Nokia Internet Stick CS-19

3

2

5

1

6

???????/1

4

7

CS-19_QSG_FCC&IC_en1.fm Page 2 Wednesday, August 18, 2010 1:33 PM

10

8

11 12

13

14

9

15

CS-19_QSG_FCC&IC_en1.fm Page 3 Wednesday, August 18, 2010 1:33 PM

ENGLISH

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this RD-14 product is in compliance with the

essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of
the Declaration of Conformity can be found
at http://www.nokia.com/phones/
declaration_of_conformity/.

© 2010 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the

Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Other product and
company names mentioned herein may be
trademarks or tradenames of their respective
owners.

Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any of

the products described in this document
without prior notice.

To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.

The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.

The availability of particular products and
applications and services for these products
may vary by region. Please check with your
Nokia dealer for details, and availability of
language options. This device may contain
commodities, technology or software
subject to export laws and regulations from
the US and other countries. Diversion
contrary to law is prohibited.

CS-19_QSG_FCC&IC_en1.fm Page 4 Wednesday, August 18, 2010 1:33 PM

ENGLISH

SAFETY

Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.

SWITCH OFF IN RESTRICTED
AREAS

Switch the device off when
mobile phone use is not allowed or when
it may cause interference or danger, for
example, in aircraft, near medical
equipment, fuel, chemicals, or blasting
areas.

INTERFERENCE

All wireless devices may be
susceptible to interference,

which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may
repair this product.

KEEP YOUR DEVICE DRY

Your device is not water­resistant. Keep it dry.

During extended operation, the device
may feel warm. In most cases, this
condition is normal. If you suspect the
device is not working properly, take it to
the nearest authorised service facility.

■ Network services and costs

Your device is approved for use on the
(E)GSM 850, 900, 1800, and 1900, and
UMTS 900/1900/2100 HSPA networks. To

use the device, you need a subscription
with a service provider.

CS-19_QSG_FCC&IC_en1.fm Page 5 Wednesday, August 18, 2010 1:33 PM

ENGLISH

Using network services may result in data
traffic costs. Some product features

require support from the network, and
you may need to subscribe to them.

Introduction

The Nokia Internet Stick CS-19 is a
wireless modem that lets you transfer
data in cellular networks.

To use the device with your computer,
you need the connection manager
application that is automatically
installed when you connect the device
to the computer for the first time.

Read this guide carefully before using
the device. Also read the user guides
for the connection manager
application, your computer, operating
system, and any software that you use
with the internet connection set up
through the device.

For additional information, go to
www.nokia.com/support.

The operating temperature of this
device is -15°C to 35°C (5°F to 95°F),
and the storage temperature is -40°C
to 85°C (-40°F to 185°F).

Warning: The plug of this
device may contain a small

amount of nickel. Persons
who are sensitised to nickel may have
symptoms from prolonged skin
contact with the plug.

Read the user guide for the

connection manager

To read the user guide for the
connection manager application, you
must have a PDF reader application
installed on your computer. You can
download the PDF reader, for example,
from the Adobe website.

CS-19_QSG_FCC&IC_en1.fm Page 6 Wednesday, August 18, 2010 1:33 PM

ENGLISH

To access the user guide, select the
question mark (Help) in the main view
of the connection manager
application. The user guide is
displayed in the language that you
selected during the installation of the
application.

Supported hardware and

software

The USB plug on the device supports
the data transfer rates defined in the
USB specification version 2.0.

To use the device for data transfer
with your computer, the computer
must have a 500 MHz 32-bit (x86) or
64-bit (x64) processor or faster, a
compatible USB port, and 350
megabytes of available space on the
hard disk. You also need one of the
following operating systems:
Microsoft Windows XP (Service Pack 3
or newer), Microsoft Windows Vista,
Windows 7, Linux Ubuntu 9.04, or
Apple Mac OS 10.4, 10.5, or 10.6.

Microsoft Windows XP 64-bit Edition
is not supported.

Get started

The device contains the following
parts shown on the title page:
indicator light (1), cover of the
memo ry ca rd sl ot (2 ), USB plug
covered with a protection cap (3), and
cover of the SIM card slot (4).

Antenna locations

Your device has internal antennas. Avoid
touching the antenna area (5)
unnecessarily while the antenna is
transmitting or receiving. Contact with
antennas affects the communication
quality and may cause a higher power
