Page 1
VSC8502
User Guide
VSC8502 Evaluation Board
January 2019
Page 2
VSC8502 Evaluation Board
Contents
1 Revision History ............................................................................................................................. 1
1.1 Revision 1.1 ........................................................................................................................................ 1
1.2 Revision 1.0 ........................................................................................................................................ 1
2 Introduction ................................................................................................................................... 2
3 General Description ....................................................................................................................... 4
3.1 Key Features ....................................................................................................................................... 4
3.1.1 Copper Port RJ45 Connections ................................................................................................................ 4
3.1.2 External RefClk Option ............................................................................................................................ 6
3.1.3 Recovered Clocks .................................................................................................................................... 6
3.1.4 GMII loopback card ................................................................................................................................. 7
3.2 Key Features ....................................................................................................................................... 7
3.2.1 Single 3.3 V Input for Both DUT and Other Components ........................................................................ 8
3.2.2 DUT On-chip Regulator Power ................................................................................................................ 8
4 Quick Start ..................................................................................................................................... 9
4.1 Connecting the Power Supply ............................................................................................................ 9
4.2 PC Software Installation ..................................................................................................................... 9
4.3 Connecting to the Board to the PC ..................................................................................................... 9
4.3.1 Board Initialization ................................................................................................................................ 10
4.3.2 Copper Media Operation (Auto-negotiation Enabled) .......................................................................... 10
4.3.3 Driving Recovered Clock Output ........................................................................................................... 11
4.4 Useful Test Features ......................................................................................................................... 11
4.4.1 Ethernet Packet Generator ................................................................................................................... 11
4.4.2 Copper PHY Error Counters ................................................................................................................... 11
4.4.3 Near-End Loopback ............................................................................................................................... 11
4.4.4 Far-End Loopback .................................................................................................................................. 12
VPPD-03741 VSC8502 User Guide Revision 1.1
Page 3
VSC8502 Evaluation Board
1 Revision History
The revision history describes the changes that were implemented in this document. The changes are
listed by revision, starting with the most current publication.
1.1 Revision 1.1
Revision 1.1 of this datasheet was published in January 2019. The new Microchip template was added to
the document.
1.2 Revision 1.0
Revision 1.0 of this datasheet was published in May 2014. This was the first publication of the
document.
VPPD-03741 VSC8502 User Guide Revision 1.1 1
Page 4
VSC8502 Evaluation Board
2 Introduction
The VSC8502 device is a low-power, cost-optimized, dual-port gigabit Ethernet PHY. It features
integrated, line-side termination to conserve board space, lower EMI, and improved system
performance. To further reduce system complexity, component count, and system cost, the VSC8502
device can operate from a single 3.3 V supply using integrated voltage regulators. Additionally,
integrated RGMII timing compensation eliminates the need for on-board delay lines. The device also
optimizes power consumption in all link operating speeds and features Wake-on-LAN (WOL) power
management using magic packets.
This document describes the architecture and usage of the VSC8502 Evaluation Board (VSC8502EV). The
Quick Start section describes how to install and run the graphical user interface (GUI) to fully control the
evaluation board.
Figure 1 • VSC8514 Evaluation Board (Top View)
The following illustration shows the bottom view of the VSC8502 evaluation board.
VPPD-03741 VSC8502 User Guide Revision 1.1 2
Page 5
VSC8502 Evaluation Board
Figure 2 • VSC8514 Evaluation Board (Bottom View)
Additional VSC8502 collateral for both the VSC8502 device and VSC8502EV, including schematics,
layout, GUI, and application notes can be found on the VSC8502 product
web page at: .https://www.vitesse.com/products/product.php?number=VSC8502
VPPD-03741 VSC8502 User Guide Revision 1.1 3
Page 6
VSC8502 Evaluation Board
3 General Description
The evaluation board, shown in Figure 1, provides the user a way to evaluate the VSC8502 device in
multiple configurations. Two RJ-45 connectors are provided for copper media interfaces. The MAC
interface is exposed via SAMTEC connector (J1) that allows for the complete eval board to be mated
with a motherboard having the necessary signals for operating the device.
For standalone access to all of the features of the device, an external microcontroller is used to
configure the VSC8502 via the MDIO bus. The GUI enables the user to read and write device registers.
3.1 Key Features
This section shows the key features for VSC8502.
3.1.1 Copper Port RJ45 Connections
PHY ports 0 and 1 use generic RJ45 connectors with discrete pulse H5008NL magnetics.
GMII MAC Connector
The parallel MAC interface is available through a Samtec connector J1. As described in section 2.1.7, it
can be configured with the companion daughtercard installed at J1 as
either single-port loopback or port-port traffic passing modes.
Switch Block Control
See Figure 3 for definition of SW1 controls.
See Figure 4 for the default settings.
Table 1 • DIP Switch 1 Options
DUT Control Signal DIP SW1 pos ’1’ = pull up to VDDMAC; pos ‘0’ = pull down to GND
REFCLK_SEL SW1.1 0=125 MHz (default); 1 =25 MHz
REGEN_10 SW1.2 0=OFF (default); 1= ON
REGEN_25 SW1.3 0=OFF (default); 1= ON
RESERVED3/CLK_SQUELCH_IN SW1.4 1=enabled(default); 0 = disabled
NRESET SW1.5 1=operational (default); 0=held in reset
COMA_MODE SW1.6 0=disabled (default); 1=enabled
The following image shows the SW1 switch control for the VSC8502EV.
VPPD-03741 VSC8502 User Guide Revision 1.1 4
Page 7
VSC8502 Evaluation Board
Figure 3 • SW1 Switch Control
The following table shows the DIP switch options for the VSC8502 evaluation board.
Table 2 • DIP Switch 2 Options
DUT Control Signal DIP SW1 pos ’1’ = pull up to VDDMAC; pos ‘0’ = pull down to GND
RCVRDCLK1/PHYADD1 SW1.1 0=default
RCVRDCLK2/PHYADD2 SW1.2 0=default
PHYADD3 SW1.3 0=default
PHYADD4 SW1.4 0=default
Note: R17 and R18 0 ohm options must be installed for PHYADD1 and PHYADD2 to be affected by SW2,
otherwise they are internally pulled to GND. Also, PHYADD3-4 pins
are internal PD on the VSC8502 IC, and are weakly pulled to GND when their corresponding SW2 pins
are kept in ‘0’ position.
Figure 4 • SW2 Switch Control
VPPD-03741 VSC8502 User Guide Revision 1.1 5
Page 8
VSC8502 Evaluation Board
3.1.2 External RefClk Option
The user may choose to provide an external PHY REFCLK via SMA connection to J8 (as shown in Figure
1). To route the SMA signal to the device the user must reorient the
zero ohm resistor R25, as shown from the PCB layout view in Figure 7.
Note: external PHY REFCLK must be connected via SMA to J8 if 3.3 V VDDIO/VDDMAC is used, since the
on-board crystal oscillator (U5) is a 2.5 V CMOS driver.
R25 can also be connected across pins 1 and 2 if a user wants to provide DUT REFCLK input from the
Samtec connector J1.
Figure 5 • REFCLK Input Options - R25 3-Way Orientation
3.1.3 Recovered Clocks
There are two recovered clocks available from the VSC8502, through SMA connections J5 (RCVRDCLK1)
and J6 (RCVRDCLK2). In the default configuration, CLK_SQUELCH_IN
is pulled down, which disables the clock squelching and RCVRDCLK1/RCVRDCLK2 are connected to the
Samtech header J1. To route RCVRDCLK1 and RCVRDCLK2 to SMAs
J5 and J6, reorient zero ohm resistors R21 and R23, respectively.
Software Interface Microcontroller Card
A Silabs F340 microcontroller is included to facilitate a software interface to the registers on the
VSC8502 through a USB port.
Note: Alternatively, a Rabbit card is available for an IP-based manager of the PHY register space,
installed in the keep-out area (U6) of the board’s top-side. Or, MDC
and MDIO can be accessed on stake header J10 if desired for another microcontroller to host the PHY
register space.
VPPD-03741 VSC8502 User Guide Revision 1.1 6
Page 9
VSC8502 Evaluation Board
3.1.4 GMII loopback card
The VSC8502EV ships with a daughter card that mounts to J1 to loop-back the GMII/RGMII interface.
As shown in Figure 8 and Figure 9 below, one orientation of the loopback card will loop each port back
to itself (IN-CHANNEL LOOPBACK in Figure 8). The other orientation
forwards bidirectional traffic from one port to the other (CHANNEL TO CHANNEL LOOPBACK).
Figure 6 • Loopback Card (Side A)
Figure 7 • Loopback Card (Side B)
Note: this daughter card loopback only supports 1000 BASE-T in GMII mode and 10/100/1000 in RGMII
mode. It will not support 10/100 in MII mode.
However, there are other internal loopback modes that will support BER testing of MII mode such as farend loopback (MII Register 23.3).
3.2 Key Features
This section shows the power supply options for VSC8502.
VPPD-03741 VSC8502 User Guide Revision 1.1 7
Page 10
VSC8502 Evaluation Board
3.2.1 Single 3.3 V Input for Both DUT and Other Components
This option allows for one external 3.3 V supply connected to J11 to power everything on the board. Use
the following steps:
SW1 REGEN1V0 = REGEN2V5 = 0: disable on-chip regulators
Insert a 3.3 V DC supply (rated for 1 Amp) into J11
Unplug banana connectors J16(+): J17(GND)
Unplug banana connectors J19(+): J20(GND)
Populate J23: 3V3_DUT = 3V3_MAIN
Populate J15: 2V5_DUT = 2V5
Populate J26: VDD25A = 2V5_DUT
Remove J18: on-board 3.3 V to 2.5 V regulator enabled
Populate J25: VDD1 = 1V0
Remove J12: on-board 3.3 V to 1.0 V regulator enabled
Populate J24: VDDMAC = 3V3_DUT or 2V5_DUT (VDDMAC is tied to VDDIO. The DUT’s VDDIO can
operate at either 2.5 V or 3.3 V)
Populate J9: VDDMDIO = VDDIO (1.2 V option is not available at this time, due to inability to drive
1.2 V from on-board microcontroller options)
DUT Power Rails Isolated from non-DUT Power
This option allows for the DUT power supplies to be isolated from the rest of the board power. Use the
following steps:
SW1 REGEN1V0 = REGEN2V5 = 0: disable on-chip regulators
Insert a 3.3 V DC supply (rated for 1 Amp) into J11
Populate banana jacks J13(+): J14(GND) with 3.3 V supply
Populate banana jacks J16(+): J17(GND) with 2.5 V supply
Populate banana jacks J19(+): J20(GND) with 1.0 V supply
Remove J23: 3V3_DUT = J13 (3.3 V)
Remove J15: 2V5_DUT = J16 (2.5 V)
Populate J26: VDD25A = 2V5_DUT
Remove J18: on-board 3.3 V to 2.5 V regulator enabled
Populate J25: VDD1 = 1V0 (note: 1V0 = J19)
Populate J12: on-board 3.3 V to 1.0 V regulator disabled
Populate J24: VDDMAC = 3V3_DUT or 2V5_DUT (VDDMAC is tied to VDDIO. The DUT’s VDDIO can
operate at either 2.5 V or 3.3 V)
Populate J9: VDDMDIO = VDDIO (1.2 V option is not available at this time, due to inability to drive
1.2 V from on-board microcontroller options)
3.2.2 DUT On-chip Regulator Power
The on-chip regulator option for this board is for engineering purposes only. There are performance
issues associated with using the on-chip regulator on this board, so it is
an unsupported board feature.
VPPD-03741 VSC8502 User Guide Revision 1.1 8
Page 11
VSC8502 Evaluation Board
1.
2.
3.
4.
4 Quick Start
This section shows the quick start for VSC8502.
4.1 Connecting the Power Supply
The evaluation board offers choices of how to power the 3.3 V, 2.5 V, and 1.0 V rails which drive the
devices as well as modules; please see section 2.2 for reference. The simplest power option for the
evaluation board is to use the power pack for 3.3 VDC. Simply plug the AC adaptor into a wall socket and
the barrel end into J11 (see the upper left corner of Figure 1). Immediately the user should see several
LEDs turn on.
Note: for proper power-on sequencing on this board, please toggle NRESET input to the DUT using
either SW3 (push-button) or SW1 (DIP) after board power is applied but prior to launching the GUI.
4.2 PC Software Installation
Download the ZIP file from Vitesse’s website onto a PC that has a USB port
Install the GUI by launching the setup.exe file
USB communication is assisted by the Silabs USBXpress® drive. If not present on the PC, the user will
need to download the
USBXpress development kit from the Silicon Labs website (URL: http://www.silabs.com/products
)/mcu/Pages/USBXpress.aspx
Double click the desktop icon to launch the GUI
4.3 Connecting to the Board to the PC
Launch the GUI either by clicking on the desktop shortcut or clicking on the “Star t> Programs > Vitesse
Semiconductor Corp > VSC8502_GUI” icon. The initial window will detect the attached USB devices
automatically. Figure 10 shows a typical EVB Connection window.
Figure 8 • GUI Connection Window
The EVB serial number should appear. If not, click on “Scan For USB Devices.” Select that EVB serial
number then click “Launch GUI”. The Register List window will appear as shown in Figure 11.
VPPD-03741 VSC8502 User Guide Revision 1.1 9
Page 12
VSC8502 Evaluation Board
Figure 9 • MII Registers GUI Window
Be sure the device is up and running by reading MII Register 0. It should read back 0 × 1040. Reading
back all 0’s or all 1’s indicates a problem. For a multi-port device, the corresponding PHY port number is
accessed via the “Port:” pick list shown above the Register Description in Figure 11.
As Figure 11 indicates, the extended MII register pages can be accessed to read or write by clicking on
one of the ExtMII/Ext2MII/ExtGMII tabs.
4.3.1 Board Initialization
Note: if J1 is used for an evaluation session, the SAMTEC connector J1 should be populated prior to
power-on of the board (for example, with the companion GMII loopback card show in section 2.1.7 for a
desired external loopback mode). Once the evaluation board connectivity has been established and
confirmed, the PHY should be initialized. Initialization can be accomplished by running an init-script
sequence, such as performed by the pre- and post-reset functions of the PHY API standalone app.
While the init-script sequence may not be required for specific operational modes, an init-script
sequence is highly recommended to ensure correct performance over the greatest set of user scenarios
for the PHY. After initialization is performed, refer to the PHY Datasheet section on configuring the PHY
and PHY Interfaces for the desired application.
4.3.2 Copper Media Operation (Auto-negotiation Enabled)
The easiest configuration for passing traffic is with Autoneg enabled (MII 0 bit 12 = 1). Use MII Register
0, 4 and 9 to change speed and restart autoneg (MII 0 bit 9) to advertise new settings. As per the
datasheet descriptions, the commonly-used speed advertisement definitions are as follows:
Table 3 • Auto-Negotiation Advertisements
VPPD-03741 VSC8502 User Guide Revision 1.1 10
Page 13
VSC8502 Evaluation Board
1.
2.
3.
4.
MII reg 4
bits 8:7
MII reg 4
bits 6:5
MII reg 9
bits 12:11
MII reg 9
bits 9:8
1000BT Master mode N/A N/A 11 11
1000BT Slave mode N/A N/A 10 11
100 BASE-TX Full Duplex 11 N/A N/A 00
10 BASE-T Full Duplex 00 11 N/A 00
The following steps are used to configure a link:
Set up the Copper traffic source (i.e., IXIA or Smartbits)
Connect Ethernet cable(s) to a single or multiple RJ-45 ports
Configure auto-negotiation as per above and re-start ANEG (MII bit 0.12)
The linkup bit is in MII Reg 1, bit 2 (MII 1.2), read it twice to update
Traffic should now be flowing.
4.3.3 Driving Recovered Clock Output
To output the a recovered clock from the PHY on this evaluation board, ensure zeroohm resistors R21
and R23 are oriented as per section 2.1.5 and perform the following register writes to enable
RCVRDCLK1 with PHY0 as the clock source:
Write 0×8101 to register 23 of the “General Purpose Registers” when PHY0’s link is up in a non-EEE
mode and not 1000BT master or 10BT
Set MII Register bit 9.12 to enable manual slave configuration then issue an auto negotiation restart
through register bit 0.9
To select a different port as the clock source or enable a recovered clock for EEE mode, refer to register
23 G/24 G in the datasheet for the programming detail.
Note: The recovered clock output is intended to drive a CMOS load, not a DCcoupled low impedance
such as a scope 50-Ohm termination. The recommended measurement equipment is an active (highimpedance) differential probe. Refer to the device datasheet for additional loading and performance
specifications.
4.4 Useful Test Features
4.4.1 Ethernet Packet Generator
ExtMII 29E is the Ethernet Packet Generator register. The EPG sends traffic in multiple of 10,000 frames
regardless of when you stop transmit activity. Refer to the datasheet for configuration options.
A good CRC packet counter is in ExtMII 18.13:0. The good CRC packet counter is a modulo 10,000
counter so values will always be between 0-9,999. A read of the register reads back the good CRC
packets and then clears the register so the subsequent reads will be 0 if no traffic has been received. If
traffic has been received since the last read, bit 15 will be set.
4.4.2 Copper PHY Error Counters
Idle errors = MII 10.7:0
RX errors = MII 19.7:0
False carrier = MII 20.7:0
Disconnects = MII 21.7:0
CRC errors = ExtMII 23.7:0
4.4.3 Near-End Loopback
When the near-end loopback test feature is enabled, the transmitted data is looped back in the PCS
block on the receive data signals. To enable the loopback, set register bit 0.14 to 1. Near-end loopback
mode involves traffic flow over the GMII/RGMII interface, so a breakout of the MAC interface on
SAMTEC connector J1 must be connected to another system for this mode to pass traffic.
VPPD-03741 VSC8502 User Guide Revision 1.1 11
Page 14
VSC8502 Evaluation Board
SAMTEC connector J1 must be connected to another system for this mode to pass traffic.
4.4.4 Far-End Loopback
When the far-end loopback test feature is enabled, incoming data from a link partner on the Copper
interface to be transmitted back to the link partner on the Copper interface. To enable the loopback, set
register bit 23.3 to 1.
VPPD-03741 VSC8502 User Guide Revision 1.1 12
Page 15
VSC8502 Evaluation Board
Microsemi Headquarters
One Enterprise, Aliso Viejo,
CA 92656 USA
Within the USA: +1 (800) 713-4113
Outside the USA: +1 (949) 380-6100
Sales: +1 (949) 380-6136
Fax: +1 (949) 215-4996
Email: sales.support@microsemi.com
www.microsemi.com
© Microsemi. All rights reserved. Microsemi and the Microsemi logo are
trademarks of Microsemi Corporation. All other trademarks and service
marks are the property of their respective owners.
Microsemi makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its products and s ervices
for any particular purpose, nor does Microsemi assume a ny liability whatsoever arising out of the app lication or use of any product or circuit. The
products sold hereunder and an y other products sold by Microsemi have been s ubject to limited testing and should not be us ed in conjunction with
mission-critical equipment or applications. Any performance specifications are believed to be reliable but are not verified, and Buyer must condu ct and
complete all performance and other testing of the products, alone and together with, or installed in , any end-products. Buyer shall not rely on any data
and per formance specifications or para meters provided by Microsemi. It is the Buyer's responsibility to ind ependently determine suitability of any
products and to test and verify the same. The information provided by Microsemi hereunder is provided "as is, where is" and with all faults, and the
entire risk associated with such information is entirely with the Buyer. Microsemi does not grant, explicitly or implicitly, to any party any patent rights,
licenses, or any other IP rights, whether with regard to such information itself or anything described by such information. Information provided in this
document is proprietar y to Microsemi, and Micr osemi reserves the right to make any changes to the information in this document or to any products
and services at any time without notice.
Microsemi, a wholly owned subsidi ary of Microchip Technology Inc. (Nasdaq: MCHP), offers a comprehensive portfolio of semiconductor and system
solutions for aerospace & defense, communications, data center and industrial markets. Products include high-performance and radiation-hardened
analog m ixed-signal integrated circuits, FPG As, SoCs and ASICs; power management products; timing and synchronization devices and p recise time
solutions, setting the world's standard for time; voice processing devices; RF solutions; discrete components; enterprise storage and communica tion
solutions; security technologies and scalable anti-tamper products; Ethernet solutions; Power-over-Ethernet ICs and midspans; as well as custom design
capabilities and services. Microsemi i s headquartered in Aliso Viejo, California, and has approxim ately 4,800 employees globally. Learn more at www.
microsemi.com.
VPPD-03741
VPPD-03741 VSC8502 User Guide Revision 1.1 13
Loading...
