User Guide for Nokia NFC Shell for Nokia 3220

0903390

Issue 1

Gepe_UG_en.fm Page 2 Wednesday, February 16, 2005 12:39 PM

DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product CC-229D is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/.

FCC ID: PYAR2 IC: 661V-R2

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People, Xpress-on and the Nokia Original Enhancements logo are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

™ and all Java-based marks are trademarks or registered trademarks of Sun

Java Microsystems, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Covered by one or more of the following U.S. patents: 6,790,396; 6773644; 6,816,083; 6,810,238; 6,771,981; 6,522,520; 6,487,397; 6,456,487. Readers attention is directed to the following U.S. Patents which may cover future implementations of the product described in this user guide: 6,594,472; 6,563,927; 6,608,996, 6466299, 6,327,153. Other patents pending.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

Gepe_UG_en.fm Page 3 Friday, February 11, 2005 11:41 AM

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

This device may contain commodities, technology or software subject to US and other countries export control laws and regulations. Diversion contrary to law is prohibited.

0903390/ Issue 1

Gepe_UG_en.fm Page 4 Thursday, February 10, 2005 11:46 AM

Contents

FOR YOUR SAFETY............................................................................. 5

1. Overview......................................................................................... 6

What are RFID and NFC? ................................................................................................. 7

Nokia NFC shell .................................................................................................................. 8

Service Discovery application......................................................................................... 8

Tags........................................................................................................................................ 9

2. Installation ..................................................................................... 9

Check the phone’s network settings .......................................................................... 11

3. Tags............................................................................................... 11

Tag features....................................................................................................................... 11

Place tags........................................................................................................................... 12

Touch tags with RFID reader ........................................................................................ 12

Create your own service shortcuts ............................................................................. 12

4. Service Discovery application ..................................................... 13

Start and close the application.................................................................................... 13

Change application language....................................................................................... 13

Read, view, and save a shortcut .................................................................................. 14

Create and edit a shortcut ............................................................................................ 15

Give a shortcut ................................................................................................................. 16

Launch a shortcut and write into a tag .................................................................... 17

Delete a shortcut ............................................................................................................. 18

View the log ...................................................................................................................... 18

Care and maintenance..................................................................... 20

Gepe_UG_en.fm Page 5 Thursday, February 10, 2005 11:46 AM

FOR YOUR SAFETY

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

QUALIFIED SERVICE

Only qualified personnel may repair this device.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

Gepe_UG_en.fm Page 6 Thursday, February 10, 2005 11:46 AM

Overview

1. Overview

Nokia NFC shell allows you to use touch to quickly and conveniently access various services with your Nokia 3220 phone. By touching Radio Frequency Identification (RFID) tags, you can launch the service shortcut contained in the tag (call dialling, web browsing, and SMS sending).

Nokia NFC shell includes a Java™ application called Service Discovery and four RFID tags. You can create your own service shortcuts and write all service shortcuts stored in your phone memory into the tags. You can also give the service shortcuts stored in your phone to another Nokia 3220 equipped with the Nokia NFC shell. Your device and its enhancements may contain small parts. Keep them out of reach of young children.

This Nokia NFC shell is designed to be used in the Nokia 3220 phone that is available separately. For more information about the Nokia 3220 phone, see www.nokia.com.

Note: This user’s guide contains information and instructions for Nokia NFC shell. For instructions on how to use your Nokia 3220 phone, see the Nokia 3220 user guide.

For examples of how you can use your Nokia NFC shell, see www.nokia.com/nfc.

Gepe_UG_en.fm Page 7 Thursday, February 10, 2005 11:46 AM

Overview

■ What are RFID and NFC?

RFID

RFID technologies use radio waves to automatically identify individual objects. The most common method of identifying objects using RFID is to store a serial number that identifies the object on an RFID tag, and attach the tag to the object.

The RFID tag is able to transmit the information it contains to an RFID reader device. The RFID reader is a short-range device (reading range 0-5 cm) and it converts the radio waves returned from the RFID tag into a format that can then be passed on to an application in the phone.

To transmit data from the RFID tag to the RFID reader, Nokia NFC shell uses the radio frequency 13.56 MHz, which is the most widely used globally available frequency for RFID.

NFC

NFC (Near Field Communication) is a short-range radio frequency technology that evolved from a combination of contactless radio frequency identification (RFID) and interconnection technologies. By emitting a short-range radio signal, the NFC device supplies power to an otherwise inactive tag, allowing the device to read the tag or write data to the tag's memory. Operating over a distance of only very few centimetres, it allows users to read small amounts of data from tags, as well as to communicate with other devices, by a simple touch.

When touching a tag, the NFC device reads the data stored on the tag, and initiates the appropriate action after the user's confirmation. For example, it will open a web page, call a favourite number, or send an SMS.
