PoE Injector IEEE 802.3at for
10/100/1000BaseT
User Manual
MS400934

Content
Overview ...................................................................... 1
Features ....................................................................... 2
Hardware Description .................................................. 3
Package Contents ....................................................... 4
Installation .................................................................... 5
Technical Specifications .............................................. 6

Overview
The Power over Ethernet Injector provides data and AC power through the
Ethernet cable to PoE-equipped device, such as AP, PoE splitter or other
equipments support IEEE 802.3at. The injector is typically installed near
the Ethernet hub/switch. The following figure shows the Power over
Ethernet Injector application.
Application for Power over Ethernet Injection
1

Features
Power over Ethernet Injector for 10/100/1000BaseT
Remote power feeding
Overload and short circuit protection
Mixes Ethernet and power into RJ-45 port
Delivers power up to 100 meters
Light weight and compact size
Plug-and-Play
IEEE802.3at compliant
2

Hardware Description
The Power over Ethernet Injector has two RJ-45 ports and one AC input
connector
.
Data In port: It is an RJ-45 Ethernet port through which data transmit
into the PoE Injector.
Data Out port: It is an RJ-45 Ethernet port which provides power and
forward data to PoE Splitter, PD, or PoE Hub via an RJ-45 cable.
DATA IN/OUT
Power In Connector: The Power In connector is for supplying the
power into the Injector.
AC Power Input
3

Package Contents
One Power over Ethernet Injector
Power Cord
User Manual
Compare the contents of your Power over Ethernet Injector package with
the standard checklist above. If any item is missing or damaged, please
contact your local dealer for service.
4

Installation
To install the Power over Ethernet Injector, please follow the steps below:
1. Connect one end of the RJ-45 cable to the Switch/HUB and connect
the other end to the Data in port on the Power over Ethernet Injector.
2. Connect the RJ-45 cable between the Data out port of the injector and
the PoE Splitter, PD (Such as Router, Access Point…etc.) or PoE Hub.
3. Plug in the power cord of the Power over Ethernet Injector to the wall
power plug.
4. Before starting, make sure all connections are correct:
The Power over Ethernet Injector connects to the Splitter, POE
Hub or PD via Data Out port.
The Power over Ethernet Injector connects to the switch via Data
In port.
The AC In connector is to get the power supply to Power over
Ethernet Injector from wall power plug.
5

IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3ab 1000Base-T
IEEE802.3at Power over Ethernet
10/100/1000 Mbps:
Data in: 1 x RJ-45 Data pin 1, 2, 3, 6, 4, 5, 7, 8
Data & Power out: 1 x RJ-45
Data pin 1, 2, 3, 6, 4, 5, 7, 8
Power pin 1, 2, 3, 6
10BASE-T: 2-pair UTP/STP Cat.3, 4,5 cable
EIA/TIA-568 100-ohm (100m)
100BASE-TX: 2-pair UTP/STP Cat.5 cable
(Cat. 5e recommended)
EIA/TIA-568 100-ohm (100m)
1000Base-T: 4-pair UTP/STP Cat. 5e or above
cable
EIA/TIA-568 100-ohm (100m)
AC Input Voltage Range : 100 ~ 240V
AC
50 ~ 60 Hz, 0.72A
10% ~ 90% Humidity (non-condensing)
Technical Specifications
The following table provides the technical specification of the Power over
Ethernet Injector.
6

65mm x 140mm x 36mm (W x D x H)
