; then select Move. 3 Select Move up, Move down, Move to top, or Move to bottom from the list

of choices. The list of Right selection key functions is displayed in the new order.

4 Select Done. 5 At the confirmation prompt, select Yes to save the changes.

ACCESS A FUNCTION

From the start screen, select Go to; then select the desired function from the list.

Quick keys

From the start screen, each scroll key takes you directly to a function:

Scroll up—Activate the camera viewfinder.

Scroll left—Create a message.

Scroll down—Go to your list of contacts.

Scroll right—View the calendar.

Power saving

The phone automatically activates a digital clock display to save power when no function of the phone has been used for a few minutes. Press any key to deactivate the digital clock display. If you have not set the time, 00:00 is displayed.

Screen saver

You can select an image or video clip to use as a screen saver when the phone is in the standby mode. See “Set screen saver” on page 81.

Wallpaper

You can set the phone to display a background picture (wallpaper) when it is in the standby mode. See “Wallpaper” on page 80.

Indicators and icons

Icon Indicates...

You have one or more text or picture messages. See “Read a message” on page 41.

+ 56 hidden pages

Microsoft RH-12 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
