Microsoft AAA User Guide

Quick Guide
xxx

2015-02-09 Issue 1.0 EN RM-1065

Keys and parts

Important: For important info on the safe use of
your device and battery, read “For your safety” and
“Product and safety info” at www.microsoft.com/
mobile/support/ before you take your device into
use. The same info is available in the in-device user
guide. Select

1Earpiece
2 Audio connector AHJ 3.5 mm
3 Front camera
4 Light sensor
5 Volume keys
6 Power/Lock key
7Microphone
8Flash
9Loudspeaker
10 NFC area
11 Camera
12 Antenna area
13 Micro-USB connector

Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable, may
be sold separately.

Avoid touching the antenna area while the antenna
is in use. Contact with antennas affects the
communication quality and may reduce battery life
due to higher power level during operation.

Lumia Help+Tips.

Get started

Before you start using your phone, remove the back
cover to insert the micro-SIM cards.

Remove the back cover

Make sure the phone is switched off.

1. With the back of the phone facing you, put your
finger in the seam between the screen frame and
the bottom corner of the back cover. Do not use any
tools, as they may damage the phone.

2. Bend the cover open, and remove it.

3. If the battery is in, lift it out.

Insert the SIM and memory card

1. Slide the micro-SIM card (SIM1) into the SIM slot

with the metal contact area down.

2. If you have a second SIM card, slide it into the
SIM2 slot.

3. If you have a memory card, slide the card into the
memory card slot.

It is recommended that you use a fast microSD card
from a well-known manufacturer.

Important: Your device uses a micro-SIM card,
also known as a mini-UICC SIM card. Use only
original micro-SIM cards. Use of incompatible SIM
cards, or use of SIM card adapters, may damage the
card or the device, and may corrupt data stored on
the card.

Replace the battery and back cover

1. Line up the battery contacts, and put the battery

in.

2. Press the bottom edge of the back cover against
the bottom edge of your phone.

3. Snap the cover into place.

4. To switch your phone on, press and hold the

power key.

Charge the battery

Plug a compatible charger into a wall outlet, and
connect the micro-USB end to your phone. You can
also charge your phone from a computer with a USB
cable, but it may take a longer time.

If the battery is completely discharged, it may take
up to 20 minutes before the charging indicator is
displayed.

Set up your phone

1. To switch your phone on, press and hold the

power key, and follow the instructions shown on
your phone.

2. When asked, create your Microsoft account if you
don’t have one already, or sign in with your existing
Xbox, Hotmail, or Outlook username and password.
Make sure you remember the credentials for the
Microsoft account you added to your phone.

You need a Microsoft account to back up and
restore your phone, to buy, install, and update apps,
and to access some Microsoft services, such as
OneDrive.

Allow some minutes while your phone installs all its
features.

Tip: If your screen switches off, press the power
key, and drag the lock screen up.
