Microsoft BT101 Revised Manual
CONFIDENTIAL
INFORMATION - MANUAL
02 November 2000
LRB-1 IS A BLUETOOTH TRANSCEIVER COMPONENT AND WILL ONLY BE USED BY NOKIA IN APPROPRIATE PRODUCTS. THESE PRODUCTS WILL HAVE TO BE TESTED AGAIN FOR COMPLIANCE.
WARNING: USERS ANS INSTALLERS MUST USE ONLY THOSE ANTENNAS SPECIFIED BY NOKIA, TO COMPLY WITH FCC'S R.F. EXPOSURE REQUIREMENTS TO AVOID EPOSING PERSONS TO HARMFUL R.F. RADIATION. DO NOT SUBSTITUTE ANY SUPPLIED ANTENNA RECOMMENDED BY THE SUPPLIER. CONTACT YOUR SUPPLIER FOR FURTHER INSTRUCTIONS.
Exhibit 10 revision 0.1 |
FCC ID: OW3BT101 |
Applicant: Nokia Mobile Phones |
Copyright © 2000 Nokia Mobile Phones |
|
1/11 |
LRB-1 Nokia Bluetooth Tranceiver Component
- Preliminary Information -
¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾
LRB-1 Nokia Bluetooth Transceiver
Component
Product Features
qComplete stand-alone Class 2 Bluetooth transceiver system
qIncluding baseband controller, 2.45 GHz radio part and firmware up to HCI
qBluetooth V 1.0 B compliant and pre-certified
qSuitable for both voice and data applications
qPoint-to-Multipoint connection support
qPark, Hold and Sniff modes
qHigh speed UART and flexible PCM data interfaces
qSeveral programmable control interfaces plus ADC input
qInternal oscillators and power regulators
qAdjustable I/O voltages
qcompletely shielded and FCC approved
qOptimized size and form-factor: 23 x 19 x 2 mm3
WARNING : LRB-1 IS A BLUETOOTH TRANSCEIVER COMPONENT, WHICH HAVE BEEN TESTED WITH A RECOMMENDED ANTENNA DESIGN AND SHOULD ONLY BE USED BY NOKIA IN APPROPRIATE PRODUCTS. THESE PRODUCTS WILL HAVE TO BE TESTED AGAIN FOR COMPLIANCE. USERS ANS INSTALLERS MUST USE ONLY THOSE ANTENNAS SPECIFIED BY NOKIA, TO COMPLY WITH FCC'S R.F. EXPOSURE REQUIREMENTS TO AVOID EPOSING PERSONS TO HARMFUL R.F. RADIATION. DO NOT SUBSTITUTE ANY SUPPLIED ANTENNA RECOMMENDED BY THE SUPPLIER. CONTACT YOUR SUPPLIER FOR FURTHER INSTRUCTIONS.
¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾
Nov 2000 Confidential 2/11
LRB-1 Nokia Bluetooth Tranceiver Component
- Preliminary Information -
¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾
Overview
The LRB-1 Nokia Bluetooth Tranceiver Component is a highly integrated multi-chip component which represents a complete standalone Bluetooth transceiver system for short-range wireless applications. All necessary components including the baseband controller, the radio part for the 2.45 GHz system and a flash memory of 2 MBit are integrated on a single PCB using advanced flip chip interconnection techniques. The Bluetooth Tranceiver Component is delivered with all needed firmware of the Bluetooth protocol stack up to HCI which resides in the on-board flash memory. A traditional high-IF radio architecture providing good sensitivity has been used.
¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾
Nov 2000 Confidential 3/11
LRB-1 Nokia Bluetooth Tranceiver Component
- Preliminary Information -
¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾
Block Diagram
2.4GHz |
SPDT |
BALUN |
SAW 111MHz |
DEMOD-TANK |
ANT |
|
2 |
|
|
|
|
|
|
|
TXON |
|
|
|
|
|
|
|
|
BBON |
VBBEN
13MHz |
Radio |
|
|
VCCVCO |
|||||
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VCC |
|
|
|
|
|
|
|
|
|
ADCREG |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VCCADC
RESETX |
|
|
|
|
|
VBB |
|
|
|
|
|
|
|
||
SLEEPX |
|
|
|
|
|
|
|
DBUSRFCLK |
|
|
|
|
|
|
|
DBUSRFDA |
|
|
|
GND |
|
|
|
DBUSRFENX |
|
|
|
|
|
|
|
|
DBUSRF |
|
|
|
|
|
|
|
BBCLK |
RFDATA |
|
|
|
|
|
|
3 |
2 |
|
|
|
|
|
RFDATA1 |
|
|
|
|
|
||
|
|
|
|
|
|
||
RFDATA2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
VIO |
|
OSCON |
|
|
|
|
|
VDD |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
VAPPL |
|
|
Baseband |
|
|
|
|||
|
|
|
|
|
|
ADCREF |
|
|
|
|
|
|
|
ADCIN |
|
|
|
|
|
|
|
CENX |
|
|
|
|
|
|
|
GPP0 |
|
|
32kHz |
|
|
|
|
GPP1 |
|
|
|
|
|
|
GPP2 |
||
TCK |
|
|
|
|
|
||
|
|
|
|
|
GPP3 |
||
TRST |
|
|
|
|
|
||
JTAG |
|
|
GND |
|
GPP4 |
||
TDI |
|
|
GPP |
||||
CSX WRX RDX |
DATA |
ADDR |
GPP5 |
||||
TDO |
|
||||||
5 |
|
|
|
12 |
GPP6 |
||
TMS |
|
|
|
||||
16 |
17 |
|
|
GPP7 |
|||
WRX |
|
|
|
||||
|
|
|
|
|
GPP8 |
||
|
|
|
|
|
|
||
|
|
|
|
|
|
GPP9 |
|
|
|
|
|
|
|
GPP10 |
|
|
|
|
|
|
|
GPP11 |
|
|
Flash Memory |
|
|
VPP |
|||
|
|
|
|
||||
|
|
|
|
|
|
RDY |
|
|
|
|
|
GND |
|
GND |
|
|
|
|
|
|
|
||
¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾¾ |
|||||||
Nov 2000 |
|
Confidential |
|
|
4/11 |
||
