Microsensys PENSOLIDUFX User Manual

iID®PENsolid UHF

iID PENsolid UHFcc System: iID-4000 EU

RFID Pen Style Read/Write Unit v1.00 with RTC, MEM, BT, USB, Li accu Display: LEDs for power, BT, status Buttons: SCAN, F1, F2 System: iID4000 EU, ISO 18000-6c, EPC G2, all customized Antenna: P3U Operation Mode: DOC / SPC Bluetooth: SPP / HID Dimensions: 120x26x20 mm³, Li Ion Battery 450mAh Including: micro USB cable, hand strap

Product Code: 43.72.850.xx

iID PENsolid UHFcc System: iID-4000 US

RFID Pen Style Read/Write Unit v1.00 US frequency with RTC, MEM, BT, USB, Li accu Display: LEDs for power, BT, status Buttons: SCAN, F1, F2 System: iID4000 US, ISO 18000-6c, EPC G2, all customized, FCC Antenna: P3U Operation Mode: DOC / SPC Bluetooth: SPP / HID Package: 120x26x20 mm³, Li Ion Battery 450mAh

Product Code: 43.72.851.xx

User Manual

RFID Read/Write Device for mobile scan applications

iID® PENsolid is a mobile RFID device suitable as Bluetooth™ enabled RFID read/write unit for UHF (868/915 MHz) frequency applications.

Based on it’s PEN style form and the implemented touch tip it can be used as input device for tablets and

smartphones with touch and capacitive screens. iID® PENsolid can be configured in Bluetooth™ HID mode. In this operation mode it emulates a Bluetooth™ keyboard.

Depending on operation mode, iID® PENsolid works together with Windows, Android and iOS devices.

Product Short Description & available Versions:

An additional product version of iID® PENsolid is available for HF (13.56 MHz) RFID applications. Please contact microsensys for further information.

iID®PENsolid UHF

Industry Canada ID: 21228-PENSOLIDUFX, contains Bluetooth™ module IC: 5123A-BGTWT12A

This device complies with Industry Canada RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of

the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio RSS-210. L’exploitation est autorisée aux deux conditions suivantes :

(1) l’appareil ne doit pas produire de brouillage, et

(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d’en compromettre le fonctionnement.

These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. These devices may not cause harmful interferences;

2. These devices must accept any interference received, including interference that may cause undesired operation.

The following figures list the Grant by FCC ID Number for each of the following devices:

FCC ID: ZLCPENSOLIDUFX

Please refer to the FCC’s website ( http://www.fcc.gov/ ) to view the grant and related documentation.

CAUTION ! Exposure to Radio Frequency Radiation. The radiated output of this device is far below the FCC radio

frequency exposure limits. Nevertheless, the device shall be used in such a manner that the potential for human contact during normal operation is minimized. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8inches) during normal operation. These devices may not be co-located with any other transmitter or transmitter antenna.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferences when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Changes or modifications not expressly approved by Microsensys GmbH could void the user’s authority to operate the equipment described in the manual. This device contains Bluetooth™ module FCC ID: QOQWT12.

User Manual

FCC compliance statement

IC compliance statement

iID®PENsolid UHF

(1) ON/OFF button

(3) rechargeable battery state LED (orange)

(4) Bluetooth™ state LED (blue)

(2) SCANbutton

(5)(6) Green and red operation state LED

Focused RFID antenna, main RF field direction

Micro-USB connector Hole for hand strap, clip

Touch tip

User Manual

Performance description

iID® PENsolid is suitable for mobile data capture and wireless RFID read / write applications, which can be connected via its integrated USB interface to PCs. The BluetoothTM-Interface is suitable to connect to smart phones, tablet computers or laptops.

Based on iID® SPC functionality, scripts can be used for definition of LED, buzzer and button support as well as communication functionalities as RF, USB and Bluetooth™.

iID® PENsolid is a battery powered device, which can be recharged using the micro USB interface. Battery cycles may vary from some hours to several days depending on the device configuration. When the device is connected via it’s USB interface, the device is powered by USB power.

The device is available in several types supporting HF as well as UHF systems suitable for closed coupling communication with very small sized up to large RFID transponders. Additionally all devices support TELID® sensor transponder applications.

First commissioning

Before using your device the first time, please charge the internal rechargeable battery using included micro USB cable.

iID®PENsolid UHF

Functionality

Operation mode

configuration

Interface

Remark

Read/write interface

DOC

USB

Bi-directional USB communication, based on iID® driver engine, device configuration

Bluetooth™ HID (human interface device / keyboard mode)

SPC

Bluetooth™ HID

Uni-directional communication, script with output functionality on device

Button

Functionality

(1) ON/OFF

Power on device, power off device when pressed for 3 seconds

(2) SCAN button

Perform scan (while device in SPC mode)

(1) and (2)

Keep holding (1) and (2) while device is off until lights come up will switch on device and perform Bluetooth™ reset.

User Manual

Manner of functioning

iID® PENsolid may be used as RFID read/write device with USB- or Bluetooth™ interface or RFID scanner using the integrated scan button. See following table for available configurations, for further information see iID® SPC/MPC related documents.

iID® PENsolid is delivered in SPC/HID mode. Please adjust operation mode connecting to a PC via USB interface. Using iID® interface configuration tool you may configure the device according your requirements before first usage. Microsensys provides sample scripts for device usage in SPC mode, which are available for download in iID® interface configuration tool.

iID® PENsolid buttons support following functionalities:

iID®PENsolid UHF

Operation

mode

Platform

Software

DOC

Windows 32/64 (without RT)

iID® software package including iID® driver engine, optional iID® tray application (http://www.microsensys.de/downloads/CDContent/Install/iID%c2%ae%20tray

%20application.zip)

Windows Mobile, Windows embedded handheld

iID® driver engine, iID® DEMOsoft (http://www.microsensys.de/downloads/CDContent/Install/RFIDDriver/Window

s/iID3000PRO/, http://www.microsensys.de/downloads/CDContent/Install/iID%c2%ae%20DEM Osoft/Windows/Mobile/RFID-Demo%20iID%20driver%20engine.CAB )

, optional iID® trigger scan (http://www.microsensys.de/downloads/CDContent/Install/iID%c2%ae%20tray

%20application/iID%c2%ae%20TriggerScan%20Mobile/iID%20TriggerScan.C AB )

Android

iID® Android DEMOsoft (http://www.microsensys.de/downloads/CDContent/Install/iID%c2%ae%20DE

MOsoft/Android/ )

SPC (Bluetooth™

HID)

All platforms (Windows, Android, iOS)

No further software required

User Manual

Software to be installed

Please download and install iID® software package including iID® DEMOsoft 2013, iID® interface config tool and iID® connection tool as well as iID® driver engine from:

http://www.microsensys.de/downloads/CDContent/Install/Setup%20iID%c2%ae%20software%20package.exe

Device configuration is possible using iID® interface configuration tool running on Windows PC environment

- via BT connection as well as USB interface. For using USB interface you may also need to install the USB driver, which is available at

http://www.microsensys.de/downloads/CDContent/USBDriver/Microsensys%20USB%20devices%20driver%20CDM%2 0v2.12.16%20WHQL%20Certified.zip

Depending on operation mode (see “manner of functioning”) and platform installation of further software

may be required:

Further microsensys product related software is located here: http:// microsensys.de/downloads/CDContent/.

iID®PENsolid UHF

Symbol

Description

(3=ORANGE)

OFF = battery good, BLINK = low charge, ON = USB charging

(4=BLUE)

BLINK = Bluetooth™ connection not established, ON = Bluetooth™ connection established

(5) operation state LED (GREEN)

In DOC mode automatic RF state visualization, in SPC mode free programmable

(6) operation state LED (RED)

In DOC mode automatic RF state visualization, in SPC mode free programmable

(5) & (6)

Blinking while POWER_ON or POWER_OFF

User Manual

Signs & their meaning

iID® PENsolid LEDs are used to show operation state. Additionally there are device states shown as described below.

Safety instructions

 The device may only be used for the intended purpose designed by for the manufacturer.  Unauthorized changes and the use of spare parts and additional devices which have not

been sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such unauthorized measures shall exclude any liability by the manufacturer.

 The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are

valid for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors, or omissions in the manual or automatically set parameters for a device or for an incorrect application of a device.

 Repairs may only be executed by the manufacturer.  Installation, operation, and maintenance procedures should only be carried out by

qualified personnel.

 Use of the device and its installation must be in accordance with national legal

requirements and local electrical codes.

 When working on devices the valid safety regulations must be observed.

iID®PENsolid UHF

Parameter

Description

Housing

Material

Plastic case

Dimension

117mm x 27mm x 19(23)mm

2 buttons

Power supply

USB (power supply)

micro USB female, 5V +/- 5%, ripple <50mV

Battery

Lithium polymer battery, 3.7V, 420mAh

Current consumption

Sleep mode

typ. 5μA

Idle mode

typ. 60mA

Active mode

max. 400mA

RFID Interface

Carrier frequency

EU 868 / US 915MHz

Implemented standards

ISO18000-6c

RF output power

24dBm

Antenna

P3U

Operating distance

0 ... 30cm (depending on transponder type and environmental conditions)

Additional interfaces

Bluetooth interface

Bluetooth™ 2.0

USB interface

USB 2.0

Operation modes

DOC

Direct online communication, serial communication or iID® driver engine or iID® Android driver engine

SPC

Script programmed communication, HID communication or serial communication or iID® driver engine or iID® Android driver engine

User Manual

Technical data

Following table contains general technical data.

iID®PENsolid UHF

User Manual

Equipment delivered:

1 x iID®PENsolid

Including following Accessories:

1 x Hand strap 1 x USB cable 1 x CD-ROM (Software & Documents)

Standard accessories:

USB cable Hand strap

Complementary microsensys Documents

Technical Datasheets: PENsolid-HF xxx.pdf, PENsolid-UHF xxx.pdf Product or System Documentation: DOC-iID SPC 01D.pdf, Quick-iID MPC 01D.pdf

Contact/Copyright

Micro-Sensys GmbH • In der Hochstedter Ecke 2 • 99098 Erfurt • Germany phone: +49 (0) 3 61 5 98 74-0 fax: +49 (0) 3 61 5 98 74-17 e-mail: info@microsensys.de web: www.microsensys.de

Any reproduction of this short manual in whole or in part, the storage in electronic media and the translation into foreign languages without the written permission of microsensys GmbH is forbidden.
