Nokia 8270

User Guide

Manufactured or sold under one or more of the following U.S. patents: 5737323, 5758278, 6076181, 5889770, 5802465, 5491718, 5859843, 6078570, 99162, 07278, 6088342, 6167038, 6148290, 5444816, 5699482, 4969192, 5754976, 5701392, 5793744, 5596571, 6009129, 6005889, 6055264, 6084471, 5990740, 6154455, 5854978, 5790957, 6205325, 6253075, 5440597, 5796757, 6292474, 6029065, 5887250, 5821891, 5887252, 5708656, 6047071, 5929813, 6025802, 5642377, D405445, D406583, D414189, D405784, D423515. Others: 4558302, 4901307, 5056109, 5101501, 5109390, 5265119, RE 32580.

The wireless phone described in this guide is approved for use in CDMA 1900 networks.

LEGAL INFORMATION

Part No. XXXXXX, Issue 1

Printed in Canada 4/2002

Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

The information contained in this user guide was written for Nokia phone

3280. The right to make changes and improvements to any of the products described in this guide without prior notice is reserved.

EXPORT CONTROLS

This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

1 FOR YOUR SAFETY

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual.

SWITCH OFF WHERE PROHIBITED

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Don't use a wireless phone while driving.

INTERFERENCE

All wireless phones may get interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any regulations or rules. Switch the wireless phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the wireless phone at a refueling point. Don't use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Don't use the wireless phone where blasting is in progress. Observe restrictions, and follow any regulations or rules.

USE SENSIBLY

Use only in the normal position. Don't touch the antenna unnecessarily.

[ 9 ]

QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

ACCESSORIES

Use only approved accessories. Do not connect incompatible products.

WATER-RESISTANCE

Your wireless phone is not water-resistant. Keep it dry.

CALLING

Ensure the phone is switched on and in service. Enter the phone number, including the area code, then press [handset up]. To end a call, press [handset down]. To answer a call, press [handset up].

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press [handset down] as many times as needed (for example, to exit a call, to exit a menu) to clear the display. Enter the emergency number, then press [handset up]. Give your location. Do not end the call until told to do so.

Note:You can also press and hold the 9 key to make an emergency call, if the emergency key 9 feature is activated.

[ 10 ]

2) Welcome

• BEFORE YOU BEGIN

This section provides information needed before you use your phone.

This guide describes the Nokia 8270 phone, which is approved for use in CDMA 1900 networks.

• UNDERSTAND NETWORK SERVICES

This guide describes a number of features known as network services. You must arrange for these special services through your wireless service provider.

Before you can use these network services features, you must subscribe to them through your service provider. Your service provider will instruct you on the use of these services. This guide informs you when you need to contact your service provider for more step-by-step information.

Note:Some networks may not support all language-dependent characters and/or services.

• VISIT NOKIA ON THE WEB

The latest version of this manual may be available on Nokia’s World Wide Web site at:

www.nokia.com

[ 11 ]

• CONTACT NOKIA

To help Nokia promptly answer your questions, please have your phone’s model number, ESN number, and your local zip code ready when you call Customer Service. The ESN and model number are on the back of your phone under the battery. If you’re calling about an accessory, please have it available for reference.

Nokia Customer Care Center 7725 Woodland Center Boulevard, Suite 150 Tampa, FL 33614 Tel: 1-888-NOKIA-2U (1-888-665-4228) Fax: 1-813-249-9619 TTY:1-800-24-NOKIA (1-800-246-6542)

Customer Care, Canada Nokia Products Ltd. 601 Westney Rd. South Ajax, Ontario L1S 4N7 Tel:1-888-22-NOKIA (1-888-226-6542) Fax:1-905-427-1070

[ 12 ]

3) Prepare your phone for use

• INSTALL THE BATTERY

Place the battery in the grooves on the back of your phone, then slide the battery upward until it clicks.

• CHARGE THE BATTERY

Before you use your phone and when the battery runs down, you need to charge it.

1 Connect the lead from the charger to the bottom of the phone.

2 Connect the charger to an AC wall outlet.

If the phone is turned on, the messages Charger connected and then Charging appear. Then

the battery power indicator bar starts to flash up and down (scroll).

• You can use the phone while the battery is charging.

• Important: Disconnect your phone from the charger if the phone becomes hot while you’re making a call.

• If the battery is totally empty, it might take a few minutes before the charging indicator appears on the screen.

• The time to charge the battery depends on the charger you use.

• The battery is fully charged when the battery indicator bar stops scrolling and the Battery full message appears (if phone is on).

[ 13 ]

3 Disconnect the charger from the AC outlet and the phone:

• When a charger is not in use, disconnect it from the power source.

• Do not leave the battery connected to a charger for longer than

a week. Overcharging the battery could shorten its life span. If left unused, a fully charged battery will discharge itself over time.

• REMOVE THE BATTERY

Note:Make sure the phone is off.

1 Press and hold the button at the top of the battery.

2 Slide the battery toward the bottom of the phone.

3 Lift the battery off the phone.

[ 14 ]

4) Get to know your phone

• KEYS AND SCREEN

Earpiece

Screen

Scroll keys

Talk key

Power key

Selection keys

End key

Voice mail

Special character keys

Number keys

Microphone

[ 15 ]

Keys

Power key

Switch the phone on or off (press and hold for more than one second

Selection keys

Perform the function indicated by the text on the screen above the key

Scroll keys

• Scroll menu items and move the highlighter line up and down in a list of displayed items

• Move the cursor to enter numbers and text

• Display the phone book

Talk key

• Make a call (enter phone number and press key)

•Answer a call

• Display a list of recently-dialed numbers (display the Start screen, then press this key)

End key

•End a call

• Silence the ringing for an incoming call (you can still answer the call by pressing )

• Return to the Start screen at any time

[ 16 ]

Warning: Do not switch on the phone where wireless phone use is prohibited, or where the use of a phone might cause interference or could be a danger. For more information, see “Important safety information” on p ag e 111.

To turn the phone on or off, press and hold the power key for a few seconds. To turn off the phone, you can also quickly press the power key

then press OK.

Number keys

Enter numbers and letters

Enter a space while entering text, press .

Call your voice mailbox, press and hold .

Make an emergency call, press .

Make a call using one-touch dialing (press and hold the appropriate number key)

Star key - Insert special characters

Pound key

• Change modes when entering text

• Type of text input (multitap/predictive)

• Letter case (upper/lower)

• Character type (letters/numbers)

Start screen

When you turn on your phone, a service provider screen (or a welcome note, if you have created one) appears for a moment, then the Start screen appears. The Start screen is the “home base” for your phone. To return to this screen, press at any time except during a call (unless you want to hang up).

[ 17 ]

Tip:While entering characters into your phone, if you press , the characters are not saved.

• NAVIGATION KEYS

Selection keys

Use the selection keys to navigate through and select the phone’s many options. At the Start screen, two options appear: Menu and Names. The selection keys are just below these options:

• The left selection key ( ) appears below Menu.

• The right selection key ( ) appears below Names.

At the Start screen, when you press the left selection key ( ), the menu item, Messages, appears. The text above the left selection key changes to Select and the text above the right selection key changes to Exit.

At the Start screen, when you press the right selection key ( ), a list of options for the Names (phone book) feature appears, along with the same Select and Exit options that appear when you select Menu.

This guide refers to the selection keys by the names that appear above them. Example: “Press Menu” means to press the selection key below the word Menu.

Scroll keys

Use the scroll keys ( and ) to:

• Scroll the menu items and move the highlighter line up and down in a list of displayed items

• Move the cursor (flashing, vertical line) when entering letters and numbers

• Display the phone book (at the Start screen, press to view a list of phone book entries)

[ 18 ]

Scroll bar

When you press Menu, a scroll bar appears on the far right side of the Start screen. This bar appears as a straight line with one tab, and it indicates your location in the menu.

As you progress through the menu, the tab moves lower on the scroll bar. If you move backward through the menu, the tab moves up.

• INDICATORS AND ICONS

Indicators

Signal strength - The signal strength of the

wireless network at your current location. The greater the number of bar segments, the stronger the signal.

Battery charge status - While the battery charges, the bar segments on the indicator move upward to show that the battery is charging. While the phone is not connected to a charger, the greater the number of bar segments, the greater the level of charge.

Earpiece volume - Appears when you adjust the earpiece volume ( and ) during a call.

Icons

Active call - A call is in progress.

Alarm - The alarm clock is set.

Keyguard - Keyguard is activated. This prevents accidental key presses. To deactivate it, press Unlock, then .

[ 19 ]

Letter mode (lower case) - Characters are entered as lower case letters. To switch to upper case letter mode, press . To switch to number mode, press and hold .

Letter mode (upper case) - Characters are entered as upper case letters. To switch to lower case letter mode, press .

Number mode - Characters entered are numbers. When you are entering letters, you can switch to the number mode by pressing and holding .

Reminder (To Do) - You have a calendar reminder to do something.

Reminder (Birthday) - You have a calendar reminder calendar that someone’s birthday is on that date.

Reminder (Call) - You have a calendar reminder to call someone.

Reminder (Meeting) - You have a calendar reminder of a meeting.

Roaming - Your phone is roaming outside its home system.

Silent tones - You selected the Silent profile (tones are off).

Special characters - Highlight a special character, then press Insert. To switch to this mode while you are entering letters, press .

Text entry (predictive, lower case) - The phone is ready for you to enter lower case letters in the predictive text input mode.

Text entry (predictive, sentence case) - The phone is ready for you to enter letters in the predictive text input mode. The first letter of the first word in each sentence will be upper case.

[ 20 ]

Text message - You have one or more new text messages.

Voice message - You have one or more new voice messages. To

call your voicemail box, press and hold .

[ 21 ]

5) Make and answer calls

• MAKE A CALL

1 If keyguard is active, press Unlock, then the

star key to deactivate it.

2 Enter the phone number (if necessary, enter a

1 and the area code).

If you make a mistake while entering the number, press to move the cursor to the left and to move it to the right. To delete the character to the left of the cursor, press Clear. To delete all characters, press and hold Clear.

3 Press . To end the call or to cancel the call, press .

Notes

• For information about blocking caller ID, See “Choose to block caller ID” on page 49.

• Your phone does not have a dial tone.

• For best signal reception, fully extend the antenna.

• Hold the phone as you would any other telephone, with the earpiece over your ear and the microphone near your mouth.

• It is normal for your phone to become warm during use. If the phone becomes too warm, it automatically drops the current call and returns to the Start screen. Until the phone cools, you will be unable to receive or make calls.

• END A CALL

To end a call or to cancel the call, press . To clear any characters from the screen, press again.

[ 22 ]

Answer a call

To answer a call, press . To end the call, press .

NOTES

• If the Anykey answer feature (Menu 4 - 1 - 4) is set to On, you can answer the call by pressing any key except or . However, if Keyguard is active, you must press to answer the call, even if the Anykey answer feature is set to On.

• If the wireless network cannot identify the caller’s phone number or if the caller has chosen to block caller ID, the message Caller ID unavailable or Caller ID blocked may appear. If two entries in your phone book have the same phone numbers for both entries, the caller’s name does not appear when they call.

• If you want to stop your phone quickly from ringing (for example, if you’re in a public place), press the End key . As long as the caller’s phone number (or name) remain on the screen, you can still answer the call.

Adjust the earpiece volume

During a phone call, you can adjust the volume for your phone’s earpiece:

• The top volume key increases volume, and the bottom one decreases the volume. The volume keys only adjust volume during phone calls.

• If an accessory, such as a headset or a handsfree device or one with its own loudspeaker, is connected to your phone, the volume keys will adjust the volume for that accessory as well.

Redial the last-dialed number

To return to the Start screen (press ), then press two times.

Get a strong signal

Your phone operates on radio waves, and the reception quality depends on the radio signal strength in your area. A wireless network maintains the radio coverage, and the quality of calls on a wireless phone depends on the wireless radio signal strength.

[ 23 ]

Tip:For best results, fully extend the antenna. As with all radio transmitting devices, do not touch the antenna unnecessarily when the phone is on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level.

An indicator on the left of the Start screen displays the radio signal strength. More segments mean a stronger signal. To improve reception, move your phone slightly; if you’re indoors, move toward a window.

Your phone is optimized for digital service in a compact size. When your phone operates in analog mode, the service area where you can make and receive calls may be smaller.

Keep calls private

The Voice Privacy feature encrypts the voice channel so that no one can eavesdrop on your phone conversations. Voice Privacy is a network service, so you must contact your service provider to access the feature.

By default, the voice privacy setting on your phone is set to Off. To turn it on:

1 Press Menu 4 - 4 -1 (Settings - Network services - Voice privacy).

2 Scroll to On, then press OK.

During a call, Voice Privacy notifies you that it is active with a beep and the message Voice privacy active on the screen. During a call, your phone sounds two short beeps and displays the message Voice privacy not active if voice privacy is lost.

[ 24 ]

6) Use phone menus

• NAVIGATE MENUS

A menu lists choices that appear on your phone’s screen. To navigate menus, you can scroll or use shortcuts.

Scroll through menus

You can navigate menus by scrolling through them:

• Menu appears above the left selection key only while the Start screen is displayed. To display the Start screen, press .

• To scroll through menus, select Menu, and press and .

• To select an item, press the selection key (Select, OK, or Options).

• To return to the previous screen, press Back or Exit.

• To return to the Start screen, press .

• If you highlight an item and return to a previous screen or the Start screen, the highlighted menu item will not be selected.

• If you use your keypad to enter characters and then return to the previous screen or the Start screen, the characters will not be saved.

Use a shortcut

To navigate to a menu item quickly without scrolling, use a menu shortcut. A shortcut number for each menu item appears in the upper right corner of the screen. For example, to adjust the ringing volume, display the Start screen by pressing , then press Menu 3 - 1 - 2 - 2. Don’t pause for more than two seconds between key presses.

Note:The number of main menus in your phone, determines whether you may need to press the 0 key before you enter a shortcut that begins with “1” and is followed by the 1 key and any other key(s). For example, to display the Inbox menu (1 - 1 - 2), press Menu .

Most menu items in your phone have a brief help message. To view the help message for a menu item, scroll to an item and wait for 10 seconds.

[ 25 ]

• LIST OF MENU SHORTCUTS

Your phone’s menu may differ from the following list. The list depends on the network services to which you subscribed and the accessories you are using. If you have any questions, call your service provider.

MESSAGES

Text messages (0-1-1)

Write new* (0-1-1-1) Inbox (0-1-1-2)

Outbox* (0-1-1-3) Saved (0-1-1-4) Erase (0-1-1-5)

All read (0-1-1-5-1) All in inbox (0-1-1-5-2) All in outbox (0-1-1-5-3) All saved (0-1-1-5-4)

Voice messages (0-1-2)

Listen to voice messages (0-1-2-1)

Voice mailbox number (0-1-2-2) Welcome note (0-1-3) Minibrowser messages* (0-1-4)

* Availability depends on your arrangement with your service provider.

CALL LOG

Missed calls (2-1)

Received calls (2-2) Dialed calls (2-3) Clear call lists (2-4)

All (2-4-1)

Missed (2-4-2)

Received (2-4-3)

Dialed (2-4-4) Call timers (2-5)

Last call (2-5-1)

All calls (2-5-2)

Life timer (2-5-3)

Clear timers (2-5-4)

[ 26 ]

PROFILES

Normal* (3-1)

Select (3-1-1) Customize (3-1-2)

Ringing options (3-1-2-1) Ringing volume (3-1-2-2) Ringing tone (3-1-2-3) Vibrating alert (3-1-2-4) Keypad tones (3-1-2-5) Warning and game tones (3-1-2-6) Message alert tone (3-1-2-7) Lights** (3-1-2-8) Automatic answer** (3-1-2-9)

Silent (3-2) Meeting (3-3) Outdoor (3-4) Pager (3-5) Handsfree ** Headset **

* Menu items that appear under the Normal profile also appear under all other profiles, but the second digit of the shortcut differs. For example, the shortcut for the Ringing options menu item for the Normal profile is 3-1-2-1; for the Silent profile, the shortcut is 3-2-2-1.

** This menu item does not appear until the phone has been connected to a handsfree/headset device at least once.

SETTINGS

Call settings (4-1)

Emergency key 9 (4-1-1) Automatic redial (4-1-2) Calling card (4-1-3) Anykey answer (4-1-4) Minibrowser confirmation* (4-1-5)

Phone settings (4-2)

Clock (4-2-1) Alarm clock (4-2-2) Touch tones (4-2-3)

[ 27 ]

Restore factory settings (4-2-4)

Language (4-2-5) Security settings (4-3)

Restrict calls (4-3-1)

Access codes (4-3-2) Network services (4-4)

Voice privacy* (4-4-1)

Call forwarding** (4-4-2)

Call waiting** (4-4-3)

Send own caller ID with next call** (4-4-4)

Network feature setting (4-4-5)

NAM selection (4-4-6)

NAM update* (4-4-7)

Automatic update of service* (4-4-8)

* Availability depends on your arrangement with your service provider.

** This menu item will not appear until the feature has been activated. See “Choose to block caller ID” on page 49.

SYSTEM*

Home area (5-1)

Automatic A (5-2) Automatic B (5-3)

* The list of menu items may differ according to service provider.

GAMES

Memory/Pairs (6-1) (may vary by service provider)

Snake (6-2) Logic (6-3) Dice (6-4)

CALCULATOR CALENDAR MINIBROWSER*

* Availability depends on your arrangement with your service provider.

KEYGUARD

[ 28 ]

7) Enter characters into your phone

Note:To enter characters quickly into a mobile message, see

“Working with predictive text input” on page 76.

• ENTER CHARACTERS (EXCEPT IN A PHONE NUMBER FIELD)

Use the following guidelines when entering characters into any field except a phone number field (for example, the Name field in your phone book, a note in your calendar, or a mobile message):

Enter letters

To enter a letter that appears on a key, press the key as many times as necessary until the letter appears. For example, to enter the letter “a”, press the 2 key ( ) once. To enter the letter “c”, press the 2 key ( ) three times.

Change letter case mode

To change the mode that controls whether letters you enter are upper case (capital) or lower case , press the pound key ( ).

Enter numbers

To enter one or just a few numbers, press the appropriate number key as many times as necessary until the number appears. To enter many numbers, it is easier to change to number entry mode (press and hold the pound key ().

Erase characters

To erase one character, position the cursor to the right of the character, then press Clear. To erase all displayed characters, press and hold Clear.

Change between letter entry mode and number entry mode.

[ 29 ]

To change between letter entry mode ( / ) and number entry mode (123), press and hold the pound key ( ).

Enter a space

To enter a space, press the ( ).

Enter special characters

To quickly enter one of the most common special characters, press ( ) several times until the character appears. To see a list of all special characters, press ( ). Scroll until the character you want to insert is highlighted, then press Insert. To move up and down quickly between rows of characters, press ( ). To move quickly to the last character in

the last row, press .

• ENTER CHARACTERS INTO A PHONE NUMBER FIELD

While entering numbers into a phone number field, press the star key ( ) as many times as necessary until one of the following special characters appears:

* Bypass an automated attendant.

+ Precede an international telephone number.

p Create a pause when a number is dialed. The numbers you enter after

this special character are automatically sent as touch tones after a

2.5-second pause. For example, the characters after the “p” could be a PIN number that you are required to enter when you call the phone number.

w Create a wait when a number is dialed. Your phone “waits” for you to

press before it sends the string of numbers as touch tones. The difference between “p” and “w” is that if you use “w”, you can control when the touch tones are sent.

[ 30 ]

8) Use the phone book

Note:Your phone book stores up to 250 names with phone

numbers. Numbers can contain 32 digits; names can contain 26 characters. Make entries unique; you cannot store identical names in your phone.

Example: You can’t have one entry for John Jones with a home number and another entry for John Jones with a work number. You need to store the names as John Jones Work and John Jones Home.

If you enter a name that is already in your phone book, the message Replace? appears, followed by the stored name. Press Back to end this sequence without replacing the name.

• USE PHONE BOOK MENUS

The phone book has several menus. These menus appear when you press Names. Use the scroll keys to move to the menu you want to use.

Add new Enter new names and numbers.

Options

One-touch dialing

Erase all

Own number

Search for a specific name.

Choose a scrolling view and show the memory status.

Assign one to one-touch dial locations (speed dialing). See “Use one-touch dialing” on page 62.

Erase all names and numbers. To erase one name and number at a time, while viewing the name press Details or Options. Scroll to Erase. Press Select.

Display your own phone number.

[ 31 ]

Change views

You can view your phone book in three different ways:

Name list

Name+number

Name only

Shows all the names that are stored in your phone book. Three names appear on the screen at a time.

Shows individual names and numbers. One name appears on the screen with its corresponding phone number. Name + number is the default setting.

Displays individual names. To view the phone number, press Details and scroll up or down.

In all views, use the scroll keys to move through the list of names.

Select a scrolling view

You can select the scrolling view that you prefer:

1 From the menu, press Names.

2 Scroll to Options. Press Select.

3 Highlight Scrolling view, and press Select.

4 Scroll until the name of the desired view appears. Press OK.

• ADD NAMES AND NUMBERS

You can add names and numbers to your names list:

1 Press Names.

2 Scroll to Add new, and press Select.

3 Using the keypad, enter the name. Use the key to switch

between upper and lowercase letters.

4 Press OK.

5 Enter the phone number. Press OK.

[ 32 ]

You can also enter numbers by using a shortcut from the Start screen:

1 Enter a phone number, and press Save.

2 Enter a name at Name.

Note:Step 2 is optional.

3 Press OK.

• CHANGE A STORED PHONE NUMBER

You can change a number without changing its associated name.

1 Press Names.

2 When Search appears, press Select.

3 Enter the first few letters of the name of the phone book entry you

want to change, and press OK.

If you chose Name only or Name list as your scrolling view, continue to step 4. If you chose Name+number as your scrolling view, proceed to step 5.

4 Press Details to view the number.

5 Press Options.

6 If Edit is not highlighted, scroll to it. Press Select.

7 Press OK. The associated number appears. To move the cursor, scroll

up and down. To erase one character, press Clear. To erase all characters, press and hold Clear.

8 Enter the new number, and press OK.

• RECALL AND REDIAL NUMBERS

You can recall and dial numbers using one of four methods.

To recall and dial a number:

[ 33 ]

1 At the Start screen, press or to display the names and

associated numbers that are stored in your phone book.

2 Scroll to the appropriate name. Press to dial the associated

number.

1 At the Start screen, press Names.

2 Enter the first few letters of the name you want to call.

3 When the appropriate name/number appears on the screen, press

to dial this number.

1 At the Start screen, press Names.

2 At Search, press Select.

3 Enter the name of the person you want to call, and press OK.

4 When the appropriate name/number appears on the Start screen,

press to dial this number.

1 Or press and scroll through the dialed calls list and press the

Talk key again to dial the desired number

• ERASE STORED NAMES AND NUMBERS

Note:You cannot undo Erase functions, so be careful!

1 Using one of the methods described in “Recall and redial numbers” on

page 33, recall the stored name and its associated number.

If you chose Name only as your scrolling view, continue to step 2.

If you chose Name+number as your scrolling view, proceed to step 3.

2 Press Details.

[ 34 ]

3 Press Options.

4 Scroll to Erase. Press Select. (Erase? appears.)

5 Press OK to erase the name and associated number.

• ERASE THE ENTIRE PHONE BOOK

You can erase the contents of your phone book. Note that this action cannot be reversed! Once you have performed this procedure, all the stored information in your phone book is erased.

To erase all the contents of your phone book:

1 Press Names.

2 Scroll to Erase all. Press Select.

The message Are you sure? appears.

3 If you truly want to erase the entire contents of your phone book,

press OK.

The Security code field appears.

4 Enter your security code, and press OK.

• CHECK MEMORY STATUS

You can check to see how many free and in-use memory locations are in your phone book:

1 Press Names, and scroll to Options. Press Select.

2 Scroll to Memory status. Press Select.

A message appears that says Phone: xx free, xx in use, where xx indicates the number of memory locations (phone book entries.)

[ 35 ]

9) Use voice mail

Voice mail is a network services feature. Colleagues who miss you when they call can leave a voice message, which you can retrieve later.

• RETRIEVE A MESSAGE

You will be notified when a voice message is available:

• Your phone beeps when you receive a voice message. The message New voice message appears on the screen, along with the icon.

• If you receive more than one voice mail message, your phone may display the number of messages that you received. This feature is

dependent on your wireless network provider.

Note:To use voice mail, you need to learn the voice mail system’s various greetings, passwords, and prompts. Your service provider can furnish instructions.

• SET UP YOUR VOICE MAILBOX

As part of your network’s voice mail feature, your service provider gives you a voice mailbox phone number. Save this number in your phone to make getting your voice messages quick and convenient.

1 Press Menu 0 -1 - 2 - 2 (Messages - Voice messages - Voice

mailbox number).

2 Enter your voice mailbox phone number.

3 Press OK.

•Press Yes if you want to save a hidden voice mailbox password in

your phone.

•Press No if you don’t.

4 If you selected Yes, enter your security code.

[ 36 ]

5 Press OK.

6 Enter your voice mailbox password, and press OK.

Your voice mailbox number can be up to 32 digits long and is used until it’s changed. Therefore, if your phone number changes, you may need to change your voice mailbox number along with it.

• SET GREETINGS AND PASSWORDS

The greetings and passwords may vary in different wireless systems. If you need information about how to record your greeting or how to store your password, contact your service provider.

Note:If you store your voice mailbox password in your phone, the phone immediately sends the password after you dial your voice mailbox number.

• LISTEN TO YOUR VOICE MESSAGES

Note:The way you listen to your voice messages may vary

depending upon your service provider. Call your service provider if you have any questions.

1 When your phone alerts you to new voice messages, press Listen and

follow the instructions given on the phone.

2 If you prefer to listen to your messages later, press Exit.

3 To listen to your voice messages at a later time:

Press and hold the 1 key.

Press Menu 0 -1 - 2 - 1 (Messages - Voice messages - Listen to voice messages).

The message Calling voice mailbox appears on the screen. Follow the prompts to access your messages.

[ 37 ]

Voice message notification

A caller who leaves a voice message can specify a priority level if your network supports this feature:

• New voice message: This normal priority message can be sent by anyone.

• Urgent voice mail: The person who sends an urgent message is requesting an immediate reply. The urgent message can be sent by anyone.

• Emergency voice mail: The emergency message can only be sent by a network operator or person in authority when life or property is threatened.

New voice message notifications overwrite older ones, regardless of the priority level. For example, if Emergency voice mail appears and you receive a new voice message of normal priority, the emergency message notification disappears and New voice message appears.

Clearing the voice message icon

In most networks, the voice message icon is automatically cleared a few seconds after you listen to your last new message. If the network where you are using your phone does not automatically clear the voice message icon, you can manually clear the icon:

Press Menu 0 - 1 - 2 - 3 (Messages - Voice messages - Clear voice message icon), then press Clear.

[ 38 ]

10) Work with the call log

The Call log (Menu 2) records information about the last 10 calls made, received, or missed:

• Phone number associated with the call

• Date and time when the call connected

The call log records the length of the most recent call you made or received, the total of all calls you made or received during a time period (Call timer), and the total duration of all calls you make or receive during the lifetime of your phone (Life timer).

NOTES

• The call log records missed calls only if the phone was on and in your service provider’s area when you received the call.

• If you chose the Forward if not answered option in “Use call forwarding” on page 46, the call log records the call as missed.

• VIEW INFORMATION ABOUT RECENT CALLS

Use the menu shortcuts to display the type of recent call list to view:

• Missed calls - Menu 2 - 1

• Received calls - Menu 2 - 2

• Dialed calls - Menu 2 - 3

To view dialed calls, you can also press , then scroll.

Note:If necessary, scroll the list until the number (or name) appears. To call the number for the displayed item quickly, press

1 Press Options, and scroll to the appropriate option:

• Call time - Shows the date and time of day when the call was

connected. (Appears only if the clock has been set.)

[ 39 ]

• Edit number - Allows you to edit the number on the screen.

• Save - Allows you to add the phone number to your phone book.

• Erase - Allows you to erase the entry from the call log.

• View number - Allows you to view the associated phone number in your phone book. (Appears only if a name from your phone book appears on the screen.)

2 Press Select.

• CLEAR THE RECENT CALLS LIST

Note:Logged calls that were cleared from a call list cannot be

recovered.

1 Press Menu 2 - 4 (Call log - Clear call lists).

2 Scroll to All to clear the logged calls from all lists: Missed, Received,

or Dialed.

Note:When you clear the Dialed calls list, the list that appears when you press and a scroll key is also cleared.

3 Press OK. If you chose All, enter your security code, then press OK.

The logged calls are cleared from the chosen list(s).

• VIEW THE DURATION OF CALLS

View the duration of the last call

Press Menu 2 - 5 (Call log - Call timers). The duration of the last call appears. (If you choose to show the current call timer on the Start screen, you can see it during your call. To show it, see “Show/hide the current call timer” on page 41.)

[ 40 ]

View the total duration of all calls

Your phone uses two timers to record the total duration of all calls:

CALL TIMER

The call timer can be cleared (reset to zero), so it is useful for monitoring how much talk time you have used. It records the total time of all calls since the timer was last cleared. To view the call timer value:

1 Press Menu 2 - 5 (Call log - Call timers).

2 Scroll to All calls. The call timer value is displayed.

Note:Your phone has a separate timer for each NAM assigned to

your phone. The timer values apply to the currently-selected NAM.

LIFE TIMER

The life timer records the total duration of all calls for the entire life of your phone. This timer cannot be reset. To view the call timer value:

1 Press Menu 2 - 5 (Call log - Call timers).

2 Scroll to Life timer. The life timer value is displayed.

• CLEAR (RESET) THE CALL TIMER

Note:After this call timer is cleared, the value cannot be

recovered. Before you clear the call timer, record the value.

1 Press Menu 2 - 5 - 4 (Call log - Call timers - Clear timers).

2 Enter your security code, and press OK. The timer value is cleared.

• SHOW/HIDE THE CURRENT CALL TIMER

You can show the current call timer on the screen to view during a call.

1 Press Menu 2 - 5 (Call log - Call timers).

2 Press Details, and press Select.

3 Scroll to On (show) or Off (hide). Press OK.

[ 41 ]

11) Use advanced calling features

• SET IN-CALL OPTIONS

Your phone allows you to use several features uring a call. dThese features are in-call options.

Note:Many in-call options are network services features that may require a subscription from your service provider.

You cannot use all options at all times. This section explains when you can use a certain option.

1 To access an option during a call, press Options.

2 Choose from some or all of the following options:

Touch tones

New call

Mute

Names

Allows you to enter a touch tone string manually or search for a string in your phone book.

Allows you to place the call to the third party when making a conference call. See “Make a conference call” on page 45.

Allows you to access the Menu.

Allows you to mute the microphone. If your microphone is already muted, Mute will change to End mute.

Allows you to access the phone book.

[ 42 ]

• USE NETWORK FEATURE CODES

Call forwarding, Call waiting, and Send own caller ID with next call are network services available through your service provider. When you subscribe to these services, your service provider gives you a feature code that you store in your phone to activate the service. Your service provider may have stored feature codes in your phone. A separate deactivation code is used to deactivate the service.

The network service name will not appear in the menu until you store the activation code. After you store the activation and deactivation codes, you can use the menu to activate and deactivate the service.

Note:If your phone has more than one phone number programmed into the NAM, stored feature codes apply only to your primary phone number, or NAM 1.

Store network feature codes

1 Press Menu 4 - 4 - 5 (Settings - Network services - Network

feature setting).

2 Enter the feature code (for example, ), and press OK.

3 Scroll to the service name for that code, and press Select.

For example, enter the call forwarding feature code, scroll until the call forwarding option you want to select appears, then press Select.

Activate network features

Note:Before you can activate a network feature, you must store

the appropriate feature code in your phone.

1 Use the appropriate menu shortcut for the feature you want to activate

(Settings - Network services - feature name):

• Call forwarding - Menu 4 - 4 - 2

• Call waiting - Menu 4 - 4 - 3

• Caller ID - Menu 4 - 4 - 4

2 Scroll to Activate, and press OK.

[ 43 ]

The phone calls the network to confirm activation of the feature. After network confirmation, the feature is available for use.

Deactivate network features

1 Use the appropriate menu shortcut for the feature you want to deactivate

(Settings - Network services - feature name):

• Call forwarding - Menu 4 - 4 - 2

• Call waiting - Menu 4 - 4 - 3

• Caller ID - Menu 4 - 4 - 4

2 Scroll to Cancel, and press OK.

Your phone calls the network to confirm deactivation of the feature. After the network confirms deactivation, the feature is no longer available for use until you activate it again.

• USE CALL WAITING

Note:Call waiting is a network services feature that may require a subscription from your service provider.

During a call, if you receive another call, the call waiting feature causes your phone to beep. Before you can use call waiting, you must store the call waiting feature code and activate the feature. See “Use network feature codes” on page 43.

Note:Call waiting may not be available in all wireless systems.

Contact your service provider for details and availability.

• To answer an incoming call, press .

• To switch from one call to another, press .

• To end both calls, press .

[ 44 ]

• USE CALLER ID

This network service helps identify incoming calls. Contact your service provider for details.

When Caller ID is active, your phone may display the caller’s phone number. The caller’s name may also display if their name and number has been stored in the phone book or if the wireless network supports it.

Call or Call-caller ID unavailable will display when the wireless network doesn’t recognize the calling number. Also, Call-caller ID blocked may display if the calling party has blocked caller ID.

Note:If you have stored a number more than once in your phone book, and that number is stored each time with a different name, then a name will not appear when someone calls from that number. See “Use the phone book” on page 31 for details on your phone book.

• MAKE A CONFERENCE CALL

You can add a third party to a call (conference call). During a call:

• Dial the phone number of the third party, then press , OR...

• Scroll to the third party’s phone number in your phone book, then press , OR...

•Press Options. Scroll to New call. Press OK. Enter the phone number. Press OK.

When the third party answers, press to connect all parties. To end the call with both parties, press .

Note:To place one party on hold, press again. (If you place a party on hold, you cannot rejoin all three parties in the same conversation.) If you press a third time, the party you placed on hold rejoins the call, and the second party is placed on hold.

[ 45 ]

• USE CALL FORWARDING

You can forward incoming calls to another number. Call forwarding is a network services feature that may require a subscription through your service provider.

This procedure assumes that you stored the Call forwarding feature code in your phone and activated the feature. If you have not completed these steps, you may be able to enter the code manually when you forward your calls. Just enter the feature code (for example, ) followed by the phone number where you will forward your calls, then press .

1 Press Menu 4 - 4 - 2 (Settings - Network services - Call forwarding). 2 Scroll to the desired call forwarding option:

• Forward all calls - Forwards all incoming calls.

• Forward if busy - Forwards calls only when you’re on your phone and do not have voice mail.

• Forward if not answered - Forwards calls if you don’t answer. Use this option when you want to give your phone to someone for a short period of time, but you don’t want them to answer the phone. For example, you could use this option if you give your child the phone to take out, in case of an emergency, but you still want to receive any incoming calls made to this phone.

• Forward if out of reach - Forwards calls if you are out of the serving wireless network or if your phone is turned off.

• Cancel call forwarding - Cancels call forwarding.

3 Press Select.

4 If you chose an option other than Cancel call forwarding, enter the

phone number where your calls are to be forwarded (or press Search to find the number in your phone book). Press OK.

Wait for your phone to call the network and confirm your choice. If your choice is confirmed, the feature is available for use.

[ 46 ]

• REDIAL AUTOMATICALLY

If you make a call and the line is busy because of problems in the wireless network, your phone can automatically redial the number three times. Press

Menu 4 - 1 - 2 (Settings - Call settings - Automatic redial). Scroll to On. Press OK. To stop a series of redialing attempts, press Quit or .

• USE A CALLING CARD

The calling card feature allows you to store calling card information in your phone, making it easy for you to make a calling card call quickly. Your phone can store information for four calling cards.

Determine the dialing sequence for your card

Before you store the calling card information in your phone, determine the dialing sequence for your calling card. This sequence should be printed on your card. If it is not, contact the calling card company:

• Access no. + phone no. + card no.

• Access no. + card no. + phone no.

• Prefix + phone no. + card no.

NOTES

• Access no. - This number is usually a 1-800 number that is listed on the back of the calling card.

• Phone no. - The phone number of the party you are calling.

• Card no. - The unique number for your card. The card may also specify that you enter a PIN number after your card number.

• Prefix - Any number(s) that must precede the phone number of the party you are calling.

Store calling card information in your phone

1 Press Menu 4 - 1 - 3 (Settings - Call settings - Calling card).

2 Scroll until the name of the card you want to enter or edit appears.

[ 47 ]

By default, the card names are A, B, C, and D, but you can change the names. Press Options.

3 Scroll to Edit, and press OK.

4 Enter your security code, and press OK.

Dialing sequence appears.

5 Press Select.

6 Determine the dialing sequence for your card. Scroll the list of dialing

sequences until the one you want appears, then press Select.

7 When you are prompted, enter the information (access number, card

number, or prefix number). After entering each number, press OK. At the access number prompt, if your access number is entered in your

phone book, press Search to retrieve it quickly.

8 When you finish entering the calling card information, Save

changes? appears. Press OK.

9 Scroll to Card name, press Select, and enter a card name. 10 Press OK.

Choose a calling card to use

Note:If information for only one calling card is stored in your

phone, you are not required to choose a calling card.

1 Press Menu 4 - 1 - 3 (Settings - Call settings - Calling card). 2 Scroll until the name of the calling card appears, and press Options. 3 Scroll to Select, and press OK. 4 Enter your security code, and press OK.

The message Card ready for use appears.

Make a calling card call

Note:This procedure may not apply to all calling card options. For

more information, refer to your calling card or contact your calling card company.

[ 48 ]

1 At the Start screen, enter the phone number of the party you are calling.

Include any necessary prefix, such as 0 or 1, that is specified by your calling card.

2 Press and hold until the message Card call appears.

3 When the message Wait for tone, then press OK appears, listen for

the tone from your calling card service, then press OK. When the message Wait for tone, press OK again appears, listen for the tone, then press OK.

• CHOOSE TO BLOCK CALLER ID

In most service areas, when you call someone, their caller ID system allows them to see your name and phone number. Your phone is set to allow this information to be seen automatically. Before you make a call, you can choose to block caller ID and prevent the recipient from seeing your name and phone number.

NOTES

• This feature works on a per-call basis, so you must perform this procedure before each call where you want to block caller ID.

• While roaming, you may not be able to block caller ID.

• The following procedure assumes that you have stored the Send own caller ID feature code in your phone and activated the feature. If you have not completed these two steps, you may be able to block caller ID manually. To block caller ID manually, enter the code (for example,

followed by the phone number that you’re calling,

then press .

1 Press Menu 4 - 4 - 4 (Settings - Network services - Send own

caller ID with next call).

2 Highlight Yes (to show your number) or No (not to show your number).

Press OK.

3 Enter the number you are calling (or press Search to retrieve the number

from the phone book), and press OK. Press OK again.

[ 49 ]

Your phone makes the call and requests that the network block caller ID to prevent the recipient of your call from seeing your name and phone number.

• SELECT A PHONE NUMBER

You can use two different phone numbers with your phone. Each phone number is used for a different service area.

• When activating your phone, the service provider sets up your phone with account information (phone number and system information).

• However, your phone can be activated in up to two different service areas. For example, your phone could be activated in Dallas and New York. Each service area assigns a different phone number or account to your phone.

You must select a phone number for your home system. If you travel outside your home system, you can choose another number. Only one phone number

can be active at a time.

Note:You may not need two numbers for your phone if your service provider has service or roaming agreements for each area where you use your phone. Contact your service provider for details.

Select the phone number

1 Press Menu 4 - 4 - 6 (Settings - Network services - Own number

selection).

2 Scroll to the phone number you will use, and press OK.

Note:The first phone number on this list is the currently selected

number. You need at least one active number to make calls. You cannot change from one phone number to another during a call.

[ 50 ]

• SET TOUCH TONES

Touch tones are sounds produced when you press the phone keys. Sometimes, touch tones are called DTMF tones.

You can use touch tones for many automated services such as checking bank balances and airline schedules and using your voice mailbox. Touch tones can be sent only when a call is active.

Set manual touch tones

1 Press Menu 4 - 2 - 3 - 1 (Settings - Phone settings - Touch

tones - Manual touch tones).

2 Select one of the following options, then press OK:

Continuous The tone sounds as long as you press and hold a key.

Fixed

Off

Sets the tone length to 0.1 second, regardless of how long you press a key.

Turns off tones; no tone is sent when you press a key.

Set touch tone length

You can also set the length of each touch tone:

1 Press Menu 4 - 2 - 3 - 2 (Settings - Phone settings - Touch

tones - Touch tone length).

2 Scroll to Short (0.1 second) or Long (0.5 second).

3 Press OK.

Store touch tone sequences (strings)

You store touch tone strings the same as you store names and numbers. You can store a digit sequence to send as touch tones.

[ 51 ]

STORE TOUCH TONE STRINGS WITH PHONE NUMBERS

1 Enter the phone number that you want associated with a touch tone.

2 Press w (wait) or p (pause) where needed.

w (wait): When you specify wait, your phone dials the number, then waits (because you chose w) for you to press Send. When you press

Send, the phone sends your touch tone.

p (pause): If you include a p character, your phone pauses for 2.5

seconds, then automatically sends your touch tone.

3 Enter the touch tone string.

4 Store the number as you normally would.

SEND A TOUCH TONE STRING

1 Press Menu 4 - 2 - 3 - 1 (Settings - Phone settings - Touch

tones - Manual touch tones).

2 Verify that the setting is not set to Off. (If so, select a different option.

Press OK.)

3 During your call, press Options. Scroll to Touch tones. Press OK.

4 Enter or recall the touch tone string from the phone book. Press OK.

[ 52 ]

12) Customize your phone

• UNDERSTAND PROFILES

A profile is a “set of settings” you can use to customize the way your phone works. You can set your preferences for these items:

• Ringing options

• Ringing volume

•Ringing tone

• Vibrating alerts

• Warning game tones

• Message alert tone

Your phone comes with seven profiles:

• Normal (default setting)

• Silent

•Meeting

• Outdoor

•Pager

• Handsfree (available only when used with a handsfree device)

• Headset (available only when used with headset)

You can customize any of the profiles. If at any time you want to return to the original settings, you can do so.

[ 53 ]

• SELECT A PROFILE

Quickly press Power Key . Scroll to highlight a profile. Press OK. (To select a profile, your phone cannot be connected to a handsfree device, and the screen must be displayed.)

• CUSTOMIZE A PROFILE

1 Press Menu 3 (Profiles).

2 Scroll to highlight a profile.

Note:The Handsfree and Headset profiles do not appear unless

your phone has been connected to these accessories. If you connect your phone to a handsfree device, these profiles remain in the menu, unless you choose to restore your phone’s factory settings.

3 Press Options to view the options for the selected profile.

4 Select one of the following options, then press OK.

Select Activates the currently highlighted profile.

Customize

Rename

Enables you to customize a profile by changing the current settings. Press OK to choose from several lists.

Enables you to rename the profile. This option is not available for Normal, Headset, or Handsfree profiles.

Note:When you change a current profile setting, it affects only that profile. Your phone’s normal settings do not change.

Set ringing options

You can choose the tone that notifies you of an incoming call. This setting does not change the alert tone for when you receive a mobile message.

1 Press Menu 3 (Profiles).

2 Scroll to the profile where you want to set the ringing options, and

[ 54 ]

press Options.

3 Highlight Customize, and press OK.

4 Scroll to Ringing options, and press Select.

5 Scroll to highlight the desired ringing option, then press OK.

• Ring - This is the normal ring.

• Ascending - The ringing volume increases (gets louder) with each ring.

• Ring once - The phone rings once (helps prevent disturbing others).

• Beep once - The phone beeps once (helps prevent disturbing others).

• Silent - The phone makes no sound.

Set the ringing volume

You can set the default ringing volume for incoming voice calls and message alert tones.

1 Press Menu 3 (Profiles).

2 Scroll to the profile where you want to set the

ringing volume. Press Options.

3 Highlight Customize, and press OK.

4 Scroll to Ringing volume, and press Select.

5 Scroll through the options. When you hear the volume level you wish

to use, press OK.

Note:As you scroll through the ringing options, you can listen to a sample of each. Although the sample for level 4 and level 5 are the same, ringing level 5 produces very loud ringing.

The ringing volume setting is stored individually for the handsfree device and the headset.

[ 55 ]

Set the ringing tone

You can set your phone’s ringing tone to a specific sound—or tune—for incoming voice calls.

Note:If you have already chosen a ringing option of either Silent or Beep once, the ringing tones are already turned off.

1 Press Menu 3 (Profiles).

Your phone lists each profile.

2 Scroll to the profile where you want to set the ringing tones.

3 Press Options.

4 Highlight Customize, and press OK.

5 Scroll to Ringing tone, and press Select.

6 Scroll to the ringing tone you want to use, and press OK.

Set a vibrating alert

You can set your phone to vibrate when you receive a voice call. This feature is one of the settings in your phone’s profiles:

1 Press Menu 3 (Profiles).

2 Scroll to the profile to be set the vibrating alert. Press Options.

3 Highlight Customize, and press OK.

4 Scroll to Vibrating alert, and press Select.

5 Scroll to On, and press OK.

The phone does not vibrate if it is connected to or in a charging device.

Set keypad tones

You can set the volume of the tone you hear when you press the keys on your phone.

1 Press Menu 3 (Profiles).

2 Scroll to the profile for which you want to set the keypad tones.

Press Options.

[ 56 ]

3 Scroll to Customize, and press OK.

4 Scroll to Keypad tones, and press Select.

5 Scroll to highlight the desired level (or Off), and press OK.

Set warning and game tones

You can set warning tones and game tones used in your phone:

Warning tones include the sounds for error conditions, confirmations, low battery, and need to recharge. Game tones are the sounds made during game play.

To turn warning tones on and off:

1 Press Menu 3 (Profiles).

Your phone lists each profile.

2 Scroll to the profile you want to change, and press Options.

3 Scroll to Customize, and press OK.

4 Scroll to Warning and game tones, then press Select.

5 Scroll to On or Off and press OK.

Set the message alert tone

You can set your phone to use a certain tone to indicate an incoming text message.

1 Press Menu 3 (Profiles).

2 Scroll to the profile for which you want to set the message alert tone.

Press Options.

3 Highlight Customize, and press OK.

4 Scroll to Message alert tone, and press Select.

5 Scroll through your choices. The phone plays a sample of each choice

as you scroll to it.

6 When you find the tone you want, press OK.

[ 57 ]

Set your phone to answer automatically

You can set your phone to answer incoming voice calls after one ring while the phone is connected to an approved handsfree device.

Note:The Handsfree profile will not appear in your phone until you have connected a handsfree device to your phone at least once.

1 Press Menu 3 (Profiles).

2 Scroll to the Handsfree or Headset profile, and press Options.

3 Scroll to Customize, and press OK.

4 Scroll to Automatic answer, and press Select.

5 Scroll to On, and press OK.

Set the lights (handsfree device only)

While your phone is connected to a handsfree device, you can specify either of two settings for the lights:

• Lights on only when you use the phone

• Lights on the entire time the phone is connected to the device

Note: This feature works only when your phone is connected to a

handsfree device.

1 Press Menu 3 (Profiles).

2 Scroll to Handsfree profile, then press Options.

3 Highlight Customize, and press OK.

4 Scroll to Lights, and press Select.

5 Scroll to Automatic or On, and press OK.

• Automatic - If no keys are pressed, the lights go off after 30 seconds.

• On - The lights stay on the entire time that your phone is connected to the handsfree device.

[ 58 ]

• RENAME PROFILES

Note:You cannot rename the Normal and Headset profiles.

1 Press Menu 3 (Profiles).

2 Scroll to the desired profile, and press Options.

3 Scroll to Rename, and press OK.

4 Enter the new name, and press OK.

• RESTORE FACTORY SETTINGS

You can change the default (factory) settings for your phone. Later, you can restore the original settings when needed.

Note:The memory, timers, language selection, security code, and lock codes are not reset. However, any profiles you modified are reset when you restore your settings.

1 Press Menu 4 - 2 - 4 (Settings - Phone settings - Restore factory

settings).

2 Enter your security code, and press OK.

• CHOOSE A DISPLAY LANGUAGE

You can choose which language is displayed on your phone.

1 Press Menu 4 - 2 - 5 (Settings - Phone

Settings - Language).

2 Select the language to use, and press OK.

[ 59 ]

• SET AND DISPLAY THE CLOCK

Your phone contains a real-time clock that can be set two different ways:

• To use the time and date provided by the wireless system

• To be set manually

You can display the time and date on the Start screen as described in “Set the alarm clock” on page 105.

Choose the format of the displayed time

You can choose to display the clock in 24-hour or am/pm format.

1 Press Menu 4 - 2 - 1 (Settings - Phone settings - Clock).

2 Scroll to Time format, and press Select.

3 Scroll to the desired time format (24-hour or am/pm). Press OK.

Note:For am/pm format, a small square appears to the right of the

displayed time. Square at top = am, square at bottom = pm.

Allow the network to set the clock

1 Press Menu 4 - 2 - 1 (Settings - Phone settings - Clock).

2 Scroll to Time settings, and press Select.

3 Scroll to Set by network, and press Select.

NOTES

• If you are outside your network and allow the network to set the clock, you will be prompted to set the clock manually. When you re-enter your network, the network automatically sets the date and time.

• If you are outside your network and you remove the battery (or battery becomes discharged), you will be prompted to set the clock manually when you install or recharge the battery.

[ 60 ]

Manually set the clock

By default, the clock is automatically set by the wireless network. You can override the network and set the clock manually.

1 Press Menu 4 - 2 - 1 (Settings - Phone settings - Clock).

2 Scroll to Time settings, and press Select.

3 Scroll to Set clock, and press Select.

4 Enter the current time.

For example, to enter 7:30, enter 0730. Press OK.

5 Scroll to am or pm, and press OK.

Display or hide the clock

1 Press Menu 4 - 2 - 1 (Settings - Phone settings - Clock).

Depending on the current setting, either Hide time/day or Show time/day will be highlighted.

2 Press Select.

• ADD A WELCOME NOTE

You can set your phone to display a welcome note each time you switch on your phone. This note could say, for example: Hello. It could include your name, a reminder, or more. The maximum length of this note is 36 characters.

1 Press Menu 0 - 1 - 3 (Messages - Welcome note). 2 Enter the text of the welcome note.

Characters you enter are added to the left of the cursor.

• To delete characters to the left of the cursor, press Clear.

• To move the cursor, press or .

3 Press Options. 4 Scroll to Save, and press OK.

To delete (erase) the welcome note, press Menu 0 - 1 - 3 (Options - Erase - OK).

[ 61 ]

USE ONE-TOUCH DIALING

You must store names and numbers before using one-touch dialing. You can assign a name from the phone book to one-touch dialing, using keys 2 through 8. When you press the key, the number is automatically dialed.

• Keys 1 and 9: The 1 key is used exclusively to dial your voice mailbox. The 9 key is used exclusively to make calls to the emergency number that is programmed into your phone.

• Key 2: Some service providers designate this key to dial a customer care operator. Your service provider can tell you if this service is available to you. You can assign a one-touch dial location to the 2 key.

Assign a name or number to a one-touch dial key

1 Press Names and scroll to one-touch dialing.

2 Press Select.

3 Scroll to a number that has the message (empty), and press Assign.

4 Scroll to the name and number to which you want to assign this key.

Press Select. Repeat these steps as many times as necessary.

To call a number using one-touch dialing, press and hold the appropriate key for a few seconds. The phone dials the number.

Change one-touch dialing numbers

After you have assigned a one-touch dialing number to a key, you can change key and number associations at any time.

1 Press Names.

2 Scroll to one-touch dialing, and press Select.

3 Scroll to the key you want to change, and press Options.

4 Scroll to Change, and press Select.

5 Scroll through the phone book.

6 When you reach the new number, press Select.

[ 62 ]

Erase one-touch dialing numbers

You can erase one-touch dialing key assignments at any time.

1 Press Names.

2 Scroll to one-touch dialing, and press Select.

3 Scroll to the key you want to erase, and press Options.

4 Scroll to Erase, and press Select.

5 Press OK.

• USE EMERGENCY KEY 9

The emergency key 9 feature allows you to dial the official emergency number quickly (for example, 911) that is programmed into your phone. Before you can use this feature, you must activate it.

NOTES

• Depending on your service provider, it may not be possible to use the emergency key 9 feature to make an emergency call if: the feature has not been activated; Keyguard is active (see “Activate keyguard” on page 68 .); your phone is locked (see “Lock and unlock your phone” on page 67.); or you set up a call restriction that will not allow the call (see “Restrict outgoing calls” on page 70.).

• Depending on your service provider, you may be able to make an emergency call manually by entering the emergency number at the screen and then pressing , regardless of your phone settings.

• For more safety information about making emergency calls, see “Emergency calls” on page 114.

Activate or deactivate emergency key 9

1 Press Menu 4 - 1 - 1 (Settings - Call settings - Emergency key 9).

2 Scroll to On (activate) or Off (deactivate). Press OK.

[ 63 ]

Make an emergency call

There are two ways to use the emergency key 9 feature to make an emergency call:

•Press , then .

• Press and hold until the phone indicates it is attempting to make an emergency call.

When you make an emergency call, your phone changes to emergency call mode. If you exit this mode, emergency operators may not be able to contact you. Keep your phone in emergency call mode until emergency personnel arrive on the scene.

In emergency call mode, some menu items may not be available. To exit emergency call mode, at the Start screen, press Exit. When the question Restore normal service? appears, press OK.

• IDENTIFY CALLERS BY CUSTOM RINGING TONES

You can assign a ringing tone to an entry in your phone book, allowing you to identify the caller by the tone you hear when they call.

To use this feature, you must subscribe to the Caller ID service that is available from your service provider.

If a caller blocks Caller ID, your phone will use the Normal ringing tone instead of the custom tone. If the ringing option for the current profile is set to Silent, your phone will not ring with a normal tone or a custom tone.

Fifty of the entries in your phone book can have a custom tone assigned to them. Assign these custom tones with this procedure:

1 In your phone book, find the entry where you will assign the custom

ringing tone.

2 Press Details, then Options (or, if the scrolling view for your phone

book is set to Name+number, just press Options).

3 Scroll to Custom tone, and press Select.

4 Scroll through the ringing tones list until the desired tone is highlighted.

[ 64 ]

• If you wait a moment while a tone is highlighted, your phone will play the tone.

• To remove assignment of the custom tone from the entry, select Default.

5 Press OK.

• PRESS ANY KEY TO ANSWER A CALL

1 This feature allows you to answer an incoming call by pressing any

key except the End key or the Power key . The default setting for this feature is On. To enable or disable Anykey answer, press Menu 4-1-4.

[ 65 ]

13) Security

A security code, a phone lock feature, and a call restriction feature prevent unauthorized use of your phone. A keypad lock prevents unintended key presses, such as when your phone is in your purse or pocket.

• CHANGE YOUR SECURITY CODE

Important:

The default security code is 12345. Nokia highly recommends that you immediately change this code, write down the new code, and store it in a safe place, away from your phone. You cannot activate or use certain phone features until you successfully enter your security code.

When you enter your security code, an asterisk (*) appears on the screen each time you press a number key, preventing others from seeing your code. If you enter the wrong code five times in a row, your phone won’t accept any entries for the next 5 minutes.

1 Press Menu 4 - 3 - 2 - 4 (Settings - Security settings - Access

codes - Change security code).

2 Enter the security code. (The default code is 12345.) Press OK.

3 Enter the new code. To prevent accidental emergency calls, don’t enter

a code that is similar to an emergency number. Press OK.

4 To verify your new security code, enter it again. Press OK. The

message Security code changed appears. Store your new code in a safe place, away from your phone.

• PROTECT YOUR PHONE WITH PHONE LOCK

You can lock your phone to prevent others from using it. When someone tries to use it, they will be required to enter a lock code.

Tip:If you save an unlocked phone number, you can make calls to that number without entering the lock code.

[ 66 ]

Important:

your phone number, depending on your service provider). Nokia highly recommends that you immediately change this code, write down the new code, and store it in a safe place, away from your phone.

When you enter your lock code, an asterisk (*) appears on the screen each time you press a number key, preventing others from seeing your code. If you enter the wrong code five times in a row, your phone will prompt you for the security code.

The default lock code is

1234

(or the last four digits of

Lock and unlock your phone

1 Press Menu 4 - 3 - 2 - 1 (Settings - Security settings - Access

codes - Phone lock).

2 Enter the lock code, and press OK.

3 Scroll to On (lock) or Off (unlock). Press OK. If you choose to lock your

phone, it will be locked when you switch it off. When you turn it back on, you must enter the lock code before you can use the phone.

Note:When your phone is locked, it may not be possible to make an emergency call. (See “Make an emergency call” on page 64.)

Store an unlocked phone number

If you store an unlocked phone number, you can make calls to that number without entering the lock code.

1 Press Menu 4 - 3 - 2 - 2 (Settings - Security settings - Access

codes - Unlocked phone number).

2 Enter the lock code. Press OK. The Number field appears.

3 Enter a phone number (or press Search to find the number).

4 Press Options.

5 Scroll to Save, then press OK.

[ 67 ]

Call an unlocked phone number

• Press or once, then , OR...

• At the Start screen, enter the phone number. Press .

Answer a call while the phone is locked

Press any key except or .

Change your lock code

1 Press Menu 4 - 3 - 2 - 3 (Settings - Security settings - Access

codes - Change lock code). The message Enter lock code appears.

2 Enter th e l oc k code. (The de fa ult l oc k c ode i s 1 23 4, or the l as t f our dig it s

of your phone number, depending on your service provider.) Press OK.

3 Enter the new lock code. Only numeric characters are accepted. To

prevent accidental emergency calls, don’t enter a code that is similar to an emergency number.

4 Press OK. 5 Verify the new lock code, and press OK. Store your new code in a safe

place, away from your phone.

• USE KEYGUARD TO LOCK THE KEYPAD

The Keyguard feature lets you lock the keypad to prevent accidental key presses while your phone is in a pocket or purse. If you press a key while Keyguard is activated, a message appears: Press Unlock and then *.

Activate keyguard

• Press and hold until Keys locked appears. (If you do this during a call, the call will end.), OR...

• At the Start screen, press Menu , OR...

• At the Start screen, press Menu 1 - 0, OR...

• At the Start screen, press Menu. Scroll to Keyguard, and press Select.

[ 68 ]

Deactivate keyguard

•Press Unlock., then , OR...

• Press and hold until Unlock keys? appears. Press OK.

Answer a call while keyguard is active

•Press , OR...

• If Anykey answer is set to On, press any key except or . (During an incoming call, Keyguard is automatically deactivated. When you end the call, Keyguard is automatically activated again.)

NOTES ABOUT KEYGUARD

• While Keyguard is active, depending on your service provider, it might not be possible to use the Emergency key 9 feature to make an emergency call. However, it may be possible to make the call by manually entering the number and then pressing . While entering the number, none of the characters will appear on the screen until you enter the last one.

• When you connect your phone to a handsfree device other than a headset, keyguard is automatically deactivated. When disconnected from the device, it is automatically activated.

• Before you turn off your phone, you must deactivate Keyguard.

• While Keyguard is active, press the Power key to switch the lights on quickly for 30 seconds.

• RESTRICT CALLS

You can restrict incoming and outgoing calls. To restrict outgoing calls, you create a list of restrictions and apply the appropriate restriction.

For outgoing calls, only one restriction option is available:

Add restriction, which enables you to create your own list of outgoing call restrictions. The maximum number of call restrictions you can define is ten.

[ 69 ]

After you have used the Add restriction option to add at least one restriction, the following options are then available:

• Select: Allows you to set call restrictions from the outgoing calls list.

• Edit: Allows you to edit an existing outgoing call restriction.

• Erase: Erases any existing outgoing call restrictions.

The All calls option cannot be erased; therefore, this option does not appear in the list of restrictions to be deleted.

Depending on the type of restriction, you may not be able to use the emergency key 9 feature to make an emergency call. However, you may be able to make the call manually by entering the emergency number and then pressing .

Restrict outgoing calls

1 Press Menu 4 - 3 - 1 (Settings - Security settings - Restrict calls).

2 Press Select.

3 Enter your security code, and press OK.

4 Scroll to Add restriction, and press OK.

5 Enter the number you want to restrict, and press OK.

For example: If you want to restrict all calls that begin with 1, enter 1. This will restrict all outgoing long distance phone calls. If you want to restrict all calls that begin with 972, enter 972, and so forth.

After you perform step 5, the Name field appears.

• If you want to add a name for the call restriction, enter the name using your phone’s keypad. Press OK.

• If you don’t want to add a name, simply press OK.

[ 70 ]

Restrict incoming calls

To restrict incoming calls:

1 Press Menu 4 - 3 - 1 (Settings - Security settings - Restrict calls).

2 Scroll to Restrict incoming calls, and press Select.

3 Enter your security code, and press OK.

4 Scroll to All calls, and press Mark.

Press Unmark to remove an already-set restriction.

5 Press Back.

The Save changes? message appears.

6 Press Yes.

Press No if you do not want to save the changes.

[ 71 ]

14) Select System

The System menu (Menu 5) allows you to customize the way your phone chooses a system in which to operate while you are “roaming” (using your phone outside your primary or “home” system). Your choice of a system affects the type and amount of charges you incur. By default, your phone is set to automatically search for the most cost-effective system while roaming. If your phone can’t find a preferred system, it uses a system based on the option you choose in the System menu.

Note:Before selecting an item in the System menu, contact your service provider to find out how your selection will affect your service charges.

Roaming

Roaming occurs when you use your phone outside its home area. While roaming, another service provider’s system handles your call, so the service rate for the call is usually higher than the rate for calls made within your home area. While roaming, the word Roaming and the roaming indicator ( ) appear on the Start screen.

Note: In some systems, you may need to have a roaming agreement to place a call. If no roaming agreement has been arranged, a network operator may interrupt and request information on how you intend to pay for the call.

Service types

In each wireless service area there are usually two service providers, referred to as type A and type B. When you first set up your wireless service account, your service provider will inform you of which system you will be using (usually type B). This is your home system. The other system (for example, type A) is known as a non-home-type system.

[ 72 ]

System choices

If you have more than one phone number (NAM), your choice affects only the currently selected number. Select Menu 5 and select from the following choices.

Note:System choices may differ, depending on service provider.

• Home area: Your phone cannot roam. This means you can make and receive calls in your home area only. While roaming, No Service appears and you will not be able to make or receive calls.

• Automatic A: Your phone searches for system A.

• Automatic B: For most service providers, this is the default selection. Your phone searches for system B.

[ 73 ]

15) Send and receive mobile messages

When you have mobile (text) messaging service, you can receive messages on the screen and send messages to e-mail addresses and phone numbers.

Note:Before you send or receive mobile messages, you may need to subscribe to the messaging service offered by your service provider. Some networks may not support mobile messaging.

The message types vary by service provider. Your phone automatically creates the types of messages supported by your service provider:

• Text: A text message can include text and a call-back number.

• Number only: A number-only message is like a numeric page. A call-

back number (the sender’s phone number) appears on the recipient’s pager or phone screen.

A message contains both a header and the body. The header may have the sender’s phone number or e-mail address and the date and time of the message. If you have a phone book entry that matches the sender’s phone number, the sender’s name also appears. The body contains the main part of the message. If you receive a message sent by e-mail, the subject (title) may appear at the beginning of the message body.

• ABOUT WRITING MESSAGES

Traditional or Predictive Input

You can write text messages with standard input or predictive text input.

• Traditional (multitap) input method: This is the default mode. This

method requires that you press some keys more than once (multitap). For example, to enter the letter c, you must press three times. See “Enter characters (except in a phone number field)” on page 29.

[ 74 ]

• Predictive text input method: In the predictive text mode, your phone “guesses” which word you are entering. This mode requires that you press a key only once for each letter you enter.

Note:To learn more about using Predictive Text when creating messages, see “Working with predictive text input”

Write a new message

1 Press Menu 0 - 1 - 1 - 1 (Messages - Text messages - Write new).

If Text and Number only appear in a list of menu items, scroll to Text, press Select, and go to the next step.

If these items are not on your menu, proceed to the next step.

2 You may address your message or write it first and address it later.

• To address your message, scroll to Add e-mail or Add number,

then press Select.

• To begin writing your message, scroll to Edit message, then press

Select. The terms writing and editing refer to the process of entering text into a text message.

After you have written your message, you can:

• Address and send it.

• Save the message in the Outbox and address and send it later.

(Press Options, scroll to Save, then press Select).

Enter text into a message

A counter in the top right corner of the screen indicates the number of remaining characters that you can enter into your message.

Caution:While editing a message, if you accidentally press and hold Clear, all text within your message will be deleted.

To exit the message editor at any time without saving your text, press Options, scroll to Exit, then press Select.

[ 75 ]

1 . , @ ’ ? ! -1 7 PQRS7

2ABC28 TUV8

3 DEF3 9 WXYZ9

4GHI40 Enters an empty space or 0

5 JKL5 * Special characters

6 MNO6 # Changes letter case; long press toggles

between ABC/abc & 123 mode

Change the text input method

To switch (toggle) between predictive and traditional text input modes while you are editing a message, press the Pound key several times until the icon indicates the mode you want to use. You must activate predictive text before you will be able to toggle between the two modes.

Tip:If you don’t want to use predictive text input mode at all, deactivate it. You can reactivate it later.

• WORKING WITH PREDICTIVE TEXT INPUT

The predictive text feature is based on a built-in dictionary to which you

can add words. Your phone includes several different language versions of this dictionary. Although your phone can display a given language on the screen, it may not have a predictive-text dictionary of that same language.

By default, your phone is set in the traditional text input mode. Before you can use the predictive text input method, you must first activate the predictive text mode.

Activate predictive text mode

Predictive text mode is active when the predictive text icon ( ) is present at the top of the screen. If the icon does not appear, predictive text mode has been deactivated.

[ 76 ]

To activate the predictive text mode while editing a message:

1 Press Options.

2 Scroll to Predictive text.

3 Press Select.

4 Scroll until the language you want appears, then press OK.

Deactivate predictive text mode

To return to the traditional text input mode, you must deactivate the predictive text input mode:

1 While editing a message, press Options.

2 Scroll to Predictive text. The language list displays.

3 On the language list, scroll to Prediction off and press OK. Your

phone is now in traditional (multitap) mode.

4 You can also use multitap on the pound key (#) to go to traditional

text in a message.

Add words to the dictionary

1 If the ? character appears after the word, press Spell, or at any time

while you are editing, press Options, scroll to Insert word, then press Select.

2 Enter the word using traditional text input, and press OK. If the

dictionary is full, the new word replaces the oldest added word.

Change the dictionary language

You can change the dictionary language while you are editing a message:

1 While editing a message, press Options.

2 Scroll to Predictive text, then press Select.

3 Scroll to a language, then press OK. The selected language is active.

[ 77 ]

• WRITE WITH PREDICTIVE TEXT INPUT

Enter words

1 Press each key only once for each letter of the word. For example, to

write hello, press 4 - 3 - 5 - 5 - 6. The characters that you enter appear underlined. The word changes after each keystroke, so only check the word after you press all the appropriate keys.

2 When you finish the word, check to make sure that the word is correct.

3 If the word is correct, enter a space (press the 0 key) and write

the next word.

4 If the word is incorrect and is underlined, press the Star key ( )

repeatedly until the desired word appears. OR, press Options, scroll to Matches, then press Select. Your phone shows a list of words. Choose

a word from the list, then press Use, or press Back to exit and return to the message editor.

5 If the ? character appears after the word, there are no more words in

the dictionary that correspond to your key presses. At this point, you can add the word to the dictionary by pressing Spell.

Writing compound words

To write a compound word quickly (for example, bluejay):

1 Write the first part of the word (blue).

2 Press (do not enter a space). The underline disappears from the

first part.

3 Write the second part of the word (jay).

Deleting characters

When you need to delete characters use one of these methods:

• To delete one character to the left of the cursor, press Clear.

• To delete all characters in the message, press and hold Clear.

[ 78 ]

Changing letter case modes

You can switch (toggle) between uppercase and lowercase letter mode by pressing the Pound key .

If the predictive text mode is active and you don’t wait at least 1.5 seconds between key presses, the text input mode will also be switched between traditional and predictive text.

If predictive text mode is active when you create a new message, the first letter of the first word that you enter will be uppercase.

Entering numbers

When you enter numbers, use either of these methods:

• For one or a few numbers, press and hold the respective number key.

• For many numbers, change to number entry mode (press and hold the Pound key ) and enter the numbers as usual.

Inserting special characters

• To insert a special character (such as a punctuation mark), press and hold the Star key , or press Options, scroll to Insert symbol, then press Select.

• To insert a period (.) quickly, press . To insert double hyphens (-

-) quickly or three dots (an ellipsis...), press a few times.

Templates

Note:Templates are available in English only.

A template is a predefined, commonly used sentence that you can quickly insert into a message:

1 While you are editing a message, press Options. 2 Scroll to Add template, then press Select. 3 Scroll to the template you want to use. For example:

1. Call me at [ ]. <phone number/time/place-

2. I’ll call you at [ ]. <time/place-

[ 79 ]

Brackets ([ ]) in a template represent a value that you can specify. The value is not retained for future use; you enter the value each time you use the template. If you select a template that contains brackets, you will be prompted to enter a value. You can edit the template text after you insert it into your message.

• RECEIVE A MOBILE MESSAGE

When you receive a mobile message, the mobile message icon appears and Message received (or New emergency message) displays. If you have a message alert tone set, a tone may sound.

When you receive notification, you can:

1 Press Clear to dismiss the notification and read the message later

from your Inbox.

Press Read to read the message now.

The Inbox opens with the new message selected.

If No space: message waiting or a similar message appears, your phone’s memory is full. You must make room for the message. Press Read again.

If necessary, scroll to read the entire message.

2 At the end of the message, scroll further to view the sender’s name or

phone number and the date and time the message was received.

When you’ve seen the last new message, the icon disappears.

• MESSAGE OPTIONS

While reading a message, you have several options. Some of these options may not be available for some types of messages:

Erase deletes the message. Press OK to confirm the deletion or Clear to cancel.

[ 80 ]

Reply allows you to send a return message to the sender.

Save sends the message to the Saved folder.

Use number allows you to call quickly or save a phone number included

in the message. If more than one number was included, a list of numbers displays.

To save the number:

a) Read the message and scroll until the number you want to save

is visible.

b) Press Options, scroll to Use number, and press Select.

If one phone number appears on the screen, press Call (or press , then Save).

If a list of numbers appears, scroll to a number, press OK, then press Call (or press , then Save).

Save address extracts one or more e-mail addresses from the message (if it contains any) and allows you to save the addresses in your phone book.

Forward allows you to send the message to another recipient. For more information about forwarding a message, see “Forward a message” on page 87 .

Reply w/ copy allows you to send a message back to the sender. Your message will include a copy of the message you received.

• MESSAGE STORAGE

Your phone can store about 80 messages. All folders share the memory, so the actual number of stored messages depends on the message length. Three folders store your messages:

• Inbox: All messages that you received and have not erased or saved.

• Outbox: Messages that you sent or created and saved to send later.

• Saved: Messages that you saved from the Inbox or Outbox.

If the memory is full when you receive a mobile message:

[ 81 ]

• Non-emergency Message: The oldest sent message in the Outbox folder is deleted. Drafts or unsent messages are not deleted. If there are no sent messages in the Outbox folder, the oldest read message in the Inbox folder is deleted. If there are no read messages in the Inbox, No space: message waiting or a similar message appears. This message prompts you to delete messages from one of the folders. The network resends the message later.

• Emergency Message: An emergency message, sent only by a network operator, follows the procedure for a nonemergency message and adds an additional safeguard. For the emergency message, other messages in the Inbox, Outbox, and Saved folders may also be automatically deleted if your phone’s memory is full.

• CREATE A TEXT MESSAGE

Address a text message

Use this procedure to address your message to one or more recipients:

1 You must be editing the message that you want to address:

•If you are in Edit message, press Options, then go to the next step.

•If you are not in Edit message (for example, you wrote the

text message and saved it to send later), open the Outbox (Menu 0 - 1 - 1 - 3). Scroll to the message you want to address.

Press Options. Scroll to Resend. Press Select. Go to the next step.

2 Scroll to Add e-mail (to add an e-mail address) or Add number

(to add a phone number), then press Select.

3 Enter the e-mail address or phone number, then press OK.

Notes about addresses

• You can address a text message to as many as 10 e-mail addresses, phone numbers, or a combination of both. To see a list of all recipients to whom your message is addressed, scroll to List recipients, then press Select.

• The maximum number of characters allowed in a phone number is 32.

[ 82 ]

The maximum number of characters allowed in an mail address is 48.

• While entering a phone number or e-mail address, press and release Clear to delete one character, or press and hold Clear to delete all characters.

• If a recipient’s e-mail address or phone number is in your phone book, you can quickly enter it by searching for the recipient’s name. To search, press Search. To jump to an entry in your phone book quickly, press the appropriate key. For example, if the entry is John (j), press . To jump to Kim (k), press twice. If an e-mail address or phone number is not associated with the entry that you select, a message will appear: No e-mail address found or No numbers found.

• When entering an e-mail address manually, you can quickly enter the @ symbol by pressing repeatedly until the @ symbol appears.

Note:To address a number-only message, see “Send a numberonly message” later in this section.

• SEND A MESSAGE

This procedure assumes that you have addressed your text message and entered some text into it (or have entered a callback number). Before you send your message, you can select one or more options. While you’re editing the message, press Options, scroll to Settings, then press Select. To select an option, Mark it. To deselect an option, Unmark it.

• Urgent: Sets the priority level of your message to “urgent”. Urgent message or a similar notification will appear on the screen of the recipient’s phone or other device.

• Delivery note: When the recipient receives your message, the network will send you a delivery note. If you address the message to more than one recipient, you will receive a separate delivery note for each recipient.

• Callback no.: Allows you to enter a phone number at which the recipient can call you.

[ 83 ]

After you mark and unmark the options, press Back. The message Save changes? appears. To accept the changes that you made to the settings,

press Yes. To discard the changes, press No.

To send the message, press Options, scroll to Send, then press Select. If the network can’t send your message, a warning note should appear. Try to resend the message later.

Message delivery notification

When you send a message, you can ask to be notified when the message is received. This notification is called a delivery note. When the recipient gets your message, the network sends you a delivery note. You will receive a separate delivery note for each recipient.

Urgent mobile messages

You can assign an urgent priority level to a mobile message. When you receive an urgent mobile message, Urgent appears in the message header. When you send an urgent mobile message, a similar notification appears on the recipient’s phone or other device if it supports this feature.

There are four ways to create a text message:

• Write a new, blank message

• Reply to a received message

• Resend a message

• Forward a message

Send a number-only message

To create a text message, see “Create a text message” on page 82. For information about types of messages, see “Send and receive e-mail messages” on page 88.

Press Menu 0 - 1 - 1 - 1 (Messages - Text messages - Write new).

Note:If Text and Number only appear in a list of menu items, scroll to Number only, then press Select.

[ 84 ]

Use the following guidelines when addressing your message and specifying a callback number:

•Use Add number to specify a recipient’s phone number. The maximum number of characters allowed in a phone number is 32.

• When prompted to enter a recipient’s phone number, you can manually enter it or search for it.

• When searching, the list of entries in your phone book is displayed.

To jump to an entry quickly, press the appropriate key. For example, if the entry is John (j), press . To jump to Kim (k), press twice.

• You can address your message to as many as 10 recipients. You can see a list of recipients who will receive your message (List recipients).

• You can create a message, save it in your Outbox, then address it and send it later (Save).

The callback number (Callback no.) is the phone number at which you want the recipient to call you. When prompted to enter a callback number, the default callback number (your mobile phone number) may appear in the field. You can use this number or enter a different number.

Resend a message

1 Open your Outbox (Menu 0 - 1 - 1 - 3). Scroll until the message you

want to resend is highlighted.

2 Press Options. Scroll to Resend. Press Select.

• Before you resend your message, you can edit it. You can also edit

the recipients list (Add e-mail, Add number, or List recipients).

•Settings (Urgency, Delivery note, and Callback no.) for the

message are kept unless you edit them (Options - Settings).

3 To send the message, press Options, scroll to Send, then press Select.

[ 85 ]

• ERASE MESSAGES

You can erase the message you’re reading or several messages at once.

Erase the current message

Press Options, scroll to Erase, then press Select.

Erase multiple messages

1 Press Menu 0 - 1 - 1 - 5 (Messages - Text messages - Erase).

2 Scroll until the message is highlighted, then press Select. Depending

on your service provider, you may be need to confirm your choice or enter your security code to prevent accidental deletion of messages.

• All read: Erases all read messages in the Inbox (unread messages are not erased); erases all messages in the Outbox and Saved folders (these folders cannot contain unread messages).

• All in inbox: Erases all messages (read or unread) in the Inbox.

• All in outbox: Erases all messages (sent or unsent) in the Outbox.

• All saved: Erases all messages in the Saved folder.

• REPLY TO A MESSAGE

1 Read the message to which you want to reply.

• If you just received the message and the Start screen is currently displayed, press Read.

• If the message is in the Inbox folder, press Menu 0 - 1 - 1 - 2.

• If the message is in the Saved folder, press Menu 0 - 1 - 1 - 4.

2 Scroll to the message, press Read, and then press Options.

3 Scroll to Reply (or Reply w/ copy if you want to include a copy of the

original message in your reply).

If you reply with copy, your message could be long. In some networks, a long message is shortened and the recipient may not see all of it.

[ 86 ]

4 Press Select.

After you write your message, you can:

• Address and send it.

• Save the message in the Outbox, and address and send it later (Press Options, scroll to Save, then press Select).

• FORWARD A MESSAGE

1 In the Inbox or Saved folder, read the message that you want to

forward.

2 Press Options, scroll to Forward, then press Select.

3 Prepare your message as you would any other message that you create.

• If the message you are forwarding is a text message, you can edit the message before you send it.

• If your phone is configured to be able to send a number-only message, you can forward a callback number as a number-only message, provided the original message was also a number-only message.

4 After you prepare your message, you can:

• Address it, then send it.

• Save it to the Outbox (press Options, scroll to Save, then press Select), then address it and send it later.

[ 87 ]

16) Send and receive e-mail messages

You can use your phone to send and receive e-mail messages. You no longer need to be at your computer to send or receive messages. The e-mail feature is not available from all service providers.

• SAVE E-MAIL ADDRESSES

You can add an e-mail address to a name you’ve already saved in the phone book. You can also add a name and address as a new entry.

Save an e-mail address for an existing name

1 At the Start screen, press Names, then at Search, press Select.

The Names box opens.

2 Enter the first two letters of the name you want to find. Press OK.

3 Press Options (or press Details if the Name list view is selected in your

phone book), and scroll to E-mail address. Press Select.

The e-mail address box opens.

4 Enter the address.

Press once for a dot (.). Press repeatedly until the @ appears. Press OK when you see the correct character.

5 When you finish entering the address, press OK.

The message Saved appears briefly, confirming your action.

Add a new e-mail address

1 At the Start screen, press Names. Scroll to Add new. Press Select.

The Names box opens.

2 Enter the name. Press OK.

[ 88 ]

The Number box opens.

3 Enter the phone number. Press OK.

The message Saved appears briefly, confirming your action.

4 Press Options, scroll to E-mail address. Press Select.

The e-mail address box opens.

5 Enter the address. Insert special characters such as the “dot” and @

signs by pressing .

6 Press OK.

The message Saved appears briefly, confirming your action.

Edit an e-mail address

1 At the Start screen, press Names, then at Search, press Select.

The Names box opens.

2 Enter the first two letters of the name you want to find. Press OK.

3 Press Options (or press Details if the Name list view is selected in your

phone book), and scroll to E-mail address. Press Select.

The e-mail address box opens.

4 Enter any changes, using the scroll keys to move the insertion point

backward and forward in the address.

5 When the address is correct, press OK.

The message Saved appears briefly, confirming your action.

• SEND AN E-MAIL MESSAGE

1 At the Start screen, press Menu and then, at Messages, press Select.

At Text messages, press Select. Scroll to Write e-mail. Press Select.

The e-mail address box opens.

If your phone asks for an e-mail gateway number, see your service provider.

[ 89 ]

2 Enter the e-mail address, or press Search.

•If you press Search, enter the first few letters of the name you want. Press OK when you find the name. The address appears in the Recipient address box. Press OK.

• The phone lists all the names from your phone book. If you select a name for which there is no e-mail address, your phone displays the message, No e-mail address for this name.

• If you enter the e-mail address, press OK when you’ve finished.

The Subject box opens.

3 Enter a subject. Press OK.

The subject line can hold a maximum of 26 characters. You can leave the line blank if you wish.

4 When the message screen appears, enter your message.

Note:The maximum number of characters for message length

varies; check with your service provider for details.

You can turn on predictive text input if you wish. For information, see “Working with predictive text input” on page 76.

5 When you finish the message, press Options, select Send. Press OK.

A status message tells you the mail is being sent.

Other options for a completed message

Save

Erase Erases the message and returns you to the Recipient

Quit

Saves the message in the saved folder until you send it.

address box.

Erases the message and returns you to the Start screen.

[ 90 ]

• REPLY TO OR FORWARD AN E-MAIL MESSAGE

1 If the message is not on the screen, press Menu, Message, Text

messages and Inbox (Menu 0 - 1 - 1 - 1).

2 Select the message you received. Press Read.

3 Press Options. Scroll to Forward or Reply. Press OK.

4 Scroll to As e-mail. Press Select.

If the phone needs an e-mail gateway number, see your provider.

5 Enter the recipient’s e-mail address or press Search to find the name.

•If you press Search, enter the first few letters of the name you want. Press OK when you find the name. The address appears in the Recipient address box. Press OK.

• The phone lists all the names from your phone book. If you select a name for which there is no e-mail address, your phone displays the message, No e-mail address for this name.

• If you enter the e-mail address, press OK when you’ve finished.

6 Enter a subject line. Press OK. The subject line holds up to 26 characters.

You can leave it blank.

7 When the message box opens, write your reply or message you want

to add when you forward the mail. You can use predictive text input.

8 When you’ve finished your message, press Options. Scroll to Send.

Press OK.

[ 91 ]

17) Minibrowser

Note:This feature is available only if your service provider’s

network supports wireless internet access. Your service provider may also require that you subscribe to this additional service. For more information, contact your service provider.

• ABOUT THE MINIBROWSER

Warning: Your phone must be switched on to use the

Minibrowser. Do not switch on the phone when wireless phone use is prohibited. See “For your safety” on page 9.

Warning: Emergency Key 9 is disabled while you are in a Minibrowser session.

The Minibrowser lets you browse the internet for information such as stock quotes and weather. Browsing via the phone is not like browsing using a PC. Site providers usually present only the critical aspects of their site to wireless phone users, so they have removed most graphics.

When you start the Minibrowser and connect to a network, two icons appear on the screen:

• Minibrowser icon (you are in a Minibrowser session)

• Active call icon (you are being billed accordingly)

After a certain period of inactivity, the Minibrowser disconnects from the

network. For this reason, you may find that you are billed for several network connections within a single session. This is normal and is designed to minimize your bill. Rates will vary according to your billing plan.

When the Minibrowser disconnects from the network, the active call icon ( ) disappears, but the Minibrowser icon ( ) remains. While you are in the Minibrowser you can still access pages stored in memory without

[ 92 ]

being connected to the Internet. However, if you navigate to a page that is not stored in memory, a new Minibrowser session begins and you’ll be billed accordingly.

• LAUNCHING THE MINIBROWSER

The first time you launch the Minibrowser, you go through a security setup process that takes 3 to 5 minutes (follow the on-screen prompts).

1 From the start screen, press Menu, then scroll to Minibrowser. The

following message appears to remind you that you may be billed for the connection time. (You can disable this message. See “Disable

minibrowser confirmations” on page 97.) Browsing may incur charges. Continue? (Yes) (No)

2 Press Yes. After a few seconds, the Home Page appears. (Your menu

may vary according to your service provider.)

Home Page 1 News 2 Yahoo! 3 Weather 4 Finance 5 Web site

Note:To end a Minibrowser session, press and hold .

• MINIBROWSER MENU

While in the Minibrowser, press and release the Power key to display the Minibrowser menu:

• Help: Show a help page for the current site (accessible from some pages).

• Home: Return to the Home page.

• Bookmark page: Set a bookmark for the current page.

• Show URL: Show the web address (Uniform Resource Locator) for

[ 93 ]

the current page.

• Restart: Return to the Home page and delete all stored pages.

• Version: Show the version of Minibrowser software.

• Advanced: Change server and encryption settings.

• Exit Minibrowser: Exit the Minibrowser.

• Switch off!: Turn off the phone.

About web page content

The following items may appear on web pages:

• numbered options (some options may not be numbered)

• links (embedded in content)

• input fields for text or numbers

• simple text

• NAVIGATING IN THE MINIBROWSER

SCROLL THROUGH THE MENUS AND CONTENTS OF A PAGE

Press the scroll keys ( and ) to scroll through the menus and contents of a page and to see the content of pages that do not fit on one screen. To scroll quickly, press and hold the scroll key.

GO BACK (PREVIOUS PAGE)

To go back to a previous page, press the End key .

GO TO THE HOME PAGE

• Press the End key repeatedly to move back through previously viewed pages until the Home Page appears.

• OR, press and release the Power key to display the Minibrowser menu, scroll to Home, then press OK.

[ 94 ]

ACTIVATE AN ITEM (FOR EXAMPLE, A LINK)

• Press the appropriate number key on your phone’s keypad (if the item on the page is numbered).

• OR, scroll to the item, then press the appropriate selection key (for example, to activate a link).

SELECTION KEYS

To navigate to different screens or select special functions, use the selection keys. The function of each selection key can change with each page and depends on each highlighted item.

• (Left selection key) - Usually selects the highlighted item, but its function may change depending on what you are doing.

• (Right selection key) - Usually selects a secondary option or displays a menu of secondary options.

•LINKS

Links usually appear as items in a numbered list. Depending on its type, when activated, a link will:

• Take you to another page or site

• Make a phone call (Some sites support this feature. When you make the call, the browser connection terminates, but the page you were viewing is stored in memory. After you end the call, the page you were viewing is displayed again and you can continue browsing.)

To activate a link:

1 Move the cursor until the desired link is highlighted. 2 Press the appropriate selection key. (If the link is a phone number, in

some cases, you can also press the Talk key to make the call.)

[ 95 ]

• BOOKMARKS

You can set a bookmark for a web page so that you can quickly go to that page later. (You may also be able to set bookmarks via a personal account at your service provider’s web site.)

SET A BOOKMARK

1 Go to the page for which you want to set a bookmark. 2 Press and release the Power key . The Minibrowser menu appears. 3 Scroll to Bookmark page, then press Select. (A message may appear

asking you to confirm this action.)

GO TO A BOOKMARKED PAGE

1 From the Home Page, scroll to Bookmarks, then press Select. A list

of your bookmarks appears.

2 Select the bookmark that represents the page you want go to, then

press Select.

Tip: A number is associated with each bookmark in the bookmark list. To quickly go to a bookmark, press and hold the appropriate number key.

• RECEIVING MESSAGES VIA THE MINIBROWSER

Depending on your service provider, you may be able to receive messages via the Minibrowser. The procedure you use to read a Minibrowser message varies depending on your service provider. For more information, contact your service provider. (This information may also be available at your service provider’s web site.)

• ENDING THE MINIBROWSER SESSION

•Press and hold .

•OR, Display the Home Page (If the Home Page is not currently displayed, press repeatedly until it is displayed.) Press . Exit Minibrowser? appears. Press Exit.

[ 96 ]

• OR, press and release the Power key . Select Exit Minibrowser.

• DISABLE MINIBROWSER CONFIRMATIONS

You can specify whether or not you want your phone to confirm your choice to connect to the web or exit the Minibrowser session.

1 Press Menu 4-1-5 (Settings - Call settings - Minibrowser

confirmations). The following options appear:

• Both: Your phone prompts you to confirm your choice before connecting to the web and before exiting the Minibrowser session.

• None: Your phone never prompts you to confirm your choice.

• On connection: Before connecting to the web, your phone prompts you to confirm your choice.

• On exit: Before exiting the Minibrowser session, your phone prompts you to confirm your choice.

2 Scroll to the appropriate option, then press OK.

Tip:To prevent unintentional exiting of the Minibrowser session

(such as when pressing repeatedly to move back through previously viewed pages), select Both or On exit. This will ensure that a confirmation message appears before exiting.

Note:If you press and hold , the Minibrowser session ends without confirmation, regardless of the Minibrowser confirmation setting.

[ 97 ]

18) Use your personal assistant

Your phone can be your personal assistant. It can wake you up in the morning, or remind you of meetings, birthdays, and tasks. Check the current time and calculate a tip at dinner. It’s a calendar, clock, alarm clock, calculator, and phone book -- everything you need to keep track of your life.

• USE THE CALENDAR

The calendar keeps track of birthdays, meetings, or calls you need to make. The calendar can sound an alarm to remind you to make call or go to a meeting.

Select

Note:Unlike the alarm clock, if your phone is turned off, it will not automatically wake up and sound the alarm for a calendar note. For the alarm to sound for a calendar note, your phone must be turned on.

Calendar

Exit

View the calendar

To view the calendar, press Menu 8 (Calendar). You may be prompted to set the date and time.

• Set the date using the mm/dd/yyyy format.

For example, if the date is May 31, 2002, enter 05312002. Existing characters are overwritten.

• Set the time using the mm:hh format.

For example, if the time is 7:00, enter 0700. Existing characters are overwritten. If your phone is set to display the am/pm time format, scroll to am or pm. Press OK.

Move from day to day

• Use the scroll keys to move through the calendar, OR...

•Press Options, scroll to Go to date, and press Select. Enter the date, and press OK.

[ 98 ]

Create a calendar note

This option lets you create a note with one of four categories: Reminder, Call, Meeting, or Birthday. You can set an alarm for any calendar note.

1 Go to the day you want, and press Options.

2 Scroll to Make note, and press Select.

3 Scroll to the type of note you want to create (Reminder, Call, Meeting,

or Birthday). Press OK.

REMINDER

The Subject field appears.

1 Enter the information, and press OK. The current date appears.

• If you want to change the date for this reminder, do so. Press OK.

• If you do not want to change the date, press OK.

The message Set alarm for the note? appears.

2 To answer the Set alarm for the note? question, press Yes or No.

•Press No to specify no alarm. Calendar note saved appears.

•If you press Yes, the Alarm date field appears.

3 Enter the date on which you want the alarm to sound, and press OK.

The Alarm time field appears.

4 Enter the time when you want the alarm to sound. Use the hh:mm

format. Press OK.

5 Select either am or pm, and press OK.

The message Calendar note saved appears.

Note:Step 5 appears only if you have selected the am/pm format.

[ 99 ]

CALL

The Number field appears.

1 Enter a number or press Search and find the number, then press OK.

The Date field appears.

2 Enter the date when you need to make this call, and press OK. The

Time field appears.

3 Enter the time when you need to make this call. Using the hh:mm

format. Press OK.

4 Select am or pm, and press OK. Set alarm for the note? appears.

Note: Step 4 appears only if you have selected the am/pm format.

5 To answer the Set alarm for the note? question, press Yes or No.

• If you don’t want to set an alarm, press No.

• The message Calendar note saved appears.

•If you press Yes, the Alarm date field appears.

6 Enter the date when you want the alarm to sound, and press OK. The

Alarm time field appears.

7 Enter the time (hh:mm format) for the alarm to sound. Press OK.

8 Select am or pm, and press OK. Calendar note saved appears.

Note: Step 8 appears only if you selected the am/pm format.

MEETING

The Subject field appears.

1 Enter the information, and press OK.

The current date appears. To use the current date, just press OK.

The Time field appears. You may enter a different date, and press OK.

2 Enter the time when you need to go to this meeting using the hh:mm

format. Press OK. Select am or pm. Press OK. Set alarm for the note? appears.

Note: Step 2 appears only if you selected the am/pm format.

[ 100 ]

3 Answer the Set alarm for the note? question, press Yes or No.

• If you do not want to set an alarm, press No.

• The message Calendar note saved appears.

•If you press Yes, the Alarm date field appears.

4 Enter the date when you want the alarm to sound, and press OK.

The Alarm time field appears.

5 Enter the time when you want the alarm to sound. Use the hh:mm

format. Press OK.

6 Select either am or pm, and press OK.

Note:Step 6 appears only if you selected the am/pm format.

The message Calendar note saved appears.

BIRTHDAY

The Name field appears.

1 Enter the name of the person having a birthday, and press OK. The

Date field appears.

2 Enter the month and day of the person’s birthday, and press OK. The

Year of birth field appears.

3 Enter the year using the yyyy format. Press OK. Set alarm for the

note? appears.

4 Press Yes or No.

• If you don’t set an alarm, Calendar note saved appears.

•If you press Yes, the Alarm date field appears.

5 Enter the date when you want the alarm to sound, and press OK. The

Alarm time field appears.

6 Enter the time for the alarm to sound. Use hh:mm format. Press OK.

7 Select either am or pm, and press OK. Calendar note saved appears.

Note:Step 7 appears only if you selected the am/pm format.

[ 101 ]

View the day’s notes

To view your notes for a given day, display that day in the calendar.

1 Press Options.

2 Scroll to View day notes.

3 Press Select.

If you have more than one note for the day, scroll the list. You have several Options:

• Erase - Erase the note.

• Edit - Edit the note.

• Move - Move the note to a different date.

View all notes

To view all notes in your calendar, press Options. Scroll to View all notes. Press Select. If your calendar has more than one note, scroll the list.

Erase notes

You must choose which notes to erase. Select from these erase options:

ERASE THE NOTE YOU’RE VIEWING

Press Options. Scroll to Erase. Press OK.

ERASE THE NOTES FOR A GIVEN DAY

While viewing the day in your calendar, press Options. Scroll to Erase notes and press Select. Scroll to Of chosen day, and press OK. Scroll the list of notes. When a note you want to erase appears, press Erase.

ERASE ONE NOTE AT A TIME FOR EACH NOTE IN YOUR CALENDAR

While viewing any day in your calendar, press Options. Scroll to Erase notes. Press Select. Scroll to One by one., and press OK. Scroll the list of notes. When a note you want to erase appears, press Erase.

[ 102 ]

ERASE ALL NOTES IN YOUR CALENDAR

To erase all notes in your calendar while viewing any day in your calendar:

1 Press Options.

2 Scroll to Erase notes.

3 Press Select.

4 Scroll to All at once, and press OK.

When a calendar alarm goes off

• To shut off the alarm, press OK.

• To shut off the alarm for 10 minutes, press Postpone. The alarm can be postponed 10-minute increments for up to 90 minutes.

Set the calendar date

1 Press Options. 2 Scroll to Set the date. 3 Press Select. 4 Enter the date using the mm/dd/yyyy format.

For example, if the date is May 31, 2002, enter 05312002. Existing characters are overwritten.

5 Press OK.

• DOWNLOAD RINGING TONES

Depending on your service provider, you can download (over the air) ringing tones and save them in your phone.

Note:Methods for downloading ringing tones vary with service providers. Some allow you to send a ringing tone to the phone from Internet web pages. Contact your service provider for details.

The names of tones that you download and save appear in the list that appears when you press Menu 3 -1 - 2 - 3 (Profiles - Normal - Customize - Ringing tone).

[ 103 ]

Note:The list also appears if you press Menu 3 - 2 - 2 - 3, Menu 3 - 3 - 2 - 3, etc., when you want to customize a profile other

than the Normal profile.

In addition to the 40 default ringing tones that come with your phone, you can save 10 downloaded ringing tones.

Notification of received ringing tone

When a ringing tone has been downloaded to your phone, the message Ringing tone received appears.

• To listen to the tone, press Options, scroll to Playback, then press OK. The phone plays the tone. To stop playing the tone, press Quit or

• To discard the tone immediately after you receive it (before you press Options), press Exit or . Or, to discard the tone after you have pressed Options, scroll to Discard, then press OK.

• To save the tone after you listen to it, scroll to Save, then press OK. If space in your phone’s memory exists for the tone, the phone prompt asks if you want to put the tone in a space. If you choose to put it in a space, the tone at first will be called Personal. If space does not exist, scroll until the name of the tone you want to replace is highlighted, then press Replace. To view the list of tones, press Menu 3 - 1 - 2 - 3 (or Menu 3 - 2 - 2 - 3, etc.).

• ALARM CLOCK

The alarm clock operates off the phone clock. If you turn your phone off after you set the alarm, it will automatically wake up and sound the alarm at the specified time. The alarm volume is determined by the current ringing volume and tone settings.

[ 104 ]

If you selected the Silent or Meeting profile or the Beep once or Silent ringing option, your alarm will quietly beep once. The best profile to use with the alarm clock is Normal or Outdoor unless you modified their original settings or renamed them. Your phone will vibrate if you’ve activated this feature in the current profile.

Set the alarm clock

1 Press Menu 4 - 2 - 2 (Settings - Phone settings - Alarm clock).

The Set alarm time message appears.

2 Enter the alarm time.

For example, to set the alarm for 7:00, press . Existing characters are overwritten.

3 Press OK. If the time format is am/pm, scroll to am or pm, and press OK.

The Alarm on message appears. On the Start screen, the alarm icon ( ) appears, indicating that the alarm is set.

Turn off the alarm clock when it rings

When the alarm clock rings:

• Press Stop to turn it off. If the phone was off when the alarm sounded, the phone asks if you want to keep the phone on. Press Yes or No.

•Press Snooze to set the alarm to go off again in 10 minutes.

If you don’t turn off the alarm, it sounds for one minute. Ten minutes later it will sound again for one minute. This continues until you press Stop.

Warning: Do not switch on the phone where wireless phone use is prohibited or where it might cause interference or danger.

Turn off the alarm clock altogether

If you never use the alarm, turn it completely off. Press Menu 4 - 2 - 2 (Settings - Phone settings - Alarm clock). Scroll to Off and press OK.

[ 105 ]

• CALCULATOR

The calculator adds, subtracts, multiplies, and divides.

1 Press Menu 7 (Calculator). 2 Enter the first number in the equation.

(To enter a decimal point, press . To clear one digit, press Clear. To clear all digits, press and hold Clear.)

3 Enter the symbol: (+ add), (- subtract), (* multiply), or(/ divide):

• Press as many times as necessary, OR...

•Press Options. Scroll to Add, Subtract, Multiply, or Divide. Press OK.

4 Enter the second number in the equation. 5 Calculate the result:

•Press , OR...

•Press Options. Scroll to Equals. Press OK.

[ 106 ]

Microsoft NSD-5FX User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

LEGAL INFORMATION

EXPORT CONTROLS

FCC/INDUSTRY CANADA NOTICE

1 FOR YOUR SAFETY

2) Welcome

• BEFORE YOU BEGIN

• UNDERSTAND NETWORK SERVICES

• VISIT NOKIA ON THE WEB

• CONTACT NOKIA

3) Prepare your phone for use

• INSTALL THE BATTERY

• CHARGE THE BATTERY

1 Connect the lead from the charger to the bottom of the phone.

2 Connect the charger to an AC wall outlet.

3 Disconnect the charger from the AC outlet and the phone:

• REMOVE THE BATTERY

1 Press and hold the button at the top of the battery.

2 Slide the battery toward the bottom of the phone.

3 Lift the battery off the phone.

4) Get to know your phone

• KEYS AND SCREEN

• NAVIGATION KEYS

• INDICATORS AND ICONS

5) Make and answer calls

• MAKE A CALL

3 Press . To end the call or to cancel the call, press .

• END A CALL

NOTES

1 Press Menu 4 - 4 -1 (Settings - Network services - Voice privacy).

2 Scroll to On, then press OK.

6) Use phone menus

• NAVIGATE MENUS

• LIST OF MENU SHORTCUTS

7) Enter characters into your phone

• ENTER CHARACTERS (EXCEPT IN A PHONE NUMBER FIELD)

• ENTER CHARACTERS INTO A PHONE NUMBER FIELD

8) Use the phone book

• USE PHONE BOOK MENUS

1 From the menu, press Names.

2 Scroll to Options. Press Select.

3 Highlight Scrolling view, and press Select.

4 Scroll until the name of the desired view appears. Press OK.

• ADD NAMES AND NUMBERS

1 Press Names.

2 Scroll to Add new, and press Select.

4 Press OK.

5 Enter the phone number. Press OK.

1 Enter a phone number, and press Save.

2 Enter a name at Name.

3 Press OK.

• CHANGE A STORED PHONE NUMBER

1 Press Names.

2 When Search appears, press Select.

4 Press Details to view the number.

5 Press Options.

6 If Edit is not highlighted, scroll to it. Press Select.

8 Enter the new number, and press OK.

• RECALL AND REDIAL NUMBERS

1 At the Start screen, press Names.

2 Enter the first few letters of the name you want to call.

1 At the Start screen, press Names.

2 At Search, press Select.

3 Enter the name of the person you want to call, and press OK.

• ERASE STORED NAMES AND NUMBERS

2 Press Details.

3 Press Options.

4 Scroll to Erase. Press Select. (Erase? appears.)

5 Press OK to erase the name and associated number.

• ERASE THE ENTIRE PHONE BOOK

1 Press Names.

2 Scroll to Erase all. Press Select.

4 Enter your security code, and press OK.

• CHECK MEMORY STATUS

1 Press Names, and scroll to Options. Press Select.

2 Scroll to Memory status. Press Select.

9) Use voice mail
