CChhaapptteerr 11

Introducing the Mainboard

IInnttrroodduuccttiioonn

Congratulations on purchasing the K7S5A mainboard. This mainboard has a
Socket-A processor socket for the type of AMD K7 processors. You can in-
stall any one of these processors on the mainboard. The mainboard supports
front-side bus speeds of 200/266MHz.

This mainboard uses the SiS 735 chipset which supports a 4X AGP slot for
highly graphics display, DDR interface and Ultra DMA 33/66/100 function,
provides outstanding high system performance under all types of system op­erations. The mainboard has a built -in AC97 Codec, provides an AMR (Audio
Modem Rise r) slot to support Audio and Modem application, and has a built-in
10BaseT/100BaseTX Network Interface. In addition, the mainboard has an
extended set of ATX I/O Ports including PS/2 keyboard and mouse ports, two
USB ports, a parallel port, and two serial ports. Two extra USB ports can be
added using the Extended USB Module that connects to the mainboard.

This mainboard has all the features you need to develop a powerful multime­dia workstation. The board is ATX size and has power connectors for an ATX
power supply.

CChheecckklliisstt

Compare the mainboard’s package contents with the following checklist:

Standard Items

• One mainboard

• One diskette drive ribbon cable

• One IDE drive ribbon cable

• Software support CD

• The User’s Manual

FFeeaattuurreess

Processor

Memory

Expansion Slots

Onboard IDE
channels

Power
Supply and
Power

Management

AC’97 Audio
Codec

Built-in Ethernet
LAN (optional)

Onboard I/O
Ports

Hardware Moni­toring

• Supports AMD Athlon XP/Athlon/Duron processors

• Supports 200/266 MHz Front-Side Bus

Note: Processors are automatically configured using

firmware and a synchronous Host/DRAM Clock
Scheme.

• Two 168-pin DIMM slots for SDRAM memory modules

• Two 184-pin DIMM slots for DDR memory modules

• Support SDRAM up to 133 MHz /DDR up to 266 MHz

memory bus

• Maximum installed memory is 1GB

Note: You cannot use SDRAM and DDR simultane-

ously.

• One AMR slot for a special audio/modem riser card

• One AGP4X slot for AGP 2.0-compliant interface

• Five 32-bit PCI slots for PCI 2.2-compliant bus interface

• Primary and Secondary PCI IDE channels

• Support for PIO (programmable input/output) modes

• Support for Multiword DMA modes

• Support for Bus Mastering and Ultra DMA 33/66/100

modes

• ATX power supply connector

• Meets ACPI 1.0b and APM 1.2 requirements, keyboard

power on/off

• Supports RTC Alarm, Wake On Modem, AC97 Wake-Up
and USB Wake-Up

• Compliant AC97 2.2 specification

• Supports 18-bit ADC (Analog Digital Converter) and DAC

(Digital Analog Converter) as well as 18-bit stereo full­duplex codec

• Built-in 10BaseT/100BaseTX Ethernet LAN

• LAN controller integrates Fast Ethernet MAC and PHY

compliant with IEEE802.3u 100BASE-TX, 10BASE-T and
ANSI X3.263 TP-PMD standards

• Compliant with ACPI 1.0 and the Network Device Class
Power Management 1.0

• High Performance provided by 100Mbps clock generator
and data recovery circuit for 100Mbps receiver

• Built-in Multi-threaded IO Link Delivering 1.2GB/s

• Provides PC99 Color Connectors for easy peripheral

device connections

• Floppy disk drive connector with 1Mb/s transfer rate

• Two serial ports with 16550-compatible fast UART

• One parallel port with ECP and EPP support

• Two USB ports and optional two USB ports module

• Two PS/2 ports for keyboard and mouse

• One infrared port connector for optional module

Built-in hardware monitoring for CPU & System temperatures,
fan speeds and mainboard voltages.

2

Onboard Flash
ROM

Dimensions ATX form factor (30.5cm x 24.4cm)

Supports Plug and Play configuration of peripheral devices
and expansion cards

CChhoooossiinngg aa CCoommppuutteerr CCaassee

There are many types of computer cases on the market. The mainboard co m­plies with the specifications for the ATX system case. Some features on the
mainboard are implemented by cabling connectors on the mainboard to ind i­cators and switches on the system case. Ensure that your case supports all
the features required. The mainboard can support one floppy diskette drive
and four enhanced IDE drives. Ensure that your case has sufficient power and
space for all the drives that you intend to install.

Most cases have a choice of I/O templates in the rear panel. Make sure that
the I/O template in the case matches the I/O ports installed on the rear edge
of the mainboard.

This mainboard has an ATX form factor of 30.5 x 24.4 cm. Choose a case that
accommodates this form factor.

This concludes Chapter 1. The next chapter explains how to install the mai n­board.

3

MMaaiinnbbooaarrdd CCoommppoonneennttss

4

CChhaapptteerr 22

Installing the Mainboard

SSaaffeettyy PPrreeccaauuttiioonnss

Follow these safety precautions when installing the mainboard:

• Wear a grounding strap attached to a grounded device to avoid
damage from static electricity.

• Discharge static electricity by touching the metal case of a safely
grounded object before working on the mainboard.

• Leave components in the static-proof bags they came in.

• Hold all circuit boards by the edges. Do not bend circuit boards.

QQuuiicckk GGuuiiddee

This Quick Guide suggests the steps you can take to assemble your system
with the mainboards.

The following table provides a reference for installing specific components:

Locating Mainboard Components Go to page 4
Installing the Mainboard in a Case Go to page 6
Setting Jumpers Go to page 6
Installing Case Components Go to page 8
Installing the CPU Go to page 10
Installing Memory Go to page 11
Installing an HDD and CD-ROM Drive Go to page 13
Installing an FDD Go to page 14
Installing Add-on Cards Go to page 15
Connecting Options Go to page 16
Connecting Peripheral (I/O) Devices Go to page 18

2. Secure the mainboard with

IInnssttaalllliinngg tthhee MMaaiinnbbooaarrdd iinn aa CCaassee

Refer to the following illustration and instructions for installing the mainboard
in a case:

This illustration shows an ex­ample of a mainboard being
installed in a tower-type case:

Note: Do not overtighten

the screws as this
can stress the main­board.

Most system cases have
mounting brackets installed in
the case, which correspond to
the holes in the mainboard.
Place the mainboard over the
mounting brackets and secure
the mainboard onto the mount­ing brackets with screws.

Ensure that your case has an I/O template that supports the I/O ports and
expansion slots on your mainboard.

CChheecckkiinngg JJuummppeerr SSeettttiinnggss

This section explains how to set jumpers for correct configuration of the main­board.

screws where appropriate.

1. Place the mainboard
over the mounting brackets.

Setting Jumpers

Use the mainboard jumpers to set system configuration options. Jumpers with
more than one pin are numbered. When setting th e jumpers, ensure that the
jumper caps are placed on the correct pins.

The illustrations below show a 2-pin jumper.
When the jumper cap is placed on both pins,
the jumper is SHORT. If you remove the
jumper cap, or place the jumper cap on just
one pin, the jumper is OPEN.

Short Open

This illustration shows a 3-pin
jumper. Pins 1 and 2 are SHORT.

1

2

6

3

JP1

JP4

Checking Jumper Settings

The following illustration shows the location of the mainboard jumpers. Pin 1 is
labeled.

Jumper Settings

Jumper Type Description Setting (default)

JP1 3-pin Keyboard Power

On Selector

JP4 3-pin Clear CMOS

jumper

JP1: Keyboard Power On Selector

If you enable the keyboard power on feature, you can use hot keys on your
keyboard as a power on/off switch for the system.

Note: The system must provide 1A on the +5VSB (+5V Standby) signal before

using the Keyboard Power On function.

JP4: Clear CMOS Jumper

Use this jumper to clear the contents of the CMOS memory. You may need to
clear the CMOS memory if the settings in the Setup Utility are incorrect and
prevent your mainboard from operating. To clear the CMOS memory, disco n-

1-2: Disable Key­board Power On

2-3: Enable Key­board Power On

1-2: Clear CMOS

2-3: Normal

7

1

1

nect all the power cables from the mainboard and then move the jumper cap
into the CLEAR setting for a few seconds.

CCoonnnneeccttiinngg CCaassee CCoommppoonneennttss

After you have installed the mainboard into a case, you can begin connecting
the mainboard components. Refer to the following:

1. Connect the power
connector from the
power supply to the
ATX_PWR1
connector on the
mainboard.

2. Connect the CPU
cooling fan cable to
CPUFAN.

3. If there is a cooling
fan installed in the
system chassis,
connect the cable
from the cooling fan to
the SYSFAN fan
power connector on
the mainboard.

4. Connect the case switches and indicator LEDs to the FP1 header JP2 for on­board LAN LED.

5. Connect the case speaker cable to SPK1.

SPK1: Speaker Connector

Connect the cable from the PC speaker to the SPK1 header on the mainboard.

Pin Signal Name

1

SPKR

2

NC

3

Ground

4

+5V

JP2: Onboard LAN LED Connections

If you have a set indicator LEDs for the onboard LAN communication, you can
connect the LED cable to the header JP2.

Pins 1-2 are for Link LED. Pins 3-4 are for 10/100 Mbps mode LED, the on­board LAN run in 100 Mbps mode when the LED lit.

8

9 10

1 2

Pin Signal Name

1

Link LED

2

VCC

3

Ground

4

10/100 Mbps mode LED

The FPI Connector

This panel connector provides a set of switch and LED connectors found on
ATX case. Refer to the table below for information.

Device Pins

HD_LED_P 1

FP PWR/SLP 2, 4

HD_LED_N 3
RST_SW_N 5, 8
RST_SW_P 6, 7

KEY 9, 10

Note: The plus sign (+) indicates a pin which must be connected to a positive

voltage.

9
