Microsoft NPD-1AW Users Manual

Nokia 3585 Phone at a glance

Power key

Earpiece

Display screen

4-way scroll keys

Selection key

Selection key

Talk key

End key

Number keys

Star key

Pound key

Microphone

Quick guide to functions

	Make a call	Enter a phone number, press
	Answer a call	Press	or Answer
	Answer a call with	Press
	call waiting
	End a call	Press
	Silence a call	Press Silence
	Decline a call	Press	or press Decline after pressing Silence
	Redial	Press	twice
	Adjust call volume	Press the scroll up or scrol down key during a call
	Use the in-call menu	Press Options while in a call
	Use 1-touch dialing	Press and hold keys 1 through 9. You must first assign
		a number in the phonebook to one of these numbers.
	Save a name and	Enter a number, press Options and select Save, then
	number	enter a name and press OK
	Recall a name/number	Press Names, select Find
	Recall a name/number	Press Options, scroll New call, press Select, press Find,
	during a call	enter first letter of the name
	Check voice mail	Press and hold		OR call your voice mailbox number
		(contact service provider for complete details)
	Send a text message	Press Menu 01-1. Write the message.
		Press Options, scroll to Send, press Select, enter the
		recipient’s number, press OK
	Read new message	Press Show, then press Select
		Press Options, select Reply, select As message, choose
	Reply to a message	a reply option, write the reply, press Options, select
		Send, then press OK
	Send an electronic	Recall a name from the phone book, press Details, press
		Options, select Send bus. card, Via text msg., enter the
	business card)
		recipient’s number, press OK.

The wireless phone described in this guide is approved for use in CDMA networks.

LEGAL INFORMATION

Part No. 9354442 Issue No. 1

Copyright © 2002 Nokia. All rights reserved.

Nokia is a registered trademark of Nokia Corporation. Nokia, Nokia Connecting People, Original Accessories logos, Snake II, Pass ‘n Rush, Space Impact, Bumper, and Racket are trademarks of Nokia Corporation and/or its affiliates.

Printed in Canada September 2002.

US Patent No 5818437 and other pending patents.

T9 text input software Copyright ©1999-2001. Tegic Communications, Inc. All rights reserved.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

The information contained in this user guide was written for Nokia 3585 phone. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

For your safety

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual.

SWITCH OFF WHERE PROHIBITED

Do not switch on the phone when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Don't use a hand-held phone while driving.

INTERFERENCE

All wireless phones may get interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any regulations or rules. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the phone at a refueling point. Don't use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Don't use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules.

USE SENSIBLY

Use only in the normal position. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your wireless phone is not water-resistant. Keep it dry.

BACKUP COPIES

Remember to make backup copies of all important data.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

INFRARED PRECAUTIONS

Do not point the IR (infrared) beam at anyone's eye or allow it to interfere with other IR devices. This device is a Class 1 Laser product.

CALLING

Ensure the phone is switched on and in service. Enter the phone number, including the area code, then press . To end a call, press . To answer a call, press .

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press as many times as needed (for example, to exit a call, to exit a menu) to clear the display. Enter the emergency number, then press . Give your location. Do not end the call until told to do so.

[ 2 ]

• MENU SHORTCUTS

Full list of shortcuts on page 23

1 MESSAGES

Text messages. . . . . . . . . . . 01-1 Write message . . . . . . 01-1-1 Inbox . . . . . . . . . . . . . . 01-1-2 Outbox. . . . . . . . . . . . . 01-1-3 Archive. . . . . . . . . . . . . 01-1-4 Templates . . . . . . . . . . 01-1-5 Erase messages . . . . . . 01-1-6 Message settings . . . . 01-1-7

Voice messages. . . . . . . . . . 01-2 Minibrowser messages. . . . 01-3

2 CALL LOG

Missed calls. . . . . . . . . . . . . . 2-1 Received calls . . . . . . . . . . . . 2-2 Dialed numbers. . . . . . . . . . . 2-3 Clear call lists . . . . . . . . . . . . 2-4 Call timers. . . . . . . . . . . . . . . 2-5

3 PROFILES

Normal . . . . . . . . . . . . . . . . . 3-1

Silent . . . . . . . . . . . . . . . . . . . 3-2

Meeting. . . . . . . . . . . . . . . . . 3-3

Outdoor . . . . . . . . . . . . . . . . . 3-4

Pager . . . . . . . . . . . . . . . . . . . 3-5

4 SETTINGS

Call settings . . . . . . . . . . . . . 4-1 Phone settings . . . . . . . . . . . 4-2 Time settings. . . . . . . . . . . . . 4-3 Accessory settings . . . . . . . . 4-4 Security settings. . . . . . . . . . 4-5 Network services . . . . . . . . . 4-6

5SYSTEM

6GAMES

Select game . . . . . . . . . . . . . . 6-1 Snake II. . . . . . . . . . . . . . . 6-1-1 Space Impact . . . . . . . . . . 6-1-2 Bumper. . . . . . . . . . . . . . . 6-1-3 Pass ‘n Rush . . . . . . . . . . . 6-1-4 Racket. . . . . . . . . . . . . . . . 6-1-5

Settings . . . . . . . . . . . . . . . . 6-2

7 VOICE

Voice tags. . . . . . . . . . . . . . . 7-1 Voice commands . . . . . . . . . . 7-2 Profiles . . . . . . . . . . . . . . . 7-2-1 Voice mailbox . . . . . . . . . 7-2-2 Infrared. . . . . . . . . . . . . . . 7-2-3 Voice recorder . . . . . . . . . 7-2-4 Call log . . . . . . . . . . . . . . . 7-2-5 Voice recorder . . . . . . . . . . . 7-3 Record . . . . . . . . . . . . . . . 7-3-1 Recordings list . . . . . . . . . 7-3-2

8MINIBROWSER

9MOBILELINK

Infrared . . . . . . . . . . . . . . . . . 9-1 Data/fax calls. . . . . . . . . . . . 9-2

10 ORGANIZER

Alarm clock . . . . . . . . . . . . . . 10-1 Calendar. . . . . . . . . . . . . . . . 10-2 To-do list . . . . . . . . . . . . . . . 10-3 Calculator . . . . . . . . . . . . . . 10-4 Stopwatch . . . . . . . . . . . . . . 10-5

1 1 Welcome

Congratulations on the purchase of your Nokia mobile phone - a new tool for the mobile information society.

Nokia recommends that you read this chapter before you use your new phone. You will find useful information about:

•How to use this guide

•How to understand network services

•How to contact Nokia

•GET THE MOST OUT OF THIS GUIDE

The tips that follow can help you use this guide efficiently as you learn to use your phone.

Understand the terms

This guide uses certain terms for certain actions.

•Press means to briefly press then release a key. For example, Press means “Press the zero key.”

•Press Menu means to press the key that is below the word Menu on the phone’s screen.

•Press and hold means to press and hold a key for two to three seconds (depending on the feature you’re using), then release the key.

•Use the selection keys and to choose an option on a menu.

•Highlighted means that an option you see on the screen is enclosed in a dark bar. Choices you make with the two selection keys act on the highlighted option.

[ 4 ]

Observe text conventions

1

This user guide provides text clues to help make instructions clear and easy to follow. These clues are called conventions.

Convention	What it means
bold	Indicates one of the following items:
	•	The word or phrase appears on the phone’s
		screen.
	•	Special text such as Notes and Warnings.

bold and blue Indicates the text is an address on the World Wide Web.

blue and italic A definition for the word or phrase appears in the terms
	list (glossary) near the end of the user guide.
italic	Italics indicate emphasis. Pay close attention to any
	information in italics.

Follow graphic clues

This guide uses certain icons (small pictures) to alert you to important information.

Tip: Provides information about a shortcut or an alternate method of doing something.

Note: Explains a feature or points out an important concept.

Important: Alerts you to information critical to using a feature correctly.

Caution! Warns you when you may lose information.

Warning! Helps you avoid personal injury, damage to the phone, or property damage.

[ 5 ]

1	Look for updates

From time to time, Nokia updates this user guide to reflect changes or corrections. The latest version can be found in the US market section of the Nokia Web site:

http://www.nokia.com

• UNDERSTAND WIRELESS NETWORK SERVICES

Your service provides’s wireless network may be equipped to provide special features or functions for use with your Nokia phone. These features are called network services, and may include some of the following:

•Voice mail and voice privacy

•Call waiting, call forwarding, and caller ID

•Text and picture messages

•Ability to block or send your own caller ID

•News and information services

•Selected Internet access services

Sign up with a service provider

Before you can take advantage of your service provider’s network services, you must sign up with a wireless service provider and subscribe to these services. Your service provider will make available descriptions of its services and instructions for using them.

Note differences among service providers

Wireless service providers may differ from each other in certain ways. For example, some networks may not support special language-dependent characters. Contact your service provider regarding your service needs.

[ 6 ]

• LEARN ABOUT ACCESSIBILITY SOLUTIONS

1

Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. Nokia maintains a Web site that is dedicated to accessibility solutions. For more information about phone features, accessories, and other Nokia products designed with your needs in mind, please visit the following Web site:

www.nokiaaccessibility.com

Alternate format user guides

This user guide is available in alternate formats, including:

•Braille

•Large print

•Audiocassette

•E-text (electronic documents on a 3.5-inch disk, in Microsoft Word or WordPerfect format).

To request any of the above formats, please contact Nokia Customer Care. Please see “Contact Nokia” on page 8 for more information.

Accessible features

Your phone has many accessible features, including the following:

•Tactile feedback when a you press a key

•Adjustable display contrast

•Ability to send and receive short text messages

•Convenience of one-touch dialing

•Vibrating alert for incoming calls and messages

•Volume keys located on the side of your phone

•Flashing lights alert for incoming calls and messages

•TTY/TDD device compatibility using the 2.5mm accessory jack

[ 7 ]

1	Text Telephone (TTY) and Teletype Device for the
	Deaf (TDD) device compatibility

Your Nokia phone is equipped with a universal 2.5mm accessory jack that can be used to connect any “cellular ready” or “cellular compatible” TTY/ TDD device’s cable to your phone. It may be possible to connect the TTY/ TDD device to the bottom connector using the HDA-8 phone adapter.

However, Nokia recommends using the 2.5mm accessory jack for optimum performance.

Important: Once your TTY/TDD device is connected to your phone, you must use the phone’s menu (Menu - Settings - Accessory settings - TTY) to enable the TTY/TDD mode.

LPS-1 mobile inductive loopset

The LPS-1 Loopset is a Nokia accessory designed to make the 6300 series phone more accessible to hearing-aid users.

The Nokia Loopset gives hearing-impaired wireless customers clear access to digital telephony for the first time. With the loopset, people who use a T-coil equipped hearing aid can make and receive calls without noise interference.

Note: The LPS-1 is sold separately as an accessory. Once you connect the LPS-1 to your phone, use the phone’s menu (Menu -

Settings - Accessory settings - Loopset) to enable loopset mode.

• CONTACT NOKIA

When you need help, the Nokia Care Center can provide information about Nokia products. Please refer to the table on the following page for more information on how to contact Nokia.

[ 8 ]

		1
Customer Care Center, USA	Customer Interaction Centre,
	Canada
Nokia Mobile Phones	Nokia Products Ltd.
7725 Woodland Center Blvd.,	601 Westney Road South
Suite #150	Ajax, Ontario L1S 4N7
Tampa, Florida 33614	Tel: 1-888-22-NOKIA
Tel: 1-888-NOKIA-2U	(1-888-226-6542)
(1-888-665-4228)	Fax: [phone]
Fax: [phone]
TTY/TDD Users Only:
1-800-24-NOKIA
(1-800-246-6542)

If you ever need to call Nokia Customer Care, Nokia Customer Interaction Center, or your wireless service provider, you will need to provide specific information about your phone. This information is provided on the phone’s label.

Your phone’s label

The label is on the back of your phone (under the battery). It contains important information about your phone, including the model and electronic serial numbers (ESN). Nokia recommends that you note this information on the title page of this guide. Please do not remove or deface the label.

Have the right information available

We recommend that you have the following information available before you contact the Nokia Customer Service department:

•the phone’s model number

•electronic serial number (ESN)

•your ZIP code

[ 9 ]

1	Have the phone or accessory available

Whether you’re calling about your phone or an accessory, have the equipment available when you call. A Nokia representative may asks a specific question about your phone or accessory, so please have the device available for quick reference.

• REGISTER YOUR PHONE

Make sure to register your phone at www.warranty.nokiausa.com or 1-888-NOKIA-2U (1-888-665-4228) so that we can serve your needs better if you should need to call the Nokia call center or have your phone repaired.

• E-NEWSLETTERS

When you register your phone, you can sign up for Nokia's e-newsletter Nokia Connections if you would like. You will receive tips and tricks on using your phone, accessory information, and special offers.

• CONTACT YOUR SERVICE PROVIDER

Some service providers have pre-programmed their customer support number into the phone. Pressing and holding the key (or the key that your service provider instructs you to use) for two seconds will automatically dial their customer support number.

This feature can be helpful if you’re having difficulties dialing a number, especially when traveling outside your home area.

If your service provider determines that the problem is Nokia-related, the provider’s representative will direct you to the Nokia Customer Care Center (USA) or Nokia Customer Service (Canada).

Note: This one-key feature may not be available on all systems. Contact your service provider for availability.

[ 10 ]

2 About your phone

2

This section gives you a brief introduction to your phone and provides you with quick steps for making, answering, and managing your calls. The rest of this guide user provides complete details on phone use.

• YOUR NOKIA PHONE

Power key

Infrared port

2.5mm

Antenna

Accessory jack

Ear piece

Volume keys

Screen

Right

Left selection key

selection key

Down scroll key

Up scroll key

End key

Talk key

Keypad

Microphone

[ 11 ]

• ABOUT THE ANTENNAS

2	Your phone is equipped with two
	antennas. The internal antenna is active

when the whip antenna is fully retracted. Extending the whip antenna disables the internal antenna

Whip antenna

Internal antenna

As with any other radio transmitting device, do not touch either of the two antennas unnecessarily when the phone is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Not touching the antenna area during a phone call optimizes the antenna performance and the talk time of your phone.

Hold the phone to your ear, placing your finger tips on the ridge of the battery cover (located below the antenna area on the back of your phone).

• ABOUT THE BATTERY

Install the battery

If your dealer has already installed the battery, please see “Charge the battery” on page 13.

1Remove the back cover of the phone by gripping the bottom of the phone between thumb and index finger. Press downward with the other thumb, sliding the cover toward the bottom of the phone. Set the back cover aside.

2Place the battery in the compartment with the label side facing up and the metal contacts aligned with the contact prongs.

[ 12 ]

3 Slide the battery into place and snap
the top of the battery in so that the	2
retainer bar comes down snugly next

to the battery.

4Replace the cover by sliding it upward until you hear a click.

Charge the battery

Follow these guidelines to charge the battery.

1With your phone on or off, connect the lead from the charger to the bottom of the phone.

2Connect the charger to an AC wall outlet.

The battery indicator bar appears on the screen and starts to scroll up and down after a few seconds.

3Disconnect the charger from the phone and AC outlet when the battery is fully charged.

After the indicator bar stops scrolling, the battery is approximately 80% charged, and is fully charged after an additional hour (approximately). See “Charging and Discharging” on page 145 for more information.

Note: For best performance, charge the battery for 24 hours before you use the phone. The charging time depends on the charger and battery you use. For example, the charging time for the BLB-3 battery with the ACP-8U charger is approximately 2 hours.

[ 13 ]

	Important: Do not leave the battery connected to a charger for
2	more than 72 hours, since prolonged maintenance charging could
	shorten its lifetime.

Remove the battery

You will need to remove the existing battery if you want to install a new battery or if you’ve purchased a spare battery. Make sure the phone has been turned off for ten seconds.

1Remove the back cover of the phone as shown in step 1 on page 12.

2Place your index finger in the space at the top of the battery, and press toward the bottom of the phone.

3Take out the battery.

Warning! Use only your

hands to remove the battery. Do not puncture, burn or use any objects that may damage the phone or the battery. Please recycle the battery, or dispose of properly.

Important battery information

•Recharge your battery only with a charger approved by Nokia.

•You can switch the phone on and use it for calls while the battery is charging.

•If the battery is totally empty, it may take a few minutes for the battery indicator to appear on the screen.

•If you switch the phone on when charging is complete, the message Battery full is displayed momentarily.

•Charging time depends on the charger and battery used. Please see “Battery information” on page 144 for more information.

•If the battery has become completely empty, you may need to recharge it for a few minutes before you can make or receive calls.

[ 14 ]

Prolong battery life

A battery lasts longer and performs better if you fully discharge it from	2
time to time. To discharge your battery, follow either of these steps.

•Leave your phone switched on until the battery drains completely.

Ignore any messages to recharge your battery and let the battery completely discharge.

•Or, use the battery discharge feature of any approved accessory available for your phone.

Important: Do not attempt to discharge the battery by any means other than those just described.

•SWITCH YOUR PHONE ON OR OFF

To switch your phone on or off, press

and hold the power key (located on the

Power key

top of the phone) for two seconds.

Warning! Do not switch on the phone when wireless phone use is prohibited or when it may cause interference or danger.

• CHECK THE START SCREEN

The Start screen refers to the phone’s display when no calls are in progress, and there are currently no menu or phone book entries displayed.

You can easily return to the Start screen from any location (other than an active call) simply by pressing the key. However, keep in mind

that any text or numbers that you were entering at the time will be lost, and your work will not be saved.

[ 15 ]

The following table describes the primary indicators and icons found on

the Start screen:

2

Element	Description

Home Your service provider’s name may appear here.

Shows the signal strength of the wireless network where you are. The higher the bar, the stronger the signal.

Shows the battery charge level.

The higher the bar, the higher the power level in the battery.

Menu

The entry point for your phone’s menu. Press (left selection key) to view the menu options.

The entry point for the phone book menu. Press Names (right selection key) to view the phone book menu

options.

Icon appears in upper left corner of screen, indicating that you are in a digital network.

• LEARN ABOUT THE KEYS

The table on the following page contains a summary of how the various keys on your phone work.

[ 16 ]

Key	Description	2
	Power: Press and hold to switch the phone on or off.

Pressing this key momentarily displays a list of profiles.Power key also displays menu while using Minibrowser

Selection: Press to choose the option shown by the word above the key (for example, Menu or Names).

Scroll keys: Press to scroll up or down through a menu list of options.

Talk: Press to make a call to the name or number shown on the screen or to answer a call. Pressing this key when not in a call (or when not in the menu or phone book) displays a list of recently dialed numbers.

						End: Press	to end a call, to silence the ring
						from an incoming call, or to exit the phone book or
						menus completely. Used as Back key in Minibrowser.
						Number: Use keys 1 through 9 to enter numbers and
						letters. Press and hold				to dial your voice
	through
						mailbox. Press and hold					to launch the
						Minibrowser.
						# key: Use # key to change case of text, or to enable
						or disable predictive text input.
						* key: Use * key to enter special characters (example:
						punctuation) or access special characters menu.
						Volume: Use to increase or decrease volume.

[ 17 ]

• MAKE AND ANSWER CALLS

2	Use the following table as a quick reference for making and answering
	calls:
	Task	Instructions
	Make a call 1	Enter the number using the keypad (include area
		code as needed).

2Press

3Hold the phone as you would any other telephone, with the ear piece over your ear and the microphone near your mouth.

Answer a	When your phone rings, press
call
End a call	Press	to terminate the active call.
Reject a call	Press	when you don’t want to answer a call, but
	still want to silence the ringer.
Avoid	Press Menu then			(within three seconds) to lock
accidental	your keypad. This		activates the Keyguard feature.
calls
Unlock	When the keypad is locked, press Menu then
keypad	(within three seconds). This deactivates the				Keyguard
	feature.

[ 18 ]

• REVIEW PHONE SYMBOLS

The following is a collection of the various indicators and icons you may 2 see on your phone.

	Symbol				Description
					A call is in progress.
					You have selected the Silent profile (silencing your
					phone’s ringer, keypad tones, warning tones, etc.)
					Keyguard is active
					You have one or more voice messages waiting.
					You have one or more unread text messages waiting.
					Digital service is available.
					Letters you enter appear as uppercase (ALL CAPS).
					Letters you enter appear in lowercase.
					Letters you enter appear in sentence case (first word in
					sentence capitalized) or title case (in phone book).
					Characters you enter appear as numbers.
					Predictive text mode is active. Predictive text feature
					available for Calendar and To-do list notes, or writing
					text messages.
					Predictive text mode activated. Characters you enter
					appear in sentence case (only first word in sentence
					capitalized).
					Predictive text mode activated. Characters you enter
					appear as uppercase letters.

[ 19 ]

2	Symbol	Description
		Predictive text mode activated. Characters you enter
		appear as lowercase letters.
		Insert symbol mode, used to enter special characters
		such as punctuation marks.
		The alarm clock is set.
		Indicates that a reminder has expired.
		Indicates you are roaming.
		Indicates call over a secure connection.
		Indicates that a headset is connected (either via the
		2.5mm jack or to bottom of phone)
		Indicates phone is in handsfree car kit
		Indicates a connection to packet data network.
		Indicates you have a minibrowser message.
		Indicates TTY/TDD mode is active

• USE THE SELECTION KEYS

Note the four selection keys
beneath the screen. The function	Left
of these keys is determined by
the word shown above them on	selection
the screen.	key

Right selection key

[ 20 ]

For example, pressing the left selection key when the word Menu appears
above it shows the first of many menus. You scroll through the menus			2
using the	and	keys.

Likewise, pressing the right selection key when Names appears above it displays the phone book menu.

When this guide says, “Press Menu,” it means, “Press the selection key beneath the word Menu.”

• VIEW YOUR PHONE’S HELP SYSTEM

Your phone provides brief descriptions of all menu options. To view any of the help texts:

1Scroll to a menu or submenu option.

2Wait about 15 seconds.

A short message appears, describing the option and what it does.

3Use and as needed to scroll down through longer descriptions.

ENABLE/DISABLE HELP SYSTEM

Press Menu 4-2-4 (Settings > Phone settings > Help text activation) to turn the phone’s help system on or off.

• BROWSE PHONE MENUS

Your phone’s menu system displays choices you can make to change settings on your phone or gives you access to various phone features. Your phone has 10 menus, plus the phone book menu (Names). Each menu can contain several levels of submenus.

Menu items

[ 21 ]

You can use menus and submenus two ways: by scrolling or by using a

shortcut.

2

Check the menu number, header line, and scroll bar

A header line appears at the top of your screen when in the phone book or while navigating the menus. The header line provides you with a reminder of the phone book entry you are working with, or serves as a reminder of the menu or sub-menu with which you are working.

Header line

Scroll bar with tab

A scroll bar appears on the right side of the screen when you scroll through the main menu. A tab on the bar gives you a visual indication of your relative position in the menu structure.

The menu number is located at the top of the scroll bar.

Scroll through menus

1At the Start screen, press Menu, then scroll through the menus using the and keys.

2Press Options, Select, or OK, pressing the selection key for the option you want.

3Use the scroll and selection keys to navigate the submenus; press the

key to return to the Start screen.

SCROLLING TIPS

•You can scroll upward (backward, so to speak) as well as downward to find some of the most frequently used submenu options.

•You can return to the previous menu level by pressing Back.

•To exit a menu and return to the Start screen, press . If you leave a menu by pressing , you cancel any changes you made.

•Some menus may not appear. Ask your service provider for details.

•ADD 4-WAY SCROLL TEXT

[ 22 ]

Learn about menu shortcuts

Menus and options are numbered so that you

can jump directly to the option you use 2 frequently. The numbers appear in the top right

corner of the screen and show your location in the menu.

USE A SHORTCUT

Example: To turn on Automatic redial:

1Press Menu.

2Within three seconds, press 4-1-2-1 (Settings > Call settings >

Automatic redial > On).

•MENU AND MENU SHORTCUTS

MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . . . 1
Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . . 01-1
Write message (Text/Page) . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 01-1-1
Add e-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-1-1
Add number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-1-2
Enter text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-1-3
List recipients. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-1-4
Send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-1-5
Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 01-1-2
Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-1
Reply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-2
Use number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-3
Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-4
Use Web link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-5
Save address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-6
Forward . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-7
Move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-8
Rename . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-9
Save picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	01-1-2-10
Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. 01-1-3

[ 23 ]

Archive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-4 Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-5 2 Erase messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-6 All read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-6-1 Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-6-2 Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-6-3 Archive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-6-4 Message settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-7 Sending options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-7-1

Other settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1-7-2 Voice messages1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-2

Listen to voice messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-2-1 View details of last voice mail . . . . . . . . . . . . . . . . . . . . . . . . . 01-2-2 Voice mailbox number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-2-3 Clear voice mail icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-2-4 Minibrowser messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-3

CALL LOG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2

Missed calls2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 Call time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-1 Send message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-2 View number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-3 Use number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-4 Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-5 Add to name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-6 Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-7 Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1-8

Received calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2 Dialed numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3 Clear call lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4 All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4-1 Missed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4-2 Received . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4-3 Dialed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4-4

1Menu option may vary, based on your service provider’s requirements.

2Options for the Received calls and Dialed calls lists are identical to Missed calls list of options.

[ 24 ]

Call Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . 2-5
Duration of last call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-5-1
Show call time on display. . . . . . . . . . . . . . . . . . . . . . . . .	2-5-1-1 2
Duration of dialed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-5-2
Duration of received calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-5-3
Duration of all calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-5-4
Life timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-5-5
Clear timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-5-6
Data/fax calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 2-6
Last sent data/fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-1
Last received data/fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-2
All sent data/fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-3
All received data/fax. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-4
Duration of last data/fax call. . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-5
Duration of all data/fax calls . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-6
Clear all data/fax logs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-6-7
Minibrowser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 2-7
Last sent browser data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-1
Last received browser data. . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-2
All sent browser data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-3
All received browser data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-4
Last browser session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-5
All browser sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-6
Clear all browser logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	2-7-7
PROFILES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 3

Normal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-1 Customize1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2

Ringing options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-1 Ringing tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-2 Ringing volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-3 Vibrating alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-4 Message alert tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-5 Keypad tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-6

1Customize options for Silent, Meeting, Outdoor, and Pager profiles are identical to those of the Normal profile

[ 25 ]

Warning tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-7

Accepted caller groups . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-8 2 Profile name1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-2-9

Timed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-3 Silent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 Meeting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 Outdoor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 Pager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4

Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1 Anykey answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-1 Automatic redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-2

1-touch dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-3 Auto-update of service2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-4

Minibrowser confirmation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-5 None . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-5-1 On connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-5-2 On exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-5-3 Both. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-5-4

Calling card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-6 No card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-6-1 Card A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-6-2 Card B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-6-3 Card C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-6-4 Card D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-6-5

Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2 Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-1 Touch tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-2 Manual touch tones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-2-1 Touch tone length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-2-2 Welcome note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-3 Help text activation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-4

1Normal profile cannot be renamed.

2Menu option may not be visible, based on your service provider’s requirements.

[ 26 ]

Lights1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-2-5
On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-2-5-1
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-2-5-2 2
Display contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-2-6
Restore factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-2-7
Time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . 4-3
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-1
Show (Hide) clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-1-1
Set the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-1-2
Time format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-1-3
Auto update of date & time. . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-2
On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-2-1
Confirm first. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-2-2
Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-3-2-3
Accessory settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 4-4
Handsfree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-1
Default profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-1-1
Automatic answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-1-2
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-1-3
Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-2
Default profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-2-1
Automatic answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-2-2
Loopset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-3
Use loopset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-3-1
Default profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-3-2
Automatic answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-3-3
TTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-4
Use TTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-4-1
Default profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-4-2
Automatic answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-4-4-3
Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 4-5
Call restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-5-1
Restrict outgoing calls . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-5-1-1
Restrict incoming calls . . . . . . . . . . . . . . . . . . . . . . . . . . .	4-5-1-2

1 Appears when in Handsfree mode.

[ 27 ]
